30 INCH DRUM FAN

MODEL NO: CAM30110V

PART NO: 3231569

OPERATION & MAINTENANCE

INSTRUCTIONS

ORIGINAL INSTRUCTIONS GC0521

INTRODUCTION

Thank you for purchasing this CLARKE 30” Drum Fan.

Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.

SPECIFICATIONS

MODEL CAM30110V

Part No: 3231569

Voltage: 110 V~ (50Hz)

Ingress Protection Rating IP20

Insulation Class 1

Fan Power Input 115.8 W

Duty Cycle S1 (continuous)

Fan Speeds

Position 1 850 rpm

Position 2 922 rpm

Standby Power Consumption N/A

Fan Sound Power Level 77 dB(A)

Sound Power Measured 83.3 dB(A) L

Wa

Guaranteed Sound Level 85.8 dB Lwa

Maximum Fan Flow Rate

264 m

3

/m

Maximum Air Velocity 2.3 m/sec

Service Value

2.5 m

3

/m/W

Measurement Standard for Service Value EU 206/2012

Dimensions (D x W x H) mm 835 x 300 x 845

Weight: 19 kg

2

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

ELECTRICAL CONNECTIONS

Plug must be BS60309 approved.

Neutral

Live

Earth

WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS
THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE
POWER SUPPLY.

Before switching the product on, make sure that the voltage of your electricity
supply is the same as that indicated on the rating plate. Connecting it to any
other power source may cause damage.

If the plug has to be changed due to damage, a replacement should be
fitted, following the wiring instructions shown below. The old plug must be
disposed of as insertion into a 110v socket could cause an electrical hazard.

WARNING: THE WIRES IN THE POWER CABLE OF THIS PRODUCT ARE
COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:
BLUE = NEUTRAL BROWN = LIVE YELLOW = EARTH

If the colours of the wires in the power cable of this product do not correspond
with the markings on the terminals of your plug, proceed as follows.

•The Blue wire must be
connected to the
terminal which is
marked N or Neutral.

•The Brown wire must
be connected to the
terminal which is
marked L or Live.

•The Yellow wire must
be connected to the
terminal which is
marked E or Earth.

If in any doubt, consult a
qualified electrician. DO
NOT attempt any repairs
yourself.

3

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

SAFETY PRECAUTIONS

1. ALWAYS read the manual before use.

2. Suitable for indoor use only.

3. Avoid using in dusty environments.

4. DO NOT use in environments containing chemical fumes etc.

5. DO NOT use as an extractor fan.

6. DO NOT use in areas of high humidity/water vapour, i.e. bathrooms etc.

7. DO NOT connect the fan to duct system.

8. DO NOT cover the fan with clothing or any material that will restrict free
airflow through the fan.

9. NEVER touch the blades with your hand or any loose object.

10. ALWAYS unplug the fan before moving it or performing maintenance.

11. DO NOT touch the fan when your hands are wet.

12. ALWAYS unplug the fan when it is not in use.

13. NEVER unplug the fan by holding the cable. Unplug by holding the plug.

14. NEVER use the fan if the cable or plug are damaged.

15. NEVER use the fan close to fires.

16. DO NOT use this fan with any solid-state speed control device to reduce
the risk of fire or electric shock.

17. Those who are not qualified electricians should not disassemble or repair
this product.

ENVIRONMENTAL RECYCLING POLICY

Through purchase of this product, the customer is taking on the
obligation to deal with the WEEE in accordance with the WEEE
regulations in relation to the treatment, recycling & recovery and
environmentally sound disposal of the WEEE.

In effect, this means that this product must not be disposed of with general
household waste. It must be disposed of according to the laws governing
Waste Electrical and Electronic Equipment (WEEE) at a recognised disposal
facility.

4

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

OPERATION

Turn the switch on the speed
regulator to select the fan speed
required.

CAM30110v

Position 1 850 RPM

Position 2 922 RPM

MAINTENANCE

WARNING: NEVER OPERATE THE FAN WITH THE FRONT OR REAR GUARDS
REMOVED.

Have any repairs carried out by a suitably qualified person.

• The motor bearings are permanently sealed for life and do not

require any additional lubrication.

If the fan has been operating for long periods in a very dusty environment, the
blades and motor assembly may eventually require cleaning.

1. Disconnect the power cable from the power supply.

2. Unscrew the front guard and lift it
away carefully.

3. Wipe the fan blades with dry cloth
and remove any dust from the
motor assembly with a soft
paintbrush, vacuum cleaner or jet
of compressed air.

• Always wear suitable eye

protection when using
compressed air.

• Never use polish or any corrosive liquid that will damage the surface

finish.

4. Replace the guard securely before use.

5

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

PARTS LIST AND DIAGRAM

N

O

DESCRIPTION

1Front Grill 8Switch Knob

2 Blade Assembly 9 Fan Motor

3 Handle 10 Rear Grill

4. Drum Body 11 Power Cable

5 Capacitor 12 Wheel & Stub Axle

6Switch 13Feet

7 Switch Box 14 Axle Support

NO

DESCRIPTION

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for its intended purpose.

Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission. This guarantee does not effect your
statutory rights.

6

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

DECLARATIONS OF CONFORMITY
