Page 1
WOOD RACK
MODEL NO: CWR1
PART NO: 3402060
ASSEMBLY INSTRUCTIONS
LS0411
Page 2
INTRODUCTION
Thank you for purchasing this Wood Rack.
Please read this manual thoroughly, and carefully follow all instructions.
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt as proof of purchase.
This guarantee is invalid if the product is found to have been abused or tampered with
in any way, or not used for the purpose for which it was intended.
Faulty goods should be returned to their place of purchase, no product can be
returned to us without prior permission.
This guarantee does not effect your statutory rights.
SPECIFICATIONS
Maximum Load 100 kg
Dimensions W x H x D 1330 x 1300 x 295 mm
PARTS
Side Rails x 2 Front Rails x 2
Connecting Strip x 2 M8 x 75 Bolts x 8
Washers x 8 M8 Nut x 8
2
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
Page 3
ASSEMBLY
1. Stand one of the side rails up
and place the two front rails
in position as shown.
2. Pass a bolt through each end
of the connecting strip then
through the higher of the two
holes in the side rail and front
rail as shown.
• Secure the bolt in place
using a washer and nut
supplied.
3. Pass a bolt through the lower
of the two holes in the side
rail and front rail as shown.
4. Position the second side rail
at the other end of the front
rails and repeat steps 2 and 3 for this end of the wood rack.
WARNINGS
• Do not overload the wood rack (Maximum 100 kg).
• Make sure all bolts are secure before using the wood rack.
• Do not use the wood rack to lift yourself up.
3
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
