Clarion SR5000 User Manual
MMooddeell SSRR55000000
➤
OOwwnneerr’’ss GGuuiiddee
lliimmiitteedd lliiffeettiimmee ccoonnssuummeerr wwaarrrraannttyy
This Ungo Pro Security system is warranted against defects in material and workmanship.
The main unit is covered by this limited lifetime warranty. This Limited Lifetime
Warranty applies to Ungo Pro Security systems that have been installed by an authorized
Ungo Pro Security dealer. This warranty is to the Original Purchaser ("Owner") and to
the original vehicle in which it was installed into. This warranty is not transferable to any
subsequent owner(s) of the product(s).
WWaarrrraannttyy PPrrooggrraamm::
Main Unit Limited Lifetime
Remote Controls One year from date of purchase
Siren One year from date of purchase
Shock Sensor One year from date of purchase
LED One year from date of purchase
Override Switch One year from date of purchase
The Warranty does not cover batteries or products deemed damaged through alterations
or installation. It also does not cover products mishandled, misused, neglected, abused,
water damaged, or with removed/altered serial numbers.
PROOF OF PURCHASE WILL BE REQUIRED FOR WARRANTY SERVICE OF
THIS PRODUCT.
This warranty does not cover the costs incurred for removal or reinstallation of the main
unit and/or any damage to the vehicle or the vehicle's electrical system.
The sole responsibility of Clarion Corporation of America ("Clarion") under this
Warranty shall be limited to the repair or replacement of the product, at the sole discretion of Clarion.
If it becomes necessary to send the product or any defective part to Clarion, the product
must be shipped in its original carton or equivalent carton, fully insured, with shipping
charges prepaid. Clarion will not assume any responsibility for any loss or damage
incurred in shipping.
ALL IMPLIED WARRANTIES EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE LAW SHALL HAVE NO GREATER DURATION THAN THE
WARRANTY PERIOD SET FORTH ABOVE. UNDER NO CIRCUMSTANCES
SHALL CLARION CORPORATION BE LIABLE FOR ANY LOSS OR DAMAGE,
DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE USE OR INABILITY
TO USE OF THE PRODUCT. BECAUSE SOME STATES DO NOT ALLOW LIMI-
i
ii
TATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR EXCLUSIONS
OR LIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, THE
ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY
ALSO HAVE THE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
Should you have any difficulties with the performance of this product during warranty,
please call: 1-800-GO-CLARION or visit your local Ungo Pro Security dealer. You may
also contact the National Service Manager at the following address below for additional
service help you may need.
Clarion Corporation of America
Attn: National Service Manager
661 W. Redondo Beach Blvd.
Gardena, Ca 90247
1
lliimmiitteedd lliiffeettiimmee ccoonnssuummeerr wwaarrrraannttyy.. .. .. .. .. ii
ttrraannsscceeiivveerr ddiiaaggrraamm .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 22
ssttaannddaarrdd ttrraannsscceeiivveerr ccoonnffiigguurraattiioonnss .. .. .. .. 33
wwhhaatt iiss iinncclluuddeedd .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 44
iimmppoorrttaanntt iinnffoorrmmaattiioonn .. .. .. .. .. .. .. .. .. .. .. .. .. .. 44
warning! safety first . . . . . . . . . . . .5
system maintenance . . . . . . . . . . .7
fcc/id notice . . . . . . . . . . . . . . . . .8
caution . . . . . . . . . . . . . . . . . . . . .8
ttrraannsscceeiivveerr ffuunnccttiioonnss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 88
standard button configurations . . .8
standard icon configurations . . . .10
function button configurations . .14
rreemmoottee ooppeerraattiioonn .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 1166
system signal paging features . . . .16
uussiinngg yyoouurr ssyysstteemm .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 1177
active arming . . . . . . . . . . . . . . . .17
passive arming . . . . . . . . . . . . . . .18
vehicle protection . . . . . . . . . . . .19
warning response description . . .20
triggered response description . . .20
arming/disarming while driving .22
remote sensor bypass . . . . . . . . . .23
disarming . . . . . . . . . . . . . . . . . .24
silence alarm without disarming .24
disarming without a transceiver
(emergency override) . . . . . . . . . .25
silent arm/disarm . . . . . . . . . . . .26
panic mode . . . . . . . . . . . . . . . . .27
override mode . . . . . . . . . . . . . . .27
remote engine start . . . . . . . . . . .28
override take-over . . . . . . . . . . . .31
setting the clock . . . . . . . . . . . . .31
temperature check mode . . . . . . .32
ssaaffeettyy ffeeaattuurreess.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 3333
starter anti-grind circuitry . . . . . .33
disabling the remote engine start
system . . . . . . . . . . . . . . . . . . . . .33
over and under rev protection . . .34
shut down inputs . . . . . . . . . . . .34
false alarm prevention circuitry . .34
ddiiaaggnnoossttiiccss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 3366
arming diagnostics . . . . . . . . . . .36
disarming diagnostics . . . . . . . . .36
system status chirps . . . . . . . . . . .37
table of zones . . . . . . . . . . . . . . .38
interpreting zone diagnostics . . . .38
aannttii--ccooddee ggrraabbbbiinngg .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 3399
iinnddiivviidduuaall rreeccooggnniittiioonn .. .. .. .. .. .. .. .. .. .. .. .. .. 4400
ppoowweerr--uupp .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 4411
ppoowweerr ssaavveerr mmooddee .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 4411
pprrooggrraammmmiinngg ooppttiioonnss .. .. .. .. .. .. .. .. .. .. .. .. .. 4422
sseeccuurriittyy && ccoonnvveenniieennccee eexxppaannssiioonnss .. .. .. 4455
gglloossssaarryy ooff tteerrmmss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 4466
ttaabbllee ooff ccoonntteennttss
2
ttrraannsscceeiivveerr ddiiaaggrraamm
3
10
12
13
19
1
29
27
25
23
21
31
2
8
5
7
6
14
11
17
18
16
9
22
20
28
26
24
30
15
4
3
ssttaannddaarrdd ttrraannsscceeiivveerr ccoonnffiigguurraattiioonnss
1 Vehicle Interior Temperature Indicator
2 Numeric Display
3 AM/PM Indicator
4 Alarm Clock Mode Indicator
5 Timer Function Indicator
6 Transmit Range Indicator
7 Transmission Indication
8 Vibrate/Beep Mode Indicator
9 Power Saver Mode Indicator
10 Remote Engine Start Timer Mode Indicator
11 No Function
12 No Function
13 Full Trigger Shock Sensor Indicator
14 Hood/Trunk Open or Trigger Indicator
15 Parking Light Indicator
16 Door Open or Trigger Indicator
17 Arm/Lock Button
18 Disarm/Unlock Button
19 Remote Engine Start Indicator
20 Hood/Trunk Open or Trigger Indicator
21 Panic Mode Button
22 Override Mode Indicator
23 Remote Start Neutral Safety Wire Shutdown
Indicator
24 Battery Level Indicator
25 Auxiliary Button
26 No Function
27 Silent Arm/Disarm Mode Indicator
28 Audible Chirp Indicator
29 Arm/Disarm Indicator
30 Function Button
31 Celsius/Fahrenheit Indicator
4
wwhhaatt iiss iinncclluuddeedd
➤ Control module
➤ A.S.K. Receiver
➤ One four-button two-way transceiver
➤ One four-button remote
➤ Two-stage shock sensor
➤ Six-tone programmable siren
➤ Red status LED indicator light
➤ Push-button override switch
➤ Your warranty registration
➤ Starter Kill
➤ Shut-down toggle switch
iimmppoorrttaanntt iinnffoorrmmaattiioonn
Congratulations on the purchase of your combination remote
engine start alarm system. Due to the complexity of this system,
it must only be installed by an authorized dealer. Installation of
this product by anyone other than an authorized dealer voids the
warranty.
By carefully reading this Owner's Guide prior to using your
system, you will maximize the use of this system and its features.
5
warning! safety first
The following safety warnings must be observed at all times:
➤ Due to the complexity of this system, installation of this product
must only be performed by an authorized dealer.
➤ When properly installed, this system can start the vehicle via
a command signal from the transceiver. Therefore, never
operate the system in an enclosed area or partially enclosed
area without ventilation (such as a garage). When parking in
an enclosed or partially enclosed area or when having the
vehicle serviced, the remote engine start system must be
disabled using the installed toggle switch. It is the user's sole
responsibility to properly handle and keep out of reach from
children all transceiver to assure that the system does not
unintentionally remote engine start the vehicle.
TTHHEE UUSSEERR
MMUUSSTT IINNSSTTAALLLL AA CCAARRBBOONN MMOONNOOXXIIDDEE
DDEETTEECCTTOORR IINN OORR AABBOOUUTT TTHHEE LLIIVVIINNGG AARREEAA
AADDJJAACCEENNTT TTOO TTHHEE VVEEHHIICCLLEE.. AALLLL DDOOOORRSS
LLEEAADDIINNGG FFRROOMM AADDJJAACCEENNTT LLIIVVIINNGG AARREEAASS TTOO
TTHHEE EENNCCLLOOSSEEDD OORR PPAARRTTIIAALLLLYY EENNCCLLOOSSEEDD
VVEEHHIICCLLEE SSTTOORRAAGGEE AARREEAA MMUUSSTT AATT AALLLL TTIIMMEESS
RREEMMAAIINN CCLLOOSSEEDD..
These precautions are the sole respon-
sibility of the user.
warning! THIS SYSTEM PROVIDES REMOTE NOTIFICATION OF SECURITY SYSTEM TRIGGER
EVENTS. CONTACT POLICE OR SECURITY PERSONNEL IMMEDIATELY. NEVER CONFRONT A
CAR THIEF OR VANDAL.
➜
6
➤ Use of this product in other than a fuel injected automatic
transmission vehicle is contrary to its intended mode of
operation may result in property damage, personal injury, or
death. (1) Never remotely start the vehicle with the vehicle
in gear, and (2) Never remotely start the vehicle with the
keys in the ignition. The user must also have the neutral
safety feature of the vehicle periodically checked, wherein
the vehicle must not remotely start while the car is in gear.
This testing should be performed by an authorized dealer in
accordance with the Safety Check outlined in the product
installation guide. If the vehicle starts in gear, cease remote
start operation immediately and consult with the authorized
dealer to fix the problem.
➤ After the remote start module has been installed, contact your
authorized dealer to have him or her test the remote start
module by performing the Safety Check outlined in the
product installation guide. If the vehicle starts when performing
the Neutral Safety Shutdown Circuit test, the remote start unit
has not been properly installed. The remote start module must
be removed or the installer must properly reinstall the remote
start system so that the vehicle does not start in gear. All instal-
lations must be performed by an authorized dealer.
OOPPEERRAA--
TTIIOONN OOFF TTHHEE RREEMMOOTTEE SSTTAARRTT MMOODDUULLEE IIFF TTHHEE
VVEEHHIICCLLEE SSTTAARRTTSS IINN GGEEAARR IISS CCOONNTTRRAARRYY TTOO IITTSS
IINNTTEENNDDEEDD MMOODDEE OOFF OOPPEERRAATTIIOONN.. OOPPEERRAATTIINNGG
TTHHEE RREEMMOOTTEE SSTTAARRTT SSYYSSTTEEMM UUNNDDEERR TTHHEESSEE
CCOONNDDIITTIIOONNSS MMAAYY RREESSUULLTT IINN PPRROOPPEERRTTYY DDAAMMAAGGEE
7
OORR PPEERRSSOONNAALL IINNJJUURRYY.. YYOOUU MMUUSSTT IIMMMMEEDDIIAATTEELLYY
CCEEAASSEE TTHHEE UUSSEE OOFF TTHHEE UUNNIITT AANNDD SSEEEEKK TTHHEE
AASSSSIISSTTAANNCCEE OOFF AANN AAUUTTHHOORRIIZZEEDD DDEEAALLEERR TTOO
RREEPPAAIIRR OORR DDIISSCCOONNNNEECCTT TTHHEE IINNSSTTAALLLLEEDD
RREEMMOOTTEE SSTTAARRTT MMOODDUULLEE.. UUNNGGOO WWIILLLL NNOOTT BBEE
HHEELLDD RREESSPPOONNSSIIBBLLEE OORR PPAAYY FFOORR IINNSSTTAALLLLAATTIIOONN
OORR RREEIINNSSTTAALLLLAATTIIOONN CCOOSSTTSS..
system maintenance
This system needs no specific maintenance beyond transceiver
battery replacement. The transceiver is powered by a 1.5V AAA
battery.
The Battery Level indicator has three level indicators that serve
as a visual indication of battery charge. When the battery reaches
a low charge level that requires replacement, the transceiver will
generate a single notification chirp, and the Battery Level indi-
cator will flash continuously.
Battery Replacement
Gently pull the battery cover release tab, then slide the door
down to expose the battery and remove the expired battery. Place
the new battery into the transceiver observing the correct
polarity. When power is returned the transceiver will light all
icons in the LCD and generate all beeper tones once.
➜
8
fcc/id notice
This device complies with Part 15 of FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesirable operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate this device.
caution
This product is designed for fuel-injected, automatic transmis-
sion vehicles only. Use of this product in a standard transmission
vehicle is dangerous and contrary the product's intended use.
ttrraannsscceeiivveerr ffuunnccttiioonnss
The transceiver buttons are used to send commands to the
system. The descriptions below reflect the standard configura-
tion for this system. The buttons can be custom configured for
the user’s specific needs by the installer.
standard button configurations
Button
The System Arm/Lock and Remote Sensor Bypass functions are
controlled by pressing this button for one second.
➜
➜
➜
9
Button
The System Disarm/Unlock and the capability to silence the
alarm without disarming. These functions are controlled by
pressing this button for one second.
Button
Channel 2 output is controlled by pressing this button for three seconds.
Hold the button down continuously while accessing Channel 2 output.
Button
The panic feature is controlled by pressing this button for two
seconds. Press again to disable panic mode.
Button
The LCD backlighting will turn on when pressed for less than one
second; when held for more than five seconds the transceiver will
enter adjustment mode allowing the setting of the clock, timer
mode, and audible melody selection. For more information, please
refer to the Function Button Configurations section of this guide.
and Buttons
The remote engine start function of the system is controlled by
pressing these buttons simultaneously for one second.
and Buttons
When pressed simultaneously these buttons activate remote
engine start timer mode, engaging the remote engine start func-
tion every 24 hours.
10
and Buttons
When pressed simultaneously these buttons display the internal
temperature of the vehicle on the LCD.
and Buttons
The numeric display toggles between the time of the day and the
alarm clock when these buttons are pressed simultaneously.
and Buttons
Press these buttons simultaneously to activate the parking timer.
Each additional press will toggle through the available options
(10 min., 20 min., 30 min., 1 hour, 1.5 hours, 2 hours, and off).
and Buttons
When pressed simultaneously these buttons toggle between beep
notification and vibrate notification.
and Buttons
When pressed simultaneously these buttons activate battery
saver mode, which will drop power consumption on the trans-
ceiver battery to zero when the alarm is inactive or disarmed.
standard icon configurations
Icon
The vehicle interior temperature icon displays the temperature
of the inside of the vehicle when prompted.
Icon
The numeric display icon will show the hours and minutes.
➜
11
Icon
The AM/PM icon indicates the time before or after noon.
Icon
The alarm clock mode icon indicates that the alarm clock mode
is active.
Icon
The timer function icon flashes during timed functions
including parking timer.
Icon
The transmit range indicator icon stays visible as long as the
system is within operating range.
Icon
The remote transmission indicator icon displays when the trans-
ceiver is transmitting a signal.
Icon
The vibrate/beep mode icon appears when the transceiver is set
to vibrate mode.
Icon
The power saver mode can be turned on or off with the trans-
ceiver. This icon displays the status.
Icon
The remote engine start timer mode icon indicates the 24-hour
autostart feature is active and automatically remote starts 24
hours from the time activated.
12
Icon
This icon has no function.
Icon
No function.
Icon
The full trigger shock sensor icon indicates that the shock sensor
has been triggered by a hard shock.
and Icons
The hood/trunk open or trigger icon illuminates when the hood
or trunk trigger has been activated or the hood or trunk is open,
and bypasses those zones until it is closed.
Icon
The parking light icon will flash twice when armed or disarmed.
The icon also flashes during WarnAway and at the beginning
and end of remote engine start cycles.
Icon
The door open or trigger icon illuminates when the door trigger
has been activated or the door is open, and bypasses that zone
until it is closed.
Icon
The remote start icon indicates when the vehicle is remotely
started.
Icon
The override mode icon appears when the system is in override.
13
Icon
The remote engine start safety shut down icon indicates the
vehicle may be in gear or other unsafe condition inhibiting
remote start operation.
Icon
The battery level icon indicates the level of power remaining in
the battery.
Icon
No function.
Icon
The silent arm/disarm icon appears when the system has been
armed or disarmed in the silent mode.
Icon
Chirps are enabled.
Icon
The arm icon appears when the vehicle is armed and locked. The
disarm icon appears when the vehicle is disarmed and unlocked.
Icon
Celsius/Fahrenheit icon indicates the current mode of the
displayed temperature either in Celsius or Fahrenheit.
Loading...
