CLARION SIRCL3 User Manual
SIR-CL3
SIR-CL3SIR-CL3
CLARION COMPATIBLE
SIRIUS SATELLITE RADIO TUNER
Ce-NET
TO HEADUNIT PASS-THRU
SIR-CL3
CLARION COMPATIBLE
SIRIUS SATELLITE RADIO TUNER
Installation Guide
Congratulations on your purchase of the SIR-CL3 ClarionCompatible SIRIUS Satellite Radio Tuner!
Y our new SIRIUS T uner is designed to work with all Clarion headunits that are
designated to be “SIRIUS-READY”. Contact Clarion or SIRIUS for model
compatibility.
What is SIRIUS Satellite Radio?
Over 120 channels of the best
entertainment and completely
commercial-free music for your car,
home or office.
Only SIRIUS has more than 65
original music channels, from today’s
hits to R&B oldies to classical
masterpieces. From authentic
Country and real Bluegrass to cool
Jazz, hot Latin, Reggae, Rock and
many more. Best of all, it’s all
completely commercial-free.
SIRIUS also has more than 55
channels of world-class sports, news
and entertainment. Included as part of
your subscription, you get up to 16
NFL games a week, up to 40 NBA
games a week and up to 40 NHL
games a week. (Games are
broadcasted during their respective
seasons.) Coupled with great sports
news from ESPN, the SIRIUS sports
offering is unrivaled. And don’t forget a
host of other great news and
entertainment, like NPR, CNBC, Fox
News, Radio Disney and
E! Entertainment Radio.
With SIRIUS, the emphasis is on the
music and entertainment you want.
The music is hosted by SIRIUS
Jockeys, who are true experts. They
back-up the music with compelling
information about the song being
played, and they understand that
sometimes it’s best to just let the
music speak for itself.
Rely on SIRIUS rocket science for
superior coverage.
Only SIRIUS has three powerful
satellites that fly directly over the U.S.
ensuring coast-to-coast coverage with
high elevation angles. This gives the
satellites a “clear line of sight” to your
car or home, with much less concern
for buildings, trees or other objects
that might block conventional satellite
signals.
Once you experience more than 120
channels of digital entertainment,
you’ll never want to leave your car.
For more information, visit
www.sirius.com.
2
SIR-CL3 Installation Guide
Table of Contents
Package Contents ..............................................................................................3
Warnings and Cautions .....................................................................................4
Installation .......................................................................................................... 6
Mounting the Tuner ............................................................................................6
Installing the Antenna ........................................................................................6
Optimum Antenna Mounting Locations ........................................................... 7
Wiring and Cable Connections .........................................................................8
System Connection Examples ........................................................................10
Activating Y our SIRIUS Subscription .............................................................12
Specifications ................................................................................................... 13
Package Contents
A
$17(11$
6,5&/6,5&/
&/$5,21&203$7,%/(
6,5,866$7(//,7(5$',2781(5
&H1(7
72+($'81,7
A
SIR-CL3 Tuner
B
Magnetic Micro Antenna
C
Antenna Cable Cover/Tail
D
Alcohol Swab
E
2.5-Meter Ce-NET Cable
F
6 Mounting Screws
3$667+58
B
C
D
E
F
SIR-CL3 Operation and Installation Guide
SIR-CL3 Installation Guide
3
3
W ARNING
This symbol means important
instructions. Failure to heed them can
result in serious injury or death.
DO NOT OPERATE ANY FUNCTION
THAT TAKES YOUR ATTENTION
AW A Y FROM SAFEL Y DRIVING YOUR
VEHICLE.
Any function that requires your
prolonged attention should only be
performed after coming to a complete
stop. Always stop the vehicle in a safe
location before performing these
functions.
Failure to do so may result in an
accident.
DO NOT OPEN, DISASSEMBLE OR
ALTER THE UNIT IN ANY WAY. Doing
so may result in fire, electric shock or
product damage.
DO NOT INSTALL IN LOCATIONS
THAT MIGHT HINDER VEHICLE
OPERATION. Doing so may obstruct
vision or hamper movement which can
result in a serious accident.
DO NOT INSTALL THE UNIT TO HIGH
LEVELS OF HUMIDITY, MOISTURE
OR DUST . Doing so can result in electric
shock or product failure.
FCC Warning: This equipment may
generate or use radio frequency energy .
Changes or modifications to this
equipment may cause harmful
interference unless the modifications are
expressly approved in this User Guide.
The user could lose the authority to
operate this equipment if an
unauthorized change or modification is
made.
DO NOT INSERT ANY OBJECTS INTO
THE UNIT. Doing so may result in fire,
electric shock or product damage.
USE THE CORRECT AMPERE
RATING WHEN REPLACING FUSE.
Failure to do so may result in fire, electric
shock or product damage.
MAKE THE CORRECT CONNECTIONS.
Failure to make proper connections may
result in fire or product damage.
DO NOT SPLICE INTO A ELECTRICAL
CABLES. Never cut away cable
insulation to supply power to other
equipment. Doing so will exceed the
current carrying capacity of the wire and
result in fire or electric shock.
4
Note: This equipment has been tested
and found to comply with Part 15 of the
FCC Rules. These rules are designed to
provide reasonable protection against
harmful interference. This equipment may
cause harmful interference to radio
communications if it is not installed and
used in accordance with these
instructions. However, there is no
guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio
or television reception, which can be
determined by turning the equipment off
and on, the user is encouraged to try to
correct the interference by one of more of
the following measures:
• Relocate the receiving antenna.
• Consult the dealer or an
experienced technician for help.
SIR-CL3 Installation Guide
CAUTION
This symbol means important
instructions. Failure to heed them can
result in injury or material property
damage.
HALT USE IMMEDIATELY IF A
PROBLEM APPEARS. Failure to do so
may cause personal injury or damage
to the product. Return the unit to your
authorized retailer or nearest service
center for repairing.
INSTALL THE WIRING SO THAT IT IS
NOT CRIMPED OR PINCHED BY
SCREWS OR SHARP MET AL EDGES.
Route the cables away from moving parts
or sharp pointed edges. This will prevent
crimping and damage to the wiring. If the
wiring must pass through a metal hole,
be sure to use a rubber grommet to
prevent the wire’s insulation from being
cut by the metal edge of the hole.
USE THE SPECIFIED ACCESSORY
P ARTS AND INST ALL THE PRODUCT
SECURELY. Be sure to use only the
specified accessory parts. Use of nonspecified parts may damage this unit
internally or may not securely install the
unit in place. This may cause parts to
become loose, resulting in hazards or
product failure.
USE CAUTION IF YOU NEED TO
DISCONNECT THE BATTERY
TERMINAL. Please consult the vehicle’s
owner’s manual or a service technician
prior to removing the battery positive or
ground connection, as it may cause
damage to the vehicle’s electrical
system or require reprogramming of the
vehicle’s computer-controlled devices.
SIR-CL3 Operation and Installation Guide
SIR-CL3 Installation Guide
5
5
