Specifications
Technical Data
Main Unit
Voltage: 12v, negative ground
Current Consumption: <15mA
Temperature Range: -20oF to +160oF
Auxiliary Output Capability: 500mA
Internal Relays: (4) 30A, (1) 7A
Transmitter
Current Consumption: <.00mA, standby
Battery Type: miniature 12v, type 23A
Model No.: RS300
Serial No.:
Dealer Name:
Address:
Purchase Date:
THIS DEVICE COMPLIES WITH FCC RULES PART 15.
OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCE THAT MAY BE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
Warranty Information
FCC ID:
MP62ZUUNGO701-702
HP92VUUNGO7000-2
Ungo Security Corporation
Gardena, CA
USA
Ungo Security Corporation
A Clarion Company
661 West Redondo Beach Blvd.
Gardena, CA 90247
www.clarion.com
© Ungo Security Corporation, Gardena, CA 97-RS300-10 Rev. 1 (8/03)
RS300 Owner’s Manual - Page 7
Warranty Information
ongratulations on your purchase of this Ungo Convenience System. Please
This Ungo Security System is warranted against defects in material and workmanship. The main unit and remote
controls are covered by this limited lifetime warranty. This Limited Lifetime Warranty applies to Ungo Security
systems that have been installed by an authorized Ungo Security dealer. This warranty is to the Original
Purchaser ("Owner") and to the original vehicle in which it was installed into. This warranty is not transferable to
does not cover batteries or products deemed damage through alterations or installation. It also
does not cover products mishandled, misused, neglected, abused, water damaged, or with removed/altered serial
This warranty does not cover the costs incurred for removal or reinstallation of the main unit and/or any damage
The sole responsibility of Clarion Corporation under this Warranty shall be limited to the repair or replacement of
If it becomes necessary to send the product or any defective part to Clarion Corporation, the product must be
shipped in its original carton or equivalent carton, fully insured, with shipping charges prepaid. Clarion
ALL IMPLIED WARRANTIES EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW SHALL HAVE NO
GREATER DURATION THAN THE WARRANTY PERIOD SET FORTH ABOVE. UNDER NO CIRCUMSTANCES
SHALL CLARION CORPORATION BE LIABLE FOR ANY LOSS OR DAMAGE, DIRECT OR CONSEQUENTIAL,
ARISING OUT OF THE USE OR INABILITY TO USE OF THE PRODUCT. BECAUSE SOME STATES DO NOT
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR EXCLUSIONS OR LIMITATIONS
OF INCIDENTIAL OR CONSEQUENTIAL DAMAGES, THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE THE OTHER RIGHTS,
Should you have any difficulties with the performance of this product during warranty, please call: 1-800-GO-
CLARION or visit your local Ungo dealer. You may also contact the National Service Manager at the following
read this manual thoroughly to familiarize yourself with your system’s
C
components and operation. Discuss any questions you might have with
your installing dealer.
Record the serial number of your Ungo system and keep all dealer records and
receipts. Be sure to discuss the installation with the dealer so that you
understand the specifics of the installation in your vehicle.
any subsequent owner(s) of the product(s).
Warranty Program:
Main Unit Limited Lifetime
Remote Controls Limited Lifetime
Siren One year from date of purchase
Shock Sensor One year from date of purchase
LED One year from date of purchase
Valet/Override Button One year from date of purchase
The Warranty
numbers.
PROOF OF PURCHASE WILL BE REQUIRED FOR WARRANTY SERVICE OF THIS PRODUCT.
to the vehicle or the vehicle's electrical system.
the product, at the sole discretion of Clarion Corporation.
Corporation will not assume any responsibility for any loss or damage incurred in shipping.
APPLY TO YOU.
CAUTIONS
• USE OF THE UNGO RS300 IS THE RESPONSIBILITY OF THE OWNER.
• KEEP THE REMOTE TRANSMITTERS OUT OF THE REACH OF CHILDREN.
• THE UNGO RS300 IS NOT INTENDED FOR USE ON VEHICLES EQUIPPED WITH A MANUAL
TRANSMISSION.
• BE SURE THE TRANSMISSION IS IN PARK BEFORE LEAVING THE VEHICLE.
• ONLY REMOTE START THE VEHICLE IN A WELL VENTILATED AREA.
WHICH VARY FROM STATE TO STATE.
address below for additional service help you may need.
Clarion Corporation of America
Attn: National Service Manager
661 W. Redondo Beach Blvd.
Gardena, Ca 90247
Auxiliary Function Output
The system is equipped with an Auxiliary Function output that can be used to remotely control an
Table of Contents
Page 1
Page 2
Page 2
Page 3
Page 3
Page 3
Page 3
Page 4
Page 4
Page 4
Page 5
Page 5
Page 5
Page 5
Page 6
Page 6
Page 6
Page 7
Back Cover
Note: Certain features described in this manual may require additional parts and/or labor. Also, some features of the Ungo
RS300 convenience system have selectable options that must be activated or programmed during the system’s
installation. These items will be identified in the following sections. Your Authorized Ungo Dealer will be happy to
optional feature such as, electric trunk release, power windows, etc.
To operate the Auxiliary Function, press Button 3.
• This function will operate regardless of whether the system is locked, unlocked, or in Valet
mode.
Dome Light Control
For increased safety and convenience this optional feature will automatically turn on the dome light
for 20 seconds when the system is Unlocked using the Remote Transmitter.
Reference Chart
This chart may be used to quickly identify and interpret the RS300’s parking light and LED indications.
Parking Light Indications
Flashes Functions
1 Doors are locked (optional)
2 Doors are unlocked (optional)
4 Auto Cold Starting engaged
Flashes Functions
Rapid Remote Started/Running
Solid Valet mode
Double Auto Cold Starting engaged
Status LED Indications
1. About Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Remote Transmitters
Remote Transmitter Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding or Deleting Transmitters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additional Remote Transmitters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. Basic Features
Remote Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shut Down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Valet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stop and Go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Auto Cold Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4. Optional Features
Remote Keyless Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Controlled Door Locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Controlled Door Unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Optional Driver Door Priority Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Auxiliary Function Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome Light Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5. Reference Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7. Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 6 - RS300 Owner’s Manual
discuss these features with you and help you design your system to meet your needs.
RS300 Owner’s Manual - Page 5
For added convenience and safety, this feature automatically locks your vehicle’s doors 10 seconds
The system will not automatically lock the doors if a door is opened during the first 10 seconds after the ignition key
For added convenience, this feature automatically unlocks your vehicle’s doors after the ignition key
This configuration adds the security of unlocking only the driver’s door when the system is
Arms the system. This button also locks the doors when the system is in Valet Mode.
Disarms the system and unlocks the driver’s door. This button also unlocks the doors
If the system is in Valet and the doors are locked, pressing Button 2 will unlock the driver’s door. Pressing Button
*Extra parts and/or labor may be required to properly utilize this feature. See your Authorized Ungo Dealer for details.
Optional Features
Remote Keyless Entry
To Lock and Unlock the doors:
1. Press Button 1 on the Remote Transmitter.
• The parking lights will flash once.
• The horn will honk once*.
• The doors will lock.
2. Press Button 2 on the Remote Transmitter.
• The parking lights will flash twice.
• The horn will honk twice*.
• The doors will unlock.
• The dome light will turn on.
*optional feature
Note: Extra parts and/or labor may be required to utilize this feature. See your Authorized Ungo Dealer for details.
Ignition Controlled Door Locking
after the ignition key is turned on.
To prevent you from accidentally locking your keys inside the vehicle:
• The system will not automatically lock the doors if a door is open when the ignition key is turned on.
•
is turned on.
Ignition Controlled Door Unlocking
is turned off.
• If driver’s door priority is installed only the driver’s door will unlock after the ignition key is turned off.
Optional Driver Door Priority Feature*
Disarmed. Pressing the Disarm button again will unlock all remaining doors.
Button 1
Button 2
when the system is in Valet Mode.
If the system is Armed, pressing Button 2 will Disarm the system and unlock the driver’s door only.
If the system is Disarmed, pressing Button 2 will unlock all remaining doors.
2 again will unlock all remaining doors.
The Ungo RS300 is a remote controlled engine start system. When activated, the RS300 will safely
start your vehicle by remote control, without your key in the ignition. If your vehicle is powered by
a diesel engine, the RS300 will turn on the ignition for several seconds prior to starting the engine,
Once the RS300 has started the engine, it will turn on your preset accessories (heater/air
conditioner) to provide you with the maximum comfort when you enter your vehicle. After activation,
the RS300 will allow the vehicle to run for approximately 12 minutes (or 24 minutes if selected by
- Specifically designed to maximize the operating range of the
- Used to disable the remote starting system in case the
To provide you with the maximum safety and reliability, the RS300 incorporates the following safety
- Prevents the engine from being started while the hood is
The RS300 Remote Start system also has the capability of controlling the following optional
RS300 Owner’s Manual - Page 1
Valet Mode
Allows you to temporarily disable the remote starting feature when the vehicle is being serviced or
turned over to a parking attendant.
To turn Valet Mode on or off:
1. Turn on the ignition.
2. While pressing the Override Switch, turn off the ignition.
• The horn will chirp once to indicate you have turned Valet Mode on.
• The horn will chirp twice to indicate you have turned Valet Mode off.
While in Valet Mode, the LED will light solid and the Remote Transmitters will continue to lock and
unlock your doors and operate the Auxiliary Function.
Stop and Go
The Stop and Go Feature allows you to remove the ignition key and exit the vehicle while keeping
the engine running during short stops.
To leave the vehicle running:
1. Park the vehicle and leave the ignition on.
2. Press Button 4 on the Remote Transmitter for 3 seconds.
• The LED will flash rapidly.
• The parking lights will turn on.
• The doors will unlock*.
3. Remove the key from the ignition switch.
4. You may now exit the vehicle and lock the doors manually or using the Remote Transmitter.
To re-enter the vehicle and resume driver control:
1. Unlock the doors manually or by pressing Button 2 on the Remote Transmitter*.
2. Turn on the ignition.
3. Press the brake pedal to disengaged the RS300.
• The LED will turn off.
*If optional keyless entry feature is installed and the Ignition Controlled Door Locking feature is enabled.
About Your System
in order for the glow plugs to warm up.
your installer at the time of installation) before automatically shutting off.
Ungo RS300 System comes with:
• Main Unit - The “brain” of the system.
• Two 5-Button Remote Transmitters
• Extended Range Receiver
Remote transmitters.
• Status LED - Red illuminated indicator that provides system status information.
• Valet / Service Mode Switch
vehicle is to be serviced. Optional keyless entry features will still function.
Safety
features:
• Brake Pedal Shutdown - Shuts down the RS300 when the brake pedal is pressed.
• Hood Pin Switch Protection
open.
• Valet Mode - Prevents the vehicle from being started when being serviced.
Options
Auto Cold Starting
The Auto Cold Starting Feature automatically starts the vehicle every two hours and runs for the
preset Run Time.
To enter Cold Start Mode:
1. Press and continue to hold the Brake pedal.
2. Press and continue to hold the Valet switch.
3. Continue holding both the Brake pedal and Valet switch, then press Transmitter Button 2.
• The parking lights will flash 4 times.
4. The system will remain in Cold Start Mode until the vehicle is started using the transmitter
or the Cold Start Feature has completed all the run cycles.
Page 4 - RS300 Owner’s Manual
convenience features:
• Remote Keyless Entry (Door Lock/Unlock)
• Remote Trunk Release
• Dome Light Control
• Horn Honk
• Window Roll-up
Remote Transmitters
RS300 Owner’s Manual - Page 3
Battery Replacement
Your Ungo Remote Transmitter uses a 12 volt alkaline battery, which will need to be replaced from
time to time. Under normal conditions, the battery may last more than 6 months before it needs
replacement. When your Remote Transmitter’s battery is in need of replacement, you will notice a
decrease in your system’s operating range or a decrease in the brightness of the Transmitter’s LED
To change the battery, remove the 2 screws at the back of the Transmitter and carefully separate
the top and bottom halves of the Transmitter case. Insert the new battery, making sure that the
Additional Remote Transmitters for your RS300 are available from your Authorized Ungo dealer.
*If the engine cranks and starts but fails to remain running on the first attempt, it will repeat the starting procedure 2 more
Turning on the ignition key then pressing the brake pedal will disengage the RS300 and allow you
Remote Transmitter Layout
LED Button 2
Button 1
Button 5
indicator.
Button 3
The Ungo RS300 comes with 2 VariCode3Remote Transmitters used to control the system’s
features. Each time a transmitter button is pressed, the LED will flash to indicate that a transmission
is taking place.
Button 1 Locks the doors.*
Button 2 Unlocks the doors.*
Button 3 Activates the system’s auxiliary function (usually used for optional trunk release).*
Button 4 Remote starts the vehicle. It is also used to shutdown the engine if remote started.
Button 5 Changes the functions of buttons 1-4 for use with multiple vehicles. See your authorized
Ungo dealer for more information about multi-car compatibility.
*optional feature
Button 4
Adding or Deleting Remote Transmitters
The Ungo RS300 has the ability to recognize 4 individual Remote Transmitters. If the vehicle is
used by multiple drivers, each can have their own Remote Transmitter.
To add a Remote Transmitter:
1. Turn on the ignition.
2. Press and hold the Override switch.
• The status LED will turn on red.
• The horn will honk 3 times.
3. Have all desired transmitters ready and follow the steps below for each transmitter.
Press Transmitter Button 1.
• The parking lights will flash once.
Press Transmitter Button 1 again.
• The parking lights will flash twice to confirm that the new Remote Transmitter has been
added.
4. Repeat Step 3 for each Transmitter.
5. Wait 5 seconds then turn off the ignition.
positive and negative terminals are positioned correctly and replace the cover.
Additional Remote Transmitters
Basic Features
Remote Starting
To Remote Start the System:
1. Be sure the System is not in Valet Mode.
2. Press Button 4.
• The parking lights will turn on.
• The horn will chirp 3 times (if installed and programmed for warning chirps).
• The ignition will turn on.
• The engine will start and run for the duration of its programmed Run Timer.*
• The heater or air conditioner will turn on (if turned on prior to exiting the vehicle).
• The LED will flash rapidly.
times.
to operate and drive your vehicle in a normal manner.
Shut Down
The following will shut down the engine when it is under Remote Start control:
1. Press Button 4.
• After the engine shuts down the doors will lock (if installed and programmed).
2. Press the brake pedal.
3. Open the hood.
4. Remote Start Time-Out (completion of the timed run cycle).
Page 2 - RS300 Owner’s Manual
Loading...
