Clarion RK1 User Manual

Model RK1

➤

OOwwnneerr’’ss GGuuiiddee

limited lifetime consumer warranty

This Ungo Pro Security system is warranted against defects in material and workmanship. The main unit is covered by this limited lifetime warranty. This Limited Lifetime Warranty applies to Ungo Pro Security systems that have been installed by an authorized Ungo Pro Security dealer. This warranty is to the Original Purchaser ("Owner") and to the original vehicle in which it was installed into. This warranty is not transferable to any subsequent owner(s) of the product(s).

WWaarrrraannttyy PPrrooggrraamm::

Main Unit Limited Lifetime Remote Controls One year from date of purchase Siren One year from date of purchase Shock Sensor One year from date of purchase LED One year from date of purchase Override Switch One year from date of purchase

The Warranty does not cover batteries or products deemed damaged through alterations or installation. It also does not cover products mishandled, misused, neglected, abused, water damaged, or with removed/altered serial numbers.

PROOF OF PURCHASE WILL BE REQUIRED FOR WARRANTY SERVICE OF THIS PRODUCT.

This warranty does not cover the costs incurred for removal or reinstallation of the main unit and/or any damage to the vehicle or the vehicle's electrical system.

The sole responsibility of Clarion Corporation of America ("Clarion") under this Warranty shall be limited to the repair or replacement of the product, at the sole discretion of Clarion.

If it becomes necessary to send the product or any defective part to Clarion, the product must be shipped in its original carton or equivalent carton, fully insured, with shipping charges prepaid. Clarion will not assume any responsibility for any loss or damage incurred in shipping.

ALL IMPLIED WARRANTIES EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW SHALL HAVE NO GREATER DURATION THAN THE WARRANTY PERIOD SET FORTH ABOVE. UNDER NO CIRCUMSTANCES SHALL CLARION CORPORATION BE LIABLE FOR ANY LOSS OR DAMAGE, DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE USE OR INABILITY

TO USE OF THE PRODUCT. BECAUSE SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR EXCLUSIONS OR LIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE THE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.

Should you have any difficulties with the performance of this product during warranty, please call: 1-800-GO-CLARION or visit your local Ungo Pro Security dealer. You may also contact the National Service Manager at the following address below for additional service help you may need.

Clarion Corporation of America Attn: National Service Manager 661 W. Redondo Beach Blvd. Gardena, Ca 90247

table of contents

limited lifetime consumer warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .i

standard configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

what is included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

important information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

system maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

FCC/ID notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

remote functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

standard configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

using your system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

warning! safety first . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

disabling the starter kill without a remote . . . . . . . . . . . . . . . . . . . . . . . .9

override mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

panic mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

remote engine start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

take-over mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

short-run/turbo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

timer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

starter anti-grind circuity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

disabling the remote engine start system . . . . . . . . . . . . . . . . . . . . . . . .15

power-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

programming options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

glossary of terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

convenience expansions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

standard configuration

controls the Lock/Panic ON/Panic OFF function.

controls the Unlock function.

controls Silent Lock/Unlock and an Auxiliary Output.

controls remote engine start.

/ controls Timer mode.

+ controls Turbo/Short Run.

+ controls Channel 4 output.

what is included

Control module

Receiver/antenna

Two four-button remotes

Blue status LED indicator light

Push-button Override switch

Shut-down toggle switch

important information

Congratulations on the purchase of your remote engine start keyless

entry system. Due to the complexity of this system, it must be installed

by an authorized dealer only. Installation of this product by anyone

other than an authorized dealer voids the warranty.

By carefully reading this Owner's Guide prior to using your system, you

will maximize the use of this system and its features.

system maintenance

The system requires no specific maintenance. Your remote is powered

by a small, lightweight 3-volt lithium battery that will last approximate-

ly one year under normal use. When the battery begins to weaken,

operating range will be reduced and the LED on the remote will dim.

FCC/ID notice

This device complies with Part 15 of FCC rules. Operation is subject to

the following conditions: (1) This device may not cause harmful inter-

ference, and (2) This device must accept any interference received,

including interference that may cause undesirable operation.

Changes or modifications not expressly approved by the party responsi-

ble for compliance could void the user's authority to operate this device.

CCAAUUTTIIOONN::

This product is designed for fuel injected, automatic transmission vehicles only. Use of this product in a standard transmission vehicle is dangerous and contrary to the product's intended use.

remote functions

The receiver uses a computer-based learn routine to learn the remote

buttons. This makes it possible to assign any specific remote button, or

combination of buttons, to any receiver function. The remote initially

comes programmed with the Standard Configuration, but may also be

customized by an authorized dealer. The remote buttons indicated in all

of the instructions in this manual correspond to a Standard

Configuration remote.

standard configuration

Button

The lock and panic functions are controlled by pressing on the

remote for one second.

Button

The unlock function is controlled by pressing on the remote for

one second.

Button

Silent Lock/Unlock and an optional auxiliary function are controlled by

this button in conjunction with the or button. (An optional

auxiliary function, such as trunk release, can be controlled by pressing

this button for 1.5 seconds.

The auxiliary output controls __________________________.

Button

The remote engine start function of your system is controlled by press-

ing this button twice within 3 seconds.

and Buttons

An optional auxiliary convenience or expansion function that you have added

to your system can be activated by pressing these buttons simultaneously.

The auxiliary output controls __________________________.

using your system

warning! safety first

The following safety warnings must be observed at all times:

Due to the complexity of this system, installation of this product

must only be performed by an authorized dealer.

When properly installed, this system can start the vehicle via a com-

mand signal from the remote. Therefore, never operate the system in an

enclosed area or partially enclosed area without ventilation (such as a

garage). When parking in an enclosed or partially enclosed area or

when having the vehicle serviced, the remote engine start system must

be disabled using the installed toggle switch. It is the user's sole respon-

sibility to properly handle and keep out of reach from children all

remotes to assure that the system does not unintentionally remote

engine start the vehicle. THE USER MUST INSTALL A CARBON

MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJA-

CENT TO THE VEHICLE. ALL DOORS LEADING FROM ADJACENT

LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHI-

CLE STORAGE AREA MUST AT ALL TIMES REMAIN CLOSED. These

precautions are the sole responsibility of the user.

Use of this product is intended only for automatic transmission

vehicles Use of this product in a manner contrary to its intended mode

of operation may result in property damage, personal injury, or death.

(1) Never remotely start the vehicle with the vehicle in gear, and (2)

Never remotely start the vehicle with the keys in the ignition. The user

must also have the neutral safety feature of the vehicle periodically

checked, wherein the vehicle must not remotely start while the car is in
