Cisco Systems WCS-BTS1 Users Manual

Ripwave™ Base Station

User Manual

Part Number 40-00197-00

Revision C (1.20), Version 1.0

September 26, 2003

Proprietary

All information disclosed by this document is the proprietary property of Navini Networks, Inc. and is protected by

copyright, trademark, and/or trade secret laws. All rights therein are expressly reserved.

Base Station User Manual Navini Networks, Inc.

About This Document

Purpose

This manual provides an overview for the Navini Networks Base Station. Topics included are installation of the Base Transceiver Station (BTS), Radio Frequency Subsystem (RFS), and cabling; and testing and commissioning the Base Station.

Revision History

Date Revision /

Version

Sept 17, 2003 A / 1.0 P. Prudhomme S. Redfoot Release of Base Station user manual for

Sept 18, 2003 B / 1.0 P. Prudhomme S. Redfoot Edit specifications. Sept 26, 2003 C / 1.0 P. Prudhomme S. Redfoot Add output power information

Author Editor Comments

FCC submission.

Contacts

Contact Navini Networks Technical Support during normal business hours: Monday through Friday 8:30 a.m. to 5:30 p.m. Central Time. You can also submit questions or comments by web or email at any time.

Corporate Headquarters: (972) 852-4200 Technical Support: 1-866-RIPWAVE Web Address: www.navini.com / select Technical Support E-mail: techsupport@navini.com

Navini Networks, Inc. 2240 Campbell Creek Blvd. Suite 110 Richardson, Texas 75082 USA

2 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

Permissions, Trademarks & Distribution

Copyright disclosed by this document is the proprietary property of Navini Networks, Inc. and all rights therein are expressly reserved. Acceptance of this material signifies agreement by the recipient that the information contained in this document is confidential and that it will be used solely for the purposes set forth herein. Acceptance of this material signifies agreement by the recipient that it will not be used, reproduced in whole or in part, disclosed, distributed, or conveyed to others in any manner or by any means – graphic, electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval systems – without the express written permission of Navini Networks, Inc.

Navini Networks, Internet at the Speed of Thought, zero-install, unwired by Navini, the Navini Networks logo, and Ripwave are trademarks of Navini Networks, Inc. Other product and company names mentioned herein may be trademarks and/or service marks of their respective owners.

Nothing herein constitutes any representation, warranty, assurance, or guaranty of any kind.

Because of continuing developments and improvements in design, manufacturing, and deployment, material in this document is subject to change without notification and does not represent any commitment or obligation on the part of Navini Networks, Inc.

Navini Networks, Inc. shall have no liability for any error or damages resulting from the use of this document. Any unauthorized usage is strictly prohibited without the express written permission of Navini Networks, Inc.

Navini Networks, Inc. 2240 Campbell Creek Boulevard Suite 110 Richardson, Texas 75082 USA

©

September 2003, Navini Networks, Inc. All information contained herein and

Part #40-00047-01 Rev C v1.0 (1.20) 3 September 26, 2003

Base Station User Manual Navini Networks, Inc.

TABLE OF CONTENTS

ABOUT THIS DOCUMENT ............................................................................................................. 2

P

ERMISSIONS, TRADEMARKS & DISTRIBUTION ........................................................................... 3

S

AFETY ........................................................................................................................................ 5

R

EGULATORY INFORMATION ....................................................................................................... 7

B

ATTERY CAUTION & PROCEDURES ............................................................................................ 8

GLOSSARY OF TERMS & ABBREVIATIONS ................................................................................... 9

OVERVIEW................................................................................................................................ 17

R

IPWAVE DESCRIPTION.............................................................................................................. 17

P

ROCEDURAL DOCUMENTS & FORMS........................................................................................ 18

H

IGH-LEVEL I&C PROCESS........................................................................................................ 19

BASE STATION COMPONENTS ........................................................................................... 30

BASE TRANSCEIVER STATION (BTS) ......................................................................................... 30

R

ADIO FREQUENCY SUBSYSTEM (RFS) ..................................................................................... 31

G

LOBAL POSITIONING SYSTEM (GPS) ....................................................................................... 32

M

OUNTING RACKS & ENCLOSURES........................................................................................... 33

G

ENERAL SPECIFICATIONS......................................................................................................... 34

B

ASE STATION SPECIFICATIONS................................................................................................. 35

M

ATERIALS SPECIFICATIONS ..................................................................................................... 37

APPENDIX A: RFS IDENTIFICATION LABEL ................................................................. 39

2.3 GHZ RFS – OMNI HIGH BAND ............................................................................................ 39

2.3 GH

Z RFS – OMNI LOW BAND ............................................................................................. 40

Z RFS – SECTOR ............................................................................................................ 41

APPENDIX B: 2.3 GHZ BTS IDENTIFICATION LABEL.................................................. 43

4 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

Safety

To optimize safety and expedite installation and service, read this document thoroughly. Follow all warnings, cautions, and instructions marked on the equipment and included in this document.

To aid in the prevention of injury and damage to property, cautionary symbols have been placed in this document to alert the reader to known potentially hazardous situations, or hazards to equipment or procedures. The symbols are placed before the information to which they apply. However, any situation that involves heavy equipment and electricity can become hazardous, and caution and safety should be practiced at all times when installing, servicing, or operating the equipment.

Caution Symbol - possible equipment or property damage

Warning Symbol - could cause personal injury or otherwise be hazardous to your health

Navini Networks, Inc., expressly requires that when using Navini electronic equipment always follow the basic safety precautions to reduce the risk of electrical shock, fire, and injury to people and/or property.

1. Follow all warnings and instructions that come with the equipment.

2. Do not use the equipment while you are in a bathtub, shower, pool, or spa. Exposure of the equipment to water could cause severe electrical shock or serious damage to the equipment.

3. Do not allow any type of liquid to come in contact with the equipment. Unplug the equipment from the power source before cleaning. Use a damp cloth for cleaning. Do not use any soaps or liquid cleaners.

4. Follow all airport and FAA regulations when using the equipment on or near aircraft.

5. Only operate the equipment from the type of power source(s) indicated in this manual (110 VAC or Navini supplied battery). Any other type of input power source may cause damage to the equipment.

6. Power the equipment using only the battery or the AC adapter cable provided, and in accordance with the instructions specified in the User Guide.

7. Do not use a frayed or damaged power cord. Do not place the power cord where it can be stepped on or tripped over.

8. Do not touch wires where the insulation is frayed or worn unless the equipment has been

Part #40-00047-01 Rev C v1.0 (1.20) 5 September 26, 2003

Base Station User Manual Navini Networks, Inc.

disconnected from its power source.

9. Do not overload wall outlets, power strips, or extension cords. This can cause serious electrical shock or fire.

10. Do not place the equipment on an unstable surface. It can fall and cause injury or damage to the equipment.

11. Do not disassemble the equipment. Removing covers exposes dangerous voltages or other risks and also voids the warranty. Incorrect reassembly can cause equipment damage or electrical shock. Only an authorized repair technician should service this product.

12. Do not expose the equipment to extreme hot or cold temperatures.

13. Do not use the equipment under the following conditions:

• When the equipment has been exposed to water or moisture.

• When the equipment has been damaged.

• When the power cord is damaged or frayed.

• When the equipment does not operate properly or shows a distinct

change in performance.

6 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

Regulatory Information

FCC Notice

WARNING! This device is a Radio Frequency transmitter. It is required to comply with FCC RF exposure requirements for transmitting devices. A minimum separation distance of one meter or more must be maintained between the antenna and all persons during device operations to ensure compliance with the FCC’s rules for Radio Frequency Exposure. If this minimum distance cannot be maintained, exposure to RF levels that exceed the FCC’s limits may result.

INFORMATION TO USER

This device has been authorized as a radio frequency transmitter under the appropriate rules of the Federal Communications Commission. Any changes or modifications not expressly approved by Navini Networks could void the user’s authority to operate the equipment.

Part #40-00047-01 Rev C v1.0 (1.20) 7 September 26, 2003

Base Station User Manual Navini Networks, Inc.

Battery Caution & Procedures

WARNING! To reduce risk of injury or fire, follow these instructions when handling the battery.

1. Risk of explosion is possible if the battery is replaced with one not supplied by Navini Networks.

2. Do not dispose of the battery in a fire. It may explode. Check with the local codes for battery disposal guidelines.

3. Do not open or mutilate the battery. The battery contains substances that are toxic, corrosive, or harmful to humans. If battery substances come in contact with the skin, seek medical help immediately.

4. Do not attempt to recharge the battery by any means except per the instructions in this manual.

5. Remove the battery from the equipment if the equipment is not going to be used for a long period of time. The battery could leak and cause damage to the equipment.

6. Exercise care when handling the battery to prevent shorting the battery with conducting materials such as bracelets, rings, and keys.

7. Store the battery pack in a dry place, 0 to +40 degrees Celsius.

8. Dispose of used batteries according to environmental guidelines.

8 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

N

Glossary of Terms & Abbreviations

Term Stands For.... Meaning

ACC

ACK

AP

ARP

ASYNCH

ATM

BB BCC

BS

BTS

BW

BYTE CAM

CC

CD

Access Channel or Access Code Channel Acknowledge Positive message sent by a protocol to acknowledge reception

Access Point Wireless LAN transceiver that acts as a center point of an all-

Address Resolution Protocol The function of the ARP is to match higher-level network IP

Asynchronous

Asynchronous Transfer Mode Transporting a broad range of user data at irregular intervals

Broadband RF system with constant data rate of 1.5 Mbps or higher. Broadcast Code (or Control) Channel Base Station

Base Transceiver Station The Ripwave BTS is a two-shelf rack that holds the RF

Bandwidth Frequency spectrum usable for data transfers. It describes the

Byte 8 bits Configuration & Alarm Manager An EMS functionality that is handled through a Graphical User

1

Communications Controller or

2

Cross-check

1

Compact Disk or 2Change Directory1An optical disk capable of storing large amounts of data (700x

AKA, Paging Channel. The signal path that tells a mobile to prepare for an incoming call.

of a transmitted packet

wireless network or as a connection point between wireless and wired networks.

addresses with the physical hardware address of a piece of equipment.

ot occurring at regular intervals, as in data piped over a

network

over network facilities

A channel of data transmitted by one entity and received by many devices.

etwork Access equipment and software that transmits and receives, as well as processes, voice or data calls from mobile units to network connections. A Ripwave Base Station consists of the Base Transceiver Station (BTS) and the Radio Frequency Subsystem (RFS), or antenna, plus a Global Positioning System (GPS) antenna for timing.

modules and digital circuit cards that interpret radio signals into computer language and sends messages to and from the local or wide area network. It functions between the RFS and the EMS to handle the signaling.

maximum data rate that a signal can attain on the medium without encountering significant loss of power. Usually expressed in bits per second (digital) or Hertz (analog).

Interface for purposes of configuring elements in the system and handling other OAM requirements.

1

A type of circuit card that resides in the Digital shelf of the Ripwave BTS. It handles all interfaces between BTS and network.

2

An EMS functionality that allows the system to

perform an automated sanity check of the datafill.

floppy disk). It can be inserted into most pc’s and “read” to load files onto a computer 2A software programming term in “C” language that tells the computer to go to a different location in the computer’s memory.

Part #40-00047-01 Rev C v1.0 (1.20) 9 September 26, 2003

Base Station User Manual Navini Networks, Inc.

Term Stands For.... Meaning

CDMA

CD-ROM

CHP

CLEC

CLI

CORBA

CPE

dB dBd

dBi

DHCP

DiffServ

DIR

DL

DNS

DS-1

DSL

Code Division Multiple Access Digital cellular technology that uses a spread-spectrum

technique where individual conversations are encoded with a random digital sequence. Increases capacity and speed of communications messages between mobile units over other types of wireless networks.

Compact Disk - Read Only Memory See “CD.” If a CD is not Read Only, computers can write data

to it with that capability.

Channel Processor Card A card in the digital shelf of the BTS that performs the first

stage of signal processing for up to 4 antennae. One Navini 2.4 GHz BTS has 8 antennae. The card performs digital-to-analog conversion (DAC) and analog-to-digital conversion (ADC) for up to 10 carriers.

Competitive Local Exchange Carrier A telephone company that competes with an incumbent Local

Exchange Carrier (LEC).

Command Line Interface A text-based programming language through which a user

communicates with an operating system or an application.

Common Object Request Broker Agent

Customer Premise Equipment Communications equipment that resides at the customer’s

Decibel Unit of measurement for sound. Decibel/Dipole A ratio, measured in decibels, of the effective gain of an

Decibel/Isotropic A ratio, measured in decibels, of the effective gain of an

Dynamic Host Configuration Protocol Differentiated Service Different Quality of Service (QoS) descriptions for different

Directory A special kind of file used to organize other files into a

DownLink In this case, data messages transmitted from the BTS to the

Domain Name Server TCP/IP networking term that is a protocol for matching objects

Digital Signal - 1 Also “T1” or “E1”. Digital transmission equipment that can

Digital Subscriber Line A type of service whereby users gain access to the Internet

A standard for Network Management Systems that allows integration with NMS regardless of programming language or Operating System.

location.

antenna compared to a dipole antenna (2 horizontal rods in line with each other). The greater the dBd value the higher the gain and therefore the more acute the angle of coverage.

antenna compared to an isotropic antenna (measured along axes in all directions). The greater the dBi value the higher the gain and therefore the more acute the angle of coverage. A protocol for dynamically assigning IP addresses to devices on a network.

types of traffic, i.e., voice, video, email. The DiffServ table is where each level of QoS is defined. Equivalent to Class of Service (COS) in POTS.

hierarchical structure.

CPE.

to network (IP) addresses.

handle up to 1.544 Mbps.

through high-speed data networks.

10 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

Term Stands For.... Meaning

DSP

EID

EMS

ERP

FCC

FE

FTP

Gain

Gb GB GHz

GPS

GUI

HW Hz I&C

IEC

IF

IMA

IP

ISP Kb KB KHz

Digital Signal Processor Compressing or manipulating analog signals to digital signals

and vice-versa.

Equipment Identifier Field in EMS for assigning IP address or name to individual

pieces of equipment for purposes of configuring the system.

Element Management System An application that allows the user to define and manipulate

managed objects as a system within an overall network.

Effective Radiated Power The actual power in Watts radiated from a transmitter’s

antenna.

Federal Communications Commission

Far End A relative term that refers to the receiving element in a

File Transfer Protocol A TCP/IP method consisting of a client and server and used to

Gain Ratio of the output amplitude of a signal to the input amplitude

Gigabit One billion (1,000,000,000) bits. Gigabyte One billion (1,000,000,000) bytes. Gigahertz One billion (1,000,000,000) hertz - cycles per second. Ultra

Global Positioning System A constellation of 24 well-spaced satellites that orbit the earth

Graphical User Interface A graphic rather than purely text based user interface to a

Hardware Physical, tangible equipment Hertz 1 cycle per second. Installation & Commissioning Term used to describe the procedures of physically installing

Inter-exchange Carrier Also IXC. Public switching network service provider (carrier)

Interface Card Card on the digital shelf of the Ripwave BTS that takes the

Inverse Multiplexing over ATM A method of building dynamic routes of 2 or more T1’s to

Internet Protocol A TCP/IP protocol used to route data from its source to its

Internet Service Provider A company that provides access to the Internet. Kilobit 1,024 bits Kilobyte 1,024 bytes Kilohertz 1,000 hertz.

United States government regulatory agency that supervises, licenses and otherwise controls electronic and electromagnetic transmission standards.

network, as opposed to the near-end element that is transmitting data.

transfer files between two or more sites or elements in a network.

of a signal, expressed in decibels (dB).

high frequency (UHF) signals, including microwave signals.

and enable users with GPS antennas to pinpoint their exact geographical position.

computer or computing system.

technical equipment then powering up the equipment to make sure it will operate (to put it “into commission”).

that connects across and between local exchange carriers (LEC).

analog signal from the Channel Processor card (CHP) and converts it to a baseband signal before sending it on to the RF modules for transmission (forward link), and vice-versa (reverse link).

increase bandwidth so that PVC’s can share the IMA resources, as needed, for data transmissions.

destination.

Part #40-00047-01 Rev C v1.0 (1.20) 11 September 26, 2003

Base Station User Manual Navini Networks, Inc.

N

Term Stands For.... Meaning

L1

L2

L3

LAN

LCP

LED

LLC

LOS

MAC

Mb MB Mbps MDM

MHz

MIB

MMDS

NE

NLOS

Layer 1 Physical Layer. Part of the OSI rules and standards for network

management. L1 describes the physical layer, or electrical and mechanical port-to-port connections, in the network.

Layer 2 Data Link Layer. Part of the OSI rules and standards for network

management. L2 describes the data link layer where data is set up and torn down in a specific format (frames), through the overall network. Also responsible for detecting and correcting errors by requesting retransmission.

Layer 3

etwork Layer. Part of the OSI rules and standards for network management. L3 describes the network addressing that gets data to its destination within the network, i.e., IP addressing.

Local Area Network A data network of interconnected computers, servers, printers,

and other peripherals that communicate at high speeds over short distances, usually within the same building. Also allows for sharing of resources.

Link Control Protocol Basis of the Point-to-Point Protocol (PPP) scheme for negotiating

and establishing connections.

Light-emitting Diode An electronic device that lights up when electricity passes

through it. Often used to indicate equipment or system state.

Logical Link Controller A protocol that governs the transition of frames between data

stations regardless of how the medium is shared. It’s the upper sub-layer that further defines the Media Access Control (MAC) protocol. It provides the basis for an unacknowledged connectionless service on a LAN - i.e., error correction, multiplexing, broadcasting.

Line-of-sight Describes laser, microwave, RF, and infrared transmission

systems that require no obstruction in a direct path between the transmitter and the receiver.

Media Access Control Protocol that governs access to a network in order to transmit

data between nodes. In a wireless LAN, the MAC is the radio controller protocol (L2).

Megabit One million (1,000,000) bits. Megabyte One million bytes. Literally - 1,048,576 bytes. Megabits Per Second Transmission speed at rate of one million bytes per second. Modem Card A card in the Navini BTS that converts digital signals into analog

so the signals can be transmitted over telephone lines, and viceversa. Modem stands for modulator/demodulator.

Megahertz One million (1,000,000) hertz - cycles per second. Normally used

to refer to how fast a microprocessor can execute instructions.

Management Information Base A collection of managed objects used in SNMP-based networks.

MIBs carry information in a standard format so external tools can analyze network management and performance.

Multipoint Multi-channel Distribution Service

1

Near-end or 2Network Element 1The transmitting end, versus the receiving end, of a signal

Fixed wireless, high-speed local service that operates at 2.1 - 2.7 GHz. Speed 10 Mbps. Originally conceived for cable TV service.

transmission.

2

A router, switch, or hub in an ISDN network.

on Line-of-site Describes laser, microwave, RF, and infrared transmission

systems that can penetrate obstructions in the path between the transmitter and the receiver.

12 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

N

Term Stands For.... Meaning

NMS

NOC

OAM

OS

OSI

PC

PCB

PDU

Ping

PPPoE

Propagation

PSK

PSN

PSTN

QAM

QoS

etwork Management System A product that helps manage a network generally hosted on a

well-equipped computer such as an engineering workstation. The system tracks network statistics and resources.

etwork Operations Center A centralized point, much like a traffic control tower, where

technicians or engineers can monitor network activity, alarms, and statistics, as well as make network configuration and other changes dynamically. For Internet, the NOC is often a hub for ISP services.

Operation, Administration, Maintenance

Operating System A software program that manages the basic operation of a

Open Systems Interconnection An ISO model for worldwide communications that defines 7

Personal Computer Any IBM-compatible computer, so named because IBM’s first

Printed Circuit Board A hardware module that holds electronic circuitry and usually

Packet Data Unit or Protocol Data Unit Ping Generalized term from sonar science, where a short sound burst

Point-to-point Protocol Over Ethernet Propagation To spread out and affect a greater area; travel through space, as

Phase Shift Keying Digital transmission term that means an angle modulation where

Packet Switched Network A network in which data is transferred in units called packets.

Public Switched Telephone

etwork

Quadrature Amplitude ModulationA bandwidth conservation process routinely used in modems.

Quality of Service A guaranteed throughput for critical network applications, such

A set of network management functions. Also describes the human-machine interface tasks - i.e., to operate the system, to administer the system, and to maintain the system.

computer. Most Operating Systems are either based on

layers of network protocol: L1 Physical Layer; L2 Data Link Layer; L3 Network Layer; L4 Transport Layer; L5 Session Layer; L6 Presentation Layer; L7 Application Layer.

commercial end user computer was called a PC.

fits into a larger frame where the various PCB’s are interconnected electronically. A data packet. Refers to that which is exchanged between peerlayer entities. Contains header, data, and trailer information.

is sent out and an echo or “ping” is received. Used to determine if signals or packets have been dropped, duplicated, or reordered. A protocol that allows dial-up Internet connections. Includes the Link Control Protocol as well as Network Control Protocols.

in radio waves.

the phase of the carrier varies in relation to a reference or former phase. An encoded shift. Each change of phase carries one bit of information, where the bit rate equals the modulation rate.

Packets can be routed individually and reassembled to form a complete message at the definition. Typically used in the same context as POTS. Analogous to a network of major highways originally built by a single organization but added to and expanded by multiple organizations. AKA, backbone networks.

Creates higher throughput but decreased coverage area.

as Voice over IP. Term primarily used in an ATM environment. Five classes of service: Class 1 Video; Class 2 Audio; Class 3 Data Connection.

Part #40-00047-01 Rev C v1.0 (1.20) 13 September 26, 2003

Base Station User Manual Navini Networks, Inc.

b

N

Term Stands For.... Meaning

RAM RF

RFS RSSI

Rx

S-CDMA

SMDS

SMS

SNMP

SNR

SSI SW SYN

SYNCH

TCC

TCP

TCP/IP

Random Access Memory Computer memory that can be accessed randomly. Radio Frequency A portion of the electromagnetic spectrum in the frequency

range between audio and infrared: 100 KHz to 20 GHz. RF measurements are expressed in Hz (unit for measuring frequency); MHz = 1 Million Hz; GHz = 1 Billing Hz.

Radio Frequency Subsystem A term for the antenna portion of the base station.

Receiver Signal Strength Indicator A term that describes the measure of the signal strength in

kilohertz or gigahertz between the transmission and the receiving end.

Receive An abbreviated way of expressing the term, receive, as in to

receive a transmission.

Synchronous Code Division Multiple Access Switched Multi-megabit Data Service

1

Short Message Service or

2

Systems Management Server or

3

Subscriber Management System

Wireless technology based on data being transferred at a fixed rate using Code Division Multiple Access algorithms. Connectionless service for MAN/WAN based on 53-

yte packets that target the interconnection of different LAN’s into a public switched network at speeds higher than T1.

1

A protocol that allows mobile users to send text-based messages from one device to another. The text appears on a device’s screen and may be a maximum 160 characters in length. 2A Windows

T process that allows a network administrator to inventory all hardware and software on the network, then perform software distribution over the LAN.

3

etwork element that provides AAA

functionality: Authentication, Authorization, & Accounting.

Simple Network Management Protocol

Standard management request-reply protocol for managing TCP/IP networks. A device is said to be SNMP compatible if it can be monitored or controlled using SNMP messages.

Signal-to-noise Ratio Related to RSSI, a measurement of the intended signal being

transmitted against the other entities that can interfere with the signal.

Signal Strength Indicator See “RSSI”. Software Computer instructions or data. Synthesizer Card A circuit card in the Navini BTS digital shelf that provides a

local oscillator and system clock with a single calibration transceiver. The card is used to calibrate the Base Station so that no external spectrum analyzer or signal generator is required.

Synchronous Digital packets or signals that are sent at the same, precisely

1

Traffic Channel or 2Transmission

Control Code

clocked fixed rate of speed.

1

A portion of a radio channel used to enable transmission of one direction of a digitized voice conversation (as opposed to the Voice Channel).

2

A way of segregating traffic in order to define

controlled communities of interest among subscribers.

Transport Control Protocol A standardized transport protocol between IP-based network

nodes that allows two hosts to establish a connection and exchange streams of data. TCP operates on top of Internet Protocols and handles the multiplexing of sessions, error recovery, reliability and flow; it guarantees packets are delivered in the same order in which they were sent.

Transport Control Protocol/Internet Protocol

A set of protocols that allows cooperating computers to share resources across the network. TCP provides the reliability in the transmission, while IP provides connectionless packet service.

14 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

Term Stands For.... Meaning

TDD

TFFS

TTL

Tx

UL

USB

VCC

VCI

VCL Vector

VPC

VP

VPI

VPL

WAN

Time Division Duplex A digital transmission method that combines signals from

multiple sources and allows a single channel to alternately carry data in each direction of a link.

True Flash File System Memory in a computing device that does not lose its information

when powered off. Available as a SIMM or PCMCIA card, it usually stores router Operating System (OS) software. Can be easily updated.

Time-to-live A field in the Internet Protocol that specifies how many more

hops a packet can travel before being discarded or returned.

Transmit To send by wire or other medium electronically or through air

via electromagnetic waves to a receiving communications device.

UpLink Describes the direction of signal flow being sent from a

subscriber to a network system, as in from a mobile device (CPE) to a base station.

Universal Serial Bus An external bus standard for plug-and-play interfaces between a

computer and add-on devices, such as a mouse, modem, keyboard, etc. One USB port can connect up to 127 devices.

Virtual Channel Circuit AKA, Virtual Channel Connection or Virtual Circuit Connection.

A logical circuit made up of Virtual Channel Links, which carry data between two end points in an ATM network.

Virtual Channel Identifier A 16-bit value in the ATM cell header that provides a unique

identifier for the Virtual Channel that carries that particular cell.

Virtual Channel Link A connection between two ATM devices. Vector A quantity representative of both magnitude and direction

(energy + orientation in space)

Virtual Private Channel AKA, Virtual Path Connection. A grouping of Virtual Channel

Connectors, which share one or more contiguous VPL’s.

Virtual Path A set of Virtual Channels grouped together between cross-points

(i.e., switches).

Virtual Path Identifier An 8-bit value in the cell header that identifies the VP as well as

the VC to which the cell belongs. The VPI + VCI identify the next destination of a cell as it passes through a series of ATM switches.

Virtual Path Link A group of unidirectional VCL’s with the same end points in a

Virtual Path. Grouping VCL’s into VPL’s reduces the number of connections to be managed. One or more VPL’s makes up a

1

Wide Area Network or

2

Wireless Access Network

VPC.

1

A communications network that spans geographically separate areas and which provide long-haul services. Examples of internetworked connections are frame relay, SMDS, and X.25 protocols. 2 General term for any product primarily used to gain access to the Internet, as opposed to being part of the actual Internet devices or software.

Part #40-00047-01 Rev C v1.0 (1.20) 15 September 26, 2003

Base Station User Manual Navini Networks, Inc.

16 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

Overview

Ripwave Description

A Ripwave system has three main components: the Customer Premise Equipment (CPE); the Base Station; and the Element Management System (EMS). The Base Station performs the CPE registration and call processing, and provides the interface between the backhaul network and the EMS. It is made up of the Base Transceiver Station (BTS) and the Radio Frequency Subsystem (RFS) (Figure 1).

Figure 1: Base Station Installation With Panel Antenna

OPTION 2

OUTDOOR BTS

24VDC @ 60A

ETHERNET

ETHERNET TELCO

TELCO

SELF SUPPORTING

SELF SUPPORTING GUIDE

GUIDE

ANTENNA TOWER

PSX

GROUND BAR

CABINET

GND

LIGHTNING

ROD

ANTENNA

BRACK

GROUND

ET

BAR

RF CABLES

CABLE

HANGERS

GPS

CABLE

ENTRY

CABLE

LADDER

GROUND

BAR

PANEL

ANTENNA

PSX-ME

SURGE

PROTECTOR

24VDC

24VDC @ 60A

@ 60A

ETHERNET

/ TELCO

CABINET

GND

Note: The illustration shows both

Note: The illustration shows both an outdoor and an indoor BTS,

an outdoor and an indoor BTS, but only one panel antenna. In

but only one panel antenna. In reality, each BTS requires

reality, each BTS requires its own panel.

its own panel.

SHELTER / HUT

OVERHEAD

OPTION 1

INDOOR BTS

NAVINI

PSX

BTS

OVERHEAD

CABLE LADDER

GROUND BAR

Part #40-00047-01 Rev C v1.0 (1.20) 17 September 26, 2003

Base Station User Manual Navini Networks, Inc.

Procedural Documents & Forms

You will refer to other Ripwave documents, procedures, and forms in the process of installing and commissioning the Base Station. The product documentation is provided on the Ripwave Standard Documentation CD (Table 1). As well, the EMS manuals can be viewed on-line through the EMS Server and Client applications.

Table 1: Ripwave Standard Documentation CD

Order Number 95-00116-00 Component or Part

Number

EMS Overview Manual 40-00016-03 MSWord/.pdf EMS Software Installation Guide 40-00017-00 MS Word/.pdf EMS-OSS Integration Guide 40-00147-00 MS Word/.pdf EMS Administration Guide 40-00031-00 MS Word/.pdf Ripwave Configuration Guide 40-00016-01 MS Word/.pdf EMS CLI Reference Manual 40-00016-02 MS Word/.pdf Ripwave Alarm Resolution Reference Manual 40-00033-00 MS Word/.pdf System Operations, Maintenance & Troubleshooting Guide* 00-00046-00 MS Word/.pdf EMS Diagnostic Tools Guide 40-00032-00 MS Word/.pdf Ripwave Modem Quick Installation Guide 40-00112-00 MS Word/.pdf English 40-00098-00 MS Word/.pdf Spanish 40-00096-00 MS Word/.pdf Ripwave Modem User Guide 40-00111-00 MS Word/.pdf English 40-00097-00 MS Word/.pdf Spanish 40-00099-00 MS Word/.pdf Customer Release Notes Varies w/each release MS Word/.pdf

*Available 4Q03

A separate CD specifically created for personnel involved with installation and commissioning of the Ripwave system, called “VAR Documentation CD”, may be ordered by authorized VARS, and business partners. The CD includes detailed procedures and electronic forms that Navini uses during the I&C process. Table 2 contains a partial listing of the files on this CD. The I&C forms found on the CD are referenced throughout this manual. .

Table 2: VAR Documentation CD

Order Number 95-00017-00 Part Number Format

Site Candidate Evaluation Form 40-00091-00 Excel Spreadsheet RFS System Test Form 40-00093-00 Excel Spreadsheet Base Station Calibration Verification Form 40-00059-00 Excel Spreadsheet Drive Study Survey Form 40-00076-00 Excel Spreadsheet Location (FTP) Test Form 40-00077-00 Excel Spreadsheet Customer Acceptance Form 40-00117-00 MS Word Document BTS Outdoor Selection Guide 44-00035-00 MS Word/.pdf Rectifier/Battery Backup Specification 44-00036-00 MS Word/.pdf

Format

18 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

High-level I&C Process

To put the I&C activities in the context of overall system deployment, Figure 2 provides a ‘flow’ of the key activities that are performed prior to and during the installation and commissioning of the Ripwave Base Station. Post-I&C, the system that has been installed and commissioned goes through Acceptance Testing against the customer’s objectives for that site. Once customer signoff on the site is achieved, the customer becomes fully responsible for operating the system.

Different job holders may perform various portions of these activities and not necessarily all of the activities. In fact, Marketing and Engineering personnel typically handle the earlier tasks, while installation may be a stand-alone function. Commissioning may or may not be handled by the same people who designed or installed the site. Regardless of who does them, these key activities have to be accomplished for successful deployment:

• Site Selection, Design, and Preparation

• Physical Installation

• Commissioning, with Acceptance Testing and Sign-off

Prior to installation, Navini and the customer formulate a Project Plan and Responsibility Assignment Matrix (RAM) to clarify who will do what to complete the I&C activities. If requested by the customer, Navini may provide personnel, procedures, forms, and/or tools required to install and commission the Base Station equipment. They may also provide special commissioning software programs, computers, and any other special test equipment required.

As part of the I&C duties, all testing results are recorded and kept for the customer to review and approve. These test results include the cable sweeps, the BTS Calibration Verification, RF System Tests, Drive Study, Line-of-Sight (LOS) FTP tests, and Non-Line-of-Sight (NLOS) FTP test results. The I&C Supervisor provides site tracking and weekly status reports. All of these tasks can be negotiated with the customer.

If Navini Networks is hired by a customer to provide Installation & Commissioning Services, involvement and some actual deliverables are still required by the customer. For example, the customer will need to review or perhaps even explain their Site Design Specifications, approve Logistics Plans, provide shipping information, approve the Network Architecture Plan, etc.

As part of a successful hand-off from Navini to the customer, it is usually necessary for Navini to provide some product training to customer personnel who will support the Base Station operation on-going. Customers may opt to take on a Train-the-Trainer program, in which case Navini certifies the customer’s instructors who then provide staff training thereafter.

Part #40-00047-01 Rev C v1.0 (1.20) 19 September 26, 2003

Base Station User Manual Navini Networks, Inc.

Figure 2: High Level I&C Process Flowchart

Phase I: Pre-installation - Site Selection, Design & Preparation

BEGIN

Sample Statement of Work (SoW)

1 - Complete the Project Plan for this deployment. <Program or Project Manager>

Sample Responsibility Assignment Matrix (RAM)

Sample Work Breakdown Structure (WBS)

2 - Generate a coverage prediction map. <RF Engineering>

3 - Conduct a site survey, filling out the Site Candidate Evaluation Form.

Site Candidate Evaluation Form

4 - Complete the Interference Analysis, following the Interference Sweep Procedure

or,

if available, using the Interference Sweep Tool

.

Interference Sweep Procedure

Interference Sweep Tool

BTS Specifications

RFS Data Sheets

5 - Acquire information about the final site selected by the customer. Physical site design completed.

BTS Outdoor Enclosures Guide

Rectifier/BBU Specifications

A

Sample Base Station Drawing

20 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

Phase I: Pre-installation - Site Selection, Design & Preparation, continued

A

6 - Complete the Network Architecture design. <Network Planning>

7 - Antenna Power & Cable selection.

Antenna Power & Cable Selection Procedure & Form

8 - Develop a Bill of Materials (BoM). <Customer >

Sample BoM

9 - Acquire the materials. <Customer>

10 - Confirm the customer backhaul, EMS Server, FTP Server, input power and grounding are installed and operational at site.

Part #40-00047-01 Rev C v1.0 (1.20) 21 September 26, 2003

Base Station User Manual Navini Networks, Inc.

p

Phase II: Physical Installation

1 - From the shipping containers received at the customer site, gather Manufacturing’s inventory sheet and test data that was collected before the BTS & RFS equipment shipped. Verify all equipment arrived (inventory it), serial numbers match paperwork, and the test data is available. Keep this as part of the customer site records.

2 - Install all system buss bars and surge

rotectors.

3 - Cut cables. Install connectors on cables.

Install Connectors on Cables Procedure

4 - Install & sweep the RF cables. Record results on the RFS System Test Form

.

RFS System Test Form

5 - Install & sweep the GPS cables.

6 - Test & install the data/power cable.

7 - If required, install the BTS mounting rack.

Chassis Alarms Information

8 - Install the BTS chassis.

9 - Install & verify the BTS & RFS grounding.

Sample Tri-sector BTS Grounding Drawing

A

22 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

p

Installation, continued

A

10 - Install & verify the DC input power source to the BTS.

Sample Tri-sector BTS Power Drawing

11 - Install the GPS antennas.

12 - Sweep the RFS, per the Single Antenna Test Procedure. Record the results & the RFS serial numbers on the RFS System Test Form (same form as Step 3, Appendix O).

Single Antenna Test Procedure

13 - Install the RFS & surge protectors. Connect the 9 RF cables & the data/power cable to the RFS.

14 - Sweep the installed RFS & cables to verify connections & cable loss. Record results on the RFS System Test Form (same form as Ste

s 3 & 11, Appendix O).

15 - Verify that the digital cards & RF/PA cards are installed and seated properly.

16 - Record the serial & version numbers of the digital and RF/PA cards on the Base Station Installation Certification Form.

Base Station Installation Certification Form

B

Part #40-00047-01 Rev C v1.0 (1.20) 23 September 26, 2003

Base Station User Manual Navini Networks, Inc.

p

Installation, continued

B

17 - If required in the Responsibility Assignment Matrix (RAM) portion of the Project Plan, test the backhaul to the customer demarcation point.

18 - Provide a printed package of the measured results and equipment inventory to the customer on-site.

19 - Go over the results using the printed

ackage and obtain customer sign-off on the completion of the Installation portion of the work. Use the Base Station Installation Certification Form for sign-off (same form as Ste

15, Appendix T).

24 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

Phase III: Commissioning

1 - Review the customer’s network plans - i.e., T1 vs Ethernet backhaul.

2 - Are you using

the customer’s

EMS Server?

No

3a - Install & configure the Test EMS Server & Client. Connect to the BTS.

3b - Install & configure the customer EMS Server & Client. Connect to the BTS.

Yes

Excel Configuration Form

4 - Enter the RFS configuration by running the RFS script that shipped with the antenna equipment.

5 - Verify that all cables are connected.

6 - Power up the BTS & reconfigure the basic Boot Line parameters through the serial port on the CC card.

7 - After the BTS has been powered up at least 15 minutes, perform 3 calibrations.

A

Part #40-00047-01 Rev C v1.0 (1.20) 25 September 26, 2003

Base Station User Manual Navini Networks, Inc.

N

Commissioning, continued

A

8 - Did it pass

calibration?

No

9a - Perform system troubleshooting procedures.

9b - Perform Base Station calibration. Verify and record the measurements on the Base Station Calibration Verification Form.

Yes

Base Station Calibration Verification Form

10 - Did it pass

calibration

verification?

No

11a - Perform system troubleshooting procedures.

11b - Perform local wired Modem test.

Yes

Local Modem Test Procedures

12 - Did it pass

the wired

Modem test?

o - Go to 11a

Yes

B

26 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

N

Commissioning, continued

B

13 - Perform the local overthe-air (OTA) Modem test.

14 - Did it pass

the OTA

Modem test?

o - Go to 11a

Yes

15 -Was the

Test EMS

used?

No

C

16 - Install & configure the Customer EMS Server & Client. Connect to the BTS.

Yes

17 - Verify the EMS Server & BTS connectivity.

18 - Perform calibration. Ensure successful results 3 times.

D

Part #40-00047-01 Rev C v1.0 (1.20) 27 September 26, 2003

Base Station User Manual Navini Networks, Inc.

m

Commissioning, continued

D

*Note: Step 19 is performed only if no RF plot is available.

C

19* - Validate that the GPS & Constellation Debugger are installed and operational on the Drive Study laptop. Perform a Preliminary Drive Study. Record the results on the Drive Study Form.

Drive Study Form

20 - Perform the Preliminary LOS Location (FTP) Test. Complete 3 uploads & 3 downloads at 3 locations. Record the results on the FTP Test For

.

21 - Perform the Preliminary NLOS Location (FTP) Test. Complete 3 uploads & 3 downloads at 3 locations. Record the results on the FTP Test For

.

FTP Test Form

22 - Send all preliminary test results to Navini Technical Support for evaluation.

23 -Results

adequate?

No

24a - Adjust the RF parameters and troubleshoot. Go back to Step 18, Perform calibration.

Yes

E

28 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

Commissioning, continued

E

24b - Perform full Drive Study, and record the results on the Drive Study Form. This is used for tuning the model (same form as Step 19, Appendix X).

25 - Perform full LOS Location (FTP) Test. Record the results (same form as Step 20, Appendix Y).

26 - Perform full NLOS Location (FTP) Test. Record the results (same form as Step 20, Appendix Y).

27 - Send test results to Navini Technical Support.

28 - Verify system operation with multiple Modems in use.

29 - Back up the EMS database.

30 - Gather all required documents & forms to create a delivery package for the Customer signoff and for the Navini Techical Support database. See Installation Closeout Documentation

.

Site Installation Closeout Documentation

31 - Participate in the Customer sign-off of the Customer Acceptance Form

.

Customer Acceptance Form

Part #40-00047-01 Rev C v1.0 (1.20) 29 September 26, 2003

Base Station User Manual Navini Networks, Inc.

Base Station Components

Base Transceiver Station (BTS)

The BTS consists of the RF Power Amplifiers (PA’s), the digital circuit cards, the backplane, and the mechanical enclosure or housing. It performs the signal processing and RF transmission for the system. There are two types of chassis: Combo and Split. The Combo Chassis is used primarily with 2.4 GHz systems. The Split Chasses is used for all other (2.3, 2.5, 2.6 GHz) systems (Figure 3).

The chassis is compartmentalized into two sections - the RF shelf and the Digital shelf. The BTS connects to the network using a 10/100 Base-T Ethernet connection or up to 8 T1 interfaces. Up to three BTS assemblies can be installed per system, depending on the configuration. The BTS specifications are provided later in this document.

Figure 3: BTS Chassis

RF Shelf

(Power Amplifiers)

Digital Shelf

(Circuit Cards)

Combo Chassis Split Chassis

30 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

Radio Frequency Subsystem (RFS)

The Radio Frequency Subsystem (RFS) is mounted on a transmission tower or building rooftop. It transmits and receives data to and from the Ripwave Customer Premise Equipment (CPE) using a digital beamforming transmission technique. The RFS may be either a panel antenna or an omni antenna (Figure 4).

An RFS panel transmits in a directional mode, covering a transmit angle of 120 degrees. The antenna can be used as a single mode antenna, or it can be used in a group of two or three sectored antennas, covering 240 and 360 degrees respectively. Each panel requires a BTS to operate. For example, in a tri-sectored cell with 3 panels, you would need 3 BTS’s. The omni antenna provides omni-directional coverage of 360 degrees.

An RFS panel or omni contains eight (8) antenna elements, cavity filters, and, optionally, low noise amplifiers (LNA). For downtilt, the omni must be situated as it comes from the factory. A panel’s downtilt can be adjusted at the site. The higher up the antenna is placed, the more downtilt it typically requires.

Figure 4: RFS

Panel (Front)

OmniPanel (Back)

Part #40-00047-01 Rev C v1.0 (1.20) 31 September 26, 2003

Base Station User Manual Navini Networks, Inc.

Global Positioning System (GPS)

One or two Global Positioning System (GPS) antennas are used with each Base Station. A GPS antenna works with a constellation of satellites that orbit the earth, and it provides the ability to pinpoint geographical locations. The two types of GPS antennas that may be ordered with a Ripwave Base Station are the VIC 100 and the Motorola Timing 2000 (Figure 5).

Figure 5: GPS Antennas

VIC 100 GPS

Motorola Timing

Motorola Timing 2000 GPS

2000 GPS

32 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

Mounting Racks & Enclosures

The BTS can be installed indoors or outdoors in industry standard 19- or 23-inch racks. Rack adapters are needed to mount the equipment in a standard 23-inch rack. For outdoor BTS’s, the customer can supply any standard enclosure from a multitude of vendors. Figure 6 shows 3 BTS’s installed indoors.

Figure 6: Indoor BTS

Data/Power Cable Lightning Arrestors Across TopData/Power Cable Lightning Arrestors Across Top

Part #40-00047-01 Rev C v1.0 (1.20) 33 September 26, 2003

Base Station User Manual Navini Networks, Inc.

General Specifications

Input Power

The BTS requires +21 to 28 VDC power supply rated at 60 amps (combo chassis) and at 50 (RF shelf) and 20 (Digital shelf) for the split chassis. Installers are referred to industry standards for power supply installations.

Humidity

The operating environment of the BTS must control relative humidity to 5% to 95% RH, noncondensing.

Heat Dissipation

The combo BTS chassis, under normal operating conditions, will dissipate a maximum of 1000 Watts or 3415 BTU’s. The split chassis will dissipate a maximum of 1500 watts.

Airflow

Fresh air intake for the BTS chassis is along the lower front vertical panel. Exhaust is out of the upper rear of the chassis. The I&C crew must ensure there are no obstacles to airflow present in these areas. Exhaust air from other equipment should not mix with the BTS fresh air intake.

Accessibility

The BTS is intended for installation and use only in a restricted access location.

34 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

Base Station Specifications

Current Ripwave operating frequencies include those shown in Table 3. Testing on other frequencies is underway and soon will be commercially available. The specifications are shown in Table 4.

Table 3: Operating Frequencies

Model Frequency Range Operating Band Chassis

2.3 GHz

2.305 GHz to 2.360 GHz WCS

Table 4: Split Chassis System (WCS Systems)

Antenna Downtilt:

Antenna Gain: Antenna Options: Backhaul Interfaces:

Bandwidth Allocation: Baseband Modulation: Beamforming Gain: Configurations: DC Power Consumption:

DC Power Interface: Duplex Format: Humidity: Mechanical Dimensions:

Multiple Access Schemes: Operational Frequency Band: Operational Temperature: Polarization: Power Control: Regulatory: Reliability/Availability: RF Channel Bandwidth: RF Output Power (per channel):

Sensitivity: Serviceability: Spreading Spectrum Scheme: Storage Temperature: System Features:

System Throughput:

2 & 4 degree options for Omni-directional; Mechanical for 120 degree Sectored 12dBi Omni-directional, 17 dBi for 120-degree Sectored Omni-directional or 120-degree Sectored 10/100 BaseT Ethernet or ATM over T1; up to (8) T1’s with or without IMA, long haul support Dynamic Uplink QAM4 18dB RFS Omni-directional or Sectored. 1 BTS per antenna. +21VDC to +28VDC; 50 amps RF shelf, 20 amps Digital shelf; 1353 Watts typical, 1500 Watts maximum 2 - ¼” lugs for +24V DC and 24V return. Time Division Duplexing (TDD) 0 to 95% non-condensing Digital: H19.2” X W19.0” X D12.9” (add ~1.3” to D with modules installed). RF: H14.0” X W19.0” XD15.2” (add ~1.5” to D with modules installed). Multi-carrier Beamforming Synchronized (MCBS) CDMA See Table 3 0 to +50 degrees C (indoor); -40 to +50 degrees C (outdoor) Vertical Forward & reverse, open & closed loop UL 1950, FCC part 27 Load-sharing 6MHz 5 watts max

-114 dBm/single channel (NF of 5dB) Field replaceable cards, EMS remote reset; Front and rear access required Direct Sequence Spreading (DSS)

-40 to +70 degrees C Reed Soloman forward error correction (FEC), congestion control, automatic repeat request (ARQ), extensive GoS/QoS mechanisms 12 Mbps (fully loaded max raw data rate downstream + upstream)

Split

Part #40-00047-01 Rev C v1.0 (1.20) 35 September 26, 2003

Base Station User Manual Navini Networks, Inc.

Up/down Link Duplex:

Upgradeability: Weight:

Symmetrical or Asymmetrical TDD with a maximum of 3:1 ratio for down/up allocations Software downloads Digital Shelf 35 lbs + RF Shelf 82 lbs.

36 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

N

Materials Specifications

The Base Station installation requires general materials and parts for installation. In Table 5 is a partial list of the items that may be used for a typical installation of the Ripwave Base Station. The quantity and use of materials will vary depending on the specific installation. The lists in Table 5 are based on a 150-foot site.

Table 5: Materials Specifications

Base Station General Materials Requirements List

BTS Install Kit 96-05000-00 Description Supplier Rqd Qty

GROUNDING

Lightning Rod Lightning Rod - 8' MTS

Ground Rod Tinned copper ground rod, 5/8" x 8' MTS

Ground Wire # 2 Stranded green ground wire MTS 50 Ft

Ground Wire # 6 AWG Stranded Green Wire LOCKE 50 Ft

Ground Buss Bar (Tower) Ground buss bar kit, 1/4" x 2-1/2" x 12-1/2" MTS 1 Kit

Ground Buss Bar (Shelter) Copper Gnd buss bar, 1/4" x 4", drilled to 5/8" ALT 1 Kit

Ground Lug #6, One Hole T&B 3 Pcs

Ground Lug #6, Two Hole T&B 6 Pcs

Ground Lug #2, Two Hole T&B 2 Pcs

Grounding Kit (1/2"), LMR600 STD Ground kit, LMR-600, 5' x 3/8" 2 hole lug MTS 27 Kits

Grounding Kit (3/8"), LMR400 STD Ground kit, LMR-400, 5' x 3/8" 2 hole lug MTS 2 Kits

Grounding Kit (1/2"), RF-1/2" Ground Kit, RF-1/2", 2 hole lug

Universal Grounding kits Universal grounding kit, 3' with 3/8" 2 hole lug MTS

ANTENNA SYSTEM

RFS Antenna Omni Antenna

RFS Surge Protector RFS surge protector POLYPHASER 9 Pcs

RFS Antenna Mount Omni Antenna Mount MTS 1 Kit

Weatherproofing kits Universal weatherproofing kit, Large MTS 2 Kits

RFS Antenna Power Cable RFFE Power/Data Main Cable assembly Probity 1 Kit

RFS Antenna Jumper Cable RFFE Power/Data Jumper cable, 10 Feet. Probity 1 Kit

Mounting Clamps Crossover Clamp, 1.5" x 3.5" OD MTS 1 Kit

Mounting Clamps Pipe to pipe clamps, kit of 2 MTS 1 Kit

MAIN FEEDER

RFS Cable LMR 600, 1/2" coaxial cable HUTTON/TIMES 1350 Ft

RFS Type N Male Connectors EZ600 N type, Male connectors HUTTON/TIMES 36 Pcs

Hoisting Grips Pre-laced Hoisting Grip, 1/2" MTS 10 Pcs

Cushion Hangers 1/2" Cushion hanger assembly, 5H, 1/2", kit of 5 MTS 12 kits

Cushion Hangers 3/8" Cushion hanger assembly, 6H, 3/8" for LMR400 MTS

Angle Adapter Adapter, Galvanized, Angle kit of 10 MTS

Cross Cushion Hanger Mounts Cross cushion hanger mount, kit of 5 MTS 6 Kits

Universal Hanger 1/2" Hanger, Universal, Snap-In, 1/2", kit of 10

Support Blocks Mini Coax Support Blocks, kit of 10 MTS 2 Kits

RFS Connector

MALE, N TYPE, 3/8 INCH

MALE, N TYPE, 5/8 INCH

MALE, N TYPE, 1/2 INCH

MALE, N TYPE, 7/8 INCH

FEMALE, N TYPE, 5/8 INCH

K Cables

avini

K Cables

Part #40-00047-01 Rev C v1.0 (1.20) 37 September 26, 2003

Base Station User Manual Navini Networks, Inc.

N

RFS Connector

Weatherproofing

RFS Cable

GPS Antenna GPS Antenna, N-type Female Motorola 2 Pcs

GPS Surge Protector GPS surge protector, Redundant POLYPHASER 2 Pcs

GPS Surge Protector GPS surge protector, Non-redundant POLYPHASER 1 Pc

GPS Cable LMR400, 3/8" coaxial cable HUTTON/TIMES 200 Ft

GPS Type N Male Connectors EZ400 N type, Male connectors HUTTON/TIMES 8 Pcs

Goose Neck - J type Hood entry TBD

Feed Thru Entry Panel TBD

Boot Assembly Kits Boot Assembly Kit, 4" w/ 4 holes (LMR 600) MTS 4 Kits

Ripwave 2400 BTS

BTS Surge Protector BTS surge protector POLYPHASER 9 Pcs

24 VDC Power Supply Argus 1 Unit

DC Power Wire # 6 AWG, Stranded, RED Wire

DC Power Wire # 6 AWG, Stranded, BLACK Wire

BREAKER 24 VDC, 60A Distribution Breaker Argus

ROUTER CISCO 2600 Dual 10/100 ENET, WIC/NM Slots CISCO

SERIAL WAN Serial Interface WAN Card, One Port CISCO

T1-IMA MODULE Multiport T1/E1 Network Module with IMA CISCO

Air conditioning TBD

110 VAC Power Outlets TBD

Telco / Ethernet Connectors RJ45 TBD

Expanding Foam Sealer TBD

Bolts (Ground) Bolt, Hex, 1/4-20 x 1.000 LG, SSPA QUESTRON

uts (Ground)

Flat Washer (Ground) Wash, Flat, Cres, #6 T-B-Reg .156x.438x.040 QUESTRON

Lock Washer (Ground) Wash, Lock. Split, Cres 1/4, Reg .252x.487x.062 QUESTRON

Star Washer (Ground)

Star Washer (BTS Chassis Ground)

ut (BTS, Power/Data Surge P)

Equipment Open Rack

Tie wraps TBD

Split Bolt #2/0 TBD

Uni-Struts TBD

Anchor/Expansion Bolts TBD

Cable Ladder TBD

FEMALE, N TYPE, 7/8 INCH

STRAIGHT PLUG, EZ PIN, FEMALE (LMR400) HUTTON/TIMES

RIGHT ANGLE, EZ PIN, MALE (LMR400) HUTTON/TIMES

RIGHT ANGLE, SOLDER PIN, MALE (LMR400) HUTTON/TIMES

STRAIGHT, SOLDER PIN,MALE (LMR400) HUTTON/TIMES

Sealing Compound, Coax Cable Connector

CABLE, COAX, RF, CORRUGATED, 3/8 INCH

CABLE, COAX, RF, CORRUGATED, 5/8 INCH

CABLE, COAX, RF, CORRUGATED, 1/2 INCH

CABLE, COAX, RF, CORRUGATED, 7/8 INCH

GPS SYSTEM

ENTRY PORT SYSTEM

BTS SYSTEM

MISCELLANEOUS

ut, Reg, Hex, Cres, 1/4-20UNC QUESTRON

Wash, Star, 1/4

Wash, Star, #10

ut, Hex, #10-24

Rack, 19" x 72" with 1/4" x 1" holes

K Cables

avini

QUESTRON

CHATSWORTH

38 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

APPENDIX A: RFS IDENTIFICATION LABEL

2.3 GHz RFS – Omni High Band

2.72 +/-.03

Navini Networks

Ripwave RFS

Model No. 2300-RFS

Model No. 2300-RFS Part No. 95-23008-20

Part No. 95-23008-20 Freq Range: 2345-2360 MHz

Freq Range: 2345-2360 MHz Electrical Down Tilt: 2°

Electrical Down Tilt: 2°

RF SAFETY NOTICE:

This antenna shall be mounted in accord-

ance with the limits for Maximum Personnel

ance with the limits for Maximum Personnel Exposure (MPE) to radio frequency fields as

Exposure (MPE) to radio frequency fields as

per §1.1307 of the Rules of the Federal

Communications Commission (FCC). This

includes labeling on this antenna to identify

the site-specific minimum separation dist-

ance as defined by FCC OET Bulletin 65.

3.58 +/-.03

Part #40-00047-01 Rev C v1.0 (1.20) 39 September 26, 2003

Base Station User Manual Navini Networks, Inc.

2.3 GHz RFS – Omni Low Band

2.72 +/-.032.72 +/-.03

Navini Networks

Ripwave RFS

Model No. 2300-RFS

Model No. 2300-RFS Part No. 95-23008-30

Part No. 95-23008-30 Freq Range: 2305-2320 MHz

Freq Range: 2305-2320 MHz Electrical Down Tilt: 2°

Electrical Down Tilt: 2°

3.58 +/-.03

RF SAFETY NOTICE:

This antenna shall be mounted in accord-

This antenna shall be mounted in accordance with the limits for Maximum Personnel

ance with the limits for Maximum Personnel Exposure (MPE) to radio frequency fields as

Exposure (MPE) to radio frequency fields as per §1.1307 of the Rules of the Federal

per §1.1307 of the Rules of the Federal Communications Commission (FCC). This

Communications Commission (FCC). This includes labeling on this antenna to identify

includes labeling on this antenna to identify the site-specific minimum separation dist-

the site-specific minimum separation distance as defined by FCC OET Bulletin 65.

ance as defined by FCC OET Bulletin 65.

40 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

2.3 GHz RFS – Sector

2.72 +/-.032.72 +/-.03

Navini Networks

Ripwave RFS

Model No. 2300-RFS

Model No. 2300-RFS Part No. 95-23000-06

Part No. 95-23000-06 Freq Range: 2345-2360 MHz

Freq Range: 2345-2360 MHz Electrical Down Tilt: 6°

Electrical Down Tilt: 6°

RF SAFETY NOTICE:

This antenna shall be mounted in accord-

This antenna shall be mounted in accordance with the limits for Maximum Personnel

ance with the limits for Maximum Personnel Exposure (MPE) to radio frequency fields as

Exposure (MPE) to radio frequency fields as per §1.1307 of the Rules of the Federal

per §1.1307 of the Rules of the Federal Communications Commission (FCC). This

Communications Commission (FCC). This includes labeling on this antenna to identify

includes labeling on this antenna to identify the site-specific minimum separation dist-

the site-specific minimum separation distance as defined by FCC OET Bulletin 65.

ance as defined by FCC OET Bulletin 65.

3.58 +/-.03

Model No. 2300-RFS

Model No. 2300-RFS Part No. 95-23000-01

Part No. 95-23000-01 Freq Range: 2305-2320 MHz

Freq Range: 2305-2320 MHz Electrical Down Tilt: 6°

Electrical Down Tilt: 6°

This antenna shall be mounted in accord-

This antenna shall be mounted in accordance with the limits for Maximum Personnel

ance with the limits for Maximum Personnel Exposure (MPE) to radio frequency fields as

Exposure (MPE) to radio frequency fields as per §1.1307 of the Rules of the Federal

per §1.1307 of the Rules of the Federal Communications Commission (FCC). This

Communications Commission (FCC). This includes labeling on this antenna to identify

includes labeling on this antenna to identify the site-specific minimum separation dist-

the site-specific minimum separation distance as defined by FCC OET Bulletin 65.

ance as defined by FCC OET Bulletin 65.

2.72 +/-.032.72 +/-.03

Navini Networks

Ripwave RFS

RF SAFETY NOTICE:

3.58 +/-.03

Part #40-00047-01 Rev C v1.0 (1.20) 41 September 26, 2003

Base Station User Manual Navini Networks, Inc.

42 Part #40-00197-00 Rev C v1.0 (1.20)

September 26, 2003

Navini Networks, Inc. Base Station User Manual

APPENDIX B: 2.3 GHZ BTS IDENTIFICATION LABEL

2.72 +/-.03

Navini Networks

Ripwave BTS

Model No. 2300-DIGITAL Part No. 95-70003-05

Freq Range US: 2305-2320 MHz

FCC ID: PL6-WCS-BTS1

2345-2360 MHz

INT’L: 2375-2385 MHz

3.00 +/-.03

Model No. 2300-RF Part No. 95-50003-01

Freq Range US: 2305-2320 MHz

FCC ID: PL6-WCS-BTS1

2.72 +/-.03

Navini Networks

Ripwave BTS

2345-2360 MHz

INT’L: 2375-2385 MHz

3.00 +/-.03

NOTE

umber is not valid and could possibly change. n

CLEAR WINDOW FOR NAVINI

BAR CODE (1.5000 X .375, SIZE

OF LABEL)

: This device has not (yet) been authorized by the FCC. Therefore, the FCC ID

Part #40-00047-01 Rev C v1.0 (1.20) 43 September 26, 2003
