Data Sheet
Cisco UCS 6200 Series Fabric Interconnects
Cisco Unified Computing System Overview
The Cisco Unified Computing System™ (Cisco UCS™) is a next-generation data center platform that unites
computing, networking, storage access, and virtualization resources into a cohesive system designed to reduce
total cost of ownership (TCO) and increase business agility. The system integrates a low-latency, lossless
10 Gigabit Ethernet unified network fabric with enterprise-class, x86-architecture servers. The system is an
integrated, scalable, multichassis platform in which all resources participate in a unified management domain
(Figure 1).
Figure 1. The Cisco Unified Computing System Is a Highly Available Cohesive Architecture
© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 1 of 10
Product Overview
The Cisco UCS 6200 Series Fabric Interconnects are a core part of the Cisco Unified Computing System,
providing both network connectivity and management capabilities for the system (Figure 2). The Cisco UCS 6200
Series offers line-rate, low-latency, lossless 10 Gigabit Ethernet, Fibre Channel over Ethernet (FCoE), and Fibre
Channel functions.
The Cisco UCS 6200 Series provides the management and communication backbone for the Cisco UCS B-Series
Blade Servers and 5100 Series Blade Server Chassis. All chassis, and therefore all blades, attached to the Cisco
UCS 6200 Series Fabric Interconnects become part of a single, highly available management domain. In addition,
by supporting unified fabric, the Cisco UCS 6200 Series provides both the LAN and SAN connectivity for all blades
within its domain.
From a networking perspective, the Cisco UCS 6200 Series uses a cut-through architecture, supporting
deterministic, low-latency, line-rate 10 Gigabit Ethernet on all ports, switching capacity of 2 terabits (Tb), and
320-Gbps bandwidth per chassis, independent of packet size and enabled services. The product family supports
Cisco® low-latency, lossless 10 Gigabit Ethernet1 unified network fabric capabilities, which increase the reliability,
efficiency, and scalability of Ethernet networks. The fabric interconnect supports multiple traffic classes over a
lossless Ethernet fabric from the blade through the interconnect. Significant TCO savings come from an
FCoE-optimized server design in which network interface cards (NICs), host bus adapters (HBAs), cables, and
switches can be consolidated.
Figure 2. Cisco UCS 6200 Series Fabric Interconnects
Unified Fabric with FCoE: I/O Consolidation
The Cisco UCS 6200 Series is built to consolidate LAN and SAN traffic onto a single unified fabric, saving the
capital expenditures (CapEx) and operating expenses (OpEx) associated with multiple parallel networks, different
types of adapter cards, switching infrastructure, and cabling within racks. The unified ports support allows either
base or expansion module ports in the interconnect to support direct connections from Cisco UCS to existing
native Fibre Channel SANs. The capability to connect FCoE to native Fibre Channel protects existing storage
system investments while dramatically simplifying in-rack cabling.
1
All Cisco UCS 6200 Series ports can alternatively be configured for 1 Gigabit Ethernet (see Table 2).
© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 2 of 10
Cisco UCS Manager
The Cisco UCS 6200 Series hosts and runs Cisco UCS Manager in a highly available configuration, enabling the
fabric interconnects to fully manage all Cisco UCS elements. Connectivity to the Cisco UCS 5100 Series blade
chassis is maintained through the Cisco UCS 2100 or 2200 Series Fabric Extenders in each blade chassis. The
Cisco UCS 6200 Series interconnects support out-of-band management through a dedicated 10/100/1000-Mbps
Ethernet management port as well as in-band management. Cisco UCS Manager typically is deployed in a
clustered active-passive configuration on redundant fabric interconnects connected through dual 10/100/1000
Ethernet clustering ports.
Optimization for Virtualization
For virtualized environments, the Cisco UCS 6200 Series supports Cisco virtualization-aware networking and
Cisco Data Center Virtual Machine Fabric Extender (VM-FEX) architecture. Cisco Data Center VM-FEX allows the
interconnects to provide policy-based virtual machine connectivity, with network properties moving with the virtual
machine, and a consistent operational model for both physical and virtual environments.
Cisco UCS 6248UP 48-Port Fabric Interconnect
The Cisco UCS 6248UP 48-Port Fabric Interconnect (Figure 3) is a one-rack-unit (1RU) 10 Gigabit Ethernet, FCoE
and Fiber Channel switch offering up to 960-Gbps throughput and up to 48 ports. The switch has 32 1/10-Gbps
fixed Ethernet, FCoE and FC ports and one expansion slot.
Figure 3. Cisco UCS 6248UP 48-Port Fabric Interconnect
Cisco UCS 6296UP 96-Port Fabric Interconnect
The Cisco UCS 6296UP 96-Port Fabric Interconnect (Figure 4) is a 2RU 10 Gigabit Ethernet, FCoE and native
Fibre Channel switch offering up to 1920-Gbps throughput and up to 96 ports. The switch has 48 1/10-Gbps fixed
Ethernet, FCoE and Fiber Channel ports and three expansion slots.
Figure 4. Cisco UCS 6296UP 96-Port Fabric Interconnect
© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 3 of 10
Table 1 summarizes the characteristics of the Cisco UCS 6200 Series Fabric interconnects.
Table 1. Characteristics of Cisco UCS 6200 Series Fabric Interconnects2
Item Cisco UCS 6248UP Cisco UCS 6296UP
Description 48-port fabric interconnect 96-port fabric interconnect
Form factor 1RU 2RU
Number of fixed 10 Gigabit Ethernet and FCoE
Enhanced Small Form-Factor Pluggable (SFP+) ports
Throughput 960 Gbps 1920 Gbps
Expansion slots 1 3
Fan modules 1+1 2+2
32 fixed ports with an additional 16 ports
available through expansion module
48 fixed ports with an additional 48 ports
available through three expansion module
Expansion Module Option for Cisco UCS 6200 Series Fabric Interconnects
The Cisco UCS 6200 Series supports an expansion module that can be used to increase the number of 10 Gigabit
Ethernet, FCoE and FC ports (Figure 5). This unified port module provides up to 16 ports that can be configured
for 10 Gigabit Ethernet, FCoE and/or 1/2/4/8-Gbps native Fibre Channel using the SFP or SFP+3 interface for
transparent connectivity with existing Fibre Channel networks.
Figure 5. Unified Port 16-Port Expansion Module
Features and Benefits
Table 2 summarizes the features and benefits of the Cisco UCS 6200 Series.
Table 2. Features and Benefits
Feature Benefit
Management by Cisco
UCS Manager
Unified fabric
Fabric extender
architecture
Performance
●
Allows all elements connected to the interconnects to participate in a single, highly available management domain
●
Decreases TCO by reducing the number of NICs, HBAs, switches, and cables needed
●
Transparently encapsulates Fibre Channel packets into Ethernet
●
Scales to 20 chassis without adding complexity by eliminating the need for dedicated chassis management and
blade switches and by reducing the number of cables needed
●
Provides deterministic latency for optimized application performance
●
Provides high-speed, low-latency connectivity to the chassis
●
Provides approximately 50% reduction in end-to-end system latency (latency is 3.2 microseconds)
2
The Cisco UCS 6200 Series requires Cisco UCS Manager operating software Release 2.0 or later.
3
Ports are fully compatible with the 8GFC standard and negotiate among 1, 2, 4, and 8 Gbps, constrained by optics
compatibility. Ports support both 1/2/4-Gbps Cisco 4GFC optical transceivers using the SFP interface and 2/4/8-Gbps Cisco
8GFC optical transceivers using the SFP+ interface.
© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 4 of 10
Feature Benefit
Lossless fabric
Priority flow control
(PFC)
Systemwide bandwidth
management
Cisco Data Center
VM-FEX technology
Rear ports
Redundant hot-
swappable fans and
power supplies
Front-to-back cooling
SFP+ ports
SFP-compatible ports
Port-based licensing
options
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
Provides a reliable, robust foundation for unifying LAN and SAN traffic on a single transport
Simplifies management of multiple traffic flows over a single network link
Supports different classes of service, helping enable both lossless and classic Ethernet on the same fabric
Helps enable consistent and coherent quality of service (QoS) throughout the system
Helps enable a consistent operational model between virtual and physical environments
Provides the same level of network visibility for virtualized and nonvirtualized environments
Improves diagnostic and troubleshooting capabilities in a virtual environment
Simplifies network and security policy enforcement when migrating virtual machines from one host to another
Helps keep cable lengths short and efficient
Helps enable high availability in multiple configurations
Increases serviceability
Provides uninterrupted service during maintenance
Supports efficient data center hot- and cold-aisle designs
Increases flexibility with a range of interconnect solutions, including copper Twinax cable for short runs and fiber for
long runs
Consumes less power per port than traditional solutions
Helps enable cost-effective connections on fabric extenders with Cisco Fabric Extender Transceiver (FET) optics
Allows all fixed and modular expansion ports to be configured to operate in 1 Gigabit Ethernet mode with the
transceiver options specified for use with SFP-compatible ports in Table 3
Helps enable a pay-as-you-go model, allowing customers to add capacity as the networking needs of an individual
system increase
Product Specifications
Transceivers
The Cisco UCS 6200 Series supports a wide variety of 10 Gigabit Ethernet connectivity options using Cisco
10GBASE SFP+ modules. In addition, all fixed and modular expansion ports on the Cisco UCS 6200 Series
support 1 Gigabit Ethernet connectivity options using 1GBASE SFP modules. Alternatively, 2/4/8-Gbps Fibre
Channel SFP+ and 1/2/4-Gbps Fibre Channel SFP interfaces are supported on all ports.
Table 3 lists the supported transceiver options.
Table 3. Cisco UCS 6200 Series Transceiver Support Matrix
Cisco SFP Description
Cisco SFP-10G-SR 10GBASE-SR SFP+ module (multimode fiber [MMF])
Cisco SFP-10G-LR 10GBASE-LR SFP+ module (single-mode fiber [SMF])
Cisco SFP-H10GB-
CU1M
Cisco SFP-H10GB-
CU3M
Cisco SFP-H10GB-
CU5M
SFP-H10GB-ACU7M 10GBASE-CU SFP+ cable 7m (Twinax cable)
SFP-H10GB-ACU10M 10GBASE-CU SFP+ cable 10m (Twinax cable)
Cisco FET-10G 10GBASE-FET SFP+ module (MMF)
Cisco GLC-T 1000BASE-T SFP (for SFP-compatible ports only, as defined in Table 2)
Cisco GLC-SX-MM GE SFP, LC connector SX transceiver (MMF) (for SFP-compatible ports only, as defined in Table 2)
Cisco GLC-LH-SM GE SFP, LC connector LX/LH transceiver (SMF) (for SFP-compatible ports only, as defined in Table 2)
Cisco SFP-GE-T 1000BASE-T SFP, extended temperature range (for SFP-compatible ports only, as defined in Table 2)
10GBASE-CU SFP+ cable 1m (Twinax cable)
10GBASE-CU SFP+ cable 3m (Twinax cable)
10GBASE-CU SFP+ cable 5m (Twinax cable)
© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 5 of 10
Cisco SFP Description
Cisco SFP-GE-S GE SFP, LC connector SX transceiver (MMF), extended temperature range and digital optical monitoring (DOM)
Cisco SFP-GE-L GE SFP, LC connector LX/LH transceiver (SMF), extended temperature range and DOM (for SFP-compatible ports
Cisco DS-SFP-FC4G-SW 4-Gbps Fibre Channel SW SFP, LC
Cisco DS-SFP-FC4G-LW 4-Gbps Fibre Channel LW SFP, LC
Cisco DS-SFP-FC8G-SW 8-Gbps Fibre Channel SW SFP+, LC
Cisco DS-SFP-FC8G-LW 8-Gbps Fibre Channel LW SFP+, LC
(for SFP-compatible ports only, as defined in Table 2)
only, as defined in Table 2)
Cabling
Table 4 provides 10 Gigabit Ethernet cabling specifications for the Cisco UCS 6200 Series.
Table 4. Cabling Specifications
Connector (Media) Cable Distance Power (Each Side) Transceiver Latency
SFP+ copper (CU) Twinax 1, 3, and 5m Approximately 0.1
SFP+ FET MM OM2
MM OM3
MM OM4
SFP+ short reach (SR)
and MMF
SFP+ long reach (LR) SMF 300m over SMF 1W Approximately 0
MM OM2
MM OM3
MM OM4
25 and 100m 1W Approximately 0
82 and 300m 1W Approximately 0
watt (W)
(Link)
Approximately 0.1
microsecond
microseconds
microseconds
microseconds
Performance
●
Cisco UCS 6248UP: Layer 2 hardware forwarding at 960 Gbps or 714.24 million packets per second
(mpps)
●
Cisco UCS 6296UP: Layer 2 hardware forwarding at 1.92 Tbps or 1428.48 million packets per second
(mpps)
●
MAC address table entries: 32,000
●
Low-latency cut-through design: Provides predictable, consistent traffic latency regardless of packet size,
traffic pattern, or enabled features
Layer 2
●
Layer 2 interconnect ports and VLAN trunks
●
IEEE 802.1Q VLAN encapsulation
●
Support for up to 1024 VLANs and virtual SANs (VSANs) per interconnect
●
Rapid Per-VLAN Spanning Tree Plus (PVRST+)
●
Internet Group Management Protocol (IGMP) Versions 1, 2, and 3 snooping
●
Cisco EtherChannel technology
●
Link Aggregation Control Protocol (LACP): IEEE 802.3ad
●
Advanced EtherChannel hashing based on Layer 2, 3, and 4 information
●
Jumbo frames on all ports (up to 9216 bytes)
Standard
SFF 8431
IEEE 802.3ae
IEEE 802.3ae
IEEE 802.3ae
© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 6 of 10
●
Pause frames (IEEE 802.3x)
QoS
●
Layer 2 IEEE 802.1p (class of service [CoS])
●
Eight hardware queues per port
●
Per-port QoS configuration
●
CoS trust
●
Per-port virtual output queuing
●
CoS-based egress queuing
●
Egress strict-priority queuing
●
Egress port-based scheduling: Weighted Round-Robin (WRR)
High Availability
●
Hot-swappable field-replaceable power supplies, fan modules, and expansion modules
●
1+1 power redundancy
●
N+1 fan module redundancy
Management
●
Interconnect management using redundant 10/100/1000-Mbps management or console ports
●
All management provided through Cisco UCS Manager; please refer to the Cisco UCS Manager data sheet
for more information about management interfaces
Low-Latency, Lossless 10 Gigabit Ethernet Unified Network Fabric
●
PFC (per-priority pause frame support)
●
Data Center Bridging Exchange (DCBX) Protocol
●
IEEE 802.1Qaz: Bandwidth management
●
Layer 2 multipathing (future)
Unified Ports
●
All ports configurable as 1/10 Gigabit Ethernet or 1/2/4/8-Gbps Fibre Channel
Industry Standards
●
IEEE 802.1p: CoS prioritization
●
IEEE 802.1Q: VLAN tagging
●
IEEE 802.1s: Multiple VLAN instances of Spanning Tree Protocol
●
IEEE 802.1w: Rapid reconfiguration of Spanning Tree Protocol
●
IEEE 802.3: Ethernet
●
IEEE 802.3ad: LACP
●
IEEE 802.3ae: 10 Gigabit Ethernet
●
SFP+ support
●
RMON
© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 7 of 10
Physical Specifications
SFP+ Optics
Cisco UCS products support 10 Gigabit Ethernet SFP+ copper Twinax cables for short distances and SFP+ optics
for longer distances. SFP+ has several advantages compared to other 10 Gigabit Ethernet connectivity options:
●
Small 10 Gigabit Ethernet form factor
●
Optical interoperability with XENPAK, X2, and 10 Gigabit Small Form-Factor Pluggable (XFP) interface
types
●
Low power consumption
●
Hot-swappable device
Power Supply
Tables 5 and 6 summarize the power supply properties for the Cisco UCS 6200 Series.
Table 5. AC Power Supply
Property Cisco UCS 6248UP Cisco UCS 6296UP
Typical operating power 350W 750W
Maximum power 600W 950W
Input voltage 100 to 240 VAC 100 to 240 VAC
Frequency 50 to 60 Hz 50 to 60 Hz
Efficiency 95 to 98% (50 to 100% load) 95 to 98% (50 to 100% load)
RoHS compliance Yes Yes
Hot swappable Yes Yes
Heat dissipation 1998 BTU/hr 3163 BTU/hr
Table 6. DC Power Supply
Property Cisco UCS 6248UP
Typical operating power 400W with 48-ports running 100%
Maximum output power 750W
Input voltage -40 to -72VDC
Input current 25A maximum
Maximum input power 1000W
Efficiency 88 to 92% (50 to 100% load)
RoHS compliance Yes
Hot swappable Yes
Heat dissipation 75W (10% of 750W)
© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 8 of 10
Cisco UCS 6200 Series Physical and Environmental Specifications
Table 7 summarizes the physical and environmental specifications for the Cisco UCS 6200 Series.
Table 7. Physical and Environmental Specifications
Property Cisco UCS 6248UP Cisco UCS 6296UP
Physical
(height x width x depth)
Operating temperature 32 to 104°F (0 to 40°C) 32 to 104°F (0 to 40°C)
Nonoperating temperature -40 to 158°F (-40 to 70°C) -40 to 158°F (-40 to 70°C)
Humidity 5 to 95% (noncondensing) 5 to 95% (noncondensing)
Altitude 0 to 10,000 ft (0 to 300m) 0 to 10,000 ft (0 to 300m)
Weight
Table 8 summarizes the weights for the Cisco UCS 6200 Series.
Table 8. Weight
1.72 x 17.3 x 30.0 in.
(4.4 x 43.9 x 76.2 cm)
3.44 x 17.3 x 29.5 in.
(8.8 x 43.9 x 74.9 cm)
Component Weight
Cisco UCS 6248UP with two power supplies, one expansion module, and two fan modules 35 lb (15.88 kg)
Cisco UCS 6296UP with two power supplies, three expansion module, and four fan modules 50 lb (22.67 kg)
Regulatory Standards Compliance: Safety and EMC
Table 9 summarizes Cisco UCS 6200 Series regulatory compliance.
Table 9. Regulatory Standards Compliance
Specification Description
Regulatory compliance Products should comply with CE Markings according to directives 2004/108/EC and 2006/95/EC
●
Safety
EMC: Emissions
EMC: Immunity
UL 60950-1
●
CAN/CSA-C22.2 No. 60950-1
●
EN 60950-1
●
IEC 60950-1
●
AS/NZS 60950-1
●
GB4943
●
47CFR Part 15 (CFR 47) Class A
●
AS/NZS CISPR22 Class A
●
CISPR22 Class A
●
EN55022 Class A
●
ICES003 Class A
●
VCCI Class A
●
EN61000-3-2
●
EN61000-3-3
●
KN22 Class A
●
CNS13438 Class A
●
EN50082-1
●
EN61000-6-1
●
EN55024
●
CISPR24
●
EN300386
●
KN 61000-4 series
© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 9 of 10
Specification Description
RoHS The product is RoHS 5-compliant with exceptions for leaded ball grid array (BGA) balls and lead press-fit connectors
Warranty Information
Warranty information is provided at Cisco.com on the Product Warranties page.
Cisco Unified Computing Services
Using a unified view of data center resources, Cisco and our industry-leading partners deliver services that
accelerate your transition to a unified computing environment. Cisco Unified Computing Services helps you quickly
deploy your data center resources and optimize ongoing operations to better meet your business needs. For more
information about these and other Cisco Data Center Services, visit
http://www.cisco.com/go/dcservices.
Why Cisco?
Cisco has significant experience in listening to customer requirements and providing solid technology innovation
for the enterprise data center. Cisco delivers standards-based solutions backed by a broad partner ecosystem of
industry leaders to provide end-to-end customer solutions. Unified computing elevates the traditional product
classification of network, server, storage, operating systems, and applications to a vision that encompasses the
whole data center. Cisco, as one of the largest technology providers in the world, has the resources, expertise,
and customer focus to deliver on this vision.
For More Information
For more information about the Cisco UCS 6200 Series Fabric Interconnects, visit
http://www.cisco.com/en/US/products/ps10276/index.html or contact your local account representative.
Printed in USA C78-675245-05 10/13
© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 10 of 10
Loading...
