Cisco STM-1 User Manual

Multichannel STM-1 Port Adapter for the
Cisco 7500 Series Router

This feature module describes the Multichannel STM-1 Port Adapter (PA-MC-STM-1). It includes
information on the benefits of this port adapter, supported platforms, related documents, configuration
examples and a command reference detailing new and enhanced commands.

This document includes the following sections:

• Feature Overview, page 1

• Supported Platforms, page 3

• Supported Standards, MIBs, and RFCs, page 3

• Prerequisites, page 4

• Configuration Tasks, page 4

• Monitoring and Maintaining the PA-MC-STM-1, page 22

• Configuration Examples, page 22

• Command Reference, page 24

• Glossary, page 47

Feature Overview

The PA-MC-STM-1 is a high-speed single-port multichannel STM-1 port adapter. You can configure the
PA-MC-STM-1 as a multichannel E1/E0 STM-1 port. The PA-MC-STM-1 can be configured into 63
individual E1 links. Each E1 link can carry a single channel at full or fractional rates, or be broken down
into multiple DS0 or Nx64 Kbps rates. The PA-MC-STM-1 supports up to three TUG-3/AU-3 transport
slots numbered 1 through 3. You can configure each TUG-3/AU-3 to carry 21 SDH TU-12s. Each SDH
TU-12 is capable of carrying a channelized E1 frame, which can be unchannelized to N*64 Kbps
timeslots.

12.0(14)S

1

Feature Overview

PA-MC-STM-1 Multiplexing Hierarchy

Figure 1 illustrates the synchronous digital hierarchy (SDH) multiplexing structure supported on the
PA-MC-STM-1. The PA-MC-STM-1 multiplexing structure is a subset of that defined in ITU-T G.707.
At the lowest level, containers are input into virtual containers (VC) with stuffing bits to create a uniform
VC payload with a common bit-rate, ready for synchronous multiplexing. The VCs are then aligned into
tributary units (TUs) where pointer processing operations are implemented. This allows the TUs to be
multiplexed into TU groups (TUGs). Three TU-12s can be multiplexed into one TUG-2.

Figure 1 PA-STM-1 Multiplexing Structure

Multichannel STM-1 Port Adapter for the Cisco 7500 Series Router

E1

2.048 Mbps

Benefits

C-12

VC-12

TU-12

TUG-3

x3

TUG-2

x7

x3

VC-4

VC-3 AU-3

x7

x1

x1

AU-4

x1

x3

AUG

x1

STM-1

47902

The TUGs are then multiplexed into higher-level VCs, which in turn are multiplexed into administrative
units (AUs).The AUs are then multiplexed into an AU group (AUG), and the final payload from the AUG
is then multiplexed into the Synchronous Transport Module (STM).

The PA-MC-STM-1 port adapter provides the following benefits:

• High-density IP aggregation

• Reduction in provisioning costs

• Improved cable management

• Easier scaling of services

• Improved network availability

Restrictions

The PA-MC-STM-1 does not support the following:

• VIP2

• More than 256 logical channel groups per PA-MC-STM-1

• Channel-associated-signaling (CAS) for voice channels

• E1 Facility Data Link (FDL)

• E3 and subrate E3

12.0(14)S

2

Multichannel STM-1 Port Adapter for the Cisco 7500 Series Router

Related Features and Technologies

• PA- MC -T 3

• PA- MC -E 3

Related Documents

PA-MC-STM-1 Port Adapter Installation and Configuration

Supported Platforms

• Cisco 7500 series

Supported Standards, MIBs, and RFCs

Supported Platforms

Standards

• CCITT/ITU G.704

• CCITT/ITU G.706

• CSA C22.2, No. 950

• ITU-T O.151

• ITU-T O.152

• ITU-T O.153

• FCC Part 15, class A

• FCC Part 68

• G.704

• G.706

• G.707

• UL1950 3rd Edition

MIBs

No new or modified MIBs are supported by this feature.

To obtain lists of MIBs supported by platform and Cisco IOS release and to download MIB modules, go
to the Cisco MIB web site on Cisco Connection Online (CCO) at
http://www.cisco.com/public/sw-center/netmgmt/cmtk/mibs.shtml.

12.0(14)S

3

Prerequisites

RFCs

• RFC 1406, Definitions of Managed Objects for the DS1 and E1 Interface Types

• RFC 1595, Definitions of Managed Objects for the SONET/SDH Interface Type

Note Because E1 FDL is not supported by the PA-MC-STM-1, the far-end statistics and control

groups defined by RFC 1406 are not available.

Prerequisites

The PA-MC-STM-1 requires a VIP4-80 installed in a Cisco 7500 series router.

Configuration Tasks

See the following sections for configuration tasks for the PA-MC-STM-1. Each task in the list indicates
if the task is optional or required.

• Configuring the SONET Controller (Required)

• Configuring an AU-3 (Required)

Multichannel STM-1 Port Adapter for the Cisco 7500 Series Router

• Configuring a TUG-3 (Required)

• Configuring a Channel Group on an E1 of an AU-3 (Required)

• Configuring a Channel Group on an E1 of a TUG-3 (Required)

• Configuring an E1 Line Mapped to an AU-3 (Required)

• Configuring an E1 Line Mapped to a TUG-3 (Required)

• Verifying the Configuration

Configuring the SONET Controller

Command Purpose

Step 1

Step 2

Step 3

Router# configure terminal

Router(config)# controller sonet

slot/port-adapter/port

Router(config-controller)# [no] framing {sonet | sdh}

Enters configuration mode and specifies that the
console terminal is the source of the configuration
subcommands.

Selects a port of a PA-MC-STM-1 and enters
controller configuration mode.

Configures the framing mode of the
PA-MC-STM-1 to SONET or SDH.

SDH is the ITU standards equivalent of SONET.

SONET is the default.

12.0(14)S

4

Multichannel STM-1 Port Adapter for the Cisco 7500 Series Router

Command Purpose

Step 4

Step 5

Step 6

Router(config-controller)# clock source
{internal | line}

Router(config-controller)# [no] loopback {local |
network}

Router(config-controller)# [no] description string

Configuration Tasks

Configures the clock source used by the SONET
controller.

• internal—The clocking source is obtained

from the port adapter line.

• line—The clocking source is obtained from

the network.

Enables or disables loopback mode on a SONET
controller.

• local—Data is looped from the transmit path

to the receive path allowing diagnostics to
send data to itself without relying on any
external connections.

• network—Data is looped from the external

port to the transmit port and back out the
external port.

No loopback enabled is the default.

Specifies up to 80 characters of text describing the
SONET controller. No description is the default.

Configuring an AU-3

Each of the administrative unit group (AUGs) and tributary unit group (TUGs) of a PA-MC-STM-1 can
be configured to carry a set of E1 links that are mapped into TU-12s. To configure the AUG mapping to
AU-3, follow the steps below:

Command Purpose

Step 1

Step 2

Step 3

Step 4

Step 5

Step 6

Router(config)# controller sonet

slot/port-adapter/port

Router(config-controller)# framing sdh

Router(config-controller)# [no] aug mapping au-3

Router(config-controller)# au-3 au-3-number

Router(config-ctrlr-au3)# mode c-12

Router(config-ctrlr-au3)# idle pattern pattern

Enters SONET controller configuration mode.

Configures the framing mode of the to SDH.

Maps the AUG to AU-3 with the following
muxing/alignment/mapping:

C-12 <-->VC-12 <--> TU-12<--> TUG-2
<--> VC-3 <--> AU-3 <--> AUG

Specifies the AU-3 number to configure:.

• au-3-number—a number in the range of

1to3.

Specifies the mode of operation of the AU-3.

• c-12—The AU-3 is divided into 21 TU-12s

each carrying an E1.

Configures the idle pattern that is to be transmitted
for unused time slots on all E1 lines of a AU-3.

• pattern—number in the range 0x0 to 0xFF

(hexadecimal) or 0 to 225 (decimal).

12.0(14)S

5

Configuration Tasks

Configuring a TUG-3

Each of the administrative unit group (AUGs) and tributary unit group (TUGs) of a PA-MC-STM-1 can
be configured to carry a set of E1 links that are mapped into TU-12s. To configure the AUG mapping to
AU-4, follow the steps below:

Command Purpose

Step 1

Step 2

Step 3

Step 4

Router(config)# controller sonet

slot/port-adapter/port

Router(config-controller)# framing sdh

Router(config-controller)# [no] aug mapping au-4

Router(config-controller)# au-4 au-4-number tug-3

tug-3-number

Multichannel STM-1 Port Adapter for the Cisco 7500 Series Router

Enters SONET controller configuration mode.

Configures the framing mode of the to SDH.

Maps the AUG to AU-4 with the following
muxing/alignment/mapping:

C-12 <-->VC-12 <--> TU-12<--> TUG-2
<--> TUG-3 <--> VC-4 <--> AU-4 <--> AUG

Specifies the TUG-3 number to configure:

• au-4-number—a number in the range of 1 to N

where N is the STM level (For the
PA-MC-STM-1 N is always 1.)

• tug-3-number—a number in the range of

Step 5

Step 6

Router(config-ctrlr-tug3)# mode c-12

Router(config-ctrlr-tug3)# idle pattern pattern

Specifies the mode of operation of a TUG-3:

• c-12—The TUG-3 is divided into 21 TU-12s

Configures the idle pattern that is to be transmitted
for unused time slots on all E1 lines of an AU-4.

• pattern—number in the range 0x0 to 0xFF

Configuring a Channel Group on an E1 of an AU-3

Command Purpose

Step 1

Step 2

Step 3

Step 4

Router(config)# controller sonet

slot/port-adapter/port

Router(config-controller)# framing sdh

Router(config-controller)# [no] aug mapping au-3

Router(config-controller)# au-3 au-3-number

Enters SONET controller configuration mode.

Configures the framing mode of the to SDH.

Maps the AUG to an AU-3 with the following
muxing/alignment/mapping:

Specifies the AU-3 number to configure:.

1to3.

each carrying an E1.

(hexadecimal) or 0 to 225 (decimal)

C-12 <-->VC-12 <--> TU-12<--> TUG-2
<--> VC-3 <--> AU-3 <--> AUG

12.0(14)S

6

• au-3-number—a number in the range of

1to3.

Multichannel STM-1 Port Adapter for the Cisco 7500 Series Router

Command Purpose

Step 5

Step 6

Router(config-ctrlr-au3)# mode c-12

Router(config-ctrlr-tug3)# [no] tug-2 tug-2-number e1

e1-number channel-group channel-group-number timeslots
list-of-timeslots

or

Configuration Tasks

Specifies the mode of operation of the AU-3.

• c-12—The AU-3 is divided into 21 TU-12s

each carrying an E1.

Creates a logical channel group on an E1 line.

• tug-2-number—a number in the range of1 to 7

• e1-number—a number in the range of 1 to 3

• channel-group—defines a logical channel

group to be a channelized E1 line

• channel-group-number—a number in the

range of 0 to 30

• list-of-timeslots—a number in the range of

1 to 31 or a combination of subranges within
1 to 31 (Each subrange is a list of timeslots
that makes up the E1 line.)

Use the no form of this command to remove a
logical channel group.

The default is no channel group configured on an
E1 line.

Step 7

Step 8

Step 9

Step 10

Router(config-ctrlr-tug3)# [no] tug-2 tug-2-number e1
e1-number unframed

Router(config-ctrlr-au3)# exit
Router(config-controller)# exit

Router(config)# interface serial

slot/port-adapter/port.au-3-number/tug-2-number/
e1-number:chanel-group-number

Router(config-if)# ip address 1.1.1.10 255.255.255.255

Router(config-if)# encapsulation ppp

Creates an unframed (clear channel) logical
channel group on an E1 line.

• tug-2-number—a number in the range of

1to7

• e1-number—a number in the range of 1 to 3

Returns to configuration mode.

Selects the channel group interface to configure.

Note When an unframed (clear

channel logical channel
group is configured on an E1
line, the
channel-group-number is
always 0.

Enables IP on the channel group interface.

Enables PPP on the channel group interface.

12.0(14)S

7

Multichannel STM-1 Port Adapter for the Cisco 7500 Series Router

Configuration Tasks

Configuring a Channel Group on an E1 of a TUG-3

Command Purpose

Step 1

Step 2

Step 3

Step 4

Step 5

Router(config)# controller sonet

slot/port-adapter/port

Router(config-controller)# framing sdh

Router(config-controller)# [no] aug mapping au-4

Router(config-controller)# au-4 au-4-number tug-3

tug-3-number

Router(config-ctrlr-tug3)# mode c-12

Enters SONET controller configuration mode.

Configures the framing mode of the to SDH.

Maps the AUG to AU-4 with the following
muxing/alignment/mapping:

Specifies the AU-4 and TUG-3 number to
configure:

• au-4-number—a number in the range of

• tug-3-number—a number in the range of

Specifies the mode of operation of an AU-4.

C-12 <-->VC-12 <--> TU-12<--> TUG-2
<--> TUG-3 <--> VC-4 <--> AU-4 <--> AUG

1 to N where N is the STM level (For the
PA-MC-STM-1 N is always 1.)

1to3.

Step 6

Router(config-ctrlr-tug3)# [no] tug-2 tug-2-number e1
e1-number channel-group channel-group-number timeslots
list-of-timeslots

or

Router(config-ctrlr-tug3)# [no] tug-2 tug-2-number e1
e1-number unframed

• c-12—The TUG-3 is divided into 21 TU-12s

each carrying an E1.

Creates a logical channel group on an E1 line.

• tug-2-number—a number in the range of1 to 7

• e1-number—a number in the range of 1 to 3

• channel-group—defines a logical channel

group to be a channelized E1 line

• channel-group-number—a number in the

range of 0 to 30

• list-of-timeslots—a number in the range of

1 to 31 or a combination of subranges within
1 to 31 (Each subrange is a list of timeslots
that makes up the E1 line.)

Use the no form of this command to remove a
logical channel group.

The default is no channel group configured on an
E1 line.

Creates an unframed (clear channel) logical
channel group on an E1 line.

• tug-2-number—a number in the range of

1to7

Step 7

Router(config-ctrlr-tug3)# exit
Router(config-controller)# exit

12.0(14)S

8

• e1-number—a number in the range of 1 to 3

Returns to configuration mode.

Multichannel STM-1 Port Adapter for the Cisco 7500 Series Router

Command Purpose

Step 8

Router(config)# interface serial

slot/port-adapter/port.au-4-number/tug-3-number/tug-2­number/ e1-number:channel-group-number

Configuration Tasks

Selects the channel group interface to configure.

Note When an unframed (clear

channel logical channel
group is configured on an E1
line, the
channel-group-number is
always 0.

Step 9

Step 10

Router(config-if)# ip address 1.1.1.10 255.255.255.255

Router(config-if)# encapsulation ppp

Configuring an E1 Line Mapped to an AU-3

Step 1

Step 2

Step 3

Step 4

Step 5

Router(config)# controller sonet

slot/port-adapter/port

Router(config-controller)# [no] aug mapping au-3

Router(config-controller)# au-3 au-3-number

Router(config-ctrlr-au3)# mode c-12

Router(config-ctrlr-au3)# tug-2 tug-2-number e1
e1-number framing {crc4 | no crc4}

Enables IP on the channel group interface.

Enables PPP on the channel group interface.

Enters SONET controller configuration mode.

Maps the AUG to an AU-3 with the following
muxing/alignment/mapping:

C-12 <-->VC-12 <--> TU-12<--> TUG-2
<--> VC-3 <--> AU-3 <--> AUG

Specifies the au-3 number to configure:.

• au-3-number—a number in the range of

1to3.

Specifies the mode of operation of the AU-3.

• c-12—The AU-3 is divided into 21 TU-12s

each carrying an E1.

Specifies the type of framing used an by an E1
line.

• tug-2-number—a number in the range of

1to7

• e1-number—a number in the range of 1 to 3

• crc4— 4-bit cyclic redundancy check

• no crc4—basic framing

The default is CRC4.

12.0(14)S

9

Configuration Tasks

Multichannel STM-1 Port Adapter for the Cisco 7500 Series Router

Step 6

Step 7

Step 8

Router(config-ctrlr-au3)# tug-2 tug-2-number e1
e1-number clock source {internal | line}

Router(config-ctrlr-au3)# tug-2 tug-2-number e1
e1-number national bits pattern

Router(config-ctrlr-au3)# [no] tug-2 tug-2-number e1
e1-number bert pattern pattern interval time

Specifies the clock source to be used by the E1
line.

• tug-2-number—a number in the range of

1to7

• e1-number—a number in the range of 1 to 3

• internal—Specifies the PA-MC-STM-1 as

the clock source

• line—Specifies the E1 line as the clock source

Configures the national reserved bits for the E1
line.

• tug-2-number—a number in the range of

1to7

• e1-number—a number in the range of 1 to 3

• pattern—The national reserved bit pattern is a

hexadecimal value in the range 0x0–0x1F
(hexadecimal) or 0-31 (decimal).

The default setting is 0x1F.

Sends a BERT pattern on an E1 line.

• tug-2-number—a number in the range of

1to7

• e1-number—a number in the range of 1 to 3

• pattern:

–

2^11, pseudorandom test pattern (2048
bits long)

–

2^15, pseudorandom O.151 test pattern
(32,768 bits long)

–

2^20-O153, 2^20-1 O.153 test pattern

–

2^20-QRSS, pseudorandom QRSS O.151
test pattern (1048575 bits long)

• time—an interval in the range of 1 to14400

minutes

The default is no BER test configured.

12.0(14)S

10

Multichannel STM-1 Port Adapter for the Cisco 7500 Series Router

Configuration Tasks

Step 9

Step 10

Router(config-ctrlr-au3)# [no] tug-2 tug-2-number e1
e1-number loopback [local | network {line | payload}]

Router(config-ctrlr-au3)# [no] tug-2 tug-2-number e1
e1-number shutdown

Configuring an E1 Line Mapped to a TUG-3

Step 1

Step 2

Step 3

Router(config)# controller sonet 2/0/0

Router(config-controller)# [no] aug mapping au-4

Router(config-controller)# au-4 au-4-number tug-3

tug-3-number

Specifies a loopback for an E1 line.

• tug-2-number—a number in the range of

1to7

• e1-number—a number in the range of 1 to 3

• local—Loops transmitted E1 output back to

the router via the internal E1 framer and loops
E1 output to the network via the internal E1
framer.

• network—Loops E1 input back to the

network.

Shuts down an E1 line.

• tug-2-number—a number in the range of

1to7

• e1-number—a number in the range of 1 to 3

Enters SONET controller configuration mode.

Maps the AUG to AU-4 with the following
muxing/alignment/mapping:

C-12 <-->VC-12 <--> TU-12<--> TUG-2
<--> TUG-3 <--> VC-4 <--> AU-4 <--> AUG

Specifies the AU-4 and TUG-3 number to
configure:

• au-4-number—a number in the range of 1 to N

where N is the STM level.(For the
PA-MC-STM-1 N is always 1.)

Step 4

Step 5

Router(config-ctrlr-tug3)# mode c-12

Router(config-ctrlr-tug3)# tug-2 tug-2-number e1
e1-number framing {crc4 | no crc4}

• tug-3-number—a number in the range of

1to3.

Specifies the mode of operation of a TUG-3.

• c-12—The TUG-3 is divided into 21 TU-12s

each carrying an E1.

Specifies the type of framing used an by an E1
line.

• tug-2-number—a number in the range of

1to7

• e1-number—a number in the range of 1 to 3

• crc4— 4-bit cyclic redundancy check

• no crc4—basic framing

The default is CRC4.

12.0(14)S

11

Configuration Tasks

Multichannel STM-1 Port Adapter for the Cisco 7500 Series Router

Step 6

Step 7

Step 8

Router(config-ctrlr-tug3)# tug-2 tug-2-number e1
e1-number clock source {internal | line}

Router(config-ctrlr-tug3)# tug-2 tug-2-number e1
e1-number national bits pattern

Router(config-ctrlr-tug3)# [no] tug-2 tug-2-number e1
e1-number bert pattern pattern interval time

Specifies the clock source to be used by the E1
line.

• tug-2-number—a number in the range of

1to7

• e1-number—a number in the range of 1 to 3

• internal—Specifies the PA-MC-STM-1 as

the clock source.

• line—Specifies the E1 line as the clock

source.

Configures the national reserved bits for the E1
line.

• tug-2-number—a number in the range of

1to7

• e1-number—a number in the range of 1 to 3

• pattern—The national reserved bit pattern is a

hexadecimal value in the range 0x0–0x1F
(hexadecimal) or 0 to 31 (decimal).

The default setting is 0x1F.

Sends a BERT pattern on an E1 line.

• tug-2-number—a number in the range of

1to7

• e1-number—a number in the range of 1 to 3

• pattern:

–

2^11, pseudorandom test pattern (2048
bits long)

–

2^15, pseudorandom O.151 test pattern
(32,768 bits long)

–

2^20-O153, 2^20-1 O.153 test pattern

–

2^20-QRSS, pseudorandom QRSS O.151
test pattern (1048575 bits long)

• interval— an interval in the range of

1 to 14400 minutes

The default is no BER test configured.

12.0(14)S

12

Multichannel STM-1 Port Adapter for the Cisco 7500 Series Router

Configuration Tasks

Step 9

Step 10

Router(config-ctrlr-tug3)# [no] tug-2 tug-2-number e1
e1-number loopback [local | network {line | payload}]

Router(config-ctrlr-tug3)# [no] tug-2 tug-2-number e1
e1-number shutdown

Specifies a loopback for an E1 line.

• tug-2-number—a number in the range of

1to7

• e1-number—a number in the range of 1 to 3

• local—Loops transmitted E1 output back to

the router via the internal E1 framer and loops
E1 output to the network via the internal E1
framer.

• network—Loops E1 input back to the

network.

Shuts down an E1 line.

• tug-2-number—a number in the range of

1to7

• e1-number—a number in the range of 1 to 3

12.0(14)S

13

Configuration Tasks

Verifying the Configuration

You can verify the configuration and status of the controller by using the show controller commands as
detailed below.

When AUG mapping is AU-4, view information about the SONET controller using the
sonet controller sonet port/port-adapter/port [brief | tabular] command.

Router# show controller sonet 2/0/0
SONET 2/0/0 is up.
Channelized OC-3/STM-1 SMI PA
H/W Version :0.2.3, ROM Version :1.2
FREEDM version :2, F/W Version :1.2.0
Applique type is Channelized Sonet/SDH
Clock Source is Internal, AUG mapping is AU4.

Medium info:
Type:SDH, Line Coding:NRZ, Line Type:Short SM

Regenerator Section Status:
No alarms detected.

Multiplex Section Status:
No alarms detected.

Multichannel STM-1 Port Adapter for the Cisco 7500 Series Router

Higher Order Path Status:
Path# 1 has no defects

Lower Order Path Status:
VC-12 1/1/1/1 has no defects
VC-12 1/1/1/2 has no defects
VC-12 1/1/1/3 has no defects
VC-12 1/1/2/1 has no defects
VC-12 1/1/2/2 has no defects
VC-12 1/1/2/3 has no defects

[display text omitted]

Data in current interval (137 seconds elapsed):
Regenerator Section:
0 CVs, 0 ESs, 0 SESs, 0 SEFSs
Multiplex Section:
0 CVs, 0 ESs, 0 SESs, 0 UASs
Higher Order Path:
Path# 1: 0 CVs, 0 ESs, 0 SESs, 0 UASs
Lower Order Path:
VC-12 1/1/1/1: 0 CVs, 0 ESs, 0 SESs, 0 UASs
VC-12 1/1/1/2: 0 CVs, 0 ESs, 0 SESs, 0 UASs
VC-12 1/1/1/3: 0 CVs, 0 ESs, 0 SESs, 0 UASs
VC-12 1/1/2/1: 0 CVs, 0 ESs, 0 SESs, 0 UASs
[display text omitted]

SONET 2/0/0 E1 1/1/1/1 is up
No alarms detected.
Framing is crc4, Clock Source is internal, National bits are 0x1F.
Data in current interval (137 seconds elapsed):
0 Line Code Violations, 0 Path Code Violations
0 Slip Secs, 0 Fr Loss Secs, 0 Line Err Secs, 0 Degraded Mins
0 Errored Secs, 0 Bursty Err Secs, 0 Severely Err Secs
0 Unavail Secs
SONET 2/0/0 E1 1/1/1/2 is up
No alarms detected.
Framing is crc4, Clock Source is internal, National bits are 0x1F.

12.0(14)S

14

Multichannel STM-1 Port Adapter for the Cisco 7500 Series Router

Data in current interval (137 seconds elapsed):
0 Line Code Violations, 0 Path Code Violations
0 Slip Secs, 0 Fr Loss Secs, 0 Line Err Secs, 0 Degraded Mins
0 Errored Secs, 0 Bursty Err Secs, 0 Severely Err Secs
0 Unavail Secs
[display text omitted]

Router# show controller sonet 2/0/0 brief
SONET 2/0/0 is up.
Channelized OC-3/STM-1 SMI PA
H/W Version :0.2.3, ROM Version :1.2
FREEDM version :2, F/W Version :1.2.0
Applique type is Channelized Sonet/SDH
Clock Source is Internal, AUG mapping is AU4.

Medium info:
Type:SDH, Line Coding:NRZ, Line Type:Short SM

Regenerator Section Status:
No alarms detected.

Multiplex Section Status:
No alarms detected.

Configuration Tasks

Higher Order Path Status:
Path# 1 has no defects

Lower Order Path Status:
VC-12 1/1/1/1 has no defects
VC-12 1/1/1/2 has no defects
VC-12 1/1/1/3 has no defects
VC-12 1/1/2/1 has no defects
VC-12 1/1/2/2 has no defects
VC-12 1/1/2/3 has no defects
[display text omitted]

SONET 2/0/0 E1 1/1/1/1 is up
No alarms detected.
Framing is crc4, Clock Source is internal, National bits are 0x1F.
SONET 2/0/0 E1 1/1/1/2 is up
No alarms detected.
Framing is crc4, Clock Source is internal, National bits are 0x1F.
SONET 2/0/0 E1 1/1/1/3 is up
No alarms detected.
Framing is crc4, Clock Source is internal, National bits are 0x1F.
[display text omitted]

Router# show controller sonet 2/0/0 tabular
SONET 2/0/0 is up.
Channelized OC-3/STM-1 SMI PA
H/W Version :0.2.3, ROM Version :1.2
FREEDM version :2, F/W Version :1.2.0
Applique type is Channelized Sonet/SDH
Clock Source is Internal, AUG mapping is AU4.

Medium info:
Type:SDH, Line Coding:NRZ, Line Type:Short SM

Regenerator Section Status:
No alarms detected.

Multiplex Section Status:
No alarms detected.

12.0(14)S

15
