Chapter 1: Introduction

Welcome

Thank you for choosing the Wireless-G Notebook Adapter with SRX400. With this Adapter, your wireless
networking experience will be faster and easier than ever.

How does the Adapter do this? Like all wireless products, the Adapter allows for greater range and mobility
within your wireless network, whether it’s using the Wireless-G (802.11g) or Wireless-B (802.11b) standard.

But what does all of this mean?

Networks are useful tools for sharing computer resources. You can access one printer from different computers
and access data located on another computer's hard drive. Networks are even used for playing multiplayer video
games. So, networks are not only useful in homes and offices, they can also be fun.

PCs equipped with wireless cards and adapters can communicate without cumbersome cables. By sharing the
same wireless settings, within their transmission radius, they form a wireless network.

The included Setup Wizard walks you through configuring the Adapter to your wireless network settings, step by
step. Use the instructions in this Guide to help you set up and connect the Adapter using the Setup Wizard. These
instructions should be all you need to get the most out of the Adapter.

What’s in This User Guide?

network: a series of computers or devices
connected for the purpose of data sharing,
storage, and/or transmission between users.

adapter: a device that adds network functionality
to your PC.

802.11b: an IEEE wireless networking standard
that specifies a maximum data transfer rate of
11Mbps and an operating frequency of 2.4GHz.

802.11g an IEEE wireless networking standard that
specifies a maximum data transfer rate of 54Mbps
and an operating frequency of 2.4GHz.

This user guide covers the steps for setting up and using the Wireless-G Notebook Adapter with SRX400.

• Chapter 1: Introduction
This chapter describes the Adapter’s applications and this User Guide.

• Chapter 2: Planning Your Wireless Network
This chapter discusses a few of the basics about wireless networking.

• Chapter 3: Getting to Know the Wireless-G Notebook Adapter with SRX400
This chapter describes the physical features of the Adapter.

• Chapter 4: Setting Up and Connecting the Wireless-G Notebook Adapter with SRX400
This chapter shows you how to set up and connect the Adapter.

Chapter 1: Introduction
Welcome

1

Wireless-G Notebook Adapter with SRX400

• Chapter 5: Using the Wireless Network Monitor
This chapter explains how to use the Adapter’s Wireless Network Monitor.

• Appendix A: Troubleshooting
This appendix describes some problems and solutions, as well as frequently asked questions, regarding
installation and use of the Adapter.

• Appendix B: Using Windows XP Wireless Zero Configuration
This chapter instructs you on how to use Window XP Wireless Zero Configuration.

• Appendix C: Wireless Security
This appendix discusses security issues regarding wireless networking and measures you can take to help
protect your wireless network.

• Appendix D: Windows Help
This appendix describes how you can use Windows Help for instructions about networking, such as installing
the TCP/IP protocol.

• Appendix E: Glossary
This appendix gives a brief glossary of terms frequently used in networking.

• Appendix F: Specifications
This appendix provides the Adapter’s technical specifications.

• Appendix G: Warranty Information
This appendix supplies the Adapter’s warranty information.

• Appendix H: Regulatory Information
This appendix supplies the Adapter’s regulatory information.

• Appendix I: Contact Information
This appendix provides contact information for a variety of Linksys resources, including Technical Support.

Chapter 1: Introduction
What’s in This User Guide?

2

Wireless-G Notebook Adapter with SRX400

Chapter 2: Planning Your Wireless Network

Network Topology

A wireless network is a group of computers, each equipped with one wireless adapter. Computers in a wireless
network must be configured to share the same radio channel. Several PCs equipped with wireless cards or
adapters can communicate with one another to form an ad-hoc network.

Linksys wireless adapters also provide users access to a wired network when using an access point or wireless
router. An integrated wireless and wired network is called an infrastructure network. Each wireless PC in an
infrastructure network can talk to any computer in a wired network infrastructure via the access point or wireless
router.

An infrastructure configuration extends the accessibility of a wireless PC to a wired network, and can double the
effective wireless transmission range for two wireless adapter PCs. Since an access point is able to forward data
within a network, the effective transmission range in an infrastructure network can be doubled.

Roaming

Infrastructure mode also supports roaming capabilities for mobile users. Roaming means that you can move your
wireless PC within your network and the access points will pick up the wireless PC's signal, providing that they
both share the same channel and SSID.

topology: the physical layout of a network.

ad-hoc: a group of wireless devices

communicating directly with each other (peer­to-peer) without the use of an access point.

access point: a device that allows wireless­equipped computers and other devices to
communicate with a wired network. Also used to
expand the range of a wireless network

infrastructure: a wireless network that is
bridged to a wired network via an access point.

roaming: the ability to take a wireless device
from one access point's range to another without
losing the connection.

Before you consider enabling roaming, choose a feasible radio channel and optimum access point position.
Proper access point positioning combined with a clear radio signal will greatly enhance performance.

Chapter 2: Planning Your Wireless Network
Network Topology

ssid: your wireless network's name.

3

Wireless-G Notebook Adapter with SRX400

Network Layout

Linksys wireless access points and wireless routers have been designed for use with 802.11b and 802.11g
products. Products using the 802.11g and 802.11b standards can communicate with each other.

Access points and wireless routers are compatible with 802.11b and 802.11g adapters, such as the notebook
adapters for your laptop computers, PCI adapters for your desktop PCs, and USB adapters for when you want to
enjoy USB connectivity. Wireless products will also communicate with a wireless print server.

When you wish to connect your wired network with your wireless network, network ports on access points and
wireless routers can be connected to any of Linksys's switches or routers.

switch: a data switch that connects computing devices
to host computers, allowing a large number of devices
to share a limited number of ports

With these, and many other, Linksys products, your networking options are limitless. Go to the Linksys website at
www.linksys.com/international for more information about wireless products.

router: a networking device that connects multiple
networks together

Chapter 2: Planning Your Wireless Network
Network Layout

4

Wireless-G Notebook Adapter with SRX400

Chapter 3: Getting to Know the Wireless-G Notebook Adapter with SRX400

The LED Indicators

The Adapter's LEDs display information about the Adapter and its wireless connection.

Figure 3-1: Adapter’s LEDs

POWER Green. The LED lights up when the Adapter is powered on.

LINK Green. The LED lights up when the Adapter has an active wireless connection. It flashes when

the Adapter is transmitting or receiving data.

Chapter 3: Getting to Know the Wireless-G Notebook Adapter with SRX400
The LED Indicators

5

Wireless-G Notebook Adapter with SRX400

Chapter 4: Setting Up and Connecting the Wireless-G Notebook Adapter with SRX400

The Wireless-G Notebook Adapter is set up with the Setup Wizard that comes on the CD enclosed with the
Adapter. This chapter will guide you through the setup procedure.

IMPORTANT: Do not connect the Adapter until you are instructed to
do so or the setup will not work.

Starting the Setup Wizard

To begin the setup process, insert the Setup Wizard CD-ROM into your CD-ROM drive. The Setup Wizard should
run automatically, and the Welcome screen should appear. If it does not, click the Start button and choose Run.
In the field that appears, enter D:\setup.exe (if “D” is the letter of your CD-ROM drive).

On the Welcome screen, you have the following choices:

Click Here to Start - Click the Click Here to Start button to begin the software installation process.

User Guide - Click the User Guide button to open this User Guide.

Exit - Click Exit to exit the Setup Wizard.

1. To install the Adapter, click the Click Here to Start button on the Welcome screen.

2. After reading the License Agreement, click Next if you agree and want to continue the installation, or click
Cancel to end the installation.

Chapter 4: Setting Up and Connecting the Wireless-G Notebook Adapter with SRX400
Starting the Setup Wizard

Figure 4-1: Setup Wizard’s Welcome Screen

Figure 4-2: Setup Wizard’s License Agreement

6

Wireless-G Notebook Adapter with SRX400

3. Windows will begin copying the files onto your notebook.

4. The Setup Wizard will now prompt you to insert the Adapter into your notebook. After installing the Adapter,
as shown below, click Next.

Proceed to the “Setting Up the Adapter” section.

Figure 4-3: Insert the Notebook Adapter Screen

Chapter 4: Setting Up and Connecting the Wireless-G Notebook Adapter with SRX400
Starting the Setup Wizard

7

Wireless-G Notebook Adapter with SRX400

Setting Up the Adapter

The next screen to appear will be the Available Wireless Network screen. This provides two options for setting up
the Adapter.

• Available Wireless Network. Most users should use this option. The networks available to this Adapter will
be listed on this screen. You can choose one of these networks and click the Connect button to connect to it.
Click the Refresh button to update the Available Wireless Network list.

• Manual Setup. To set up the Adapter manually, select Manual Setup.

The setup for each option is described, step by step, under the appropriate heading on the following pages.

Click Exit to close the Setup Wizard, if you wish to set up the Adapter later.

Figure 4-4: Available Wireless Network Screen

Chapter 4: Setting Up and Connecting the Wireless-G Notebook Adapter with SRX400
Setting Up the Adapter

8

Wireless-G Notebook Adapter with SRX400

Setting Up the Adapter with an Available Network

The available networks are listed in the table on the center of the screen by SSID. Select the wireless network
you wish to connect to and click the Connect button. (If you do not see your network listed, you can click the
Refresh button to bring the list up again.) If the network utilizes wireless security, you will need to configure
security on the Adapter. If not, you will be taken directly to the Congratulations screen.

1. If wireless security has been enabled on this network, you will see a wireless security screen. If your network
uses WEP (Wired Equivalent Privacy) encryption, the WEP Key Needed for Connection screen will appear. If
your network uses WPA Personal or WPA2 Personal security, a screen will appear for one of those encryption
methods.

WEP Key Needed for Connection

Select the level of encryption you want to use, 64-bit or 128-bit.

Then, enter a passphrase or WEP key.

Passphrase - Enter a passphrase in the Passphrase field, so a WEP key is automatically generated. The
passphrase is case-sensitive and should not be longer than 31 alphanumeric characters. It must match the
passphrase of your other wireless network devices and is compatible with Linksys wireless products only. (If
you have any non-Linksys wireless products, enter the WEP key manually on those products.)

Figure 4-5: Available Wireless Network Screen

encryption: encoding data transmitted in a network.

wep (wired equivalent privacy): a method of encrypting

network data transmitted on a wireless network for
greater security.

wpa (wi-fi protected access): a wireless security
protocol using TKIP (Temporal Key Integrity Protocol)
encryption, which can be used in conjunction with a
RADIUS server.

WEP Key 1 - The WEP key you enter must match the WEP key of your wireless network. For 64-bit
encryption, enter exactly 10 hexadecimal characters. For 128-bit encryption, enter exactly 26 hexadecimal
characters. Valid hexadecimal characters are “0” to “9” and “A” to “F”.

Then, click Connect and proceed to the Congratulations screen. To cancel the connection, click Cancel.

Chapter 4: Setting Up and Connecting the Wireless-G Notebook Adapter with SRX400
Setting Up the Adapter

Figure 4-6: WEP Key Needed for Connection

9

Wireless-G Notebook Adapter with SRX400

WPA-Personal for Connection

WPA Personal offers two encryption methods, TKIP and AES, with dynamic encryption keys. Select one of
these methods. Then enter a passphrase.

Encryption - Select the type of algorithm you want to use, TKIP or AES, from the Encryption drop-down
menu.

Passphrase - Enter a Passphrase, also called a pre-shared key, of 8-63 characters in the Passphrase field.
The longer and more complex your Passphrase is, the more secure your network will be.

Then, click Connect and proceed to the Congratulations screen. To cancel the connection, click Cancel.

WPA2 - Personal Needed for Connection

AES is automatically used as the encryption method. Enter a passphrase on this screen.

Passphrase - Enter a Passphrase, also called a pre-shared key, of 8-63 characters in the Passphrase field.
The longer and more complex your Passphrase is, the more secure your network will be.

Then, click Connect and proceed to the Congratulations screen. To cancel the connection, click Cancel.

2. After the Adapter has been configured for the network, the Congratulations screen will appear. Click Connect

to Network to connect to your network.

Congratulations! Setup is complete.

Figure 4-7: WPA-Personal Needed for Connection

Figure 4-8: WPA2-Personal Needed for Connection

To check the link information, search for available wireless networks, or make additional configuration

changes, refer to “Chapter 5: Using the Wireless Network Monitor.”

Chapter 4: Setting Up and Connecting the Wireless-G Notebook Adapter with SRX400
Setting Up the Adapter

Figure 4-9: Congratulations Screen

10

Wireless-G Notebook Adapter with SRX400

Setting Up the Adapter with Manual Setup

Click Manual Setup on the Available Wireless Network screen to set up the Adapter manually.

1. After clicking Manual Setup, the Network Settings screen will appear. If your network has a router or other
DHCP server, click the radio button next to Obtain network settings automatically (DHCP).

If your network does not have a DHCP server, click the radio button next to Specify network settings. Enter
an IP Address, Subnet Mask, Default Gateway, and DNS addresses appropriate for your network. You must
specify the IP Address and Subnet Mask on this screen. If you are unsure about the Default Gateway and DNS
addresses, leave these fields empty.

IP Address - This IP Address must be unique to your network.

Subnet Mask - The Adapter’s Subnet Mask must be the same as your wired network’s Subnet Mask.

Default Gateway - Enter the IP address of your network’s Gateway here.

DNS 1 and DNS 2 - Enter the DNS address(es) of your wired Ethernet network here.

Figure 4-10: Available Wireless Network Screen

Click Next to continue, or click Back to return to the Available Wireless Network screen.

Chapter 4: Setting Up and Connecting the Wireless-G Notebook Adapter with SRX400
Setting Up the Adapter

Figure 4-11: Network Settings Screen

ip address: the address used to identify a computer or
device on a network.

subnet mask: an address code that determines the size of
a network.

default gateway: a device that forwards
Internet traffic from your local area network.

dns (domain name server): the IP address of your ISP's server,
which translates the names of websites into IP addresses.

11

Wireless-G Notebook Adapter with SRX400

2. The Wireless Mode screen shows a choice of two wireless modes. Click the Infrastructure Mode radio
button if you want to connect to a wireless router or access point. Click the Ad-Hoc Mode radio button if you
want to connect to another wireless device directly without using a wireless router or access point. Then,
enter the SSID for your network.

Infrastructure Mode - Use this mode if you want to connect to a wireless router or access point.

Ad-Hoc Mode - Use this mode if you want to connect to another wireless device directly without using a

wireless router or access point.

SSID - This is the wireless network name that must be used for all the devices in your wireless network. It is
case-sensitive and should be a unique name to help prevent others from entering your network.

Click Next to continue or Back to return to the previous screen.

3. If you chose Infrastructure Mode, go to Step 4 now. If you chose Ad-Hoc Mode, the Ad-Hoc Mode Settings
screen will appear. Select your channel and network mode settings on this screen.

Channel - Select the correct channel for your wireless network. The channel you choose should match the
channel set on the other devices in your wireless network. If you are unsure about which channel to use, keep
the default setting.

Network Mode - Select the mode in which your wireless network will operate. Select Mixed Mode if you
want both Wireless-B and Wireless-G devices operating on the network, though at a slower speed. Select G-
Only Mode if you do not want any Wireless-B devices operating on the network.

Click Next to continue or click Back to change any settings.

Figure 4-12: Wireless Mode Screen

Figure 4-13: Ad-Hoc Mode Settings Screen

Chapter 4: Setting Up and Connecting the Wireless-G Notebook Adapter with SRX400
Setting Up the Adapter

12

Wireless-G Notebook Adapter with SRX400

4. The Wireless Security screen will appear.

If your wireless network doesn’t use wireless security, select Disabled and then click the Next button to
continue. Proceed to Step 5.

From the Security drop-down menu, select the security method you want to use: WEP, WPA Personal, WPA2
Personal, WPA Enterprise, or RADIUS. WEP stands for Wired Equivalent Privacy, and WPA uses a security
standard stronger than WEP encryption. RADIUS stands for Remote Authentication Dial-In User Service. Then
proceed to the appropriate instructions for your security method.

NOTE: If you selected Ad-Hoc Mode in step 2, then you will have two choices. Select WEP or
Disabled from the Security drop-down menu.

WEP

Select a level of WEP encryption to use, and then enter a passphrase or WEP key.

WEP - To use WEP encryption, select 64-bit or 128-bit characters from the drop-down menu.

Passphrase - Instead of manually entering a WEP key, you can enter a passphrase in the Passphrase field, so

a WEP key is automatically generated. This case-sensitive passphrase must match the passphrase of your
other wireless network devices and is compatible with Linksys wireless products only. (If you have any non­Linksys wireless products, enter the WEP key manually on those products.)

WEP Key- The WEP key you enter must match the WEP key of your wireless network. If you are using 64-bit
WEP encryption, then the key must consist of exactly 10 hexadecimal characters. If you are using 128-bit
WEP encryption, then the key must consist of exactly 26 hexadecimal characters. Valid hexadecimal
characters are “0” to “9” and “A” to “F”.

Advanced Users:
TX Key - The default transmit key number is 1. If your network’s access point or wireless router uses transmit

key number 2, 3, or 4, select the appropriate number from the TX Key drop-down box.

Authentication - The default is set to Auto, where it auto-detects for Shared Key or Open system. Shared
Key is when both the sender and the recipient share a WEP key for authentication. Open key is when the
sender and the recipient do not share a WEP key for authentication. All devices on your network must use the
same authentication type.

Click the Next button to continue to the Confirm New Settings screen or the Back button to return to the
previous screen.

Figure 4-14: Wireless Security Screen

Figure 4-15: Wireless Security - WEP Screen

Chapter 4: Setting Up and Connecting the Wireless-G Notebook Adapter with SRX400
Setting Up the Adapter

13

Wireless-G Notebook Adapter with SRX400

WPA Personal

Select an encryption method, TKIP or AES, and then enter a passphrase.

Encryption - Select the type of algorithm, TKIP or AES, from the Encryption drop-down menu.

Passphrase - Enter a Passphrase of 8-63 characters in the Passphrase field.

Click the Next button to continue to the Confirm New Settings screen or the Back button to return to the
previous screen.

WPA2 Personal

WPA2 Personal automatically uses AES, which is a stronger encryption method than TKIP. Enter a passphrase
on this screen.

Figure 4-16: Wireless Security - WPA Personal Screen

Passphrase - Enter a Passphrase of 8-63 characters in the Passphrase field.

Click the Next button to continue to the Confirm New Settings screen or the Back button to return to the
previous screen.

Chapter 4: Setting Up and Connecting the Wireless-G Notebook Adapter with SRX400
Setting Up the Adapter

Figure 4-17: Wireless Security - WPA2 Personal Screen

14

Wireless-G Notebook Adapter with SRX400

WPA Enterprise

WPA Enterprise is used in coordination with a RADIUS server. (This should only be used when a RADIUS server
is connected to the Router.) WPA Enterprise offers two encryption methods, TKIP and AES, with dynamic
encryption keys. It offers two authentication methods, EAP-TLS and PEAP. Select one of these methods and
follow the appropriate instructions below.

EAP-TLS

Login Name - Enter the login name of your wireless network.

Server Name - Enter the name of the authentication server (this is optional).

Certificate - Select the certificate you have installed to authenticate you on your wireless network. If you
want to use any certificate, keep the default setting, Trust Any.

Encryption - Select the type of algorithm you want to use, TKIP or AES.

PEAP

Login Name - Enter the login name of your wireless network.

Password - Enter the password of your wireless network.

Server Name - Enter the name of the authentication server (this is optional).

Certificate - Select the certificate you have installed to authenticate you on your wireless network. If you
want to use any certificate, keep the default setting, Trust Any.

Inner Authen. - Select the authentication method used inside the PEAP tunnel.

Encryption - Select the type of algorithm you want to use, TKIP or AES.

Click the Next button to continue to the Confirm New Settings screen or the Back button to return to the
previous screen.

Figure 4-18: Wireless Security - WPA Enterprise Using

EAP-TLS Screen

Figure 4-19: Wireless Security - WPA Enterprise Using

PEAP Screen

Chapter 4: Setting Up and Connecting the Wireless-G Notebook Adapter with SRX400
Setting Up the Adapter

15

Wireless-G Notebook Adapter with SRX400

RADIUS

RADIUS uses the security of a RADIUS server. (This should only be used when a RADIUS server is connected to
the Router.) It offers two authentication methods, EAP-TLS and PEAP. Select one of these methods and follow
the appropriate instructions below.

EAP-TLS

Login Name - Enter the login name of your wireless network.

Server Name - Enter the name of the authentication server (this is optional).

Certificate - Select the certificate you have installed to authenticate you on your wireless network. If you

want to use any certificate, keep the default setting, Trust Any.

PEAP

Login Name - Enter the login name of your wireless network.

Figure 4-20: Wireless Security - RADIUS Using EAP-TLS

Screen

Password - Enter the password of your wireless network.

Server Name - Enter the name of the authentication server (this is optional).

Certificate - Select the certificate you have installed to authenticate you on your wireless network.

Inner Authen. - Select the authentication method used inside the PEAP tunnel.

Click the Next button to continue to the Confirm New Settings screen or the Back button to return to the
previous screen.

Chapter 4: Setting Up and Connecting the Wireless-G Notebook Adapter with SRX400
Setting Up the Adapter

radius (remote authentication dial-in user service): a
protocol that uses an authentication server to control
network access.

Figure 4-21: Wireless Security - RADIUS Using PEAP

Screen

16

Wireless-G Notebook Adapter with SRX400

5. The next screen displays all of the Adapter’s settings. If these are correct, click Save to save these settings to
your hard drive. If these settings are not correct, click Back to change your settings.

6. After the software has been successfully installed, the Congratulations screen will appear. Click Connect to
Network to connect to your network. Click Return to Profiles screen to open the Wireless Network
Monitor’s Profiles screen. For more information about the Wireless Network Monitor, refer to “Chapter 5:
Using the Wireless Network Monitor.”

Figure 4-22: Confirm New Settings Screen

Congratulations! Setup is complete.

To check the link information, search for available wireless networks, or make additional configuration

changes, refer to “Chapter 5: Using the Wireless Network Monitor.”

Chapter 4: Setting Up and Connecting the Wireless-G Notebook Adapter with SRX400
Setting Up the Adapter

Figure 4-23: Congratulations Screen

17

Wireless-G Notebook Adapter with SRX400

Chapter 5: Using the Wireless Network Monitor

Use the Wireless Network Monitor to check the link information, search for available wireless networks, or
create profiles that hold different configuration settings.

Accessing the Wireless Network Monitor

After setting up and connecting the Adapter, the Wireless Network Monitor icon will appear in your PC’s system
tray. If the Wireless Network Monitor is enabled, then the icon will be green. If the Wireless Network Monitor is
disabled or the Adapter is not connected, then the icon will be gray.

Link Information Screens

The opening screen of the Wireless Network Monitor is the Link Information screen. From this screen, you can
find out how strong the current wireless signal is and how good the connection’s quality is. You can also click the
More Information button to view additional status and statistics about the current wireless connection. To
search for available wireless networks, click the Site Survey tab. To perform configuration changes or create
connection profiles, click the Profiles tab.

Link Information

The Link Information screen displays network mode, signal strength, and link quality information about the
current connection. It also provides a button to click for additional status information.

NOTE: The Wireless Network Monitor should only be
accessed AFTER installing the Adapter. For more
information on setting up and connecting the

Adapter, refer to “Chapter 4: Setting Up and
Connecting the Wireless-G Notebook Adapter
with SRX400.”

Figure 5-1: Wireless Network Monitor Icon

Ad-Hoc Mode or Infrastructure Mode - The screen indicates whether the Adapter is currently working in Ad-

Hoc or Infrastructure mode.

Signal Strength - The Signal Strength bar indicates signal strength.

Link Quality - The Link Quality bar indicates the quality of the wireless network connection.

Click the More Information button to view additional information about the wireless network connection on the

Wireless Network Status screen.

Chapter 5: Using the Wireless Network Monitor
Accessing the Wireless Network Monitor

Figure 5-2: Link Information Screen

18

Wireless-G Notebook Adapter with SRX400

Wireless Network Status

The Wireless Network Status screen provides information on your current network settings.

Status - This shows the status of the wireless network connection.

SSID - This is the unique name of the wireless network.

Wireless Mode - The mode of the wireless network currently in use is displayed here.

Transfer Rate - The data transfer rate of the current connection is shown here.

Channel - This is the channel to which the wireless network devices are set.

Security - The status of the wireless security feature is displayed here.

Authentication - This is your wireless network’s authentication method.

IP Address - The IP Address of the Adapter is displayed here.

Subnet Mask - The Subnet Mask of the Adapter is shown here.

Default Gateway - The Default Gateway address of the Adapter is displayed here.

DNS - This is the DNS address of the Adapter.

DHCP Client - This displays the Adapter’s status as a DHCP client.

MAC Address- The MAC address of the wireless network’s access point or wireless router is shown here.

Signal Strength - The Signal Strength bar indicates the signal strength.

Link Quality - The Link Quality bar indicates the quality of the wireless network connection.

Click the Back button to return to the initial Link Information screen. Click the Statistics button to go to the
Wireless Network Statistics screen. Click the Save to Profile button to save the currently active connection

settings to a profile.

Figure 5-3: More Information - Wireless Network

Status Screen

Chapter 5: Using the Wireless Network Monitor
Link Information Screens

19

Wireless-G Notebook Adapter with SRX400

Wireless Network Statistics

The Wireless Networks Statistics screen provides statistics on your current network settings.

Transmit Rate - This is the data transfer rate of the current connection. (In Auto mode, the Adapter dynamically
shifts to the fastest data transfer rate possible at any given time.)

Receive Rate - This is the rate at which data is received.

Packets Received - This shows the number of packets received by the Adapter, in real time, since connecting to

the wireless network or since the Refresh Statistics button was last pressed.

Packets Transmitted - This shows the number of packets transmitted from the Adapter, in real time, since
connecting to the wireless network or since the Refresh Statistics button was last pressed.

Bytes Received - This shows the number of bytes received by the Adapter, in real time, since connecting to the
wireless network or since the Refresh Statistics button was last pressed.

Bytes Transmitted - This shows the number of bytes transmitted from the Adapter, in real time, since connecting
to the wireless network or since the Refresh Statistics button was last pressed.

Driver Version - This shows the version of the Adapter’s driver.

Noise Level - This shows the level of background noise affecting the wireless signal. A lower reading translates

into a higher quality signal.

Figure 5-4: More Information - Wireless Network

Statistics Screen

Signal Strength - This is the intensity of the wireless signal received by the Adapter.

Up Time - This indicates the length of the most recent connection to a wireless network.

Refresh - Click the Refresh button to reset the statistics.

Total Up Time - This indicates the cumulative total of the Adapter’s connection time.

Signal Strength - The Signal Strength bar indicates the signal strength.

Link Quality - The Link Quality bar indicates the quality of the wireless network connection.

Click the Back button to return to the initial Link Information screen. Click the Status button to go to the Wireless
Network Status screen. Click the Save to Profile button to save the currently active connection settings to

a profile.

Chapter 5: Using the Wireless Network Monitor
Link Information Screens

20

Wireless-G Notebook Adapter with SRX400

Site Survey

The Site Survey screen displays a list of available networks in the table on the left. The table shows each
network’s SSID, Channel, and the quality of the wireless signal the Adapter is receiving. You may click SSID,

CH (Channel), or Signal, to sort by that field.

SSID - The SSID or unique name of the wireless network is displayed here.

CH - This is the channel that the network uses.

Signal - This is the percentage of signal strength, from 0 to 100%.

Site Information

For each network selected, the following settings are listed:

SSID - This the SSID or unique name of the wireless network.

Wireless Mode - This is the mode of the wireless network currently in use.

Channel - This is the channel to which the wireless network devices are set.

Security - The status of the wireless security feature is displayed here.

MAC Address- The MAC address of the wireless network’s access point is displayed here.

Refresh - Click the Refresh button to perform a new search for wireless devices.

Connect - To connect to one of the networks on the list, select the wireless network, and click the Connect

button. If the network has wireless security enabled, a screen requiring security information will appear.

If the network has WEP encryption enabled, then you will see the WEP Key Needed for Connection screen. Select
the appropriate level of WEP encryption, 64-bit or 128-bit Then enter the network’s Passphrase or WEP Key. To
connect to the network, click Connect. To cancel the connection, click Cancel.

Figure 5-5: Site Survey Screen

Figure 5-6: WEP Key Needed for Connection

Chapter 5: Using the Wireless Network Monitor
Site Survey

21

Wireless-G Notebook Adapter with SRX400

If the network has WPA Personal security enabled, then you will see the WPA-Personal Needed for Connection
screen. Select the appropriate encryption type, TKIP or AES. Enter the network’s Passphrase or pre-shared key in
the Passphrase field. To connect to the network, click Connect. To cancel the connection, click Cancel.

If the network has WPA2 Personal security enabled, then you will see the WPA2-Personal Needed for Connection
screen. Enter the network’s Passphrase or pre-shared key in the Passphrase field. To connect to the network,
click Connect. To cancel the connection, click Cancel.

Figure 5-7: WPA-Personal Needed for Connection

Chapter 5: Using the Wireless Network Monitor
Site Survey

Figure 5-8: WPA2-Personal Needed for Connection

22

Wireless-G Notebook Adapter with SRX400

Profiles

The Profiles screen lets you save different configuration profiles for different network setups. The table on the left
displays a list of available profiles with their profile names and SSIDs.

Profile - The name of the profile is displayed here.

SSID - The SSID or unique name of the wireless network is displayed here.

Site Information

For each profile selected, the following are listed:

Wireless Mode - This is the mode of the wireless network currently in use.

Transfer Rate - The rate of data transfer is displayed here.

Channel - This is the channel to which the wireless network devices are set.

Security - The status of the wireless security feature is displayed here.

Authentication - The authentication setting for the network is shown here.

Connect - To connect to a wireless network using a specific profile, select the profile, and click the Connect

button.

New - Click New to create a new profile. See the next section, “Creating a New Profile,” for detailed instructions.

Edit - Select the profile you want to change, and then click Edit.

Import - Click Import to import a profile that has been saved in another location. Select the appropriate file, and
click the Open button.

Export - Select the profile you want to save in a different location, and click Export. Direct Windows to the
appropriate folder, and click the Save button.

NOTE: If you want to export more than one profile, you have to export them one at a time.

Delete - Select the profile you want to delete, and then click Delete.

Figure 5-9: Profiles Screen

Figure 5-10: Import a Profile

Figure 5-11: Export a Profile

Chapter 5: Using the Wireless Network Monitor
Profiles

23

Wireless-G Notebook Adapter with SRX400

Creating a New Profile

On the Profiles screen, click the New button to create a new profile. Enter a name for the new profile, and click
the OK button. Click the Cancel button to return to the Profiles screen without entering a name.

The Available Wireless Network screen provides two options for setting up a profile.

• Available Wireless Network. Most users should use this option. The networks available to this Adapter will
be listed on this screen. You can choose one of these networks and click the Connect button to connect to it.
Click the Refresh button to update the Available Wireless Network list.

• Manual Setup. To set up the Adapter manually, select Manual Setup.

The setup for each option is described, step by step, under the appropriate heading on the following pages.

Click Exit to close the Setup Wizard, if you wish to set up the Adapter later.

Figure 5-12: Create a New Profile

Chapter 5: Using the Wireless Network Monitor
Creating a New Profile

Figure 5-13: Available Wireless Network Screen

24

Wireless-G Notebook Adapter with SRX400

Setting Up the Adapter with an Available Network

The available networks are listed in the table on the center of the screen by SSID. Select the wireless network you
wish to connect to and click the Connect button. (If you do not see your network listed, you can click the Refresh
button to bring the list up again.) If the network utilizes wireless security, you will need to configure security on
the Adapter. If not, you will be taken directly to the Congratulations screen.

1. If wireless security has been enabled on this network, you will see a wireless security screen. If your network
uses WEP (Wired Equivalent Privacy) encryption, the WEP Key Needed for Connection screen will appear. If
your network uses WPA Personal or WPA2 Personal security, a screen will appear for one of those encryption
methods.

WEP Key Needed for Connection

Select the level of encryption you want to use, 64-bit or 128-bit.

Figure 5-14: Available Wireless Network Screen

Then, enter a passphrase or WEP key.

Passphrase - Enter a passphrase in the Passphrase field, so a WEP key is automatically generated. The
passphrase is case-sensitive and should not be longer than 31 alphanumeric characters. It must match the
passphrase of your other wireless network devices and is compatible with Linksys wireless products only. (If
you have any non-Linksys wireless products, enter the WEP key manually on those products.)

WEP Key 1 - The WEP key you enter must match the WEP key of your wireless network. For 64-bit
encryption, enter exactly 10 hexadecimal characters. For 128-bit encryption, enter exactly 26 hexadecimal
characters. Valid hexadecimal characters are “0” to “9” and “A” to “F”.

Then, click Connect and proceed to the Congratulations screen. To cancel the connection, click Cancel.

Chapter 5: Using the Wireless Network Monitor
Creating a New Profile

Figure 5-15: WEP Key Needed for Connection

25
