Cisco Systems SR224G User Manual
USER GUIDE
24-Port 10/100 +
2-Port Gigabit Switch +
2 MiniGBIC
Model: SR224G
BUSINESS SERIES
Table of Contents
Chapter 1: Introduction 1
The 24-Port 10/100 + 2-Port Gigabit Switch + 2 MiniGBIC . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Chapter 2: Product Overview 3
Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Side Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Placement Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chapter 3: Installation 6
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connection Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Appendix A: Specifications 8
Appendix B: Warranty and Regulatory Information
Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Safety Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Industry Canada Statement . . . . . . . . . . . . . . . . . . . . . . . . 12
Règlement d’Industry Canada . . . . . . . . . . . . . . . . . . . . . . 12
EC Declaration of Conformity (Europe) . . . . . . . . . . . . . . . . . 12
User Information for Consumer Products Covered by EU Directive
2002/96/EC on Waste Electric and Electronic Equipment (WEEE) 13
Appendix C: Contact Information 21
9
i24-Port 10/100 + 2-Port Gigabit Switch + 2 MiniGBIC
About This User Guide
About This User Guide
Icon Descriptions
While reading through the User Guide, you may encounter various icons designed to call
attention to a specific item. Below are descriptions of these icons:
NOTE: This check mark indicates that there is a note of interest and is
something that you should pay special attention to while using the product.
WARNING: This exclamation point indicates that there is a caution or
warning and it is something that could damage your property or product.
WEB: This globe icon indicates a noteworthy website address or e-mail
address.
Online Resources
Most web browsers allow you to enter the web address without adding the http:// in front
of the address. This User Guide will refer to websites without including http:// in front of
the address. Some older web browsers may require you to add it.
Resource Website
Linksys www.linksys.com
Linksys International www.linksys.com/international
Glossary www.linksys.com/glossary
Network Security www.linksys.com/security
Copyright and Trademarks
Specifications are subject to change without notice. Linksys is a registered trademark or
trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries.
Copyright © 2007 Cisco Systems, Inc. All rights reserved. Other brands and product names
are trademarks or registered trademarks of their respective holders.
ii 24-Port 10/100 + 2-Port Gigabit Switch + 2 MiniGBIC
Chapter 1: Introduction
Chapter 1:
Introduction
The 24-Port 10/100 + 2-Port Gigabit Switch + 2 MiniGBIC
This new Linksys rack-mount switch delivers non-blocking, wire speed
switching for your 10/100 Mbps network clients, plus multiple options
for connecting to your network backbone. Twenty-four 10/100 ports
wire-up your workstations, while the integrated 10/100/1000 ports or
miniGBIC ports connect to your servers or backbone at Gigabit speeds.
The SR224G incorporates non-blocking, wire-speed architecture that
forwards packets as fast as your network can deliver them. It features
broadcast storm suppression that maximizes the system availability.
Also included are Address Learning and Aging function to prevent data
transfer errors and Data Flow Control to help prevent packet loss.
All ports have automatic MDI/MDI-X crossover detection, so you don’t
have to worry about the cable type. Each port independently and
automatically negotiates for best speed and whether to run in half- or
full-duplex mode. Head-of-line blocking prevention keeps your highspeed clients from bogging down in lower-speed traffic and fast storeand-forward switching prevents damaged packets from being passed
on into the network.
No matter how intensive your network demands, the Linksys 24-Port
10/100 + 2-Port Gigabit Switch + 2 MiniGBIC has speed, flexibility, and
reliability that you can count on.
124-Port 10/100 + 2-Port Gigabit Switch + 2 MiniGBIC
Chapter 1: Introduction
Features
Ideal for integrating your 10 Mbps and 100 Mbps network
•
hardware
24 10/100 Ports provide dedicated bandwidth in Half or Full-Duplex
•
modes
2 Gigabit Ethernet ports and 2 shared miniGBIC slots for Gigabit
•
Fiber expansion
Each port supports Auto MDI/MDI-X cable detection
•
Compatible with all major network operating systems
•
Advanced store-and-forward packet switching optimizes data
•
transfers
Auto partitioning protects PCs from downed network lines
•
Signal regeneration ensures data transfer integrity
•
2 24-Port 10/100 + 2-Port Gigabit Switch + 2 MiniGBIC
Chapter 2: Product Overview
Chapter 2:
Product Overview
Front Panel
The LEDs and network ports are located on the front panel of the
Switch.
Front Panel
LEDs
System (Green) This LED lights up and remains lit when the Switch is
powered on.
1-24
(Green) Each LED lights up when a connection is made through its
corresponding port. It flashes when the corresponding port is active.
Gigabit/miniGBIC 1-2
when a connection is made through the corresponding Gigabit port. It
flashes when the corresponding port is active.
(Green) The Gigabit/miniGBIC LED lights up
Ports
1-24 These ports connect the Switch to network devices,
such as computers.
Gigabit 1-2 The Gigabit RJ-45 ports support 10/100/1000
Mbps connections and are connection points for network
devices such as Gigabit servers. Each Gigabit RJ-45 port is
paired with a miniGBIC port. If a miniGBIC module is present,
the corresponding 10/100/1000 RJ-45 port will be disabled.
MiniGBIC 1-2 The two miniGBIC (Gigabit interface converter)
ports are connection points for miniGBIC modules, so the
Switch can uplink via fiber to another switch or two. The
miniGBIC ports are compatible with the MGBSX1, MGBLH1,
and MGBT1 only.
24-Port 10/100 + 2-Port Gigabit Switch + 2 MiniGBIC
3
Chapter 2: Product Overview
Back Panel
The power port is located on the back panel of the Switch.
Back Panel
Power The power port is where you will connect the included
power cord.
Side Panel
The security slot is located on the side panel of the Switch.
Side Panel with Security Slot
Security slot The security slot is where you can attach a lock
to protect the Switch from theft.
Placement Options
There are two ways to physically install the Switch:
Set the Switch on its four rubber feet.
•
Mount the Switch in a standard rack (1U high).
•
4 24-Port 10/100 + 2-Port Gigabit Switch + 2 MiniGBIC
Chapter 2: Product Overview
Rack-Mount
To rack-mount the Switch, follow these instructions:
The Switch has four mounting holes on each side. Screw an included
1.
mounting bracket into each side.
Attach the Brackets
Lift the Switch into the rack, and secure the brackets with additional
2.
screws (not included).
Connect to Rack
24-Port 10/100 + 2-Port Gigabit Switch + 2 MiniGBIC
5
