Cisco 827 and SOHO 77 Routers Hardware Installation Guide

Audience v

Organization v

Conventions v

Audience

Preface

This preface describes the audience for, organization of, and conventions used in this guide. It also discusses related documentation and tells how to access electronic documentation.

This guide is intended for service technicians who have no experience installing routers but whose goal is to connect routers to networks as quickly as possible.

Organization

This guide is organized as follows:

Conventions

This section describes the conventions used in this guide.

Note Means reader take note. Notes contain helpful suggestions or references to additional information and

material.

• Chapter 1, “Product Overview”—Describes the Cisco 827 and SOHO 77 routers and their features.

• Chapter 2, “Installation”—Provides information on preinstallation, mounting, connecting, and

configuring the router, and verification of router connections.

• Chapter 3, “Troubleshooting”—Describes problems with the router and how to identify and solve

them.

• Appendix A, “Specifications and Cables”—Provides Cisco part numbers for cables that you can

order and contains port connector pinouts and specifications for cables that you might need to provide.

78-6854-03

Caution This symbol means reader be careful. In this situation, you might do something that could result in

equipment damage or loss of data.

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

Conventions

Preface

Warning

Waarschuwing

Varoitus

Attention

Warnung

This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with the standard practices for preventing accidents.

Dit waarschuwingssymbool betekent gevaar. U verkeert in een situatie die lichamelijk letsel kan veroorzaken. Voordat u aan enige apparatuur gaat werken, dient u zich bewust te zijn van de bij elektrische schakelingen betrokken risico's en dient u op de hoogte te zijn van standaard maatregelen om ongelukken te voorkomen.

Tämä varoitusmerkki merkitsee vaaraa. Olet tilanteessa, joka voi johtaa ruumiinvammaan. Ennen kuin työskentelet minkään laitteiston parissa, ota selvää sähkökytkentöihin liittyvistä vaaroista ja tavanomaisista onnettomuuksien ehkäisykeinoista.

Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation pouvant causer des blessures ou des dommages corporels. Avant de travailler sur un équipement, soyez conscient des dangers posés par les circuits électriques et familiarisez-vous avec les procédures couramment utilisées pour éviter les accidents.

Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu einer Körperverletzung führen könnte. Bevor Sie mit der Arbeit an irgendeinem Gerät beginnen, seien Sie sich der mit elektrischen Stromkreisen verbundenen Gefahren und der Standardpraktiken zur Vermeidung von Unfällen bewußt.

Avvertenza

Advarsel

Aviso

Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe causare infortuni alle persone. Prima di lavorare su qualsiasi apparecchiatura, occorre conoscere i pericoli relativi ai circuiti elettrici ed essere al corrente delle pratiche standard per la prevenzione di incidenti.

Dette varselsymbolet betyr fare. Du befinner deg i en situasjon som kan føre til personskade. Før du utfører arbeid på utstyr, må du vare oppmerksom på de faremomentene som elektriske kretser innebærer, samt gjøre deg kjent med vanlig praksis når det gjelder å unngå ulykker.

Este símbolo de aviso indica perigo. Encontra-se numa situação que lhe poderá causar danos físicos. Antes de começar a trabalhar com qualquer equipamento, familiarize-se com os perigos relacionados com circuitos eléctricos, e com quaisquer práticas comuns que possam prevenir possíveis acidentes.

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Preface

Obtaining Documentation

Cisco documentation and additional literature are available on Cisco.com. Cisco also provides several ways to obtain technical assistance and other technical resources. These sections explain how to obtain technical information from Cisco Systems.

Cisco.com

You can access the most current Cisco documentation at this URL:

http://www.cisco.com/univercd/home/home.htm

You can access the Cisco website at this URL:

http://www.cisco.com

You can access international Cisco websites at this URL:

http://www.cisco.com/public/countries_languages.shtml

Documentation DVD

Cisco documentation and additional literature are available in a Documentation DVD package, which may have shipped with your product. The Documentation DVD is updated regularly and may be more current than printed documentation. The Documentation DVD package is available as a single unit.

78-6854-03

Registered Cisco.com users (Cisco direct customers) can order a Cisco Documentation DVD (product number DOC-DOCDVD=) from the Ordering tool or Cisco Marketplace.

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

vii

Documentation Feedback

Cisco Ordering tool:

http://www.cisco.com/en/US/partner/ordering/

Cisco Marketplace:

http://www.cisco.com/go/marketplace/

Ordering Documentation

You can find instructions for ordering documentation at this URL:

http://www.cisco.com/univercd/cc/td/doc/es_inpck/pdi.htm

You can order Cisco documentation in these ways:

• Registered Cisco.com users (Cisco direct customers) can order Cisco product documentation from

the Ordering tool:

http://www.cisco.com/en/US/partner/ordering/

• Nonregistered Cisco.com users can order documentation through a local account representative by

calling Cisco Systems Corporate Headquarters (California, USA) at 408 526-7208 or, elsewhere in North America, by calling 1 800 553-NETS (6387).

Preface

Documentation Feedback

You can send comments about technical documentation to bug-doc@cisco.com.

You can submit comments by using the response card (if present) behind the front cover of your document or by writing to the following address:

Cisco Systems Attn: Customer Document Ordering 170 West Tasman Drive San Jose, CA 95134-9883

We appreciate your comments.

Cisco Product Security Overview

Cisco provides a free online Security Vulnerability Policy portal at this URL:

http://www.cisco.com/en/US/products/products_security_vulnerability_policy.html

From this site, you can perform these tasks:

• Report security vulnerabilities in Cisco products.

• Obtain assistance with security incidents that involve Cisco products.

• Register to receive security information from Cisco.

viii

A current list of security advisories and notices for Cisco products is available at this URL:

http://www.cisco.com/go/psirt

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Preface

If you prefer to see advisories and notices as they are updated in real time, you can access a Product Security Incident Response Team Really Simple Syndication (PSIRT RSS) feed from this URL:

http://www.cisco.com/en/US/products/products_psirt_rss_feed.html

Reporting Security Problems in Cisco Products

Cisco is committed to delivering secure products. We test our products internally before we release them, and we strive to correct all vulnerabilities quickly. If you think that you might have identified a vulnerability in a Cisco product, contact PSIRT:

• Emergencies— security-alert@cisco.com

• Nonemergencies— psirt@cisco.com

Tip We encourage you to use Pretty Good Privacy (PGP) or a compatible product to encrypt any sensitive

information that you send to Cisco. PSIRT can work from encrypted information that is compatible with PGP versions 2.x through 8.x.

Never use a revoked or an expired encryption key. The correct public key to use in your correspondence with PSIRT is the one that has the most recent creation date in this public key server list:

http://pgp.mit.edu:11371/pks/lookup?search=psirt%40cisco.com&op=index&exact=on

Obtaining Technical Assistance

In an emergency, you can also reach PSIRT by telephone:

• 1 877 228-7302

• 1 408 525-6532

Obtaining Technical Assistance

For all customers, partners, resellers, and distributors who hold valid Cisco service contracts, Cisco Technical Support provides 24-hour-a-day, award-winning technical assistance. The Cisco Technical Support Website on Cisco.com features extensive online support resources. In addition, Cisco Technical Assistance Center (TAC) engineers provide telephone support. If you do not hold a valid Cisco service contract, contact your reseller.

Cisco Technical Support Website

The Cisco Technical Support Website provides online documents and tools for troubleshooting and resolving technical issues with Cisco products and technologies. The website is available 24 hours a day, 365 days a year, at this URL:

http://www.cisco.com/techsupport

Access to all tools on the Cisco Technical Support Website requires a Cisco.com user ID and password. If you have a valid service contract but do not have a user ID or password, you can register at this URL:

78-6854-03

http://tools.cisco.com/RPF/register/register.do

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

Obtaining Technical Assistance

Note Use the Cisco Product Identification (CPI) tool to locate your product serial number before submitting

a web or phone request for service. You can access the CPI tool from the Cisco Technical Support Website by clicking the Too l s & R e sou r c es link under Documentation & Tools. Choose Cisco Product

Identification Tool from the Alphabetical Index drop-down list, or click the Cisco Product Identification Tool link under Alerts & RMAs. The CPI tool offers three search options: by product ID

or model name; by tree view; or for certain products, by copying and pasting show command output. Search results show an illustration of your product with the serial number label location highlighted. Locate the serial number label on your product and record the information before placing a service call.

Submitting a Service Request

Using the online TAC Service Request Tool is the fastest way to open S3 and S4 service requests. (S3 and S4 service requests are those in which your network is minimally impaired or for which you require product information.) After you describe your situation, the TAC Service Request Tool provides recommended solutions. If your issue is not resolved using the recommended resources, your service request is assigned to a Cisco TAC engineer. The TAC Service Request Tool is located at this URL:

http://www.cisco.com/techsupport/servicerequest

For S1 or S2 service requests or if you do not have Internet access, contact the Cisco TAC by telephone. (S1 or S2 service requests are those in which your production network is down or severely degraded.) Cisco TAC engineers are assigned immediately to S1 and S2 service requests to help keep your business operations running smoothly.

Preface

To open a service request by telephone, use one of the following numbers:

Asia-Pacific: +61 2 8446 7411 (Australia: 1 800 805 227) EMEA: +32 2 704 55 55 USA: 1 800 553-2447

For a complete list of Cisco TAC contacts, go to this URL:

http://www.cisco.com/techsupport/contacts

Definitions of Service Request Severity

To ensure that all service requests are reported in a standard format, Cisco has established severity definitions.

Severity 1 (S1)—Your network is “down,” or there is a critical impact to your business operations. You and Cisco will commit all necessary resources around the clock to resolve the situation.

Severity 2 (S2)—Operation of an existing network is severely degraded, or significant aspects of your business operation are negatively affected by inadequate performance of Cisco products. You and Cisco will commit full-time resources during normal business hours to resolve the situation.

Severity 3 (S3)—Operational performance of your network is impaired, but most business operations remain functional. You and Cisco will commit resources during normal business hours to restore service to satisfactory levels.

Severity 4 (S4)—You require information or assistance with Cisco product capabilities, installation, or configuration. There is little or no effect on your business operations.

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Preface

Obtaining Additional Publications and Information

Information about Cisco products, technologies, and network solutions is available from various online and printed sources.

• Cisco Marketplace provides a variety of Cisco books, reference guides, and logo merchandise. Visit

Cisco Marketplace, the company store, at this URL:

http://www.cisco.com/go/marketplace/

• Cisco Press publishes a wide range of general networking, training and certification titles. Both new

and experienced users will benefit from these publications. For current Cisco Press titles and other information, go to Cisco Press at this URL:

http://www.ciscopress.com

• Pack et magazine is the Cisco Systems technical user magazine for maximizing Internet and

networking investments. Each quarter, Packet delivers coverage of the latest industry trends, technology breakthroughs, and Cisco products and solutions, as well as network deployment and troubleshooting tips, configuration examples, customer case studies, certification and training information, and links to scores of in-depth online resources. You can access Packet magazine at this URL:

http://www.cisco.com/packet

• iQ Magazine is the quarterly publication from Cisco Systems designed to help growing companies

learn how they can use technology to increase revenue, streamline their business, and expand services. The publication identifies the challenges facing these companies and the technologies to help solve them, using real-world case studies and business strategies to help readers make sound technology investment decisions. You can access iQ Magazine at this URL:

http://www.cisco.com/go/iqmagazine

• Internet Protocol Journal is a quarterly journal published by Cisco Systems for engineering

professionals involved in designing, developing, and operating public and private internets and intranets. You can access the Internet Protocol Journal at this URL:

http://www.cisco.com/ipj

• World-class networking training is available from Cisco. You can view current offerings at

this URL:

http://www.cisco.com/en/US/learning/index.html

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

Obtaining Additional Publications and Information

Preface

xii

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

CHA P TER

Product Overview

The Cisco 827 and SOHO 77 routers can connect a corporate telecommuter or small office to an Internet service provider (ISP) over asymmetric digital subscriber line (ADSL) lines to the following types of networks:

• Corporate LANs

• Internet

The routers are capable of bridging and multiprotocol routing between LAN and WAN ports.

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

1-1

Features

Table 1-1 summarizes the features of the Cisco 827 series and SOHO 77 series routers.

Table 1-1 Cisco 827 and SOHO 77 Routers Features Summary

Feature Routers Description

10BASE-T Ethernet port(s)

ADSL port All Provides connection to ADSL network.

Telephone ports Cisco 827-4V Provides connection to telephone or fax machine

Flash memory

All Provides connection to 10BASE-T (10-Mbps) Ethernet

networks. Compatible with 10/100-Mbps devices.

connected to telephone services through ADSL line.

• Cisco 827-4V

• Cisco 827H

• 12 MB of Flash memory.

Chapter 1 Product Overview

Dynamic RAM (DRAM)

• Cisco 827

• SOHO 77H

• SOHO 77

• Cisco 827-4V

• Cisco 827H

• Cisco 827

• SOHO 77H

• SOHO 77

• 12 MB of Flash memory.

• 8 MB of Flash memory.

• 16 MB of DRAM and 8-MB DIMM card.

• 16 MB of DRAM. Supports 4-,8-, or 16-MB DIMMS.

• 16 MB of DRAM.

Ease of installation All Color-coded ports and cables to reduce the chance of

error.

Cisco IOS software All Supports Cisco IOS software.

Cisco Router Web Setup

All Provides a web-based software tool for basic

configurations.

Console port All Provides connection to terminal or PC for

troubleshooting and for software configuration using command-line interface.

Cable lockable

Locking power

• Cisco 827-4V

• Cisco 827

• SOHO 77

All Locks power connector in place.

Provides complementary feature for physically securing router.

connector

Wall-mounting feature All Brackets on router bottom provide for mounting the

router on a wall or vertical surface.

Router Overview

Table 1-2 tells how many Ethernet and telephone ports each Cisco 827 router and SOHO 77 router has.

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

1-2

78-6854-03

Chapter 1 Product Overview

Front Panels

Router Overview

Table 1-2 Router Ports

Router Ethernet Ports Telephone Ports

Cisco 827-4V 1 4

Cisco 827H 4 0

Cisco 827 1 0

SOHO 77H 4 0

SOHO 77 1 0

Figure 1-1 through Figure 1-3 show the front panels of the Cisco 827 routers.

Figure 1-1 Cisco 827-4V Front Panel

1 - 2 - 3 - 4

PHONE

Figure 1-2 Cisco 827H Front Panel

Figure 1-3 Cisco 827 Front Panel

RXD

TXD

ADSL

RXD

TXD

ADSL

RXD

TXD

ADSL

RXD

ETHERNET

CISCO 800

ETHERNET

CISCO 800

RXD

ETHERNET

CISCO 800

TXD

SERIES

RXD

TXD

SERIES

TXD

SERIES

65611

65574

65612

78-6854-03

Figure 1-4 and Figure 1-5 show the front panels of the SOHO 77 routers.

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

1-3

Router Overview

Chapter 1 Product Overview

Figure 1-4 SOHO 77H Front Panel

Back Panels

RXD

TXD

ETHERNET

CISCO SOHO

SERIES

Figure 1-5 SOHO 77 Front Panel

RXD

TXD

ADSL

RXD

TXD

ETHERNET

CISCO SOHO

SERIES

Figure 1-6 through Figure 1-8 show the back panels of the Cisco 827 routers.

65731

65732

Figure 1-6 Cisco 827-4V Back Panel

Cable lock

Physically secures router

TO HUB TO PC

TO HUB/TO PC button

Determines cable type for Ethernet device connection.

Ethernet port

Connects to Ethernet network device

ETHERNET

CONSOLE

ADSL

Console port

Connects to PC or terminal

ADSL port

Connects to external wall jack

Model Cisco 827-4V

PHONE

143

Power switch

= On. = Standby or no power output

+5,+12,-12,-24,-71 VDC

65566

Locking power connector

Connects to power supply

1-4

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Chapter 1 Product Overview

Figure 1-7 Cisco 827H Back Panel

Ethernet ports

Connect to Ethernet network devices

ADSL port

Connects to External wall jack

Router Overview

Power switch

= On. = Standby or no power output

TO HUB TO PC

TO HUB/TO PC button

(for Ethernet 4 port) Determines cable type for Ethernet device connection

Figure 1-8 Cisco 827 Back Panel

Cable lock

Physically secures router

ETHERNET 10 BASE T

Ethernet port

Connects to Ethernet network device

ETHERNET

TO HUB TO PC

Cisco 827H

CONSOLE

Console port

Connects to PC or terminal

CONSOLE

ADSL

ADSL port

Connects to external wall jack

Model Cisco 827

+5 VDC

65573

Locking power connector

Connects to power supply

Power switch

= On. = Standby or no power output

+5,+12,-12,-24,-71 VDC

78-6854-03

TO HUB/TO PC button

Determines cable type for Ethernet device connection.

Console port

Connects to PC or terminal

Locking power connector

Connects to power supply

Figure 1-9 and Figure 1-10 show the back panels of the SOHO 77 routers.

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

65565

1-5

Router Overview

Figure 1-9 SOHO 77H Back Panel

Ethernet ports

Connect to Ethernet network devices

ADSL port

Connects to External wall jack

Chapter 1 Product Overview

Power switch

= On. = Standby or no power output

TO HUB TO PC

TO HUB/TO PC button

(for Ethernet 4 port) Determines cable type for Ethernet device connection

Figure 1-10 SOHO 77 Back Panel

Cable lock

Physically secures router

ETHERNET 10 BASE T

Ethernet port

Connects to Ethernet network device

ETHERNET

TO HUB TO PC

Cisco SOHO 77H

CONSOLE

Console port

Connects to PC or terminal

CONSOLE

Model Cisco SOHO 77

ADSL

Locking power connector

Connects to power supply

ADSL port

Connects to external wall jack

+5 VDC

65734

Power switch

= On. = Standby or no power output

+5,+12,-12,-24,-71 VDC

TO HUB/TO PC button

Determines cable type for Ethernet device connection.

Console port

Connects to PC or terminal

Locking power connector

Connects to power supply

LEDs

Table 1-3 summarizes the functions of the LEDs on the Cisco 827-4V router.

Table 1-3 LED Functions on Cisco 827-4V Router

LED Color Function

OK LED Green On when power is supplied to the router and when the router

completes the self-test procedure and begins operating.

PHONE 1, 2, 3, 4 Green On when basic telephone service is in use.

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

1-6

65733

78-6854-03

Chapter 1 Product Overview

Table 1-3 LED Functions on Cisco 827-4V Router (continued)

LED Color Function

ADSL CD Green On when the ADSL device is physically connected. Blinks when the

connection has a problem. See Chapter 3, “Troubleshooting.”

ADSL RXD Green Blinks when an ADSL port receives data.

ADSL TXD Green Blinks when an ADSL port sends data.

ETHERNET 1 Green On when Ethernet device is connected. Blinks when the connection

has a problem. See Chapter 3, “Troubleshooting.”

ETHERNET RXD Green Blinks when an Ethernet port receives a packet.

ETHERNET TXD Green Blinks when an Ethernet port sends a packet.

Table 1-4 summarizes the function of the LEDs on the Cisco 827H router and the SOHO 77H router.

Table 1-4 Functions of LEDs on the Cisco 827H Router and SOHO 77H Router

LED Color Function

OK LED Green On when power is supplied to the router and when the router

completes the self-test procedure and begins operating.

ADSL CD Green On when the ADSL device is physically connected. Blinks when the

connection has a problem. See Chapter 3, “Troubleshooting.”

ADSL RXD Green Blinks when the ADSL port receives data.

ADSL TXD Green Blinks when the ADSL port sends data.

ETHERNET 1, 2, 3, 4 Green On when Ethernet device is connected. Blinks when the connection

has a problem. See Chapter 3, “Troubleshooting.”

ETHERNET RXD Green Blinks when an Ethernet port receives a packet.

ETHERNET TXD Green Blinks when an Ethernet port sends a packet.

Router Overview

Table 1-5 summarizes the function of the LEDs on the Cisco 827 router and SOHO 77 router.

Table 1-5 LED Functions on Cisco 827 Router and SOHO 77 Router

LED Color Function

OK LED Green On when power is supplied to the router and when the router

completes the self-test procedure and begins operating.

ADSL CD Green On when the ADSL device is physically connected. Blinks when the

connection has a problem. See Chapter 3, “Troubleshooting.”

ADSL RXD Green Blinks when an ADSL port receives data.

ADSL TXD Green Blinks when an ADSL port sends data.

ETHERNET 1 Green On when Ethernet device is connected. Blinks when the connection

has a problem. See Chapter 3, “Troubleshooting.”

ETHERNET RXD Green Blinks when an Ethernet port receives a packet.

ETHERNET TXD Green Blinks when an Ethernet port sends a packet.

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

1-7

Router Overview

Chapter 1 Product Overview

1-8

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Installation

This chapter provides information on the following topics:

• Preparing for Installation

• Preventing Router Damage

• Mounting the Router

• Installing the Router

• Using the Router LEDs to Check Links

• Configuring the Router

CHA P TER

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

2-1

Preparing for Installation

This section provides information on safety, mounting the router, and unpacking the contents of the router box.

Safety

This section provides safety warnings and electrostatic and router damage information for the Cisco 827 routers and SOHO 77 routers.

Warnings

Before installing the router, read the following warnings:

Chapter 2 Installation

Warning

Only trained and qualified personnel should be allowed to install or replace this equipment.

Read the installation instructions before you connect the system to its power source.

Before working on a system that has a standby/off switch, turn the power to standby and unplug the power cord.

Before working on equipment that is connected to power lines, remove jewelry (including rings, necklaces, and watches). Metal objects will heat up when connected to power and ground and can cause serious burns or weld the metal object to the terminals.

To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telephone-network voltage (TNV) circuits. LAN ports contain SELV circuits, and WAN ports contain TNV circuits. Some LAN and WAN ports both use RJ-45 connectors. Use caution when connecting cables.

Ultimate disposal of this product should be handled according to all national laws and regulations.

2-2

Warning

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

If the symbol of suitability with an overlaid cross ( ) appears above a port, you must not connect the port to a public network that follows the European Union standards. Connecting the port to this type of public network can cause severe injury or damage your router.

78-6854-03

Chapter 2 Installation

Preventing Electrostatic Discharge Damage

Electrostatic discharge (ESD) is a transfer of electrostatic charge between bodies of different electrostatic potentials, such as an operator and a piece of electrical equipment. It occurs when electronic components are improperly handled, and it can damage equipment and impair electrical circuitry. Electrostatic discharge is more likely to occur with the combination of synthetic fibers and dry atmosphere.

Always use the following ESD-prevention procedures when removing and replacing components:

Step 1 Wear an ESD-preventive wrist strap that you provide, ensuring that it makes good skin contact.

Caution To properly guard against ESD damage and shocks, the wrist strap and cord must operate effectively.

Always observe the warnings in the preceding section, “Safety.”

Step 2 Do not touch any exposed contact pins or connector shells of interface ports that do not have a cable

attached.

If cables are connected at one end only, do not touch the exposed pins at the unconnected end of the cable.

Preparing for Installation

Note This device is intended for use in residential and commercial environments only.

Caution Periodically check the resistance value of the antistatic strap, which should be between 1 and 10

megohms (Mohms).

Unpacking the Box

Table 2-1 lists the items that come with your router. All these items are in the accessory kit that is inside

the box that your router came in. If any of the items is missing or damaged, contact your customer service representative.

Table 2-1 Router Box Contents

Power cord (black)

•

• Desktop power supply

• Console cable, RJ-45-to-DB-9 (light blue)

• ADSL cable (lavender)

• Ethernet cable (yellow)

• Product documentation

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

2-3

Preventing Router Damage

To prepare for installation, follow these steps:

Step 1 Obtain the ADSL line.

Step 2 Remove the yellow Ethernet cable, light blue console cable, lavender ADSL cable, product

documentation, and Cisco 800 Documentation CD-ROM from the Open Me First bag. Remove the desktop power supply and the black power cord from the accessory kit. Gather the Ethernet devices to be connected to the router: hub, server, workstation, or PC.

Step 3 If you plan to connect an analog telephone or fax machine, gather these devices. You must also provide

the telephone cable to connect each device (this cable is usually provided with the device).

Step 4 If you plan to configure the software using a terminal or PC connected to the router, provide the terminal

or PC.

Step 5 If you plan to use the cable lock feature available on the Cisco 827, SOHO 77, and Cisco 827-4V routers,

you must provide a Kensington or equivalent locking cable.

Chapter 2 Installation

Preventing Router Damage

Follow these guidelines when connecting devices to your router:

• Connect the color-coded cables supplied by Cisco Systems to the color-coded ports on the back

panel.

• If you must supply your own cable, see Appendix A, “Specifications and Cables,” for cabling

specifications. If this appendix does not provide specifications for a particular cable, we strongly recommend ordering the cable from Cisco Systems.

• If the symbol of suitability ( ) appears above a port, you can connect the port directly to a public

network that follows the European Union standards.

Warning

2-4

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Chapter 2 Installation

Mounting the Router

You can mount the router on one of the following surfaces:

• Table or other horizontal surface

• Wall or other vertical surface

Mounting on a Table

Do not cover or obstruct the router vents, which are located on the sides of the router.

Mounting on a Wall

You can mount the router on a wall or other vertical surface by using the molded mounting brackets on the bottom of the router and two number-six, 3/4-in. (M3.5 x 20 mm) screws. You must provide the screws. Figure 2-1 shows the mounting brackets.

Mounting the Router

Figure 2-1 Wall-Mounting Brackets (Bottom of Router)

Front panel of router

ounting bracket

Bottom

of router

Caution If you are mounting the router on drywall, use two hollow wall-anchors

7 in. (19.35 cm)

(1/8-in. with 5/16-in. drill bit, or M3 with 8-mm drill bit) to secure the screws. If the screws are not properly anchored, the strain of the network cable connections could pull the router from the wall.

The following requirements must be met when you mount the router:

Mounting bracket

11671

78-6854-03

• Because the LEDs are used as status and problem indicators, the LEDs on the front panel must face

upward and be easily visible.

• The back panel must face downward to reduce strain on the cable connections.

• The power supply must rest on a horizontal surface, such as the floor or a table. If the power supply

is not supported, strain on the power supply cable could cause it to disconnect from the connector on the router back panel.

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

2-5

Installing the Router

To mount the router, follow the steps in Figure 2-2. The last page of this manual provides a template for measuring the distance between the screws.

Figure 2-2 Mounting Router on a Wall

Chapter 2 Installation

1. Secure two screws 7 in. (19.35 cm) apart in a wall

and in. (0.32 cm) from

the wall.

Wall

Wall-mount

screw

Wall

7 in. (19.35 cm)

in. (0.32 cm)

Screw

Wall-mount screw

ETHE

RXD-

RNET

Maximum distance 6 ft (1.8 m)

Front panel

PHONE

ADSL

RXD-

TXD

Mounting brackets

2. Hang router on screws.

Installing the Router

To install the router, you need to perform the following tasks in the following order:

1. Connect the Ethernet devices to the router.

2. Connect the ADSL line.

3. Connect an optional analog telephone or fax machine.

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

2-6

3. Place power supply on horizontal surface.

30102

78-6854-03

Chapter 2 Installation

4. Connect a terminal or PC to the router for software configuration using the command-line interface

(CLI) or for troubleshooting.

5. Connect the router to the power source.

6. Verify the links using the router LEDs.

Connect Ethernet Devices

Table 2-2 lists the Ethernet devices you can connect to Cisco 827, Cisco 827-4V, and SOHO 77 routers;

the connections for each device; and the settings of the router TO HUB/TO PC button (the default setting is IN).

Table 2-2 Ethernet Device Connections for Cisco 827, Cisco 827-4V, and SOHO 77 Routers

Router HUB/NO Network Device Connected To Router Router Port

Hub with equivalent to

ETHERNET port 1 Straight-through IN MDI (IN)

Ethernet Cable

Ty pe

HUB Button

Setting

router TO HUB/TO PC button

Hub with equivalent to

ETHERNET port 1 Straight-through OUT MDI-X (OUT) router TO HUB/TO PC button

Hub without equivalent

ETHERNET port 1 Straight-through OUT MDI-X (OUT) to router TO HUB/TO PC button

Server, PC, or

ETHERNET port 1 Straight-through OUT – workstation

1. Cisco provides a yellow straight-through cable. You provide crossover or additional straight-through cables. For details on cables, see Appendix A, “Specifications and Cables.”

2. Hub vendors choose different names for the button that controls the cable selection. This table uses the Cisco 1528 Micro Hub 10/100 with an MDI/MDI-X button as an example. Determine the button name and setting for your particular hub. Refer to your hub documentation for details.

Network Device Button Setting

Installing the Router

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

2-7

Installing the Router

Table 2-3 lists the Ethernet devices you can connect to Cisco 827H and SOHO 77H routers, the

connections for each device, and the settings of the router TO HUB/TO PC button (the default setting is IN).

Table 2-3 Ethernet Device Connections for Cisco 827H and SOHO 77H Routers

Network

Router TO Network Device Connected to Router Router Port

Hub with equivalent to

ETHERNET port 4 Straight-through IN MDI (IN)

Ethernet Cable

Ty pe

HUB/TO PC

Button Setting

router TO HUB/TO PC button

Hub with equivalent to

ETHERNET port 4 Straight-through OUT MDI-X router TO HUB/TO PC button

Hub without equivalent

ETHERNET port 4 Straight-through OUT MDI-X to router TO HUB/TO PC button

Server, PC, or

ETHERNET port 4 Straight-through OUT – workstation

Hub with equivalent to

ETHERNET port 1, 2, 3 Crossover N/A MDI (IN) router TO HUB/TO PC button

Hub with equivalent to

ETHERNET port 1, 2, 3 Straight-through N/A MDI-X router TO HUB/TO PC button

Hub without equivalent

ETHERNET port 1, 2, 3 Crossover N/A MDI-X to router TO HUB/TO PC button

Server, PC, or

ETHERNET port 1, 2, 3 Straight-through N/A – workstation

1. Cisco provides a yellow straight-through cable. You provide crossover or additional straight-through cables. For cable specifications, see Appendix A, “Specifications and Cables.”

Device Button Setting

(OUT)

Chapter 2 Installation

2-8

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Chapter 2 Installation

E T

T O

N S

O LE

Model Cisco 827-4V

S L

Connecting Hubs

Installing the Router

Before connecting a hub to the router, see Ta b le 2-2 to determine how to set the router TO HUB/TO PC button. To connect a hub to the router, follow the steps in Figure 2-3.

Figure 2-3 Connecting a Hub to the Router

1. Set TO HUB/TO PC button.

Cisco 827, 827-4V and SOHO 77

2. Connect yellow cable to ETHERNET 4 port on router.

SPEED

LED

100BaseTX

SOLID

10BaseT BLINK

3. Connect other end of cable to hub.

1. Set TO HUB/TO PC button.

T O H

B T O

2. Connect yellow cable to ETHERNET 4 port on router.

Cisco 1528 Micro Hub 10/100

ETHERNET

3X 4X

MDI

MDI-X

4. If applicable, check setting of hub equivalent of router TO HUB/TO PC.

Cisco 827H and SOHO 77H

E T HE

E T

10B

E T

Cisco 827 H

N SO

A DS

+5 V

74117

To verify the hub connection, check that the port’s Ethernet LED on the front panel is on after you complete the router installation.

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

2-9

Installing the Router

Connecting a Server, PC, or Workstation

Before connecting a server, PC, or workstation to the router, see Table 2-2 on page 2-7 to determine how to set the router TO HUB/TO PC button.

To connect a server, PC, or workstation to the router, follow the steps in Figure 2-4 on page 2-10.

Figure 2-4 Connecting a Server, PC, or Workstation to the Router

Chapter 2 Installation

1. Set TO HUB/TO PC button.

Cisco 827, 827-4V

S L

odel Cisco 827-4V

and SOHO 77

+5,+1

E TH

E R

O N

O P

2. Connect yellow cable to ETHERNET 4 port on router.

1. Set TO HUB/TO PC button.

Cisco 827H and SOHO 77H

T O

E TH

R N

ET 10B

A SE

Cisco 827 H

O LE

2,-12,-2

4,-71 V

+5 V

2. Connect yellow cable to ETHERNET 4 port on router.

74116

2-10

3. Connect other end of cable to server, PC, or workstation.

To verify the connection, check that the Ethernet 1 LED is on after you complete the router installation.

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Chapter 2 Installation

Connect an ADSL Line

The procedure for connecting an ADSL line depends on the router and, in some cases, on the location.

Figure 2-5 shows how to connect the ADSL line to a cable wall jack. (Figure 2-5 depicts a Cisco 827-4V

router, but the process is the same for Cisco 827, Cisco 827H, SOHO 77, and SOHO 77H routers.)

Installing the Router

Warning

Do not work on the system or connect or disconnect cables during periods of lightning activity.

Figure 2-5 Connecting an ADSL Line to a Wall Jack

ETHERNET

TO HUB TO PC

odel Cisco 827-4V

CONSOLE

ADSL

PHONE

+5,+12,-12,-24,-71 VDC

1. Connect lavender cable to ADSL port on router.

2. Connect other end of cable to wall jack.

65560

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

2-11

Installing the Router

Connect an Analog Telephone or Fax Machine (Cisco 827-4V Routers Only)

You can connect as many as four devices such as analog push button telephones or fax machines to a Cisco 827-4V router. Each device is connected to basic telephone services through the color-coded gray phone ports.

To connect an analog telephone or fax machine, follow the steps in Figure 2-6. You must provide the telephone cable for connecting each device. The telephone cable is usually provided with the device.

Figure 2-6 Connecting an Analog Telephone or Fax Machine

ETHERN

HUB

NSOLE

Model Cisco 827-4V

DSL

PHONE

Chapter 2 Installation

+5,+12,-12,-24,-71 VDC

1. Connect telephone cable to gray PHONE port 1, 2, 3, or 4. If you are connecting only one

Analog telephone

device, use PHONE port 1.

2. Connect other end of cable to telephone or fax machine.

Warning

This equipment contains a ring signal generator (ringer), which is a source of hazardous voltage. Do not touch the RJ-11 (phone) port wires (conductors), the conductors of a cable connected to the RJ-11 port, or the associated circuit-board when the ringer is active. The ringer is activated (indicated by a clicking sound) by an incoming call.

Caution Do not connect the router telephone ports to the telephone wall jack. These ports are not meant for direct

connection to a public network. This connection can damage your router.

65561

2-12

The gray phone ports are RJ-11 connectors. If you are outside North America, you must buy and attach adapters that allow telephones or fax machines to be connected to these RJ-11 connectors. In some countries, these adapters need additional electronics so that the telephones or fax machines will work properly with the router phone ports. For example, in the United Kingdom, you must buy an adapter that also provides a master socket, which causes incoming calls to ring the connected devices. For information on recommended master sockets, see Tabl e 2-4 .

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Chapter 2 Installation

Table 2-4 Recommended Vendors for Master Sockets Required for United Kingdom

Vendor Name Product Name For More Information

RS Components Avro Pacific Telephone Ring

http://www.rswww.com/

Adapter (part number 303-2000)

Tandy Export Adapter (part number

http://www.tandy.co.uk/

2797057)

Connect a Terminal or PC to the Router’s Console Port (Optional)

You can connect either a terminal or a PC to the router’s console port. You can use the terminal or PC for configuring the software via the command line interface (CLI) or for troubleshooting. To connect a terminal or PC, follow the steps in Figure 2-7. (Figure 2-7 depicts a Cisco 827-4V, but the process applies to connecting all Cisco 827 series routers and SOHO 77 series routers.)

Note Unless you are an experienced network administrator, it is recommended that you use the Cisco Router

Web Setup software to configure the router. Use of this software is described in the “Using Cisco Router

Web Setup to Configure the Router” section on page 2-16.

Installing the Router

Figure 2-7 Connecting a Terminal or PC

Cisco 827-4V router

Model Cisco 827-4V

5,+

,-12

,-24

,-7

1. Connect light blue cable to CONSOLE port.

2. Connect DB-9 connector to terminal or PC.

If you have experience configuring Cisco routers and prefer to use the CLI, refer to the Cisco 827 Router Software Configuration Guide for instructions on configuring the router.

65562

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

2-13

Installing the Router

Connect the AC Adapter

To connect the power supply, follow the steps in Figure 2-8. (Figure 2-8 depicts a Cisco 827-4V router, but the process is the same for the Cisco 827, Cisco 827H, SOHO 77, and SOHO 77H routers.)

Chapter 2 Installation

Warning

The device is designed to work with TN power systems.

This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that a fuse or circuit breaker no larger than 120 VAC, 15A U.S. (240 VAC, 16A international) is used on the phase conductors (all current-carrying conductors).

This equipment is intended to be grounded. Ensure that the host is connected to earth ground during normal use.

Figure 2-8 Connecting the AC Adapter

1. Press power switch to standby ( ).

ETHERNET

TO HUB TO PC

CONSOLE

Model Cisco 827-4V

ADSL

PHONE

+5,+12,-12,-24,-71 VDC

65558

5. Press power

Desktop power

switch to on ( ).

supply

4. Connect power cord to electrical outlet.

3. Connect power cord to power supply.

2. Connect power supply cable.

2-14

Note Be sure to use the power supply that was shipped with your router. Although you may be able to connect

another Cisco power supply to your router, that power supply may not provide all the features that the power supply that shipped with your router does.

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Chapter 2 Installation

Using the Router LEDs to Check Links

Use the LEDs on the front of the router to check the links between the router and attached Ethernet devices or telephones. Use Tab l e 2- 5 to verify the link status of devices attached to Cisco 827, Cisco 827-4V, and SOHO 77 routers.

Table 2-5 LED Patterns for CIsco 827, Cisco 827-4V and SOHO 77 Routers

Power/Link LEDs to Check Normal Patterns

Power OK On

To hub, server, PC, or workstation

To analog telephone or fax machine

(827-4V only)

1. You can also pick up the handset and listen for a dial tone.

ETHERNET 1, ETHERNET RXD, and ETHERNET TXD

PHONE 1, PHONE 2, PHONE 3, PHONE 4

• ETHERNET 1 is on when the Ethernet is

physically connected.

• ETHERNET RXD blinks when an Ethernet

port receives an Ethernet packet.

• ETHERNET TXD blinks when an Ethernet

port sends an Ethernet packet.

On when telephone or fax machine is in use.

Using the Router LEDs to Check Links

Use Table 2-6 to verify the link status of devices attached to Cisco 827H and SOHO 77H routers.

Table 2-6 LED Patterns for Cisco 827H and SOHO 77H Routers

Power/Link LEDs to Check Normal Patterns

Power OK On

To hub, server, PC, or workstation

ETHERNET 1, 2, 3, or 4; ETHERNET RXD; and ETHERNET TXD

• ETHERNET LED is on when the Ethernet is

physically connected to the appropriate port.

• RXD LED blinks when an Ethernet port

receives an Ethernet packet.

• TXD LED blinks when an Ethernet port

sends an Ethernet packet.

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

2-15

Configuring the Router

When you have finished installing the router, you must configure the router software. First, check PC configurations to ensure that all PCs will be able to communicate with the router. Then configure the router software using the web interface.

Checking the PC Configuration

Each PC that is connected to the router must be configured to use the Transmission Control Protocol/Internet Protocol (TCP/IP) and to obtain its IP address automatically. Follow these steps to configure each PC that is running Microsoft Windows NT or Microsoft Windows 95 or 98. If the PC is running a different version of Microsoft Windows, refer to the documentation that came with the PC.

Step 1 Start the PC, and open the Control Panel.

Step 2 Click the Network icon to display the Network window.

Step 3 Verify that TCP/IP has been added and associated with the Ethernet adapter. TCP/IP is shown as a cable

icon in the Configuration window on Microsoft Windows 95 and 98; it is shown as a cable icon in the Protocol window on Microsoft Windows NT. If the icon is not visible, click Add, and add the Microsoft TCP/IP protocol.

Chapter 2 Installation

Step 4 To verify that the PC is configured to obtain an IP address automatically, click the TCP/IP cable icon,

and select the IP address tab in the TCP/IP Properties window. Check Obtain an IP address from a DHCP server if it is not checked. The IP address and Subnet mask fields should be greyed out.

Step 5 Click OK to accept all changes and exit this window, and click OK in the Network window.

Step 6 To reboot the PC, click Yes if you are prompted.

For more information on how to configure TCP/IP, refer to the Cisco Router Web Setup Troubleshooting Guide, which is available on the Cisco 800 and SOHO Series Product Documentation CD.

Using Cisco Router Web Setup to Configure the Router

Cisco strongly recommends that inexperienced network administrators use the Cisco Router Web Setup application that has been installed on the router. To use this application, complete the following steps:

Step 1 Start, or restart, one of the PCs connected to the router through ETHERNET port 1, 2, 3, or 4.

Step 2 Open a web browser. Make sure that your browser is set to work in online mode.

• In Internet Explorer, click the File menu, and verify that the work offline option is unchecked.

• In Netscape, the default selection in the File menu is set to work online.

Step 3 Type in the universal resource locator (URL) http://10.10.10.1. The CRWS home page will appear in

one or two minutes.

2-16

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Chapter 2 Installation

Tip If the CRWS home page does not appear when you enter the URL http://10.10.10.1, test the connection

Configuring the Router

between the PC and the router by doing the following:

1. Check that the OK LED on the router is on, and check the cable connection between the router and

the PC. Be sure that the TO HUB/TO PC button is in the correct position. The button is in the correct position if the LED for the port on the front of the router is on.

2. If the CRWS home page still does not appear, verify that the web browser’s “work offline” option

is disabled.

3. If the web page still does not appear, verify that your PC is automatically configured to receive an

IP address. Follow the instructions in the Cisco Router Web Setup Troubleshooting Guide, which is available on the Cisco 800 and SOHO Series Product Documentation CD.

4. If the PC is configured to automatically receive an IP address, but the web page still does not appear,

select Start/Run, type winipcfg in the Run window, and examine the address in the IP address field. The address should be in the format 10.10.10.X, in which X is a number that is equal or greater than 2; for example, 10.10.10.2, or 10.10.10.3. If the IP address is not in this format, verify that an Ethernet adapter name is visible in the Adapter field. If there is no name in the field, return to Step 3 in “Checking the PC Configuration," add TCP to the list of protocols. Then return to “Using Cisco

Router Web Setup to Configure the Router, page 2-16," and complete the procedure.

Step 4 If you have no special configuration requirements, click the Router Setup link on the home page, and

then click Easy Setup. (This may appear as Quick Setup on some models.) Then, enter the user name and password provided to you by your Internet service provider, and click Apply.

Step 5 If you need to configure special features such as Network Address Translation (NAT), click the

appropriate links on the home page, and complete the configuration screens.

Step 6 Click the Password link on the home page, and set a password for the router.

Step 7 Click the Tes t Co n nec t ion link on the home page, and allow the connection to be tested.

Step 8 Select Start/Run, and type winipcfg in the Open field of the Run window. When the IP Config window

appears, click Release to release the PC’s IP address. Then click Renew to renew the PC’s IP address.

Alternatively, open the Run window and enter ipconfig /release to release the PC’s IP address.Then enter ipconfig /renew to renew the IP address of the PC.

Step 9 Open a web browser on the PC, and connect to a website.

The router installation is complete when you have connected to a website.

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

2-17

Configuring the Router

Chapter 2 Installation

2-18

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Troubleshooting

This chapter describes symptoms of problems that could occur with the Cisco 827 or SOHO 77 routers, identifies the likely underlying problems, and provides steps for solving the problems. The problems are grouped into the following areas:

• Problems during first startup

• Problems after the router has been up and running

For more information about problems that could occur with the software, refer to the Cisco 827 Routers Software Configuration Guide.

Before You Call Your Cisco Reseller

Some of the solutions in this chapter instruct you to contact your Cisco reseller. Before you contact your reseller, make sure you have the following information available:

• Router model and serial number (on the back panel)

CHA P TER

• Maintenance agreement or warranty information

• Date you received the router

• Brief description of the problem

• Brief description of the steps you have taken to solve the problem

Problems During First Startup

Table 3-1 lists problems that could occur the first time you turn on the power switch.

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

3-1

Problems During First Startup

Table 3-1 Problems During First Startup

Symptom Problem Solutions

All LEDs, including OK LED, are off.

No power to router. Perform the following steps:

1. Make sure that the power switch is set to ON.

2. Make sure that all connections to and from the power

supply are secure.

3. Make sure that the power outlet has power.

4. If the problem continues, the power supply might be

faulty. Contact your Cisco reseller.

No connection to Ethernet device. (Ethernet 1 LED is off.)

• A cable-related

problem:

–

Improperly connected cable.

–

Damaged cable.

Perform the following steps:

1. To make sure that you have cabled the device

correctly, see Figure 2-3 or Figure 2-4 in Chapter 2,

“Installation.”

2. Make sure that the connectors at both ends of the

cable are securely seated.

3. Make sure that the cable is not physically damaged.

If it is damaged, order another cable from Cisco or replace it with a similar cable.

• Improperly set

router TO HUB/TO PC button or hub equivalent of TO

• To make sure that you have set buttons correctly, see

Table 2-2 on page 2-7 if you are installing a

Cisco 827, Cisco 827-4V, or SOHO 77 router. See

Table 2-3 on page 2-8 if you are installing a Cisco

827H or SOHO 77H router. HUB/TO PC button.

No connection to ADSL link. (The

• Wrong cable. • To make sure that you are using the correct cable,

refer to Appendix A, “Specifications and Cables.”

CD LED on the front panel is off for a long time.)

• Improperly

connected cable.

• To make sure that you have connected the ADSL

cable properly, see Figure 2-5 in Chapter 2,

“Installation.”

• Make sure that the connectors at both ends of the

cable are securely seated.

Chapter 3 Troubleshooting

3-2

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Chapter 3 Troubleshooting

Problems After Router Is Running

Table 3-2 lists problems that could occur after the router has been up and running.

Table 3-2 Problems After Router Is Running

Symptom Problem Solutions

Problems with Ethernet connection. (ETHERNET 1, 2, 3, or 4 LED is off.)

Connection to the ADSL line is intermittent or lost. (The CD LED on the front panel is off.)

• A cable-related

problem:

–

Disconnected cable.

–

Damaged cable.

• A cable-related

problem:

–

Disconnected cable.

–

Damaged cable.

• Problem with

ADSL line or WAN service.

Perform the following steps:

1. Make sure that the connectors at both

ends of the cable are secure.

2. Make sure that the cable is not

physically damaged. If it is damaged, order another cable from Cisco Systems or replace it with a similar cable.

• Make sure that the connectors at both

ends of the cable are secure.

• Make sure that the cable is not

physically damaged. If it is damaged, order another cable from Cisco Systems or replace it with a similar cable.

• Contact your ADSL line or WAN

service provider to determine whether there is a problem with the ADSL or WAN service.

Problems After Router Is Running

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

3-3

Problems After Router Is Running

Chapter 3 Troubleshooting

3-4

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

APPENDIX

Specifications and Cables

This appendix provides system, port, and cabling specifications for the Cisco 827 routers.

System Specifications

Table A-1 outlines the system specifications for the routers.

Table A-1 System Specifications

Description Design Specification

Physical Dimensions

Dimensions (H x W x D) 2.0 x 9.7 x 8.5 in. (5.1 x 24.6 x 21.6 cm)

Weight (does not include desktop power supply)

• Cisco 827-4V router: 1.5 lb. (0.68 kg)

• Cisco 827H router: 1.48 lb. (0.67 kg)

• Cisco 827 router: 1.48 lb. (0.67 kg)

Environmental Operating Ranges

Nonoperating temperature –4 to 149°F (–20 to 65°C)

Nonoperating humidity 5 to 95%, relative humidity

Nonoperating altitude 0 to 15,000 ft (4570 m)

Operating temperature 32 to 104°F (0 to 40°C)

Operating humidity 10 to 85% relative humidity

Operating altitude 0 to 10,000 ft (3000 m)

Router Power (Cisco 827, 827-4V, and SOHO 77)

AC input voltage 100 to 250 VAC

Frequency 50 to 60 Hz

Power consumption 29W

Router Power (Cisco 827H and SOHO 77H)

AC input voltage 100 to 240 VAC

Frequency 50 to 60 Hz

Power consumption 15W

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

A-1

Port Connector Pinouts

Table A-1 System Specifications (continued)

Description Design Specification

Telephone Port Power (Cisco 827-4V)

Voltage -24V and -71V

For information on regulatory compliance, refer to the Regulatory Compliance and Safety Information for Cisco 827 Routers document that shipped with your router.

Appendix A Specifications and Cables

Warning

Ultimate disposal of this product should be handled according to all national laws and regulations.

Port Connector Pinouts

This section provides pinouts for the following connectors:

• Ethernet—See Table A-2.

• Console (for connecting a terminal or PC)—See Table A- 3.

• Telephone—See Ta b l e A-4.

• ADSL—See Tab l e A- 5

• Power—See Tab le A-6 and Tab le A-7 .

Table A-2 shows the Ethernet connector pinouts for the Cisco 827-4V, Cisco 827, Cisco 827H,

SOHO 77, and SOHO 77H routers.

Table A-2 Ethernet Connector Pinouts (RJ-45)

Function (TO HUB/TO PC Button –

1TX+ RX+

2TX– RX–

3RX+ TX+

4 Unused Unused

5 Unused Unused

6RX– TX–

7 Unused Unused

8 Unused Unused

IN Position)

Function (TO HUB/TO PC Button – OUT Position)

A-2

Table A-3 shows the Ethernet connector pinouts for the Cisco 827-4V, Cisco 827, Cisco 827H,

SOHO 77, and SOHO 77H routers.

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Appendix A Specifications and Cables

Table A-3 Console Connector Pinouts (RJ-45)

Pin Function

1RTS

2DTR

3TXD

4GND

5GND

6RXD

7DSR

8CTS

Port Connector Pinouts

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

A-3

Port Connector Pinouts

Appendix A Specifications and Cables

The console port is configured as a data communications equipment (DCE) device. The default parameters for the console port are as follows:

• 9600 baud

• Eight data bits

• No parity

• One stop bit

Table A-4 shows telephone connector pinouts for the Cisco 827-4V router.

Table A-4 Cisco 827-4V Router Telephone Connector Pinouts (RJ-11)

Pin Function

1Unused

2Tip

3Ring

4Unused

Table A-5 shows ADSL connector pinouts for the Cisco 827-4V, Cisco 827, Cisco 827H, SOHO 77, and

SOHO 77H routers.

Table A-5 ADSL Connector Pinouts (RJ-11)

Pin Function

1 Loopback to pin 6

2Unused

3Tip

4Ring

5Unused

6 Loopback to pin 1

A-4

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Appendix A Specifications and Cables

Table A-6 shows the power connector pinouts for the Cisco 827, Cisco 827-4V, and SOHO 77 routers.

Table A-6 Cisco 827, Cisco 827-4V, and SOHO 77 Power Connector Pinouts

Pin Function

1ROF

2RTN

3+12

4 –12

5+5

6RTN

7 –71

8 –24

Table A-7 shows the power connector pinouts for the Cisco 827H and SOHO 77H routers.

Cabling Specifications

Table A-7 Cisco 827H and SOHO 77H Power Connector Pinouts

Pin Function

1ROF

2RTN

3AC_Lost

4Unused

5+5VF

6RTN

7Unused

8Unused

Cabling Specifications

This section provides specifications for the following Ethernet cables, which you might need to provide:

• Straight-through cables

• Crossover cables

This section also provides information on Ethernet and telephone cable distance limitations. (Telephone cable connects a device to a telephone port.)

Ethernet Cable Specifications

Table A-8 lists the specifications for straight-through and crossover Ethernet cables.

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

A-5

Cabling Specifications

Table A-8 Ethernet Cable Specifications

Type Category Shielding

10BASE-T Category 3 or 5 Shielded twisted-pair (STP)

10BASE-T – Unshielded twisted-pair (UTP)

Maximum Cable Distances

Table A-9 provides the maximum distances of Ethernet and telephone cables that you can use to connect

equipment to the router.

Table A-9 Maximum Cable Distances

Cable Maximum Distance

Ethernet cables 328 ft (100 m)

Telephone cable 500 ft (152 m)

Appendix A Specifications and Cables

A-6

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

INDEX

Numerics

10BASE-T Ethernet ports 1-2

accessory kit 2-3

AC input voltage (table) A-1

adapter, included 2-3

ADSL 1-2

ADSL line, connecting (figure) 2-11

ADSL port (figure) 1-3, 1-4

altitude specifications (table) A-1

analog telephone, connecting 2-12

Asymmetric digital subscriber line

See ADSL

back panels (figures) 1-4

brackets (figure) 2-5

cable lock (figure) 1-4, 1-5, 1-6

cables

and router damage

Ethernet, types 2-7, 2-8

included with router 2-3

cabling

distances, maximum (table)

specifications (table) A-5

caution statements defined v

2-4

A-6

Cisco Router Web Setup 2-16

console port 1-2

console port (figure) 1-4, 1-5, 1-6

conventions, note, caution, and warning v

DRAM 1-2

dynamic RAM

See DRAM

electrostatic damage, preventing 2-3

ETHERNET 1 LED 2-15

Ethernet cable

specifications

types 2-7, 2-8

Ethernet devices, connecting 2-7

Ethernet LEDs 2-15

Ethernet port (figure) 1-3, 1-4

ETHERNET RXD LED 2-15

ETHERNET TXD LED 2-15

European Union standards 2-4

A-6

fax machine, connecting 2-12

feature summary 1-2

Flash memory 1-2

frequency specifications A-1

front panels (figure) 1-3

78-6854-03

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

IN-1

Index

HUB/NO HUB button settings 2-7

hubs, connecting 2-9

humidity specifications A-1

installation

preparing for

verifying 2-15

2-1

LED functions

Cisco 827-4V router

Cisco 827H router 1-7

Cisco 827 router 1-7

Cisco SOHO 77 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Audience

Preface

Organization

Conventions

Related Documentation

Obtaining Documentation

Cisco.com

Documentation DVD

Documentation Feedback

Ordering Documentation

Cisco Product Security Overview

Reporting Security Problems in Cisco Products

Obtaining Technical Assistance

Cisco Technical Support Website

Submitting a Service Request

Definitions of Service Request Severity

Obtaining Additional Publications and Information

Product Overview

Features

Router Overview

Front Panels

Back Panels

LEDs

Installation

Preparing for Installation

Safety

Warnings

Preventing Electrostatic Discharge Damage

Unpacking the Box

Preventing Router Damage

Mounting the Router

Mounting on a Table

Mounting on a Wall

Installing the Router

Connect Ethernet Devices

Connecting Hubs

Connecting a Server, PC, or Workstation

Connect an ADSL Line

Connect an Analog Telephone or Fax Machine (Cisco 827-4V Routers Only)

Connect a Terminal or PC to the Router’s Console Port (Optional)

Connect the AC Adapter

Using the Router LEDs to Check Links

Configuring the Router

Checking the PC Configuration

Using Cisco Router Web Setup to Configure the Router

Troubleshooting

Before You Call Your Cisco Reseller

Problems During First Startup

Problems After Router Is Running

Specifications and Cables

System Specifications

Port Connector Pinouts

Cabling Specifications

Ethernet Cable Specifications

Maximum Cable Distances

INDEX
