Quick Start Guide

Cisco 220 Series Smart Switches

Package Contents

• Cisco 220 Series Smart Switch

• Power Cord

• Rack-Mount Kit and Rubber Feet

• Console Cable

• This Quick Start Guide

• Product CD

• Technical Support Contacts

Welcome

1

2

Thank you for choosing the Cisco 220 Series Smart Switch, a Cisco
network communications device. This device is designed to be
operational right out-of-the-box as a standard bridge. In the default
configuration, it will forward packets between connecting devices after
power up.

This guide familiarizes you with the layout of the switch and describes how
to deploy the switch in your network. For additional information, see

www.cisco.com/go/220switches.

Before You Begin

Before you begin the installation, make sure that you have the following:

• RJ-45 Ethernet cables (Category 5E or higher) for connecting network
devices.

• Console cable for using the console port to manage your switch.

• Tools for installing the hardware. The rack-mount kit packed with the

switch contains four rubber feet for desktop placement, and two
brackets and twelve screws for rack-mounting.

• PC with Internet Explorer (version 8.0 and higher), Firefox (version 20.0
or higher), Chrome (version 23.0 or higher), or Safari (version 5.7 or
higher) for using the web-based interface or the console port to
manage your switch.

Cisco 220 Switch Features

This section describes the available product models and the exterior of the
switch to help familiarize you with your switch.

Product Models

Model Description Ports

SF220-24 24-Port 10/100 Smart Switch 24 FE Copper + 2 GE

Combo

SF220-24P 24-Port 10/100 PoE Smart Switch 24 FE Copper + 2 GE

Combo

SF220-48 48-Port 10/100 Smart Switch 48 FE Copper + 2 GE

Combo

2 Cisco 220 Series Smart Switches Quick Start Guide

Model Description Ports

Left Side Right Side

SF220-48P 48-Port 10/100 PoE Smart Switch 48 FE Copper + 2 GE

Combo

SG220-26 26-Port Gigabit Smart Switch 24 GE Copper + 2 GE

Combo

SG220-26P 26-Port Gigabit PoE Smart

Switch

SG220-50 50-Port Gigabit Smart Switch 48 GE Copper + 2 GE

SG220-50P 50-Port Gigabit PoE Smart

Switch

24 GE Copper + 2 GE
Combo

Combo
48 GE Copper + 2 GE

Combo

Front Panel

The ports, LEDs, and Reset button are located on the front panel of the
switch.

RJ-45 Ethernet Ports—The RJ-45 Ethernet ports connect network
devices, such as computers, printers, and access points, to the switch.

SFP Ports—The small form-factor pluggable (SFP) ports are connection
points for modules so that the switch can link to other switches. These
ports are also commonly referred to as mini Gigabit Interface Converter
(miniGBIC) ports. The term SFP will be used in this guide.

• The SFP ports are compatible with Cisco modules MFEBX1, MFEFX1,
MFELX1, MGBLH1, MGBLX1, MGBSX1, MGEBX1, and MGBT1.

• The SFP port is shared with one other RJ-45 port, called a combo port.
When the SFP port is active, the adjacent RJ-45 port is disabled.

• The LEDs of the corresponding RJ-45 ports flash green to respond to
the SFP port traffic.

Cisco 220 Series Smart Switches Quick Start Guide 3

Reset Button—The Reset button is used to reboot or reset the switch with

100-240V~

8-4A 50-60Hz

CONSOLE

370927

a pin or paper clip. See Returning the Cisco 220 Switch to the Factory

Default Settings for more information.

System LED—(Green) Lights steady when the switch is powered on, and

flashes green when booting, performing self-tests, and/or acquiring an IP
address. If the LED flashes amber, the switch has detected a hardware
failure, a firmware failure, and/or a configuration file error.

Link/ACT LED—(Green) Located on the left of the port. Lights steady
when a link between the corresponding port and other device is detected.
Flashes when the port is passing traffic.

NOTE The System and LINK/ACT LEDs are on each model of the switch.

The LEDs that follow are only present on the switch models that have
those capabilities.

100M LED (if present)—(Green) Located on the right of the port. Lights
steady when other device is connected to the port, is powered on, and a
100 Mbps link is established between the devices. When the LED is off, the
connection speed is under 100 Mbps or nothing is cabled to the port.

GIGABIT LED (if present)—(Green) Located on the right of the port. Lights
steady when another device is connected to the port, is powered on, and a
1000 Mbps link is established between the devices. When the LED is off,
the connection speed is under 1000 Mbps or nothing is cabled to the port.

PoE LED (if present)—(Amber) Located on the right of the port. Lights
steady to indicate that power is being supplied to a device attached to the
corresponding port.

Back Panel

The power and console ports are located on the back panel of the switch.

POWER—The power port connects the switch to power.

CONSOLE—The console port connects the supplied console cable to a
computer’s serial port for configuration using a terminal emulation
program.

4 Cisco 220 Series Smart Switches Quick Start Guide

Mounting the Cisco 220 Switch

3

390235

There are three ways to physically install the switch:

• Place the switch on a flat surface. To place the switch on a desktop,
install the four rubber feet (included) on the bottom of the switch.

• Mount the switch in a standard rack (1 rack unit high).

• Mount the switch to a wall (non-PoE models only).

Placement Tips

•Ambient Temperature—To prevent the switch from overheating, do not

operate it in an area that exceeds an ambient temperature of 122°F
(50°C).

•Air Flow—Be sure that there is adequate air flow around the switch.

• Mechanical Loading—Be sure that the switch is level and stable to

avoid any hazardous conditions.

• Circuit Overloading—Adding the switch to the power outlet must not
overload that circuit.

Rack Mounting

You can mount the switch in any standard size, 19-inch (about 48 cm) wide
rack. The switch requires 1 rack unit (RU) of space, which is 1.75 inches
(44.45 mm) high.

CAUTION For stability, load the rack from the bottom to the top, with the

heaviest devices on the bottom. A top-heavy rack is likely to
be unstable and might tip over.

To install the switch into a 19-inch standard chassis:

STEP 1 Attach one of the supplied brackets on the side of the switch so that

the four holes align to the screw holes, and use the four supplied M5
(non-PoE models) or M4 (PoE models) screws to secure it.

Cisco 220 Series Smart Switches Quick Start Guide 5
