Introduction

The Cisco Nexus® B22 Blade Fabric Extender for IBM® extends the Cisco Nexus switch fabric to the server edge. Logically, it behaves like a remote line card to a parent Cisco Nexus 5000 or 6000 Series Switch. The fabric extender and the parent Cisco Nexus 5000 or 6000 Series Switch together form a distributed modular system. The Cisco Nexus B22 for IBM forwards all traffic to the parent Cisco Nexus 5000 or 6000 Series Switch over eight 10 Gigabit Ethernet uplinks. Low-cost uplink connections of up to 10 meters can be made with copper Twinax cable, and longer connections of up to 100 meters can use the Cisco® 10-Gbps fabric extender transceiver (FET10G). Standard 10-Gbps optics such as short reach (SR), long reach (LR), and extended reach (ER) are also supported. Downlinks to each server are 10 Gigabit Ethernet and work with all Ethernet and converged network adapter (CNA) mezzanine cards, allowing customers a choice of Ethernet, Fibre Channel over Ethernet (FCoE), or Small Computer System Interface over IP (iSCSI) connections. Because the Cisco Nexus B22 for IBM is a transparent extension of a Cisco Nexus switch, traffic can be switched according to policies established by the Cisco Nexus switch using a single point of management.

The Cisco Nexus B22 for IBM provides the following benefits: Highly scalable, consistent server access: This distributed modular system creates a scalable server access

environment with no reliance on Spanning Tree Protocol and with consistent features and architecture between blade and rack servers.

Simplified operations: The availability of one single point of management and policy enforcement using upstream Cisco Nexus 5000 Series Switches eases the commissioning and decommissioning of blades through zero-touch installation and automatic configuration of fabric extenders.

Increased business benefits: Consolidation, reduced cabling, investment protection through feature inheritance from the parent switch, and the capability to add functions without the need for a major equipment upgrade of server-attached infrastructure all contribute to reduced operating expenses (OpEx) and capital expenditures (CapEx).

The Cisco Nexus B22 for IBM integrates into the I/O module slot of a third-party blade chassis, drawing both power and cooling from the blade chassis itself.

Network Diagram

Figure 1 presents a sample network topology that can be built using the Cisco Nexus B22 for IBM, 2000 Series Fabric Extenders, and 5000 or 6000 Series Switches. In this topology, the Cisco Nexus 5000 or 6000 Series Switch serves as the parent switch, performing all packet switching and policy enforcement for the entire distributed modular system. The Cisco Nexus switch also serves as the only point of management for both configuration and monitoring within the domain, making it simple to manage blade server and rack server connections together.

Figure 1: Cisco Nexus Virtual Chassis Topology

The Cisco Nexus switches, along with the Cisco Nexus 2000 Series and B22 for IBM, create a distributed modular system that unifies the data center architecture. Within this distributed modular system, both IBM Flex System® computing nodes and rack servers are managed identically. This approach allows the use of the same business and technical processes and procedures.

The left-most blade chassis in Figure 1 contains dual Cisco Nexus B22 for IBM fabric extenders. Each Cisco Nexus B22 for IBM is singlely attached to a parent Cisco Nexus 5500 platform switch, a connection mode referred to as straight-through mode. The fabric links can be either statically pinned or put into a Port Channel. This connection mode helps ensure that all data packets from a particular Cisco Nexus B22 for IBM enter the same parent Cisco Nexus switch. This approach may be necessary when certain types of traffic must be restricted to either the left or right Cisco Nexus 5500 platform switch: for instance, to maintain SAN A and SAN B separation. Also, in this example the connections to individual computing nodes are in active-standby mode, which helps ensure traffic flow consistency but does not make full use of the server network interface card (NIC) bandwidth.

The second IBM Flex System chassis from the left in Figure 1 improves on the first with the creation of an Ethernet virtual Port Channel (vPC) from the computing node to the Cisco Nexus parent switch. This vPC places the Ethernet portion of the NICs in an active-active configuration, giving increased bandwidth to each host. The FCoE portion of the CNA is also configured as active-active but maintains SAN A and SAN B separation because each virtual Fibre Channel (vFC) interface is bound to a particular link at the server. This configuration also achieves high availability through redundancy, and it can withstand a failure of a Cisco Nexus 5500 platform switch, a Cisco Nexus B22 for IBM, or any connecting cable. This topology is widely used in FCoE deployments.

The third blade chassis from the left in Figure 1 contains Cisco Nexus B22 for IBM fabric extenders that connect to both Cisco Nexus 5500 platform switches through vPC for redundancy. In this configuration, active-active load balancing using vPC from the blade server to the Cisco Nexus 5500 platform switch cannot be enabled. However, the servers can still be dual-homed with active-standby or active-active transmit-load-balancing (TLB) teaming. This topology is only for Ethernet traffic because SAN A and SAN B separation between the fabric extender and the parent switch is necessary.

The fourth blade chassis from the left in Figure 1 contains Cisco Nexus B22 for IBM fabric extenders that connect

Card

Connection Blades

LAN on motherboard (LoM) plus mezzanine card in slot 1

I/O module bays 1 and 2 Mezzanine card in slot 2

I/O module bays 3 and 4

Card

Connection Blades

Mezzanine 1 ports 1 to 4

I/O module bays 1 and 2

Mezzanine 2 ports 1 to 4

I/O module bays 3 and 4

Card

Connection Blades

Mezzanine 1 ports 1 to 4

I/O module bays 1 and 2

Mezzanine 2 ports 1 to 4

I/O module bays 3 and 4

Mezzanine 3 ports 1 to 4

I/O module bays 1 and 2

Mezzanine 4 ports 1 to 4

I/O module bays 3 and 4

Blade Chassis

Server Manager Firmware

IBM PureFlex™ System Model 8721HC1

DSA:9.41, IMM2:2.6, UEFI:1.31, and CMM: 2PET12E

to both Cisco Nexus 5500 platform switches with enhanced vPC (EvPC) technology. This configuration allows active-active load balancing from the fabric extenders and the computing nodes.

The last two configurations show how rack-mount servers can connect to the same Cisco Nexus parent switch using rack-mount Cisco Nexus 2000 Series Fabric Extenders. The topology for blade servers and rack-mount servers can be identical if desired.

Hardware Installation

Installation of the Cisco Nexus B22 for IBM in the rear of the blade server chassis is similar to the installation of other connection blades. The layout of the blade server chassis, as well as the server types and mezzanine cards used, determines the slots that should be populated with the Cisco Nexus B22 for IBM for 10 Gigabit Ethernet connectivity. Tables 1 through 3 summarize the typical options for servers using dual-port 10 Gigabit Ethernet devices.

Table 1 Mapping of Third-Party Half-Wide Server Dual-Port Mezzanine Card to I/O Module

Table 2 Mapping of Third-Party Half-Wide Server Quad-Port Mezzanine Card to I/O Module

Table 3 Mapping of Third-Party Full-Wide Server Quad-Port Mezzanine Card to I/O Module

After the Cisco Nexus B22 for IBM fabric extenders are installed, the chassis management module (CMM) should be updated to at least the minimum version shown in Table 4.

Table 4 Management Blade Minimum Firmware Versions

No configuration is required from the chassis MMB. Only the minimum CMM firmware is required to properly detect and enable the Cisco Nexus B22 for IBM in the blade chassis (Figure 2).

Figure 2: Cisco Nexus B22 for IBM Fabric Extenders as Seen in the CMM

Fabric Extender Management Model

The Cisco Nexus fabric extenders are managed by a parent switch through the fabric interfaces using a zerotouch configuration model. The switch discovers the fabric extender by using a detection protocol.

After discovery, if the fabric extender has been correctly associated with the parent switch, the following operations are performed:

1. The switch checks the software image compatibility and upgrades the fabric extender if necessary.

2. The switch and fabric extender establish in-band IP connectivity with each other. The switch assigns an IP address in the range of loopback addresses (127.15.1.0/24) to the fabric extender to avoid conflicts with IP addresses that might be in use on the network.

3. The switch pushes the configuration data to the fabric extender. The fabric extender does not store any configuration locally.

4. The fabric extender updates the switch with its operating status. All fabric extender information is displayed using the switch commands for monitoring and troubleshooting.

This management model allows fabric extender modules to be added without adding management points or complexity. Software image and configuration management is also handled automatically, without the need for user intervention.

Fabric Connectivity Options

Interface

Fabric Link

1, 2, 3, 4, 5, 6, and 7

Fabric link 1

8, 9, 10, 11, 12, 13, and 14

Fabric link 2

The Cisco Nexus B22 for IBM creates a distributed, modular chassis with the Cisco Nexus parent switch after a fabric connection has been made over standard 10-Gbps cabling. This connection can be accomplished using any of the following types of interconnects:

 Cisco passive direct-attach cables (1m, 3m, or 5m)  Cisco active direct-attach cables (7m or 10m)  Cisco standard Enhanced Small Form-Factor Pluggable (SFP+) optics (SR, LR, and ER)  Cisco Fabric Extender Transceivers (FET modules)

After the fabric links have been physically established, the logical configuration of the links must be established. The fabric links to the Cisco Nexus B22 for IBM can use either of two connection methods:

 Statically pinned fabric interface connection  Port Channel fabric interface connection

Statically Pinned Fabric Interface Connection

Static pinning is the default method of connection between the fabric extender and the Cisco Nexus parent switch. In this mode of operation, a deterministic relationship exists between the host interfaces and the upstream parent; up to eight fabric interfaces can be connected. These fabric interfaces are equally divided among the 16 serverside host ports. If fewer fabric ports are allocated, more server ports are assigned to a single fabric link. The advantage of this configuration is that the traffic path and the amount of allocated bandwidth are always known for a particular set of servers.

Since static pinning will group host-side ports into individual fabric links, you should understand how ports are grouped. The size of the port groups is determined by the number of host ports divided by the max link parameter value. For example, if the max link parameter is set to 2, eight host ports would be assigned to each link. The interfaces will be grouped in ascending order starting from interface 1. Thus, interfaces 1 to 8 will be pinned to one fabric link, and interfaces 9 to 16 will be pinned to a different interface (Table 5).

Table 5 Interface Assignment with Two Fabric Links

Table 6 summarizes the assignment with four fabric links: With the max link parameter set to 4, the interfaces are

Interface

Fabric Link

1, 2, 3, and 4

Fabric link 1

5, 6, 7, and 8

Fabric link 2

9, 10, and 11

Fabric link 3

12, 13, and 14

Fabric link 4

Interface

Fabric Link

1 and 2

Fabric link 1

3 and 4

Fabric link 2

5 and 6

Fabric link 3

7 and 8

Fabric link 4

9 and 10

Fabric link 5

11 and 12

Fabric link 6

13

Fabric link 7

14

Fabric link 8

divided into four groups. Table 6 Interface Assignment with Four Fabric Links

Table 7 summarizes the assignment of eight fabric links: With the max link parameter set to 8, the interfaces are divided into eight groups.

Table 7 Interface Assignment with Eight Fabric Links

Note: The assignment of the host-side ports is always based on the configured max link parameter and not the actual

physical number of fabric ports connected. Be sure to match the max link parameter with the actual number of physical links used.

The relationship of host-side ports to parent switch fabric ports is static. If a fabric interface fails, all its associated host interfaces are brought down and will remain down until the fabric interface is restored. Figure 3 shows static port mappings.

Figure 3: Static Port Mapping Based on Max Link Parameter

Port Channel Fabric Interface Connection

The Port Channel fabric interface provides an alternative way of connecting the parent switch and the Cisco Nexus B22 for IBM fabric extender. In this mode of operation, the physical fabric links are bundled into a single logical channel. This approach prevents a single fabric interconnect link loss from disrupting traffic to any one server. The total bandwidth of the logical channel is shared by all the servers, and traffic is spread across the members through the use of a hash algorithm.

 For a Layer 2 frame, the switch uses the source and destination MAC addresses.  For a Layer 3 frame, the switch uses the source and destination MAC addresses and the source and

destination IP addresses.

Since both redundancy and increased bandwidth are possible, configuration of the fabric links on a Port Channel is the most popular connection option.

Figure 4 shows Port Channel designs.

Note: A fabric interface that fails in the Port Channel does not trigger a change to the host interfaces. Traffic is automatically

redistributed across the remaining links in the Port Channel fabric interface.

Figure 4: Port Channel Designs

Configuring a Fabric Port Channel

Follow these steps to configure a fabric Port Channel.

1. Log into the first parent switch and enter configuration mode:

Nexus 5000 Switch

login: admin

Password:

Cisco Nexus Operating System (NX-OS) Software

TAC support: http://www.cisco.com/tac

The copyrights to certain works contained in this software are

owned by other third parties and used and distributed under

license. Certain components of this software are licensed under

the GNU General Public License (GPL) version 2.0 or the GNU

Lesser General Public License (LGPL) Version 2.1. A copy of each

such license is available at

http://www.opensource.org/licenses/gpl-2.0.php and

http://www.opensource.org/licenses/lgpl-2.1.php

N5548-Bottom# configure terminal

Enter configuration commands, one per line. End with CNTL/Z.

N5548-Bottom(config)#

2. Enable the fabric extender feature:

N5548-Bottom(config)#

N5548-Bottom(config)# feature fex

N5548-Bottom(config)#

3. Logically create the fabric extender:

N5548-Bottom(config)#

N5548-Bottom(config)# fex 191

N5548-Bottom(config-fex)#

4. Create the Port Channel, change the port mode, and associate the fabric extender with the Port Channel:

N5548-Bottom(config-if)# interface port-channel 191

N5548-Bottom(config-if)# switchport mode fex-fabric

N5548-Bottom(config-if)# fex associate 191

N5548-Bottom(config-if)#

5. Assign the Cisco Nexus parent switch ports to the Port Channel:

N5548-Bottom(config-if)# interface ethernet 1/17

N5548-Bottom(config-if)# switchport mode fex-fabric

N5548-Bottom(config-if)# fex associate 191

N5548-Bottom(config-if)# channel-group 191

N5548-Bottom(config-if)# interface ethernet 1/18

N5548-Bottom(config-if)# switchport mode fex-fabric

N5548-Bottom(config-if)# fex associate 191

N5548-Bottom(config-if)# channel-group 191

6. Repeat the steps on the second Cisco Nexus 5000 Series Switch connected to the fabric extender in interconnect bay 4:

N5548-Top# configure terminal

N5548-Top(config)# feature fex

N5548-Top(config)# fex 192

N5548-Top(config-if)# interface port-channel 192

N5548-Top(config-if)# switchport mode fex-fabric

N5548-Top(config-if)# fex associate 192

N5548-Top(config-if)# interface ethernet 1/17

N5548-Top(config-if)# switchport mode fex-fabric

N5548-Top(config-if)# fex associate 192

N5548-Top(config-if)# channel-group 192

N5548-Top(config-if)# interface ethernet 1/18

N5548-Top(config-if)# switchport mode fex-fabric

N5548-Top(config-if)# fex associate 192

N5548-Top(config-if)# channel-group 192

7. Verify that the Cisco Nexus B22 for IBM is up and running:

switch(config-if)# show fex

FEX FEX FEX FEX

Number Description State Model Serial

------------------------------------------------------------------------

192 FEX0192 Online N2K-B22IBM-P FOC1730R0XQ

A pair of fabric extenders now is configured in straight-through mode, also known as a single-attached configuration, and each is communicating with its respective Cisco Nexus switch. The links between the two Cisco Nexus switches and the Cisco Nexus B22 fabric extenders use Port Channels for connectitivity.

Virtual Port Channel Connection

vPCs allow links that are physically connected to two different Cisco Nexus switches to form a Port Channel to a downstream device. The downstream device can be a switch, a server, or any other networking device that supports IEEE 802.3ad Port Channels. vPC technology enables networks to be designed with multiple links for redundancy while also allowing those links to connect to different endpoints for added resiliency (Figure 5).

More information about vPC technology can be found at

http://www.cisco.com/en/US/products/ps9670/products_implementation_design_guides_list.html.

Figure 5: Blade Server Configuration Options

Configuring a vPC

The high-level steps for enabling vPC are listed here. This configuration should be implemented on both switches in parallel.

1. Enable the vPC feature.

2. Create the vPC domain.

3. Configure the peer keepalive link.

4. Configure the vPC peer link Port Channel.

5. Check the status of the vPC.

1. Enable the vPC feature:

N5548-Bottom# configure terminal

N5548-Bottom(config)# feature vpc

N5548-Top# configure terminal

N5548-Top(config)# feature vpc

2. Create the vPC domain (the domain should be unique within network):

N5548-Bottom(config)# vpc domain 5

N5548-Bottom(config)# role priority 1

N5548-Bottom(config)# system-priority 1

N5548-Top(config)# vpc domain 5

N5548-Top(config)# role priority 2

N5548-Top(config)# system-priority 1

3. Configure the peer keepalive link over the management network:

N5548-Bottom(config-vpc-domain)# peer-keepalive destination 172.25.182. 109 source

172.25.182. 108

Note:

--------:: Management VRF will be used as the default VRF ::--------

N5548-Top(config-vpc-domain)# peer-keepalive destination 172.25.182. 108 source

172.25.182. 109

Note:

--------:: Management VRF will be used as the default VRF ::--------

4. Configure the vPC peer link:

N5548-Bottom# interface port-channel 20

N5548-Bottom(config-if)# interface ethernet 1/9

N5548-Bottom(config-if)# channel-group 20

N5548-Bottom(config-if)# interface ethernet 1/10

N5548-Bottom(config-if)# channel-group 20

N5548-Bottom(config-if)# interface port-channel 20

N5548-Bottom(config-if)# vpc peer-link

Please note that spanning tree port type is changed to "network" port type on vPC peerlink.

This will enable spanning tree Bridge Assurance on vPC peer-link provided the STP Bridge Assurance(which is enabled by default) is not disabled.

N5548-Bottom(config-if)#

N5548-Top# interface port-channel 20

N5548-Top (config-if)# interface ethernet 1/9

N5548-Top(config-if)# channel-group 20

N5548-Top(config-if)# interface ethernet 1/10

N5548-Top(config-if)# channel-group 20

N5548-Top(config-if)# interface port-channel 20

N5548-Top(config-if)# vpc peer-link

Please note that spanning tree port type is changed to "network" port type on vPC peerlink.

This will enable spanning tree Bridge Assurance on vPC peer-link provided the STP Bridge Assurance(which is enabled by default) is not disabled.

N5548-Bottom(config-if)#

5. Check the vPC status:

N5548-Bottom(config-if)# show vpc

Legend:

(*) - local vPC is down, forwarding via vPC peer-link

vPC domain id : 5

Peer status : peer adjacency formed ok

vPC keep-alive status : peer is alive

Configuration consistency status: success

Per-vlan consistency status : success

Type-2 consistency status : success

vPC role : primary

Number of vPCs configured : 0

Peer Gateway : Disabled

Dual-active excluded VLANs : -

Graceful Consistency Check : Enabled

vPC Peer-link status

---------------------------------------------------------------------

id Port Status Active vlans

-- ---- ------ --------------------------------------------------

1 Po20 up 1,182

N5548-Bottom(config-if)#

Now the two switches have been configured to support vPC links to other devices. These connections can be used for upstream links to the data center core. These vPC links can be used for connections to hosts in the data center, allowing additional bandwidth and redundant links.

Server Network Teaming

Server NIC teaming provides an additional layer of redundancy to servers. It makes it possible for multiple links to be available, for redundancy. In the blade server environment, server network teaming typically is limited to active-standby configurations and cannot provide active-active links, because active-active links require an EtherChannel or Link Aggregation Control Protocol (LACP) connection to a single switch. However, because the Cisco Nexus B22 for IBM fabric extender is an extension of the parent switch, EtherChannel or LACP connections can be created between the blade server and the virtual chassis. Dual Cisco Nexus switches can be used with vPC for additional switch redundancy while providing active-active links to servers, thus enabling aggregate 40Gbps bandwidth with dual links (Figure 6).

Figure 6: Fabric Link and Server Topologies

Figure 7: Enhanced vPC Configuration

Creating Host-Side vPC for Server Links with LACP

1. Enable LACP on both parent switches.

5548-Bottom(config)# feature lacp

5548-Top(config)# feature lacp

2. Define and configure the left diagram FEX 191 for enhanced vPC on the left Nexus parent

5548-Bottom(config)# fex 191

5548-Bottom(config-fex)# interface ethernet 1/21-22

5548-Bottom(config-if)# channel-group 191

5548-Bottom(config-if)# no shutdown

5548-Bottom(config-if)# interface port-channel 191

5548-Bottom(config-if)# switchport mode fex-fabric

5548-Bottom(config-if)# fex associate 191

5548-Bottom(config-if)# vpc 191

5548-Bottom(config-if)# no shutdown

3. Define and configure the right diagram FEX 192 for enhanced vPC on the left Nexus parent

5548-Bottom(config)# fex 192

5548-Bottom(config-fex)# interface ethernet 1/23-24

5548-Bottom(config-if)# channel-group 192

5548-Bottom(config-if)# no shutdown

5548-Bottom(config-if)# interface port-channel 192

5548-Bottom(config-if)# switchport mode fex-fabric

5548-Bottom(config-if)# fex associate 192

5548-Bottom(config-if)# vpc 192

5548-Bottom(config-if)# no shutdown

4. Define and configure the left diagram FEX 191 for enhanced vPC on the right Nexus parent

5548-Top(config)# fex 191

5548-Top(config-fex)# interface ethernet 1/21-22

5548-Top(config-if)# channel-group 191

5548-Top(config-if)# no shutdown

5548-Top(config-if)# interface port-channel 191

5548-Top(config-if)# switchport mode fex-fabric

5548-Top(config-if)# fex associate 191

5548-Top(config-if)# vpc 191

5548-Top(config-if)# no shutdown

5. Define and configure the right diagram FEX 192 for enhanced vPC on the right Nexus parent

5548-Top(config)# fex 192

5548-Top(config-fex)# interface ethernet 1/23-24

5548-Top(config-if)# channel-group 192

5548-Top(config-if)# no shutdown

5548-Top(config-if)# interface port-channel 192

5548-Top(config-if)# switchport mode fex-fabric

5548-Top(config-if)# fex associate 192

5548-Top(config-if)# vpc 192

5548-Top(config-if)# no shutdown

6. Create the port channel between the blade server and the FEX

5548-Bottom# configure terminal

Enter configuration commands, one per line. End with CNTL/Z.

5548-Bottom#(config)# interface port-channel 201

5548-Bottom#(config-if)# switchport mode trunk

5548-Bottom#(config-if)# switchport trunk native vlan 182

5548-Bottom#(config-if)# switchport trunk allowed vlan 182-184,200

5548-Bottom#(config-if)# no shutdown

5548-Top# configure terminal

5548-Top#(config)# interface port-channel 201

5548-Top#(config)# switchport mode trunk

5548-Top#(config)# switchport trunk native vlan 182

5548-Top#(config)# switchport trunk allowed vlan 182-182,201

5548-Top#(config)# no shutdown

7. Add the member interfaces to the vPC port channel and permit VLAN or desired VLANs for L2 Trunk links.

Note: If a Native VLAN besides 1 is desired ensure it is correctly defined before use.

5548-Bottom(config-if)# interface ethernet 191/1/7

5548-Bottom(config-if)# switchport mode trunk

5548-Bottom(config-if)# switchport trunk native vlan 182

5548-Bottom(config-if)# switchport trunk allowed vlan 182-184,200

5548-Bottom(config-if)# channel-group 201 mode active

5548-Bottom(config-if)# no shutdown

5548-Bottom(config-if)# interface ethernet 192/1/7

5548-Bottom(config-if)# switchport mode trunk

5548-Bottom(config-if)# switchport trunk native vlan 182

5548-Bottom(config-if)# switchport trunk allowed vlan 182-184,200

5548-Bottom(config-if)# channel-group 201 mode active

5548-Bottom(config-if)# no shutdown

8. Repeat the vlan configuration on the second Nexus parent switch for the vPC port channel and permit VLAN or desired VLANs for L2 Trunk links.

5548-Top(config-if)# interface ethernet 191/1/7

5548-Top(config-if)# switchport mode trunk

5548-Top(config-if)# switchport trunk native vlan 182

5548-Top(config-if)# switchport trunk allowed vlan 182-184,201

5548-Top(config-if)# channel-group 201 mode active

5548-Top(config-if)# no shutdown

5548-Top(config-if)# interface ethernet 192/1/7

5548-Top(config-if)# switchport mode trunk

5548-Top(config-if)# switchport trunk native vlan 182

5548-Top(config-if)# switchport trunk allowed vlan 182-184,201

5548-Top(config-if)# channel-group 201 mode active

5548-Top(config-if)# no shutdown

Note: With EvPC when you configure a Port Channel from the Cisco Nexus 2000 Series to the server, do not include the

vpc x configuration under the Port Channel. vPC should be assigned automatically by the Cisco NX-OS Software. For more information, see

http://www.cisco.com/en/US/docs/switches/datacenter/nexus5500/sw/layer2/6x/b_5500_Layer2_Config_602N12_cha pter_0101.html.

To verify that the vPC is formed, go to one of the Cisco Nexus switches to check the status of the server Port Channel interface. The pair of Cisco Nexus switches is in a vPC configuration, so each has a single port in the Port Channel. A check of the status of the Port Channel on each parent switch shows that channel group 201 is in the “P - Up in port-channel” state on each switch. A check from the OneCommand utility will show that the status is “Active” for each link that is up in the Port Channel.

5548-Bottom# show port-channel summary

Flags: D - Down P - Up in port-channel (members)

I - Individual H - Hot-standby (LACP only)

s - Suspended r - Module-removed

S - Switched R - Routed

U - Up (port-channel)

M - Not in use. Min-links not met

--------------------------------------------------------------------------------

Group Port- Type Protocol Member Ports

Channel

--------------------------------------------------------------------------------

20 Po20(SU) Eth NONE Eth1/9(P) Eth1/10(D)

191 Po191(SU) Eth NONE Eth1/17(P)

192 Po192(SU) Eth NONE Eth1/18(P)

193 Po193(SU) Eth NONE Eth1/19(P)

194 Po194(SD) Eth NONE Eth1/20(D)

201 Po201(SU) Eth NONE Eth191/1/1(P)

202 Po202(SU) Eth NONE Eth192/1/1(P)

5548-Bottom #

N5548-Top# show port-channel summary

show port-channel summary

Flags: D - Down P - Up in port-channel (members)

I - Individual H - Hot-standby (LACP only)

s - Suspended r - Module-removed

S - Switched R - Routed

U - Up (port-channel)

M - Not in use. Min-links not met

--------------------------------------------------------------------------------

Group Port- Type Protocol Member Ports

Channel

--------------------------------------------------------------------------------

10 Po10(SD) Eth NONE --

20 Po20(SU) Eth NONE Eth1/9(P) Eth1/10(D)

61 Po61(SU) Eth NONE Eth1/5(P) Eth1/6(P)

191 Po191(SU) Eth NONE Eth1/17(P)

192 Po192(SU) Eth NONE Eth1/18(P)

193 Po193(SU) Eth NONE Eth1/19(P)

194 Po194(SD) Eth NONE Eth1/20(D)

201 Po201(SU) Eth NONE Eth191/1/1(P)

202 Po202(SU) Eth NONE Eth192/1/1(P)

N5548-Top#

Fibre Channel over Ethernet

FCoE combines LAN and storage traffic on a single link, eliminating the need for dedicated adapters, cables, and devices for each type of network, resulting in savings that can extend the life of the data center. The Cisco Nexus B22 for IBM is the building block that enables FCoE traffic to travel outside the blade chassis.

Best practices for unified fabric are listed in the Cisco NX-OS operations guide for the Cisco Nexus 5000 Series at

http://www.cisco.com/en/US/docs/switches/datacenter/nexus5000/sw/operations/n5k_ops_guide.html.

Configuring FCoE

Follow these steps to configure FCoE:

1. Enable the FCoE personality on the CNA.

2. Verify and, if necessary, install the FCoE drivers in the server OS.

3. Enable FCoE on the parent switches.

4. Configure quality of service (QoS) to support FCoE on the Cisco Nexus parent switch.

5. Enable the FCoE feature on the Cisco Nexus switch.

6. Create the SAN A and SAN B VLANs.

7. Create vFC interfaces.

1. Enable FCoE on the CNA.

The CNA personality should be set to FCoE according to the CNA documentation.

2. Verify and, if necessary, install the FCoE drivers in the server OS.

Verify that the latest FCoE drivers and firmware are loaded for the operating system. The latest versions can be obtained from the third-party support website. The FCoE drivers are separate from the Ethernet NIC drivers. Generally, the latest versions of the CNA drivers and the CNA firmware should be used.

Figure 8 shows the ports configured for FCoE and the drivers loaded.

Figure 8: OneCommand FCoE Utility Showing Ports Configured for FCoE with Drivers Loaded

Configuring the Cisco Nexus 5000 Series and B22 for IBM for FCoE

This example assumes that a server in bay 2 is using connection blade bays 3 and 4 for FCoE connectivity.

1. Enable the FCoE feature on the Cisco Nexus switches:

N5548-Bottom # config terminal

Enter configuration commands, one per line. End with CNTL/Z.

switch(config)# feature fcoe

FC license checked out successfully

fc_plugin extracted successfully

FC plugin loaded successfully

FCoE manager enabled successfully

FC enabled on all modules successfully

Warning: Ensure class-fcoe is included in qos policy-maps of all types

N5548-Bottom (config)#

N5548-Top # config terminal

Enter configuration commands, one per line. End with CNTL/Z.

switch(config)# feature fcoe

FC license checked out successfully

fc_plugin extracted successfully

FC plugin loaded successfully

FCoE manager enabled successfully

FC enabled on all modules successfully

Warning: Ensure class-fcoe is included in qos policy-maps of all types

N5548-Top (config)#

2. Configure QoS to support FCoE on both switches:

N5548-Bottom(config)# system qos

N5548-Bottom(config-sys-qos)# service-policy type qos input fcoe-default-in-policy

N5548-Bottom(config-sys-qos)# service-policy type queuing input fcoe-default-in-policy

N5548-Bottom(config-sys-qos)# service-policy type queuing output fcoe-default-out-policy

N5548-Bottom(config-sys-qos)# service-policy type network-qos fcoe-default-nq-policy

N5548-Bottom(config-sys-qos)#

N5548-Top(config)# system qos

N5548-Top(config-sys-qos)# service-policy type qos input fcoe-default-in-policy

N5548-Top(config-sys-qos)# service-policy type queuing input fcoe-default-in-policy

N5548-Top(config-sys-qos)# service-policy type queuing output fcoe-default-out-policy

N5548-Top(config-sys-qos)# service-policy type network-qos fcoe-default-nq-policy

N5548-Top(config-sys-qos)#

3. Create the virtual Fibre Channel interface (physical port) on both switches:

N5548-Bottom(config)#

N5548-Bottom(config)# interface vfc 1032

N5548-Bottom(config-if)# switchport mode F

N5548-Bottom(config-if)# bind interface ethernet 191/1/7

N5548-Bottom(config-if)# switchport trunk allowed vsan 200

N5548-Bottom(config-if)# no shut

N5548-Bottom(config-if)#

N5548-Top(config)#

N5548-Top(config)# interface vfc 1032

N5548-Top(config-if)# switchport mode F

N5548-Top(config-if)# bind interface ethernet 192/1/7

N5548-Top(config-if)# switchport trunk allowed vsan 201

N5548-Top(config-if)# no shut

N5548-Top(config-if)#

Create the virtual Fibre Channel interface (Port Channel) on both switches:

N5548-Bottom(config)#

N5548-Bottom(config)# interface vfc 1032

N5548-Bottom(config-if)# switchport mode F

N5548-Bottom(config-if)# bind interface port-channel 201

N5548-Bottom(config-if)# no shut

N5548-Bottom(config-if)#

N5548-Top(config)#

N5548-Top(config)# interface vfc 1032

N5548-Top(config-if)# switchport mode F

N5548-Top(config-if)# bind interface port-channel 201

N5548-Top(config-if)# no shut

N5548-Top(config-if)#

4. Create the FCoE VSAN and map it to the VLAN on the switches:

N5548-Bottom(config)# vlan 200

N5548-Bottom(config-vlan)# fcoe vsan 200

N5548-Bottom(config-vlan)#

N5548-Top(config)# vlan 201

N5548-Top(config-vlan)# fcoe vsan 201

N5548-Top(config-vlan)#

5. Configure the VLANs allowed to transverse the vPC links:

N5548-Bottom(config)# interface port-channel 20

N5548-Bottom(config-if)# switchport trunk allowed vlan 1, 200

N5548-Bottom(config-vsan-db)#

N5548-Top(config)# interface port-channel 20

N5548-Top(config-vsan-db)# switchport trunk allowed vlan 1, 201

N5548-Top(config-vsan-db)#

6. Bind the entry in the VSAN database on the switches:

N5548-Bottom(config)#

N5548-Bottom(config)# vsan database

N5548-Bottom(config-vsan-db)# vsan 200

N5548-Bottom(config-vsan-db)# vsan 200 interface vfc1032

N5548-Bottom(config-vsan-db)#

N5548-Top(config)#

N5548-Top(config)# vsan database

N5548-Top(config-vsan-db)# vsan 201

N5548-Top(config-vsan-db)# vsan 201 interface vfc1032

N5548-Top(config-vsan-db)#

Note: The VLAN and VSAN numbers do not have to be the same.

Configure the native fibre channel slot/module

N5548-Bottom(config)# slot 2

N5548-Bottom(config-slot)# port 1-16 type fc

N5548-Bottom(config-slot)# poweroff module 2

N5548-Bottom(config)# no poweroff module 2

Configure the native fibre channel slot/module

N5548-Top(config)# slot 2

N5548-Top(config-slot)# port 1-16 type fc

N5548-Top(config-slot)# poweroff module 2

N5548-Top(config)# no poweroff module 2

7. Configure the Fibre Channel interface port type:

N5548-Bottom(config)# interface fc 1/48

N5548-Bottom(config-if)# switchport mode F

N5548-Bottom(config-if)#

N5548-Top(config)# interface fc 1/48

N5548-Top(config-if)# switchport mode F

N5548-Top(config-if)#

8. Bind the VSAN to the Fibre Channel interface:

N5548-Bottom(config)# vsan database

N5548-Bottom(config-vsan-db)# vsan 200 interface fc 1/48

N5548-Bottom(config-vsan-db)#

N5548-Top(config)# vsan database

N5548-Top(config-vsan-db)# vsan 201 interface fc 1/48

N5548-Top(config-vsan-db)#

9. Create the necessary zone and zone sets with appropriate members:

N5548-Bottom(config)# zoneset name zoneset1 vsan 200

N5548-Bottom(config-zoneset)#zone name zone1

N5548-Bottom(config-zoneset-zone)# member pwwn 50:00:40:20:05:df:43:2c

N5548-Bottom(config-zoneset-zone)# member pwwn 10:00:6c:ae:8b:2c:cb:c1

N5548-Top(config)# zoneset name zoneset1 vsan 201

N5548-Top(config-zoneset)#zone name zone1

N5548-Top(config-zoneset-zone)# member pwwn 50:00:40:21:05:df:43:2c

N5548-Top(config-zoneset-zone)# member pwwn 10:00:6c:ae:8b:2c:cb:c5

Note: Use a relevant display command (for example, show interface or show flogi database) to obtain the required value

in hexadecimal format.

10. Activate the zone sets:

N5548-Bottom(config-zoneset)# zoneset activate name zoneset1 vsan 200

N5548-Top(config-zoneset)# zoneset activate name zoneset2 vsan 201

You can now use the following commands to check the connectivity between the blade server and the Cisco Nexus B22 for IBM:

N5548-Bottom# show flogi database

--------------------------------------------------------------------------------

INTERFACE VSAN FCID PORT NAME NODE NAME

--------------------------------------------------------------------------------

fc1/48 200 0x300000 50:00:40:20:05:df:43:2c 20:05:00:04:02:df:43:2c

vfc1032 200 0x300020 10:00:6c:ae:8b:2c:cb:c1 20:00:6c:ae:8b:2c:cb:c1

vfc1033 200 0x300040 10:00:6c:ae:8b:2c:d8:41 20:00:6c:ae:8b:2c:d8:41

N5548-Bottom#

N5548-Bottom# show fcns database

VSAN 200:

--------------------------------------------------------------------------

FCID TYPE PWWN (VENDOR) FC4-TYPE:FEATURE

--------------------------------------------------------------------------

0x300000 N 50:00:40:20:05:df:43:2c scsi-fcp:target

0x300020 N 10:00:6c:ae:8b:2c:cb:c1

0x300040 N 10:00:6c:ae:8b:2c:d8:41

N5548-Bottom#

You can run these commands on a second Cisco Nexus Switches to verify the fabric. Figure 9 shows a server that has successfully connected to the SAN.

Figure 9: Server with FCoE Connected to Volumes on a Fibre Channel Array

iSCSI Configuration

iSCSI provides an alternative to FCoE for block-level storage. Through the use of the iSCSI type-length-value (TLV) settings, iSCSI TLV-capable NICs/CNAs, and Cisco Nexus 5000/ 6000 Series Switches, configuration can be simplified. The iSCSI TLV settings tell the host which QoS parameters to use, similar to the process for Data Center Bridging Exchange (DCBX) Protocol and FCoE; DCBX negotiates the configuration between the switch and the adapter through a variety of TLV and sub-TLV settings. The TLV settings can be used for traditional TCP and drop-behavior iSCSI networks as well as for complete end-to-end lossless iSCSI fabrics. If you enable Enchanced Transmisson Selection (ETS) and Priority Flow Control (PFC), storage traffic will be separated from other IP traffic, allowing more accurate and error-free configurations to be transmitted from the switch to the adapter.

Follow these steps to configure iSCSI TLV settings on each Cisco Nexus switch:

1. Define a class map for each class of traffic to be used in QoS policies.

2. Use QoS policies to classify the interesting traffic. QoS policies are used to classify the traffic of a specific

system class identified by a unique QoS group value.

3. Configure a no-drop class. If you do not specify this command, the default policy is drop.

4. Attach the created QoS policies to the system.

1. Define a class map of QoS policies on the first switch to identify the iSCSI traffic (here, iSCSI traffic is matched to class-of-service [CoS] 5):

N5548-Bottom(config)# class-map type qos match-all iSCSI-C1

N5548-Bottom(config-cmap-qos)# match protocol iscsi

N5548-Bottom(config-cmap-qos)# match cos 5

2. Configure the type of QoS policies used to classify the traffic of a specific system class (here, the QoS-group value 2 is used):

N5548-Bottom(config)# policy-map type qos iSCSI-C1

N5548-Bottom(config-pmap-qos) class iSCSI-C1

N5548-Bottom(config-pmap-c-qos)# set qos-group 2

N5548-Bottom(config-pmap-c-qos)# exit

N5548-Bottom(config-pmap-c-qos)# class class-default

3. Configure the no-drop policy maps:

N5548-Bottom(config)# class-map type network-qos iSCSI-C1

N5548-Bottom(config-cmap-nq)# match qos-group 2

N5548-Bottom(config-cmap-nq)# exit

N5548-Bottom(config)# policy-map type network-qos iSCSI-C1

N5548-Bottom(config-pmap-nq)# class type network-qos iSCSI-C1

N5548-Bottom(config-pmap-nq-c)# pause no-drop

N5548-Bottom(config-pmap-nq-c)# class type network-qos class-default

N5548-Bottom(config-pmap-nq-c)# mtu 9216

4. Apply the system service policies:

N5548-Bottom(config-sys-qos)# service-policy type qos input iSCSI-C1

N5548-Bottom(config-sys-qos)# service-policy type network-qos iSCSI-C1

5. Identify the iSCSI traffic on the other Cisco Nexus switch using the same process as for the first switch by defining a class map for each class of traffic to be used in the QoS policies:

N5548-Top(config)# class-map type qos match-all iSCSI-C1

N5548-Top(config-cmap-qos)# match protocol iscsi

N5548-Top(config-cmap-qos)# match cos 5

6. Configure the QoS policy type:

N5548-Top(config)# policy-map type qos iSCSI-C1

N5548-Top(config-pmap-qos) class iSCSI-C1

N5548-Top(config-pmap-c-qos)# set qos-group 2

N5548-Top(config-pmap-c-qos)# exit

N5548-Top(config-pmap-c-qos)# class class-default

7. Configure the no-drop policy maps:

N5548-Top(config)# class-map type network-qos iSCSI-C1

N5548-Top(config-cmap-nq)# match qos-group 2

N5548-Top(config-cmap-nq)# exit

N5548-Top(config)# policy-map type network-qos iSCSI-C1

N5548-Top(config-pmap-nq)# class type network-qos iSCSI-C1

N5548-Top(config-pmap-nq-c)# pause no-drop

N5548-Top(config-pmap-nq-c)# class type network-qos class-default

N5548-Top(config-pmap-nq-c)# mtu 9216

8. Apply the system service policies:

N5548-Top(config-sys-qos)# service-policy type qos input iSCSI-C1

N5548-Top(config-sys-qos)# service-policy type network-qos iSCSI-C1

Figure 10 shows how the iSCSI ports appear in VMware ESXi. Two additional storage adapters are created in VMware ESXi.

Figure 10: IBM Flex System X440+10GB Fabric Blade Running VMware ESXi 5.1.0,1065491

The storage array should then be visible as shown in Figure 11.

Figure 11: IBM Flex System X440+10GB Fabric Blade Running VMware ESXi 5.1.0,1065491

Virtual Network Adapter Partitioning

Various IBM adapters can present a single Ethernet link to the server operating system as if it were different physical adapters. This capability allows bare-metal servers and hypervisors to offer multiple NICs and adapters while physically having a pair of high-bandwidth links. This feature provides the flexibility to limit the bandwidth allocated to each virtual adapter without the need for a server administrator to know the network QoS configuration parameters.

To configure the virtual adapter function, follow this procedure:

1. Install the license.

2. Configure the virtual network adapters.

3. Configure the switch interface for the correct VLANs.

1. Install the license:

a. Capture the application-specific integrated circuit (ASIC) ID from the LoM by opening the unified

extensible firmware interface (UEFI) menu and choosing System Settings > Network > Feature on Demand (FoD).

b. Generate the FoD key for the advanced software function. c. Install the key using the IBM Integrated Management Module (IMM) web interface.

d. Verify that the key was successfully installed.

e. Reboot the system.

2. Configure the virtual network adapter:

a. During the boot cycle, press F1 to open the UEFI menu. b. Select the adapter port by opening the UEFI menu and choosing System Settings > Network and

selecting the adapter port.

c. Select the Emulex NIC.

d. Select Advanced Mode option: NIC, iSCSI, or FCoE.

e. Make sure that the multichannel mode is set to Switch Independent and select Controller

Configuration.

f. Select the Configure Bandwidth option.

g. Allocate the minimum and maximum bandwidth.

Note: Function 2 on both physical NICs corresponds to the second vNIC, which can be the iSCSI or FCoE initiator. In this

example, it is the FCoE initiator with 4-Gbps of bandwidth allocated.

h. Select the Configure LPVID option.

3. Configure unique VLANs as necessary for each Ethernet vNIC.

a. This feature works by applying VLAN tags to the traffic egressing the adapter and entering the

network. Thus, for correct operation, the VLAN tags on the physical network port to the adapter must match. Note that a VLAN ID cannot be assigned for the FCoE vNIC.

b. Make sure that the VLANs are configured and allowed on the internal and external switch ports as

needed.

c. Configure the network port attached to the server. Use the following configuration as a reference.

interface Ethernet191/1/7

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182,200

spanning-tree port type edge trunk

channel-group 207

interface port-channel207

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182,200

spanning-tree port type edge trunk

Debug Commands

show fex

This command displays the status of the fabric extenders that are powered on and connected.

Cisco Nexus B22 for IBM installed but parent switch not configured:

N5548-Bottom# show fex

FEX FEX FEX FEX

Number Description State Model Serial

------------------------------------------------------------------------

--- -------- Discovered N2K-B22IBM-P FOC1515ZZU4

N5548-Bottom#

Cisco Nexus B22 for IBM loading after parent switch is configured:

N5548-Bottom(config-if)# show fex

FEX FEX FEX FEX

Number Description State Model Serial

------------------------------------------------------------------------

103 FEX0103 Connected N2K-B22IBM-P FOC1515ZZU4

N5548-Bottom(config-if)#

N5548-Bottom#

show fex

FEX FEX FEX FEX Fex

Number Description State Model Serial

------------------------------------------------------------------------

191 FEX0191 Online N2K-B22IBM-P FOC1730R0XQ

192 FEX0192 Online N2K-B22IBM-P FOC1730R0XM

Cisco Nexus B22 for IBM online and ready for use:

N5548-Top# show fex

FEX FEX FEX FEX

Number Description State Model Serial

------------------------------------------------------------------------

104 FEX0104 Online N2K-B22IBM-P FOC1515ZZUU

N5548-Top#

show fex

FEX FEX FEX FEX Fex

Number Description State Model Serial

191 FEX0191 Online N2K-B22IBM-P FOC1730R0XQ

192 FEX0192 Online N2K-B22IBM-P FOC1730R0XM

show fex detail

This command displays the details of the fabric extender module, including the connection blade bay number, rack name, and enclosure information for the blade server chassis.

N5548-Top#

show fex 191 detail

FEX: 191 Description: FEX0191 state: Online

FEX version: 6.0(2)N2(1a) [Switch version: 6.0(2)N2(1a)]

FEX Interim version: 6.0(2)N2(1a.19)

Switch Interim version: 6.0(2)N2(1a.19)

Extender Serial: FOC1730R0XQ

Extender Model: N2K-B22IBM-P, Part No: 73-15000-03

Bay: 1

Machine Type/Model: 8721HC1

Machine Serial Number: 06MVGY8

UUID: 100E 4829 C606 45B1 A8E1 D697 BCCD 2884

Card Id: 211, Mac Addr: f8:4f:57:ce:36:42, Num Macs: 64

Module Sw Gen: 21 [Switch Sw Gen: 21]

post level: complete

Pinning-mode: static Max-links: 1

Fabric port for control traffic: Eth1/17

FCoE Admin: false

FCoE Oper: false

FCoE FEX AA Configured: true

Fabric interface state:

Po191 - Interface Up. State: Active

Eth1/17 - Interface Up. State: Active

Fex Port State Fabric Port

Eth191/1/1 Up Po191

Eth191/1/2 Down Po191

Eth191/1/3 Up Po191

Eth191/1/4 Up Po191

Eth191/1/5 Down Po191

Eth191/1/6 Down Po191

Eth191/1/7 Up Po191

Eth191/1/8 Down Po191

Eth191/1/9 Down Po191

Eth191/1/10 Down Po191

Eth191/1/11 Down Po191

Eth191/1/12 Down Po191

Eth191/1/13 Down Po191

Eth191/1/14 Up Po191

Logs:

09/25/2013 11:09:20.990637: Module register received

09/25/2013 11:09:20.993278: Registration response sent

09/25/2013 11:09:21.98103: create module inserted event.

09/25/2013 11:09:21.99012: Module Online Sequence

09/25/2013 11:09:22.829803: Module Online

show interface brief

This command displays a summary of the interfaces with information including the VLAN, link status, and speed.

N5548-Top# show interface brief

-------------------------------------------------------------------------------

Interface Vsan Admin Admin Status SFP Oper Oper Port

Mode Trunk Mode Speed Channel

Mode (Gbps)

-------------------------------------------------------------------------------

fc1/41 1 auto on sfpAbsent -- -- --

fc1/42 1 auto on sfpAbsent -- -- --

fc1/43 1 auto on sfpAbsent -- -- --

fc1/44 1 auto on sfpAbsent -- -- --

fc1/45 1 auto on sfpAbsent -- -- --

fc1/46 1 auto on sfpAbsent -- -- --

fc1/47 1 auto on down swl -- --

fc1/48 201 F on up swl F 8 --

--------------------------------------------------------------------------------

Ethernet VLAN Type Mode Status Reason Speed Port

Interface Ch #

--------------------------------------------------------------------------------

Eth1/1 1 eth fabric up none 10G(D) --

Eth1/2 1 eth fabric up none 10G(D) --

Eth1/3 1 eth access down SFP not inserted 10G(D) --

Eth1/4 1 eth access down SFP not inserted 10G(D) --

Eth1/5 1 eth fabric up none 10G(D) 61

Eth1/6 1 eth fabric up none 10G(D) 61

Eth1/7 182 eth access up none 1000(D) --

Eth1/8 182 eth access up none 1000(D) --

Eth1/9 1 eth trunk up none 10G(D) 20

Eth1/10 1 eth trunk down SFP not inserted 10G(D) 20

Eth1/11 1 eth access down SFP not inserted 10G(D) --

Eth1/12 1 eth access down SFP not inserted 10G(D) --

Eth1/13 1 eth access down SFP not inserted 10G(D) --

Eth1/14 1 eth access down SFP not inserted 10G(D) --

Eth1/15 1 eth access down SFP not inserted 10G(D) --

Eth1/16 1 eth access down SFP not inserted 10G(D) --

Eth1/17 1 eth fabric up none 10G(D) 191

Eth1/18 1 eth fabric up none 10G(D) 192

Eth1/19 1 eth fabric up none 10G(D) 193

Eth1/20 1 eth fabric up none 10G(D) 194

Eth1/21 1 eth access down SFP not inserted 10G(D) --

Eth1/22 1 eth access down SFP not inserted 10G(D) --

Eth1/23 1 eth access down SFP not inserted 10G(D) --

Eth1/24 1 eth access down SFP not inserted 10G(D) --

Eth1/25 1 eth access down SFP not inserted 10G(D) --

Eth1/26 1 eth access down SFP not inserted 10G(D) --

Eth1/27 1 eth access down SFP not inserted 10G(D) --

Eth1/28 1 eth access down SFP not inserted 10G(D) --

Eth1/29 1 eth access down SFP not inserted 10G(D) --

Eth1/30 1 eth access down SFP not inserted 10G(D) --

Eth1/31 1 eth access down SFP not inserted 10G(D) --

Eth1/32 1 eth access down SFP not inserted 10G(D) --

Eth1/33 1 eth access down SFP not inserted 10G(D) --

Eth1/34 1 eth access down SFP not inserted 10G(D) --

Eth1/35 1 eth access down SFP not inserted 10G(D) --

Eth1/36 1 eth access down SFP not inserted 10G(D) --

Eth1/37 1 eth access down SFP not inserted 10G(D) --

Eth1/38 1 eth access down SFP not inserted 10G(D) --

Eth1/39 1 eth access down SFP not inserted 10G(D) --

Eth1/40 1 eth access down SFP not inserted 10G(D) --

Eth2/1 1 eth access down SFP not inserted 10G(D) --

Eth2/2 1 eth access down SFP not inserted 10G(D) --

Eth2/3 1 eth access down SFP not inserted 10G(D) --

Eth2/4 1 eth access down SFP not inserted 10G(D) --

Eth2/5 1 eth access down SFP not inserted 10G(D) --

Eth2/6 1 eth access down SFP not inserted 10G(D) --

Eth2/7 1 eth access down SFP not inserted 10G(D) --

Eth2/8 1 eth access down SFP not inserted 10G(D) --

Eth2/9 1 eth access down SFP not inserted 10G(D) --

Eth2/10 1 eth access down SFP not inserted 10G(D) --

Eth2/11 1 eth access down SFP not inserted 10G(D) --

Eth2/12 1 eth access down SFP not inserted 10G(D) --

Eth2/13 1 eth access down SFP not inserted 10G(D) --

Eth2/14 1 eth access down SFP not inserted 10G(D) --

Eth2/15 1 eth access down SFP not inserted 10G(D) --

Eth2/16 1 eth access down SFP not inserted 10G(D) --

--------------------------------------------------------------------------------

Port-channel VLAN Type Mode Status Reason Speed Protocol

Interface

--------------------------------------------------------------------------------

Po10 1 eth trunk down No operational members auto(I) lacp

Po20 1 eth trunk up none a-10G(D) none

Po61 1 eth fabric up none a-10G(D) none

Po191 1 eth fabric up none a-10G(D) none

Po192 1 eth fabric up none a-10G(D) none

Po193 1 eth fabric up none a-10G(D) none

Po194 1 eth fabric up none a-10G(D) none

Po201 182 eth access up none a-10G(D) none

Po202 182 eth access up none a-10G(D) none

Po203 182 eth access up none a-10G(D) none

Po207 182 eth trunk up none a-10G(D) none

Po214 182 eth access up none a-10G(D) none

Po215 182 eth trunk up none a-10G(D) none

--------------------------------------------------------------------------------

Port VRF Status IP Address Speed MTU

--------------------------------------------------------------------------------

mgmt0 -- up 172.25.182.109 1000 1500

-------------------------------------------------------------------------------

Interface Vsan Admin Admin Status Bind Oper Oper

Mode Trunk Info Mode Speed

Mode (Gbps)

-------------------------------------------------------------------------------

vfc1032 201 F on trunking Eth192/1/7 TF auto

vfc1033 201 F on trunking Eth192/1/14 TF auto

-------------------------------------------------------------------------------

Interface Secondary VLAN(Type) Status Reason

-------------------------------------------------------------------------------

Vlan1 -- down Administratively down

Vlan50 -- up --

--------------------------------------------------------------------------------

Ethernet VLAN Type Mode Status Reason Speed Port

Interface Ch #

--------------------------------------------------------------------------------

Eth160/1/1 1 eth access up none 10G(D) --

Eth160/1/2 1 eth access down Link not connected auto(D) --

Eth160/1/3 1 eth access down Link not connected auto(D) --

Eth160/1/4 1 eth access down Link not connected auto(D) --

Eth160/1/5 1 eth access down Link not connected auto(D) --

Eth160/1/6 1 eth access down Link not connected auto(D) --

Eth160/1/7 1 eth access down Link not connected auto(D) --

Eth160/1/8 1 eth access down Link not connected auto(D) --

Eth160/1/9 1 eth access down Link not connected auto(D) --

Eth160/1/10 1 eth access down Link not connected auto(D) --

Eth160/1/11 1 eth access down Link not connected auto(D) --

Eth160/1/12 1 eth access down Link not connected auto(D) --

Eth160/1/13 1 eth access down Link not connected auto(D) --

Eth160/1/14 1 eth access down Link not connected auto(D) --

Eth160/1/15 1 eth access down Link not connected auto(D) --

Eth160/1/16 1 eth access down Link not connected auto(D) --

Eth161/1/1 1 eth access up none 10G(D) --

Eth161/1/2 1 eth access up none 1000(D) --

Eth161/1/3 1 eth access down Link not connected auto(D) --

Eth161/1/4 1 eth access down Link not connected auto(D) --

Eth161/1/5 1 eth access up none 1000(D) --

Eth161/1/6 1 eth access up none 10G(D) --

Eth161/1/7 1 eth access down Link not connected auto(D) --

Eth161/1/8 1 eth access down Link not connected auto(D) --

Eth161/1/9 1 eth access down Link not connected auto(D) --

Eth161/1/10 1 eth access down Link not connected auto(D) --

Eth161/1/11 1 eth access down Link not connected auto(D) --

Eth161/1/12 1 eth access down Link not connected auto(D) --

Eth161/1/13 1 eth access up none 1000(D) --

Eth161/1/14 1 eth access up none 10G(D) --

Eth161/1/15 1 eth access down Link not connected auto(D) --

Eth161/1/16 1 eth access down Link not connected auto(D) --

Eth191/1/1 182 eth access up none 10G(D) 201

Eth191/1/2 1 eth access down Link not connected auto(D) --

Eth191/1/3 182 eth access up none 10G(D) 203

Eth191/1/4 182 eth access up none 10G(D) 202

Eth191/1/5 1 eth access down Link not connected auto(D) --

Eth191/1/6 1 eth access down Link not connected auto(D) --

Eth191/1/7 182 eth trunk up none 10G(D) 207

Eth191/1/8 1 eth access down Link not connected auto(D) --

Eth191/1/9 1 eth access down Link not connected auto(D) --

Eth191/1/10 1 eth access down Link not connected auto(D) --

Eth191/1/11 1 eth access down Link not connected auto(D) --

Eth191/1/12 1 eth access down Link not connected auto(D) --

Eth191/1/13 1 eth access down Link not connected auto(D) --

Eth191/1/14 182 eth access up none 10G(D) 214

Eth192/1/1 182 eth access up none 10G(D) --

Eth192/1/2 1 eth access down Link not connected auto(D) --

Eth192/1/3 182 eth access up none 10G(D) 203

Eth192/1/4 182 eth access up none 10G(D) --

Eth192/1/5 1 eth access down Link not connected auto(D) --

Eth192/1/6 1 eth access down Link not connected auto(D) --

Eth192/1/7 182 eth trunk up none 10G(D) 207

Eth192/1/8 1 eth access down Link not connected auto(D) --

Eth192/1/9 1 eth access down Link not connected auto(D) --

Eth192/1/10 1 eth access down Link not connected auto(D) --

Eth192/1/11 1 eth access down Link not connected auto(D) --

Eth192/1/12 1 eth access down Link not connected auto(D) --

Eth192/1/13 1 eth access down Link not connected auto(D) --

Eth192/1/14 182 eth trunk up none 10G(D) 215

Eth193/1/1 1 eth access down Link not connected auto(D) --

Eth193/1/2 1 eth access up none 10G(D) --

Eth193/1/3 1 eth access down Link not connected auto(D) --

Eth193/1/4 1 eth access down Link not connected auto(D) --

Eth193/1/5 1 eth access down Link not connected auto(D) --

Eth193/1/6 1 eth access down Link not connected auto(D) --

Eth193/1/7 1 eth access down Link not connected auto(D) --

Eth193/1/8 1 eth access down Link not connected auto(D) --

Eth193/1/9 1 eth access down Link not connected auto(D) --

Eth193/1/10 1 eth access down Link not connected auto(D) --

Eth193/1/11 1 eth access down Link not connected auto(D) --

Eth193/1/12 1 eth access down Link not connected auto(D) --

Eth193/1/13 1 eth access down Link not connected auto(D) --

Eth193/1/14 1 eth access down Link not connected auto(D) --

Eth194/1/1 1 eth access down Link not connected auto(D) --

Eth194/1/2 1 eth access up none 10G(D) --

Eth194/1/3 1 eth access down Link not connected auto(D) --

Eth194/1/4 1 eth access down Link not connected auto(D) --

Eth194/1/5 1 eth access down Link not connected auto(D) --

Eth194/1/6 1 eth access down Link not connected auto(D) --

Eth194/1/7 1 eth access down Link not connected auto(D) --

Eth194/1/8 1 eth access down Link not connected auto(D) --

Eth194/1/9 1 eth access down Link not connected auto(D) --

Eth194/1/10 1 eth access down Link not connected auto(D) --

Eth194/1/11 1 eth access down Link not connected auto(D) --

Eth194/1/12 1 eth access down Link not connected auto(D) --

Eth194/1/13 1 eth access down Link not connected auto(D) --

Eth194/1/14 1 eth access down Link not connected auto(D) --

show interface ethernet 191/1/1

This command displays detailed statistics for Cisco Nexus B22 for IBM fabric extender port 1.

N5548-Bottom# show interface ethernet 191/1/1

Ethernet191/1/1 is up

Belongs to Po201

Hardware: 1000/10000 Ethernet, address: f84f.57ce.3642 (bia f84f.57ce.3642)

MTU 1500 bytes, BW 10000000 Kbit, DLY 10 usec

reliability 255/255, txload 1/255, rxload 1/255

Encapsulation ARPA

Port mode is access

full-duplex, 10 Gb/s

Beacon is turned off

Input flow-control is off, output flow-control is on

Switchport monitor is off

EtherType is 0x8100

Last link flapped 19:40:49

Last clearing of "show interface" counters never

12 interface resets

30 seconds input rate 40 bits/sec, 0 packets/sec

30 seconds output rate 2592 bits/sec, 4 packets/sec

Load-Interval #2: 5 minute (300 seconds)

input rate 152 bps, 0 pps; output rate 3.31 Kbps, 4 pps

RX

1414070 unicast packets 6375 multicast packets 11769 broadcast packets

1432214 input packets 108330909 bytes

0 jumbo packets 0 storm suppression bytes

0 runts 0 giants 0 CRC 0 no buffer

0 input error 0 short frame 0 overrun 0 underrun 0 ignored

0 watchdog 0 bad etype drop 0 bad proto drop 0 if down drop

0 input with dribble 0 input discard

0 Rx pause

TX

3062593 unicast packets 87916 multicast packets 318028 broadcast packets

3468537 output packets 4619474058 bytes

0 jumbo packets

0 output error 0 collision 0 deferred 0 late collision

0 lost carrier 0 no carrier 0 babble 0 output discard

0 Tx pause

show vlan

This command displays the VLAN and the ports associated with the VLAN.

N5548-Bottom(config-if)# show vlan

N5548-Bottom(config-if)#

N5548-Bottom# show vlan

VLAN Name Status Ports

---- -------------------------------- --------- -------------------------------

1 default active Po20, Eth1/2, Eth1/3, Eth1/4

Eth1/5, Eth1/6, Eth1/9, Eth1/10

Eth1/11, Eth1/12, Eth1/13

Eth1/14, Eth1/15, Eth1/16

Eth1/21, Eth1/22, Eth1/23

Eth1/24, Eth1/25, Eth1/26

Eth1/27, Eth1/28, Eth1/29

Eth1/30, Eth1/31, Eth1/32

Eth1/33, Eth1/34, Eth1/35

Eth1/36, Eth1/37, Eth1/38

Eth1/39, Eth1/40, Eth2/1, Eth2/2

Eth2/3, Eth2/4, Eth2/5, Eth2/6

Eth2/7, Eth2/8, Eth2/9, Eth2/10

Eth2/11, Eth2/12, Eth2/13

Eth2/14, Eth2/15, Eth2/16

Eth191/1/2, Eth191/1/5

Eth191/1/6, Eth191/1/8

Eth191/1/9, Eth191/1/10

Eth191/1/11, Eth191/1/12

Eth191/1/13, Eth192/1/2

Eth192/1/5, Eth192/1/6

Eth192/1/8, Eth192/1/9

Eth192/1/10, Eth192/1/11

Eth192/1/12, Eth192/1/13

Eth193/1/1, Eth193/1/2

Eth193/1/3, Eth193/1/4

Eth193/1/5, Eth193/1/6

Eth193/1/7, Eth193/1/8

Eth193/1/9, Eth193/1/10

Eth193/1/11, Eth193/1/12

Eth193/1/13, Eth193/1/14

Eth194/1/1, Eth194/1/2

Eth194/1/3, Eth194/1/4

Eth194/1/5, Eth194/1/6

Eth194/1/7, Eth194/1/8

Eth194/1/9, Eth194/1/10

Eth194/1/11, Eth194/1/12

Eth194/1/13, Eth194/1/14

50 iSCSI-VL50 active Po20, Eth1/9, Eth1/10

77 VLAN0077 active Po20, Eth1/9, Eth1/10

182 MGMT active Po20, Po201, Po202, Po203

Po207, Po214, Po215, Eth1/7

Eth1/8, Eth1/9, Eth1/10

Eth191/1/1, Eth191/1/3

Eth191/1/4, Eth191/1/7

Eth191/1/14, Eth192/1/1

Eth192/1/3, Eth192/1/4

Eth192/1/7, Eth192/1/14

200 FCoE-VL200 active Po20, Po207, Po215, Eth1/9

Eth1/10, Eth191/1/7, Eth192/1/7

Eth192/1/14

VLAN Type Vlan-mode

---- ----- ----------

1 enet CE

50 enet CE

77 enet CE

182 enet CE

200 enet CE

Primary Secondary Type Ports

------- --------- --------------- -------------------------------------------

show interface fex-fabric

This command displays a list of interfaces and their association with fabric extenders.

N5K_Bottom# show interface fex-fabric

N5548-Bottom# show interface fex-fabric

Fabric Fabric Fex FEX Fex

Fex Port Port State Uplink Model Serial

---------------------------------------------------------------

135 Eth1/1 Configured 0

191 Eth1/17 Active 1 N2K-B22IBM-P FOC1730R0XQ

192 Eth1/18 Active 1 N2K-B22IBM-P FOC1730R0XM

193 Eth1/19 Active 1 N2K-B22IBM-P FOC1730R0WU

194 Eth1/20 Active 1 N2K-B22IBM-P FOC1720R0VV

N5596-1-B22#

Cisco Nexus Configurations

Cisco Nexus 5000 Series Switch 1 Configuration

N5548-Bottom(config)# show run

!Command: show running-config

!Time: Mon Oct 14 16:19:18 2013

version 6.0(2)N2(1a)

feature fcoe

hostname N5596-1-B22

feature npiv

feature telnet

cfs eth distribute

feature interface-vlan

feature hsrp

feature lacp

feature vpc

feature lldp

feature fex

username admin password 5 $1$WT0Dr2VE$mLbfY0mjbfBbfc8a1F5en/ role network-admin

no password strength-check

ip domain-lookup

logging event link-status default

class-map type qos match-all iSCSI-C1

match protocol iscsi

match cos 5

policy-map type qos iSCSI-C1

class iSCSI-C1

set qos-group 2

class-map type network-qos iSCSI-C1

match qos-group 2

policy-map type network-qos iSCSI-C1

class type network-qos iSCSI-C1

pause no-drop

class type network-qos class-default

mtu 9216

multicast-optimize

system qos

service-policy type queuing input fcoe-default-in-policy

service-policy type queuing output fcoe-default-out-policy

service-policy type qos input iSCSI-C1

service-policy type network-qos iSCSI-C1

control-plane

service-policy input copp-system-policy-customized

fex 135

pinning max-links 1

description "FEX0135"

fex 191

pinning max-links 1

description "FEX0191"

fcoe

fex 192

pinning max-links 1

description "FEX0192"

fex 193

pinning max-links 1

description "FEX0193"

fcoe

fex 194

pinning max-links 1

description "FEX0194"

fcoe

slot 1

port 41-48 type fc

slot 2

port 1-16 type ethernet

snmp-server user admin network-admin auth md5 0x831c48b6e0670a2b350abe618a78f703 priv 0x831c48b6e

0670a2b350abe618a78f703 localizedkey

snmp-server community public group network-operator

ntp distribute

ntp server 161.44.248.75 use-vrf management

ntp commit

vrf context management

ip route 0.0.0.0/0 172.25.182.1

vlan 1,77

vlan 182

name MGMT

vlan 200

fcoe vsan 200

name FCoE-VL200

spanning-tree vlan 1-3967 priority 4096

vpc domain 5

role priority 1

system-priority 1

peer-keepalive destination 172.25.182.109 source 172.25.182.108

delay restore 150

port-profile default max-ports 512

vsan database

vsan 200 name "VS200"

fcdomain fcid database

vsan 1 wwn 50:00:40:20:05:df:43:2c fcid 0x190000 dynamic

vsan 200 wwn 50:00:40:20:05:df:43:2c fcid 0x300000 dynamic

vsan 200 wwn 10:00:6c:ae:8b:2c:cb:c1 fcid 0x300020 dynamic

vsan 200 wwn 10:00:6c:ae:8b:2c:d8:41 fcid 0x300040 dynamic

interface Vlan1

interface port-channel20

switchport mode trunk

spanning-tree port type network

vpc peer-link

interface port-channel191

switchport mode fex-fabric

fex associate 191

vpc 191

interface port-channel192

switchport mode fex-fabric

fex associate 192

vpc 192

interface port-channel193

switchport mode fex-fabric

fex associate 193

vpc 193

interface port-channel194

switchport mode fex-fabric

fex associate 194

vpc 194

interface port-channel201

switchport mode trunk

switchport trunk allowed vlan 182-184,200

interface port-channel202

switchport access vlan 182

interface port-channel203

switchport access vlan 182

interface port-channel207

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182,200

spanning-tree port type edge trunk

interface port-channel214

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182,200

spanning-tree port type edge trunk

interface port-channel215

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182,200

spanning-tree port type edge trunk

interface vfc1031

bind interface Ethernet191/1/1

switchport trunk allowed vsan 200

no shutdown

interface vfc1037

bind interface Ethernet191/1/7

switchport trunk allowed vsan 200

no shutdown

interface vfc1044

bind interface Ethernet191/1/14

switchport trunk allowed vsan 200

no shutdown

interface vfc1044

vsan database

vsan 200 interface vfc1031

vsan 200 interface vfc1037

vsan 200 interface vfc1044

vsan 200 interface fc1/48

interface fc1/41

interface fc1/42

interface fc1/43

interface fc1/44

interface fc1/45

interface fc1/46

interface fc1/47

interface fc1/48

no shutdown

interface Ethernet1/1

switchport mode fex-fabric

fex associate 135

spanning-tree port type edge

interface Ethernet1/2

interface Ethernet1/3

interface Ethernet1/4

interface Ethernet1/5

interface Ethernet1/6

interface Ethernet1/7

description iscsi-net0-nexsan

switchport access vlan 182

speed 1000

interface Ethernet1/8

switchport access vlan 182

speed 1000

interface Ethernet1/9

switchport mode trunk

channel-group 20

interface Ethernet1/10

switchport mode trunk

channel-group 20

interface Ethernet1/11

interface Ethernet1/12

interface Ethernet1/13

interface Ethernet1/14

interface Ethernet1/15

interface Ethernet1/16

interface Ethernet1/17

interface Ethernet1/18

interface Ethernet1/19

switchport mode fex-fabric

fex associate 193

channel-group 193

interface Ethernet1/20

switchport mode fex-fabric

fex associate 194

channel-group 194

interface Ethernet1/21

switchport mode fex-fabric

fex associate 191

channel-group 191

interface Ethernet1/22

switchport mode fex-fabric

fex associate 191

channel-group 191

interface Ethernet1/23

switchport mode fex-fabric

fex associate 192

channel-group 192

interface Ethernet1/24

switchport mode fex-fabric

fex associate 192

channel-group 192

interface Ethernet1/25

interface Ethernet1/26

interface Ethernet1/27

interface Ethernet1/28

interface Ethernet1/29

interface Ethernet1/30

interface Ethernet1/31

interface Ethernet1/32

interface Ethernet1/33

interface Ethernet1/34

interface Ethernet1/35

interface Ethernet1/36

interface Ethernet1/37

interface Ethernet1/38

interface Ethernet1/39

interface Ethernet1/40

interface Ethernet2/1

interface Ethernet2/2

interface Ethernet2/3

interface Ethernet2/4

interface Ethernet2/5

interface Ethernet2/6

interface Ethernet2/7

interface Ethernet2/8

interface Ethernet2/9

interface Ethernet2/10

interface Ethernet2/11

interface Ethernet2/12

interface Ethernet2/13

interface Ethernet2/14

interface Ethernet2/15

interface Ethernet2/16

interface mgmt0

ip address 172.25.182.108/24

interface Ethernet191/1/1

switchport mode trunk

switchport trunk allowed vlan 182,200

interface Ethernet191/1/2

interface Ethernet191/1/3

switchport access vlan 182

channel-group 203

interface Ethernet191/1/4

switchport access vlan 182

channel-group 202

interface Ethernet191/1/5

interface Ethernet191/1/6

interface Ethernet191/1/7

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182-184,200

channel-group 201 mode active

interface Ethernet191/1/8

interface Ethernet191/1/9

interface Ethernet191/1/10

interface Ethernet191/1/11

interface Ethernet191/1/12

interface Ethernet191/1/13

interface Ethernet191/1/14

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182,200

channel-group 214

interface Ethernet192/1/1

switchport mode trunk

switchport trunk allowed vlan 182,200

interface Ethernet192/1/2

interface Ethernet192/1/3

switchport access vlan 182

channel-group 203

interface Ethernet192/1/4

switchport access vlan 182

interface Ethernet192/1/5

interface Ethernet192/1/6

interface Ethernet192/1/7

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182-184,200

channel-group 201 mode active

interface Ethernet192/1/8

interface Ethernet192/1/9

interface Ethernet192/1/10

interface Ethernet192/1/11

interface Ethernet192/1/12

interface Ethernet192/1/13

interface Ethernet192/1/14

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182,200

interface Ethernet193/1/1

switchport mode trunk

spanning-tree port type edge trunk

channel-group 311

interface Ethernet193/1/2

interface Ethernet193/1/3

interface Ethernet193/1/4

interface Ethernet193/1/5

interface Ethernet193/1/6

interface Ethernet193/1/7

switchport mode trunk

spanning-tree port type edge trunk

channel-group 317

interface Ethernet193/1/8

interface Ethernet193/1/9

interface Ethernet193/1/10

interface Ethernet193/1/11

interface Ethernet193/1/12

interface Ethernet193/1/13

interface Ethernet193/1/14

clock timezone pst -7 0

system default zone default-zone permit

system default zone distribute full

cli alias name wr copy run start

line console

line vty

exec-timeout 1440

boot kickstart bootflash:/n5000-uk9-kickstart.6.0.2.N2.1a.19.bin

boot system bootflash:/n5000-uk9.6.0.2.N2.1a.19.bin

interface fc1/41

interface fc1/42

interface fc1/43

interface fc1/44

interface fc1/45

interface fc1/46

interface fc1/47

interface fc1/48

switchport mode F

zone default-zone permit vsan 200

zoneset distribute full vsan 200

!Full Zone Database Section for vsan 200

zone name zone1 vsan 200

member pwwn 50:00:40:20:05:df:43:2c

member pwwn 10:00:6c:ae:8b:2c:cb:c1

zone name zone2 vsan 200

member pwwn 50:00:40:20:05:df:43:2c

member pwwn 10:00:6c:ae:8b:2c:d8:41

zoneset name zoneset1 vsan 200

member zone1

member zone2

zoneset activate name zoneset1 vsan 200

Cisco Nexus 5000 Series Switch 2 Configuration

N5548-Top(config)# show run

!Command: show running-config

!Time: Mon Oct 14 16:21:29 2013

version 6.0(2)N2(1a)

feature fcoe

hostname N5596-2-B22

feature telnet

cfs eth distribute

feature ospf

feature interface-vlan

feature hsrp

feature lacp

feature vpc

feature lldp

feature fex

username admin password 5 $1$p4Mv/hIx$qEBLcupJS.7vx1a16TB6w1 role network-admin

no password strength-check

ip domain-lookup

logging event link-status default

class-map type qos match-all iSCSI-C1

match protocol iscsi

match cos 5

policy-map type qos iSCSI-C1

class iSCSI-C1

set qos-group 2

class-map type network-qos iSCSI-C1

match qos-group 2

policy-map type network-qos iSCSI-C1

class type network-qos iSCSI-C1

pause no-drop

class type network-qos class-default

mtu 9216

multicast-optimize

system qos

service-policy type queuing input fcoe-default-in-policy

service-policy type queuing output fcoe-default-out-policy

service-policy type qos input iSCSI-C1

service-policy type network-qos iSCSI-C1

control-plane

service-policy input copp-system-policy-customized

fex 160

pinning max-links 2

description "FEX0160"

fex 161

pinning max-links 1

description "FEX0161"

fex 191

pinning max-links 1

description "FEX0191"

fex 192

pinning max-links 1

description "FEX0192"

fcoe

fex 193

pinning max-links 1

description "FEX0193"

fcoe

fex 194

pinning max-links 1

description "FEX0194"

fcoe

fex 196

pinning max-links 1

description "FEX0196"

slot 1

port 41-48 type fc

slot 2

port 1-16 type ethernet

snmp-server user admin network-admin auth md5 0xa497c8207ab2dccb7b56b764f6d34be5 priv 0xa497c8207

ab2dccb7b56b764f6d34be5 localizedkey

snmp-server community public group network-operator

ntp distribute

ntp server 161.44.248.75 use-vrf management

ntp commit

vrf context management

ip route 0.0.0.0/0 172.25.182.1

vlan 1,77

vlan 182

name MGMT

vlan 201

fcoe vsan 201

name FCoE-VL201

spanning-tree vlan 1-3967 priority 8192

vpc domain 5

role priority 2

system-priority 1

peer-keepalive destination 172.25.182.108 source 172.25.182.109

delay restore 150

port-profile default max-ports 512

vsan database

vsan 201 name "VS201"

fcdomain fcid database

vsan 201 wwn 50:00:40:20:05:df:43:2c fcid 0x330000 dynamic

vsan 201 wwn 10:00:6c:ae:8b:2c:cb:c5 fcid 0x330020 dynamic

vsan 201 wwn 50:00:40:21:05:df:43:2c fcid 0x330001 dynamic

vsan 201 wwn 10:00:6c:ae:8b:2c:d8:45 fcid 0x330040 dynamic

interface Vlan1

interface port-channel10

switchport mode trunk

spanning-tree port type network

interface port-channel20

switchport mode trunk

spanning-tree port type network

speed 10000

vpc peer-link

interface port-channel61

switchport mode fex-fabric

fex associate 161

interface port-channel191

switchport mode fex-fabric

fex associate 191

vpc 191

interface port-channel192

switchport mode fex-fabric

fex associate 192

vpc 192

interface port-channel193

switchport mode fex-fabric

fex associate 193

vpc 193

interface port-channel194

switchport mode fex-fabric

fex associate 194

vpc 194

interface port-channel201

switchport mode trunk

switchport trunk allowed vlan 182-184,201

interface port-channel202

switchport access vlan 182

interface port-channel203

switchport access vlan 182

interface port-channel207

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182,201

spanning-tree port type edge trunk

interface port-channel214

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182,201

spanning-tree port type edge trunk

interface port-channel215

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182,201

spanning-tree port type edge trunk

interface port-channel311

switchport mode trunk

interface port-channel317

switchport mode trunk

inteface vfc1031

bind interface ethernet 192/1/1

switchport allowed vsan 201

no shutdown

interface vfc1037

bind interface Ethernet192/1/7

switchport trunk allowed vsan 201

no shutdown

interface vfc1044

bind interface Ethernet192/1/14

switchport trunk allowed vsan 201

no shutdown

vsan database

vsan 201 interface vfc1031

vsan 201 interface vfc1037

vsan 201 interface vfc1044

vsan 201 interface fc1/48

interface fc1/41

interface fc1/42

interface fc1/43

interface fc1/44

interface fc1/45

interface fc1/46

interface fc1/47

interface fc1/48

no shutdown

interface Ethernet1/1

switchport mode fex-fabric

fex associate 160

interface Ethernet1/2

switchport mode fex-fabric

fex associate 160

interface Ethernet1/3

interface Ethernet1/4

interface Ethernet1/5

switchport mode fex-fabric

fex associate 161

channel-group 61

interface Ethernet1/6

switchport mode fex-fabric

fex associate 161

channel-group 61

interface Ethernet1/7

description iscsi-net1-nexsan

switchport access vlan 182

speed 1000

interface Ethernet1/8

switchport access vlan 182

speed 1000

interface Ethernet1/9

switchport mode trunk

channel-group 20

interface Ethernet1/10

switchport mode trunk

channel-group 20

interface Ethernet1/11

interface Ethernet1/12

interface Ethernet1/13

interface Ethernet1/14

interface Ethernet1/15

interface Ethernet1/16

interface Ethernet1/17

interface Ethernet1/18

interface Ethernet1/19

switchport mode fex-fabric

fex associate 193

channel-group 193

interface Ethernet1/20

switchport mode fex-fabric

fex associate 194

channel-group 194

interface Ethernet1/21

switchport mode fex-fabric

fex associate 191

channel-group 191

interface Ethernet1/22

switchport mode fex-fabric

fex associate 191

channel-group 191

interface Ethernet1/23

switchport mode fex-fabric

fex associate 192

channel-group 192

interface Ethernet1/24

switchport mode fex-fabric

fex associate 192

channel-group 192

interface Ethernet1/25

switchport mode fex-fabric

fex associate 196

interface Ethernet1/26

switchport mode fex-fabric

fex associate 196

interface Ethernet1/27

switchport mode fex-fabric

fex associate 196

interface Ethernet1/28

switchport mode fex-fabric

fex associate 196

interface Ethernet1/29

switchport mode fex-fabric

fex associate 196

interface Ethernet1/30

switchport mode fex-fabric

fex associate 196

interface Ethernet1/31

switchport mode fex-fabric

fex associate 196

interface Ethernet1/32

switchport mode fex-fabric

fex associate 196

interface Ethernet1/33

interface Ethernet1/34

interface Ethernet1/35

interface Ethernet1/36

interface Ethernet1/37

interface Ethernet1/38

interface Ethernet1/39

interface Ethernet1/40

interface Ethernet2/1

interface Ethernet2/2

interface Ethernet2/3

interface Ethernet2/4

interface Ethernet2/5

interface Ethernet2/6

interface Ethernet2/7

interface Ethernet2/8

interface Ethernet2/9

interface Ethernet2/10

interface Ethernet2/11

interface Ethernet2/12

interface Ethernet2/13

interface Ethernet2/14

interface Ethernet2/15

interface Ethernet2/16

interface mgmt0

ip address 172.25.182.109/24

interface Ethernet160/1/1

interface Ethernet160/1/2

interface Ethernet160/1/3

interface Ethernet160/1/4

interface Ethernet160/1/5

interface Ethernet160/1/6

interface Ethernet160/1/7

interface Ethernet160/1/8

interface Ethernet160/1/9

interface Ethernet160/1/10

interface Ethernet160/1/11

interface Ethernet160/1/12

interface Ethernet160/1/13

interface Ethernet160/1/14

interface Ethernet160/1/15

interface Ethernet160/1/16

interface Ethernet161/1/1

interface Ethernet161/1/2

interface Ethernet161/1/3

interface Ethernet161/1/4

interface Ethernet161/1/5

interface Ethernet161/1/6

interface Ethernet161/1/7

interface Ethernet161/1/8

interface Ethernet161/1/9

interface Ethernet161/1/10

interface Ethernet161/1/11

interface Ethernet161/1/12

interface Ethernet161/1/13

interface Ethernet161/1/14

interface Ethernet161/1/15

interface Ethernet161/1/16

interface Ethernet191/1/1

switchport access vlan 182

switchport trunk allowed vlan 182-184,201

interface Ethernet191/1/2

interface Ethernet191/1/3

switchport access vlan 182

channel-group 203

interface Ethernet191/1/4

switchport access vlan 182

channel-group 202

interface Ethernet191/1/5

interface Ethernet191/1/6

interface Ethernet191/1/7

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182-184,201

channel-group 201 mode active

interface Ethernet191/1/8

interface Ethernet191/1/9

interface Ethernet191/1/10

interface Ethernet191/1/11

interface Ethernet191/1/12

interface Ethernet191/1/13

interface Ethernet191/1/14

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182,201

channel-group 214

interface Ethernet192/1/1

switchport mode trunk

switchport trunk allowed vlan 182,201

interface Ethernet192/1/2

interface Ethernet192/1/3

switchport access vlan 182

channel-group 203

interface Ethernet192/1/4

switchport access vlan 182

interface Ethernet192/1/5

interface Ethernet192/1/6

interface Ethernet192/1/7

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182-184,201

channel-group 201 mode active

interface Ethernet192/1/8

interface Ethernet192/1/9

interface Ethernet192/1/10

interface Ethernet192/1/11

interface Ethernet192/1/12

interface Ethernet192/1/13

interface Ethernet192/1/14

switchport mode trunk

switchport trunk native vlan 182

switchport trunk allowed vlan 182,201

interface Ethernet193/1/1

switchport mode trunk

spanning-tree port type edge trunk

channel-group 311

interface Ethernet193/1/2

interface Ethernet193/1/3

interface Ethernet193/1/4

interface Ethernet193/1/5

interface Ethernet193/1/6

interface Ethernet193/1/7

switchport mode trunk

spanning-tree port type edge trunk

channel-group 317

interface Ethernet193/1/8

interface Ethernet193/1/9

interface Ethernet193/1/10

interface Ethernet193/1/11

interface Ethernet193/1/12

interface Ethernet193/1/13

interface Ethernet193/1/14

interface Ethernet196/1/1

interface Ethernet196/1/2

interface Ethernet196/1/3

interface Ethernet196/1/4

interface Ethernet196/1/5

interface Ethernet196/1/6

interface Ethernet196/1/7

interface Ethernet196/1/8

interface Ethernet196/1/9

interface Ethernet196/1/10

interface Ethernet196/1/11

interface Ethernet196/1/12

interface Ethernet196/1/13

interface Ethernet196/1/14

clock timezone pst -7 0

system default zone default-zone permit

system default zone distribute full

cli alias name wr copy run start

line console

line vty

exec-timeout 1440

boot kickstart bootflash:/n5000-uk9-kickstart.6.0.2.N2.1a.19.bin

boot system bootflash:/n5000-uk9.6.0.2.N2.1a.19.bin

interface fc1/41

interface fc1/42

interface fc1/43

interface fc1/44

interface fc1/45

interface fc1/46

interface fc1/47

interface fc1/48

switchport mode F

zone default-zone permit vsan 201

zoneset distribute full vsan 201

!Full Zone Database Section for vsan 201

zone name zone1 vsan 201

member pwwn 50:00:40:21:05:df:43:2c

member pwwn 10:00:6c:ae:8b:2c:cb:c5

zone name zone2 vsan 201

member pwwn 50:00:40:21:05:df:43:2c

member pwwn 10:00:6c:ae:8b:2c:d8:45

zoneset name zoneset1 vsan 201

member zone1

member zone2

zoneset activate name zoneset1 vsan 201

© 2014 Cisco and/or its affiliates. All rights reserved. Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (1110R)

IBM, IBM Flex System, and PureFlex are trademarks of International Business Machines Corp., registered in many jurisdictions worldwide. Other product and service names might be trademarks of IBM or other companies.

A current list of IBM trademarks is available on the web at http://www.ibm.com/legal/us/en/copytrade.shtml.

C07-730422-00 02/14

Conclusion

The advent of Cisco Nexus 2000 Series Fabric Extenders has enabled customers to benefit from both top-of-rack (ToR) and end-of-row (EoR) designs. This technology achieves these benefits while reducing the costs associated with cabling and cooling in EoR models and without introducing any additional management points, in contrast to traditional ToR designs. This unique architecture has been tremendously successful in the first generation of Cisco Nexus fabric extenders and rack-mount servers.

The Cisco Nexus B22 for IBM Blade Fabric Extender brings these innovations to third-party blade server chassis and offers unified fabric with FCoE deployments for blade server chassis. This solution brings Cisco networking innovations to the server access layer from rack-mount servers using Cisco Nexus 2000 Series Fabric Extenders into third-party blade chassis.

For More Information

 Cisco NX-OS operations guide for Cisco Nexus 5000 Series Switches:

http://www.cisco.com/en/US/docs/switches/datacenter/nexus5000/sw/operations/n5k_ops_guide.html

 Fabric extender configuration (Cisco NX-OS 6.x):

http://www.cisco.com/en/US/docs/switches/datacenter/nexus6000/sw/layer2/6x/b_6k_Layer2_Config_6x. html

 SAN Switching Configuration Guide (Cisco NX-OS 6.x):

http://www.cisco.com/en/US/docs/switches/datacenter/nexus6000/sw/san_switching/6x/b_6k_SAN_Switc hing_Config_6x.html

 Nexus B22 Blade Fabric Extender Datasheet:

http://www.cisco.com/en/US/products/ps11975/index.html

Cisco Nexus B22 Design And Deployment Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
