Cisco NCS 540 Series Routers, NCS 5500 Series Command Reference Manual

Download

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

First Published: 2015-12-23

Last Modified: 2018-08-01

Americas Headquarters

Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 USA http://www.cisco.com Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.

THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.

The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB's public domain version of the UNIX operating system. All rights reserved. Copyright©1981, Regents of the University of California.

NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS" WITH ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE.

IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Any Internet Protocol (IP) addresses and phone numbers used in this document are not intended to be actual addresses and phone numbers. Any examples, command display output, network topology diagrams, and other figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses or phone numbers in illustrative content is unintentional and coincidental.

All printed copies and duplicate soft copies of this document are considered uncontrolled. See the current online version for the latest version.

Cisco has more than 200 offices worldwide. Addresses and phone numbers are listed on the Cisco website at www.cisco.com/go/offices.

Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com

go trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any

other company. (1721R)

CONTENTS

PREFACE

CHAPTER 1

Preface v

Changes to This Document v

Obtaining Documentation and Submitting a Service Request v

QoS Classification Commands 1

class (policy-map) 2

class-map 4

end-class-map 6

end-policy-map 7

hw-module profile qos ingress-model peering 8

hw-module profile qos max-classmap-size 9

hw-module profile stats qos-enhanced 10

match access-group 11

match cos 13

match dei 15

match dscp 16

match mpls experimental topmost 19

match precedence 21

match protocol 23

match qos-group 25

random-detect discard-class 27

set cos 29

set dei 30

set discard-class 31

set dscp 33

set mpls experimental 34

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

iii

Contents

set precedence 35

set qos-group 37

shape average 39

CHAPTER 2

CHAPTER 3

Congestion Management Commands 41

decapsulate gre 42

police rate 43

policy-map 45

priority (QoS) 47

vrf-policy 48

show qos interface 49

show policy-map interface 55

show policy-map targets 60

show policy-map type pbr 62

Congestion Avoidance Commands 63

bandwidth (QoS) 64

bandwidth remaining 66

queue-limit 68

random-detect 71

CHAPTER 4

service-policy (interface) 73

Hierarchical Modular QoS Commands 75

hw-module profile qos hqos-enable 76

hw-module profile qos max-trunks (hw-module profile bundle-scale) 77

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Preface

This preface contains these sections:

• Changes to This Document, on page v

• Obtaining Documentation and Submitting a Service Request, on page v

Changes to This Document

This table lists the technical changes made to this document since it was first released.

Table 1: Changes to This Document

SummaryDate

Initial release of this document.December 2015

July 2016

November 2016

May 2017

Republished with documentation updates for Cisco IOS XR Release 6.0.2 features.

Republished with documentation updates for Cisco IOS XR Release 6.1.x features

Republished with documentation updates for Cisco IOS XR Release 6.1.31 features

Republished for Release 6.3.2.March 2018

Republished for Release 6.5.1.July 2018

Obtaining Documentation and Submitting a Service Request

For information on obtaining documentation, using the Cisco Bug Search Tool (BST), submitting a service request, and gathering additional information, see What's New in Cisco Product Documentation.

To receive new and revised Cisco technical content directly to your desktop, you can subscribe to the What's

New in Cisco Product Documentation RSS feed. RSS feeds are a free service.

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Obtaining Documentation and Submitting a Service Request

Preface

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

Note

All commands applicable for the Cisco NCS 5500 Series Router are also supported on the Cisco NCS 540 Series Router that is introduced from Cisco IOS XR Release 6.3.2. References to earlier releases in Command History tables apply to only the Cisco NCS 5500 Series Router.

This chapter describes the commands used for QoS packet classification.

• class (policy-map), on page 2

• class-map, on page 4

• end-class-map, on page 6

• end-policy-map, on page 7

• hw-module profile qos ingress-model peering, on page 8

• hw-module profile qos max-classmap-size, on page 9

• hw-module profile stats qos-enhanced, on page 10

• match access-group, on page 11

• match cos, on page 13

• match dei, on page 15

• match dscp, on page 16

• match mpls experimental topmost, on page 19

• match precedence, on page 21

• match protocol, on page 23

• match qos-group, on page 25

• random-detect discard-class, on page 27

• set cos , on page 29

• set dei, on page 30

• set discard-class, on page 31

• set dscp, on page 33

• set mpls experimental, on page 34

• set precedence, on page 35

• set qos-group, on page 37

• shape average, on page 39

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

class (policy-map)

To specify the name of the class whose policy you want to create or change, use the class command in policy map configuration mode. To remove a class from the policy map, use the no form of this command.

class [type qos] {class-name|class-default} no class [type qos] {class-name|class-default}

QoS Classification Commands

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

(Optional) Specifies a quality-of-service (QoS) class.type qos

class-name

Name of the class for which you want to configure or modify policy.

Configures the default class.class-default

No class is specified.

Type is QoS when not specified.

Policy map configuration

ModificationRelease

This command was introduced.Release 6.0

Within a policy map, the class (policy-map) command can be used to specify the name of the class whose policy you want to create or change. The policy map must be identified first.

To identify the policy map (and enter the required policy map configuration mode), use the policy-map command before you use the class (policy-map) command. After you specify a policy map, you can configure the policy for new classes or modify the policy for any existing classes in that policy map.

The class name that you specify in the policy map ties the characteristics for that class—that is, its policy—to the class map and its match criteria, as configured using the class-map command.

The class-default keyword is used for configuring default classes. It is a reserved name and cannot be used with user-defined classes. It is always added to the policy map (type qos) even if the class is not configured. For example, the following configuration shows that the class has not been configured, but the running configuration shows ‘class class-default’.

RP/0/RP0/CPU0:router(config)# class-map p2 RP/0/RP0/CPU0:router(config-cmap)# match precedence 2 RP/0/RP0/CPU0:router(config-cmap)# end-class-map RP/0/RP0/CPU0:router(config)# commit

RP/0/RP0/CPU0:router(config)# policy-map pm2 RP/0/RP0/CPU0:router(config-pmap)# class p2 RP/0/RP0/CPU0:router(config-pmap-c)# set precedence 3 RP/0/RP0/CPU0:router(config-pmap-c)# end-policy-map RP/0/RP0/CPU0:router(config)# commit RP/0/RP0/CPU0:router(config)# end

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

RP/0/RP0/CPU0:router# show run policy-map pm2 policy-map pm2 class p2 set precedence 3 ! class class-default ! end-policy-map !

class (policy-map)

Task ID

Examples

OperationsTask

qos

read, write

This example shows how to create a policy map called policy1, which is defined to shape class1 traffic at 30 percent and default class traffic at 20 percent.

RP/0/RP0/CPU0:router(config)# class-map class1 RP/0/RP0/CPU0:router(config-cmap)# match precedence 3 RP/0/RP0/CPU0:router(config-cmap)# exit

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:routerconfig-pmap-c)# shape average percent 30 RP/0/RP0/CPU0:router(config-pmap-c)# exit

RP/0/RP0/CPU0:router(config-pmap)# class class-default RP/0/RP0/CPU0:router(config-pmap-c)# shape average percent 20

The default class is used for packets that do not satisfy configured match criteria for class1. Class1 must be defined before it can be used in policy1, but the default class can be directly used in a policy map, as the system defines it implicitly.

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

class-map

QoS Classification Commands

To define a traffic class and the associated rules that match packets to the class, use the class-map command in XR Config mode. To remove an existing class map from the router, use the no form of this command.

class-map [type [traffic | qos]] [match-all] [match-any] class-map-name no class-map [type [traffic | qos]] [match-all] [match-any] class-map-name

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

(Optional) Specifies a quality-of-service (QoS) class-map.type qos

(Optional) Specifies traffic type class-map.traffic

(Optional) Specifies a match on all of the match criteria.match-all

(Optional) Specifies a match on any of the match criteria. This is the default.match-any

class-map-name

Type is QoS when not specified.

XR Config mode

The class-map command specifies the name of the class for which you want to create or modify class map match criteria. Use of this command enables class map configuration mode in which you can enter any match command to configure the match criteria for this class. Packets arriving on the interface are checked against the match criteria configured for a class map to determine if the packet belongs to that class.

Name of the class for the class map. The class name is used for the class map and to configure policy for the class in the policy map. The class name can be a maximum of 63 characters, must start with an alphanumeric character, and in addition to alphanumeric characters, can contain any of the following characters: . _ @ $ % + | # : ; - =

ModificationRelease

This command was introduced.Release 6.0

These commands can be used in a class map match criteria for the ingress direction:

• match access-group

• match [not] dscp

• match [not] mpls experimental topmost

• match [not] precedence

• match [not] protocol

Task ID

qos

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

OperationsTask

read, write

QoS Classification Commands

class-map

Examples

This example shows how to specify class1 as the name of a class and defines a class map for this class. The packets that match the access list 1 are matched to class class1.

RP/0/RP0/CPU0:router(config)# class-map class1 RP/0/RP0/CPU0:router(config-cmap)# match access-group ipv4 1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

end-class-map

To end the configuration of match criteria for the class and to exit class map configuration mode, use the

end-class-map command in class map configuration mode.

end-class-map

QoS Classification Commands

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

Examples

This command has no keywords or arguments.

No default behavior or values

Class map configuration

ModificationRelease

This command was introduced.Release 6.0

No specific guidelines impact the use of this command.

OperationsTask

qos

read, write

This example shows how to end the class map configuration and exit class map configuration mode:

RP/0/RP0/CPU0:router(config)# class-map class1 RP/0/RP0/CPU0:router(config-cmap)# match access-group ipv4 1 RP/0/RP0/CPU0:router(config-cmap)# end-class-map

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

end-policy-map

To end the configuration of a policy map and to exit policy map configuration mode, use the end-policy-map command in policy map configuration mode.

end-policy-map

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

Examples

This command has no keywords or arguments.

No default behavior or values

Policy map configuration

ModificationRelease

This command was introduced.Release 6.0

No specific guidelines impact the use of this command.

OperationsTask

qos

read, write

This example shows how to end the policy map configuration and exit policy map configuration mode.

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:router(config-pmap-c)# police rate 250 RP/0/RP0/CPU0:router(config-pmap)# end-policy-map

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

hw-module profile qos ingress-model peering

To enable the peering QoS profile feature, use the hw-module profile qos ingress-model peering command in the XR Config mode. To disable this feature, use the no form of this command.

hw-module profile qos ingress-model peering [locationnode-id]

QoS Classification Commands

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

location node-id

Indicates the designated node. The node-id argument is entered in the rack/slot/module notation.

The peering QoS profile feature is disabled by default, unless enabled by this command.

XR Config mode

ModificationRelease

This command was introduced.Release

6.2.1

The router must be reloaded for the hw-module command to be functional.

OperationTask

qos

read, write

The following example shows how to enable the peering QoS profile feature.

RP/0/RP0/CPU0:router#config RP/0/RP0/CPU0:router(config)#hw-module profile qos ingress-model peering RP/0/RP0/CPU0:router(config)#commit RP/0/RP0/CPU0:router# reload

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

hw-module profile qos max-classmap-size

To define the maximum number of class-maps per policy, use the hw-module profile qos max-classmap-size command in the XR Config mode.

hw-module profile qos max-classmap-sizesize

hw-module profile qos max-classmap-size

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

Indicates the maximum number of class-maps permitted per policy. Range is between 4 to 32, in powers

size

of 2.

Default size is 32.

XR Config mode

ModificationRelease

This command was introduced.Release

6.0.0

The router must be reloaded for the hw-module command to be functional.

This command only applies to ingress policies and only 4, 8, 16, or 32 classes per policy-map are supported. Egress policies can support up to 8 classes per policy-map.

OperationTask

qos

read, write

The following example shows how to change the maximum number of class-maps to 16.

RP/0/RP0/CPU0:router#config RP/0/RP0/CPU0:router(config)#hw-module profile qos max-classmap-size 16 RP/0/RP0/CPU0:router(config)#commit RP/0/RP0/CPU0:router# reload

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

hw-module profile stats qos-enhanced

To enable the four counter mode in the system, use the hw-module profile stats qos-enhancedcommand in XR Config mode. To disable this mode, use the no form of the command. In the four counter mode, statistics for conform, violate, and exceed packets are collected in the hardware and displayed using the show policy-map command.

hw-module profile stats qos-enhanced

QoS Classification Commands

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

This command has no keywords or arguments.

The qos-enhanced mode is disabled by default, and therefore only the conform and violate statistics are available in the two counter mode.

XR Config mode

ModificationRelease

This command was introduced.Release

6.2.1

The router must be reloaded for the hw-module command to be functional.

OperationTask

qos

read, write

The following example shows how to enable the four counter mode on the router.

RP/0/RP0/CPU0:router#config RP/0/RP0/CPU0:router(config)#hw-module profile stats qos-enhanced RP/0/RP0/CPU0:router(config)#commit RP/0/RP0/CPU0:router# reload

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

match access-group

To identify a specified access control list (ACL) number as the match criteria for a class map, use the match access-group command in class map configuration mode.

match access-group {ipv4|ipv6} access-group-name

match access-group

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Specifies the name of the IPv4 access group to be matched.ipv4

Specifies the name of the IPv6 access group to be matched.ipv6

access-group-name

By default, if neither IPv6 nor IPv4 is specified as the match criteria for a class map, IPv4 addressing is used.

Class map configuration

For class-based features (such as marking and policing), you define traffic classes based on match criteria, including ACLs and input interfaces. Packets satisfying the match criteria for a class constitute the traffic for that class.

The match access-group command specifies an ACL whose contents are used as the match criteria against which packets are checked to determine if they belong to the class specified by the class map.

The match access-group command is supported only in the ingress direction. The maximum allowed entries: 8

ACL whose contents are used as the match criteria against which packets are checked to determine if they belong to this class.

ModificationRelease

This command was introduced.Release 6.0

Task ID

Examples

To use the match access-group command, you must first enter the class-map command to specify the name of the class whose match criteria you want to establish. You can specify up to eight IPv4 and IPv6 ACLs in a match statement.

QoS classification based on the packet length or TTL (time to live) field in the IPv4 and IPv6 headers is not supported.

When an ACL list is used within a class-map, the deny action of the ACL is ignored and the traffic is classified based on the specified ACL match parameters.

OperationsTask

qos

This example shows how to specify a class map called map1 and configures map1 to be used as the match criteria for this class:

read, write

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

match access-group

QoS Classification Commands

RP/0/RP0/CPU0:router(config)# class-map map1 RP/0/RP0/CPU0:router(config-cmap)# match access-group ipv4 map1 RP/0/RP0/CPU0:router(config-cmap)# match access-group ipv6 map2

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

match cos

To identify specified class of service (CoS) values as a match criteria in a class map, use the match cos command in class map configuration mode. To remove a specified CoS class value from the matching criteria for a class map, use the no form of this command.

match cos {cos-value [cos-value1 ... cos-value7]} no match cos {cos-value [cos-value1 ... cos-value7]}

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

cos-value

Identifier that specifies the exact value from 0 to 7. Up to eight CoS identifiers can be specified to match packets.

No match criteria are specified.

Class map configuration

ModificationRelease

This command was introduced.Release 6.1.2

The match cos command is supported only in the ingress direction.

The match cos command specifies a class of service that is used as the match criteria against which packets are checked to determine if they belong to the class specified by the class map.

To use the match cos command, you must first enter the class-map command to specify the name of the class whose match criteria you want to establish. If you specify more than one match cos command in a class map, the values of subsequent match statements are added to the first match cos command.

OperationsTask

qos

read, write

Examples

This example shows how to configure the service policy called policy-in and attach service policy policy-in to an interface HundredGigE 0/0/0/3. In this example, class map cos146 evaluates all packets of service values of 1, 4, or 6. If the incoming packet has been marked with any of these CoS values, the traffic is policed at 300 mbps.

RP/0/RP0/CPU0:router(config)# class-map cos146 RP/0/RP0/CPU0:router(config-cmap)# match cos 1 4 6 RP/0/RP0/CPU0:router(config-cmap)# exit RP/0/RP0/CPU0:router(config)# policy-map policy-in RP/0/RP0/CPU0:router(config-pmap)# class cos146 RP/0/RP0/CPU0:router(config-pmap-c)# police rate 300 mbps RP/0/RP0/CPU0:router(config-pmap-police)#exit RP/0/RP0/CPU0:router(config-pmap-c)# exit RP/0/RP0/CPU0:router(config-pmap)# exit

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

match cos

QoS Classification Commands

RP/0/RP0/CPU0:router(config)# interface HundredGigE 0/0/0/3 RP/0/RP0/CPU0:router(config-if)# service-policy input policy-in

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

match dei

To specify a drop eligible indicator (DEI) value as a match criteria in a class map, use the match dei command in class map configuration mode. To remove a specified DEI value from the matching criteria for a class map, use the no form of this command.

match dei value no match dei

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

Examples

value

Value of the DEI bit. Can be 0 or 1.

There is no default DEI value; it must be specified.

Class map configuration

ModificationRelease

This command was introduced.Release

6.1.2

The match dei command specifies a DEI value that is used as the match criteria against which packets are checked to determine if they belong to the class specified by the class map.

OperationTask

qos

read, write

In this example, DEI value is specified as the matching criteria in a class map.

RP/0/RP0/CPU0:router(config)# class-map match-any match-dei RP/0/RP0/CPU0:router(config-cmap)# match dei 0 RP/0/RP0/CPU0:router(config-cmap)# exit RP/0/RP0/CPU0:router(config)# policy-map p1 RP/0/RP0/CPU0:router(config-pmap)# class match-dei RP/0/RP0/CPU0:router(config-pmap)# set dei 1 RP/0/RP0/CPU0:router(config-pmap-c)#exit RP/0/RP0/CPU0:router(config)# interface HundredGigE 0/5/0/0.0 l2transport RP/0/RP0/CPU0:router(config-subif)# encapsulation dot1q 1 RP/0/RP0/CPU0:router(config-subif)# rewrite ingress tag push dot1ad 5 symmetric RP/0/RP0/CPU0:router(config-subif)# service-policy input p1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

match dscp

QoS Classification Commands

To identify specific IP differentiated services code point (DSCP) values as match criteria for a class map, use the match dscp command in class map configuration mode. To remove a DSCP value from a class map, use the no form of this command.

match [not] dscp {[{ipv4|ipv6}] dscp-value [dscp-value1 ... dscp-value7] |[min-value - max-value]} no match [not] dscp {[{ipv4| ipv6}] dscp-value [dscp-value1 ... dscp-value7] |[min-value -

max-value]}

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

(Optional) Negates the specified match result.not

(Optional) Specifies the IPv4 DSCP value.ipv4

(Optional) Specifies the IPv6 DSCP value.ipv6

dscp-value

min-value

max-value

Matching on IP Version 4 (IPv4) and IPv6 packets is the default.

Class map configuration

The match dscp command is supported only in the ingress direction. The minimum value is 0 and maximum value is 63. The maximum allowed entries: 64.

IP DSCP value identifier that specifies the exact value or a range of values. Range is 0 - 63. Up to 64 IP DSCP values can be specified to match packets. Reserved keywords can be specified instead of numeric values. Table 2: IP DSCP Reserved Keywords, on page 17 describes the reserved keywords.

Lower limit of DSCP range to match. Value range is 0 - 63.

Upper limit of DSCP range to match. Value range is 0 - 63.

ModificationRelease

This command was introduced.Release 6.0

The match dscp command specifies a DSCP value that is used as the match criteria against which packets are checked to determine if they belong to the class specified by the class map.

To use the match dscp command, you must first enter the class-map command to specify the name of the class whose match criteria you want to establish

The match dscp command examines the higher-order six bits in the type of service (ToS) byte of the IP header. If you specify more than one match dscp command in a class map, the new values are added to the existing statement.

The IP DSCP value is used as a matching criterion only. The value has no mathematical significance. For instance, the IP DSCP value 2 is not greater than 1. The value simply indicates that a packet marked with the IP DSCP value of 2 should be treated differently than a packet marked with an IP DSCP value of 1. The treatment of these marked packets is defined by the user through the setting of policies in policy map class configuration mode.

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

Table 2: IP DSCP Reserved Keywords

match dscp

DSCP Value

Reserved Keyword

default0

AF1110

AF1212

AF1314

AF2118

AF2220

AF2322

AF3126

AF3228

AF3330

AF4134

AF4236

Task ID

qos

AF4338

EF46

CS18

CS216

CS324

CS432

CS540

CS648

CS756

ipv4 dscpipv4

ipv6 dscpipv6

OperationsTask

read, write

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

match dscp

QoS Classification Commands

Examples

This example shows how to configure the service policy called policy1 and attach service policy policy1 to an interface HundredGigE 0/7/0/0 . In this example, class map dscp14 evaluates all packets entering for an IP DSCP value of 14. If the incoming packet has been marked with the IP DSCP value of 14, the packet is queued to the class queue with the bandwidth setting of 1000 mbps.

RP/0/RP0/CPU0:router(config)# class-map dscp14 RP/0/RP0/CPU0:router(config-cmap)# match dscp ipv4 14 RP/0/RP0/CPU0:router(config-cmap)# exit

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class dscp14 RP/0/RP0/CPU0:router(config-pmap-c)#bandwidth 1000 mbps RP/0/RP0/CPU0:router(config-pmap-c)#exit RP/0/RP0/CPU0:router(config-pmap)# exit

RP/0/RP0/CPU0:router(config)# interface HundredGigE 0/7/0/0 RP/0/RP0/CPU0:router(config-if)# service-policy input policy1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

match mpls experimental topmost

To identify specific three-bit experimental (EXP) field values in the topmost Multiprotocol Label Switching (MPLS) label as match criteria for a class map, use the match mpls experimental topmost command in class map configuration mode. To remove experimental field values from the class map match criteria, use the no form of the command.

match [not] mpls experimental topmost exp-value [exp-value1 ...exp-value7] no match [not] mpls experimental topmost exp-value [exp-value1 ...exp-value7]

match mpls experimental topmost

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

notnot

exp-value

No default behavior or values

Class map configuration

The match mpls experimental topmost command is supported only in the ingress direction. The minimum value is 0 and maximum value is 7. The maximum allowed entries: 8.

The match mpls experimental topmost command is used by the class map to identify MPLS experimental values matching on a packet.

To use the match mpls experimental topmost command, you must first enter the class-map command to specify the name of the class whose match criteria you want to establish. If you specify more than one match mpls experimental topmost command in a class map, the new values are added to the existing match statement.

This command examines the three experimental bits contained in the topmost label of an MPLS packet. Up to eight experimental values can be matched in one match statement. For example, match mpls experimental topmost 2 4 5 7 returns matches for experimental values of 2, 4, 5, and 7. Only one of the four values is needed to yield a match (OR operation).

Experimental value that specifies the exact value from 0 to 7. Up to eight experimental values can be specified to match MPLS headers.

ModificationRelease

This command was introduced.Release 6.0

The experimental values are used as a matching criterion only. The value has no mathematical significance. For instance, the experimental value 2 is not greater than 1. The value indicates that a packet marked with the experimental value of 2 should be treated differently than a packet marked with the EXP value of 1. The treatment of these different packets is defined by the user through the setting of QoS policies in policy map class configuration mode.

Task ID

qos

OperationsTask

read, write

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

match mpls experimental topmost

QoS Classification Commands

Examples

This example shows how to configure the service policy called policy1 and attach service policy policy1 to an interface. In this example, class map mplsmap1 evaluates all packets entering HundredGigabit Ethernet interface 0/1/0/9 for an MPLS experimental value of 1. If the incoming packet has been marked with the MPLS experimental value of 1, the packet is queued to the class queue with the bandwidth setting of 1000 mbps.

RP/0/RP0/CPU0:router(config)# class-map mplsmap1 RP/0/RP0/CPU0:router(config-cmap)# match mpls experimental topmost 1 RP/0/RP0/CPU0:router(config-cmap)# exit

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class mplsmap1 RP/0/RP0/CPU0:router(config-pmap-c)# bandwidth 1000 mbps RP/0/RP0/CPU0:router(config-pmap-c)#exit RP/0/RP0/CPU0:router(config-pmap)#exit

RP/0/RP0/CPU0:router(config)# interface HundredGigabitEthernet 0/1/0/9 RP/0/RP0/CPU0:router(config-if)# service-policy input policy1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

match precedence

To identify IP precedence values as match criteria, use the match precedence command in class map configuration mode. To remove precedence values from a class map, use the no form of this command.

match [not] precedence [{ipv4|ipv6}] precedence-value [precedence-value1 ... precedence-value7] no match [not] precedence [{ipv4|ipv6}] precedence-value [precedence-value1 ...

precedence-value7]

match precedence

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

(Optional) Negates the specified match result.not

(Optional) Specifies the IPv4 precedence value.ipv4

(Optional) Specifies the IPv6 precedence value.ipv6

precedence-value

Matching on both IP Version 4 (IPv4) and IPv6 packets is the default.

Class map configuration

The match precedence command is supported only in the ingress direction. The minimum value is 0 and maximum value is 7. The maximum allowed entries: 8.

The match precedence command specifies a precedence value that is used as the match criteria against which packets are checked to determine if they belong to the class specified by the class map.

An IP precedence value identifier that specifies the exact value. Reserved keywords can be specified instead of numeric values. Table 3: IP Precedence Values and Names, on

page 22 describes the reserved keywords.

Up to eight precedence values can be matched in one match statement.

ModificationRelease

This command was introduced.Release 6.0

To use the match precedence command, you must first enter the class-map command to specify the name of the class whose match criteria you want to establish. If you specify more than one match precedence command in a class map, the new values are added to the existing statement.

The match precedence command examines the higher-order three bits in the type of service (ToS) byte of the IP header. Up to eight precedence values can be matched in one match statement. For example, match precedence ipv4 0 1 2 3 4 5 6 7 returns matches for IP precedence values of 0, 1, 2, 3, 4, 5, 6, and 7. Only one of the eight values is needed to yield a match (OR operation).

The precedence values are used as a matching criterion only. The value has no mathematical significance. For instance, the precedence value 2 is not greater than 1. The value simply indicates that a packet marked with the precedence value of 2 is different than a packet marked with the precedence value of 1. The treatment of these different packets is defined by the user through the setting of QoS policies in policy map class configuration mode.

This table lists the IP precedence value number and associated name in descending order of importance.

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

match precedence

Table 3: IP Precedence Values and Names

NameValue

routine0

priority1

immediate2

flash3

flash-override4

critical5

internet6

network7

ipv4

precedence

QoS Classification Commands

Task ID

Examples

ipv6

precedence

OperationsTask

qos

read, write

This example shows how to configure the service policy called policy1 and attach service policy policy1 to an interface. In this example, class map ipprec5 evaluates all packets entering HundredGigabit Ethernet interface 0/1/0/9 for a precedence value of 5. If the incoming packet has been marked with the precedence value of 5, the packet is queued to the class queue with the bandwidth setting of 1000 mbps.

RP/0/RP0/CPU0:router# configure RP/0/RP0/CPU0:router(config)# class-map ipprec5 RP/0/RP0/CPU0:router(config-cmap)# match precedence ipv4 5 RP/0/RP0/CPU0:router(config-cmap)# exit

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class ipprec5 RP/0/RP0/CPU0:router(config-pmap-c)# bandwidth 1000 mbps RP/0/RP0/CPU0:router(config-pmap)# exit

RP/0/RP0/CPU0:router(config)# interface HundredGigabitEthernet 0/1/0/9 RP/0/RP0/CPU0:router(config-if)# service-policy input policy1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

match protocol

To identify a specific protocol as the match criterion for a class map, use the match protocol command in class map configuration mode. To remove protocol-based match criteria from a class map, use the no form of this command.

match [not] protocol {protocol-value [protocol-value1 ... protocol-value7] |[min-value - max-value]} no match [not] protocol {protocol-value [protocol-value1 ... protocol-value7] |[ min-value - max-value]}

match protocol

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

(Optional) Negates the specified match result.not

protocol-value

A protocol identifier. A single value for protocol-value (any combination of numbers and names) can be matched in one match statement.

min-value

max-value

Lower limit of protocol range to match. Minimum value is 0.

Upper limit of protocol range to match. Maximum value is 255.

No default behavior or values

Class map configuration

ModificationRelease

This command was introduced.Release 6.0

The match protocol command is supported only in ingress direction. The maximum allowed entry is 1.

Definitions of traffic classes are based on match criteria, including protocols, access control lists (ACLs), input interfaces, QoS labels, and experimental (EXP) field values. Packets satisfying the match criteria for a class constitute the traffic for that class.

The match protocol command specifies the name of a protocol to be used as the match criteria against which packets are checked to determine if they belong to the class specified by the class map. Available protocol names are listed in the table that follows.

The protocol-value argument supports a range of protocol numbers. After you identify the class, you may use the match protocol command to configure its match criteria.

Table 4: Protocol Names and Descriptions

DescriptionName

Authentication Header Protocolahp

Encapsulation Security Payloadesp

Cisco Generic Routing Encapsulation Tunnelinggre

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

match protocol

QoS Classification Commands

DescriptionName

Internet Control Message Protocolicmp

Internet Gateway Message Protocoligmp

Cisco IGRP Routing protocoligrp

IP in IP tunnelingipinip

Any IPv4 protocolipv4

Any IPv6 protocolipv6

Any MPLS packetmpls

KA9Q NOS Compatible IP over IP Tunnelingnos

Open Shortest Path First, Routing Protocolospf

Payload Compression Protocolpcp

Task ID

Examples

Protocol Independent Multicastpim

Stream Control Transmission Protocolsctp

Transport Control Protocoltcp

User Datagram Protocoludp

OperationsTask

qos

read, write

In this example, all TCP packets belong to class class 1:

RP/0/RP0/CPU0:router(config)# class-map class 1 RP/0/RP0/CPU0:router(config-cmap)# match protocol tcp

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

match qos-group

To identify specific quality-of-service (QoS) group values as match criteria in a class map, use the match qos-group command in class map configuration mode. To remove a specific QoS group value from the matching criteria for a class map, use the no form of this command.

match qos-group [qos-group-value ] no match qos-group

match qos-group

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

qos-group-value

QoS group value identifier that specifies the exact value from 1 to 7. Range is not supported.

No match criteria are specified.

Class map configuration

ModificationRelease

This command was introduced.Release 6.0

The match qos-group command is supported only in the egress direction. The egress default class will implicitly match qos-group 0. The minimum value is 1 and maximum value is 7. The maximum allowed entries: 7.

The match qos-group command sets the match criteria for examining QoS groups marked on the packet. One class map can match only one qos-group value from 1 to 7. The qos-group values 1 to 7 maps to queue 1 to 7 on the egress port. Queue 0 is reserved for class-default.

The QoS group value is used as a matching criterion only. The value has no mathematical significance. For instance, the QoS group value 2 is not greater than 1. The value simply indicates that a packet marked with the QoS group value of 2 should be treated differently than a packet marked with a QoS group value of 1. The treatment of these different packets is defined using the service-policy command in policy map class configuration mode.

The QoS group setting is limited in scope to the local router. Typically, the QoS group is set on the ingress on the local router to be used locally and the router to give differing levels of service based on the group identifier.

In the ingress policy-map, in order to designate the traffic class to a certain CoSQ other than CoSQ 0, the class-map needs to have an explicit set qos-group x statement, where 'x' is the CoSQ in the range of 0 to 7. The default COSQ is 0. In the egress policy-map, a class-map with a corresponding match qos-group x will allow further Quality of Service actions to be applied to the traffic class. For example,

class-map prec1

match prec 1

policy-map test-ingress

class prec1

set qos-group 1 police rate percent 50

class-map qg1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

match qos-group

QoS Classification Commands

match qos-group 1

policy-map test-egress

class qg1

shape average percent 70

Task ID

Examples

OperationsTask

qos

read, write

This example shows a service policy called policy1 attached to an HundredGigabit Ethernet interface 0/1/0/9. In this example, class map qosgroup5 will evaluate all packets leaving HundredGigabit Ethernet interface 0/1/0/9 for a QoS group value of 5. If the packet has been marked with the QoS group value of 5, the packet is queued to the class queue with the bandwidth setting of 1000 mbps.

RP/0/RP0/CPU0:router(config)# class-map qosgroup5 RP/0/RP0/CPU0:router(config-cmap)# match qos-group 5 RP/0/RP0/CPU0:router(config-cmap)# exit

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class qosgroup5 RP/0/RP0/CPU0:router(config-pmap-c)# bandwidth 1000 mbps RP/0/RP0/CPU0:router(config-pmap-c)# exit RP/0/RP0/CPU0:router(config-pmap)# exit

RP/0/RP0/CPU0:router(config)# interface HundredGigabitEthernet 0/1/0/9 RP/0/RP0/CPU0:router(config-if)# service-policy output policy1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

random-detect discard-class

To configure the Weighted Random Early Detection (WRED) thresholds for packets with a specific discard class value, use the random-detect discard-class command in policy map class configuration mode. To return the thresholds to the default for the discard class, use the no form of this command.

random-detect discard-class discard-value min-threshold [units] max-threshold [units] no random-detect discard-class discard-value min-threshold [units] max-threshold [units]

random-detect discard-class

Syntax Description

Command Default

Command Modes

discard-value

min-threshold

max-threshold

units

Default unit for max-threshold and min-threshold is packets.

Policy map class configuration

Discard class value. The value is 0 or 1.

Minimum threshold in number of packets. The value range of this argument is from 0 to 1073741823 in bytes.

Maximum threshold in number of packets. The value range of this argument is from the value of the min-threshold argument to 1073741823. When the average queue length exceeds the maximum threshold, WRED drops all packets with the specified discard class value.

(Optional) Units for the threshold values. Values can be:

• bytes—bytes

• gbytes—gigabytes

• kbytes—kilobytes

• mbytes —megabytes

• ms—milliseconds

• packets—packets (default)

• us—microseconds

Command History

Usage Guidelines

WRED is a congestion avoidance mechanism that slows traffic by randomly dropping packets when congestion exists. WRED is most useful with protocols like TCP that respond to dropped packets by decreasing the transmission rate.

When you configure the random-detect discard-class command on an interface, packets are given preferential treatment based on the discard class of the packet.

When the value of the units argument is packets, packets are assumed to be 256 bytes in size.

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

ModificationRelease

This command was introduced.Release 6.0

random-detect discard-class

QoS Classification Commands

Task ID

Examples

OperationsTask

qos

read, write

This example shows how to set the discard class values for discard class 1 to a minimum byte threshold of 1000000 and a maximum byte threshold of 2000000:

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:router(config-pmap-c)# random-detect discard-class 1 1000000 bytes 2000000

bytes

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

set cos

To set the Layer 2 class of service (CoS) value of an outgoing packet, use the set cos command in policy map class configuration mode. To remove a specific CoS value setting, use the no form of this command.

set cos cos-value no set cos cos-value

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

Examples

cos-value

Specific IEEE 802.1Q CoS value from 0 to 7.

No Layer 2 CoS value of an outgoing packet is set.

Policy map class configuration

ModificationRelease

This command was introduced.Release 6.1.2

Use the set cos command to mark a packet that is being sent to a switch. Switches can leverage Layer 2 header information, including a CoS value marking.

The set cos command is supported only in the ingress direction. Only unconditional COS marking in the ingress direction is supported.

OperationsTask

qos

read, write

In this example, the policy map called cos-set is created to assign different CoS values for different service classes, and then is attached to the output interface HundredGigE 0/0/0/3.

RP/0/RP0/CPU0:router(config)# policy-map cos-set RP/0/RP0/CPU0:router(config-pmap)# class class1... RP/0/RP0/CPU0:router(config-pmap-c)# set cos 1 RP/0/RP0/CPU0:router(config-pmap-c)# exit RP/0/RP0/CPU0:router(config-pmap)# class class2... RP/0/RP0/CPU0:router(config-pmap-c)#set cos 2 RP/0/RP0/CPU0:router(config-pmap-c)#exit RP/0/RP0/CPU0:router(config-pmap)# interface HundredGigE 0/0/0/3 RP/0/RP0/CPU0:router(config-if)# service-policy input cos-set

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

set dei

QoS Classification Commands

To set the drop eligible indicator (DEI) value in a policy map class, use the set dei command in policy map class configuration mode. To remove a specified DEI value from a policy map class, use the no form of this command.

set dei value no set dei

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

Examples

Value of the DEI bit. Can be 0 or 1.

value

There is no default DEI value; it must be specified.

Policy map class configuration

ModificationRelease

This command was introduced.Release

6.1.2

The set dei command specifies a DEI value in a policy map class. For example, traffic can be policed and the excess traffic can be marked with DEI value of 1, so that it can be preferentially dropped in the egress interface or further downstream, when there is congestion.

OperationTask

qos

read, write

In this example, 802.1ad CoS plus DEI is derived from the incoming 802.1q CoS. Packets with a CoS value of 0 are remarked with a DEI value of 1.

RP/0/RP0/CPU0:router(config)# class-map match-any remark-cos RP/0/RP0/CPU0:router(config-cmap)# match cos 0 RP/0/RP0/CPU0:router(config-cmap)# exit RP/0/RP0/CPU0:router(config)# policy-map p1 RP/0/RP0/CPU0:router(config-pmap)# class remark-cos RP/0/RP0/CPU0:router(config-pmap-c)# set dei 1 RP/0/RP0/CPU0:router(config-pmap-c)# exit RP/0/RP0/CPU0:router(config)# interface HundredGigE0/5/0/0.0 l2transport RP/0/RP0/CPU0:router(config-subif)# encapsulation dot1q 1 RP/0/RP0/CPU0:router(config-subif)# rewrite ingress tag push dot1ad 5 symmetric RP/0/RP0/CPU0:router(config-subif)# service-policy input p1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

set discard-class

To set the discard class and Quality of Service (QoS) group identifiers on IP Version 4 (IPv4) or Multiprotocol Label Switching (MPLS) packets, use the set discard-class command in policy map class configuration mode. To leave the discard-class values unchanged, use the no form of this command.

set discard-class discard-class-value no set discard-class discard-class-value

set discard-class

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Note

discard-class-value

Discard class ID. An integer 0 to 1, to be marked on the packet.

No default behavior or values

Policy map class configuration

ModificationRelease

This command was introduced.Release 6.0

The set discard-class command associates a discard class ID with a packet. After the discard class is set, other QoS services such as Weighted Random Early Detection (WRED) can operate on the bit settings.

Discard-class indicates the discard portion of the per hop behavior (PHB). The set discard-class command is typically used in Pipe mode. Discard-class is required when the input PHB marking is used to classify packets on the output interface.

The set discard-class command is supported only in the ingress direction.Unconditional discard-class marking is supported.

The discard-class values can be used to specify the type of traffic that is dropped when there is congestion.

1. Marking of the discard class has only local significance on a node.

2. Discard class cannot be associated with a QoS profile in peering mode.

Task ID

OperationsTask

qos

read, write

Examples

This example shows how to set the discard class value to 1 for packets that match the MPLS experimental bits 1:

RP/0/RP0/CPU0:router(config)# class-map cust1 RP/0/RP0/CPU0:router(config-cmap)# match mpls experimental topmost 1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

set discard-class

QoS Classification Commands

RP/0/RP0/CPU0:router(config-cmap)# exit RP/0/RP0/CPU0:router(config)# policy-map policy2 RP/0/RP0/CPU0:router(config-pmap)# class cust1 RP/0/RP0/CPU0:router(config-pmap-c)# set discard-class 1 RP/0/RP0/CPU0:router(config-pmap-c)# exit RP/0/RP0/CPU0:router(config-pmap)# exit RP/0/RP0/CPU0:router(config)# interface HundredGigE 0/1/0/0 RP/0/RP0/CPU0:router(config-if)# service-policy input policy2

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

set dscp

To mark a packet by setting the IP differentiated services code point (DSCP) in the type of service (ToS) byte, use the set dscp command in policy-map class configuration mode. To remove a previously set DSCP value, use the no form of this command.

set dscp [tunnel] dscp-value no set dscp [tunnel] dscp-value

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

tunnel

(Optional) Sets the DSCP on the outer IP header. This command is available on Layer 3 interfaces in the ingress direction.

dscp-value

Number from 0 to 63 that sets the DSCP value. Reserved keywords can be specified instead of numeric values. Table 2: IP DSCP Reserved Keywords, on page 17 describes the reserved keywords.

No default behavior or values

Policy map class configuration

ModificationRelease

This command was introduced.Release 6.0

After the DSCP bit is set, other quality-of-service (QoS) services can then operate on the bit settings. The set dscp is supported only in the ingress direction.

The network gives priority (or some type of expedited handling) to marked traffic. Typically, you set the DSCP value at the edge of the network (or administrative domain); data then is queued based on the DSCP value.

OperationsTask

qos

read, write

Examples

In this example, the DSCP ToS byte is set to 6 in the policy map called policy-in. All packets that satisfy the match criteria of class1 are marked with the DSCP value of 6. The network configuration determines how packets are marked.

RP/0/RP0/CPU0:router (config)# policy-map policy-in RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:router(config-pmap-c)# set dscp 6

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

set mpls experimental

To set the experimental (EXP) value of the Multiprotocol Label Switching (MPLS) packet topmost or imposition labels, use the set mpls experimental command in policy map configuration mode. To leave the EXP value unchanged, use the no form of this command.

set mpls experimental {topmost} exp-value no set mpls experimental {topmost} exp-value

QoS Classification Commands

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

Specifies to set the EXP value of the topmost label.topmost

exp-value

Value of the MPLS packet label. Range is 0 to 7.

No MPLS experimental value is set

Policy map class configuration

ModificationRelease

This command was introduced.Release 6.0

After the MPLS experimental bits are set, other QoS services can then operate on the bit settings.

This command is supported only in ingress direction. Unconditional MPLS experimental marking is supported.

The network gives priority (or some type of expedited handling) to the marked traffic. Typically, the MPLS experimental value is set at the edge of the network (or administrative domain) and queuing is acted on it thereafter.

OperationsTask

qos

read, write

Examples

This example shows how to set the MPLS experimental to 5 for packets that match access list 101:

RP/0/RP0/CPU0:router(config)# class-map class1 RP/0/RP0/CPU0:router(config-cmap)# match access-group ipv4 acl101 RP/0/RP0/CPU0:router(config-cmap)# exit

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:router(config-pmap-c)# set mpls experimental topmost 5 RP/0/RP0/CPU0:router(config-pmap-c)# exit RP/0/RP0/CPU0:router(config-pmap)# exit

RP/0/RP0/CPU0:router(config)# interface HundredGigE 0/1/0/0 RP/0/RP0/CPU0:router(config-if)# service-policy input policy1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

set precedence

To set the precedence value in the IP header, use the set precedence command in policy map class configuration mode. To leave the precedence value unchanged, use the no form of this command.

set precedence [tunnel] value no set precedence [tunnel] value

set precedence

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

(Optional) Sets the IP precedence on the outer IP header.tunnel

value

Number or name that sets the precedence bits in the IP header. Range is from 0 to 7. Reserved keywords can be specified instead of numeric values. Table 3: IP Precedence Values and Names,

on page 22 describes the reserved keywords.

No default behavior or values

Policy map class configuration

ModificationRelease

This command was introduced.Release 6.0

Precedence can be set using a number or corresponding name. After IP Precedence bits are set, other QoS services can then operate on the bit settings.

The set precedence command is supported only in the ingress direction. Unconditional precedence marking is supported.

The network gives priority (or some type of expedited handling) to the marked traffic. IP precedence can be set at the edge of the network (or administrative domain) and have queueing act on it thereafter.

The mapping from keywords such as 0 (routine) and 1 (priority) to a precedence value is useful only in some instances. That is, the use of the precedence bit is evolving. You can define the meaning of a precedence value by enabling other features that use the value. In the case of high-end Internet QoS, IP precedences can be used to establish classes of service that do not necessarily correspond numerically to better or worse handling in the network.

Task ID

OperationsTask

qos

read, write

Examples

This example shows how to set the IP precedence to 5 (critical) for packets that match the access control list named customer1:

RP/0/RP0/CPU0:router(config)# class-map class1 RP/0/RP0/CPU0:router(config-cmap)# match access-group ipv4 customer1 RP/0/RP0/CPU0:router(config-cmap)# exit

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

set precedence

QoS Classification Commands

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:router(config-pmap-c)# set precedence 5 RP/0/RP0/CPU0:router(config-pmap-c)# exit RP/0/RP0/CPU0:router(config-pmap)# exit

RP/0/RP0/CPU0:router(config)# interface HundredGigE 0/1/0/9 RP/0/RP0/CPU0:router(config-if)# service-policy input policy1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

set qos-group

To set the quality of service (QoS) group identifiers on packets, use the set qos-group command in policy map class configuration mode. To leave the QoS group values unchanged, use the no form of this command.

set qos-group qos-group-value no set qos-group qos-group-value

set qos-group

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

qos-group-value

QoS group ID. An integer from 1 to 7, to be marked on the packet.

The qos-group-value is used to select a CoSQ and eventually to a VOQ

No group ID is specified.

Policy map class configuration

ModificationRelease

This command was introduced.Release 6.0

The set qos-group command is supported only in the ingress direction.

The set qos-group will be used as internal priority to choose the queue on the egress port.

class-map prec1

match prec 1

policy-map test-ingress

class prec1

set qos-group 1 police rate percent 50

class-map qg1

match qos-group 1

policy-map test-egress

class qg1

shape average percent 70

Task ID

OperationsTask

qos

read, write

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

set qos-group

QoS Classification Commands

Examples

This example sets the QoS group to 5 for packets that match the MPLS experimental bit 1:

RP/0/RP0/CPU0:router(config)# class-map class1 RP/0/RP0/CPU0:router(config-cmap)# match mpls experimental topmost 1 RP/0/RP0/CPU0:router(config-cmap)# exit

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:router(config-pmap-c)# set qos-group 5 RP/0/RP0/CPU0:router(config-pmap-c)# exit RP/0/RP0/CPU0:router(config-pmap)# exit

RP/0/RP0/CPU0:router(config)# HundredGigE interface 0/1/0/0 RP/0/RP0/CPU0:router(config-if)# service-policy input policy1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

QoS Classification Commands

shape average

To shape traffic to the indicated bit rate according to the algorithm specified, use the shape average command in policy map class configuration mode. To remove traffic shaping, use the no form of this command.

shape average {percent percentage |rate [units]} no shape average

shape average

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

percent percentage

rate

units

Specifies the interface bandwidth in percentage. Values can be from 1 to 100.

Average shaping rate in the specified units. Values can be from 1 to 4294967295.

(Optional) Units for the bandwidth. Values can be:

• bps—bits per second (default)

• gbps—gigabits per second

• kbps—kilobits per second

• mbps—megabits per second

units: bps

Policy map class configuration

ModificationRelease

This command was introduced.Release 6.0

The shape average command is supported only in the egress direction.

When you use the shape average command, egress shaping is done at the Layer 1 level and includes the Layer 1 header in the rate calculation. The minimum shape rate is 469 kbps. If you have both shape and bandwidth configured for a class, ensure that the shape percent value is always greater than the percent value for bandwidth. For bundled interfaces, shape average can be configured only as a percentage.

The priority and shape average commands can be configured together in the same class.

Task ID

OperationsTask

qos

read, write

Examples

This example sets traffic shaping to 50 percent of the parent shaper rate milliseconds:

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:router(config-pmap-c)# shape average percent 50

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

shape average

QoS Classification Commands

This example shows how to set traffic shaping to 100000 kbps:

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:router(config-pmap-c)# shape average 100000 kbps

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Congestion Management Commands

Note

This chapter describes the commands used to manage congestion.

• decapsulate gre, on page 42

• police rate, on page 43

• policy-map, on page 45

• priority (QoS), on page 47

• vrf-policy, on page 48

• show qos interface , on page 49

• show policy-map interface, on page 55

• show policy-map targets, on page 60

• show policy-map type pbr, on page 62

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

decapsulate gre

To enable decapsulation of the Generic Routing Encapsulation (GRE) packets, use the decapsulate gre command in policy map class configuration mode. To remove a previously configured GRE decapsulation for a class, use the no form of this command.

decapsulate gre no decapsulate gre

Congestion Management Commands

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

Examples

No default action.

Policy map class configuration

ModificationRelease

This command was introduced.Release 6.0.1

This command applies only to the incoming IPv4 packets only.

OperationsTask

qos

read, write

This example shows how to configure decapsulation of the GRE packets :

RP/0/RP0/CPU0:router(config)# policy-map type pbr gre-policy RP/0/RP0/CPU0:router(config-pmap)# class type traffic gre-class RP/0/RP0/CPU0:router(config-pmap-c)# decapsulate gre

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Congestion Management Commands

police rate

To configure traffic policing and enter policy map police configuration mode, use the police rate command in policy map class configuration mode. To remove traffic policing from the configuration, use the no form of this command.

police rate {value [units]|percent percentage}[burst burst-size [burst-units]] [peak-rate {value [units]|percent percentage}] [peak-burst peak-burst [burst-units]] no police rate {value [units]|percent percentage}[burst burst-size [burst-units]] [peak-rate {value [units]|percent percentage}] [peak-burst peak-burst [burst-units]]

police rate

Syntax Description

value

units

percent percentage

burst burst-size

burst-units

Committed information rate (CIR). Range is from 1 to 4294967295.

(Optional) Unit of measurement for the CIR. Values can be:

• bps —bits per second (default)

• gbps —gigabits per second

• kbps —kilobits per second

• mbps —megabits per second

Specifies the police rate as a percentage of the CIR. Range is from 1 to 100. See the Usage Guidelines for information on how to use this keyword.

(Optional) Specifies the burst size in the specified burst-units . The default burst value is 10 milliseconds of the CIR. The maximum burst value allowed is 4194304 bytes.

(Optional) Unit of measurement for the burst values. Values can be:

• bytes —bytes (default)

• gbytes —gigabytes

• kbytes —kilobytes

• mbytes —megabytes

• ms —milliseconds

• us —microseconds

• packets —packets

peak-burst peak-burst

Command Default

Command Modes

No restrictions on the flow of data are applied to any interface.

Policy map class configuration

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

(Optional) Specifies the Peak Information Rate (PIR) in the specified units.peak-rate value

(Optional) Specifies the peak burst size in the specified burst-units. The default peak burst value is 10 milliseconds of the PIR. The maximum peak-burst value allowed is 8388608 bytes. Also, the difference of the peak-burst value and burst value cannot be larger than 4194304 bytes.

police rate

Congestion Management Commands

Command History

Usage Guidelines

ModificationRelease

This command was introduced.Release 6.0

Policer conditional set is unsupported.

Policing can be applied only in the ingress direction.

For police rate commands, interpret the percent keyword in this way:

• For a one-level policy, the percent keyword specifies the CIR as a percentage of the link rate. For example, the command police rate percent 35 configures the CIR as 35% of the link rate.

Note

Configured values take into account the Layer 2 encapsulation applied to traffic. This applies to ingress policing. For Ethernet transmission, the encapsulation is considered to be 14 bytes, whereas for IEEE 802.1Q, the encapsulation is 18 bytes.

For more information, see the Committed Bursts and Excess Bursts section in the Modular QoS Configuration Guide for Cisco NCS 5500 Series Routers.

Note

A police rate minimum of 21 kbps is supported.

Task ID

OperationsTask

qos

read, write

In this example for MPLS, traffic policing is configured with the average rate at 250 kbps, and the normal burst size at 50 bytes for all packets leaving HundredGigE interface 0/1/0/0:

RP/0/RP0/CPU0:router(config)# class-map class1 RP/0/RP0/CPU0:router(config-cmap)# match mpls experimental topmost 0 RP/0/RP0/CPU0:router(config-cmap)# exit

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:router(config-pmap-c)# police rate 250 kbps burst 50 RP/0/RP0/CPU0:router(config-pmap-c)# exit RP/0/RP0/CPU0:router(config-pmap)# exit

RP/0/RP0/CPU0:router(config)# HundredGigE interface 0/1/0/0 RP/0/RP0/CPU0:router(config-if) service-policy input policy1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Congestion Management Commands

policy-map

To create or modify a policy map that can be attached to one or more interfaces to specify a service policy, use the policy-map command in XR Config mode. To delete a policy map, use the no form of this command.

policy-map [type qos] policy-name no policy-map [type qos] policy-name

policy-map

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

type qos

qos

policy-name

A policy map does not exist until one is configured. Because a policy map is applied to an interface, no restrictions on the flow of data are applied to any interface until a policy map is created.

Type is QoS when not specified.

XR Config mode

Use the policy-map command to specify the name of the policy map to be created, added to, or modified before you can configure policies for classes whose match criteria are defined in a class map. Entering the policy-map command enables policy map configuration mode in which you can configure or modify the class policies for that policy map.

(Optional) Specifies type of the service policy.

(Optional) Specifies a quality-of-service (QoS) policy map.

Name of the policy map.

ModificationRelease

This command was introduced.Release 6.0

You can configure class policies in a policy map only if the classes have match criteria defined for them. Use the class-map and match commands to configure the match criteria for a class.

A single policy map can be attached to multiple interfaces concurrently.

The number of classes per policy-map supported in the egress direction is 8 and ingress direction is 32.

For egress classification, in order to see statistics on all 8 CoSQs, you are recommended to configure all 8 classes including class-default.

Task ID

qos

OperationsTask

read, write

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

policy-map

Congestion Management Commands

Examples

These examples show how to create a policy map called policy1 and configures two class policies included in that policy map. The policy map is defined to contain policy specification for class1 and the default class (called class-default) to which packets that do not satisfy configured match criteria are directed. Class1 specifies policy for traffic that matches access control list 136.

RP/0/RP0/CPU0:router(config)# class-map class1 RP/0/RP0/CPU0:router(config-cmap)# match access-group ipv4 136

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:router(config-pmap-c)# set precedence 3 RP/0/RP0/CPU0:router(config-pmap-c)# exit

RP/0/RP0/CPU0:router(config-pmap)# class class-default RP/0/RP0/CPU0:router(config-pmap-c)# queue-limit 1000000 bytes

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Congestion Management Commands

priority (QoS)

To assign priority to a traffic class based on the amount of available bandwidth within a traffic policy, use the priority command in policy map class configuration mode. To remove a previously specified priority for a class, use the no form of this command.

priority [level priority-level] no priority

priority (QoS)

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

level priority-level

(Optional) Sets multiple levels of priority to a traffic class. Level 1 through 7. Default level is 1. Level 1 traffic has higher priority.

No default action.

Policy map class configuration

ModificationRelease

This command was introduced.Release 6.0

The priority command configures low-latency queueing (LLQ), providing strict priority queueing (PQ). Strict PQ allows delay-sensitive data such as voice to be dequeued and sent before packets in other queues are dequeued. The priority command is supported only in the egress direction. No policer is allowed with a priority class. To limit the priority traffic use the shape average command.

The priority command sets up classes based on a variety of criteria (not just User Datagram Protocol [UDP] ports) and assigns a priority to them.

The bandwidth and priority commands cannot be used in the same class, within the same policy map. These commands can be used together in the same policy map.

OperationsTask

qos

read, write

Examples

This example shows how to configure priority queuing for the policy map named policy1 :

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:router(config-pmap-c)# priority level 1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

vrf-policy

Congestion Management Commands

To apply a policy on a per VPN routing and forwarding (VRF) basis, use the vrf-policy command in global configuration mode. To remove the association of the policy on a VRF, use the no form of this command.

vrf-policy vrf vrf-name address-family {ipv4 | ipv6 } policy type pbr input policy-name no vrf-policy vrf vrf-name address-family {ipv4 | ipv6 } policy type pbr input policy-name

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

vrf vrf-name

policy type pbr input policy-name

Sets the VRF name.

Sets the policy name.

No default action.

Policy map class configuration

ModificationRelease

This command was introduced.Release 6.0.1

This command is supported with sub-mode. This command applies only to the incoming IPv4 packets only.

Use this command to apply a PBR policy on a per VRF basis during the classification and decapsulation of GRE packets.

OperationsTask

qos

read, write

Examples

This example shows how to apply an already configured policy on a per VRF basis:

/* Configuring a VRF */ RP/0/RP0/CPU0:router(config)# vrf gre-vrf address-family ipv4 unicast ... /* Configuring a policy */ RP/0/RP0/CPU0:router(config)# policy-map type pbr gre-policy ... /* Applying the policy on the VRF */ RP/0/RP0/CPU0:router(config)# vrf-policy vrf gre-vrf address-family ipv4 policy type pbr

input gre-policy

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Congestion Management Commands

show qos interface

To display QoS information for a specific interface, use the show qos interface command in the XR EXEC mode.

show qos interface interface-name {input|output}[location node-id]

show qos interface

Syntax Description

Command Default

Command Modes

Command History

interface-name

input

output

location node-id

No default behavior or values

XR EXEC mode

Interface name. For more information about the syntax for the router, use the question mark (?) online help function.

Note

Use the show interfaces command to see a list of all interfaces currently configured on the router.

Attaches the specified policy map to the input interface.

Attaches the specified policy map to the output interface.

(Optional) Displays detailed QoS information for the designated node. The node-id argument is entered in the rack/slot/module notation.

ModificationRelease

This command was introduced.Release 6.0

Usage Guidelines

The show qos interface command displays configuration for all classes in the service policy that is attached to an interface.

Use this command to check the actual values programmed in the hardware from the action keywords in the police rate command.

Task ID

OperationsTask

readqos

Examples

This is the sample output shows the QoS information on a interface hundredGigE 0/6/0/18 that are in the input direction:

RP/0/RP0/CPU0:router# show qos interface hundredGigE 0/6/0/18 input

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

show qos interface

Congestion Management Commands

Wed Dec 2 22:34:20.241 UTC NOTE:- Configured values are displayed within parentheses Interface HundredGigE0/6/0/18 ifh 0x3000210 -- input policy NPU Id: 3 Total number of classes: 28 Interface Bandwidth: 100000000 kbps Accounting Type: Layer1 (Include Layer 1 encapsulation and above)

-----------------------------------------------------------------------------Level1 Class = exp-classifier-af1 New topmost exp = 7

Default Policer Bucket ID = 0x102a0 Default Policer Stats Handle = 0x8b304d98 Policer not configured for this class

Level1 Class = exp-classifier-af2 New topmost exp = 6

Default Policer Bucket ID = 0x102a1 Default Policer Stats Handle = 0x8b304b48 Policer not configured for this class

Level1 Class = exp-classifier-af3 New topmost exp = 5

Default Policer Bucket ID = 0x102a2 Default Policer Stats Handle = 0x8b3048f8 Policer not configured for this class

Level1 Class = exp-classifier-af4 New topmost exp = 3

Default Policer Bucket ID = 0x102a3 Default Policer Stats Handle = 0x8b3046a8 Policer not configured for this class

Level1 Class = exp-classifier-be1 New topmost exp = 4

Default Policer Bucket ID = 0x102a4 Default Policer Stats Handle = 0x8b304458 Policer not configured for this class

Level1 Class = inet4-classifier-af1 New qos group = 1

Default Policer Bucket ID = 0x102a5 Default Policer Stats Handle = 0x8b304208 Policer not configured for this class

Level1 Class = inet4-classifier-af2 New qos group = 2

Default Policer Bucket ID = 0x102a6 Default Policer Stats Handle = 0x8b303fb8 Policer not configured for this class

Level1 Class = inet4-classifier-af3 New qos group = 3

Default Policer Bucket ID = 0x102a7 Default Policer Stats Handle = 0x8b303d68 Policer not configured for this class

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Congestion Management Commands

Level1 Class = inet4-classifier-af4 New qos group = 4

Default Policer Bucket ID = 0x102a8 Default Policer Stats Handle = 0x8b303b18 Policer not configured for this class

Level1 Class = inet4-classifier-be1 New qos group = 5

Default Policer Bucket ID = 0x102a9 Default Policer Stats Handle = 0x8b3038c8 Policer not configured for this class

Level1 Class = inet4-classifier-nc1 New qos group = 6

Default Policer Bucket ID = 0x102aa Default Policer Stats Handle = 0x8b303678 Policer not configured for this class

Level1 Class = inet6-classifier-af1 New qos group = 1

show qos interface

Default Policer Bucket ID = 0x102ab Default Policer Stats Handle = 0x8b303428 Policer not configured for this class

Level1 Class = inet6-classifier-af2 New qos group = 2

Default Policer Bucket ID = 0x102ac Default Policer Stats Handle = 0x8b3031d8 Policer not configured for this class

Level1 Class = inet6-classifier-af3 New qos group = 3

Default Policer Bucket ID = 0x102ad Default Policer Stats Handle = 0x8b302f88 Policer not configured for this class

Level1 Class = inet6-classifier-af4 New qos group = 4

Default Policer Bucket ID = 0x102ae Default Policer Stats Handle = 0x8b302d38 Policer not configured for this class

Level1 Class = inet6-classifier-be1 New qos group = 5

Default Policer Bucket ID = 0x102af Default Policer Stats Handle = 0x8b302ae8 Policer not configured for this class

Level1 Class = inet6-classifier-nc1 New qos group = 6

Default Policer Bucket ID = 0x102b0 Default Policer Stats Handle = 0x8b302898 Policer not configured for this class

Level1 Class = inet-classifier-ipv6-af1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

show qos interface

Congestion Management Commands

New qos group = 1

Default Policer Bucket ID = 0x102b1 Default Policer Stats Handle = 0x8b302648 Policer not configured for this class

Level1 Class = inet-classifier-ipv6-af2 New qos group = 2

Default Policer Bucket ID = 0x102b2 Default Policer Stats Handle = 0x8b3023f8 Policer not configured for this class

Level1 Class = inet-classifier-ipv6-af3 New qos group = 3

Default Policer Bucket ID = 0x102b3 Default Policer Stats Handle = 0x8b3021a8 Policer not configured for this class

Level1 Class = inet-classifier-ipv6-af4 New qos group = 4

Default Policer Bucket ID = 0x102b4 Default Policer Stats Handle = 0x8b301f58 Policer not configured for this class

Level1 Class = inet-classifier-ipv6-af5 New qos group = 5

Default Policer Bucket ID = 0x102b5 Default Policer Stats Handle = 0x8b301d08 Policer not configured for this class

Level1 Class = inet-classifier-ipv6-af6 New qos group = 6

Default Policer Bucket ID = 0x102b6 Default Policer Stats Handle = 0x8b301ab8 Policer not configured for this class

Level1 Class = inet-management-classifier-af4 New qos group = 7

Default Policer Bucket ID = 0x102b7 Default Policer Stats Handle = 0x8b301868 Policer not configured for this class

Level1 Class = exp-classifier-nc1 New qos group = 6 New topmost exp = 2

Default Policer Bucket ID = 0x102b8 Default Policer Stats Handle = 0x8b301618 Policer not configured for this class

Level1 Class = inet-management-classifier-nc1 New prec = 6 New qos group = 5

Default Policer Bucket ID = 0x102b9 Default Policer Stats Handle = 0x8b3013c8 Policer not configured for this class

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Congestion Management Commands

Level1 Class = inet6-management-classifier-nc1 New qos group = 4

Default Policer Bucket ID = 0x102ba Default Policer Stats Handle = 0x8b301178 Policer not configured for this class

Level1 Class = class-default

Default Policer Bucket ID = 0x102bb Default Policer Stats Handle = 0x8b3074e8 Policer not configured for this class

This is the sample output shows the QoS information on a interface hundredGigE 0/6/0/18 that are in the output direction:

RP/0/RP0/CPU0:router# show qos interface hundredGigE 0/6/0/18 output Wed Dec 2 22:34:25.476 UTC NOTE:- Configured values are displayed within parentheses Interface HundredGigE0/6/0/18 ifh 0x3000210 -- output policy NPU Id: 3 Total number of classes: 3 Interface Bandwidth: 100000000 kbps VOQ Base: 11176 VOQ Stats Handle: 0x887a6e18 Accounting Type: Layer1 (Include Layer 1 encapsulation and above)

-----------------------------------------------------------------------------Level1 Class (HP7) = qos-1 Egressq Queue ID = 11177 (HP7 queue) Queue Max. BW. = 0 kbps (default) TailDrop Threshold = 125304832 bytes / 10 ms (default) WRED not configured for this class

show qos interface

Level1 Class (HP6) = qos-2 Egressq Queue ID = 11178 (HP6 queue) Queue Max. BW. = 0 kbps (default) TailDrop Threshold = 125304832 bytes / 10 ms (default) WRED not configured for this class

Level1 Class = class-default Egressq Queue ID = 11176 (Default LP queue) Queue Max. BW. = 101803495 kbps (default) Queue Min. BW. = 0 kbps (default) Inverse Weight / Weight = 1 / (BWR not configured) TailDrop Threshold = 1253376 bytes / 10 ms (default) WRED not configured for this class

This table describes the significant fields shown in the display.

Table 5: show QoS interface Field Descriptions

DescriptionField

Level 1 class identifier in decimal format.Level 1 class

Policer bucket identifier.Policer Bucket ID

Policer statistics handle for this class.Policer Stats Handle

VOQ number of the packet in this class.Queue ID

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Maximum bandwidth of the queue.Queue Max. BW

show qos interface

Congestion Management Commands

DescriptionField

Minimum bandwidth of the queue.Queue Min. BW

Inverse Weight / Weight

TailDrop Threshold

Remaining bandwidth weight.

Note

The hardware weight is expressed in inverse value.

Number of bytes taildropped for this queue and the default/user-configured queue-limit expressed in milliseconds/user-configured unit.

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Congestion Management Commands

show policy-map interface

To display policy information and statistics for all classes configured for all service policies on the specified interface, use the show policy-map interface command in XR EXEC mode.

show policy-map[interface {interface type| all} interface-path-id][{input |output }]

show policy-map interface

Syntax Description

Command Default

Command Modes

Command History

interface type

interface-path-id

input

output

None

XR EXEC mode

Interface type. For more information, use the question mark (?) online help function.

Specifies all interfaces.all

Physical interface or virtual interface.

Note

For more information about the syntax for the router, use the question mark (?) online help function.

(Optional) Displays per class statistics on inbound traffic for the specified policy map and interface.

(Optional) Displays per class statistics on outbound traffic for the specified policy map and interface.

Use the show interfaces command to see a list of all interfaces currently configured on the router.

ModificationRelease

Usage Guidelines

Task ID

Examples

The show policy-map interface command displays the statistics for classes in the service policy attached to an interface.

The show policy-map interface command does not display the statistics and counters for the egress marking policy.

OperationsTask

readqos

This sample output shows how to display policy statistics information for all classes on the interface hundredGigE 0/6/0/18 that are in the input direction:

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

This command was introduced.Release 6.0

show policy-map interface

RP/0/RP0/CPU0:router# show policy-map interface hundredGigE 0/6/0/18 input

Mon Nov 30 17:10:29.065 UTC

HundredGigE0/6/0/18 input: 32-classmaps

Class exp-classifier-af1

Class exp-classifier-af2

Class exp-classifier-af3

Class exp-classifier-af4

Class exp-classifier-be1

Class inet4-classifier-af1

Class inet4-classifier-af2

Class inet4-classifier-af3

Class inet4-classifier-af4

Class inet4-classifier-be1

Class inet4-classifier-nc1

Class inet6-classifier-af1

Congestion Management Commands

Classification statistics (packets/bytes) (rate - kbps)

Matched : 53186/54090162 3769 Transmitted : 53186/54090162 3769 Total Dropped : 0/0 0

Classification statistics (packets/bytes) (rate - kbps)

Matched : 54279/55201743 7483 Transmitted : 54279/55201743 7483 Total Dropped : 0/0 0

Classification statistics (packets/bytes) (rate - kbps)

Matched : 56710/57674070 7898 Transmitted : 56710/57674070 7898 Total Dropped : 0/0 0

Classification statistics (packets/bytes) (rate - kbps)

Matched : 110405/112281885 11584 Transmitted : 110405/112281885 11584 Total Dropped : 0/0 0

Classification statistics (packets/bytes) (rate - kbps)

Matched : 52753/53649801 3756 Transmitted : 52753/53649801 3756 Total Dropped : 0/0 0

Classification statistics (packets/bytes) (rate - kbps)

Matched : 38796901/14695393569 1580677 Transmitted : 38796901/14695393569 1580677 Total Dropped : 0/0 0

Classification statistics (packets/bytes) (rate - kbps)

Matched : 38850080/14715510334 1589124 Transmitted : 38850080/14715510334 1589124 Total Dropped : 0/0 0

Classification statistics (packets/bytes) (rate - kbps)

Matched : 38757080/14679867944 1580632 Transmitted : 38757080/14679867944 1580632 Total Dropped : 0/0 0

Classification statistics (packets/bytes) (rate - kbps)

Matched : 77228177/29251757855 3137985 Transmitted : 77228177/29251757855 3137985 Total Dropped : 0/0 0

Classification statistics (packets/bytes) (rate - kbps)

Matched : 38921394/14742645566 1588557 Transmitted : 38921394/14742645566 1588557 Total Dropped : 0/0 0

Classification statistics (packets/bytes) (rate - kbps)

Matched : 77088116/29199136824 3144053 Transmitted : 77088116/29199136824 3144053 Total Dropped : 0/0 0

Classification statistics (packets/bytes) (rate - kbps)

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Congestion Management Commands

Matched : 21953707/22326920019 1237979 Transmitted : 21953707/22326920019 1237979 Total Dropped : 0/0 0

Class inet6-classifier-af2

Classification statistics (packets/bytes) (rate - kbps)

Matched : 21701336/22070258712 1208262 Transmitted : 21701336/22070258712 1208262 Total Dropped : 0/0 0

Class inet6-classifier-af3

Classification statistics (packets/bytes) (rate - kbps)

Matched : 21715705/22084871985 1210060 Transmitted : 21715705/22084871985 1210060 Total Dropped : 0/0 0

Class inet6-classifier-af4

Classification statistics (packets/bytes) (rate - kbps)

Matched : 43418446/44156559582 2413245 Transmitted : 43418446/44156559582 2413245 Total Dropped : 0/0 0

Class inet6-classifier-be1

Classification statistics (packets/bytes) (rate - kbps)

Matched : 21958845/22332119845 1236894 Transmitted : 21958845/22332119845 1236894 Total Dropped : 0/0 0

Class inet6-classifier-nc1

Classification statistics (packets/bytes) (rate - kbps)

Matched : 43428930/44167221810 2415137 Transmitted : 43428930/44167221810 2415137 Total Dropped : 0/0 0

Class inet-classifier-ipv6-af1

Classification statistics (packets/bytes) (rate - kbps)

Matched : 0/0 0 Transmitted : 0/0 0 Total Dropped : 0/0 0

Class inet-classifier-ipv6-af2

Classification statistics (packets/bytes) (rate - kbps)

Matched : 0/0 0 Transmitted : 0/0 0 Total Dropped : 0/0 0

Class inet-classifier-ipv6-af3

Classification statistics (packets/bytes) (rate - kbps)

Matched : 0/0 0 Transmitted : 0/0 0 Total Dropped : 0/0 0

Class inet-classifier-ipv6-af4

Classification statistics (packets/bytes) (rate - kbps)

Matched : 0/0 0 Transmitted : 0/0 0 Total Dropped : 0/0 0

Class inet-classifier-ipv6-af5

Classification statistics (packets/bytes) (rate - kbps)

Matched : 0/0 0 Transmitted : 0/0 0 Total Dropped : 0/0 0

Class inet-classifier-ipv6-af6

Classification statistics (packets/bytes) (rate - kbps)

Matched : 0/0 0 Transmitted : 0/0 0 Total Dropped : 0/0 0

Class inet-management-classifier-af4

Classification statistics (packets/bytes) (rate - kbps)

Matched : 0/0 0 Transmitted : 0/0 0 Total Dropped : 0/0 0

Class exp-classifier-nc1

show policy-map interface

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

show policy-map interface

Class class-default

This sample output shows how to display policy statistics information for all classes on the interface hundredGigE 0/6/0/0 that are in the output direction:

RP/0/RP0/CPU0:router# show policy-map interface hundredGigE 0/6/0/0 output

Wed Dec 9 16:18:10.179 UTC HundredGigE0/6/0/0 output: test-pol-out

Congestion Management Commands

Classification statistics (packets/bytes) (rate - kbps)

Matched : 57115/58085955 7953 Transmitted : 57115/58085955 7953 Total Dropped : 0/0 0

Policing statistics (packets/bytes) (rate - kbps)

Policed(conform) : 57115/58085955 7953 Policed(exceed) : 0/0 0 Policed(violate) : 0/0 0 Policed and dropped : 0/0

Classification statistics (packets/bytes) (rate - kbps)

Matched : 0/0 0 Transmitted : 0/0 0 Total Dropped : 0/0 0

Class qos-grp1

Classification statistics (packets/bytes) (rate - kbps)

Matched : 885333442/900384110514 57036859 Transmitted : 299199945/304286344065 19278557 Total Dropped : 586133497/596097766449 37758302

Queueing statistics

Queue ID : 10409 Taildropped(packets/bytes) : 586133497/596097766449

Class qos-grp2

Classification statistics (packets/bytes) (rate - kbps)

Matched : 0/0 0 Transmitted : 0/0 0 Total Dropped : 0/0 0

Queueing statistics

Queue ID : 10410 Taildropped(packets/bytes) : 0/0

Class class-default

Classification statistics (packets/bytes) (rate - kbps)

Matched : 1487720301/1513011546117 98203543 Transmitted : 1182422140/1202523316380 78285945 Total Dropped : 305298161/310488229737 19917598

Queueing statistics

Queue ID : 10408 Taildropped(packets/bytes) : 305298161/310488229737

This table describes the significant fields shown in the display.

Table 6: show policy-map interface Field Descriptions

DescriptionField

Classification statistics

Matched

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Number of packets or bytes that matched this class.

Number of packets or bytes transmitted for this class.Transmitted

Number of packets or bytes dropped for this class.Total Dropped

Congestion Management Commands

Policing statistics

show policy-map interface

DescriptionField

Policed(conform)

Queuing statistics

Queue ID

Number of packets or bytes that conformed to the police rate for this class.

Number of packets or bytes that exceeded the police rate for this class.Policed(exceed)

Number of packets or bytes that violated the police rate for this class.Policed(violate)

Number of packets or bytes dropped by the policer of this class.Policed and dropped

VOQ number of the packet in this class.

Number of bytes taildropped for this queue.Taildropped (bytes)

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

show policy-map targets

To display information about the interfaces on which policy maps are applied, use the show policy-map targets command in XR EXEC mode.

show policy-map targets [{location node-id|pmap-name name|type qos [{location node-id|pmap-name name}]}]

Congestion Management Commands

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

location node-id

(Optional) Displays information about the interfaces on which policy maps are applied for the specified location. The node-id argument is entered in the rack/slot/module notation.

pmap-name name

(Optional) Displays information about the interfaces on which the specified policy map is applied.

type qos

(Optional) Displays information about the interfaces on which QoS policy maps are applied. This is the default type.

The default QoS policy type is QoS.

XR EXEC mode

ModificationRelease

This command was introduced.Release 6.0

For a short period of time while a QoS policy is being modified, there might not be any policy in effect on the interfaces in which the modified policy is used. For this reason, modify QoS policies that affect the fewest number of interfaces at a time. Use the show policy-map targets command to identify the number of interfaces that will be affected during policy map modification.

Task ID

OperationsTask

readqos

Examples

In this example, the TenGigabit Ethernet interface 4/0/10/0 has one policy map attached as a main policy. Outgoing traffic on this interface will be affected if the policy is modified:

RP/0/RP0/CPU0:router# show policy-map targets

Wed Dec 2 22:35:13.993 UTC

1) Policymap: test-qlimit Type: qos Targets (applied as main policy):

TenGigE0/4/0/10/0 output TenGigE0/6/0/30/1 output

Total targets: 2

Targets (applied as child policy): Total targets: 0

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Congestion Management Commands

2) Policymap: test-priority Type: qos Targets (applied as main policy):

Total targets: 30

show policy-map targets

HundredGigE0/6/0/35 output HundredGigE0/6/0/34 output HundredGigE0/6/0/33 output HundredGigE0/6/0/32 output HundredGigE0/6/0/31 output HundredGigE0/6/0/29 output HundredGigE0/6/0/28 output HundredGigE0/6/0/27 output HundredGigE0/6/0/25 output HundredGigE0/6/0/24 output HundredGigE0/6/0/23 output HundredGigE0/6/0/22 output HundredGigE0/6/0/21 output HundredGigE0/6/0/20 output HundredGigE0/6/0/19 output HundredGigE0/6/0/1 output HundredGigE0/6/0/3 output HundredGigE0/6/0/4 output HundredGigE0/6/0/5 output HundredGigE0/6/0/6 output HundredGigE0/6/0/7 output HundredGigE0/6/0/8 output HundredGigE0/6/0/9 output HundredGigE0/6/0/10 output HundredGigE0/6/0/11 output HundredGigE0/6/0/13 output HundredGigE0/6/0/14 output HundredGigE0/6/0/15 output HundredGigE0/6/0/16 output HundredGigE0/6/0/17 output

Targets (applied as child policy): Total targets: 0

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

show policy-map type pbr

To view details of the configured PBR policy and related statistics, use the show policy-map type pbr vrf

vrf-name addr-family ipv4 statistics command in XR EXEC mode.

show policy-map type pbr vrf vrf-name addr-family {ipv4 | ipv6 } statistics

Congestion Management Commands

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

Examples

vrf vrf-name

Sets the VRF name.

No default action.

XR EXEC mode

ModificationRelease

This command was introduced.Release 6.0.1

This command applies only to the incoming IPv4 packets only.

OperationsTask

readqos

This example shows how to view details of the configured PBR policy and related statistics:

input gre-policy

/* Displaying policy details and statistics */ RP/0/RP0/CPU0:router# show policy-map type pbr vrf gre-vrf addr-family ipv4 policy type pbr

input gre-policy

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Congestion Avoidance Commands

Note

This chapter describes commands used to avoid congestion.

Congestion avoidance is achieved through packet dropping.

• bandwidth (QoS), on page 64

• bandwidth remaining, on page 66

• queue-limit, on page 68

• random-detect, on page 71

• service-policy (interface), on page 73

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

bandwidth (QoS)

To specify the minimum bandwidth allocated to a class belonging to a policy map, use the bandwidth command in policy map class configuration mode. To remove the bandwidth specified for a class, use the no form of this command.

bandwidth {rate [units]|percent percentage-value} no bandwidth {rate [units]|percent percentage-value}

Congestion Avoidance Commands

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

rate

units

percent percentage-value

The default units is kbps.

Policy map class configuration

The bandwidth command is used to specify the minimum guaranteed bandwidth allocated for traffic matching a particular class. Bandwidth may be defined as a specific value or may be set as a percentage of the interface bandwidth.

Minimum bandwidth, in the units specified, to be assigned to the class. Range is from 1 to 4294967295.

Specifies the units for the bandwidth. Values can be:

• bps—bits per second

• gbps—gigabits per second

• kbps—kilobits per second (default)

• mbps—megabits per second

Specifies the amount of minimum guaranteed bandwidth, based on an absolute percentage of available bandwidth. Range is from 1 to 100.

ModificationRelease

This command was introduced.Release 6.0

If a percentage value is set, the accuracy that can be expected is 1 percent.

The bandwidth command is supported only in the egress direction.

A policy map can have a single bandwidth statement per class. Both percentage and actual value bandwidth configurations can be used within a policy map.

The bandwidth command does not specify how the bandwidth is to be shared. Instead it specifies how much bandwidth is guaranteed per class, by setting the number of tokens that are assigned to the token bucket of a particular class. For configured behavior to work correctly, you must ensure that the sum of the bandwidths plus any priority traffic is not greater than the bandwidth of the interface itself. If the interface is oversubscribed, unpredictable behavior results.

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Congestion Avoidance Commands

bandwidth (QoS)

Task ID

Examples

OperationsTask

qos

read, write

This example shows how to guarantee 50 percent of the interface bandwidth to a class called class1 and 10 percent of the interface bandwidth to a class called class2:

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:router(config-pmap-c)# bandwidth percent 50 RP/0/RP0/CPU0:router(config-pmap-c)# exit RP/0/RP0/CPU0:router(config-pmap)# class class2 RP/0/RP0/CPU0:router(config-pmap-c)# bandwidth percent 10

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

bandwidth remaining

To specify how to allocate leftover bandwidth to various classes, use the bandwidth remaining command in policy map class configuration mode. To return to the system defaults, use the no form of this command.

bandwidth remaining [{percent percentage-value|ratio ratio-value}] no bandwidth remaining [{percent percentage-value|ratio ratio-value}]

Congestion Avoidance Commands

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Note

percent percentage-value

Specifies the amount of guaranteed bandwidth, based on an absolute percentage of the available bandwidth. Range is from 1 to 100.

ratio ratio-value

Specifies the amount of guaranteed bandwidth, based on a bandwidth ratio value. Range is 1 to 2000.

No bandwidth is specified.

Policy map class configuration

ModificationRelease

This command was introduced.Release 6.0

Bandwidth, bandwidth remaining, shaping, queue-limit and WRED commands can be configured together in the same class.

The bandwidth remaining command is supported only in the egress direction.

The available bandwidth is equally distributed among those queueing classes that do not have the remaining bandwidth explicitly configured.

The bandwidth remaining command is used to proportionally allocate bandwidth to the particular classes, but there is no reserved bandwidth capacity.

On egress, if the bandwidth remaining command is not present, then the bandwidth is shared equally among the configured queueing classes present in the policy-map.

Task ID

OperationsTask

qos

read, write

Examples

This example shows how the remaining bandwidth is shared by classes class1 and class2 in a 20:80 ratio.

RP/0/RP0/CPU0:router(config)# policy-map policy1

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Congestion Avoidance Commands

RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:router(config-pmap-c)# bandwidth remaining percent 20 RP/0/RP0/CPU0:router(config-pmap-c)# exit RP/0/RP0/CPU0:router(config-pmap)# class class2 RP/0/RP0/CPU0:router(config-pmap-c)# bandwidth remaining percent 80

bandwidth remaining

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

queue-limit

Congestion Avoidance Commands

To specify or modify the maximum number of packets the queue can hold for a class policy configured in a policy map for each port, use the queue-limit command in policy map class configuration mode. To remove the queue packet limit from a class, use the no form of this command.

queue-limit value [unit ] | percent <1-100> no queue-limit

Syntax Description

Command Default

value

unit

percent

The default value is 10 milliseconds for all queues including the high-priority queues.

Maximum threshold for tail drop in bytes. Range is from 1 to 4294967295.

(Optional) Units for the queue limit value. Values can be:

• bytes —bytes

• kbytes —kilobytes

• mbytes —megabytes

• ms —milliseconds

• packets —packets (default)

• us —microseconds

Note

(Optional) Allows you to specify queue limit thresholds as a percentage of the total buffer limit for each port. This makes your provisioning model simpler and makes it easier for you to adjust the queue burst limit, irrespective of the queue’s service rate. The calculation is based on the assumption that a port takes 40 milli-seconds of buffering at port-rate. This option was introduced in Release

6.1.2.

When the specified units is packets, packets are assumed to be 256 bytes in size.

Command Modes

Command History

Usage Guidelines

Policy map class configuration

When configuring the queue-limit command, you must configure one of the following commands: priority, shape average, bandwidth or bandwidth remaining, except for the default class. The default value is 10 milliseconds for all queues including the high-priority queues.

The queue-limit command is supported only in the egress direction.

Packets satisfying the match criteria for a class accumulate in the queue reserved for the class until they are serviced by the scheduling mechanism. The queue-limit command defines the maximum threshold for a class. When that threshold is reached, enqueued packets to the class queue result in tail drop (packet drop).

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

ModificationRelease

This command was introduced.Release 6.0

Congestion Avoidance Commands

Tail drop is a congestion avoidance technique that drops packets when an output queue is full, until congestion is eliminated.

Use the show qos interface command to display the queue limit and other QoS values.

Queue Limit Default Values

These default values are used when queue-limit is not configured in the class:

• If QoS is configured and Weighted Random Early Detection (WRED) is not configured:

• If QoS is configured and WRED is configured:

queue-limit

• Queue limit is 10 ms at the guaranteed service rate of the queue for non-priority queues.

• Queue limit is 10 ms at the interface rate for priority classes

• Queue limit is two times the WRED maximum threshold. The maximum threshold can be an explicitly configured value or an implicit 10 ms.

• If more than one WRED profile is configured in the class, the maximum threshold is the maximum for all profiles.

• When the queue-limit is configured in time units, the guaranteed service rate (for the non-priority class) or the interface rate (for the priority class) is used to compute the queue-limit.

These restrictions apply to queue limits:

• For releases before Release 6.3.2, the queue limit should be at least the maximum MTU size, which is fixed at 9 * 1024 bytes = 9kb. From Release 6.3.2 onwards, the minimum queue limit is the interface MTU (which is dynamically configured).

• Queue limit should be 3 GB, which is the maximum packet buffer size in ingress and egress queuing ASICs.

• Only time-based units are allowed on bundle targets.

Guaranteed Service Rate

The guaranteed service rate is defined as the service rate of the queue when all queues are backlogged and derived as:

minimum_bandwidth + (bandwidth_remaining_percent * unallocated_bandwidth)

This example shows the guaranteed service rate calculation:

policy-map sample_policy

class c1

bandwidth percent 30 bandwidth remaining percent 40

class c2

bandwidth percent 20

class class-default

guaranteed service rate of c1 = 30 percent LR + (40 percent * 50 percent * LR)

guaranteed service rate of c2 = 20 percent LR + (30 percent * 50 percent * LR)

guaranteed service rate of class-default = 30 percent * 50 percent * LR

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

queue-limit

Congestion Avoidance Commands

• Where LR is line rate of the target on which service policy "sample_policy" is attached.

• 50 percent is unallocated bandwidth.

Task ID

Examples

OperationsTask

qos

read, write

This example shows how to set the queue limit for a class to 1000000 packets for policy map policy1:

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:router(config-pmap-c)# queue-limit 1000000

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Congestion Avoidance Commands

random-detect

To enable random early detection (RED), use the random-detect command in policy map class configuration mode. To remove RED, use the no form of this command.

random-detect {default|discard-class value|min-threshold [units] max-threshold [units]} no random-detect

random-detect

Syntax Description

Command Default

Command Modes

Enables RED with default minimum and maximum thresholds.default

discard-class value

min-threshold

max-threshold

units

Default unit for max-threshold and min-threshold is packets.

Policy map class configuration

Discard-class based WRED (up to 2 values, which is 0 and 1).

Minimum threshold in number of packets. The value range of this argument is from 0 to 1073741823 in packets.

Maximum threshold in number of packets. The value range of this argument is from the value of the min-threshold argument to 1073741823. When the queue length exceeds the maximum threshold, RED drops all packets with the specified discard class value.

(Optional) Units for the threshold values. Values can be:

• bytes—bytes

• gbytes—gigabytes

• kbytes—kilobytes

• mbytes —megabytes

• ms —milliseconds

• packets —packets (default)

• us —microseconds

Command History

Usage Guidelines

The RED congestion avoidance technique takes advantage of the congestion control mechanism of TCP. By randomly dropping packets before periods of high congestion, RED tells the packet source to decrease its transmission rate. Assuming the packet source is using TCP, it decreases its transmission rate until all the packets reach their destination, indicating that the congestion is cleared. You can use RED as a way to cause TCP to slow transmission of packets. TCP not only pauses, but it also restarts quickly and adapts its transmission rate to the rate that the network can support.

RED distributes losses in time and maintains normally low queue depth while absorbing traffic bursts. When enabled on an interface, RED begins dropping packets when congestion occurs at a rate you select during configuration.

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

ModificationRelease

This command was introduced.Release 6.0

random-detect

Congestion Avoidance Commands

When time units are used, the guaranteed service rate is used to compute thresholds. The default minimum threshold is 6 ms and the maximum threshold is 10 ms.

When the value of the units argument is packets, packets are assumed to be 256 bytes in size.

Weighted Random Early Detection

The following restriction apply to Weighted Random Early Detection (WRED):

• For thresholds in time units, the guaranteed service rate is used to calculate the thresholds in bytes.

For bundles, queue limit and WRED thresholds are supported in time units only.

Task ID

Examples

OperationsTask

qos

read, write

This example shows how to enable RED using a minimum threshold value of 1000000 and a maximum threshold value of 2000000:

RP/0/RP0/CPU0:router(config)# policy-map policy1 RP/0/RP0/CPU0:router(config-pmap)# class class1 RP/0/RP0/CPU0:router(config-pmap-c)# random-detect 1000000 2000000

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Congestion Avoidance Commands

service-policy (interface)

To attach a policy map to an input interface or output interface to be used as the service policy for that interface, use the service-policy command in the appropriate configuration mode. To remove a service policy from an input or output interface, use the no form of the command.

service-policy {input|output} policy-map no service-policy {input|output} policy-map

service-policy (interface)

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

Attaches the specified policy map to the input interface.input

Attaches the specified policy map to the output interface.output

policy-map

Name of a service policy map (created using the policy-map command) to be attached.

No service policy is specified.

Interface configuration.

ModificationRelease

This command was introduced.Release 6.0

You can attach a single policy map to one or more interfaces to specify the service policy for those interfaces. The class policies composing the policy map are then applied to packets that satisfy the class map match criteria for the class. To apply a new policy to an interface, you must remove the previous policy. A new policy cannot replace an existing policy.

OperationsTask

qos

read, write

Examples

This example shows policy map policy2 applied to HundredGigabitEthernet 0/0/0/1.

RP/0/RP0/CPU0:router(config)# class-map class2 RP/0/RP0/CPU0:router(config)# match precedence ipv4 2 RP/0/RP0/CPU0:router(config-cmap)# exit

RP/0/RP0/CPU0:router(config)# policy-map policy2 RP/0/RP0/CPU0:router(config-pmap)# class-map class2 RP/0/RP0/CPU0:router(config-pmap-c)# set precedence 3 RP/0/RP0/CPU0:router(config-pmap)# exit

RP/0/RP0/CPU0:router(config)# HundredGigabitEthernet 0/0/0/1 RP/0/RP0/CPU0:router(config-if)# service-policy input policy2

This example shows policy map policy 1 applied to Bundle-Ether interface.

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

service-policy (interface)

Congestion Avoidance Commands

RP/0/RP0/CPU0:router(config)# interface Bundle-Ether1 RP/0/RP0/CPU0:router(config-if)# service-policy input policy1 RP/0/RP0/CPU0:router(config-if)# exit

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Hierarchical Modular QoS Commands

Note

This chapter describes the commands used to manage hierarchical modular QoS.

• hw-module profile qos hqos-enable, on page 76

• hw-module profile qos max-trunks (hw-module profile bundle-scale), on page 77

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

hw-module profile qos hqos-enable

To enable H-QoS profile, use the hw-module profile qos hqos-enable command in XR Config mode. To remove the H-QoS profile, use the no form of the command.

hw-module profile qos hqos-enable

no hw-module profile qos hqos-enable

Hierarchical Modular QoS Commands

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

This command has no keywords or arguments.

H-QoS is disabled by default.

XR Config mode

ModificationRelease

This command was introduced.Release

6.3.1

After enabling H-QoS profile, the router must be reloaded.

OperationTask

qos

read, write

The following example shows how to enable the H-QoS profile on the router.

RP/0/RP0/CPU0:router#config RP/0/RP0/CPU0:router(config)# hw-module profile qos hqos-enable RP/0/RP0/CPU0:router(config)# commit RP/0/RP0/CPU0:router# reload

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Hierarchical Modular QoS Commands

hw-module profile qos max-trunks (hw-module profile bundle-scale)

To control the scale of bundle sub-interfaces and the number of members per bundle, use the hw-module profile qos max-trunks or hw-module profile bundle-scale (only from Release 6.5.1) command in XR

Config mode.

hw-module profile qos max-trunks {256|512|1024}

hw-module profile bundle-scale {256|512|1024}

Syntax Description

Command Default

Command Modes

Command History

Usage Guidelines

Task ID

Permits up to 128 bundle sub-interfaces, each containing up to 64 member-links256

Permits up to 384 bundle sub-interfaces, each containing up to 32 member-links.512

Permits up to 896 bundle sub-interfaces, each containing up to 16 member-links.1024

hw-module profile qos max-trunks 256, that is, permits up to 128 bundle sub-interfaces, each containing up to 64 member-links.

XR Config mode

ModificationRelease

This command was introduced.Release

6.3.1

Release

6.5.1

The router must be reloaded for the hw-module command to be functional.

The hw-module profile qos max-trunks <256/512/1024> command is replaced with the hw-module profile bundle-scale <256/512/1024> command

OperationTask

qos

The following example shows how to change the scale of bundle interfaces to 256.

RP/0/RP0/CPU0:router#config RP/0/RP0/CPU0:router(config)# hw-module profile qos hqos-enable RP/0/RP0/CPU0:router(config)#hw-module profile qos max-trunks 256 RP/0/RP0/CPU0:router(config)# commit RP/0/RP0/CPU0:router# reload

read, write

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

hw-module profile qos max-trunks (hw-module profile bundle-scale)

Hierarchical Modular QoS Commands

Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers

Cisco NCS 540 Series Routers, NCS 5500 Series Command Reference Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
