Cisco IE 4000 User Manual

Data Sheet

Feature

Benefit

Robust industrial design

●

Built for harsh environment and temperature range (-40 to 70 C).

●

Hardened for vibration, shock and surge, and noise immunity.

●

Resilient dual ring design via 4x Gigabit Ethernet uplink ports.

●

Complies with multi-industry specifications for automation, ITS, and substation environments.

●

Improves uptime, performance, and safety of industrial systems and equipment.

●

Fitted with compact, DIN rail compliant form factor ideal for industrial deployment.

●

Covers a wide range of Power over Ethernet (PoE) application requirements.

Cisco Industrial Ethernet 4000 Series Switches

Developed specifically to withstand the harshest industrial environments, these switches offer the most flexible and resilient industrial Ethernet products with secure connectivity, simple management and edge application execution.

Product overview

The Cisco® Industrial Ethernet (IE) 4000 Series delivers Gigabit connectivity to Cisco ruggedized switching portfolio with superior high-bandwidth switching capacity and proven Cisco IOS® Software. The IE 4000 Series provides highly secure access and industry-leading convergence ring protocols to support resilient and scalable networks while adhering to industry compliance requirements.

The IE 4000 Series is ideal for industrial Ethernet applications where hardened products are required, including manufacturing, energy, transportation, smart cities. The IE4000 has built-in SW image verification to ensure authenticity of the Cisco Software. With improved overall performance, greater bandwidth, advanced security features, and enhanced hardware, the Cisco IE 4000 Series complements the current industrial Ethernet portfolio of related Cisco industrial switches, such as the Cisco IE 2000 and IE 3000.

The IE 4000 Series can be used to easily and securely extend the enterprise network to harsh environments with a software-defined access extension for the Internet of Things (IoT) enabling connectivity in outdoor areas, warehouses, distribution centers, roadways, etc., using powerful enterprise-grade intent-based network management platform such as Cisco DNA™ Center.

The Cisco IE 4000 can easily be installed. with a GUI based Device Manager, it also offers out-of-the-box industrial usage configuration and simplified manageability to deliver advanced security, data, video, and voice services over industrial networks.

The IE 4000 executes edge applications using Cisco IOx to transform sensor data into insight and action. With Cisco IOx for customers take advantage of consistent, distributed computing across Cisco IoT network infrastructure. For more information on Cisco IOx, please see the Cisco IOx data sheet.

Features and benefits

Table 1 lists the features and benefits of Cisco IE 4000 Series Switches.

Table 1. Features and benefits of Cisco IE 4000 switches

Feature

Benefit

User-friendly GUI device manager

●

Allows easy configuration and monitoring via a web based device manager.

●

Eliminates the need for more complex terminal emulation programs.

●

Reduces the cost of deployment.

SwapDrive: “zero-config” replacement

●

Simple switch replacement in case of a failure.

●

No networking expertise required.

●

Helps ensure fast recovery.

High-density industrial Power over Ethernet (PoE)

●

Reduces complexity with one cable for both connectivity and power.

●

Controls costs by limiting wiring, distribution panels, and circuit breakers.

●

Creates space and reduces heat dissipation.

●

Enables ready-to-use PoE devices like IP phones and wireless access points.

●

Supports (on select models) maximum HD camera deployments.

●

Designed to support PoE power budget up to 240W(on select models)

Full Gigabit Ethernet switch

●

Connects new wireless access point (802.11n and 802.11ac).

●

Enables new HD IP Cameras and new PLC (Programmable Logic Control).

●

Allows SCADA (Supervisory Control And Data Acquisition) connectivity.

●

Provides introduction of new bandwidth-hungry applications in the industrial space.

●

Supports very-delay-sensitive applications and time-sensitive networks.

●

Delivers multiple rings, redundant ring topology for new network configurations.

●

Extends geographical scalability where longer distance connectivity is required.

Cisco IOx for Fog Compute applications

● Reach business outcomes associated with IoT initiatives with application execution close to edge network.

● Reach production scale rapidly by offering flexible application development and deployment approaches

●

Build new business with the ability to process high volumes of data close to network edge and deliver closedloop system control in real time.

Your ruggedized choice for industrial environments

The Cisco Industrial Ethernet (IE) 4000 Series offers:

●

Bandwidth and capacity to grow with your networking needs: 20-Gbps nonblocking switching capacity with up to 20 Gigabit Ethernet ports per switch

●

High-density industrial PoE/PoE+ support providing in-line power to up to 8 power devices, including IP cameras and phones, badge readers, wireless access points, etc.

●

Cisco IOS Software features for smooth IT integration and policy consistency

●

Robust resiliency enabled by dual ring design via 4x Gigabit Ethernet uplink ports, Resilient Ethernet Protocol (REP), Parallel Redundancy Protocol (PRP), PROFINET– Media Redundancy Protocol (MRP) ring, High Availability Seamless Redundancy (HSR) ring, EtherChannel and Flex Links support, redundant power input, dying gasp, etc.

●

True zero-touch replacement for middle-of-the-night or middle-of-nowhere failure

●

Line-rate, low-latency forwarding with advanced hardware assist features (such as NAT, IEEE1588)

●

Simplified software upgrade path with universal images

●

Support of Industrial automation protocols EtherNet/IP (CIP), PROFINET, and Modbus TCP

Product number

Total ports

GE combo uplinks (4G)1

Additional combo ports

RJ-45 copper ports (T)

SFP fiber ports (S)

PoE/PoE+ ports (P, GP)

Default software

IE-4000-4TC4G-E

8

All models have 4 GE combo uplink ports

4 (FE)

All models ship with LAN Base feature set

2

IE-4000-8T4G-E

12 8 (FE)

IE-4000-8S4G-E

12

8 (FE)

IE-4000-4T4P4G-E

12 4 (FE)

4 (FE)

IE-4000-16T4G-E

20 16 (FE)

IE-4000-4S8P4G-E

16

4 (FE)

8 (FE)

IE-4000-8GT4G-E

12 8 (GE)

IE-4000-8GS4G-E

12

8 (GE)

IE-4000-4GC4GP4G-E

12

4 (GE)

IE-4000-16GT4G-E

20 16 (GE)

IE-4000-8GT8GP4G-E

20 8 (GE)

8 (GE)

IE-4000-4GS8GP4G-E

16

4 (GE)

8 (GE)

Cisco ONE Software

Cisco ONE Software offers a simplified consumption model, centered on common customer scenarios in the industrial automation and extended enterprise environments. Cisco ONE Software and services provide customers with four primary benefits:

●

Software suites that address typical customer use scenarios at an attractive price

●

Investment protection for their software purchase through software services-enabled license portability

●

Access to ongoing innovation and new technology with Cisco Software Support Service (SWSS)

●

Flexible licensing models to smoothly distribute customers' software spending over time

Figure 1 shows the switch models, Table 2 lists all the available Cisco IE 4000 Series models, Table 3 lists the power supplies for Cisco IE 4000 Series Switches.

Figure 1. IE 4000 models

Table 2. Cisco IE 4000 Series Switches

1

Combo ports provide one copper and one fiber physical port and only one can be activated at a time.

2

Can be upgraded to IP Services at a fee. All copper Gigabit Ethernet interfaces support speed negotiation to 10/100/1000 mbps and duplex negotiation. All copper Fast Ethernet interfaces support speed negotiation to 10/100 mbps and duplex negotiation.

Product number

Wattage

Rated nominal input operating range

Supported input voltage operating range

power output

PoE/PoE+ support

Use case scenario

PWR-IE170W- PC-AC=

170W

AC 100-240V/2.3A 50-60Hz or DC 125-250V/2.1A

AC 90-264V or DC 106-300V

54VDC/3.15A

Yes

Maximum PoE/PoE+ port support in a AC or high DC environment1

PWR-IE170W- PC-DC=

170W

DC 12-54V/23A

DC 10.8-60V

54VDC/3.15A

Yes

Maximum PoE/PoE+ port support in a DC environment1

PWR-IE50W- AC=

50W

AC 100-240V/1.25A 50-60Hz or DC 125-250V/1.25A

AC 90-264V or DC 106-300V

24VDC/2.1A

No

No PoE/PoE+ support needed in an AC or DC environment

PWR-IE50W- AC-IEC=

50W

AC 100-240V/1.25A 50-60Hz

AC 90-264V

24VDC/2.1A

No

No PoE/PoE+ support needed when IEC plug is desired

PWR-IE65W- PC-AC=

65W

AC 100-240V/1.4A 50-60Hz or DC 125-250V/1.0A

AC 90-264V or DC 106-300V

54VDC/1.2 A

Yes

Minimum (1~2 port) PoE support needed in an AC or high DC environment2

PWR-IE65W- PC-DC=

65W

DC 24-48VDC/4.5A

DC 18-60V

54VDC/1.2 A

Yes

Minimum (1~2 port) PoE support needed in a DC environment2

Table 3. Power supplies for Cisco IE 4000 Series Switches

1

The entire power budget for the switch and PoE ports needs to stay within 170W. A PoE port draws up to 15.4W of power, and

a PoE+ port draws up to 30W of power.

2

The entire power budget for the switch and PoE ports needs to stay within 65W.

The diagram in Figure 2 can help you select a Cisco IE 4000 model.

Figure 2. Cisco IE 4000 model selection guide

Description

Specification

Hardware

●

1GB DRAM

●

128-MB onboard flash memory

●

1-GB removable SD flash memory card

●

Mini-USB connector

●

RJ-45 connector

Alarm ● Alarm I/O: two alarm inputs to detect dry contact open or closed, one alarm output relay

Power Input

●

Redundant DC input voltage with operating range: nominal 9.6 to 60VDC

●

Maximum DC input current:

3.7A - IE-4000-4T4P4G-E, IE-4000-8T4G-E, IE-4000-8GT4G-E, IE-4000-16T4G-E

4.3A - IE- 4000-4GC4GP4G-E, IE-4000-4TC4G-E, IE-4000-4S8P4G-E, IE-4000-4GS8GP4G-E, IE-4000-16GT4G-E, IE- 4000-8GT8GP4G-E 5A - IE-4000-8S4G-E, IE-4000-8GS4G-E

Power consumption

●

IE-4000-4T4P4G-E, IE-4000-8T4G-E, IE-4000-8GT4G-E, and IE-4000-16T4G-E: 35W

●

IE-4000-4GC4GP4G-E, IE-4000-4TC4G-E, IE-4000-4S8P4G-E, IE-4000-4GS8GP4G-E, and IE-4000-16GT4GE: 40W

●

IE-4000-8S4G-E, IE-4000-8GS4G-E: 42W

●

These numbers are measured at 9.6V and do not include PoE power consumption

Dimensions (H x W x D)

●

All IE 4000 models have the following dimensions: 6.12 x 6.12 x 5.09 in. (155.4 x 155.4 x 129.2 mm)

●

PWR-IE170W-PC-AC=: 5.93 x 3.72 x 5.60 in. (150.6 x 94.5 x 142.2)

●

PWR-IE170W-PC-DC=: 5.93 x 4.47 x 5.75 in. (150.6 x 113.5 x 145.8)

●

PWR-IE50W-AC=: 5.8 x 2.0 x 4.4 in. (147 x 51 x 112 mm)

●

PWR-IE50W-AC-IEC=: 5.8 x 2.0 x 4.4 in. (147 x 51 x 112 mm)

●

PWR-IE65W-PC-AC=: 5.9 x 2.6 x 4.6 in. (150 x 66 x 117 mm)

●

PWR-IE65W-PC-DC=: 5.9 x 2.6 x 4.6 in. (150 x 66 x 117 mm)

Weight ● All IE4000 models listed in Table 1: 6.35 pounds (2.88 kg)

●

PWR-IE170W-PC-AC=: 3.88 pounds (1.76 kg)

●

PWR-IE170W-PC-DC=: 3.7 pounds (1.67 kg)

●

PWR-IE50W-AC=: 1.4 lb (0.65 kg)

●

PWR-IE50W-AC-IEC=: 1.4 lb (0.65 kg)

●

PWR-IE65W-PC-DC=: 2.6 (1.18 Kg)

●

PWR-IE65W-PC-AC=: 2.7 (1.24 Kg)

Description

Specification

Forwarding rate

Line rate for all ports and all packet sizes

Number of queues

4 egress

Unicast MAC addresses

16,000

IGMP multicast groups

1,000

Number of VLANs

1,000

IPv4 MAC security ACEs

1,000 with default TCAM Template

NAT translation

Bidirectional, 128 unique subnet NAT translation entries, which can expand to tens of thousands of translated entries if designed properly

Product specifications

Table 4 lists specifications, Table 5 gives information about switch performance and scalability, Tables 6 and 7 list important software features. Table 8 provides information on software licenses and accessory PIDs.Tables 9–12 provide information about Cisco ONE™ licenses, DNA features and PIDs available for order, and Table 13 lists compliance specifications. Table 14 gives information about management and standards of the Cisco IE 4000 Series Switches, and Table 15 shows the list of supported SFPs.

Table 4. Product specifications

Table 5. Switch performance and scalability

LAN Base license (default)

Features

Layer 2 switching

IEEE 802.1, 802.3, 802.3at, 802.3af standard, VTPv2, NTP, UDLD, CDP, LLDP, Unicast Mac filter, Flexlink, Resilient Ethernet Protocol (REP), VTPv3, EtherChannel, Voice VLAN, qinq tunneling, Industrial macro configuration

Security

SCP, SSH, SNMPv3, TACACS+, RADIUS Server/Client, MAC Address Notification, BPDU Guard, Port-Security, Private VLAN, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard, 802.1x, Guest VLAN, MAC Authentication Bypass, 802.1x Multi-Domain Authentication, Storm Control, Trust Boundary, FIPS 140-2, ACT2, Secure boot, Full flexible Netflow2

Layer 2 multicast

IGMPv1, v2, v3 Snooping, IGMP filtering, IGMP Querier

Management

Fast Boot, Express setup, Web Device Manager, Industrial Network Director (IND), MIB, Smartport, SNMP, syslog, storm control, unicast, multicast, broadcast, SPAN sessions, RSPAN, DHCP server, customized DOM (digital optical management), Embedded Event Manager (EEM), Plug-n-Play Agent, Port-based DHCP

Industrial Ethernet

CIP Ethernet/IP, Profinet v2, IEEE 1588 PTP v2, NTP to PTP translation, CIP Time Sync

Quality of service

Ingress Policing, Rate-Limit, Egress Queueing/shaping, AutoQoS, QoS, PROFINET QoS

Layer 2 IPv6

IPv6 Host support, HTTP over IPv6, SNMP over IPv6

Layer 3 routing

IPv4 Static Routing

Industrial management

Layer 2 switching with 1:1 static Network Address Translation (NAT)

Redundancy

Redundancy Ethernet Protocol ring (REP) Parallel Redundancy Protocol (PRP) Media Redundancy Protocol (MRP) ring, MRP Auto Manager (MAM) High Availability Seamless Redundancy (HSR) HSR-PRP (Dual RedBox mode)

Utility

Power Profile, dying gasp, GOOSE messaging, SCADA protocol classification, MODBUS TCP/IP, utility SmartPort macro, BFD, Ethernet OAM, IEEE 802.3ah, CFM (IEEE 802.1ag)

IP Services license

Additional features

IP multicast

PIM sparse mode (PIM-SM), PIM dense mode (PIM-DM), and PIM sparse-dense mode

IP unicast routing protocols

OSPF, EIGRP, BGPv4, IS-IS, RIPv2, Policy-Based Routing (PBR), HSRP

Cisco Express forwarding

Hardware routing architecture delivers extremely high-performance IP routing

IPv6 routing

RIPng, OSPFv6, and EIGRPv6 support

Security

IEEE 802.1AE MACsec, Cisco TrustSec®, SGT inline tagging and SGACL,Full flexible Netflow

Virtualization

VRF-lite

License

Description

IE-LICENSE-SPARE

Spare license for software upgrade ( L2 to L3 features or MRP protocols)

L-IE4000-RTU=

IE4000 Electronic software license upgrade from LAN base L2 to IP Services L3 features

LIC-MRP-Manager=

MRP ring manager license

LIC-MRP-Client=

MRP ring client license

STK-RACK-DINRAIL=

19” DIN Rail mount kit

Table 6. Cisco IE 4000 LAN Base: Key software features

1

Support after product general availability.

2

Full flexible NetFlow is included on all IE-4000 Switches and requires either one of the following licenses per switch:

 Cisco ONE™ Foundation Perpetual license  DNA Essentials license  Cisco IP Services license

Table 7. Cisco IE 4000 IP Services: Key software features

Table 8. Cisco IE 4000 software licenses and accessories PIDs

Feature

Description

C1F1PIE4K5K1K9

Cisco ONE Foundation Lite Perpetual

Includes Prime Infrastructure (LF and AS), Identity Services Engine Base

C1F1PIE40001K9

Cisco ONE Foundation Perpetual

Includes Full flexible Netflow, Stealthwatch, Prime Infrastructure, and Identity Services Enginer - Base

C1A1PIE40001K9

Cisco ONE Advanced Perpetual

Includes IP Services

Feature

Description

Cisco DNA Center

Discovery, topology, inventory, software image management

Visibility

DNA assurance, full flexible Netflow, Device 360

Day-zero network bring-up automation

Cisco Network Plug-and-Play application

Feature

Description

DNA Essentials

All DNA Essentials features

Software-defined access

Policy based automation, IE 4000 can function as an SD-Access extended node

PID

Description

IE4000-DNA-E-L

DNA Essentials license(up to 12 ports)

IE4000-DNA-E-L-3Y

DNA Essentials 3 year term license(up to 12 ports) option

IE4000-DNA-E-L-5Y

DNA Essentials 5 year term license(up to 12 ports) option

IE4000-DNA-A-L

DNA Advantage license(up to 12 ports)

IE4000-DNA-A-L-3Y

DNA Advantage 3 year term license(up to 12 ports) option

IE4000-DNA-A-L-5Y

DNA Advantage 5 year term license(up to 12 ports) option

IE4000-DNA-E-M

DNA Essentials license(up to 24 ports)

IE4000-DNA-E-M-3Y

DNA Essentials 3 year term license(up to 24 ports) option

IE4000-DNA-E-M-5Y

DNA Essentials 5 year term license(up to 24 ports) option

IE4000-DNA-A-M

DNA Advantage license(up to 24 ports)

IE4000-DNA-A-M-3Y

DNA Advantage 3 year term license(up to 24 ports) option

IE4000-DNA-A-M-5Y

DNA Advantage 5 year term license(up to 24 ports) option

Type

Standards

Electromagnetic emissions

FCC 47 CFR Part 15 Class A EN 55022A Class A VCCI Class A AS/NZS CISPR 22 Class A CISPR 11 Class A CISPR 22 Class A ICES 003 Class A CNS13438 Class A KN22

Table 9. Cisco ONE™ Licenses

Table 10. Cisco IE 4000 DNA Essentials licenses

Table 11. Cisco IE 4000 DNA Advantage licenses

Table 12. Cisco IE 4000 DNA license PIDs

Table 13. Compliance Specifications

Type

Standards

Electromagnetic immunity

EN55024 CISPR 24 AS/NZS CISPR 24 KN24 EN 61000-4-2 Electro Static Discharge EN 61000-4-3 Radiated RF EN 61000-4-4 Electromagnetic Fast Transients N 61000-4-5 Surge EN 61000-4-6 Conducted RF EN 61000-4-8 Power Frequency Magnetic Field EN 61000-4-9 Pulse Magnetic Field EN 61000-4-11 AC Power Voltage EN 61000-4-18 Damped Oscillatory Wave EN-61000-4-29 DC Voltage Dips

Industry standards

EN 61000-6-1 Light Industrial EN 61000-6-2 Industrial EN 61000-6-4 Industrial EN 61326 Industrial Control EN 61131-2 Programmable Controllers Substation KEMA (IEEE 1613, IEC 61850-3) Marine DNV NEMA TS-2 (EMC, environmental, mechanical) IEEE 1613 Electric Power Stations Communications Networking IEC 61850-3 Electric Substations Communications Networking EN50155 Railway - Electronic Equipment on Rolling Stock (EMC, ENV, Mech) EN50121-4 Railway - Signaling and Telecommunications Apparatus EN50121-3-2 Railway - Apparatus for Rolling Stock ODVA Industrial EtherNet/IP PROFINET conformance B IP30 (per EN60529)

Safety standards and certifications

Information Technology Equipment:

UL/CSA 60950-1 EN 60950-1 CB to IEC 60950-1 with all country deviations NOM to NOM-019-SCFI (through partners and distributor)

Industrial Floor (Control Equipment):

UL 508 CSA C22.2, No 142

Hazardous Locations:

ANSI/ISA 12.12.01 CSA C22.2 No 213 IEC 60079-0, -15 IECEx test report EN 60079-0, -15 ATEX certification (Class I Zone 2) Cabinet enclosure required

Operating environment

Operating Temperature: -40C to +75C

●

-40C to +70C (Vented Enclosure Operating)

●

-40C to +60C (Sealed Enclosure Operating)

●

-34C to +75C (Fan or Blower equipped Enclosure Operating) EN 60068-2-1 EN 60068-2-2 EN 61163 Altitude: up to 15,000 feet

Storage environment

Temperature: -40 to +85 degrees C Altitude: 15,000 feet IEC 60068-2-14

Humidity

Relative humidity of 5% to 95% non-condensing IEC 60068-2-3 IEC 60068-2-30

Type

Standards

Shock and vibration

IEC 60068-2-27 (operational shock, 50G, 11ms, Half Sine) IEC 60068-2-27 (Non-Operational Shock, 65-80G, 9ms, Trapezoidal) IEC 60068-2-6, IEC 60068-2-64, EN 61373 (Operational Vibration) IEC 60068-2-6, IEC 60068-2-64, EN 61373 (Non-operational Vibration)

Corrosion

ISO 9223: Corrosion class C3-Medium class C4-High EN 60068-2-52 (Salt Fog) EN 60068-2-60 (Flowing Mixed Gas)

Others

RoHS Compliance China RoHS Compliance TAA (Government) CE (Europe)

Warranty

Five-year limited HW warranty on all IE-4000 PIDs and all IE Power Supplies (see table 3 above). See link below for more details on warranty

Mean time between failures (MTBF)

IE-4000-4TC4G-E: 578, 730 Hours IE-4000-8T4G-E: 591, 070 Hours IE-4000-8S4G-E: 583, 700 Hours IE-4000-4T4P4G-E: 562, 300 Hours IE-4000-16T4G-E: 558, 310 Hours IE-4000-4S8P4G-E: 535, 880 Hours IE-4000-8GT4G-E: 591, 240 Hours IE-4000-8GS4G-E: 583, 700 Hours IE-4000-4GC4GP4G-E: 550, 940 Hours IE-4000-16GT4G-E: 558, 630 Hours IE-4000-8GT8GP4G-E: 519, 190 Hours IE-4000-4GS8GP4G-E: 536, 220 Hours

Description

Specification

IEEE standards

●

IEEE 802.1D MAC Bridges, STP

●

IEEE 802.1p Layer2 COS prioritization

●

IEEE 802.1q VLAN

●

IEEE 802.1s Multiple Spanning-Trees

●

IEEE 802.1w Rapid Spanning-Tree

●

IEEE 802.1x Port Access Authentication

●

IEEE 802.1AB LLDP

●

IEEE 802.3ad Link Aggregation (LACP)

●

IEEE 802.3af Power over Ethernet provides up to

15.4W DC power to each end device

●

IEEE 802.3at Power over Ethernet provides up to

25.5W DC power to each end device

●

IEEE 802.3af Power over Ethernet

●

IEEE 802.3at Power over Ethernet Plus

●

IEEE 802.3ah 100BASE-X SMF/MMF only

●

IEEE 802.3x full duplex on 10BASE-T

●

IEEE 802.3 10BASE-T specification

●

IEEE 802.3u 100BASE-TX specification

●

IEEE 802.3ab 1000BASE-T specification

●

IEEE 802.3z 1000BASE-X specification

●

IEEE 1588v2 PTP Precision Time Protocol

●

IEEE 802.1AS PTP

●

IEEE 802.1Qbv TSN

RFC compliance

●

RFC 768: UDP

●

RFC 783: TFTP

●

RFC 791: IPv4 protocol

●

RFC 792: ICMP

●

RFC 793: TCP

●

RFC 826: ARP

●

RFC 854: Telnet

●

RFC 951: BOOTP

●

RFC 959: FTP

●

RFC 1157: SNMPv1

●

RFC 1901,1902-1907 SNMPv2

●

RFC 2273-2275: SNMPv3

●

RFC 1305: NTP

●

RFC 1492: TACACS+

●

RFC 1493: Bridge MIB Objects

●

RFC 1534: DHCP and BOOTP interoperation

●

RFC 1542: Bootstrap Protocol

●

RFC 1643: Ethernet Interface MIB

●

RFC 1757: RMON

●

RFC 2068: HTTP

●

RFC 2131, 2132: DHCP

●

RFC 2236: IGMP v2

●

RFC 3376: IGMP v3

●

RFC 2474: DiffServ Precedence

Table 14. Management and standards

Description

Specification

●

RFC 2571: SNMP Management

●

RFC 1166: IP Addresses

●

RFC 1256: ICMP Router Discovery

●

RFC 3046: DHCP Relay Agent Information Option

●

RFC 3580: 802.1x RADIUS

●

RFC 4250-4252 SSH Protocol

SNMP MIB objects

●

BRIDGE-MIB

●

CALISTA-DPA-MIB

●

CISCO-ACCESS-ENVMON-MIB

●

CISCO-ADMISSION-POLICY-MIB

●

CISCO-AUTH-FRAMEWORK-MIB

●

CISCO-BRIDGE-EXT-MIB

●

CISCO-BULK-FILE-MIB

●

CISCO-CABLE-DIAG-MIB

●

CISCO-CALLHOME-MIB

●

CISCO-CAR-MIB

●

CISCO-CDP-MIB

●

CISCO-CIRCUIT-INTERFACE-MIB

●

CISCO-CLUSTER-MIB

●

CISCO-CONFIG-COPY-MIB

●

CISCO-CONFIG-MAN-MIB

●

CISCO-DATA-COLLECTION-MIB

●

CISCO-DHCP-SNOOPING-MIB

●

CISCO-EMBEDDED-EVENT-MGR-MIB

●

CISCO-ENTITY-ALARM-MIB

●

CISCO-ENTITY-SENSOR-MIB

●

CISCO-ENTITY-VENDORTYPE-OID-MIB

●

CISCO-ENVMON-MIB

●

CISCO-ERR-DISABLE-MIB

●

CISCO-FLASH-MIB

●

CISCO-FTP-CLIENT-MIB

●

CISCO-IF-EXTENSION-MIB

●

CISCO-IGMP-FILTER-MIB

●

CISCO-IMAGE-MIB

●

CISCO-IP-STAT-MIB

●

CISCO-LAG-MIB

●

CISCO-LICENSE-MGMT-MIB

●

CISCO-MAC-AUTH-BYPASS-MIB

●

CISCO-MAC-NOTIFICATION-MIB

●

CISCO-MEMORY-POOL-MIB

●

CISCO-PAE-MIB

●

CISCO-PAGP-MIB

●

CISCO-PING-MIB

●

CISCO-PORT-QOS-MIB

●

CISCO-PORT-SECURITY-MIB

●

CISCO-PORT-STORM-CONTROL-MIB

●

CISCO-PRIVATE-VLAN-MIB

●

CISCO-PROCESS-MIB

●

CISCO-PRODUCTS-MIB

●

CISCO-RESILIENT-ETHERNET-PROTOCOL-MIB

●

CISCO-RTTMON-ICMP-MIB

●

CISCO-RTTMON-IP-EXT-MIB

●

CISCO-RTTMON-MIB

●

CISCO RTTMON-RTP-MIB

●

CISCO RTTMON-RTP-MIB

●

CISCO-SNMP-TARGET-EXT-MIB

●

CISCO-STACK-MIB

●

CISCO-STACKMAKER-MIB

●

CISCO-STP-EXTENSIONS-MIB

●

CISCO-SYSLOG-MIB

●

CISCO-TCP-MIB

●

CISCO-UDLDP-MIB

●

CISCO-VLAN-IFTABLE-RELATIONSHIP-MIB

●

CISCO-VLAN-MEMBERSHIP-MIB

●

CISCO-VTP-MIB

●

ENTITY-MIB

●

ETHERLIKE-MIB

●

HC-RMON-MIB

●

IEEE8021-PAE-MIB

●

IEEE8023-LAG-MIB

●

IF-MIB

●

IP-FORWARD-MIB

●

LLDP-EXT-MED-MIB

●

LLDP-EXT-PNO-MIB

●

LLDP-MIB

●

NETRANGER

●

NOTIFICATION-LOG-MIB

●

OLD-CISCO-CHASSIS-MIB

●

OLD-CISCO-CPU-MIB

●

OLD-CISCO-FLASH-MIB

●

OLD-CISCO-INTERFACES-MIB

●

OLD-CISCO-IP-MIB

●

OLD-CISCO-MEMORY-MIB

●

OLD-CISCO-SYS-MIB<

●

OLD-CISCO-SYSTEM-MIB

●

OLD-CISCO-TCP-MIB

●

OLD-CISCO-TS-MIB

●

RMON-MIB

●

RMON2-MIB

●

SMON-MIB

●

SNMP-COMMUNITY-MIB

●

SNMP-FRAMEWORK-MIB

●

SNMP-MPD-MIB

●

SNMP-NOTIFICATION-MIB

●

SNMP-PROXY-MIB

●

SNMP-TARGET-MIB

●

SNMP-USM-MIB

●

SNMP-VIEW-BASED-ACM-MIB

●

SNMPv2-MIB

●

TCP-MIB

●

UDP-MIB

Part number

Specification

SFP type

Max distance

Cable type

Temp range*

DOM support

GLC-FE-100FX-RGD=

100BASE-FX

FE

2km

MMF

IND

Yes

GLC-FE-100LX-RGD=

100BASE-LX10

FE

10km

SMF

IND

Yes

GLC-FE-100FX=

100BASE-FX

FE

2km

MMF

COM

No

GLC-FE-100LX=

100BASE-LX10

FE

10km

SMF

COM

No

GLC-FE-100EX=

100BASE-EX

FE

40km

SMF

COM

No

GLC-FE-100ZX=

100BASE-ZX

FE

80km

SMF

COM

No

GLC-FE-100BX-D=

100BASE-BX10

FE

10km

SMF

COM

No

GLC-FE-100BX-U=

100BASE-BX10

FE

10km

SMF

COM

Yes

GLC-SX-MM-RGD=

1000BASE-SX

GE

550m

MMF

IND

Yes

GLC-LX-SM-RGD=

1000BASE-LX/LH

GE

550m/10km

MMF/SMF

IND

Yes

GLC-ZX-SM-RGD=

1000BASE-ZX

GE

70km

SMF

IND

Yes

GLC-BX40-U-I=

1000BASE-BX40

GE

40km

SMF

IND

Yes

GLC-BX40-D-I=

1000BASE-BX40

GE

40km

SMF

IND

Yes

GLC-BX40-DA-I=

1000BASE-BX40

GE

40km

SMF

IND

Yes

GLC-BX80-U-I=

1000BASE-BX80

GE

80km

SMF

IND

Yes

GLC-BX80-D-I=

1000BASE-BX80

GE

80km

SMF

IND

Yes

GLC-SX-MMD=

1000BASE-SX

GE

550m

MMF

EXT

Yes

GLC-LH-SMD=

1000BASE-LX/LH

GE

550m/10km

MMF/SMF

EXT

Yes

GLC-EX-SMD=

1000BASE-EX

GE

40km

SMF

EXT

Yes

GLC-ZX-SMD=

1000BASE-ZX

GE

70km

SMF

EXT

Yes

GLC-BX-D=

1000BASE-BX10

GE

10km

SMF

COM

Yes

GLC-BX-U=

1000BASE-BX10

GE

10km

SMF

COM

Yes

CWDM-SFP-xxxx= (8 freq)

CWDM 1000BASE-X

GE SMF

COM

Yes

DWDM-SFP-xxxx= (40 freq)

DWDM 1000BASE-X

GE SMF

COM

Yes

SFP-GE-S=

1000BASE-SX

GE

550m

MMF

EXT

Yes

SFP-GE-L=

1000BASE-LX/LH

GE

550m/10km

MMF/SMF

EXT

Yes

SFP-GE-Z=

1000BASE-ZX

GE

70km

SMF

EXT

Yes

GLC-SX-MM=

1000BASE-SX

GE

550m

MMF

COM

No

GLC-LH-SM=

1000BASE-LX/LH

GE

550m/10km

MMF/SMF

COM

No

GLC-ZX-SM=

1000BASE-ZX

GE

70km

SMF

COM

Yes

GLC-TE=

1000BASE-T

GE

100m

Copper

EXT

NA

Table 15. SFP support

Note: Not all SFPs are supported in all software versions. For first software release supporting SFP, refer to

https://www.cisco.com/en/US/products/hw/modules/ps5455/products_device_support_tables_list.html.

Not all SFPs are supported in PROFINET GSD, SIMATIC STEP7/TIA Portal. Please visit

https://www.cisco.com/c/en/us/td/docs/switches/lan/industrial/software/configuration/guide/b_sfp_TIA.html.

*

If nonindustrial (EXT, COM) SFPs are used, the switch operating temperature must be derated.

MMF = multimode fiber SMF = single-mode fiber

Figure 3 shows the IE4000 mechanical dimensions.

Figure 3. IE-4000 dimensions

Warranty information

Warranty information for the IE 4000 is available on https://www.cisco-servicefinder.com/warrantyfinder.aspx.

Printed in USA C78-733058-14 04/18

Cisco Capital

Financing to help you achieve your objectives

Cisco Capital can help you acquire the technology you need to achieve your objectives and stay competitive. We can help you reduce CapEx. Accelerate your growth. Optimize your investment dollars and ROI. Cisco Capital financing gives you flexibility in acquiring hardware, software, services, and complementary third-party equipment.

And there’s just one predictable payment. Cisco Capital is available in more than 100 countries. Learn more.

Cisco IE 4000 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
