Cisco Ethernet switch Installation Manual
Cisco Systems Intelligent Gigabit Ethernet
Switch Module
for the IBM Eserver BladeCenter
Installation Gui de
Cisco Systems Intelligent Gigabit Ethernet
Switch Module
for the IBM Eserver BladeCenter
Installation Gui de
Note:
Before using this information and the product it supports, read the general information
in Appendix A, “IBM Statement of Limited Warranty Z125-4753-08 04/2004,” on page 41,
Appendix B, “Notices,” on page 65.
Fourth Edition (March 2005)
© Copyright International Business Machines Corporation 2005. All rights reserved.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by
GSA ADP Schedule Contract with IBM Corp.
Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . .v
Chapter 1. Introducing the Cisco Systems Intelligent Gigabit Ethernet
switch module . . . . . . . . . . . . . . . . . . . .1
Features and specifications . . . . . . . . . . . . . . . . . .2
Standards . . . . . . . . . . . . . . . . . . . . . . .7
Related documentation . . . . . . . . . . . . . . . . . . .7
Notices and statements used in this document . . . . . . . . . . .8
Major components of the Gigabit Ethernet switch module . . . . . . .9
Information panel overview . . . . . . . . . . . . . . . .10
LEDs . . . . . . . . . . . . . . . . . . . . . .11
External connections . . . . . . . . . . . . . . . . .12
Chapter 2. Installing and removing a Gigabit Ethernet switch module 13
Installation guidelines . . . . . . . . . . . . . . . . . . .13
System reliability considerations . . . . . . . . . . . . . .14
Handling static-sensitive devices . . . . . . . . . . . . . .14
Installing a Gigabit Ethernet switch module . . . . . . . . . . .14
Removing a Gigabit Ethernet switch module . . . . . . . . . . .16
Chapter 3. Configuring the Gigabit Ethernet switch module . . . . .19
Establishing a TCP/IP session for the Gigabit Ethernet switch module using
the management module . . . . . . . . . . . . . . . . .22
Enabling management over external ports . . . . . . . . . . . .23
Establishing a TCP/IP session for the switch through the external Gigabit
Ethernet switch module connectors . . . . . . . . . . . . .24
Configuring the Gigabit Ethernet switch module using Telnet . . . . .25
Connecting to the Gigabit Ethernet switch module . . . . . . . .25
Telnet usage conventions . . . . . . . . . . . . . . . . .25
Accessing the Gigabit Ethernet switch module command-line interface 26
Configuring the Gigabit Ethernet switch module using the serial-port
interface . . . . . . . . . . . . . . . . . . . . . .26
Configuring the Gigabit Ethernet switch module using the
management-module We b interface . . . . . . . . . . . . .27
Initial VLAN configuration . . . . . . . . . . . . . . . . .28
Chapter 4. Configuring Serial over Local Area Network . . . . . .29
Configuring SOL on the management module . . . . . . . . . . .29
Configuring SOL on the Gigabit Ethernet switch module . . . . . . .29
Chapter 5. Management-module software level . . . . . . . . .31
© Copyright IBM Corp. 2005 iii
Chapter 6. Updating the Gigabit Ethernet switch module software . . .33
Determining the level of Gigabit Ethernet switch module software . . . .33
Obtaining the latest level of switch software . . . . . . . . . . .33
Upgrading the Gigabit Ethernet switch module software . . . . . . .34
Resetting and restarting the Gigabit Ethernet switch module . . . . . .35
Chapter 7. Getting help and technical assistance . . . . . . . . .37
Before you call . . . . . . . . . . . . . . . . . . . . .37
Using the documentation . . . . . . . . . . . . . . . . . .37
Getting help and information from the World Wide We b . . . . . . .38
Software service and support . . . . . . . . . . . . . . . .38
Hardware service and support . . . . . . . . . . . . . . . .38
Chapter 8. Solving problems . . . . . . . . . . . . . . . .39
Running POST . . . . . . . . . . . . . . . . . . . . .39
POST errors . . . . . . . . . . . . . . . . . . . . . .39
Appendix A. IBM Statement of Limited Warranty Z125-4753-08 04/2004 41
Part 1 - General Terms . . . . . . . . . . . . . . . . . . .41
Part 2 - Country-unique Terms . . . . . . . . . . . . . . . .45
Part 3 - Warranty Information . . . . . . . . . . . . . . . .60
Appendix B. Notices . . . . . . . . . . . . . . . . . . .65
Edition notice . . . . . . . . . . . . . . . . . . . . .66
Trademarks . . . . . . . . . . . . . . . . . . . . . .66
Important notes . . . . . . . . . . . . . . . . . . . . .67
Product recycling and disposal . . . . . . . . . . . . . . . .68
Battery return program . . . . . . . . . . . . . . . . . .68
Electronic emission notices . . . . . . . . . . . . . . . . .69
Federal Communications Commission (FCC) statement . . . . . . .69
Industry Canada Class A emission compliance statement . . . . . .69
Australia and New Zealand Class A statement . . . . . . . . .70
United Kingdom telecommunications safety requirement . . . . . .70
European Union EMC Directive conformance statement . . . . . .70
Taiwanese Class A warning statement . . . . . . . . . . . .70
Chinese Class A warning statement . . . . . . . . . . . . .71
Japanese Voluntary Control Council for Interference (VCCI) statement 71
Index . . . . . . . . . . . . . . . . . . . . . . . .73
iv Cisco Systems Intelligent Gigabit Ethernet Switch Module: Installation Guide
Safety
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety
Information.
Avant d’installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.
Les sikkerhetsinformasjonen (Safety Information) før du installerer dette
produktet.
© Copyright IBM Corp. 2005 v
Antes de instalar este produto, leia as Informações sobre Segurança.
Antes de instalar este producto, lea la información de seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
vi Cisco Systems Intelligent Gigabit Ethernet Switch Module: Installation Guide
Statement 1:
DANGER
Electrical
current from power, telephone, and communication cables is
hazardous.
To avoid a shock hazard:
v Do not connect or disconnect any cables or perform installation,
maintenance, or reconfiguration of this product during an electrical
storm.
v Connect all power cords to a properly wired and grounded electrical
outlet.
v Connect to properly wired outlets any equipment that will be attached
to this product.
v When possible, use one hand only to connect or disconnect signal
cables.
v Never turn on any equipment when there is evidence of fire, water, or
structural damage.
v Disconnect the attached power cords, telecommunications systems,
networks, and modems before you open the device covers, unless
instructed otherwise in the installation and configuration procedures.
v Connect and disconnect cables as described in the following table
when installing, moving, or opening covers on this product or attached
devices.
To Connect: To Disconnect:
1. Turn everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn device ON.
1. Turn everything OFF.
2. First, remove power cords from outlet.
3. Remove signal cables from connectors.
4. Remove all cables from devices.
Safety vii
Statement 3:
CAUTION:
When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or
transmitters) are installed, note the following:
v Do not remove the covers. Removing the covers of the laser product could
result in exposure to hazardous laser radiation. There are no serviceable
parts inside the device.
v Use of controls or adjustments or performance of procedures other than
those specified herein might result in hazardous radiation exposure.
DANGER
Some
laser products contain an embedded Class 3A or Class 3B laser
diode. Note the following.
Laser radiation when open. Do not stare into the beam, do not view
directly with optical instruments, and avoid direct exposure to the beam.
Class 1 Laser Product
Laser Klasse 1
Laser Klass 1
Luokan 1 Laserlaite
Appareil A Laser de Classe 1
`
viii Cisco Systems Intelligent Gigabit Ethernet Switch Module: Installation Guide
Statement 5:
CAUTION:
The power control button on the device and the power switch on the power
supply do not turn off the electrical current supplied to the device. The
device also might have more than one power cord. To remove all electrical
current from the device, ensure that all power cords are disconnected from
the power source.
1
2
Statement 8:
CAUTION:
Never remove the cover on a power supply or any part that has the
following label attached.
Hazardous voltage, current, and energy levels are present inside any
component that has this label attached. There are no serviceable parts inside
these components. If you suspect a problem with one of these parts, contact
a service technician.
WARNING: Handling the cord on this product or cords associated with
accessories sold with this product, will expose you to lead, a chemical known
to the State of California to cause cancer, and birth defects or other
reproductive harm. Wash hands after handling.
ADVERTENCIA: El contacto con el cable de este producto o con cables de
accesorios que se venden junto con este producto, pueden exponerle al plomo,
Safety ix
un elemento químico que en el estado de California de los Estados Unidos está
considerado como un causante de cancer y de defectos congénitos, además de
otros riesgos reproductivos. Lávese las manos después de usar el producto.
x Cisco Systems Intelligent Gigabit Ethernet Switch Module: Installation Guide
Chapter 1. Introducing the Cisco Systems Intelligent
Gigabit Ethernet switch module
The Cisco Systems Intelligent Gigabit Ethernet Switch Module for the IBM
®
ER s e r v e r
®
BladeCenter
™
is an I/O module that is installed into a BladeCenter
unit. This Installation Guide contains information about installing and
configuring the Cisco Systems Intelligent Gigabit Ethernet Switch Module for
the IBM Eserver BladeCenter.
Note: Throughout this document, the Cisco Systems Intelligent Gigabit
Ethernet Switch Module for the IBM Eserver BladeCenter is referred to
as the Gigabit Ethernet switch module. Related documentation also
refers to the Cisco Systems Intelligent Gigabit Ethernet Switch Module
for the IBM Eserver BladeCenter as the IGESM.
For installation details, see Chapter 2, “Installing and removing a Gigabit
Ethernet switch module,” on page 13. For additional information, see the
instructions in the BladeCenter documentation.
This module supports Cisco IOS Release 12.1 (22) AY or later.
Note: The illustrations in this document might differ from your hardware.
You can obtain up-to-date information about the BladeCenter and other IBM
server products at http://www.ibm.com/pc/support. Record information
about your Gigabit Ethernet switch module in the following table:
Product name Cisco Systems Intelligent Gigabit Ethernet Switch Module
for the IBM Eserver BladeCenter
Serial number _________________________________________________
Media access
control (MAC)
address
_________________________________________________
The product name and serial number are on the identification label on the
Gigabit Ethernet switch module. Yo u will need this information when you
register your Gigabit Ethernet switch module with IBM. The media access
control (MAC) address is on a separate label on the information panel under
the external Ethernet port connectors.
© Copyright IBM Corp. 2005 1
See the following illustration for the locations of the identification label and the
MAC address label.
Note: The illustrations in this document might differ from your hardware.
Media access control
(MAC) address label
Product name
and serial
number label
Features and specifications
This section provides a summary of the features and specifications of the
Gigabit Ethernet switch module. For more information about the features, see
the Cisco Systems Intelligent Gigabit Ethernet Switch Modules for the IBM Eserver
BladeCenter Software Configuration Guide on the Documentation CD, and available
at http://www.ibm.com/pc/support.
The supported features and specifications for the Gigabit Ethernet switch
module are:
v Ports
– Four external 1000BASE-T connectors for making 10/100/1000 Mbps
connections to a backbone, end stations, and servers
– Fourteen internal full-duplex Gigabit ports, one connected to each of the
blade servers in the BladeCenter unit
– Two internal full-duplex 100 Mbps ports connected to the management
module
v
Performance features
– Autosensing of speed on the 10/100/1000 ports and auto-negotiation of
duplex mode on the ports for optimizing bandwidth
– Gigabit EtherChannel for enhanced fault-tolerance and for providing up
to 4 Gbps of bandwidth between switches, routers, and servers
– Support for standard frames with sizes from 64 to 1530 bytes and jumbo
frames with a maximum size of 9216
2 Cisco Systems Intelligent Gigabit Ethernet Switch Module: Installation Guide
– Per-port broadcast-storm control for preventing a faulty end station from
degrading overall system performance with broadcast storms
– Port Aggregation Protocol (PAgP) and Link Aggregation Control Protocol
(LACP) for automatic creation of EtherChannel links
– Internet Group Management Protocol (IGMP) snooping support to limit
flooding of IP multicast traffic
– Multicast Virtual Local Area Network (VLAN) registration (MVR) to
continuously send multicast streams in a multicast VLAN while isolating
the streams from subscriber VLANs for bandwidth and security
– IGMP filtering for controlling the set of multicast groups to which hosts
on a switch port can belong
– Protected port (private VLAN edge port) option for restricting the
forwarding of traffic to designated ports on the same switch
– Dynamic address learning for enhanced security
v
Manageability
– Address Resolution Protocol (ARP) for identifying a switch through its IP
address and its corresponding MAC address
– Cisco Discovery Protocol (CDP) versions 1 and 2 for network topology
discovery and mapping between the switch and other Cisco network
devices
– Network Time Protocol (NTP) for providing a consistent time stamp to all
switches from an external source
– Directed unicast requests to a Trivial File Transfer Protocol (TFTP) server
for obtaining software upgrades from a TFTP server
– Default configuration storage in flash memory to ensure that the switch
can be connected to a network and can forward traffic with minimal user
intervention
– In-band management access through the device manager management
software Web-interface session. Prior to this release in-band management
access was provided by the Cisco Management Suite (CMS)
– In-band management access through up to 16 simultaneous Telnet
connections for multiple command-line interface (CLI)-based sessions over
the network
– In-band management access through up to five simultaneous, encrypted
Secure Shell (SSH) connections for multiple CLI-based sessions over the
network. This option is available only in the cryptographic software
– In-band management access through SNMP versions 1, 2c, and 3 get and
set requests
Chapter 1. Introducing the Gigabit Ethernet switch module 3
v Redundancy
– Link state tracking to mirror the state of the external ports on the internal
Ethernet links and to allow the failover of the processor blade traffic to an
operational external link on a separate Cisco Ethernet switch.
– UniDirectional link detection (UDLD) on all Ethernet ports for detecting
and disabling unidirectional links caused by port faults
– IEEE 802.1D Spanning Tr ee Protocol (STP) for redundant backbone
connections and loop-free networks
– IEEE 802.1s Multiple STP (MSTP) for grouping VLANs into a
spanning-tree instance, and provided for multiple forwarding paths for
data traffic and load balancing
– IEEE 802.1w Rapid STP (RSTP) for rapid convergence of the spanning tree
by immediately transitioning root and designated ports to the converting
state
– Optional spanning-tree features available in the PVST+, rapid PVST+, and
MSTP modes
v
VLAN support
– Support for 250 port-based VLANs for assigning users to VLANs
associated with the applicable network resources, traffic patterns, and
bandwidth.
– Support for up to 4094 VLAN IDs to enable service provider networks to
support the number of VLANs allowed by the IEEE 802.1Q standard.
– IEEE 802.1Q trunking protocol on all ports for network moves, adds, and
changes; management and control of broadcast and multicast traffic; and
network security by establishing VLAN groups for high-security users
and network resources.
– VLAN Membership Policy Server (VMPS) for dynamic VLAN
membership.
– VLAN Trunking Protocol (VTP) pruning for reducing network traffic by
restricting flooded traffic to links destined for stations receiving the traffic.
– Dynamic Trunking Protocol (DTP) for negotiating trunking on a link
between two devices and for negotiating the type of trunking
encapsulation (802.1Q) to be used.
– Voice VLAN for creating subnets for voice traffic from Cisco IP phones
– VLAN 1 minimization to reduce the risk of spanning-tree loops or storms
by enabling VLAN 1 to be disabled on any individual VLAN trunk link.
With this feature enabled, no user traffic is sent or received. The switch
CPU continues to send and receive control protocol frames.
4 Cisco Systems Intelligent Gigabit Ethernet Switch Module: Installation Guide
v Security
– Bridge protocol data unit (BPDU) guard for shutting down a Port
Fast-configured port when an invalid configuration occurs
– Protected port option for restricting the forwarding of traffic to designated
ports on the same switch
– Password-protected access (read-only and write-only access) to
management interfaces (the device manager and CLI) for protection
against unauthorized configuration changes
– Port security option for limiting and identifying MAC addresses of the
station allowed to access the port
– Port security aging to set the aging time for secure addresses on a port
– Multilevel security for a choice of security level, notification, and resulting
actions
– MAC-based port-level security for restricting the use of a switch port to a
specific group of source addresses and preventing switch access from
unauthorized stations
– Terminal Access Controller Access Control System Plus (TACACS+), a
proprietary feature for managing network security through a TACACS
server
– IEEE 802.1X port-based authentication to prevent unauthorized devices
from gaining access to the network
– IEEE 802.1X port-based authentication with VLAN assignment for
restricting 802.1X-authenticated users to a specified VLAN
– IEEE 802.1X port-based authentication with port security for
authenticating the port and managing network access for all MAC
addresses, including that of the client
– IEEE 802.1X port-based authentication with voice VLAN to allow an IP
phone access to the voice VLAN irrespective of the authorized or
unauthorized state of the port
– IEEE 802.1X port-based authentication with guest VLAN to provided
limited services to non-802.1X-compliant users
– Standard and extended IP access control lists (ACLs) for defining security
policies
v
Quality of Service (QoS) and Class of Service (CoS)
– Classification
- IEEE 802.1p CoS with eight priority queues on the Gigabit Ethernet
switch-module ports for prioritizing mission-critical and time-sensitive
traffic from data, voice, and telephony applications
- IP Differentiated Services Code Point (IP DSCP) and CoS marking
priorities on a per-port basis for protecting the performance of
mission-critical applications
Chapter 1. Introducing the Gigabit Ethernet switch module 5
- Flow-based packet classification (classification based on information in
the MAC, IP, and TCP/UDP headers) for high-performance QoS at the
network edge, allowing for differentiated service levels for different
types of network traffic and for prioritizing mission-critical traffic in the
network
- Support for IEEE 802.1p CoS scheduling for classification and
preferential treatment of high-priority voice traffic
–
Egress policing and scheduling of egress queues – four egress queues on
all switch ports; support for strict priority and weighted round-robin
(WRR) CoS policies
– Source IP/Destination IP (SIP/DIP) address routing.
v
Monitoring
– Switch LEDs that provide visual port and switch status
– SPAN/RSPAN support for local and remote monitoring of the network
– Four groups (history, statistics, alarms, and events) of embedded remote
monitoring (RMON) agents for network monitoring and traffic analysis
– MAC address notification for tracking the MAC addresses that the switch
has learned or removed
– Syslog facility for logging system messages about authentication or
authorization errors, resource issues, and time out events
– Layer 2 trace route to identify the physical path that a packet takes from a
source device to a destination device
v
Network cables:
– 10BASE-T:
- UTP Category 3, 4, 5 (100 meters (328 feet) maximum)
- 100-ohm STP (100 meters maximum)
–
100BASE-TX:
- UTP Category 5 (100 meters maximum)
- EIA/TIA-568 100-ohm STP (100 meters maximum)
–
1000BASE-T:
- UTP Category 6 (standard for 1 GB devices)
- UTP Category 5e (100 meters maximum)
- UTP Category 5 (100 meters maximum)
- EIA/TIA-568B 100-ohm STP (100 meters maximum)
6 Cisco Systems Intelligent Gigabit Ethernet Switch Module: Installation Guide
Standards
The Gigabit Ethernet switch module supports the following standards:
v IEEE standards
– IEEE 802.1d Spanning Tr ee Protocol
– IEEE 802.1P Tagged Packets
– IEEE 802.1Q Tagged VLAN (frame tagging on all ports when VLANs are
enabled)
– IEEE 802.2 Logical Link Control
– IEEE 802.3 10BASE-T Ethernet
– IEEE 802.3u 100BASE-TX Fast Ethernet
– IEEE 802.3x Full-duplex Flow Control for external ports only
Related documentation
In addition to this document, the following related documentation is provided
in PDF format on the Documentation CD and available at
http://www.ibm.com/pc/support.
v Safety Information
This document is in Portable Document Format (PDF) on the Documentation
CD. It contains translated caution and danger statements. Each caution and
danger statement that appears in the documentation has a number that you
can use to locate the corresponding statement in your language in the Safety
Information document.
v Installation and User’s Guide for your BladeCenter unit type
This document contains general information about your BladeCenter unit,
including how to install options in the BladeCenter unit.
v Cisco Systems Intelligent Gigabit Ethernet Switch Modules for the IBM Eserver
BladeCenter Software Configuration Guide
This document contains software configuration information for the Gigabit
Ethernet switch module.
v Cisco Systems Intelligent Gigabit Ethernet Switch Modules System Message Guide
This document contains information about the switch-specific system
messages. During operation, the system software sends these messages to
the console or logging server on another system.
v Cisco Systems Intelligent Gigabit Ethernet Switch Modules System Command
Reference Guide
This document contains information about the command line interface (CLI)
commands, the CLI modes, and related commands.
v Cisco IOS Release 12.1 documentation at http://www.ibm.com/pc/support/
Chapter 1. Introducing the Gigabit Ethernet switch module 7
In addition to reviewing these documents, make sure to review the Planning
and Installation Guide for your BladeCenter unit type for information to help
you prepare for system installation and configuration.
To locate online BladeCenter documents, use the following procedures:
1. Go to http://www.ibm.com/pc/support/.
2. In the Learn section, click Online publications.
3. From the Brand menu, select Servers.
4. From the Family menu, select BladeCenter.
5. Click Continue and locate the Planning and Installation Guide for your
BladeCenter unit type.
For
BladeCenter units with 4 I/O-module bays, you must also install an
Ethernet-I/O card (also known as an Ethernet expansion card) in the blade
server to support the Gigabit Ethernet switch module in I/O-module bays 3 or
4. For information about the types of compatible I/O-expansion cards for the
blade servers, see the documentation that came with the BladeCenter unit.
Notices and statements used in this document
The caution and danger statements that appear in this document are also in
the multilingual Safety Information document, which is on the Documentation
CD. Each statement is numbered for reference to the corresponding statement
in the Safety Information document.
The following types of notices and statements are used in this document:
v Note: These notices provide important tips, guidance, or advice.
v Important: These notices provide information or advice that might help you
avoid inconvenient or problem situations.
v Attention: These notices indicate possible damage to programs, devices, or
data. An attention notice is placed just before the instruction or situation in
which damage could occur.
v Caution: These statements indicate situations that can be potentially
hazardous to you. A caution statement is placed just before the description
of a potentially hazardous procedure step or situation.
v Danger: These statements indicate situations that can be potentially lethal or
extremely hazardous to you. A danger statement is placed just before the
description of a potentially lethal or extremely hazardous procedure step or
situation.
8 Cisco Systems Intelligent Gigabit Ethernet Switch Module: Installation Guide
Major components of the Gigabit Ethernet switch module
Orange on the release latch on the Gigabit Ethernet switch module indicates
that the device can be hot-swapped, which means that you can install or
remove this component while the BladeCenter unit is on. See Chapter 2,
“Installing and removing a Gigabit Ethernet switch module,” on page 13 for
more information about installing and removing a Gigabit Ethernet switch
module.
Note: The illustrations in this document might differ from your hardware.
Media access control
(MAC) address label
Product name
and serial
number label
Ethernet ports (4)
Information panel
Release latch
Chapter 1. Introducing the Gigabit Ethernet switch module 9
Information panel overview
The information panel provides comprehensive LEDs, which display the status
of the Gigabit Ethernet switch module and the network (see “LEDs” on page
11) and external connections for the Gigabit Ethernet switch module. The
following illustration shows the information panel of the Gigabit Ethernet
switch module.
TX/RX
TX/RX
TX/RX
TX/RX
LINK
LINK
LINK
LINK
Connectors
LEDs
LEDs
OK
17
18
19
20
SYS
MGMT
Serial port
Notes:
1. The illustrations in this document might differ from your hardware.
2. An amber LED is lit when a system error or event has occurred. To identify
the error or event, check the LEDs on the information panel of the Gigabit
Ethernet switch module. For additional information, see Chapter 8, “Solving
problems,” on page 39.
10 Cisco Systems Intelligent Gigabit Ethernet Switch Module: Installation Guide
LEDs
In addition to the OK and Gigabit Ethernet switch module error (fault) LEDs
on the information panel each external port on the Gigabit Ethernet switch
module has an Ethernet Tx/Rx LED. The following illustration shows the
LEDs on the Gigabit Ethernet switch module. A description of each LED
follows the illustration.
OK
Ethernet link OK
Ethernet Tx/Rx
Gigabit Ethernet switch
module error
OK
17
18
19
20
TX/RX
TX/RX
TX/RX
TX/RX
LINK
LINK
LINK
LINK
SYS
MGMT
Serial port
OK: This green LED is on the left side of the information panel, above the four
external 10/100/1000 Mbps connectors. When this LED is lit, it indicates that
the Gigabit Ethernet switch module has passed the power-on self-test (POST)
with no critical faults and is operational.
Gigabit Ethernet switch module error (fault): This amber LED is on the right
side of the information panel, above the four external 10/100/1000 Mbps
connectors. When this LED is lit, it indicates that the Gigabit Ethernet switch
module has a fault. If the Gigabit Ethernet switch module fails the POST or
detects an operational fault, this LED is lit.
Note: When this LED is lit, the system-error LED on the BladeCenter unit is
also lit.
Ethernet link OK: This green link status LED is at the top of each external
10/100/1000 Mbps connector. When this LED is lit on a port, it indicates that
there is a connection (or link) to a device on that connector.
Ethernet Tx/Rx: This green activity LED is at the bottom of each external
10/100/1000 Mbps connector. When this LED flashes on a connector, it
indicates that data is being transmitted or received (that is, activity is
Chapter 1. Introducing the Gigabit Ethernet switch module 11
occurring) between that port and another device on the network link. The
flashing frequency is proportional to the amount of traffic on the network link.
External connections
The switch-module external connections include
v Four external 1000BASE-T Ethernet connectors for connecting to external
Ethernet devices, such as backbones, end stations, and servers. These
connectors are identified as ports 17, 18, 19, and 20 in the switch
configuration menus and are labeled 17 through 20 (from top to bottom) on
the Gigabit Ethernet switch module.
v Serial port RS-232 connector for local console port connections.
12 Cisco Systems Intelligent Gigabit Ethernet Switch Module: Installation Guide
Chapter 2. Installing and removing a Gigabit Ethernet
switch module
Attention: To maintain proper system cooling, each I/O-module bay must
contain either a module or a filler module; each blade bay must contain either
a blade or a filler blade.
The BladeCenter unit supports one hot-plug Gigabit Ethernet switch module,
in I/O-module bay 1. The Gigabit Ethernet switch modules in I/O-module
bays 1 and 2 are for the integrated Ethernet controllers or Fibre Channel
expansion modules in the blade servers. You might want to install Gigabit
Ethernet switch modules in other I/O-module bays of the BladeCenter unit
when additional Ethernet or fiber controllers are installed or activated.
For additional information about the location of the Gigabit Ethernet switch
module, the network interface requirements, and expansion options, see the
documentation that came with the BladeCenter unit.
Installation guidelines
Before you begin to install the Gigabit Ethernet switch module in the
BladeCenter unit, read the following information:
v Read the safety information beginning on page v and the guidelines in
“Handling static-sensitive devices” on page 14, and read the safety
statements in the BladeCenter unit documents.
v Orange on the release latch on the Gigabit Ethernet switch module indicates
that the device can be hot-swapped, which means that you can install or
remove this component while the BladeCenter unit is on. See the instructions
in this chapter for more information about installing or removing hot-swap
or hot-plug components.
v You do not have to turn off the BladeCenter unit to install or replace any of
the hot-swap modules on the rear of the unit.
v If you plan to install a Gigabit Ethernet switch module in I/O-module bay 3
or 4 of the BladeCenter unit, you must also install an I/O expansion card in
the blade server to support the Gigabit Ethernet switch modules in these
bays.
© Copyright IBM Corp. 2005 13
System reliability considerations
To help ensure proper cooling and system reliability, make sure that:
v Each of the I/O-module bays on the rear of the BladeCenter unit has either a
module or a filler module installed.
v A removed hot-swap module or blade server is replaced with another
module or filler module within 1 minute of removal.
Handling static-sensitive devices
Attention: Static electricity can damage electronic devices. To avoid damage,
keep static-sensitive devices in their static-protective packages until you are
ready to install them.
To reduce the possibility of electrostatic discharge, observe the following
precautions:
v Limit your movement. Movement can cause static electricity to build up
around you.
v Handle the device carefully, holding it by its edges or its frame.
v Do not touch solder joints, pins, or exposed printed circuitry.
v Do not leave the device where others can handle and damage it.
v While the device is still in its static-protective package, touch it to any
unpainted metal surface of the BladeCenter unit or any unpainted metal
surface on any other grounded rack component for at least 2 seconds. (This
drains static electricity from the package and from your body.)
v Remove the device from its package and install it directly into the
BladeCenter unit without setting it down. If it is necessary to set down the
device, put it back into its static-protective package. Do not place the device
on the BladeCenter unit or on a metal surface.
v Take additional care when handling devices during cold weather. Heating
reduces indoor humidity and increases static electricity.
Installing a Gigabit Ethernet switch module
To install a Gigabit Ethernet switch module, complete the following steps:
1. Read the safety information beginning on page v and “Installation
guidelines” on page 13.
2. Remove the acoustic attenuation module, if one is installed, from the rear
of the BladeCenter unit. For more information, see the documentation that
came with the BladeCenter unit.
3. Select an I/O-module bay in which to install the Gigabit Ethernet switch
module.
14 Cisco Systems Intelligent Gigabit Ethernet Switch Module: Installation Guide
Note: For details about I/O-module bay requirements, see the
BladeCenter documents that came with your BladeCenter unit.
4. Remove the filler module from the selected bay. Store the filler module for
future use.
5. If you have not already done so, touch the static-protective package that
contains the Gigabit Ethernet switch module to any unpainted metal
surface of the BladeCenter unit or any unpainted metal surface on any
other grounded rack-component for at least 2 seconds.
6. Remove the Gigabit Ethernet switch module from its static-protective
package.
7. Make sure that the release latch on the Gigabit Ethernet switch module is
in the open position (perpendicular to the module).
8. Slide the Gigabit Ethernet switch module into the applicable I/O-module
bay until it stops.
I/O module
Release latch
9. Push the release latch on the front of the Gigabit Ethernet switch module
to the closed position. After you insert and lock the Gigabit Ethernet
switch module, it is turned on, and the power-on self-test (POST) runs to
verify that the Gigabit Ethernet switch module is operating correctly. The
POST results are displayed by the status LEDs.
10. Make sure that the LEDs on the Gigabit Ethernet switch module indicate
that it is operating correctly. Make sure that the OK LED on each Gigabit
Ethernet switch module is lit. See “LEDs” on page 11 for a description of
the operation of these LEDs.
Chapter 2. Installing and removing a Gigabit Ethernet switch module 15
