DATA SHEET
CISCO 100BASE-X SFP FOR FAST ETHERNET SFP PORTS
PRODUCT OVERVIEW
The Cisco® 100BASE-X Small Form-factor Pluggable (SFP) is a hot-swappable input/output device that plugs into a Fast Ethernet port or slot,
linking the port with the network.
Main features include the following:
• Hot-swappable when deployed, the switch or router does not have to reboot.
• Supports the “pay-as-you-populate” model.
• Interchangeable with other 100BASE-X SFPs on the same line card.
• Supports the Cisco quality ID feature that enables the switch or router to identify whether or not the SFP is a Cisco qualified SFP.
• Optically interoperable with respective 100BASE-X Ethernet interfaces on the same link.
Figure 1. Cisco 100M Ethernet SFP
Cisco 100BASE-FX SFP
The Cisco 100BASE-FX SFP (part number GLC-FE-100FX) operates on ordinary multimode fiber-optic (MMF) link spans up to 2 kilometers long.
Cisco 100BASE-LX10 SFP
The Cisco 100BASE-LX10 SFP (part number GLC-FE-100LX) operates on ordinary single-mode fiber-optic (SMF) link spans up to 10 kilometers
long.
Cisco 100BASE-BX10 SFP
The Cisco 100BASE-BX10 (part numbers GLC-FE-100BX-D and GLC-FE-100BX-U) SFPs operate on ordinary SMF single-strand link spans up
to 10 kilometers long.
TECHNICAL SPECIFICATIONS
Platform Support
The Cisco SFPs are supported across a variety of Cisco Systems® switches, routers, and optical transport devices. For more details, refer to the
document Cisco 100M Ethernet SFP Compatibility Matrix.
All contents are Copyright © 1992–2004 Cisco Systems, Inc. All rights reserved. Important Notices and Privacy Statement.
Page 1 of 1
Connectors and Cabling
• Connectors: Dual LC connector (GLC-FE-100FX and GLC-FE-100LX) or single LC connector (GLC-FE-BX-D and GLC-FE-BX-U)
Table 1 provides cabling specifications for the SFPs for installation in a Fast Ethernet SFP port. Note that all SFP ports have LC-type connectors,
and the minimum cable distance for all SFPs listed (MMF and SMF [G.652] is 2 meters [6.5 feet]).
Table 1. SFP Port Cabling Specifications
SFP Wavelength (nm) Fiber Type Cable Distance
GLC-FE-100FX 1310 MMF 2 km (6562 ft)
GLC-FE-100LX 1310 SMF 10 km (32,810 ft)
GLC-FE-100BX-U 1310 SMF 10 km (32,810 ft)
GLC-FE-100BX-D 1550 SMF 10 km (32,810 ft)
Standards
• Compatible with IEEE 802.3ah Draft 3.0
• Compatible with standard as specified in IEEE 802.3
Table 2 gives information about fiber loss.
Table 2. Fiber-Loss Budgets
SFP Type
GLC-FE-100FX 100BASE-FX
GLC-FE-100LX 100BASE-LX10
GLC-FE-100BX-U 100BASE-BX10-U
GLC-FE-100BX-D 100BASE-BX10-D
Dimensions
• Dimensions (H x W x D): 8.5 x 13.4 x 56.5 mm
Environmental Conditions and Power Requirements
• Operating temperature range: 0 to 50°C (32 to 122°F)
• Storage temperature range: –40 to 85°C (–40 to 185°F)
Transmit (dBm) Receive (dBm)
Maximum Minimum Maximum Minimum
–14 –20 –14 –31
–8 –15 –8 –28
–8 –14 –7 –28.2
–8 –14 –7 –28.2
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com.
© 2004 Cisco Systems, Inc. All rights reserved.
Page 2 of 5
Table 3. Electrical Power Interface
Parameter Symbol Minimum Typical Maximum Units
Supply Current Is – 200 300 mA
Surge Current I
Input Voltage Vcc 3.1 3.3 3.5 V
Warranty
• Standard warranty: 90 days
• Extended warranty (option): Available under a Cisco SMARTnet™ support contract for the Cisco switch or router chassis
ORDERING INFORMATION
Table 4 gives ordering information for the Cisco SFP.
Surge
– – 30 mA
Table 4. Ordering Cisco SFP
Product Number SFP
GLC-FE-100FX 100BASE-FX SFP for Fast Ethernet SFP ports
GLC-FE-100LX 100BASE-LX10 SFP for Fast Ethernet SFP ports
GLC-FE-100BX-U 100BASE-BX10-U SFP for Fast Ethernet SFP ports
GLC-FE-100BX-D 100BASE-BX10-D SFP for Fast Ethernet SFP ports
Regulatory and Standards Compliance
Safety
• Laser Class 1 21CFR1040
ADDITIONAL INFORMATION
For more information about Cisco 100BASE-X SFPs for Fast Ethernet SFP ports, contact:
• United States and Canada: 800 553-6387
• Europe: 32 2 778 4242
• Australia: 61 2 9935 4107
• Other: 408 526-7209
• http://www.cisco.com
