CISCO CISCO CBS224FP4X Datasheet

Cisco Business 220 Series
Data sheet
Smart Switches
© 2021 Cisco and/or its affiliates. All rights reserved. Page 1 of 23
Contents
Value statement 3
Product overview 3
Prominent feature 4
Product sustainability 6
Product specifications 7
System requirements 19
Ordering information 20
Warranty information 22
Cisco and partner services 22
Cisco Capital 22
Custom call to action 22
© 2021 Cisco and/or its affiliates. All rights reserved. Page 2 of 23
Value statement
Simple, affordable business networking
Product overview
From connectivity to cloud applications, networking plays a crucial role in every business journey. Reliability, security, and affordability continue to be priorities, while ongoing management and operations add additional complexity that takes time and resources.
Cisco Business is a portfolio of affordable wireless access points, switches, and routers designed and built for Small Business. Managed through Cisco Business Dashboard and mobile app, the portfolio provides a simple and reliable experience. Cisco Business Dashboard simplifies traditional challenges in deploying and managing business networks by automating the deployment, monitoring, and lifecycle management of the network.
Cisco Business 220 Series Smart Switches
The Cisco Business 220 Series are affordable smart switches with ease of use, security, and reliability for business-class networks. With intuitive dashboard, Power over Ethernet (PoE) options, and customizable features, these switches deliver a solid business network within your budget parameters. When you need a business-class network and cost is top priority, Cisco Business 220 Series provides an excellent solution.
© 2021 Cisco and/or its affiliates. All rights reserved. Page 3 of 23
Prominent feature
Business Applications
With Cisco Business 220 Series switches, you can not only build an efficient and reliable network to connect the workforce, you can also create advanced solutions to deliver data, voice, and video services on a converged infrastructure. Get the best value for your money by improving the productivity of employees. Possible deployment scenarios include:
Small office networking: The versatility and affordability of the Cisco Business 220 Series family of switches provide an ideal business-class networking foundation for small businesses with limited IT support and budget.
Wireless connectivity. With PoE+ support, and comprehensive security and Quality of Service (QoS) capabilities, Cisco Business 220 Series switches provide a solid foundation to add business-grade wireless to the network. You can easily deploy Cisco Business wireless access points to increase workforce productivity without worrying about power and throughput.
Unified communications. The Cisco Business 220 Series switches provide QoS features to automatically prioritize delay-sensitive traffic to help you easily deploy an IP-based communication solution on a converged network. PoE+ support can enable IP cameras and videophones to be easily added to your current network. Cisco offers a complete portfolio of IP telephony and other unified communications products designed for small businesses. Cisco Business 220 Series switches have been rigorously tested to help ensure easy integration and full compatibility with these and other vendor products.
Features and benefits
Cisco Business 220 Series provides capabilities that help you create business-class networks. These features deliver a solution to simplify the operation, increase uptime, and get your business better connected to employees, customers, and suppliers. Some primary features include:
Easy configuration and deployment. Cisco Business 220 Series switches are designed to be easy to deploy and use by small businesses and the partners that manage them. Other ease-of-use features include the following:
Cisco Business Dashboard is designed to manage Cisco Business switches, routers, and wireless
access points. Using the Dashboard, you easily customize the interface and widgets to proactively manage your network. Cisco Business 220 Series switches connect directly to Cisco Business Dashboard, eliminating the need to set up separate hardware or a virtual machine on site. For more information, visit https://www.cisco.com/go/cbd.
The Cisco Network Plug and Play solution provides a simple, secure, unified, and integrated offering
to ease new device rollouts, as well as provisioning updates to an existing network. The solution provides a unified approach to provision Cisco routers, switches, and wireless devices with a zero touch deployment experience.
The simple and intuitive web-based interfaces enable users without extensive IT expertise to
configure, manage, and troubleshoot the switch in minutes. Configuration wizards simplify the most common configuration tasks and provide the tool for anyone to set up and manage the network.
© 2021 Cisco and/or its affiliates. All rights reserved. Page 4 of 23
Reliability and performance. Cisco Business 220 Series switches have been tested to deliver the high availability and performance that users have come to expect from Cisco switches. The switches speed up file transfer times, keep vital business applications available, and help your employees respond more quickly to customers and each other. With enhanced QoS capabilities, the Cisco Business 220 Series also gives you the flexibility to manage and prioritize high-bandwidth traffic so you can easily integrate all the business communications and connectivity needs on a single converged infrastructure.
Power over Ethernet (PoE). PoE+ streamlines the deployment for wireless access points, IP telephony, and video surveillance by allowing power and data to run over a single network cable. Cisco Business 220 Series switches support PoE+, which provides up to 30 watts of power per port. PoE+ can enable deployments for 802.11ac wireless access points, Pan Tilt Zoom (PTZ) IP cameras, and videophones, delivering more flexibility and investment protection.
Network security. The Cisco Business 220 Series switches provide new levels of security for smart switches and deliver more ways to safeguard your network.
Support for network security applications such as the Institute for Electrical and Electronic Engineers
(IEEE) 802.1X and port security can tightly limit access to specific segments of your network.
Extensive Access Control Lists (ACLs) can restrict sensitive portions of the network from unauthorized
users and guard against network attacks.
Security mechanisms such as broadcast/multicast/unknown unicast storm control and Bridge Protocol
Data Unit (BPDU) guard can protect the network from invalid configurations or malicious intent.
Denial-of-Service (DOS) attack prevention helps to increase uptime in the event of a network attack.
Optimal energy efficiency. Cisco Business 220 Series switches are designed with Energy Efficient Ethernet (IEEE 802.3az) and Energy Detect support on all models, as well as fanless designs on selected models. These designs help you save operational expenses and reduce your environmental footprint.
Peace of mind and investment protection. Cisco Business 220 Series switches offer the reliable performance, investment protection, and peace of mind you expect from a Cisco switch. Complementary one-year access to our Small Business Support Center provides ongoing support. The 3-year limited hardware warranty with return to factory replacement keeps your business running smoothly.
© 2021 Cisco and/or its affiliates. All rights reserved. Page 5 of 23
Sustainability Topic
Reference
General
Information on product-material-content laws and regulations
Materials
Information on electronic waste laws and regulations, including our products, batteries and packaging
WEEE Compliance
Information on product takeback and reuse program
Cisco Takeback and Reuse Program
Sustainability Inquiries
Contact: csr_inquiries@cisco.com
Environment (unit dimensions, unit weight, power, certifications, operating temperature, storage temperature, operating humidity, storage humidity)
Table2. Product Specifications
Accoustic noise and Mean Time Before Failure
Table2. Product Specifications
Power
Power Efficiency
Features and Benefits
Table2. Product Specifications
Power Consumption
Table2. Product Specifications
Material
Product packaging weight and materials
Contact: environment@cisco.com
Package Contents
Table2. Product Specifications
Product sustainability
Information about Cisco’s environmental, Social and Governance (ESG) initiatives and performance is provided in Cisco’s CSR and sustainability reporting.
Table 1. Cisco environmental sustainability information
© 2021 Cisco and/or its affiliates. All rights reserved. Page 6 of 23
Feature
Description
Performance
Switching capacity
Model name
Forwarding rate in millions of packets per second (mpps; 64-byte packets)
Switching capacity in Gigabits per second (Gbps)
CBS220-8T-E-2G
14.88
20
CBS220-8P-E-2G
14.88
20
CBS220-8FP-E-2G
14.88
20
CBS220-16T-2G
26.78
36
CBS220-16P-2G
26.78
36
CBS220-24T-4G
41.66
56
CBS220-24P-4G
41.66
56
CBS220-24FP-4G
41.66
56
CBS220-48T-4G
74.38
104
CBS220-48P-4G
74.38
104
CBS220-24T-4X
95.23
128
CBS220-24P-4X
95.23
128
CBS220-24FP-4X
95.23
128
CBS220-48T-4X
130.94
176
CBS220-48P-4X
130.94
176
CBS220-48FP-4X
130.94
176
Product specifications
Table 2 lists the product specifications for the Cisco Business 220 Series Smart Switches.
Table 2. Product specifications
© 2021 Cisco and/or its affiliates. All rights reserved. Page 7 of 23
Feature
Description
Layer 2 switching
MAC table
Up to 8,192 Media Access Control (MAC) addresses
Spanning Tree Protocol (STP)
Standard 802.1d Spanning Tree support, enabled by default
Fast convergence using 802.1w (Rapid Spanning Tree [RSTP])
Multiple Spanning Tree instances using 802.1s (MSTP)
16 instances are supported
Port grouping
Support for IEEE 802.3ad Link Aggregation Control Protocol (LACP)
Up to 8 groups
Up to 8 ports per group with 16 candidate ports for each (dynamic) 802.3ad link aggregation
Load balance based on source and destination MAC address, or source and destination MAC/IP
VLAN
Support for up to 256 Virtual Local Area Networks (VLANs) simultaneously
Port-based and 802.1Q tag-based VLANs
Management VLAN
Guest VLAN
Auto voice VLAN
Voice traffic is automatically assigned to a voice-specific VLAN and treated with appropriate levels of QoS
QinQ VLAN
VLANs transparently cross a service provider network while isolating traffic among customers
Generic VLAN Registration Protocol (GVRP) and Generic Attribute Registration Protocol (GARP)
Protocols for automatically propagating and configuring VLANs in a bridged domain
Head-of-Line (HOL) blocking
HOL blocking prevention
Jumbo frame
Frame sizes up to 9,216 supported
Loopback detection
Loopback detection provides protection against loops by transmitting loop protocol packets out of ports on which loop protection has been enabled. It operates independently of STP.
Automatic Media­Dependent Interface Crossover (MDIX)
Automatically adjusts transmit and receive pairs if an incorrect cable type (crossover or straight­through) is installed.
© 2021 Cisco and/or its affiliates. All rights reserved. Page 8 of 23
Feature
Description
Security
ACLs
Drop or rate limit based on source and destination MAC, VLAN ID or IP address, protocol, port, Differentiated Services Code Point (DSCP)/IP precedence, Transmission Control Protocol (TCP)/ User Datagram Protocol (UDP) source and destination ports, 802.1p priority, Ethernet type, Internet Control Message Protocol (ICMP) packets, Internet Group Management Protocol (IGMP) packets, TCP flag
Support up to 512 rules
Port security
Creates the ability to lock source MAC addresses to ports; limits the number of learned MAC addresses
IEEE 802.1X (authenticator role)
802.1X: Remote Authentication Dial-in User Service (RADIUS) authentication; guest VLAN;
Single-host, multiple-host, and multisession mode
RADIUS, TACACS+
Supports RADIUS and Terminal Access Controller Access Control System (TACACS) authentication; switch functions as a client
MAC address filtering
Supported
Storm control
Broadcast, multicast, and unknown unicast
DoS protection
DOS attack prevention
STP Bridge Protocol Data Unit (BPDU) Guard
This security mechanism protects the network from invalid configurations. A port enabled for BPDU Guard is shut down if a BPDU message is received on that port.
Spanning Tree Loop Guard
This feature provides additional protection against Layer 2 forwarding loops (STP loops).
Secure Shell (SSH) Protocol
SSH is a secure replacement for Telnet traffic. SCP also uses SSH. SSH v1 and v2 are supported.
Secure Sockets Layer (SSL)
SSL support: Encrypts all HTTPS traffic, allowing highly secure access to the browser-based management GUI in the switch
QoS
Priority levels
8 hardware queues per port
Scheduling
Strict priority and Weighted Round-Robin (WRR) queue assignment based on DSCP and class of service (802.1p/CoS)
Class of service
Port-based; 802.1p VLAN priority-based; IPv4/v6 IP precedence, Type of Service (ToS), and DSCP-based; Differentiated Services (DiffServ); classification and re-marking ACLs, trusted QoS
Rate limiting
Ingress policer; egress shaping and rate control; per VLAN, per port, and flow-based
Congestion avoidance
A TCP congestion avoidance algorithm is required to reduce and prevent global TCP loss synchronization.
© 2021 Cisco and/or its affiliates. All rights reserved. Page 9 of 23
Feature
Description
Multicast
Internet Group Management Protocol (IGMP) Versions 1, 2, and 3 Snooping
IGMP limits bandwidth-intensive multicast traffic to only the requesters; supports 256 multicast groups
IGMP querier
IGMP querier is used to support a Layer 2 multicast domain of snooping switches in the absence of a multicast router
Standards
Standards
IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab
1000BASE-T Gigabit Ethernet, IEEE 802.3ad LACP, IEEE 802.3z Gigabit Ethernet, IEEE
802.3x Flow Control, IEEE 802.1D (STP, GARP, and GVRP), IEEE 802.1Q/p VLAN, IEEE
802.1w RSTP, IEEE 802.1s Multiple STP, IEEE 802.1X Port Access Authentication, IEEE
802.3af, IEEE 802.3at, RFC 768, Request for Comments (RFC) 783, RFC 791, RFC 792, RFC 793, RFC 813, RFC 879, RFC 896, RFC 826, RFC 854, RFC 855, RFC 856, RFC 858, RFC 894, RFC 919, RFC 922, RFC 920, RFC 950, RFC 1042, RFC 1071, RFC 1123, RFC 1141, RFC 1155, RFC 1157, RFC
1350, RFC 1533, RFC 1541, RFC 1624, RFC 1700, RFC 1867, RFC 2030, RFC 2616, RFC
2131, RFC 2132, RFC 3164, RFC 3411, RFC 3412, RFC 3413, RFC 3414, RFC 3415, RFC
2576, RFC 4330, RFC 1213, RFC 1215, RFC 1286, RFC 1442, RFC 1451, RFC 1493, RFC
1573, RFC 1643, RFC 1757, RFC 1907, RFC 2011, RFC 2012, RFC 2013, RFC 2233, RFC
2618, RFC 2665, RFC 2666, RFC 2674, RFC 2737, RFC 2819, RFC 2863, RFC 1157, RFC
1493, RFC 1215, RFC 3416
IPv6
IPv6
IPv6 host mode
IPv6 over Ethernet
IPv6/IPv4 Dual Stack
IPv6 neighbor and router discovery (ND)
IPv6 stateless address auto-configuration
Path Maximum Transmission Unit (MTU) discovery
Duplicate Address Detection (DAD)
ICMP version 6
IPv6 ACL
Drop or rate limit IPv6 packets in hardware
IPv6 QoS
Prioritize IPv6 packets in hardware
Multicast Listener Discovery (MLD v1/2) Snooping
Deliver IPv6 multicast packets only to the required receivers
IPv6 applications
Web/SSL, Telnet server/SSH, DHCP Client, DHCP Autoconfig, Cisco Discovery Protocol (CDP), Link Layer Discovery Protocol (LLDP)
© 2021 Cisco and/or its affiliates. All rights reserved. Page 10 of 23
Feature
Description
IPv6 Requests for Comments (RFCs) supported
RFC 4443 (which obsoletes RFC2463) - ICMP version 6
RFC 4291 (which obsoletes RFC 3513) - IPv6 address architecture
RFC 4291 - IPv6 addressing architecture
RFC 2460 - IPv6 specification
RFC 4861 (which obsoletes RFC 2461) - Neighbor discovery for IPv6
RFC 4862 (which obsoletes RFC 2462) - IPv6 stateless address auto-configuration
RFC 1981 - Path MTU discovery
RFC 4007 - IPv6 scoped address architecture
RFC 3484 - Default address selection mechanism
Management
Cisco Business Dashboard
Support direct management with Cisco Business Dashboard and mobile app. Eliminates the need to set up a separate hardware or virtual machine for the Cisco Business Dashboard Probe on site.
Cisco Business mobile app
Mobile app for Cisco Business Switch and Wireless products. Helps to set up a local network in minutes and provide easy management at your fingertips.
Cisco Network Plug and Play (PnP) agent
The Cisco Network Plug and Play solution provides a simple, secure, unified, and integrated offering to ease new branch or campus device rollouts or for provisioning updates to an existing network. The solution provides a unified approach to provision Cisco routers, switches, and wireless devices with a zero touch deployment experience.
Supports Cisco PnP Connect
Web user interface
Built-in switch configuration utility for easy browser-based device configuration (HTTP/HTTPS). Supports configuration, system dashboard, system maintenance, and monitoring
Text-editable config files
Config files can be edited with a text editor and downloaded to another switch, facilitating easier mass deployment
Command-line interface
Scriptable CLI; a full CLI is supported. User privilege levels 1 and 15 are supported for the CLI
SNMP
Simple Management Network Protocol (SNMP) versions 1, 2c, and 3 with support for traps, and SNMP version 3 User-based Security Model (USM)
Standard Management Information Bases (MIBs)
MIB-II (RFC1213)
IF-MIB (RFC2863)
Bridge-MIB (RFC4188)
Bridge-MIB-Extension (RFC2674)
RMON (RFC2819)
Etherlike MIB (RFC3635)
Radius Client MIB (RFC2618)
Entity MIB (RFC2737)
POWER-ETHERNET-MIB (RFC3621)
Syslog MIB (RFC3164)
Generic Traps MIB (RFC1215)
SNMP-COMMUNITY-MIB
SNMP-MIB
LLDP-MIB
LLDP-EXT-MED-MIB
IEEE8023-LAG-MIB
CISCO-PORT-SECURITY-MIB
CISCO-ENVMON-MIB
CISCO-CDP-MIB
CISCO-CONFIG-COPY-MIB
© 2021 Cisco and/or its affiliates. All rights reserved. Page 11 of 23
Feature
Description
Remote Monitoring (RMON)
Embedded RMON software agent supports 4 RMON groups (history, statistics, alarms, and events) for enhanced traffic management, monitoring, and analysis
IPv4 and IPv6 dual stack
Coexistence of both protocol stacks to ease migration
Port mirroring
Traffic on a port or VLAN can be mirrored to another port for analysis with a network analyzer or RMON probe. Up to 8 source ports can be mirrored to one destination port. Four sessions are supported.
Firmware upgrade
Web browser upgrade (HTTP/HTTPS) and Trivial File Transfer Protocol (TFTP)
Dual images for resilient firmware upgrades
DHCP (Option 12, 66, 67, 82, 129, and 150)
DHCP options facilitate tighter control from a central point (DHCP server) to obtain IP address, auto-configuration (with configuration file download), DHCP relay, and hostname
Time synchronization
Simple Network Time Protocol (SNTP)
Login banner
Configurable multiple banners for web as well as CLI
Other management
HTTP/HTTPS; TFTP upgrade; DHCP client; Bootstrap Protocol (BOOTP); cable diagnostics; ping; traceroute; syslog
Discovery
Bonjour
The switch advertises itself using the Bonjour protocol
Link Layer Discovery Protocol (LLDP) (802.1ab) with LLDP­MED Extensions
LLDP allows the switch to advertise its identification, configuration, and capabilities to neighboring devices that store the data in a MIB. LLDP-MED is an enhancement to LLDP that adds the extensions needed for IP phones.
Cisco Discovery Protocol
The switch advertises itself using the Cisco Discovery Protocol. Displays brief information for connected Cisco network devices, IP phones, and wireless access points
Power efficiency
EEE compliance (802.3az)
Support 802.3az Energy Efficient Ethernet on all ports; substantially reduce the power consumption when link bandwidth is not at full utilization
Energy Detect
Automatically turns power off on Gigabit Ethernet and 10/100 RJ-45 ports when detecting a link down
Active mode is resumed without loss of any packets when the switch detects the link up
Disable port LEDs
LEDs can be manually turned off to save on energy.
Time-based PoE
PoE power can be on or off based on user-defined schedule to save energy.
Time-based port operation
Link up or down based on user-defined schedule (when the port is administratively up).
© 2021 Cisco and/or its affiliates. All rights reserved. Page 12 of 23
Feature
Description
Power over Ethernet
802.3af PoE or 802.3at PoE+ delivered over any of the RJ-45 network ports within the listed power budgets
Switches support 802.3af, 802.3at, and Cisco pre-standard (legacy) PoE with maximum power of 30 W per port.
This applies to the following PoE-enabled models; the maximum number of ports providing PoE power simultaneously is determined by the total PoE budget for the switch listed as below:
Model Name
PoE Power Budget
Number of Ports That Support PoE
CBS220-8P-E-2G
65 W
8
CBS220-8FP-E-2G
130 W
8
CBS220-16P-2G
130 W
16
CBS220-24P-4G
195 W
24
CBS220-24FP-4G
382 W
24
CBS220-48P-4G
382W
48
CBS220-24P-4X
195 W
24
CBS220-24FP-4X
382 W
24
CBS220-48P-4X
382W
48
CBS220-48FP-4X
740W
48
Pre-standard PoE
Support Cisco Pre-Standard PoE
Intelligent PoE power management
Support the granular power negotiation with CDP/LLDP communication with PD devices after IEEE classification
Hardware
Buttons
Reset button
Cabling type
Unshielded Twisted Pair (UTP) Category 5 or better for 10BASE-T/100BASE-TX; UTP Category 5
Ethernet or better for 1000BASE-T
LEDs
System, Link/Act, Speed
Flash
64 MB
CPU memory
256 MB
© 2021 Cisco and/or its affiliates. All rights reserved. Page 13 of 23
Feature
Description
Ports
Model name
Total system ports
RJ-45 ports
Uplink ports
CBS220-8T-E-2G
10 Gigabit Ethernet
8 Gigabit Ethernet
2 Gigabit Ethernet Small form-factor pluggable (SFP)
CBS220-8P-E-2G
10 Gigabit Ethernet
8 Gigabit Ethernet
2 Gigabit Ethernet SFP
CBS220-8FP-E-2G
10 Gigabit Ethernet
8 Gigabit Ethernet
2 Gigabit Ethernet SFP
CBS220-16T-2G
18 Gigabit Ethernet
16 Gigabit Ethernet
2 Gigabit Ethernet SFP
CBS220-16P-2G
18 Gigabit Ethernet
16 Gigabit Ethernet
2 Gigabit Ethernet SFP
CBS220-24T-4G
28 Gigabit Ethernet
24 Gigabit Ethernet
4 Gigabit Ethernet SFP
CBS220-24P-4G
28 Gigabit Ethernet
24 Gigabit Ethernet
4 Gigabit Ethernet SFP
CBS220-24FP-4G
28 Gigabit Ethernet
24 Gigabit Ethernet
4 Gigabit Ethernet SFP
CBS220-48T-4G
52 Gigabit Ethernet
48 Gigabit Ethernet
4 Gigabit Ethernet SFP
CBS220-48P-4G
52 Gigabit Ethernet
48 Gigabit Ethernet
4 Gigabit Ethernet SFP
CBS220-24T-4X
24 Gigabit Ethernet + 4 10 Gigabit Ethernet
24 Gigabit Ethernet
4 10G SFP+
CBS220-24P-4X
24 Gigabit Ethernet + 4 10 Gigabit Ethernet
24 Gigabit Ethernet
4 10G SFP+
CBS220-24FP-4X
24 Gigabit Ethernet + 4 10 Gigabit Ethernet
24 Gigabit Ethernet
4 10G SFP+
CBS220-48T-4X
48 Gigabit Ethernet + 4 10 Gigabit Ethernet
48 Gigabit Ethernet
4 10G SFP+
CBS220-48P-4X
48 Gigabit Ethernet + 4 10 Gigabit Ethernet
48 Gigabit Ethernet
4 10G SFP+
CBS220-48FP-4X
48 Gigabit Ethernet + 4 10 Gigabit Ethernet
48 Gigabit Ethernet
4 10G SFP+
Packet Buffer
All numbers are aggregate across all ports as the buffers are dynamically shared.
Model name
Packet buffer
CBS220-8T-E-2G
4.1 Mb
CBS220-8P-E-2G
4.1 Mb
CBS220-8FP-E-2G
4.1 Mb
CBS220-16T-2G
4.1 Mb
CBS220-16P-2G
4.1 Mb
© 2021 Cisco and/or its affiliates. All rights reserved. Page 14 of 23
Feature
Description
CBS220-24T-4G
4.1 Mb
CBS220-24P-4G
4.1 Mb
CBS220-24FP-4G
4.1 Mb
CBS220-48T-4G
12 Mb
CBS220-48P-4G
12 Mb
CBS220-24T-4X
12 Mb
CBS220-24P-4X
12 Mb
CBS220-24FP-4X
12 Mb
CBS220-48T-4X
16 Mb
CBS220-48P-4X
16 Mb
CBS220-48FP-4X
16 Mb
Supported SFP Modules
SKU
Media
Speed
Maximum distance
MGBSX1
Multimode fiber
1000 Mbps
500 m
MGBLX1
Single-mode fiber
1000 Mbps
10 km
MGBLH1
Single-mode fiber
1000 Mbps
40 km
MGBT1
UTP Category 5
1000 Mbps
100 m
GLC-SX-MMD
Multimode fiber
1000 Mbps
550 m
GLC-LH-SMD
Single-mode fiber
1000 Mbps
10 km
GLC-BX-U
Single-mode fiber
1000 Mbps
10 km
GLC-BX-D
Single-mode fiber
1000 Mbps
10 km
GLC-TE
UTP cat 5e
1000 Mbps
100 m
SFP-H10GB-CU1M
Copper coax
10 Gig
1 m
SFP-10G-SR
Multimode fiber
10 Gig
26 m – 400 m
SFP-10G-LR
Single-mode fiber
10 Gig
10 km
SFP-10G-SR-S
Multimode fiber
10 Gig
26 m – 400 m
SFP-10G-LR-S
Single-mode fiber
10 Gig
10 km
© 2021 Cisco and/or its affiliates. All rights reserved. Page 15 of 23
Feature
Description
Environmental
Unit dimensions (W x D x H)
Model name
Unit dimensions
CBS220-8T-E-2G
279 x 170 x 44 mm (11.0 x 6.7 x 1.7 in)
CBS220-8P-E-2G
279 x 170 x 44 mm (11.0 x 6.7 x 1.7 in)
CBS220-8FP-E-2G
279 x 170 x 44 mm (11.0 x 6.7 x 1.7 in)
CBS220-16T-2G
440 x 203 x 44 mm (17.3 x 8.0 x 1.7 in)
CBS220-16P-2G
440 x 203 x 44 mm (17.3 x 8.0 x 1.7 in)
CBS220-24T-4G
440 x 203 x 44 mm (17.3 x 8.0 x 1.7 in)
CBS220-24P-4G
440 x 257 x 44 mm (17.3 x 10.1 x 1.7 in)
CBS220-24FP-4G
440 x 257 x 44 mm (17.3 x 10.1 x 1.7 in)
CBS220-48T-4G
440 x 257 x 44 mm (17.3 x 10.1 x 1.7 in)
CBS220-48P-4G
440 x 257 x 44 mm (17.3 x 10.1 x 1.7 in)
CBS220-24T-4X
440 x 203 x 44 mm (17.3 x 8.0 x 1.7 in)
CBS220-24P-4X
440 x 257 x 44 mm (17.3 x 10.1 x 1.7 in)
CBS220-24FP-4X
440 x 257 x 44 mm (17.3 x 10.1 x 1.7 in)
CBS220-48T-4X
440 x 257 x 44 mm (17.3 x 10.1 x 1.7 in)
CBS220-48P-4X
440 x 350 x 44 mm (17.3 x 13.8 x 1.7 in)
CBS220-48FP-4X
440 x 350 x 44 mm (17.3 x 13.8 x 1.7 in)
Unit weight
Model name
Unit weight
CBS220-8T-E-2G
1.16 kg (2.56 lb)
CBS220-8P-E-2G
1.18 kg (2.60 lb)
CBS220-8FP-E-2G
1.18 kg (2.60 lb)
CBS220-16T-2G
2.48 kg (5.47 lb)
CBS220-16P-2G
3.03 kg (6.68 lb)
CBS220-24T-4G
2.75 kg (6.06 lb)
CBS220-24P-4G
4.07 kg (8.97 lb)
CBS220-24FP-4G
4.10 kg (9.04 lb)
© 2021 Cisco and/or its affiliates. All rights reserved. Page 16 of 23
Feature
Description
CBS220-48T-4G
3.18 kg (7.01 lb)
CBS220-48P-4G
5.29 kg (11.66 lb)
CBS220-24T-4X
2.69 kg (5.93 lb)
CBS220-24P-4X
4.03 kg (8.88 lb)
CBS220-24FP-4X
4.03 kg (8.88 lb)
CBS220-48T-4X
3.54 kg (7.80 lb)
CBS220-48P-4X
5.36 kg (11.82 lb)
CBS220-48FP-4X
5.65 kg (12.46 lb)
Power
100-240 V, 50-60 Hz, Internal: CBS220-16T-2G, CBS220-16P-2G, CBS220-24T-4G, CBS220-24P-4G, CBS220-24FP-4G, CBS220-48T-4G, CBS220-48P-4G, CBS220-24T-4X, CBS220-24P-4X, CBS220-24FP-4X, CBS220-48T-4X, CBS220-48P-4X, CBS220-48FP-4X
100-240 V, 50-60 Hz, External: CBS220-8T-E-2G, CBS220-8P-E-2G, CBS220-8FP-E-2G
Certifications
UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, C-tick
Operating temperature
0-50° C
Storage temperature
20° C to +70° C
Operating humidity
10% to 90%, relative, noncondensing
Storage humidity
10% to 90%, relative, noncondensing
Power Consumption
Model name
System power consumption
Power consumption (with PoE)
Heat dissipation (BTU/hr)
CBS220-8T-E-2G
110V=5.7W
220V=5.9W
N/A
20.13
CBS220-8P-E-2G
110V=7.8W
220V=8.2W
110V=81.2W
220V=81.6W
278.43
CBS220-8FP-E-2G
110V=9.1W
220V=9.1W
110V=151.4W
220V=148.9W
516.6
CBS220-16T-2G
110V=11.1W
220V=11.4W
N/A
38.9
CBS220-16P-2G
110V=16.8W
220V=18.3W
110V=160.2W
220V=159.4W
546.63
CBS220-24T-4G
110V=18.0W
220V=18.0W
N/A
61.42
© 2021 Cisco and/or its affiliates. All rights reserved. Page 17 of 23
Feature
Description
CBS220-24P-4G
110V=30.2W
220V=30.4W
110V=244.3W
220V=240.3W
833.59
CBS220-24FP-4G
110V=30.8W
220V=30.8W
110V=459W
220V=445W
1,566.17
CBS220-48T-4G
110V=36.5W
220V=36.1W
N/A
124.54
CBS220-48P-4G
110V=52.6W
220V=53.0W
110V=478.2W
220V=464W
1,631.69
CBS220-24T-4X
110V=23.2W
220V=23.6W
N/A
80.5
CBS220-24P-4X
110V=36.9W
220V=37.6W
110V=248.7W
220V=244.4W
848.6
CBS220-24FP-4X
110V=39.6W
220V=39.6W
110V=470W
220V=456.4W
1,603.71
CBS220-48T-4X
110V=41.0W
220V=41.2W
N/A
140.58
CBS220-48P-4X
110V=54.8W
220V=55.1W
110V=482W
220V=468W
1,644.65
CBS220-48FP-4X
110V=65.7W
220V=64.4W
110V=900W
220V=875.3W
3,070.92
Acoustic Noise and Mean Time Between Failure (MTBF)
Model name
Fan (number)
Acoustic noise
MTBF @ 25°C (hours)
CBS220-8T-E-2G
Fanless
N/A
1,489,560
CBS220-8P-E-2G
Fanless
N/A
315,326
CBS220-8FP-E-2G
Fanless
N/A
660,457
CBS220-16T-2G
Fanless
N/A
1,062,289
CBS220-16P-2G
Fanless
N/A
611,476
CBS220-24T-4G
Fanless
N/A
1,049,371
CBS220-24P-4G
2
25°C: 42.7 dB
587,473
CBS220-24FP-4G
2
25°C: 43.2 dB
588,411
CBS220-48T-4G
1
25°C: 35.0 dB
727,181
© 2021 Cisco and/or its affiliates. All rights reserved. Page 18 of 23
Feature
Description
CBS220-48P-4G
1
25°C: 34.8 dB
452,351
CBS220-24T-4X
1
25°C: 34 dB
1,372,359
CBS220-24P-4X
2
25°C: 42.7 dB
617,232
CBS220-24FP-4X
2
25°C: 44.2 dB
588,411
CBS220-48T-4X
1
25°C: 32.6 dB
420,827
CBS220-48P-4X
1
25°C: 35.1 dB
265,589
CBS220-48FP-4X
1
25°C: 37.7 dB
289,406
Package contents
Package contents
Cisco Business 220 Series Ethernet switch
Power cord or adaptor
Mounting kit
Quick start guide
Feature
Description
Web browser
Chrome, Firefox, Edge, Safari
Ethernet cable
Category 5e Ethernet network cable
Others
TCP/IP, network adapter, and network operating system (such as Microsoft Windows, Linux, or Mac OS) installed on each computer in the network
System requirements
Minimum requirements
Table 3. Minimum requirement
© 2021 Cisco and/or its affiliates. All rights reserved. Page 19 of 23
Model name
Order product ID
Description
Gigabit Ethernet
CBS220-8T-E-2G
CBS220-8T-E-2G-xx
8 10/100/1000 ports
2 Gigabit SFP
CBS220-8P-E-2G
CBS220-8P-E-2G-xx
8 10/100/1000 ports with 65W power budget
2 Gigabit SFP
CBS220-8FP-E-2G
CBS220-8FP-E-2G-xx
8 10/100/1000 ports with 130W power budget
2 Gigabit SFP
CBS220-16T-2G
CBS220-16T-2G-xx
16 10/100/1000 ports
2 Gigabit SFP
CBS220-16P-2G
CBS220-16P-2G-xx
16 10/100/1000 ports with 130W power budget
2 Gigabit SFP
CBS220-24T-4G
CBS220-24T-4G-xx
24 10/100/1000 ports
4 Gigabit SFP
CBS220-24P-4G
CBS220-24P-4G-xx
24 10/100/1000 ports with 195W power budget
4 Gigabit SFP
CBS220-24FP-4G
CBS220-24FP-4G-xx
24 10/100/1000 ports with 382W power budget
4 Gigabit SFP
CBS220-48T-4G
CBS220-48T-4G-xx
48 10/100/1000 ports
4 Gigabit SFP
CBS220-48P-4G
CBS220-48P-4G-xx
48 10/100/1000 ports with 382W power budget
4 Gigabit SFP
Gigabit Ethernet with 10G Uplinks
CBS220-24T-4X
CBS220-24T-4X-xx
24 10/100/1000 ports
4 10G SFP+
CBS220-24P-4X
CBS220-24P-4X-xx
24 10/100/1000 PoE+ ports with 195 W power budget
4 10G SFP+ port
CBS220-24FP-4X
CBS220-24FP-4X-xx
24 10/100/1000 PoE+ ports with 382 W power budget
Ordering information
Table 4 provides ordering information for Cisco Business 220 Series Smart Switches.
Table 4. Ordering information
© 2021 Cisco and/or its affiliates. All rights reserved. Page 20 of 23
Model name
Order product ID
Description
4 10G SFP+ port
CBS220-48T-4X
CBS220-48T-4X-xx
48 10/100/1000 ports
4 10G SFP+ port
CBS220-48P-4X
CBS220-48P-4X-xx
48 10/100/1000 PoE+ ports with 382 W power budget
4 10G SFP+ port
CBS220-48FP-4X
CBS220-48FP-4X-xx
48 10/100/1000 PoE+ ports with 740 W power budget
4 10G SFP+ port
Suffix
Country/region
-NA
USA, Canada, Mexico, Colombia, Chile and rest of Latin America
-BR
Brazil
-AR
Argentina
-EU
European Economic Area, Switzerland, Turkey, Russia, Ukraine, Israel, United Arab Emirates, Egypt, South Africa, Indonesia, Philippines, Vietnam, Thailand, Korea
-UK
United Kingdom, Saudi Arabia, Qatar, Kuwait, Singapore, Hong Kong, Malaysia
-AU
Australia, New Zealand
-CN
China
-IN
India
-KR
Korea
The -xx in the product ID is a country/region-specific suffix. For example, the complete product ID of CBS220­24T-4G for the United States is CBS220-24T-4G-NA. Please refer to Table 4 for the suffix to use for your country or region.
Cisco Business products are available only through distributors and not available to order directly from Cisco. Partners should order these products from their preferred distributors. End users should order from their preferred partners.
Accessories such as power supply and mounting kit are included with the device and are not available to order separately as spare parts. Replacement of malfunctioning accessories can be processed under the warranty with a support case.
Table 5. Country/region suffix for product ID
The products may also be available in countries/regions not listed above. Not all product models are offered in all countries/regions. For Korea, either the -EU or -KR suffix will be used, depending on product models. Please consult with your local Cisco sales representative or Cisco partner for more details.
© 2021 Cisco and/or its affiliates. All rights reserved. Page 21 of 23
Warranty information
Cisco Business 220 series smart switches are offered with 3-year limited hardware warranty with return to factory replacement. This warranty also includes complementary one-year phone or online chat support by Small Business Support Center and software updates for the warranty term.
Cisco and partner services
World-class services
To extend the support coverage beyond the warranty provisions, you can choose Cisco Smart Net Total Care™ Service, which helps you get the most value from Cisco solutions, providing peace of mind at an affordable price. The subscription-based service offers next-business-day advanced hardware replacement, software upgrades, access to the Cisco Small Business Support Center, and telephone and online chat support.
To learn more, visit https://www.cisco.com/c/en/us/solutions/small-business/services.html.
Cisco Capital
Flexible payment solutions to help you achieve your objectives
Cisco Capital makes it easier to get the right technology to achieve your objectives, enable business transformation and help you stay competitive. We can help you reduce the total cost of ownership, conserve capital, and accelerate growth. In more than 100 countries, our flexible payment solutions can help you acquire hardware, software, services and complementary third-party equipment in easy, predictable payments. Learn more.
Custom call to action
A powerful foundation for your small business network
As you strive to make your business more competitive and efficient, every dollar counts. Cisco Business 220 Series Smart Switches give you the simplicity, security, and reliability you need, without making you pay for
advanced features you don’t. With Cisco Business 220 Series switches, you can rest assured that your business
applications and communications tools are running on a strong technology foundation, so you can focus on achieving your business goals.
For more information about the Cisco Business 220 Series Smart Switches, visit
https://www.cisco.com/c/en/us/products/switches/business-220-series-smart-switches/index.html.
© 2021 Cisco and/or its affiliates. All rights reserved. Page 22 of 23
Printed in USA C78-744915-00 05/21
© 2021 Cisco and/or its affiliates. All rights reserved. Page 23 of 23
Loading...
