CISCO CISCO C931-4P, CISCO C927-4P Datasheet

Data Sheet

Cisco 900 Series Integrated

Services Routers

© 2019 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 1 of 15

Contents

Product Overview 3

Features and Benefits 4

Platform Support 5

Product Specifications 7

Cisco IOS Software Licensing and Packaging 11

Ordering Information 12

Our Experts Recommend 13

Cisco and Partner Services 14

For More Information 14

Cisco Capital 14

Document History 15

© 2019 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 2 of 15

The Cisco® 900 Series Integrated Services Routers (ISRs) combine Internet access,
comprehensive security, and wireless services in a single high-performance device that
is easy to deploy and manage. They are well suited for deployment as Customer
Premises Equipment (CPE) in enterprise small branch offices and in service provider
managed-service environments.

Product Overview

The Cisco 900 Series ISRs deliver integrated security and threat defense, protecting networks from both
known and new Internet vulnerabilities and attacks. These powerful, fixed-configuration routers provide
secure broadband and Metro Ethernet and wireless LTE WAN connectivity. Service providers offering both
managed Ethernet and wireless LTE WAN services can deploy them in customer locations as CPE.
Centralized and remote management capabilities are available through web-based tools and Cisco IOS®
Software for full visibility and control of network configurations at the remote site.

The 900 Series ISRs simplify the deployment of Ethernet WAN services, with end-to-end Operations,
Administration, and Maintenance (OA&M), Service-Level Agreement (SLA) monitoring and verification, and
configuration management.

The Cisco 900 Series ISRs come with a 4-port managed switch, providing LAN ports to connect multiple
devices. Figures 1 and 2 show the C921-4P and C926-4P models.

Figure 1.

C921-4P ISR Front, Back, and Top Views

© 2019 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 3 of 15

Business need

Features and descriptions

High availability and business continuity

● Redundant WAN connections for failover protection and load balancing

● Dynamic failover protocols such as Virtual Router Redundancy Protocol

(VRRP, RFC 2338), Hot Standby Router Protocol (HSRP), and Multigroup
HSRP (MHSRP)

Consistent, high application performance levels

● Can run multiple services simultaneously with no performance degradation

Risk mitigation with multilevel security

● Network perimeter security with integrated application inspection firewall

● Data privacy through high-speed IP Security (IPsec) Triple Data Encryption

Standard (3DES) and Advanced Encryption Standard (AES) encryption

● Enforced security policy with intrusion prevention

● Security hardware acceleration

● FlexVPN

● Next-generation encryption for secure network communications systems,

reliable for the next decade

Feature consolidation for real estate, Capital
Expenditures (CapEx), and management savings

● Supports LAN connections

Figure 2.

C926-4P ISR Front, Back, and Top Views

Features and Benefits

Table 1 describes some of the business needs enterprises have in branch offices and other edge
networking locations and how the Cisco 900 Series ISRs fulfill those requirements.

Table 1. How the Cisco 900 Series ISRs Address Edge Networking Challenges

© 2019 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 4 of 15

Business need

Features and descriptions

Unified control of wired and wireless networks
from a common console for streamlined
operations

● Simplifies and centralizes configuration and management of wireless and

wireline devices

Remote configuration and management to keep
local IT staff lean

● Supports separate console ports

Model

WAN interfaces

LAN interfaces

Integrated USB 2.0

C921-4P

2 ports Gigabit Ethernet (GE)

4-port GE managed switch

Yes

C931-4P

2 ports Gigabit Ethernet (GE)

4-port GE managed switch

Yes

C927-4P

1 port GE and 1 VADSL (Annex A)

4-port GE managed switch

Yes

C926-4P

1 port GE and 1 VADSL (Annex B/J)

4-port GE managed switch

Yes

C927-4PM

1 port GE and 1 VADSL (Annex M)

4-port GE managed switch

Yes

Model

WAN

LAN switch

Integrated USB 2.0
GE

ADSL2/VDSL2+

LTE (CAT4)

GE

C921-4PLTEGB

2

NA

YES 4 Yes

C921-4PLTEAU

2

NA

YES 4 Yes

C921-4PLTEAS

2

NA

YES 4 Yes

C927-4PLTENA

1

1 VA-DSL
(Annex A)

YES 4 Yes

C927-4PLTEGB

1

1 VA-DSL
(Annex A)

YES 4 Yes

C927-4PLTEAU

1

1 VA-DSL
(Annex A)

YES 4 Yes

C927-4PMLTEGB

1

1 VA-DSL
(Annex M)

YES 4 Yes

C926-4PLTEGB

1

1 VA-DSL
(Annex B/J)

YES 4 Yes

Platform Support

Table 2 describes the interfaces and integrated capabilities supported by each of the Cisco 900 Series ISR
models.

Table 2. Cisco 900 Series ISRs Ethernet and DSL only SKUs

Table 3. Cisco 900 Series ISRs LTE SKUs

© 2019 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 5 of 15

Model

C921-4PLTEGB

C927-4PLTENA

C927-4PLTEGB

C927-4PMLTEGB

C926-4PLTEGB

C921-4PLTEAS

C921-4PLTEAU

C927-4PLTEAU

Bands

LTE bands 1, 3, 7, 8, 20,

28.
FDD LTE 700 MHz

(band 28),
800 MHz (band 20),

900 MHz
(band 8), 1800 MHz

(band 3), 2100 MHz
(band 1), and

2600 MHz (band 7)

LTE bands 1, 3, 5, 8, 40, 41
FDD LTE 850 MHz (band 5

CLR), 900 MHz (band 8),
1800 MHz (band 3), and
2100 MHz (band 1). TDD
LTE 2300 MHz (band 40),
and 2500 MHz (band 41)

LTE bands 1, 3, 5, 7, 8, 28
FDD LTE 700 MHz (band 28), 850 MHz

(band 5 CLR), 900 MHz (band 8), 1800
MHz (band 3), 2100 MHz (band 1), and
2600 MHz (band 7)

Theoretical
Category 4
download/upload
speeds

150 Mbps/50 Mbps

150 Mbps/50 Mbps

150 Mbps/50 Mbps

Mexico

●

Europe

●

Middle East with
specific LTE
bands/frequencies

●

Australia

●

China

●

India

●

Southeast Asia

●

Latin America

Dependent upon specific
operators supporting the
LTE bands listed above

Dependent upon specific
operators supporting the LTE
bands listed above

Item

Specification

Important LTE features

● Multichannel-Interface-Processor (MIP) profile configuration

● Remotely initiated data callback using voice

● Remotely initiated data callback using Short Message Service (SMS)

● Remote firmware upgrade over LTE

● SIM lock and unlock capabilities

Table 4. Cisco LTE 2.5 Bands Supported

Table 5. Cisco LTE

© 2019 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 6 of 15

Item

Specification

Single SIM support

● High reliability, and cellular multihoming support for single micro (3FF) SIMs card socket;

compliant with ISO-7816-2 (SIM mechanical), Auto SIM carrier capability with correct
firmware selection

SMS

● Send and receive SMS (maximum 160 characters)

Modem information

Modem form factor: WP7600 series for Cisco LTE 2.5

Wireless technologies supported
(performance and throughput)

Cisco LTE 2.5 (Refer to Table 10: LTE Bands Supported) Backward compatibility:

● LTENA, LTEGB, LTEAU: UMTS, HSPA+ (Band 1, 5, 8), EDGE, GSM, GPRS (900/1800)

● LTEAS: UMTS, HSPA+ (Band 1, 8), EDGE, GSM, GPRS (900/1800)

Included antenna

● One multiband swivel-mount dipole antennas (LTE-ANTM-SMA-D) are included with all

Cisco LTE 2.5 (Recommend to order 2nd LTE-ANTM-SMA-D option for better 2X2 MIMO
coverage)

For –N antenna and cable installation guidance, view the Connected Grid Antennas

Installation Guide

Carrier support

● For a list of carriers that offer services on the Cisco 1100 Series LTE Advanced 3.0, please

visit the Wireless Carrier Partners page

Feature

Specification

Cisco IOS Software

IP and IP services

● Routing Information Protocol Versions 1 and 2 (RIPv1 and RIPv2)

● Generic Routing Encapsulation (GRE) and Multipoint GRE (MGRE)

● Cisco Express Forwarding

● Standard 802.1d Spanning Tree Protocol

● Layer 2 Tunneling Protocol (L2TP)

● L2TP Version 3 (L2TPv3)

● Network Address Translation (NAT)

● Dynamic Host Configuration Protocol (DHCP) server, relay, and client

● Dynamic DNS

● DNS Proxy and DNS Spoofing

● Access Control Lists (ACLs)

● IPv4 and IPv6 multicast

● Open Shortest Path First (OSPF)

● Border Gateway Protocol (BGP)

● Performance Routing (PfR)

● Enhanced Interior Gateway Routing Protocol (EIGRP)

● Virtual Route Forwarding (VRF) Lite

● Next Hop Resolution Protocol (NHRP)

● Bidirectional Forwarding Detection (BFD)

● Web Cache Communication Protocol (WCCP)

Product Specifications

Table 5 shows Cisco IOS Software features and general system specifications for the 900 Series ISRs.

Table 6. Cisco IOS Software Features and System Specifications

© 2019 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 7 of 15

Feature

Specification

xDSL

● True Multimode VDSL2 and ADSL2+ over Annex A, B, J, and M, including traditional G.DMT and T1.413

● World-class interoperability with industry-standard DSL Access Multiplexer (DSLAM) chipsets

● Highest field reliability with Impulse Noise Protection (INP) over Repetitive Electrical Impulse Noise

(REIN) and single isolated impulse noise (SHINE), extended INP delay, G.INP, physical layer
retransmission, Seamless Rate Adaptation (SRA), and Bitswap

● VDSL2 Persistent Storage Device (PSD) profiles up to 17a/b with support for spectral shaping

● VDSL2 vectoring to offer blazing fiber speeds over copper

● Remote management with TR069 and CWMP

● Investment protection with Gigabit Ethernet

Switch features

● Auto Media Device In/Media Device Cross Over (MDI-MDX)

● 25 802.1Q VLANs

● MAC filtering

● Switched Port Analyzer (SPAN)

● Storm control

● Smart ports

● Secure MAC address

● Internet Group Management Protocol Version 3 (IGMPv3) snooping

● 802.1X

Security features

Secure connectivity:

● Secure Sockets Layer (SSL) VPN for secure remote access

● Hardware-accelerated DES, 3DES, AES 128, AES 192, and AES 256

● Public-Key-Infrastructure (PKI) support

● 50 IPsec tunnels

● Cisco Easy VPN client and server

● NAT transparency

● Dynamic Multipoint VPN (DMVPN)

● Tunnel-less Group Encrypted Transport VPN (GET VPN)

● VRF-aware IPsec

● IPsec over IPv6

● Adaptive control technology

● Session Initiation Protocol (SIP) application-layer gateway

● Cisco IOS Firewall:

◦ Zone-based policy firewall
◦ VRF-aware stateful inspection routing firewall
◦ Stateful inspection transparent firewall

● Advanced application inspection and control

● HTTPS, FTP, and Telnet Authentication Proxy

● Dynamic and static port security

● Firewall stateful failover

● VRF-aware firewall

● Cisco IOS Software blocked and allowed lists

● Control plane policing

● Flexible packet matching

● Network foundation protection

© 2019 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 8 of 15

Feature

Specification

Quality of Service (QoS)

● Low-Latency Queuing (LLQ)

● Weighted Fair Queuing (WFQ)

● Class-Based WFQ (CBWFQ), Class-Based Traffic Shaping (CBTS), Class-Based Traffic Policing (CBTP)

● Policy-Based Routing (PBR)

● Class-Based QoS MIB

● Class of Service (CoS)-to-Differentiated Services Code Point (DSCP) mapping

● Class-Based Weighted Random Early Detection (CBWRED)

● Network-Based Application Recognition (NBAR)

● Link Fragmentation and Interleaving (LFI)

● Resource Reservation Protocol (RSVP)

● Real-Time Transport Protocol (RTP) header compression (cRTP)

● Differentiated Services (DiffServ)

● QoS preclassify and prefragmentation

● Hierarchical QoS (HQoS)

Management

● Cisco Configuration Professional

● Cisco Configuration Express

● Cisco Configuration Engine support

● Cisco AutoInstall

● Cisco IP Service-Level Agreement (IP SLA)

● Cisco IOS Embedded Event Manager (EEM)

● Cisco Security Manager

● Telnet, Simple Network Management Protocol Version 3 (SNMPv3), Secure Shell (SSH) Protocol,

Command-Line Interface (CLI), and HTTP management

● RADIUS and TACACS+

● Cisco Next Generation Plug-and-Play (NG PnP) Protocol

High availability

● Virtual Router Redundancy Protocol (VRRP) (RFC 2338)

● HSRP

● MHSRP

Metro Ethernet

● Ethernet OA&M

● Ethernet Local Management Interface (E-LMI)

● IP SLA for Ethernet

IPv6

● IPv6 addressing architecture

● IPv6 name resolution

● IPv6 statistics

● IPv6 translation: Transport packets between IPv6-only and IPv4-only endpoints (NAT-Protocol

Translation)

● Internet Control Message Protocol Version 6 (ICMPv6)

● IPv6 DHCP

● OSPFv3

● BGP4+

● IPv6 Path Maximum Transmission Unit (PMTU)

● IPv6 neighbor discovery

● IPv6 stateless address autoconfiguration (SLAAC)

● IPv6 multicast routing

Application visibility and
control

● NBAR2

● Flexible NetFlow (FNF)

● Performance Agent

© 2019 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 9 of 15

Feature

Specification

Number of
recommended users

● 50

Default and maximum
DRAM

● Default 1 GB

Default and maximum
flash memory

● 2 GB on all Cisco 900 Series ISR models; not upgradable

WAN

● Refer to Table 2, 3 and 4 for details

LAN switch

● Refer to Table 2 for details

Separate console ports

● RJ-45

USB 2.0

● One USB 2.0 Type A port

Note: USB 2.0 ports cannot be used for connecting external devices other than those specified
at:

https://www.cisco.com/en/US/prod/collateral/modules/ps6247/product_data_sheet0900aecd

80232473.html

Physical dimensions,
LEDs, and weight

Dimensions:

● C921-4P, C931-4P, and C921-4PLTEXX

◦ H x W x D = 1.70 x 9.0 x 9.5 in. (4.32 x 22.86 x 24.13 cm) (includes rubber feet)

● C927-4P, C927-4PM, C926-4P, C927-4PLTEXX, C927-4PMLTEXX, and C926-4PLTEXX

◦ H x W x D = 1.10 x 10.20 x 7.00 in. (2.80 x 25.91 x 17.78 cm) (includes rubber feet)

LEDs:

● 1x green per Ethernet

● 2x green DSL - CD+Data

● 1x bicolor LED LTE RSSI

● 1x green LED LTE SIM/Activity

● VPN

● System OK

Weight: 2.65 lb (1.20 kg) maximum

Power supply

Power specifications:

● AC input voltage: Universal 100 to 240 VAC

● Frequency: 50 to 60 Hz

● Internal power supply (C921-4P, C931-4P, and C921-4PLTEXX only)

● External power adapter (C927-4P, C927-4PM, C926-4P, C927-4PLTEXX, C927-4PMLTEXX, and

C926-4PLTEXX only): 12 VDC; 30 W

Approvals and
compliance

Safety:

● IEC 60950-1

● UL 60950-1

● CAN/CSA C22.2 No. 60950-1

● EN 60950-1

● AS/NZS 60950.1

● Class I Equipment (C921-4P and C931-4P only)

● Class III Equipment (C927-4P, C927-4PM, and C926-4P only)

Emissions:

● 47 CFR Part 15: 2006

© 2019 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 10 of 15

Feature

Specification

◦ CISPR22: Edition 6.0: 2008
◦ CNS13438: 2006
◦ EN 300 386 V1.6.1
◦ EN 55032
◦ EN61000-3-2: 2006 [+ amd 1 & 2]
◦ EN61000-3-3: 2008
◦ ICES-003 Issue 5: 2012
◦ KN 22: 2009

● TCVN 7189: 2009

● VCCI: V-3/2012.04

Immunity:

● CISPR24: 2010 [+ amd 1 & 2]

◦ EN300386: V1.6.1
◦ EN55024: 2010
◦ EN61000-6-1: 2007
◦ KN24: 2011
◦ TCVN 7317:2003

Environmental
operating range

● Nonoperating temperature: -40° to 158°F (-40° to 70°C)

● Nonoperating humidity: 5% to 95% relative humidity (noncondensing)

● Nonoperating altitude: 0 to 15,000 ft (0 to 4570 m)

● Operating temperature:

◦ C921-4P and C931-4P: 0° to 50°C (de-rate 1°C per 1000-ft increase in altitude)
◦ C927-4P, C926-4P, C927-4PM, C921-4PLTEXX,: 0° to 45°C (de-rate 1°C per 1000-ft increase in

altitude)

● Operating humidity: 5% to 95% relative humidity (noncondensing)

● Operating altitude: 0 to 10,000 ft (0 to 3000 m)

Cisco IOS Software Licensing and Packaging

Cisco IOS Universal Image

A single Cisco IOS Universal image encompassing all functions is delivered with the platform. Advanced
features can be enabled simply by activating a software license on the Universal image. Technology
packages and feature licenses, enabled through right-to-use licenses, simplify software delivery and
decrease the operational costs of deploying new features.

Three major technology licenses are available on the Cisco 900 Series; these licenses can be activated
through the Cisco software activation process identified at https://www.cisco.com/go/sa. The following
licenses are available:

●

IP Base: This technology package is the default

●

Application Experience (APP): This license includes data and application performance features

●

Security (SEC) or Security with No Payload Encryption (SEC-NPE): This license includes features for
securing network infrastructure

© 2019 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 11 of 15

Part number

Bundle

Features

SL-900-IPB

IP Base (default)

Routing protocols, ACL, NAT, QoS, BFD, VRF Lite, IP SLA
Responder

SL-900-APP(=)

Application Experience
(APP)

IP Base + advanced networking protocols: L2TPv3, MPLS
Application Experience: PfRv3, NBAR2, AVC, IP SLA Initiator
Hybrid Cloud Connectivity: LISP, Virtual Private LAN Services

(VPLS), Ethernet over MPLS

SL-900-SEC(=)

SL-900-SECNPE(=)

Security (SEC)

IP Base + Advanced Security: Zone-based firewall, IPsec VPN,
DMVPN, FlexVPN, GET VPN, SSL VPN

Provides up to 250-Mbps IPsec performance

Part number

Description

Router software images

SISR900UK9­1583MB(=)

C900-universalk9-mz: Universal image for C921-4P, C931-4P, C927-4P, C927-4PM, C926­4P,C921-4PLTE*,C926-4PLTE*,C927-4PLTE*

SISR900NPEUK9­1583MB(=)

Cisco 900 ISR Universal image and non-payload encryption image

Part number

Product description

Integrated services routers

C921-4P (C921-4PLTEGB,
C921-4PLTEAS and C921­4PLTEAU)

Cisco 921 Gigabit Ethernet security router with internal power supply
(with CAT4 LTE)

C931-4P

Cisco 931 Gigabit Ethernet security router with internal power supply

C927-4P (C927-4PLTENA, C
C927-4PLTEGB and C927­4PLTEAU)

Cisco 927 Gigabit Ethernet security router with VDSL/ADSL2+ Annex A
(with CAT4 LTE)

C927-4PM (C927-4PMLTEGB)

Cisco 927 Gigabit Ethernet security router with VDSL/ADSL2+ Annex M
(with CAT4 LTE)

Table 7 lists the part numbers and features for each of the licenses. Table 8 lists the part numbers for the
software images.

Table 7. Licenses

Table 8. Software Images

Ordering Information

Table 6 lists the part numbers and Cisco IOS Software image details for each of the Cisco 900 Series ISR
models. To place an order, visit the Cisco Ordering Home Page. To download software, visit the Cisco

Software Center.

Table 9. Product Part Numbers and Software Images

© 2019 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 12 of 15

Part number

Product description

C926-4P (C926-4PLTEGB)

Cisco 926 Gigabit Ethernet security router with VDSL/ADSL2+ Annex B/J
(with CAT4 LTE)

● Cisco C921-4P and C931-4P are supported only on Cisco IOS Software Release 15.8(3)Mb and later

● Cisco C927-4P, C927-4PM, C926-4P, and C921-4PLTE

*

, C926-4PLTE*, C927-4PLTE* are supported only on Cisco IOS Software

Release 15.8(3)M1 and later

Mount kits

ACS-900-RM-19(=)

Rack-mount kit for 900 Series ISRs [Only for C921-4P, C931-4P, and C921-4PLTEXX]

ACS-900-DM(=)

Under-the-desk mount kit for all 900 Series ISRs [Only for C921-4P, C931-4P, and C927­4PLTEXX, C927-4PMLTEXX, and C926-4PLTEXX ]

For additional information and details about Cisco IOS Software licensing and packaging on the 900 Series,
please visit:

https://www.cisco.com/c/en/us/support/routers/900-series-integrated-services-routers-isr/products­licensing-information-listing.html

For the Cisco 900 Series ISR Hardware and Software Installation Guide, go to:

https://www.cisco.com/c/en/us/support/routers/900-series-integrated-services-routers-isr/products­installation-guides-list.html

https://www.cisco.com/c/en/us/support/routers/900-series-integrated-services-routers-isr/products­installation-and-configuration-guides-list.html

Our Experts Recommend

Cisco 900 Series Integrated Services Routers At-a-Glance

Viewers of This Document Also Viewed

 Cisco 900 Series Integrated Services Routers Ordering Guide

 Cisco 900 Series Integrated Services Routers FAQ
 Cisco 1000 Series Integrated Services Routers Ordering Guide

 Cisco 1000 Series Integrated Services Routers FAQ

 Cisco 4000 Family Integrated Services Router Data Sheet

 Cisco 890 Series Integrated Services Routers - Data Sheet

© 2019 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 13 of 15

Cisco and Partner Services

Services from Cisco and our certified partners can help you reduce the cost and complexity of branch­office deployments. We have the depth and breadth of experience across technologies to architect a
blueprint for a branch-office solution to meet your company's needs. Planning and design services align
technology with business goals and can increase the accuracy, speed, and efficiency of deployment.
Technical services help maintain operational health, strengthen software application functions, solve
performance problems, and lower expenses. Optimization services are designed to continually improve
performance and help your team succeed with new technologies. For more information, visit

https://www.cisco.com/go/services.

Cisco Smart Net Total Care® technical support for the 900 Series ISRs is available on a one-time or annual
contract basis. Support options range from help-desk assistance to proactive, onsite consultation. All
support contracts include:

●

Major Cisco IOS Software updates in protocol, security, bandwidth, and feature improvements

●

Full access rights to Cisco.com technical libraries for technical assistance, electronic commerce, and
product information

●

24-hour access to the industry’s largest dedicated technical support staff

For More Information

For more information about the Cisco 900 Series ISRs, visit https://www.cisco.com/go/isr900 or contact
your local Cisco account representative.

Cisco Capital

Flexible Payment Solutions to Help you Achieve your Objectives

Cisco Capital makes it easier to get the right technology to achieve your objectives, enable business
transformation and help you stay competitive. We can help you reduce the total cost of ownership,
conserve capital, and accelerate growth. In more than 100 countries, our flexible payment solutions can
help you acquire hardware, software, services and complementary third-party equipment in easy,
predictable payments. Learn more.

© 2019 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 14 of 15

New or revised topic

Described in

Date

Added support for CAT4 LTE models

Table 2: Cisco 900 Series ISRs DSL and LTE SKUs

April 11, 2019

Document History

Printed in USAs C78-741615-03 04/20

© 2019 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 15 of 15
