Release Notes for Cisco CallManager
Release 3.0(10)
Original CCO appearance: June 20, 2001
Revised: July 2, 2001
These release notes describe the new features and caveatsforCisco CallManager
Release 3.0(10).
Foralist of the openand resolvedcaveats for Cisco CallManager Release 3.0(10),
see “Resolved Caveats” section on page 20 and “Open Caveats” section on
page 64. These release notes are updated every maintenance and major release.
Use these release notes in conjunction with the Installing Cisco CallManager
Release 3.0(10) document, located on Cisco Connection Online (CCO), and the
Cisco Documentation CD-ROM. The Installing Cisco CallManager Release
3.0(10) document is also packaged with your CDs or convergence server.
Access the latest software upgrades and release notes for Cisco CallManager
3.0(10) on Cisco Connection Online (CCO) at
http://www.cisco.com/cgi-bin/tablebuild.pl/callmgr.
Corporate Headquarters:
Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
Copyright © 2001. Cisco Systems, Inc. All rights reserved.
Contents
Contents
Introduction
These release notes discuss the following topics:
• Introduction, page 2
• System Requirements, page 3
• Related Documentation, page 3
• New and Changed Information, page 4
• Resolved Caveats, page 20
• Open Caveats, page 64
• Documentation Updates, page 82
• Obtaining Documentation, page 100
• Obtaining Technical Assistance, page 102
Cisco CallManager, a network business communication system, provides
high-quality telephony over IP networks. Cisco CallManager enables the
conversion of conventional, proprietary, circuit-switched PBXs to multiservice,
open LAN systems.
Release Notes for Cisco CallManager Release 3.0(10)
2
78-13493-02
System Requirements
Make sure Cisco CallManager Release 3.0 is installed and configured on a Cisco
Media Convergence Server. You may also install Cisco CallManager on a
Cisco-approved Compaq server configuration or a Cisco-approved IBM server
configuration.
Caution The installation will not complete if you do not follow the exact configuration.
Access the correct Cisco-approved server configuration for IBM server or
Compaq server at
http://www.cisco.com/go/swonly/
For other system hardware component information and system requirements,
refer to Installing Cisco CallManager Release 3.0(10).
Determining the Software Version
System Requirements
To determine the software version of Cisco CallManager 3.0(10), open Cisco
CallManager Administration; then click Details on the main Cisco CallManager
Administration page. The following information displays:
• Cisco CallManager System version
• Cisco CallManager Administration version
• Database information and database DLL versions
Related Documentation
The following list shows related documents for Release 3.0(10) of
Cisco CallManager:
• Installing Cisco CallManager 3.0(10)
• Quick Start Guide for Cisco CallManager Release 3.0
• Cisco CallManager Administration Guide for Release 3.0(5)
• Troubleshooting Guide for Cisco CallManager Release 3.0(5)
78-13493-02
Release Notes for Cisco CallManager Release 3.0(10)
3
New and Changed Information
• Cisco IP Phone 7900 Family Administration Guide
• Configuring Remote Serviceability for Cisco CallManager Release 3.0
• Using Cisco CallManager Trace Gathering Tool for Diagnostic Traces
• Cisco WebAttendant Quick Start Guide
• Cisco WebAttendant User Guide
• Cisco JTAPI Developer Guide
• Cisco TAPI Developer Guide
• Software License Agreement
New and Changed Information
New Software Features for Release 3.0(10)
Cisco CallManager Release 3.0(10) adds features and provides additional
workarounds to open caveats and resolves caveats.
Refer to “Resolved Caveats - Release 3.0(10)” section on page 20, “Open
Caveats” section on page 64, and the “Important Notes for Release 3.0(10)”
section on page 5 for more information.
Customer Enterprise Directory Integration Component for Microsoft Active
Directory and Netscape Directory Server
Cisco CallManager Release 3.0(10) supports the customer enterprise directory
integration component for Microsoft Active Directory and Netscape Directory
Server.
The enterprise directory integration component allows the customers' enterprise
directories to maintain the association of devicesto users. Usingthese directories,
administrators can add users manually or link to them from an existing corporate
Lightweight Directory Access Protocol (LDAP) directory.
To read installation instructions, refer to
http://www.cisco.com/cgi-bin/tablebuild.pl/callmgr.
Release Notes for Cisco CallManager Release 3.0(10)
4
78-13493-02
Backup Utility
The Backup Utility now creates backup files with the .sti extension instead of
using the .tar extension.
If you have .tar files already on your system, such as from an upgrade, the Backup
Utility restores those files as well, but all current back ups are saved as a .sti
extension.
Important Notes for Release 3.0(10)
Compatibility Matrix
Table 1 lists versions with which Cisco CallManager 3.0(10) has been tested.
Table 1 Compatibility Matrix
Component/Application Version Tested
Cisco Unity 2.4.6.102
Cisco Unity TSP 1.0.0.28
Cisco Personal Assistant 1.1
Apps 2.1 and 2.2
Cisco Customer Response
Application
IOS 12.2(2T)
Cisco WebAttendant 3.0(3.36)
Cisco IP SoftPhone 1.1(1), 1.1(2) and 1.2(1)
ICD 2.1(1a)
Firmware:Cisco IP Phone 7960 P003D310
Firmware: Cisco IP Phone 7940 P003D310
Firmware: Cisco IP Phone 7910 P004D310
IPCC/ICM Do not upgrade to
New and Changed Information
2.2
Cisco CallManager Release
3.0(10)
78-13493-02
Release Notes for Cisco CallManager Release 3.0(10)
5
New and Changed Information
Table 1 Compatibility Matrix
Component/Application Version Tested
Cisco Unity 2.4.6.102
JTAPI 1.1(1.19)
TAPI 3.0(1.18)
Service Parameters
During an upgrade, Cisco CallManager does not overwrite service parameter
values that the system administrator manually configures in Cisco CallManager
Administration.
New Software Features in Release 3.0(9)
The following section contains new and changed software features in
Cisco CallManager Release 3.0(9).
User Interface Enhancement
A new configuration parameter check box exists on the Cisco CallManager
Administration H.323 Gateway Configuration Web page. Thisallows aH.225D to
"run on every node.” If you select this option (by default it is on), theH.225D runs
on every node.
When upgrading an existing system, your current configuration remains.
Note See CSCdt40606 in the Resolved Caveats - Release 3.0(9) section
for more information.
Release Notes for Cisco CallManager Release 3.0(10)
6
78-13493-02
Service Parameters
Cisco CallManager Release 3.0(9) supports new service parameters.
Refer toTable 9 on page 83 for a complete listingof all serviceparameters, which
includes descriptions and default values, that were not included in Release 3.0(5)
of Cisco CallManager Administration Guide.
New Software Features in Release 3.0(8)
The following sections contain new and changed software features in
Cisco CallManager Release 3.0(8).
Strong Encryption
Cisco CallManager Release 3.0(8) contains low encryption (56-bit or less) in all
of its components.
Access the Download Cryptographic Software link from the main CCO
download location at http://www.cisco.com/cgi-bin/tablebuild.pl/callmgr for
applications that contain 128-bit encryption, such as, TNDconnect.exe (Bridged
Telnet application) and DC directory .dll extensions.
New and Changed Information
Note Versions preceding Cisco CallManager Release 3.0(8) included
Global Call ID
78-13493-02
TNDconnect.exe(Bridged Telnetapplication) andDC Directory .dll
extensions. These files contain strong encryption (128-bit).
The TAPI Service Provider (TSP) Version 3.0, which is packaged with
Cisco CallManager 3.0, supports Global Call ID.
Applications use the Global Call ID to identify a specific call as it traverses
various resources in the Cisco CallManager. For example, a Call Center
application uses Global Call ID to track a call that comes into a CTI route point,
gets redirected to a CTI port, and terminates at an Agent IP phone.
Release Notes for Cisco CallManager Release 3.0(10)
7
New and Changed Information
New Software Features in Release 3.0(7)
Cisco CallManager Release 3.0(7), a maintenance release, adds no new features.
Refer to the “Resolved Caveats - Release 3.0(7)” section on page 47 for more
information.
Important Notes for Release 3.0(7)
Service Parameter Restart Conditions
If you modify any of the service parameters in the following list, you must restart
the Cisco CallManager 3.0(7) before the modifications take effect.
• Digital Port
• Ethernet Phone Port
• Analog Port
• MGCP Listen Port
• MGCP Keep-alive Port
• MessageWaitingOffDN
• MessageWaitingOnDN
• StatisticsEnabled
• MaxDaResponseTimeoutErrorCount
• MaxTotalNumberOfRegisteredCallingEntities
Note The service parameter restart conditions apply to all versions up to
an including Cisco CallManager 3.0(7).
Note Refer to Table 9 on page 83 for more information on service
parameter definitions and defaults.
Release Notes for Cisco CallManager Release 3.0(10)
8
78-13493-02
New and Changed Information
Cisco IP Phone 7910 and Cisco IP Phone 7940 Compatibility Issue
Cisco IP Phone 7910 and Cisco IP Phone 7940 are only supported by
Cisco CallManager Release 3.0(5a) and higher. If you are running an earlier
version, you must upgrade to a later version at
http://www.cisco.com/cgi-bin/tablebuild.pl/callmgr.
New Software Features in Release 3.0(6)
The following sections contain new and changed hardware and software features
in Release 3.0(6) of Cisco CallManager.
Cisco WebAttendant
Cisco WebAttendant supports the traditional role of a manual attendant console.
Associated with a Cisco IP Phone, the application allows the attendant to quickly
accept and dispatch calls to enterprise users. An integrated directory service
provides traditional busy lamp field (BLF) and direct station select (DSS)
functions for any line in the system. The application is Web-enabled and,
therefore, portable to Windows 98, NT, and 2000 platforms.
As one of its primary benefits over traditional attendant console systems, Cisco
WebAttendant monitors the stateof everyline in thesystem to efficiently dispatch
calls. The absence of a hardware-based line monitor device offers a much more
affordable and distributable manual attendant solution than traditional consoles.
78-13493-02
Note Each Cisco CallManager in a cluster can process as many as 2000
Cisco WebAttendant calls per hour.
Release Notes for Cisco CallManager Release 3.0(10)
9
New and Changed Information
Tech Prefixes
Step 1 Choose Cisco CallManager.
Step 2 Choose Cisco CallManager from Configured Services.
Step 3 Enter GateKeeperSupportedPrefix in the Params section.
Step 4 Choose String as the type.
Step 5 Click update.
Step 6 Select GateKeeperSupportedPrefix from the Configured Service Parameters.
Step 7 Add the proper value; i.e., 1#, 2#, etc. Only one tech prefix is allowed.
Service Parameter
Cisco CallManager Release 3.0(6) supports tech prefixes in the Gatekeeper. To
properly configure the Cisco CallManager to register with a tech prefixyou must
go to service parameters and perform the following steps:
Cisco CallManager Release 3.0(6) supports a new service parameter.
MaxCTIConnections—This parameter sets the maximum number of
simultaneous active CTI connections between an application and the
Cisco CallManager. The default value is 400 connections.
Note Refer to Table 9 on page 83 for more information on service
parameter definitions and defaults.
Important Notes for Release 3.0(6)
Cisco IP Phone 7910 and Cisco IP Phone 7940 Compatibility Issue
Cisco IP Phone 7910 and Cisco IP Phone 7940 are only supported by
Cisco CallManager Release 3.0(5a) and higher. If you are running an earlier
version, you must upgrade to a later version at
http://www.cisco.com/cgi-bin/tablebuild.pl/callmgr.
Release Notes for Cisco CallManager Release 3.0(10)
10
78-13493-02
New and Changed Information
New Hardware and Software Features in Release 3.0(5a)
The following sections contain new and changed hardware and software features
in Release 3.0(5a) of Cisco CallManager.
Support for New Cisco IP Phones
These new phone models, Cisco IP Phone 7910, Cisco IP Phone 7910-SW+, and
Cisco IP Phone 7940, broaden the product line of Cisco IP phones.
• Cisco IP Phone 7910—This is a single-line Cisco IP Phone with the
following features:
–
Two-line, 24-character display
–
Four fixed function buttons (Line, Hold, Transfer, Settings)
–
Six programmable buttons
–
Hands-free dialing speaker
–
Single 10 BaseT (RJ-45) connector
–
Message waiting indicator
–
Provision for either inline or local plug power
• Cisco IP Phone 7910-SW+—This is a single-line Cisco IP Phone with the
following features:
–
Two-line, 24-character display
–
Four fixed function buttons (Line, Hold, Transfer, Settings)
–
Six programmable buttons
–
Hands-free dialing speaker
–
Dual 10/100 BaseT (RJ-45) connectors into dual port 10/100 BaseT
switch
–
Message waiting indicator
–
Provision for either inline or local plug power
78-13493-02
Release Notes for Cisco CallManager Release 3.0(10)
11
New and Changed Information
• Cisco IP Phone 7940—This is a two-line Cisco IP Phone with the following
features:
–
Line buttons assignable as either lines or speed dials
–
Pixel-based display
–
Four soft keys with context-sensitive features
–
Five fixed function buttons (Messages, Services, Information, Directory,
Settings)
–
Full-duplex speakerphone
–
Message waiting indicator
–
Dual 10/100 BaseT (RJ-45) connectors into dual port 10/100 BaseT
switch
–
Provision for either inline or local plug power
TAPI 2.1 and JTAPI 1.2 Service Providers
The Microsoft Telephony Application Programming Interface (TAPI) and Java
Telephony API (JTAPI) service providers enable development of sophisticated,
converged multimedia applications. These APIs support the following Cisco
applications in this release:
• Cisco IP SoftPhone
• Cisco IP Contact Center
• Cisco IP Interactive Voice Response System
• Cisco IP Auto Attendant
• E-Services Application Engine
In addition, third-party software vendors may develop applications using these
APIs. This release does not support Service Providers Interface redundancy.
Multicluster Scalability and ITU-T H.323 Enhancements
Cisco CallManager Release 3.0(5a) adds the following scalability and ITU-T
H.323 enhancements for multicluster environment in which call admission
control is provided by Cisco’s H.323 gatekeeper, the Cisco Multimedia
Conference Manager (MCM):
Release Notes for Cisco CallManager Release 3.0(10)
12
78-13493-02
New and Changed Information
• Simpler configuration—Previous versions of Cisco CallManager required all
Cisco CallManagers in separate clusters to be configured in the Cisco MCM
as a source address/destination address (SA/DA) pair. Registration by cluster
pairs meant that for a ten-site system, 90 (9 x 10) separate entries would be
required in the Cisco MCM configuration. Also, because the SA/DA name
required a hexadecimal address, configuration at the Cisco MCM and in the
Cisco CallManager database was error prone. Cisco CallManager Release
3.0(5a) allows individual gatekeeper-controlled Cisco CallManagers to be
configured at the Cisco MCM and allows a Cisco CallManager host name or
dotted decimal IP address to be used instead of a hexadecimal address.
• More efficient Cisco CallManager to H.323 Gatekeeper
registration—Cisco CallManager can register to the Cisco MCM using full
RRQ upon Cisco CallManager initialization. Subsequent RRQs are
periodically sent to the gatekeeper as a keep-alive function. In
Cisco CallManager Release 3.0(5a) the lightweight RRQ format of H.225
RAS specification is used to reduce periodic-processing burden on the
Cisco MCM CPU.
• Admission Request (ARQ) enhancements—When an intercluster call is
initiated, the gatekeeper-controlledCisco CallManager in a cluster issues the
E.164 address of the destination in its ARQ to the MCM. Also, the
gatekeeper-controlled Cisco CallManager in the source cluster accepts the IP
address of the destination device in the resulting Admission Confirm (ACF)
message.
• Gatekeeper-controlled Cisco CallManagers, during the initial RRQ, send a
full E.164 address range Cisco MCM—Cisco MCM will accept the
registration now that it is aware of the full E.164 address range of the cluster
associated with that gatekeeper-controlled Cisco CallManager. Future
enhancements to the Cisco MCM software will include the ability for
Cisco MCM to automatically add the address ranges to the Cisco MCM dial
plan.
Cisco IP Phone Services on Cisco Pixel-Based Display Phones
Cisco IP Phone 7940 and Cisco IP Phone 7960 havean HTTP client withan XML
parser. When a user presses the Services fixed-function button, the HTTP client
will attach to a preconfigured (by the administrator) URL. This URL will display
a menu of available HTML/XML services for the user. These services are
normally located on an HTTP server separate from the Cisco CallManager or
Release Notes for Cisco CallManager Release 3.0(10)
78-13493-02
13
New and Changed Information
applications server. When the user selects one of the services, the service emits
XML tags to the same phone according to the design behavior of the service.
XML tags for menu display, item selection, graphics display, and character
display are available. Customers may create HTML/XML services that are
accessible to pixel-based Cisco IP Phone displays.
Note The eXtensible Markup Language (XML) Application
Programming Interface (API) is available for end-user application
development.The description of this API is documented in Cisco IP
Phone Services Application Development Note, which is available
for download from CCO at
http://www.cisco.com/univercd/cc/td/doc/product/voice/sw_ap_to/
under the category “Third-Party Application Development Guides.”
Assistance to resolve bugs in the API is available through TAC.
Assistance for application development is not available through
TAC. Applicationsdevelopment assistancewill be madeavailable in
the near-termthrough a specifically taskedhelp desk. Until thathelp
desk is available, application development support is not available
for the XML API.
Corporate Directory Dialing from Cisco IP Phones
The Cisco IP Phone 7940 and Cisco IP Phone 7960 display a menu of directories
when a user presses directories. When the user selects Corporate Directory from
the menu, the phone presents the option of specifying characters to find the
destination user’s first name, last name, or directory number. The user may enter
any number of characters in any of these fields, then press Search. An HTTP
request goes to an HTML service, which queries the embedded
Cisco CallManager directory. The HTML service then delivers, through XML
tags, the complete listing of matched user entries to the phone’s display. The user
may then scroll to select the destination entry and press Dial to initiate the dial
sequence to that destination.
Release Notes for Cisco CallManager Release 3.0(10)
14
78-13493-02
Additional MGCP Support for Cisco VoIP Gateways
Media Gateway Configuration Protocol (MGCP) support provides two primary
benefits over H.323 support. First, MGCP provides a centralized dial plan. An
H.323 network requires that the dial plan for each gateway be statically
configured. Every dial plan change requires updating the dial plan in every
gateway. MGCP provides centralized dial plan configuration support at the
Cisco CallManager.
Cisco CallManager Release 3.0(5a) adds MGCP support for the following
Cisco VoIP gateways:
• Cisco 2600 Series gateways with FXS and FXO analog interfaces
• Cisco 3600 Series gateways (362X, 364X, 366X) with FXS and FXO analog
interfaces
Note At Cisco CallManager Release 3.0(5a), MGCP code support in the
36XX router/gatewayswas not complete. Once complete and tested,
these gateways will be supported in an AVVID network.
New and Changed Information
Cisco VG200 FXO Hookflash Support
The added Cisco VG200 FXO hookflash support Symbol NetVision Phones,
which are configured as H.323 client devices. The Cisco VG200 can be
configured to provide hookflash feature support from H.323 NetVision phones
through Cisco VG200 FXO ports attached to PBXs. The NetVision Phones issue
H.245 messages through the Cisco CallManager to Cisco VG200 FXO gateways
on initiation by the user of PBX functions. The Cisco VG200 gateway interprets
the signals and translates them to an FXO hookflash followed by a PBX-specific
feature code.
AMIS-A Support
Signaling within the Skinny GatewayControl Protocolclient and Skinny Gateway
stacks in Cisco CallManager has been extended to properly interpret and pass
out-of-band equivalent signals for “A,” “B,” “C,” and “D” DTMF signals. These
additional signals can be passed from AMIS-A compliant messaging system
78-13493-02
Release Notes for Cisco CallManager Release 3.0(10)
15
New and Changed Information
through the Cisco AVVID network, out of TDM networks to another
AMIS-equivalent voice messaging system. The capabilities allowed include the
ability to reply to and forward messages from one messaging system to another.
User Interface Enhancements
Cisco CallManager Release 3.0(5a) makes the following enhancements to the
Cisco CallManager Administration configuration pages:
• Cisco IP Phone Services Configuration—This new page enables
administrators to add, modify, or delete Cisco IP Phone services to which
users can subscribe to at their site. To access this page from the main
Cisco CallManager Administration page, select Feature > Cisco IP Phone
Services.
• Cisco uOne Port Wizard—The Cisco uOne Port Wizard enables
administrators to quickly configure ports associated with a Cisco uOne
messaging server to the Cisco CallManager database. To access the wizard
from the main Cisco CallManager Administration page, select Device >
Cisco uOne Port; then, click the Cisco uOne Port Wizard link.
• CTI Route Point Configuration—This new page enables administrators to
add, modify, and delete CTI route points. A CTI route point is a virtualdevice
that can receive multiple, simultaneous calls for the purpose of
application-controlled redirection. Applications that use CTI route points
include the Cisco IP Interactive Voice Response System. To access this page
from the main Cisco CallManager Administration page, select Device> CTI
Route Point.
• CTI Port Configuration—This new page enables administrators to add,
modify,and deletea CTI portconfiguration. CTI ports are virtual devices that
are used by software-based Cisco CallManager applications such as Cisco
SoftPhone, Cisco AutoAttendant, and Cisco IP Interactive Voice Response
(IVR). To access this page from the main Cisco CallManager Administration
page, select Device > Phones; then, select CTI Ports.
• Gatekeeper Configuration—You can now access gatekeeper configuration as
a separate configuration page where administrators can configure one
gatekeeper, or Cisco MCM, per Cisco CallManager cluster. A gatekeeper
device supports the H.225 RAS message set used for call admission control,
bandwidth allocation, and dial pattern resolution. To access this page from
the main Cisco CallManager Administration page, select Device >
Gatekeeper.
16
Release Notes for Cisco CallManager Release 3.0(10)
78-13493-02
• Cisco WebAttendant Configuration—A new set of added pages enables
administrators to configure Cisco WebAttendant pilot points, hunt groups,
and users. To access this page from the main Cisco CallManager
Administration page, select Service > Cisco WebAttendant.
• Gateway Configuration—The modified Cisco CallManager Administration
interfaceincludes supportfor additional MGCP gateways,such asCisco 2600
Series gateways with FXS and FXO analog interfaces. The MGCP gateway
configuration no longer appears as a separate menu item under Device. To
access gateway configuration pages from the main Cisco CallManager
Administration pages, select Device > Add a New Device; then, select
Gateway from the drop-down listbox menu.
Important Notes for Release 3.0(5a)
Computer Telephony Integration
Computer Telephony Integration serves as the base interface to
Cisco CallManager for TAPI and JTAPI applications as well as direct CTI
applications such as Cisco WebAttendant.Cisco CallManager 3.0(5a) allows you
to control CTI application usage on a per-user basis. You can enable CTI
application use for a particular user by browsing to entry in the User->Global
Directory in the Cisco CallManager Administration Console and selecting the
“Enable CTI Application Use” checkbox.
New and Changed Information
78-13493-02
Note By default, CTI application use is disabled for all users.
In addition, Cisco CallManager 3.0(5a) also enforces a limit of 400 concurrent
CTI connections per Cisco CallManager server. Each CTI application opens a
single CTI connection to the Cisco CallManager on successful initialization.
Alive CTI connection is required for the application to function.
Note A CTI connection is simply a TCP connection between the CTI
application and the Cisco CallManager server and is distinct from a
CTI port that is a virtual device.
Release Notes for Cisco CallManager Release 3.0(10)
17
New and Changed Information
The following example highlights the difference:
The Cisco IP Interactive Voice Response System typically opens several CTI
route points and CTI ports; it will always open a single CTI connection to a
Cisco CallManager in the cluster. The 400 connection limit applies to the CTI
connection and not the CTI ports or route points.
BAT Reinstallation
Administrators must reinstall BAT after installing Cisco CallManager 3.0(5a)
because of a change made to the database.
IOS Version
The Cisco CallManager Release 3.0(5a) was tested with IOS 12.1(3x)XI2.
Intercluster Trunk Configuration
An intercluster trunk, a virtual h.323 gateway, interlinks Cisco CallManagers in
different clusters. Beginning with Cisco CallManager Release 3.0(4), intercluster
trunks were configured differently. To ensure redundancy and proper failover
operation, each cluster must configure an intercluster trunk to each
Cisco CallManager in the remote cluster with which it shares a link.
For example, assume that you are configuring intercluster trunks among three
Cisco CallManager clusters: Cluster-1, Cluster-2, and Cluster-3C:
• Cluster-1 has three Cisco CallManagers: CCM-A, CCM-B, and CCM-C.
• Cluster-2 has two Cisco CallManagers: CCM-D and CCM-E.
• Cluster-3 has two Cisco CallManagers: CCM-F and CCM-G.
In the preceding scenario, you must configure 14 intercluster trunks to ensure
redundancy:
• Cluster-1 configures 4 intercluster trunks (to CCM-D and CCM-E in
Cluster-2 and CCM-F and CCM-G in Cluster-3).
18
Release Notes for Cisco CallManager Release 3.0(10)
78-13493-02
New and Changed Information
• Cluster-2 configures 5 intercluster trunks (to CCM-A, CCM-B, and CCM-C
in Cluster1 and to CCM-F and CCM-G in Cluster-3).
• Cluster-3 configures 5 intercluster trunks (to CCM-A, CCM-B, and CCM-C
in Cluster-1 and to CCM-D and CCM-E in Cluster-2).
Note If you add another cluster to this exampleconfiguration and you still
want to maintain the intercluster links, you must modify the
configurationfor each cluster to add the necessary linksbetween the
cluster toall of the Cisco CallManagers in thenew cluster.You must
also configure the new cluster with intercluster trunks to all of the
Cisco CallManagers in the existing clusters.
Cisco CallManager Integration with Corporate LDAP Directories
Cisco CallManager integration with corporate LDAP directories, such as
Microsoft Active Directory and Netscape Directory Services, is not available in
Cisco CallManager Release 3.0(5a). The availability of this feature will be
announced at a later date, pending completion of integration testing
Cisco IP Phone 7910 and Cisco IP Phone 7940 Compatibility Issue
Cisco IP Phone 7910 and Cisco IP Phone 7940 are only supported by
Cisco CallManager Release 3.0(5a) and higher. If you are running an earlier
version, you must upgrade to a later version at
http://www.cisco.com/cgi-bin/tablebuild.pl/callmgr.
Release Notes for Cisco CallManager Release 3.0(10)
78-13493-02
19
Resolved Caveats
Resolved Caveats
Resolved Caveats - Release 3.0(10)
Table 2 lists and describes Caveats that were resolved in Cisco CallManager
Release 3.0(10).
Note If you have an account with Cisco.com (Cisco Connection Online), you can
use the Bug Toolkit to find caveats of any severity for any release.
To access the Bug Toolkit, log on to http://www.cisco.com/support/bugtools.
Table 2 Cisco CallManager Release 3.0(10) Resolved Caveats
DDTS Number Summary Explanation
CSCdr51841 When a shared line appearance is
updated, all line appearances change.
CSCdr81185 WindowsMediaPlayer maycrash when
streaming media.
CSCds20015 Cisco IP Phone7960 P3 port does not
forward for first 9 seconds after link-up.
When the shared line is changed, only this
one appearance now changes.
A problem existed with the co-existence of
a TAPI service provider and the Windows
Media Player. If a TAPI service provider is
installed, the Windows Media Player may
hang or generate an error message when
streaming media.
A Cisco CallManager code change corrects
this behavior.
A Cisco CallManager code change adds a
service parameter to Settings/Network
Configuration/Forwarding Delay YES/NO.
Set to YES for connecting twoswitches. Set
to NO for connecting a PC\workstation.
The default setting designates Forwarding
Delay YES.
20
Release Notes for Cisco CallManager Release 3.0(10)
78-13493-02
Table 2 Cisco CallManager Release 3.0(10) Resolved Caveats (continued)
DDTS Number Summary Explanation
CSCds43704 Call looping uses CPU and other
resources in Cisco CallManager.
CSCds74822 Service Configuration application does
not function properly.
CSCds82957 SQLdatabasedoes notproperly instruct
Cisco CallManager to start after
upgrade.
A Cisco CallManager code change fixes
this problem.
A Cisco CallManager code change fixes
this behavior.
DBLR used code that was not setting up
CDR connection strings. This situation
preventedCisco CallManager from coming
up. The new code retries the CDR setup
until it completes.
CSCdt29182 Analog gateway sends caller name to
Cisco CallManager in calling party
number IE.
CSCdt31211 A forwarded call to a particular cellular
phone on a Cisco CallManager
disconnects.
The code now ensures forward and
backward capability to correct this
behavior.
When Cisco 7960 IP Phone with
Cisco CallManager 3.0(7) redirects
(forwards) a call from PSTN to the AU
phone viaPRI with WS-X6608-T1 gateway
or Cisco Digital Access Gateway DT24+,
PSTN side terminates the forwarded call
and the originator phone receives no
ringback tone.
A code change fixes this problem.
CSCdt41472 Cisco WebAttendant client cannot log
in because the UserID is already
reported as logged in.
This results from a problem with the
verbiage on the display. A message now
displays to say that the device was not
found, instead of showing that the login
failed.
CSCdt41479 Cisco WebAttendant client install does
not have default port number of 4321.
When the Cisco WebAttendant client is
installed, the default value "4321" is in the
TcdSrv Listen Port.
CSCdt41493 Cisco WebAttendant selects operating
system web browser to create client
shortcut.
The Cisco WebAttendant shortcut in the
Start Menu will now open
Cisco WebAttendant with Microsoft
Internet Explorer.
Resolved Caveats
78-13493-02
Release Notes for Cisco CallManager Release 3.0(10)
21
Resolved Caveats
Table 2 Cisco CallManager Release 3.0(10) Resolved Caveats (continued)
DDTS Number Summary Explanation
CSCdt42403 User loses a call after transferring
toward a busy line.
A Cisco CallManager code change corrects
this behavior. This item duplicates
CSCdt45632, CSCdt82239, and
CSCdr58998.
CSCdt47805 High CPU usage during directory
searches from Cisco IP Phone 7960
occurs.
This only occurred when 3-4 phones were
set to simultaneously do a corporate
directory search with blank search criteria
that the publisher CPU hits 95+% for 10-20
seconds.
CSCdt46334 Bandwidth doesnot releaseto poolafter
normal call clearing.
CSCdt49472 User cannot assign an all-numeric
pattern to Gatekeeper-controlled H.225
A Cisco CallManager code change corrects
this behavior.
A code change allows entry of numeric
patterns.
device.
CSCdt51077 User cannot use hostname as
Cisco CallManager server name when
primary DNS suffix is set.
CSCdt59773 Cisco IP Phone 7960 is susceptible to a
ping attack and may crash and reboot.
The software now allows a user to use
hostname as Cisco CallManager server
name when primary DNS suffix is set.
This occurred when scrolling through
various menus on the phone while it is
under a ping attack. This no longer occurs.
CSCdt62462 Synchronous Data Link (SDL) router
service stopped.
CSCdt65935 CallForward SDL updatedoes not work
(SsapiPtr->SsDbChangeFwdInfoReq).
A Cisco CallManager code change corrects
this behavior.
A Cisco CallManager code change puts in
an alarm to collect more information when
the Cisco CallManager fails to update the
local database tables when it receives
change notification from database layer.
CSCdt66312 Message Waiting Indicator(MWI) stays
off when message is left while SP is up,
but line is closed.
A newer version of Cisco Unity TSP
appears to have made this caveat
unreproducible.
22
Release Notes for Cisco CallManager Release 3.0(10)
78-13493-02
Resolved Caveats
Table 2 Cisco CallManager Release 3.0(10) Resolved Caveats (continued)
DDTS Number Summary Explanation
CSCdt71276 Backing up Media Convergence Server
takes about 50 minutes; in previous
versions, this took much less time.
The priority of the backup engine was
reduced, so it does not interfere with the
operation of the Cisco CallManager.
A code change corrects this behavior,so the
backup takes less time.
CSCdt71631 Name changes to partitions do not take
effect until the Cisco CallManager
reboots.
A code change ensures that, after changing
the name of partition, the renaming will
take effect without restarting database layer
and calling search space.
CSCdt72448 “lineGetCallInfo” fails after call
transitions from CONF to IDLE.
If an application tries to do a
lineGetCallInfo on a call that has
transitioned from the CONFERENCED
state to the IDLE state, the TSP returns
LINEERR_OPERATIONFAILED.
The problem occured on
Cisco CallManager 3.0(6) with TSP
3.0(0.42).
CSCdt72868 The existing route pattern update fails. A Cisco CallManager code change inserts
an alarm to collect more information when
the Cisco CallManager fails to update the
local database tables when it receives
change notification from database layer.
CSCdt73576 Deleting multiple CTI route points
A modification fixes the JavaScript error.
causes a JavaScript runtime error.
CSCdt74051 Pilot point stops working after TCD
stops and starts.
CSCdt74385 A need exists for CDR
globalCallID_callid to be more than 20
bits.
CSCdt74871 A need exists to delete unassigned
directory numbers from previous
A Cisco CallManager code change corrects
this behavior.
The code now allows globalCallID to be 24
bits so that theCDR databasecan holdmore
than 1,048,575 unique records.
Directory numbers now disappear from this
list after upgrade.
versions.
78-13493-02
Release Notes for Cisco CallManager Release 3.0(10)
23
Resolved Caveats
Table 2 Cisco CallManager Release 3.0(10) Resolved Caveats (continued)
DDTS Number Summary Explanation
CSCdt75620 A need exists for TAPI dwCalledID to
reflect original called party.
A code change ensures that TAPI
dwCalledID reflects the original called
party.
CSCdt75990 Calls with compatible regions and
A code change resolves this behavior.
capabilities fail.
CSCdt78337 If call park range overlaps at pattern,
Cisco CallManager router thread may
stop.
If call park range overlapped an external
dial pattern, and you dialed one of the call
park numbers, Cisco CallManager may
have displayed a router thread stopped
error.
A code change corrects this behavior.
CSCdt80375 Cisco Access Digital Trunk Gateway
DT-24+ may not reregister after failure.
Rare circumstances can lead
Cisco CallManager to perceive a
Cisco Access Digital Trunk Gateway
DT-24+ D-channel as still online when, in
reality,it is down and has unregistered with
the Cisco CallManager. This causes
CallManager to bar the Cisco Access
Digital Trunk GatewayDT-24+ from
reregistering because it perceives the
D-channel to be up.
A Cisco CallManager code change corrects
this behavior.
CSCdt82340 Cisco CallManager does not restart
when experiencing race condition.
Cisco CallManager software modification
in the initilization procedure makes it exit
abnormally when there is a problem
(exception returned from DBL) with
initializing the CDR thread.
CSCdt83029 When an extension has a call on hold
and an activecall, the held call does not
disconnect when each caller hangs up
CTI now sends an event indicating that the
call on HOLD and an active call exist, and
the active call hangs up.
on the call.
CSCdt83360 After Cisco CallManager is upgraded,
some services do not appear.
A code change extends the services URL
maximum length to beyond 128 characters.
24
Release Notes for Cisco CallManager Release 3.0(10)
78-13493-02
Resolved Caveats
Table 2 Cisco CallManager Release 3.0(10) Resolved Caveats (continued)
DDTS Number Summary Explanation
CSCdt83902 User cannot answer a consult transfer. The fix releases the answer thread when
applications invoke an answer request on a
consult call that is cleared due to transfer.
CSCdt84284 AVVID: Cisco WebAttendent client
does not have access to wausers share.
Microsoft security is inherited, which in
certain sites, caused problems where
adminstrators changed security settings at
higher point than the WAUSERS directory,
which then prevented domain users from
accessing the data with the advertised
method.
CSCdt84616 Blind transfer from voice mail to
MeetMe does not bridge audio.
CSCdt86530 AVVID:SMDI LTN does not increment
across PRI spans
CSCdt86741 Pressing the line soft key button does
not answer call.
CSCdt88683 Transfer button fails with call waiting
A code change enables transfer to work
properly.
The solution allows SMDI port to
increment accross PRI spans.
A code change allowsthe userto answerthe
phone by pressing the line button.
A code change resolves this behavior.
enabled.
CSCdt91200 A Cisco Media Convergence Server
backup operation hangs when manually
A Cisco CallManager code change corrects
this behavior.
initiated.
CSCdt91533 Changes to ringlist.xml can cause
phone-booting loop.
The problem occurred because the phone
was resetting after the ring list was
shortened.
CSCdt91824 A need exists for a method to clear stale
held calls.
A code change allows applications to clear
a connection in a stale or disconnected
state.
CSCdt92019 No events occur to third party when
second party drops consult transfer call.
This problem occurred using the Cisco TSP
that is bundled with Cisco CallManager
3.0(8). The problem intermittently
occurred about one in four times.
Cisco CallManager code change corrects
this behavior.
78-13493-02
Release Notes for Cisco CallManager Release 3.0(10)
25
Resolved Caveats
Table 2 Cisco CallManager Release 3.0(10) Resolved Caveats (continued)
DDTS Number Summary Explanation
CSCdt94077 Device tables do not update correctly
after failover occurs.
Calls going out through a digital gateway
were being dropped after one
Cisco CallManager in a cluster fails in a
certain way (links to other
Cisco CallManagers in the cluster stay up,
even though its devices fail over), and its
phones and gateways have registered with
the backup Cisco CallManager.
A user running Cisco CallManager Release
3.0(8) or earlier in a clustered environment
more likely encounters this problem.
A Cisco CallManager code change corrects
this behavior.
CSCdt94179 Redirect fails, and subsequent redirect
gets no response.
A Cisco CallManager code change ensures
that orphaned destinations get cleaned up
properly during a redirect of the originator.
CSCdt95027 Cisco CallManager does not allow
simulated phones to register.
Anydevice,which duringregistration sends
the MaxFramePacketSize as zero during
registration, cannot register with the
Cisco CallManager.The device needs to
send the correct capabilities to be able to
register.
CSCdt95612 When a user right-clicks on the backup
utility icon in the task tray, then clicks
A Cisco CallManager code change corrects
this behavior.
somewhere on the desktop, part of the
popup menu remains on the screen.
CSCdt95934 After Cisco CallManager is upgraded,
the Cisco CallManager server IP
address changes to the
To correct this caveat, the database layer
now resolves the host name and IP address
better.
Cisco CallManager DNS name.
26
Release Notes for Cisco CallManager Release 3.0(10)
78-13493-02
Table 2 Cisco CallManager Release 3.0(10) Resolved Caveats (continued)
DDTS Number Summary Explanation
CSCdt96338 The simultaneous call limit for H.323
device equals 248 when it should be
360.
Intercluster callsstop at 248 active calls per
H.323 device. A code change allows 360
calls to be in place simultaneously.
Users experience this problem only with
Cisco CallManager Release 3.0(8) or
earlier.
CSCdt96745 H.245 negotiation fails on intercluster
trunk for forwarded call.
In certain scenarios, when a call across an
intercluster trunk is forwarded to another
gateway, the call will fail due to a Media
Capabilities Exchange timeout. This has
only been observed when the subscriber
machines in a cluster are up. This behavior
no longer exists in Cisco CallManager
Release 3.0(10).
CSCdu00792 Callswere getting dropped for constant
delay.
When large packet delays were inserted
between gateways and Cisco CallManager,
some timers were expiring.
The code change compensates several
internal timers for inaccuracy and sets a
higher minimum default value for the
configurable timer
MediaExchangeTimeout.
Only customers who install
Cisco CallManager 3.0(10)forthe firsttime
receive this bug fix. A customer who
upgrades to Cisco CallManager 3.0(10)
does not get this bug fix.
CSCdu02128 A race condition can cause transfer
table corruption.
CSCdu03062 RDNIS does not appear in Q931
message.
A code change prevents the race condition
from occurring.
The RDNIS was sometimes not being sent
out the digital gateway, even though the
Redirecting Number IE Delivery box is
checked in the gateway configuration.
Resolved Caveats
78-13493-02
Release Notes for Cisco CallManager Release 3.0(10)
27
Resolved Caveats
Table 2 Cisco CallManager Release 3.0(10) Resolved Caveats (continued)
DDTS Number Summary Explanation
CSCdu04286 After conferencing, if only two parties
are left in the conference, TAPI redirect
A Cisco CallManager code change corrects
this behavior.
causes both parties to be dropped
instead of just the one doing the
redirect.
CSCdu05420 Locations bandwidth takes more than
20 hours to free up.
Although this problem could not be exactly
reproduced, from the provided trace we
gather that a problem with media occurs
when media are being set up and then torn
down before completing the set up.
CSCdu05485 Sending out 3.1 kHz causes problems
for some calls. This occurs when using
A Cisco CallManager code change corrects
this behavior.
the Cisco Catalyst 6000 E1.
CSCdu06291 Cisco IPphone acceptsonly one default
router from Unix Dynamic Host
Cisco IP Phone 7960 now accepts
additional routers.
configuration Protocol (DHCP) server.
CSCdu07051 Cisco CallManager users can have a
user ID with an underscore, but they
The software now accepts an underscore in
the user ID.
cannot log in to CCMUser page with a
login name with an underscore.
CSCdu08613 Cisco uOne port hangs after transfer to
a device where call forward all and/or
call forward back fails.
Cisco CallManager now sends an onhook
signal when the device uses call forward all
and/or call forward back to an unreachable
directory number.
CSCdu09807 H.323 endpoint always uses display
name of the first line.
CSCdu09917 A need exists for a user to be able to
change AnonymousDevice protocol to
A code change allows for the H.323
gateway to operate differently.
The AnonymousDevice protocol can be
changed to H.225.
H.225.
28
Release Notes for Cisco CallManager Release 3.0(10)
78-13493-02
Table 2 Cisco CallManager Release 3.0(10) Resolved Caveats (continued)
DDTS Number Summary Explanation
CSCdu10146 Locations bandwidth calculation is
wrong with software conference and
codec change.
A caller initiates a call to a low bandwidth
(30 KB) location with codec G.729. The
caller initiates a conference using a
software conference bridge, and the codec
changes to G.711. The called party in the
low bandwidth location changes to G.711
and joins the conference even though not
enough bandwidth exists.
A code change corrects this behavior.
CSCdu12450 AnonymousDevice does not work until
Cisco CallManager stops/starts.
CSCdu13710 Dual-tone multifrequency (DTMF)
intermittenly fails.
CSCdu19849 Cisco CallManager may crash when a
user performs a directory look up to a
A Cisco CallManager code change corrects
this behavior.
A Cisco CallManager code change corrects
this behavior.
This problem occurred because the
directory was not properly configured.
partially initialized directory.
CSCdu20435 lineSetupTransfer sometimes returns
call in ONHOLD not OHPT state.
CSCdu20892 Pilot point stops working due to
CtiDeviceOpenReq failure.
CSCdu43517 Cisco IP Phone 7940/7960 headset
transmit level is too low versus the
The TSP was not setting the TAPI call state
appropriately.
The customer’s pilot point was not
registering with digit analysis.
Three decibals were added to the headset
microphone.
handset level.
Resolved Caveats
78-13493-02
Release Notes for Cisco CallManager Release 3.0(10)
29
Resolved Caveats
Table 2 Cisco CallManager Release 3.0(10) Resolved Caveats (continued)
DDTS Number Summary Explanation
CSCdu68211 Thedefault SdlTraceTypeFlags value is
inadequate for debugging needs.
The default value SdlTraceTypeFlags
changed to 0x00004B15. This change only
occurs on new installs. On upgrade
installations, the previous setting for the
"SDLTraceTypeFlags" service parameter
remains at 0x00004B05.
Customers who install Cisco CallManager
3.0(10) for the first time receivethis bug fix.
A customer who upgrades to
Cisco CallManager 3.0(10) does not
receive a bug fix for this.
During an upgrade, Cisco CallManager
does not overwriteservice parameter values
manually configured by the system
administrator in Cisco CallManager
Administration.
CMTerminals -- Firmware
CSCdt68876 WS-X6608 portresets whensetting upa
FAX call.
A code change resolves a problem that was
causing a timer to restart, which initially
caused this caveat.
CSCdt97510 DTMF tones are sometimes not sent
A code change corrects this behavior.
through 6608 PRI from IP phone.
CSCdu09034 Phones lose IP leases at renewal. They
are forced to unregister from the
A problem no longer exists in
Cisco CallManager Release 3.0(10).
Cisco CallManager and acquire a new
IP address.
30
Release Notes for Cisco CallManager Release 3.0(10)
78-13493-02
Loading...
