Cisco Systems C3413U User Manual

User Guide
DRAFT 5/23/11
Cisco 3413DVB Digital Set-Top
GUIDE OK Ż9O/± 9O/Ź CH±ź CHŸ
DRAFT 5/23/11
IMPORTANT SAFETY INSTRUCTIONS ........................................................ 2
Welcome .........................................................................................................4
Safety First .....................................................................................................4
Serial Number and MAC Address...................................................................4
About the Remote Control ..............................................................................5
Front Panel .....................................................................................................6
Back Panel .....................................................................................................7
Side Panel ...................................................................................................... 7
Connecting the Set-Top .................................................................................. 8
Connecting to a TV ......................................................................................... 9
Watch TV ......................................................................................................10
Setup Wizard ................................................................................................10
Set Parental Control PIN .............................................................................. 10
Revert to Factory Settings ............................................................................ 11
Navigator Bar................................................................................................ 11
Color-Coded Options ................................................................................ 11
View Blocked Channels ............................................................................12
Set Blocking Options................................................................................. 12
Program Information .................................................................................12
Options......................................................................................................12
Electronic Program Guide ............................................................................13
Favorites List.............................................................................................13
Program Reminders ..................................................................................13
Main Menu .................................................................................................... 14
TV Categories ........................................................................................... 14
Setting Up Favorites Lists ......................................................................... 15
On Demand...............................................................................................15
Pay-Per-View Events ................................................................................ 16
Ordering VOD Services ............................................................................17
Mosaic.......................................................................................................17
Troubleshooting ............................................................................................18
Disclaimer ..................................................................................................... 18
Open Source GNU GPL Statement .............................................................. 18
1
IMPORTANT SAFETY INSTRUCTIONS
DRAFT 5/23/11
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand,
apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as a power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/
Power Source Warning
A label on this product indicates the correct power source for this product. Operate this product only from an electrical outlet with the voltage and frequency indicated on the product label. If you are uncertain of the type of power supply to your home or business, consult your service provider or your local power company.
The AC inlet on the unit must remain accessible and operable at all times.
Ground the Product
WARNING: Avoid electric shock and fire hazard! If this product connects to coaxial cable wiring, be sure the cable system is grounded (earthed). Grounding provides some protection against voltage surges and built-up static charges.
WARNING: Avoid electric shock and fi re hazard! Do not locate an outside antenna system in the vicinity of overhead power lines or power circuits. Touching power lines or circuits might be fatal.
This product may contain a tuner capable of receiving off-the-air broadcasts.
Protect the Product from Lightning
In addition to disconnecting the AC power from the wall outlet, disconnect the signal inputs.
Verify the Power Source from the On/Off Power Light
When the on/off power light is not illuminated, the apparatus may still be connected to the power source. The light may go out when the apparatus is turned off, regardless of whether it is still plugged into an AC power source.
Note: Where the mains plug or an appliance coupler is used to disconnect the device, the disconnect device shall remain readily operable.
Eliminate AC Power/Mains Overloads
WARNING: Avoid electric shock and fire hazard! Do not overload AC power/mains, outlets, extension cords, or integral convenience receptacles. For products that require battery power or other power sources to operate them, refer to the operating instructions for those products.
2
IMPORTANT SAFETY INSTRUCTIONS, continued
DRAFT 5/23/11
Handling Disposable Batteries
This product may contain disposable batteries. Heed the following warning and follow the Battery Safety and Battery Disposal instructions below.
WARNING: There is danger of explosion if the battery is mishandled or incorrectly replaced. Replace only with the same type of battery. Do not disassemble it or attempt to recharge it outside the system. Do not crush, puncture, dispose of in fi re, short the external contacts, or expose to water or other liquids. Dispose of the battery in accordance with local regulations and instructions from your service provider.
Battery Safety
• Insert batteries correctly. There may be a risk of explosion if the batteries are incorrectly inserted.
• Do not attempt to recharge ‘disposable’ or ‘non­reusable’ batteries.
• Please follow instructions provided for charging ‘rechargeable’ batteries.
• Replace batteries with the same or equivalent type that we recommend.
• Do not expose batteries to temperatures above 100°C (212°F).
• Do not expose batteries to excessive heat (such as sunlight or fi re).
Battery Disposal
• The batteries may contain substances that could be harmful to the environment.
• Recycle or dispose of batteries in accordance with the battery manufacturer’s instructions and local/national disposal and recycling regulations.
• The batteries may contain perchlorate, a known hazardous substance, so special handling and disposal of this product might be necessary. For more information about perchlorate and best management practices for perchlorate-containing substance, see www.dtsc. ca.gov/hazardouswaste/perchlorate
Provide Ventilation and Select a Location
• Remove all packaging material before applying power to the product.
• Do not place this apparatus on a bed, sofa, rug, or similar surface.
• Do not place this apparatus on an unstable surface.
• Do not install this apparatus in an enclosure, such as a bookcase or rack, unless the installation provides proper ventilation.
• Do not place entertainment devices (such as VCRs or DVDs), lamps, books, vases with liquids, or other objects on top of this product.
• Do not block ventilation openings.
Operating Environment
The set-top is designed for operation indoors with a temperature range from 32° to 104° F (0° to 40°C). Each set-top should have adequate spacing on all sides so that the cooling air vents on the chassis are not blocked.
Protect from Exposure to Moisture and Foreign Objects
WARNING: Avoid electric shock and fi re hazard! Do not expose this product to dripping or splashing liquids, rain, or moisture. Objects fi lled with liquids, such as vases, should not be placed on this apparatus.
WARNING: Avoid electric shock and fi re hazard! Unplug this product before cleaning. Do not use a liquid cleaner or an aerosol cleaner. Do not use a magnetic/static cleaning device (dust remover) to clean this product.
WARNING: Avoid electric shock and fi re hazard! Never push objects through the openings in this product. Foreign objects can cause electrical shorts that can result in electric shock or fi re.
Service Warnings
WARNING: Avoid electric shock! Do not open the cover of this product. Opening or removing the cover may expose you to dangerous voltages. If you open the cover, your warranty will be void. This product contains no user-serviceable parts.
Check Product Safety
Upon completion of any service or repairs to this product, the service technician must perform safety checks to determine that this product is in proper operating condition.
Protect the Product When Moving It
Always disconnect the power source when moving the apparatus or connecting or disconnecting cables.
20110316_Cable_Safety
3
Welcome
DRAFT 5/23/11
Enjoy crystal clear pictures and CD quality sound with your Cisco® 3413DVB Set-Top. Best of all, you can watch what you want to watch when you want to watch it at the press of a button. It’s all described in this user guide. Go through it right away to learn about each feature and to help you enjoy your experience to the fullest.
Safety First
Before using the set-top, read the Important Safety Instructions section of this guide.
Serial Number and MAC Address
Your service provider may ask for the serial number or the MAC address of the set-top if your system requires troubleshooting in the future.
Look for the serial number and the MAC address on the bottom of the set-top.
Write the serial number here: _____________________________________
Write the MAC address here: _____________________________________
4
