Quick Reference

CATA LY ST 8510 AND

LIGHTSTREAM 1010

H

ARDWARE INFORMATION

Chassis Installation

WARNING:Before you install, operate or service the system, read
the

Site Preparation and Safety Guide

important safety information you should know before working
with the system.

. This guide contains

Attaching Brackets and Guides

Installing a Chassis in a Rack

WARNING:Two people are required to lift the chassis.To

prevent damage to the chassis and components, never
attempt to lift the chassis by the handles on the power
supplies or on the interface modules.

Ports and Cabling

ROUTE PROCESSOR
PORTS

CABLE
CONNECTORS

RJ-45Management port

PORT ADAPTER/
INTERFACE MODULE
PORTS

10/100BaseT, T1/E1,
CES, CE1 Frame Relay

100BaseFX

155 Mbps, 622 Mbps

Gigabit Ethernet

CABLE
CONNECTORS

RJ-45, RJ-48c

MT-RJ fiber

SC-type fiber

Console port

EIA/TIA-232

E1, CES, DS3/E3, CDS3

25 Mbps

BNC

96-pin Molex

Replacing Components

Inserting an Interface Module Inserting a Port AdapterSecuring an ESD Strap

WARNING: Always connect the ESD

wriststraptotheESDstrapconnection

atthe top leftside of the chassisbefore

removing any component.

Inserting and Removing Flash PC Cards

Changing a Power Supply

Inserting a New Fan

WARNING: Always turn off the power supply unit

before removing it. While holding the AC or DC
power supply handle with one hand, place your
other hand underneath to support the bottom of
the supply.

LEDs and Troubleshooting

Distance and Pinout Information

Maximum Transmission Distances

Max. Distance

Transceiver Speed Cable Type

10/100-Mbps Ethernet Category 5 UTP 328 feet (100 m)
100-Mbps Ethernet Multimode fiber 1640 feet (500 m)
1000-Mbps Ethernet Multimode fiber 1640 feet (500 m)
1000-Mbps Ethernet Single-mode fiber 16404 feet (5 km)
25-Mbps ATM Category 5 UTP 328 feet (100 m)
155-Mbps ATM Single-mode fiber 9 miles (15 km)
155-Mbps ATM Single-mode fiber, long reach 18 miles (30 km)
155-Mbps ATM Multimode fiber 1.2 miles (2 km)
622-Mbps ATM Single-mode fiber 9 miles (15 km)
622-Mbps ATM Single-mode fiber, long reach 25 miles (40 km)
622-Mbps ATM Multimode fiber 1640 feet (500 m)
T1, 1.544-Mbps ATM Category 5 twisted-pair 650 feet (198 m)
E1, 2.048-Mbps ATM Category 5 twisted-pair and FTP (120 ohm) 650 feet (198 m)
E1, 2.048-Mbps ATM Coaxial cable (75 ohm) 650 feet (198 m)
CDS3, 45-Mbps Coaxial cable 450 feet (137 m)
CE1, 2.048-Mbps ATM Category 5 twisted-pair 650 feet (198 m)
CES T1 Category 5 twisted-pair and FTP 650 feet (198 m)
CES E1 Category 5 twisted-pair and FTP (120 ohm) 820 feet (248.5 m)
CES E1 Coaxial cable (75 ohm) 650 feet (198 m)
DS3, 45-Mbps Coaxial cable 450 feet (137 m)
E3, 34-Mbps Coaxial cable 1299 feet (396 m)

1. If you are attaching a short cable to the 622-Mbps long-reach port adapter, you must add 10 dB of
attenuation to the cable or the transmitter might overdrive the receiver and introduce data errors.

Between Stations

Pinouts to RJ-45 Connectors

The 10/100 Mbps Ethernet interface module with unshielded twisted-pair (UTP)
ports supports RJ-45 connectors.

Pin Signal Description

1 RXD+ Receive data +
2 RXD– Receive data –
3 NC No connection
4 NC No connection
5 NC No connection
6 NC No connection
7 TXD+ Transmit data +
8 TXD– Transmit data –

1

Pinouts to RJ-48c Connectors

The T1, E1, CES T1 and CES E1 port adapters support RJ-48c connectors.

Pin Description

1 Receive ring
2 Receive tip
3 No connection
4 Transmit ring
5 Transmit tip
6 No connection
7 No connection
8 No connection

Specifications and Regulatory Compliance Information

Description Specifications

Switch and processor
capacity

Dimensions (H x W x D) Chassis: 10.4 x 17.25 x 18.4 in (26.4 x 43.1 x 46.0 cm)

Weight Empty chassis: 32 lb (15.5 kg)

Airflow 95 cfm through the system fan assembly
Operating temperature 32 to 122 F (0 to 50 C)
Nonoperating temperature
Humidity 10 to 90%, noncondensing
Altitude
Microprocessor 100-Mhz MIPS R4700
AC total output 388W maximum
AC-input voltage 100-240 VAC wide input with power factor correction
AC frequency Auto sensing limits: 100 to 127/200 to 240 VAC, 8/4A, 47 to

AC current rating 8/4A with the chassis fully populated
Power supply load 376W maximum configuration, 200W typical with max

DC voltages supplied and
steady-state maximum
current ratings

10-Gbps shared memory, nonblocking switch fabric up to 32
KB frames

Processor card and carrier module:

1.2 x 14.4 x 16 in (3.0 x 36.6 x 40.6 cm)
Port adapter: 1.2 x 6.5 x 10 in (3.0 x 16.5 x 25.4 cm)
Power supply: 2.7 x 6.0 x 15.3 in (6.9 x 15.2 x 38.9 cm)

Fully populated chassis: approximately 130 lb (59.09 kg)
AC power supply: 11 lb (4.98 kg)
DC power supply: 10 lb (4.54 kg)

°°

–40 to 167 F (–40 to 75 C)

°°

–500 to 10,000 ft (–52 to 3048 m)

63 Hz

configuration
System: +5V @ 70A

+12V @ 2A
+24V @ 0.2A

Processor: +5V @ 15A

+24V @ 25mA
+12V @ 500mA

Description Specifications

Memory 8-MB Flash memory SIMM (upgradable to 16 MB)

64-MB DRAM
256-KB boot EPROM
128-KB SRAM
No Flash PC card installed by default (accepts 8-, 16-, or

20-MB Intel Series 2+ Flash PC cards)

Regulatory Compliance UL 1950 (U.S.A.)

CSA 950 (Canada)
EN60950 (European Union)
IEC 950 (International)
AS/NZS 3260 (Australia/New Zealand)
TS001:1997 (Australia)
21CFR1040 (Laser - U.S.A.)
EN60825 (Laser - European Union)
IEC60825 (Laser - International)
CE Marking (European Union)
FCC Part 15 (CFR 47) Class A (U.S.A.)
VCCI Class A with UTP and Class B with FTP cables (Japan)
EN55022 Class A with UTP and Class B with FTP cables

(European Union)
CISPR 22 Class A with UTP and Class B with FTP cables

(International)
AS/NZS 3548 Class A with UTP and Class B with FTP cables

(Australia/New Zealand)
