Cisco IP Phone 7905G

Data Sheet

Cisco IP Communications, a
comprehensive system of powerful,
enterprise-class solutions including IP
telephony, unified communications, IP
video/audio conferencing, and customer
contact, helps organizations realize
business gains by improving operational
efficiencies, increasing organizational
productivity, and enhancing customer
satisfaction. Cisco IP Phones—an integral
component of the Cisco IP
Communications system—provide
unmatched levels of integrated business
functionality and converged
communications that go beyond today’s
conventional voice systems.

The Cisco IP Phone 7905G is a
cost-effective, basic IP phone providing a
coresetofbusinessfeatures.Itisspecifically
suited for enterprise and service provider
applications, and can be deployed in
the following end-user environments:
enterprises, small and medium-sized
businesses (SMB), and small offices, home

offices (SOHO). It is also suitable for places
where single-line phones are typically
installed such as cafeterias, break rooms,
lobbies, and manufacturing floors.

The Cisco IP Phone 7905G provides
single-line access and four interactive soft
keys that guide a user through call features
and functions via the pixel-based liquid
crystal display (LCD). The graphic
capabilityofthedisplayprovidesarichuser
experience by presenting calling
information, intuitive access to features,
and language localization in future
firmware releases.

The Cisco IP Phone 7905G supports inline
power, which allows the phone to receive
power over the LAN. This capability gives
the network administrator centralized
powercontrol,whichtranslatesintogreater
network availability. In addition, XML
applicationsdeliver impressive applications
and network data to the Cisco IP Phone
7905G display.

Cisco IP Phone 7905G

All contents are Copyright © 1992–2002 Cisco Systems, Inc. All rights reserved. Important Notices and Privacy Statement.

Key Features

TheCiscoIPPhone7905Gisdesignedto be
easy to use with conveniently placed
features.

• Pixel-based display—A pixel-based
display provides intuitive access to
calling features. Four soft keys
dynamically present calling options to
the user. The scroll toggle bar allows
easy movement through the displayed
information.

Cisco Systems, Inc.

Page 1 of 5

• “Menu” key—This key allows users to quickly access information such as call logs and phone settings.

– The user can retrieve voice-mail messages.
– The user can display missed calls, outgoing calls that have been placed, and incoming calls that have been

received.

– The user can set various preferences such as ring types and display contrast.

• “Hold” key—This lighted key provides the user a red visual indication that they have placed a call on hold.

• A volume-control toggle provides easy decibel-level adjustments of the handset and ringer.

• A hearing-aid-compatible handset (meets American Disabilities Act [ADA] requirements)

• A single-position foot stand provides optimum display viewing and comfortable use of buttons and keys. The
foot stand can be removed to allow wall mounting via mounting holes located on the base of the phone.

• XML Applications can be delivered to the display.

Calling Features

The Cisco IP Phone 7905G is designed to grow with system capabilities. Features will keep pace with new changes
via software updates to the phone’s flash memory. Examples of currently available features include:

• Single Line/Directory Number (DN)

• Calling name and number display

• Call Waiting

• Call Forward

• Call Transfer

• Three-way calling (conference)

• On-hook dialing, Pre-Dialing, and Off-hook dialing

• Redial

• Call hold

• Call monitor (speaker-only, no microphone)

• “Messages” soft key allows access to voice mail messages

• Four Speed dials configurable at the Call Manager

Network Features

• Cisco Discovery Protocol (CDP)

• IEEE 802.1q (VLAN)

• G.711a, G.711u, G.729ab audio-compression coder-decoders (codecs)

• 10BASE-T Ethernet connection via a RJ-45 interface for LAN connectivity

• Software upgrade supported via Trivial File Transfer Protocol (TFTP) server

• Provisioning of network parameters through Dynamic Host Configuration Protocol (DHCP)

• Voice-activity detection, silence suppression, comfort-noise generation, and error concealment

All contents are Copyright © 1992–2002 Cisco Systems, Inc. All rights reserved. Important Notices and Privacy Statement.

Cisco Systems, Inc.

Page 2 of 5

Protocols Supported

• Compatible with Cisco CallManager 3.3 and above, using the SCCP protocol

• H.323 Version 2

• SIP (RFC 2543)

Physical Specifications

• Dimensions: (H x W x D): 8 x 7 x 6 in. (20.3 x 17.67 x 15.2 cm)

• Phone weight: 1.9 lb (0.9 kg)

Power Supply

• Inline power

• Power can also be supplied locally using an optional AC to 48 VDC power adaptor,CP-PWR-CUBE, which also
requires one of the country-specific cords below.

– CP-PWR-CORD-NA (North America)
– CP-PWR-CORD-CE (Central Europe)
– CP-PWR-CORD-UK (United Kingdom)
– CP-PWR-CORD-AU (Australia)
– CP-PWR-CORD-JP (Japan)
– CP-PWR-CORD-AP (Asia Pacific)

Temperature

• Operating temperature: 32 to 104 F (0 to 40 C)

• Relative humidity: 10 to 95% (non-condensing)

• Storage temperature: 14 to 140 F (-10 to 60 C)

Certification

Regulatory Compliance

Products bear the CE marking to indicate compliance with the 89/336/EEC (Eurocontrol Experimental Centre) and
73/23/EEC directives, which includes the following safety and Electromagnetic Compatibility (EMC) standards:

Safety

• Underwriters Laboratories (UL) 60950

• Canadian Standards Association (CSA) C22.2 No. 60950

• EN 60950

• IEC 60950

• AS/NZS 3260

• TS 0001

All contents are Copyright © 1992–2002 Cisco Systems, Inc. All rights reserved. Important Notices and Privacy Statement.

Cisco Systems, Inc.

Page 3 of 5

Electromagnetic Compatibility (EMC)

• Federal Communications Commission (FCC) Part 15 (CFR 47) Class B

• ICES-003 Class B

• EN55022 Class B

• CISPR22 Class B

• AS/NZS 3548 Class B

• VCCI Class B

• EN55024

• EN 50082-1

• EN 61000-3-2

• EN 61000-3-3

Telecom

• FCC Part 68 (CFR 47) (hearing-aid-compatible)

Ordering Information

Table 1 Part Numbers

Part Number Description

CP-7905G Cisco IP Phone 7905G hardware
SW-CCM-UL-7905 Station User License for Cisco CallManager
SW-SMH-UL-7905 Station User License for SIP or H.323 protocol

™

Cisco offers a standard one-year warranty. A Cisco SMARTnet

optional service agreement is available.

Cisco IP Communications Services and Support

Cisco IP Communications services and support reduce the cost, time, and complexity associated with implementing
a converged network. Cisco and its partners have designed and deployed some of today’s largest and most complex
IP Communications networks—which means that they understand how to integrate an IP Communications solution
into your network.

Ciscodesigntoolsand best practices ensure the solution best fits your business needs from the start,eliminatingcostly
redesigns and downtime. Our proven methods ensure a sound implementation that will deliver the functions and
features you expect—on time. Support services include remote network operations, network management tools to
administer the converged application and network infrastructure, and technical support services.

Through these services, your organization benefits from the experience gained by Cisco and its partners. Leveraging
this valuable experience, you can create and maintain a resilient converged network that will meet your business
needs today—and in the future.
