Catalyst 6500 Series Switch
Command Reference
Release 7.6
Corporate Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: 408 526-4000
800 553-NETS (6387)
Fax: 408 526-4100
Customer Order Number: DOC-7815328=
Text Part Number: 78-15328-01
THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS M ANUAL ARE SUBJECT TO CHA NGE WITHOUT NO TICE. ALL
STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT
WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSI BILITY FOR THEIR APPLICA TION OF ANY PRODUCT S.
THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORT H IN THE INFORMATION PACKET T HAT
SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE
OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.
The Cisco implementation of TCP head er compressi on is an adap tation of a program developed by the Universi ty of Ca lifornia, Berk eley (UCB) as part of UCB ’s public
domain version of the UNIX operatin g system. All rights reserved . Copyri ght © 1981 , Rege nts of the Uni versity of Calif ornia.
NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THE SE SUPPLIERS ARE PROVIDED “AS IS” WITH
ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAI M ALL WARRANTIE S, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT
LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NO NINFRINGEM ENT OR ARISING FROM A COURS E OF
DEALING, USAGE, OR TRADE PRACTICE.
IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING ,
WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO
OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE S.
CCIP, CCSP, the Cisco Arrow logo, the Cisco Powered Network mark, the Cisco Systems Verified logo, Cisco Unity, Follow Me Browsing, FormShare, iQ Net Readiness
Scorecard, Networking Academy, and ScriptShare are trademarks of Cisco Systems, Inc.; Changing the Way We Wor k, Liv e, Pl ay, and L earn, The F astest Way to Increase
Your Internet Quotient, and iQuick S tudy are serv ice marks of Cisco Sys tems, Inc.; and Airo net, ASIS T, BPX, Cat alyst, C CDA, CCDP , CCIE, CCNA, CCNP, Cisco, the
Cisco Certified Internetwork Expert logo, Cisco IOS, the Cisco IOS logo, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Empo wering th e
Internet Generation, Enterpris e/Solv er, Ether Chann el, EtherS witch, Fas t Step, Gig aSt ack, Internet Quotient , IOS, I P/TV, iQ E xper tise, the iQ logo, LightStream, MGX,
MICA, the Networkers logo, Network Registrar, Packet, PIX, Post-Routing, Pre-Routing, RateMUX, Registrar, SlideCast, SMARTnet, StrataView Plus, Stratm, SwitchProbe,
TeleRouter, TransPath, and VCO are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries.
All other trademarks mentioned in this document or Web site are the property of their respective owners. The use of the word partner does not imply a partnership relationship
between Cisco and any other company. (0303 R))
Catalyst 6500 Series Switch Command Reference
Copyright © 1999 –2003, Cisco Systems, Inc.
All rights reserved.
Preface xxv
Audience xxv
Organization xxv
Related Documentation xxv
Conventions xxvi
Obtaining Documentation xxvii
Cisco.com xxvii
Documentation CD-ROM xxvii
Ordering Documentation xxvii
Documentat ion Feedback xxviii
Obtaining Technical Assistance xxviii
Cisco.com xxviii
Technical Assistance Center xxix
Obtaining Additional Publications and Information xxx
CONTENTS
CHAPTER
CHAPTER
1 Command-Line Interfac es 1-1
Switch CLI 1-1
Accessing the Switch CLI 1-1
Operating the Switch CLI 1-3
ROM Monitor CLI 1-13
Accessing the ROM Monitor CLI 1-13
Operating th e RO M Monitor CLI 1-13
2 Catalyst6500 Series Switch and ROM Monitor Commands 2-1
alias 2-2
boot 2-4
cd 2-5
clear acllog 2-6
clear alias 2-7
clear arp 2-8
clear banner motd 2-9
clear boot auto-config 2-10
78-15328-01
clear boot device 2-11
Catalyst 6500 Series Switch Command Reference—Release 7.6
iii
Contents
clear boot syst em 2-12
clear cam 2-13
clear cam noti fic a tio n 2-14
clear channel statistics 2-15
clear config 2-16
clear config pv la n 2-18
clear cops 2-19
clear counter s 2-21
clear crypto ke y rs a 2-22
clear dot1x con f ig 2-23
clear dot1x gue s t-vlan 2-24
clear gmrp stat is t ics 2-25
clear gvrp stat is tics 2-26
clear igmp statis tics 2-27
clear ip alias 2-28
clear ip dns domain 2-29
clear ip dns server 2-30
clear ip permit 2-31
clear ip route 2-33
clear kerberos clients mandatory 2-34
clear kerberos cr edentials forward 2-35
clear kerbero s cre ds 2-36
clear kerberos realm 2-37
clear kerbero s ser ver 2-38
clear key confi g-key 2-39
clear l2protocol-tunnel cos 2-40
clear l2protocol-tunnel statistics 2-41
clear lacp-channel statistics 2-42
clear lda 2-43
clear localus er 2-45
iv
clear log 2-46
clear log comma nd 2-47
clear logging buffer 2-48
clear logging lev el 2-49
clear logging ser ve r 2-51
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
clear mls cef 2-52
clear mls entry 2-53
clear mls entry cef adjacency 2-55
clear mls exclude protocol 2-56
clear mls multicast statistics 2-57
clear mls nde flow 2-58
clear mls statistics 2-59
clear mls statis tics entry 2-61
clear module password 2-63
clear multicast router 2-64
clear ntp server 2-65
clear ntp timezone 2-66
clear pbf 2-67
Contents
clear pbf-map 2-68
clear port broadcast 2-70
clear port cops 2-71
clear port host 2-72
clear port qos cos 2-73
clear port security 2-74
clear pvlan mapping 2-75
clear qos acl 2-76
clear qos config 2-78
clear qos cos-dscp-map 2-79
clear qos dscp-cos-map 2-80
clear qos ipprec-dscp-map 2-81
clear qos mac-cos 2-82
clear qos map 2-83
clear qos policed-dscp-map 2-85
clear qos policer 2-86
clear qos statistics 2-88
78-15328-01
clear radius 2-89
clear rcp 2-90
clear rgmp statistics 2-91
clear security acl 2-92
clear security acl capture-ports 2-94
Catalyst 6500 Series Switch Command Reference—Release 7.6
v
Contents
clear securit y ac l l og flo w 2-95
clear securit y ac l m ap 2-96
clear snmp access 2-98
clear snmp access-list 2-99
clear snmp community 2-100
clear snmp community-ext 2-101
clear snmp gro u p 2-102
clear snmp ifalia s 2-103
clear snmp not if y 2-104
clear snmp tar ge ta d dr 2-105
clear snmp targetparams 2-106
clear snmp tra p 2-107
clear snmp user 2-108
clear snmp vie w 2-109
clear spantree detected-protocols 2-110
clear spantree mst 2-111
clear spantree portcost 2-112
clear spantree portinstancecost 2-113
clear spantree portinstancepri 2-115
clear spantree portpri 2-116
clear spantree portvlancost 2-117
clear spantree portvlanpri 2-119
clear spantree root 2-120
clear spantree statistics 2-122
clear spantree uplinkfast 2-124
clear tacacs ke y 2-125
clear tacacs se rv e r 2-126
clear timezon e 2-127
clear top 2-128
clear trunk 2-129
vi
clear vlan 2-130
clear vlan coun te rs 2-132
clear vlan map pi ng 2-133
clear vmps rcp 2-135
clear vmps ser ve r 2-136
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
clear vmps statistics 2-137
clear vtp pruneeligible 2-138
clear vtp statistics 2-139
commit 2-140
commit lda 2-142
configure 2-143
confreg 2-145
context 2-147
copy 2-149
delete 2-155
dev 2-156
dir—ROM monitor 2-157
dir—switch 2-158
Contents
disable 2-160
disconnect 2-161
download 2-162
enable 2-166
format 2-167
frame 2-169
fsck 2-170
history—ROM monitor 2-172
history—switch 2-173
l2trace 2-174
meminfo 2-177
ping 2-178
pwd 2-181
quit 2-182
reconfirm vmps 2-183
reload 2-184
repeat 2-185
78-15328-01
reset—ROM monitor 2-187
reset—switch 2-188
restore counters 2-191
rollback 2-192
session 2-193
Catalyst 6500 Series Switch Command Reference—Release 7.6
vii
Contents
set 2-194
set accounting commands 2-195
set accounting connect 2-196
set accounting exec 2-197
set accounting suppress 2-199
set accounting system 2-200
set accounting update 2-202
set acllog ratelimit 2-203
set aclmerge algo 2-204
set aclmerge bdd 2-205
set alias 2-206
set arp 2-207
set authentication enable 2-209
set authentication login 2-211
set authorization commands 2-213
set authorization enable 2-215
set authorization exec 2-217
set banner lcd 2-219
set banner motd 2-220
set banner telnet 2-221
set boot auto-config 2-222
set boot config-register 2-223
set boot config-register auto-conf ig 2-226
set boot device 2-229
set boot sync now 2-231
set boot system flash 2-232
set cam 2-234
set cam notification 2-236
set cdp 2-239
set channelprot ocol 2-241
viii
set channel vlanc ost 2-243
set config acl nvram 2-245
set config mode 2-246
set cops 2-248
set crypto key rs a 2-250
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
set default portstatus 2-251
set dot1q-all-tagged 2-252
set dot1x 2-253
set enablepass 2-256
set errdisable-timeout 2-257
set errordetection 2-259
set feature agg-l ink-partner 2-261
set feature dot1x-radius-keepalive 2-262
set feature mdg 2-263
set garp timer 2-264
set gmrp 2-265
set gmrp fwdall 2-266
set gmrp registra tion 2-267
Contents
set gmrp timer 2-268
set gvrp 2-270
set gvrp applicant 2-271
set gvrp dynamic-vlan-creation 2-272
set gvrp registration 2-273
set gvrp timer 2-275
set igmp 2-277
set igmp fastblock 2-278
set igmp fastleave 2-279
set igmp flooding 2-280
set igmp leave-que ry-type 2-281
set igmp mode 2-282
set igmp ratelimit 2-283
set igmp querier 2-285
set igmp v3-processing 2-287
set inlinepower defaultallocation 2-288
set interface 2-289
78-15328-01
set ip alias 2-292
set ip dns 2-293
set ip dns domain 2-294
set ip dns server 2-295
set ip fragmentat ion 2-296
Catalyst 6500 Series Switch Command Reference—Release 7.6
ix
Contents
set ip http port 2-297
set ip http server 2-298
set ip permit 2-299
set ip redirect 2-301
set ip route 2-302
set ip unreachable 2-304
set kerberos clients mandatory 2-305
set kerberos credentials forward 2-306
set kerberos local-realm 2-307
set kerberos realm 2-308
set kerberos server 2-309
set kerberos srvtab entry 2-310
set kerberos srvtab remote 2-312
set key config-key 2-313
set l2protocol -tunnel cos 2-314
set l2protocol -tunnel trunk 2-315
set lacp-channel system-priority 2-316
set lcperroraction 2-317
set lda 2-318
set length 2-321
set localuser 2-322
set logging buffer 2-324
set logging console 2-325
set logging history 2-326
set logging level 2-327
set logging server 2-330
set logging session 2-332
set logging telnet 2-333
set logging timestamp 2-334
set logout 2-335
set mls agingtime 2-336
set mls bridged-flow-statistics 2-339
set mls cef load-balance 2-340
set mls cef per-prefix-statistics 2-341
set mls exclude protocol 2-342
Catalyst 6500 Series Switch Command Reference—Release7.6
x
78-15328-01
set mls flow 2-343
set mls nde 2-345
set mls rate 2-349
set mls statistics protocol 2-350
set mls verify 2-351
set module 2-353
set module name 2-355
set module power 2-356
set module shutdown 2-357
set msfcautostate 2-358
set msmautostate 2-360
set multicast router 2-361
set ntp broadcastclient 2-362
Contents
set ntp broadcastdelay 2-363
set ntp client 2-364
set ntp server 2-365
set ntp summertime 2-366
set ntp timezone 2-368
set password 2-369
set pbf 2-370
set pbf-map 2-372
set port arp-inspection 2-374
set port auxiliaryvlan 2-375
set port broadcast 2-377
set port channel 2-379
set port cops 2-382
set port debounce 2-383
set port disable 2-385
set port dot1q-all-tagged 2-386
set port dot1qtunnel 2-388
78-15328-01
set port dot1x 2-390
set port duplex 2-393
set port enable 2-394
set port errdisable-timeout 2-395
set port flowcontrol 2-396
Catalyst 6500 Series Switch Command Reference—Release 7.6
xi
Contents
set port gmrp 2-398
set port gvrp 2-399
set port host 2-401
set port inlinepower 2-402
set port jumbo 2-403
set port l2protocol-tunnel 2-404
set port lacp-channel 2-406
set port macro 2-408
set port membership 2-411
set port name 2-413
set port negotiation 2-414
set port protocol 2-415
set port qos 2-417
set port qos autoqos 2-419
set port qos cos 2-421
set port qos policy-source 2-422
set port qos trust 2-424
set port qos trust-device 2-426
set port qos trust-ext 2-427
set port rsvp dsbm-election 2-428
set port security 2-429
set port speed 2-432
set port sync-restart-delay 2-433
set port trap 2-434
set port unicast-flood 2-435
set port voice interface dhcp 2-437
set power redundanc y 2-439
set prompt 2-440
set protocolfi lter 2-441
set pvlan 2-442
xii
set pvlan mapping 2-444
set qos 2-446
set qos acl default-action 2-447
set qos acl ip 2-449
set qos acl ipx 2-454
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
set qos acl mac 2-457
set qos acl map 2-459
set qos autoqos 2-461
set qos bridged-mi croflow-policing 2-462
set qos cos-dscp-map 2-463
set qos drop-threshold 2-464
set qos dscp-cos-map 2-466
set qos ipprec-ds cp-map 2-467
set qos mac-cos 2-469
set qos map 2-470
set qos policed-dscp-map 2-473
set qos policer 2-474
set qos policy-source 2-477
Contents
set qos rsvp 2-479
set qos rxq-ratio 2-481
set qos statistics export 2-483
set qos statistics export aggregate 2-484
set qos statistics export destination 2-485
set qos statistics export interval 2-486
set qos statistics export port 2-487
set qos txq-ratio 2-488
set qos wred 2-490
set qos wrr 2-492
set radius attribute 2-494
set radius deadtime 2-495
set radius key 2-496
set radius retransmit 2-497
set radius server 2-498
set radius timeout 2-499
set rcp username 2-500
78-15328-01
set rgmp 2-501
set rspan 2-502
set security acl adjacency 2-505
set security acl arp-inspection 2-506
set security acl capture-ports 2-508
Catalyst 6500 Series Switch Command Reference—Release 7.6
xiii
Contents
set security acl feature ratelimit 2-509
set security ac l ip 2-510
set security ac l ipx 2-516
set security ac l log 2-519
set security ac l mac 2-520
set security ac l map 2-522
set snmp 2-524
set snmp access 2-525
set snmp access-list 2-527
set snmp buffer 2-529
set snmp chassis-alias 2-530
set snmp community 2-531
set snmp community-ext 2-533
set snmp extendedrmon netflow 2-535
set snmp group 2-536
set snmp ifalias 2-537
set snmp notify 2-538
set snmp rmon 2-539
set snmp rmonmemory 2-540
set snmp targetaddr 2-541
set snmp targetparams 2-543
set snmp trap 2-545
set snmp user 2-548
set snmp view 2-550
set span 2-552
set spantree backbonefast 2-555
set spantree bpdu-filter 2-556
set spantree bpdu-guard 2-557
set spantree bpdu-skewing 2-558
set spantree channelcost 2-559
xiv
set spantree channelvlancost 2-561
set spantree defaultcostmode 2-562
set spantree disable 2-564
set spantree enable 2-566
set spantree fwddelay 2-568
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
set spantree global-default 2-570
set spantree guard 2-572
set spantree hello 2-574
set spantree link-type 2-576
set spantree macreduction 2-577
set spantree maxage 2-578
set spantree mode 2-580
set spantree mst 2-582
set spantree mst config 2-583
set spantree mst link-type 2-585
set spantree mst maxh ops 2-586
set spantree mst vl an 2-587
set spantree portcost 2-588
Contents
set spantree portfast 2-590
set spantree portfast bpdu-filter 2-592
set spantree portfast bpdu-guard 2-593
set spantree portinstancecost 2-594
set spantree portinstancepri 2-596
set spantree portpri 2-598
set spantree portvlancost 2-599
set spantree portvlanpri 2-602
set spantree priority 2-604
set spantree root 2-606
set spantree uplinkfast 2-609
set summertime 2-611
set system baud 2-613
set system contact 2-614
set system core-dump 2-615
set system core-f ile 2-616
set system countrycode 2-617
78-15328-01
set system crossbar-fallback 2-618
set system highava ilability 2-619
set system highavailability versioning 2-620
set system location 2-622
set system modem 2-623
Catalyst 6500 Series Switch Command Reference—Release 7.6
xv
Contents
set system name 2-624
set system supervisor-update 2-625
set system switchmode allow 2-627
set system syslog-dump 2-629
set system syslog- file 2-630
set tacacs attempts 2-631
set tacacs directedrequest 2-632
set tacacs key 2-633
set tacacs server 2-634
set tacacs timeout 2-635
set test diagfai l-action 2-636
set test diaglev el 2-637
set time 2-638
set timezone 2-639
set traffic monitor 2-640
set trunk 2-641
set udld 2-644
set udld aggressive-mode 2-646
set udld interval 2-647
set vlan 2-648
set vlan mapping 2-652
set vmps downloadmethod 2-654
set vmps downloadserver 2-655
set vmps server 2-656
set vmps state 2-658
set vtp 2-659
set vtp pruneeligible 2-661
show accounting 2-662
show acllog 2-665
show aclmerge 2-666
xvi
show alias 2-667
show arp 2-668
show authentication 2-669
show authorization 2-670
show banner 2-671
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
show boot 2-672
show boot device 2-673
show cam 2-674
show cam agingtime 2-676
show cam count 2-677
show cam msfc 2-678
show cam notification 2-679
show cdp 2-682
show channel 2-685
show channel group 2-690
show channel hash 2-694
show channel mac 2-695
show channelproto col 2-696
Contents
show channel traffic 2-697
show config 2-698
show config mode 2-704
show config qos acl 2-705
show cops 2-706
show counters 2-709
show crypto key 2-715
show default 2-716
show dot1q-all-tagged 2-717
show dot1x 2-718
show dvlan statistics 2-719
show environment 2-720
show errdisable-timeout 2-725
show errordetection 2-726
show fabric channel 2-727
show file 2-730
show flash 2-731
78-15328-01
show garp timer 2-734
show gmrp configuration 2-735
show gmrp statistics 2-736
show gmrp timer 2-737
show gvrp configuration 2-738
Catalyst 6500 Series Switch Command Reference—Release 7.6
xvii
Contents
show gvrp statist ics 2-740
show ifindex 2-742
show igmp flooding 2-743
show igmp leave-query-type 2-744
show igmp mode 2-745
show igmp querier information 2-746
show igmp ratelimit-info 2-747
show igmp statistics 2-748
show imagemib 2-750
show interface 2-751
show ip alias 2-753
show ip dns 2-754
show ip http 2-756
show ip permit 2-758
show ip route 2-760
show kerberos 2-762
show l2protocol-tunnel statistics 2-764
show lacp-channel 2-766
show lcperroraction 2-770
show lda 2-771
show localuser 2-775
show log 2-776
show log command 2-778
show logging 2-779
show logging buffer 2-781
show mac 2-782
show microcode 2-785
show mls 2-786
show mls acl-route 2-788
show mls cef interface 2-789
xviii
show mls cef mac 2-791
show mls cef summary 2-792
show mls entry 2-794
show mls entry cef 2-800
show mls entry netflow-route 2-804
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
show mls exclude protocol 2-806
show mls multicast 2-807
show mls nde 2-812
show mls netflow-route 2-813
show mls pbr-route 2-814
show mls statistics 2-815
show mls verify 2-819
show module 2-820
show moduleinit 2-823
show msfcautostate 2-825
show msmautostate 2-826
show multicast group 2-827
show multicast group co unt 2-829
Contents
show multicast protocols status 2-830
show multicast router 2-831
show multicast v3-group 2-833
show netstat 2-834
show ntp 2-841
show pbf 2-843
show pbf-map 2-845
show port 2-846
show port arp-inspection 2-854
show port auxiliaryvlan 2-855
show port broadcast 2-857
show port capabilities 2-859
show port cdp 2-864
show port channel 2-866
show port cops 2-872
show port counters 2-874
show port debounce 2-876
78-15328-01
show port dot1q-all-tagged 2-877
show port dot1q-et hertype 2-878
show port dot1qtun nel 2-879
show port dot1x 2-880
show port errdisable-timeout 2-882
Catalyst 6500 Series Switch Command Reference—Release 7.6
xix
Contents
show port flowcontrol 2-884
show port inlinepower 2-886
show port jumbo 2-887
show port l2proto col-tunnel 2-888
show port lacp-cha nnel 2-889
show port mac 2-892
show port mac-addre ss 2-894
show port negotiat ion 2-896
show port prbs 2-897
show port protocol 2-898
show port qos 2-899
show port rsvp 2-902
show port security 2-903
show port spantree 2-906
show port status 2-907
show port sync-restart-delay 2-908
show port tdr 2-909
show port trap 2-911
show port trunk 2-912
show port unicast-flood 2-914
show port voice 2-915
show port voice acti ve 2-918
show port voice fdl 2-922
show port voice interface 2-924
show proc 2-925
show protocolfilter 2-929
show pvlan 2-930
show pvlan capabil ity 2-932
show pvlan mapping 2-934
show qos acl editbuffer 2-936
xx
show qos acl info 2-937
show qos acl map 2-939
show qos acl resourc e-usage 2-941
show qos bridged-microflow-policing 2-942
show qos info 2-943
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
show qos mac-cos 2-949
show qos maps 2-951
show qos policer 2-954
show qos policy-source 2-956
show qos rsvp 2-957
show qos statistics 2-958
show qos statisti cs export info 2-960
show qos status 2-961
show radius 2-962
show rcp 2-964
show reset 2-965
show rgmp group 2-966
show rgmp statisti cs 2-967
Contents
show rspan 2-968
show running-conf ig 2-970
show security acl 2-973
show security ac l ar p- inspection 2-976
show security acl capture-ports 2-977
show security ac l fe at u re ratelimit 2-978
show security ac l lo g 2-979
show security acl map 2-982
show security acl resource-usage 2-983
show snmp 2-984
show snmp access 2-986
show snmp access-list 2-988
show snmp buffer 2-989
show snmp community 2-990
show snmp context 2-992
show snmp counters 2-993
show snmp engineid 2-997
78-15328-01
show snmp group 2-998
show snmp ifalias 2-1000
show snmp notify 2-1001
show snmp rmonmemory 2-1003
show snmp targetaddr 2-1004
Catalyst 6500 Series Switch Command Reference—Release 7.6
xxi
Contents
show snmp targetparams 2-1006
show snmp user 2-1008
show snmp view 2-1010
show span 2-1012
show spantree 2-1014
show spantree backb onefast 2-1018
show spantree blockedports 2-1019
show spantree bpdu-filter 2-1021
show spantree bpdu- guard 2-1022
show spantree bpdu-skewing 2-1023
show spantree conflicts 2-1025
show spantree defaultcostmode 2-1027
show spantree guard 2-1028
show spantree mappin g 2-1030
show spantree mistp-instance 2-1032
show spantree mst 2-1034
show spantree mst config 2-1036
show spantree portfast 2-1038
show spantree portinstancecost 2-1039
show spantree portvlancost 2-1040
show spantree statistics 2-1041
show spantree summary 2-1048
show spantree uplinkfast 2-1051
show startup-con fig 2-1053
show summertime 2-1056
show system 2-1057
show system highavailability 2-1061
show system supervisor-update 2-1062
show system switchmode 2-1063
show tacacs 2-1064
xxii
show tech-support 2-1066
show test 2-1069
show time 2-1074
show timezone 2-1075
show top 2-1076
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
show top report 2-1078
show traffic 2-1080
show trunk 2-1081
show udld 2-1084
show users 2-1086
show version 2-1087
show vlan 2-1090
show vlan counters 2-1095
show vmps 2-1097
show vmps mac 2-1099
show vmps statistics 2-1100
show vmps vlan 2-1102
show vtp domain 2-1103
Contents
show vtp statisti cs 2-1105
slip 2-1107
squeeze 2-1108
stack 2-1109
switch 2-1110
switch console 2-1111
switch fabric 2-1112
sync 2-1113
sysret 2-1114
telnet 2-1115
test cable-diagnostics 2-1116
test snmp trap 2-1118
traceroute 2-1119
unalias 2-1122
undelete 2-1123
unset=varname 2-1124
varname= 2-1125
78-15328-01
verify 2-1126
wait 2-1127
whichboot 2-1128
write 2-1129
write tech-support 2-1132
Catalyst 6500 Series Switch Command Reference—Release 7.6
xxiii
Contents
APPENDIX
I
NDEX
A Acronyms A-1
xxiv
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Preface
This preface descri b es t he a udie nc e, o rganiza tio n, an d co nventions of th is pu bli cat ion an d p rovides
information on how to obtain related documentation.
Audience
This publication is for experi ence d network ad mini str ator s wh o a re r esp onsib le for configuri ng and
maintaining Catalyst 6500 series switches.
Organization
This publication is organized a s fo llows:
Chapter Title Description
Chapter 1 Command-Line
Chapter 2 Catalyst 6500 Series
Appendix A Acronyms Defines the acronyms used in this
Interfaces
Switch and ROM
Monitor Commands
Describes the two typ es of CL Is fo und on
Catalyst 6500 series switches.
Lists alphabetically and provides detailed
information for all Catalyst 6500 series
switch and ROM-monitor comma nds.
publication.
Related Documentation
Other documents in the Catalyst 6500 series switch documentation set include:
• Catalyst 6500 Series Switch Installation Guide
• Catalyst 6000 Series Switch Installation Guide
• Catalyst 6500 Seri es Sw itch M odule I nstall ation Gui de
• Catalyst 6500 Seri es Sw itch S oft ware Configuration Gui de
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
xxv
Conventions
For information about MI Bs, refer to:
http://www.cisco.com/public/sw-center/netmgmt/cmtk/mibs.shtml
Conventions
This publication uses the following conventions:
Preface
• System Message Guide—Catalyst 650 0 Series, Cata lyst 4000 Family, Catalyst 2948G, and
Catalyst 2980G Switches
• Catalyst 6500 Seri es Sw itch Q uick Sof tware Configuration Gu ide
• ATM Software Configuration Guide and Command Reference for the Catalyst 5000 Family and 6000
Family Switches
• Release Notes for Catalyst 6500 Series Switch
Convention Description
boldface font Commands, command op tions, an d keywords are in
boldface.
italic font Arguments for which you supply values are in ita li cs.
[ ] Elements in square brackets are optional.
{ x | y | z } Alternative keywords are grouped in braces and separated by
vertical bars.
[ x | y | z ] Optional alterna tive keywords are grouped in brac kets and
separated by vertical ba rs.
string A nonquoted set of characters. Do no t use quotatio n marks
around the string or the string will include the quotation
marks.
screen font Terminal sessions and information the system displays are in
screen font.
boldface screen
Information you must enter is in boldface screen font.
font
italic screen font Arguments for which you supply values are in ita lic s c reen
font.
^ The symbol ^ r epre se nts t he key labe led Con trol— fo r
example, the key combination ^D in a screen display means
hold down the Control key while you press the D key.
< > Nonprinting char acters, suc h as passwords are in angle
brackets.
[ ] Default responses to system prompts are in square brackets.
!, # An exclamation point (!) or a pound sign (#) at the beginning
of a line of code indicates a comment line.
xxvi
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Preface
Notes use the following conventions:
Note Means reader take note. Notes contain helpful suggestions or references to material not covered in the
publication.
Obtaining Documentation
Cisco provides several ways to obtain documentation, techn ical assistance , and other tec hnical
resources. These sect ion s expla in h ow to obta in te chni cal infor ma tion fr om Ci sco Sy stem s.
Cisco.com
You can access the m ost cur rent C isco docum ent ation on the World Wide Web at this U RL:
http://www.cisco.com/univercd/home/home.htm
You can access the Cisco website at this URL:
Obtaining Documentation
http://www.cisco.com
International Cisco web sites can be accessed from this URL:
http://www.cisco.com/public/countries_languages.shtml
Documentation CD-ROM
Cisco documentation and additional literature are available in a Cisco Documentation CD-ROM
package, which may have shipped with your product. The Documentation CD-ROM is updated monthly
and may be more curre nt than printed do cumentati on. The CD-R OM pack age is av ailable as a single unit
or through an an nual su bscript ion.
Registered Cisco.com users can order the Documentation CD-ROM (product number
DOC-CONDOCCD=) through the online Subscription Store:
http://www.cisco.com/go/subscription
Ordering Documentation
You can find instruct ions for orde ring do cu me nta tio n at this U RL:
http://www.cisco.com/univercd/cc/td/doc/es_inpck/pdi.htm
You can order Cisco documentati on in these way s:
78-15328-01
• Registered Cisco.com users (Cisco direct customers) can order Cisco product documentation from
the Networking Produ cts Market Pla ce:
http://www.cisco.com/en/US/partner/ordering/index.shtml
• Registered Cisco.com users can order the Documentation CD-ROM (Customer Order Number
DOC-CONDOCCD=) through the online Subscription Store:
http://www.cisco.com/go/subscription
Catalyst 6500 Series Switch Command Reference—Release 7.6
xxvii
Obtaining Technical As sistance
• Nonregistered Cisco.co m u ser s can o rd er docum en tati on th rou gh a l oc al ac count r epre sen tative by
calling Cisco Systems Corpo rate Headqu arter s (Califo rnia, U.S.A. ) at 408 526-7208 or, elsewhere
in North America, by calli ng 800 55 3-NE TS (6387).
Documentation Feedback
You can submit comments elec troni call y on Cisc o.com . On the Cisco D ocume nta tio n home pag e, click
Feedback at the top of the page.
You can e-mail your comm ents to bug-doc @cisco. com.
You can submit your commen ts by mail by using the re sponse card behin d the front cover of your
document or by wri ting t o the fo llowing a ddress:
Cisco Systems
Attn: Customer Docume nt Ordering
170 West Tasman Drive
San Jose, CA 95134- 988 3
We apprecia te your co mm ents .
Preface
Obtaining Technical Assistanc e
Cisco provides Cisco.com, which includes the Cisco Technical Assistance Center (TAC) Website, as a
starting point for all technical assistance. Customers and partners can obtain online documentation,
troubleshooting tips, and sample configurations from the Cisco T AC website. Cisco.com registered users
have complete access to the technical support resources on the Cisco TAC website, including TAC tools
and utilities.
Cisco.com
Cisco.com offers a suite of in tera ct ive, networked servi ces th at let y ou ac cess Cisc o in for matio n,
networking solutions, services, pr ogram s, and re sources at any time, from anywhe re in the world.
Cisco.com provides a br oad r ange of fea tur es an d s er vice s to h elp you wi th th ese ta sks:
• Streamline business processes and improve productivity
• Resolve technical issues with online support
• Download and te st so ft war e pa ck ag es
• Order Cisco learning m ateri als and me rcha ndise
• Register for online skill assessment, training, and certification programs
To obtain customized information and service, you can self-register on Cisco.com at this URL:
http://www.cisco.com
xxviii
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Preface
Technical Assistance Center
The Cisco TAC is available to all customers who need technical assistance with a Cisco product,
technology, or solution. Two levels of support are available: the Cisco TAC website and the Cisco TAC
Escalation Center. The avenue of support that you choose depends on the priority of the problem and the
conditions stated in service contracts, when applicable.
We categorize Ci sco TAC inquiries according to urgency:
• Priority level 4 (P4)—You need information or assistance conc erni n g Cisc o pr odu ct c apa bil ities,
product installation, or basi c product configuration.
• Priority level 3 (P3)—Your network performance is degraded. Ne twork functio nality i s noticeab ly
impaired, but most business operations continue.
• Priority level 2 (P2)—Your production network i s severely degraded, affecting signi ficant aspect s
of business operations. No workar oun d is available.
• Priority level 1 (P1)—Y our production network is down, and a critical impact to business operations
will occur if se rv ice is n ot r esto re d qui ck ly. No workaround i s available.
Cisco TAC Website
Obtaining Technical Assistance
You can use the Cisco T AC website to resolve P3 and P4 issues yourself, saving both cost and time. The
site provides around-t he-c lock acc ess t o on lin e tools, kn owledge ba ses, an d so ftware . To access the
Cisco TAC website, go to this URL:
http://www.cisco.com/tac
All customers, partners, and resellers who have a valid Cisco service contract have complete access to
the technical support resources on the Cisco TAC website. Some services on the Cisco TAC website
require a Cisco.co m login ID and password. If you have a valid service contract but do not have a login
ID or password, go t o th is URL to register :
http://tools.cisco.com/RPF/register/register.do
If you are a Cisco.com registere d user, and you cannot resol ve your tech ni cal issues by using the Cisco
TAC website, you can open a case online at this URL:
http://www.cisco.com/en/US/support/index.html
If you have Internet access, we recommend that you open P3 and P4 cases th rough the Cisco TAC
website so that y ou ca n desc ribe the s ituati on in your own wor ds an d a ttac h any nece ssar y files.
Cisco TAC Escalation Center
The Cisco TAC Escalation Center addresses priority level 1 or priority level 2 issues. These
classifications are assigned when severe network degradation significantly impacts business operations.
When you contact the TAC Escalation Center with a P1 or P2 problem, a Cisco TAC engineer
automatically opens a case.
78-15328-01
To obtain a d ire ctor y o f t oll- fr ee C isco TAC telephone numbers for yo ur count r y, go to this UR L:
http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml
Before calling, please check with your network operations center to determine the level of Cisco support
services to which your company is entitled: for example, SMARTnet, SMARTnet Onsite, or Network
Supported Account s (NSA ). W he n you c all t he ce nte r, please have available your serv ice agre eme nt
number and your product seri al number.
Catalyst 6500 Series Switch Command Reference—Release 7.6
xxix
Obtaining Additiona l Publications and Informatio n
Obtaining Additional Publications and Information
Information about Cisco products, technologies, and network solutions is available from various online
and printed sources.
• The Cisco Product Catalog describes the networking products offered by Cisco Systems as well as
ordering and custome r support ser vices. Access the Cisco Product Catalog at this URL:
http://www.cisco.com/en/US/products/products_catalog_links_launch.html
• Cisco Press publishes a wid e ran ge of n etworki ng pub l icatio ns. Cisco suggest s the se t itle s for new
and experienced users: Internetworking Terms and Acronyms Dictionary, Internetworking
Technology Handbook, I ntern etwo rkin g Troubleshooting Guide, and the Inter netw ork ing D esi gn
Guide. For current Cisco Press titles and other information, go to Cisco Press online at this URL:
http://www.ciscopress.com
• Packet magazine is the Cisco monthly periodical that provides industry professionals with the latest
information about t he field of net working. You can access Packet magazine at this URL:
http://www.cisco.com/en/US/about/ac123/ac114/about_cisco_packet_magazine.html
• iQ Magazine is the Cisco monthly periodical that provides business leaders and decisi on makers
with the latest information about the networkin g industry. You can access iQ Magazin e at this URL:
http://business.cisco.com/prod/tree.taf%3fasset_id=44699&public_view=true&kbns=1.html
Preface
• Internet Protocol Journal is a quarterly journal published by Cisco Systems for engin eering
professionals involved in the design, development, and operation of public and private internets and
intranets. You can access the Internet Protocol Journal at this URL:
http://www.cisco.com/en/US/about/ac123/ac147/about_cisco_the_internet_protocol_journal.html
• Training—Cisco offers world-class networking traini ng, with current offerings in network traini ng
listed at this URL:
http://www.cisco.com/en/US/learning/le31/learning_recommended_training_list.html
xxx
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Switch CLI
CHAPTER
1
Command-Line Interfaces
This chapter describes the command-line interfaces (CLI) available on the Catalyst 6500 series switches
and contains the se sect ion s:
• Switch CLI, page 1-1
• ROM Monitor CLI, page 1-13
For information regarding the A TM CLI and commands, refer to the ATM Software Configuration Guide
and Command Reference—Catalyst 5000 Family and 6000 Family Switches publication.
For information regar ding th e ID SM C LI a nd c omm an ds, r ef er t o t he Catalyst 6500 Series Switch
Intrusion Detection System Module Installation and Configuration Note publication.
For definitions of terms and acronyms listed in this publication, see Appendix A, “Acronyms.”
Catalyst 6500 series switches are multimodule systems. Commands you enter from the CLI can apply to
the entire system or to a specific module, port, or VLAN.
Y ou can configure and maintain the Catalyst 6500 series switches by entering commands from the switch
CLI. The CLI is a basic command-line interpreter similar to the UNIX C shell. Using the CLI session
command, you can access th e router configuratio n software and perform tasks suc h as histor y
substitution and alias creation.
Note The Catalyst 6500 series consists of the Catalyst 6500 and 6000 series switches. The Catalyst 6500 series
consists of the Catalyst 600 6, 6009, 6506, 6509, 650 9-NEB, an d 6513 swit ches. Throug hout thi s
publication and all Catalyst 6500 series switch docum ents , the phrase Catalyst 65 00 series switches
refers to these s wit che s, unl ess o th erw ise note d.
Accessing the Switch CLI
You can access the switch CLI from a console terminal co nnected to an EIA /TIA-232 port or th rough a
Telnet session. The CLI allows fixed baud rates. Telnet sessions disconnect automatically after
remaining idle for a user-defined time period.
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
1-1
Switch CLI
Note EIA/TIA-232 was known as RS-232 before its acceptanc e as a standard by the Electron ic Industri es
Alliance and Telecommunications Industry Association.
Accessing the Switch CLI Through the Console Port (EIA/TIA-232)
To access the switch through the console (EIA/TIA-232) port, perform these steps:
Task Command
Step 1
Step 2
Step 3
Step 4
From the Cisco Systems Con sole
prompt, press Return.
At the prompt, enter the system
password. The
Console> promp t
<password>
appears, indicati ng that you have
accessed the CLI in normal mode.
Enter the necessary commands to
Appropriate commands
complete your desired tasks.
When finished, exit the session. quit
Chapter1 Command-Line Interfaces
After connecting thr ough t he con sol e po rt, yo u see thi s displa y:
Cisco Systems Console
Enter password:
Console>
Console>
Accessing the Switch CLI Through Telnet
To access the switch through a Telnet session, you must first set the IP address for the switch. You can
open multiple sessions to the switch through Telnet.
To access the switch from a remote host with Telnet, perform these steps:
Task Command
Step 1
Step 2
Step 3
Step 4
From the remote host, enter the
telnet command and the nam e or
IP address of the sw itch yo u want
to access.
At the prompt, enter the password
for the CLI. If no pa ssword h as
been configured, press Return .
Enter the necessary commands to
complete your desired tasks.
When finished, exit the Telnet
session.
telnet hostname | ip_addr
<password>
Appropriate commands
quit
1-2
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 1 Command-L ine Interfaces
After connecting thr ough a Telnet session, you see t his displa y:
host% telnet cat6000-1.cisco.com
Trying 172.16.44.30 ...
Connected to cat6000-1.
Operating the Switch CLI
This section describes co mmand mode s and funct ions that allow you to opera te the switch CLI.
Accessing the Command Modes
The CLI has two modes of operation : normal and privileged. Both are password -prote cted. Use
normal-mode com mand s fo r everyday syst em moni tor ing. U se pr ivileged co mm an ds for syst em
configuration and basic trou bleshoot ing.
After you log in, the system enter s normal mode, wh ich gives you access to normal- mode comm ands
only. You can en ter p rivileged mode by entering the enable comm and fo llo we d b y the ena ble pass wo rd.
Privileged m ode is indicated b y the word “enab le” in the system prompt. To return to normal mode, enter
the disable command at the prompt.
Switch CLI
The following exam pl e s h ows how to en te r pr ivileged m od e:
Console> enable
Enter password: <password>
Console> (enable)
Using Command-Line Processing
Switch commands are not case sensitive. You can abbreviate commands and parameters as long as they
contain enough l et ters to be differe nt fr om any ot her cu rre ntly available com ma nd s or pa rame ter s. You
can scroll through the las t 20 comm ands store d in the hist ory buffer and enter or ed it the comm and at
the prompt. (See Table 1-1.)
Table 1-1 Command-Line Processing Keystroke
Keystroke Function
Ctrl-A Jumps to the first ch arac te r of the c omman d lin e.
Ctrl-B or the left arrow key Moves the cursor back one character.
Ctrl-C Escapes and terminates prompts and tasks.
Ctrl-D Deletes the character at the cursor.
Ctrl-E Jumps to the e nd o f t h e cu rre nt co mm an d l ine .
Ctrl-F or the rig ht arr ow key
Ctrl-K Deletes from the cursor to the end of the command line.
Ctrl-L; Ctrl-R Repeats cu rrent comm and line on a new line.
Ctrl-N or th e down arrow key
Ctrl-P or the up a rrow key
Ctrl-U; Ctrl-X Deletes from the cursor to the beginning of the command line.
Ctrl-W Deletes last word typed.
1
Moves the cursor forward one character.
1
Enters next command l ine in the hist ory buffer.
1
Enters previous command line in the history buffer.
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
1-3
Switch CLI
Table 1-1 Command-Line Processing Keystroke (continued)
Keystroke Function
Esc B Moves the cursor back one word.
Esc D Deletes from the cursor to the end of the word.
Esc F Moves the cursor forward one word.
Delete key or Backspace key Erases a mistake when entering a command; reenter the
1. The arrow keys function only on ANSI-compatible terminals such as VT100s.
Using the Command-Line Editing Features
Catalyst 6500 serie s switch s o ftware inc ludes an e nhanc ed e dit ing mo de th at p rovides a se t of edi ting
key func tio ns similar to those of t he Em ac s ed ito r. You can enter commands in u pper ca s e, lowercase, or
a mix of both. Onl y password s a re case se nsitive. You can abbreviate commands and keywords to the
number of characters th at allow a unique a bbreviation.
For example, you can abbreviate th e show command to sh. After enter in g t h e co mm an d at th e s yst em
prompt, press Return to execute the command.
Chapter1 Command-Line Interfaces
command after using this key.
Moving Around on the Command Line
Perform one of these task s to move the cursor ar ound on the co mmand line for c orrect ions or cha nges:
Task Keystrokes
Move the cursor back one character. Press Ctrl-B or press the left arrow key
Move the curso r forward on e character . Press Ctrl-F or press the right arrow key1.
Move the cursor to the beginning of the
command line.
Move the cursor to the end of the
command line.
Move the cursor bac k one wo rd. Press Esc B.
Move the cursor forward one word. Press Esc F.
1. The arrow keys function only on ANSI-compatible terminals such as VT100s.
Completing a Partial Command Name
If you cannot remember a complete com mand name, press th e Tab key to allow the system to complete
a partial entry. To do so, perform this task:
Press Ctrl-A.
Press Ctrl-E.
1
.
1-4
Task Keystrokes
Complete a command name. Enter the first few letters and press the
Tab ke y.
If your keyboard does n ot h ave a Tab key, press Ctrl-I instea d.
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 1 Command-L ine Interfaces
In the following ex ample, whe n you enter the letters conf and press the Tab key, t he system pro vides the
complete comman d:
Console> (enable) conf<Tab>
Console> (enable) configure
If you enter a set of ch aract ers tha t could ind icate mo re than one com mand, th e sys tem be eps to in dica te
an error . Enter a question mark (?) to obtai n a list of commands that begi n with that set of character s. Do
not leave a space between the last letter and the question mark (?). For example, three commands in
privileged mode start with co. To see what they are, enter co? at the privileged pro mpt. The sys tem
displays all commands that begin with co, as follows:
Console> (enable) co?
configure connect copy
Pasting in Buffer Entries
The system provides a buffer that contains th e la st ten items you deleted. You can recall these items and
paste them in the command line by performing this task:
Switch CLI
Task Keystrokes
Recall the most recent entry in the
buffer.
Recall the next buffer entry. Press Esc Y.
The buffer contains only the last ten items you have deleted or cut. If you press Esc Y more than ten
times, you cycle back to the first buffer entry.
Editing Command Lines That Wrap
The new editing comma nd set pro vides a wr aparoun d featur e for comman ds that exten d be yond a single
line on the screen. When the cursor reaches the right margin, the command line shifts ten spaces to the
left. You cannot see the first ten chara cter s of the line, but you can scroll back a nd chec k the syntax at
the beginning of the co mman d. To scroll back, per for m this ta sk:
Task Keystrokes
Return to the beginning of a
command line to verify that you
have entered a lengthy comm a nd
correctly.
1. The arrow keys function only on ANSI-compatible terminals such as VT100s.
Press Ctrl-Y.
Press Ctrl-B or the left arrow key repeatedly until
you scroll back to the beginning of the comm and
entry, or press Ctrl-A to return directly to the
beginning of the line
1
.
78-15328-01
Use line wrapping wit h the comm and hi story fea ture to rec all and modi fy previous comp lex comman d
entries. See the “Using History Substitution” section on page 1 -8 fo r informa tion ab out reca lling
previous command entries.
The system assumes your terminal screen is 80 columns wide. If your screen has a different width, enter
the terminal width command to tell the router the correct width of your screen.
Catalyst 6500 Series Switch Command Reference—Release 7.6
1-5
Switch CLI
Deleting Entries
Perform one of these task s to delete com mand entri es if you make a mista ke or change your mind:
Task Keystrokes
Erase the character to the left of the cursor. Press the Delete or Backspace key.
Delete the character at the cursor. Press Ctrl-D.
Delete from the cursor to the end of the
command line.
Delete from the cursor to the beginning of the
command line.
Delete the word to the left of the cursor. Press Ctrl-W.
Delete from the cursor to the end of the wo rd. Press Esc D.
Scrolling Down a Line or a Screen
When you use the help facilit y to l ist the comm ands in a p articula r mode, the list is often longe r than th e
terminal screen can disp lay. In such cases, a ---More--- prompt is displaye d at th e botto m of the scr een .
To view the next line or screen, perform these tasks:
Chapter1 Command-Line Interfaces
Press Ctrl-K.
Press Ctrl-U or Ctrl-X.
Task Keystrokes
Scroll down one line. Press the Return key.
Scroll down one screen . Press the Spacebar.
Note The ---More-- - p rompt is us ed for a ny output tha t ha s m or e line s t han ca n b e di spla yed on the ter mina l
screen, includ ing show com mand ou tput .
Scrolling to Specified Text
If you enter /text and press the Return key at the --More-- prompt, the display starts two lines above the
line containing the text string. If the text strin g is no t fo und , “Patt ern N ot Found” is di spla yed. You can
also enter “ n” at the --More-- prompt to search for the last entered text string. You can use this search
method on all show commands that use the more bu f fer to disp lay scre en b y screen o uput. Th e follo wing
is a list of show commands that do not use the more buffer and do not support this feature:
• show cam
• show mls
• show tech-support
1-6
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 1 Command-L ine Interfaces
Redisplaying the Current Command Line
If you enter a command an d the system sudd enly sends a message to your sc reen , you can recal l your
current comm and lin e en try. To do so, perform this t ask:
Task Keystrokes
Redisplay the current command line. Press Ctrl-L or Ctrl-R.
Transposing Mistyped Characters
If you mistype a co mma nd e ntry, you can tra nspo se the m isty ped c hara ct er s by perf orm ing thi s ta sk:
Task Keystrokes
Transpose the character to the left of the
cursor with the character located at the
cursor.
Switch CLI
Press Ctrl-T.
Controlling Capitalization
You can change words to uppercas e or lowercase , or capita lize a set of let ters, w ith simpl e keystroke
sequences:
Task Keystrokes
Capitalize at the cursor. Press Esc C.
Change the word at the cursor to lowercase. Press Esc L.
Capitalize letters from the cursor to the end
of the word.
Designating a Keystroke as a Command Entry
Yo u can use a particular keystroke as an executable command. Perform this task:
Task Keystrokes
Insert a code to indicat e to the system t hat the
keystroke immediately f ollowing s hould be
treated as a command entry, not an editing
key.
Press Esc U.
Press Ctrl-V or Esc Q.
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
1-7
Switch CLI
Using Command Aliases
Like regular commands, aliases are not case sensitive. Howev er , unlike regular commands, some aliases
cannot be abbreviated. See Table 1-2 for a list of switch CLI aliases that cannot be abbreviated.
Table 1-2 Switch CLI Command Aliases
Alias Command
batch configure
di show
earl cam
exit quit
logout quit
Using History Substitution
Commands that you enter du ring each term inal session are stor ed in a histor y buffer, which stores the
last 20 commands you entered during a terminal session. History substitution allows you to access these
commands witho ut ret ypi ng them by u sin g specia l a bbr eviated c om mands. ( See Table 1-3.)
Chapter1 Command-Line Interfaces
Table 1-3 History Substitution Commands
Command Function
To repeat recent commands:
!! Repeat the most rece nt comm and.
!-nn Repeat the nnth most recent command.
!n Repeat command n.
!aaa Repea t the comma nd beginnin g with stri ng aaa.
!?aaa Repeat the command containing the string aaa.
To modify and repeat the most recent command:
^aaa^bbb Replace string a aa wit h string bb b i n t he most rece nt
command.
To add a string to the end of a previous command and repeat it:
!!aaa Add string aaa to the end of the most recent command.
!n aaa Add string aaa to the end of command n.
!aaa bbb Ad d string bbb to th e end of the com mand beginni ng with
string aaa.
!?aaa bbb Add string bbb to the end of the com mand cont aining st ring
aaa.
1-8
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 1 Command-L ine Interfaces
Accessing Command Help
To see a list of top-level commands and command categories, type help in normal or privileged mode.
Context-sensitive help (usage and sy ntax inf orm atio n) for i nd ividual com mands c an be s een by
appending help to any specif ic comm and. If you ente r a command usin g the wrong numb er of argu ments
or inappropriate arguments, usage and syntax i n formation for that command is displayed. Additionally,
appending help to a command category displays a list of commands in that category.
Top-Level Commands and Command Categories
In normal mode, use the help command to display a list of top-le vel comman ds and command c ategories,
as follows:
Console> help
Commands:
---------------------------------------------------------------------cd Set default flash device
dir Show list of files on flash device
enable Enable privileged mode
help Show this help screen
history Show contents of history substitution buffer
l2trace Layer2 trace between hosts
ping Send echo packets to hosts
pwd Show default flash device
quit Exit from the Admin session
session Tunnel to ATM or Router module
set Set commands, use 'set help' for more info
show Show commands, use 'show help' for more info
traceroute Trace the route to a host
verify Verify checksum of file on flash device
wait Wait for x seconds
whichboot Which file booted
Console>
Switch CLI
In privileged mode, enter the help command to display a l ist of t op -level comma nd s a nd comm an d
categories, as fo llows:
Console> (enable) help
Commands:
---------------------------------------------------------------------cd Set default flash device
clear Clear, use 'clear help' for more info
commit Commit ACL to hardware and NVRAM
configure Configure system from network
copy Copy files between TFTP/RCP/module/flash devices
delete Delete a file on flash device
dir Show list of files on flash device
disable Disable privileged mode
disconnect Disconnect user session
download Download code to a processor
enable Enable privileged mode
format Format a flash device
help Show this help screen
history Show contents of history substitution buffer
l2trace Layer2 trace between hosts
ping Send echo packets to hosts
pwd Show default flash device
quit Exit from the Admin session
reconfirm Reconfirm VMPS
reload Force software reload to linecard
reset Reset system or module
rollback Rollback changes made to ACL in editbuffer
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
1-9
Switch CLI
Command Categories
Chapter1 Command-Line Interfaces
session Tunnel to ATM or Router module
set Set commands, use 'set help' for more info
show Show commands, use 'show help' for more info
slip Attach/detach Serial Line IP interface
squeeze Reclaim space used by deleted files
switch Switch to standby <clock|supervisor>
telnet Telnet to a remote host
test Test command, use 'test help' for more info
undelete Undelete a file on flash device
upload Upload code from a processor
verify Verify checksum of file on flash device
wait Wait for x seconds
whichboot Which file booted
write Write system configuration to terminal/network
Console> (enable)
On some commands (such as clear, set, and show), typing help after the comman d provid es a lis t of
commands in that category. For example, this display shows a partial list of commands for the clear
category:
Console> (enable) clear help
Clear commands:
---------------------------------------------------------------------------clear alias Clear aliases of commands
clear arp Clear ARP table entries
clear banner Clear Message Of The Day banner
clear boot Clear booting environment variable
clear cam Clear CAM table entries
clear channel Clear PAgP statistical information
.
.
.
Context-Sensitive Help
Usage and synt ax i n forma tio n for i nd ividual c om mands ca n be se en by a pp endi ng help to any specific
command. For example, the fol lowing disp lay shows usa ge and syntax i nform atio n for th e set length
command:
Console> set length help
Usage: set length <screenlength> [default]
(screenlength = 5..512, 0 to disable 'more' feature)
Console>
Designating Modules, Ports, and VLANs
The Catalyst 650 0 series modul es (modu le s lots ), port s, an d VLANs a re numbe red st art ing wit h 1. The
supervisor engine modul e is module 1, re siding in the top slot. On each module , port 1 is the lef tmost
port. To reference a specific port on a specific module, the command syntax is mod/port. For example,
3/1 denotes module 3, port 1. In some commands, such as set trunk, set cam, and set vlan, you can enter
lists of ports and VLANs.
1-10
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 1 Command-L ine Interfaces
You can designate ports by entering the module and port number pairs, separated by commas. To specify
a range of po rts, use a d as h ( -) bet wee n the mo dul e n umb er a nd port n umb er pai rs . Da shes take
precedence over co mm as . Th e fol lowing exam ple s sh ow several way s o f designating p orts :
Switch CLI
Example 1: 2/1, 2/3
Example 2: 2/1- 12
Example 3: 2/1- 2/12
denotes module 2, port 1 and mod ule 2, port 3.
denotes modul e 2 , port s 1 thro ugh 12 .
also denotes mod ule 2, ports 1 throu gh 12.
Each VLAN is designated by a single number. You can specify lists of VLANs the same way you do for
ports. Individual VL ANs are se para ted by co mm as (, ); ran ge s are s epar ate d by d ashes (- ). In t he
following example, VLA Ns 1 t hrough 1 0 a nd VL AN 100 0 are speci fied:
1-10,1000
Designating MAC Addresses, IP and IPX Addresses, and IP Aliases
Some commands require a MAC address that you must designate in a standard format. The MAC address
format must be six hexadeci mal nu mb ers se para ted by hyp hen s, as shown in thi s exampl e:
00-00-0c-24-d2-fe
Some commands require an IP address. Th e IP a ddress forma t is 32 bits, written a s four octets sepa rated
by periods (dotted de ci mal fo rmat ). I P a dd resses a re m ade up of a ne twor k sec tion, a n o ptiona l su bne t
section, and a host section, as shown in this example:
126.2.54.1
If DNS is configured pr operl y on t he sw it ch, you can us e IP host na me s inste ad o f I P a dd resses . For
information on conf iguring DNS, refer to the Catalyst 6500 Series Switch Software Configuration Guide.
If the IP alias table is configured, you can use IP aliases in place of the dotted decimal IP address. This
is true for most commands that use an IP address, except commands that define the IP address or IP alias.
When entering th e IPX addres s synta x, use th e following format :
• IPX net address—1..FFFFFFFE
• IPX node address—x.x.x where x is 0..FFFF
• IPX address—ipx_net.ipx_ node (f or example 3.003 4.1245 .AB45 , A43.000 0.0000 .0001)
Using Command Completion Features
The command com ple tion f eatur es cons ist of th ese functi ons:
• Using Command Self-Repeat
• Using Keyword Lookup
• Using Partial Keyword Lookup
• Using Command Completion
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
1-11
Switch CLI
Using Command Self-Repeat
Use the command self-r epeat function to display mat ches to all possible keywords if a string represents
a unique match. If a unique match is not found, the longest matching string is provided. To display the
matches, enter a space after the last parameter and enter ?. Once the matches a re di spla yed, the system
comes back to the prompt and displays the last command without the ?. In the following example, notice
how the system repeats the command en tered w ithout the ?:
Console> (enable) set mls nde
disable Disable multilayer switching data export filter
enable Enable multilayer switching data export filter
engineer Engineer setting of the export filter
flow Setting multilayer switching export filter
<collector_ip> IP address
Console> (enable) set mls nde
Using Keyword Lookup
Use the keyword-lookup funct ion to disp lay a lis t of valid keywords an d argument s fo r a com ma nd. To
display the matches, enter a space after the last parameter and enter ?. For example, five parameters are
used by the set mls command. To see these parameters, enter set mls ? at the privileged prompt. In the
following example, notice how the system re peats t he comma nd entere d without the ?:
Console> (enable) set mls ?
agingtime Set agingtime for MLS cache entry
exclude Set MLS excluded protocol ports
flow Set minimum flow mask
nde Configure Netflow Data Export
statistics Add protocols to protocol statistics list
Console> (enable)
Chapter1 Command-Line Interfaces
set mls
Using Partial Keyword Lookup
Use the partial keyword-look up f unct ion to di spla y a l ist of c omm an ds tha t begin wit h a sp ec ific set of
characters. To display the matches, en ter ? immediatel y after th e last p aram eter. For example, enter co?
at the privileged prompt to display a list of commands that start with co. The system displays all
commands that begin wit h co and repe ats the comm and en tered w ithout th e ?:
Console> (enable) co?
commit Commit ACL to hardware and NVRAM
configure Configure system from network
copy Copy files between TFTP/RCP/module/flash devices
Console> (enable)
Using Command Completion
Use the command comple tion fun ction to complet e a comma nd or keyword. When you ente r a uniq ue
partial character string and press Tab, the syste m completes the command or keyword on the command
line. For example, if you enter co at the privileged prompt and press Tab, the system completes the
command as configure because it is the only command that matches the criteria.
If no completion ca n be done, no a ction i s carr ied o ut an d the syst em re tu rns to the p rom pt and t he last
command. The c urso r ap pear s imm ed iat el y a fte r t he keyword, al lowing y ou to e nt er ad dit iona l
information.
co
1-12
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 1 Command-L ine Interfaces
ROM Monitor CLI
The ROM monitor is a ROM-based program that executes upon platf orm start up, reset , or when a fatal
exception occurs.
Accessing the ROM Monitor CLI
The system enters R OM-m onitor mod e if the switch doe s not find a valid system image, if the NVRAM
configuration is corrupted, or if the configuration register is set to enter ROM-monitor mode. From the
ROM-mo nitor mod e, you ca n load a s yst em image ma nua lly from Flash memory, from a network server
file, or from bootflash. You can also enter R OM-monitor mode by restarting the switch and pressing the
Break key during the first 60 seconds of startup.
Note Break is always enabled for 60 seconds af ter rebooti ng the system , regardless of wheth er Break is
configured to be off by configuration register settin gs.
To connect through a terminal server, escape to the Telnet prompt, and enter the send break command
to break back to the ROM-monitor mode.
ROM Monitor CLI
Operating the ROM Monitor CLI
The ROM monitor commands are used to load and copy system images, micr ocode im ages, and
configuration files. System images contain the system software. Microcode images contain microcode
to be downloaded to various hardware devices. Configurati on files contain c omman ds to customi ze
Catalyst 6500 series software.
The manual boot comm and has the following syntax:
Note Enter the copy file-id {tftp | flash | file-id} co mma nd to obt ai n an i ma ge f ro m t h e ne twork .
• boot—Boot from ROM
• boot [-xv] [device:][imagename]—Boot from the local device. If you do not specify an image name,
the system defaults to the first valid file in the device. The image name is case sensitive.
Once you are in ROM-monitor mode, the prompt changes to rommon 1>. While you are in ROM-monitor
mode, each time you enter a command, the number in the prompt increments by one.
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
1-13
ROM Monitor CLI
Chapter1 Command-Line Interfaces
1-14
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
CHAPTER
2
Catalyst 6500 Series Switch and ROM Monitor
Commands
This chapter contain s an alpha betica l listin g of all switc h and ROM monitor command s available on the
Catalyst 6500 series switches.
For information regar di ng ATM module-related com ma nds, r ef er t o the ATM Software Configuration
Guide and Command Refe rence for the Cat aly st 50 00 Family and 6000 Family Switches.
For information regarding ID S modul e-rel ated co mmand s, refer t o the Cataly st 6500 Series Switch
Intrusion Detection Syste m Module Insta llation and Con figuration Note.
Except where spec ifically differen tiated , the La yer 3 switc hing engi ne refe rs to one of the following:
• Supervisor Engine 1 wi th L aye r 3 Sw itch ing Eng ine WS- F6K-PFC (Poli cy Featu re Ca rd)
• Supervisor Engine 2 w ith L a yer 3 Sw itch ing Eng ine II (PFC2)
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-1
alias
alias
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
To set and display command aliases, use the alias command.
alias [name=value]
Syntax Descri ption
name= (Optional) Name you give to the alias.
value (Optional) Value of the alias.
Defaults This command has no default settings.
Command Types ROM monitor command.
Command Modes Normal.
Usage Guidelines If value contains white space or other special (shell) characters, you must use quotation marks. If value
has a space as its la st char act er, the next com mand line w or d is check ed fo r an ali as. ( Nor mally, only the
first word on a command line is che cked.)
Without an argument, this command prints a list of all aliased names with their values.
An equal sign (=) is requir ed betw een the name and value of the alias.
You must issue a sync command to save your ch ange . If you do no t issue a sy nc comma nd, th e chan ge
is not saved, and a re set rem oves your c hange .
Examples This example shows how to display a list of available alias commands and how to create an alias for the
set command:
rommon 1 > alias
r=repeat
h=history
?=help
b=boot
ls=dir
i=reset
k=stack
rommon 2 > alias s=set
rommon 3 > alias
r=repeat
h=history
?=help
b=boot
ls=dir
i=reset
Catalyst 6500 Series Switch Command Reference—Release7.6
2-2
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
k=stack
s=set
rommon 4 > s
PS1=rommon ! >
BOOT=bootflash:RTSYNC_llue_11,1;slot0:f1,1;
=========================================================================
Related Comma nds unalias
alias
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-3
boot
boot
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
To boot up an ext erna l pr oc es s, use t he boot co mman d.
boot [-x] [-v] [device:][imagename]
Syntax Descri ption
-x (Optional) Load the image but do not execute.
-v (Optional) Toggle verbose mode.
device: (Optional) ID of the device.
imagename (Optional) Name of the image.
Defaults This command has no default settings.
Command Types ROM monitor command.
Command Modes Normal.
Usage Guidelines If you do not ente r any arguments, the boot co mmand boots the first image in bootfla sh. To specify an
image, enter the image name. To specify the device, enter the device ID.
If a device is not entered with an image name, the image is not booted.
If a device name is not recognized by the monitor, the monitor passes the device ID to the boot helper
image.
This command will not boot the MSFC if the PFC is not present in the Catalyst 6500 series switch.
Examples This example shows how to use the bo ot comm and:
rommon 2 > boot bootflash:cat6000-sup.6-1-1.bin
CCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCC
Uncompressing file:
##########################################################################################
##########################################################################################
################################################################################
Catalyst 6500 Series Switch Command Reference—Release7.6
2-4
78-15328-01
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
22
cd
To set the default Fla sh device for the sy stem , use t he cd co mmand .
cd [[m/]device:]
cd
Syntax Description
m/ (O pti onal ) Modu le num ber of the supe rv isor en gi ne con taini ng the
Flash device.
device: (Optional) Valid devices include bootflash and slot0.
Defaults The default Flash device is bootflash.
Command Types Switch comm and.
Command Modes Normal.
Usage Guidelines A colon (:) is re quire d aft er t he s pe cified device.
With comm ands where th e de vice is an optio n, if the def ault de vice is not specif ied, the d evi ce set by the
cd command is used.
Examples This example shows how to set the system default Flash device to bootflash:
Console> cd bootflash:
Default flash device set to bootflash.
Console>
Related Comma nds pwd
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-5
clear acllog
clear acllog
To disable ACL log rate limiting, use the clear ac llog command.
clear acllog
Syntax Descri ption This command ha s no argume nts o r keywords .
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Examples This example shows how to disable ACL log rate limiting:
Console> (enable) clear acllog
ACL log rate limit is cleared.
If the ACLs-LOG were already applied, the rate limit mechanism will be disabled on system
restart, or after shut/no shut the interface.
Console> (enable)
Related Comma nds set acllog ratelimit
show acllog
2-6
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear alias
To clear the abbreviated versions of commands, use the clear alias command.
clear alias {name | all}
clear alias
Syntax Description
name Alternate identifier of the command.
all Clears every alternate identifier previously created.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Examples This example sh ows how to er as e t h e ar pdel a li as:
Console> (enable) clear alias arpdel
Command alias deleted.
Console> (enable)
This example shows how to erase all the aliases:
Console> (enable) clear alias all
Command alias table cleared. (1)
Console> (enable)
(1) indicates the number of command aliases cleared.
Related Comma nds set alias
show alias
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-7
clear arp
clear arp
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
To delete a specific entry or all entries from the ARP table, use the clear arp command.
clear arp [all | dynamic | permanen t | static] { ip_ addr }
Syntax Descri ption
all (Optional) Clears all ARP entries.
dynamic (Optional) Clears all dynamic ARP entries.
permanent (Optional) Clears all permanent ARP entries.
static (Optional) Clears all static ARP entries.
ip_addr IP address to clear from the ARP table.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Examples This example shows how to remove IP a ddres s 19 8. 133.21 9.2 09 fr om t he A RP table :
Console> (enable) clear arp 198.133.219.209
ARP entry deleted.
Console> (enable)
This example shows how to remove all entries from the ARP table:
Console> (enable) clear arp all
ARP table cleared. (1)
Console> (enable)
(1) indicates the number of entries cleared.
This example shows how to remove all dynamically learned ARP entries:
Console> (enable) clear arp dynamic
Unknown host
Dynamic ARP entries cleared. (3)
Console> (enable)
This example shows how to clear all permanently entered ARP entries:
Console> (enable) clear arp permanent
Unknown host
Permanent ARP entries cleared.(5)
Console> (enable)
Related Comma nds set arp
show arp
Catalyst 6500 Series Switch Command Reference—Release7.6
2-8
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear banner motd
To clear the me ssag e-of- t he-da y banne r, use th e clear banner motd command.
clear banner motd
Syntax Description Th is comm a nd ha s n o argume nts or keyword s.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
clear banner motd
Examples This example shows how to cle ar t he m e ssage- of- the -day ba nner:
Console> (enable) clear banner motd
MOTD banner cleared
Console> (enable)
Related Comma nds set banner motd
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-9
clear boot auto-config
clear boot auto-config
T o clear the cont ent s of the CONFIG_ FILE envir onm ent vari ab le used to speci fy th e conf igura tion f iles
used during bootup, use the clear boot auto-config command.
clear boot auto-config [mod]
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Syntax Descri ption
mod (Optional) Mo dule n umb er of t he supe rvis or en gine con tai ning the Fla sh device.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Examples This example shows how to clear the auto-config file:
Console> (enable) clear boot auto-config
CONFIG_FILE variable =
Console> (enable)
Related Comma nds set boot auto-config
show boot
2-10
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear boot device
To clear the contents of the CONFIG_FILE environment variable used to specify the NAM startup
configuration files use d, use the clear boot device command.
clear boot device mod
clear boot device
Syntax Description
mod Number of the module cont aining the Flash device.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Usage Guidelines This comm a nd is sup por ted by the NAM module on ly.
Examples This example shows how to cle ar th e N AM b oot string fr om NVR AM for modu le 2:
Console> (enable) clear boot device 2
Device BOOT variable =
Console> (enable)
Related Comma nds set boot device
show boot device
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-11
clear boot system
clear boot system
To clear the con tent s of the B OOT e nvir onm en t va ria ble and t he c onf igur atio n re gist er sett ing, u se the
clear boot system command.
clear boot system all [mod]
clear boot system flash device:[filename] [mod]
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Syntax Descri ption
all Clears the whole BOOT environment variable.
mod (Optional) Module num ber of the supe rv isor en gine con taini ng the
Flash device.
flash (Optional) Clears the Flash device.
device: Name of the Flash device.
filename (Optional) Filename of the Flash device.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Examples This example shows how to cle ar t he w h ole BOO T en viro nme nt vari ab le:
Console> (enable) clear boot system all
BOOT variable =
Console> (enable)
This example shows how to clear a specific device; note how the specified device is not listed:
Console> (enable) clear boot system flash bootflash:cat6000-sup.5-5-1.bin
BOOT variable = bootflash:cat6000-sup.6-1-1.bin,1;bootflash:cat6000-sup.5-5-2.
bin,1;
Console> (enable)
Related Comma nds set boot system flash
show boot
Catalyst 6500 Series Switch Command Reference—Release7.6
2-12
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear cam
To delete a specific entry or all entries from the CAM table, use the clear cam command.
clear cam mac_addr [vlan]
clear cam {dynamic | static | permanent} [vlan]
clear cam
Syntax Description
mac_addr One or more MAC addresses.
vlan (Optional) Number of the VLAN; valid values are from 1 to 1000 and from
1025 to 4094.
dynamic Clears the dynamic CAM entries from the CAM table.
static Clears the static CAM entries from the CAM table.
permanent Clears the permanent CAM entries from the CAM table.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Examples This example shows how to remove MAC address 00 -40 -0b-a 0- 03-fa f rom t h e CA M tab le:
Console> (enable) clear cam 00-40-0b-a0-03-fa
CAM table entry cleared.
Console> (enable)
This example shows how to clear dynamic entries from the CAM table:
Console> (enable) clear cam dynamic
Dynamic CAM entries cleared.
Console> (enable)
Related Comma nds set cam
show cam
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-13
clear cam notification
clear cam notification
To clear the CAM notification counters and history log, use the clear cam notification command.
clear cam notification {all | counters | history}
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Syntax Descri ption
all Clears the CAM notification counters and history log.
counters Clears the CAM notification counters.
history Clears the CAM notification history log.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Examples This example shows how to cle ar t he C AM not ificat ion co unte rs an d h is tory log:
Console> (enable) clear cam notification all
MAC address notification counters and history log cleared.
Console> (enable)
This example shows how to cle ar t he C AM not ificatio n count ers:
Console> (enable) clear cam notification counters
MAC address notification counters cleared.
Console> (enable)
This example shows how to cle ar the C AM noti fication hist ory log :
Console> (enable) clear cam notification history
MAC address notification history log cleared.
Console> (enable)
Related Comma nds set cam notification
set snmp trap
show cam notification
Catalyst 6500 Series Switch Command Reference—Release7.6
2-14
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear channel statistics
To clear PAgP statistical information, use the clear channel statistics command.
clear channel statistics
Syntax Description Th is comm a nd ha s n o argume nts or keyword s.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
clear channel statistics
Examples This example shows how to clear PAgP statistical information:
Console> (enable) clear channel statistics
PAgP statistics cleared.
Console> (enable)
Related Comma nds show channel
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-15
clear config
clear config
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
To clear the system or module configuration information stored in NVRAM, use the clear config
command.
clear config {mod | rmon | all | snmpv 3 | acl nvram | interface}
Syntax Descri ption
mod Number of the mo dule.
rmon Clears all RMON configurations, including the historyControlTable, the alarmTable,
the eventTable, and the ringStation ControlTable.
all Clears all module and system configuration information, including the IP address.
snmpv3 Clears all SNMP version 3 configuration s.
acl nvram Clears all ACL configurations.
interface Clears all interface configurations.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Usage Guidelines When you use a Multilayer Switch Module (MSM), you can enter the clear config command to clear the
portion of the M SM configur ation r eta ined by the C atal yst 6500 series swit ch sup er visor engi n e. You
must clear the port ion of the configu ratio n kep t by t he M SM at the rout er level (router> pro mpt) .
Before using the clear co nfig all command, save a backup of the configuration using the cop y command.
Examples This example shows how to dele te the configu rat ion i nfor ma tio n in NV RAM on m odu le 2 :
Console> (enable) clear config 2
This command will clear module 2 configuration.
Do you want to continue (y/n) [n]? y
..............................
Module 2 configuration cleared.
Console> (enable)
This example shows how to dele te t he c onfigura tio n in forma tio n stored in NV RAM on modu le 1
(the superviso r engine ):
Console> (enable) clear config 1
This command will clear module 1 configuration.
Do you want to continue (y/n) [n]? y
......
Module 1 configuration cleared.
host%
Catalyst 6500 Series Switch Command Reference—Release7.6
2-16
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
This example shows how to delete all the configuration information for the Catalyst 6500 series
switches:
Console> (enable) clear config all
This command will clear all configuration in NVRAM.
Do you want to continue (y/n) [n]? y
...........................................
Connection closed by foreign host
host%
This example shows how to delete all the SNMP configuration information for the Catalyst 6500 series
switches:
Console> (enable) clear config snmpv3
This command will clear SNMPv3 configuration in NVRAM.
Do you want to continue (y/n) [n]? y
...........................................
Connection closed by foreign host
host%
This example shows how to delete all ACL configuration information from NVR AM:
Console> (enable) clear config acl nvram
ACL configuration has been deleted from NVRAM.
Warning:Use the copy commands to save the ACL configuration to a file
and the 'set boot config-register auto-config' commands to configure the
auto-config feature.
Console> (enable)
clear config
Related Comma nds set config acl nvram
show config qos acl
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-17
clear config pvlan
clear config pvlan
To clear all private VLAN configurati ons in the syste m inclu ding port mappings, use the c lea r config
pvlan command.
clear config pvlan
Syntax Descri ption This command ha s no argume nts o r keywords .
Defaults This command has no default settings.
Command Types Switch comm and.
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Command Modes Privileged.
Examples This example shows how to cl ear al l pr ivate VLAN co nfigur ati ons in the syst em:
Console> (enable) clear config pvlan
This command will clear all private VLAN configurations.
Do you want to continue (y/n) [n]? y
VLAN 15 deleted
VLAN 16 deleted
VLAN 17 deleted
VLAN 18 deleted
Private VLAN configuration cleared.
Console> (enable)
Related Comma nds clear pvlan mapping
clear vlan
configure
set vlan
set pvlan
set pvlan mapping
show config
show pvlan
show pvlan mapping
show vlan
2-18
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear cops
To clear Comm on Open Po licy Serv i ce ( COPS) co nfigurati ons, u se t he c lear co ps command.
clear cops roles role1 [role2]...
clear cops all-roles
clear cops server all [diff-serv | rsv p ]
clear cops server ipaddr [ diff-serv | rsvp]
clear cops domain-name
clear cop s
Syntax Description
roles ro l e# Specifies the role s to clear.
all-roles Clears all roles.
server Spec ifies th e CO PS se rver.
all Clears all server tables.
diff-serv ( Optional) Specifies the differentiated services server table.
rsvp (Optional) Specifies the RSVP+ server table.
ipaddr IP address or IP alias of the server.
domain-name Speci fies th e do main nam e of the se rver.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Usage Guidelines You can use the clear cops all-roles command to clear all roles from all ports.
Examples This example shows how to clear specific roles:
Console> (enable) clear cops roles backbone_port main_port
Roles cleared.
Console> (enable)
This example shows how to clear all roles:
Console> (enable) clear cops all-roles
All roles cleared.
Console> (enable)
Catalyst 6500 Series Switch Command Reference—Release 7.6
78-15328-01
2-19
clear cops
This example shows how to clear all COPS servers:
Console> (enable) clear cops server all
All COPS servers cleared.
Console> (enable)
This example shows how to clear a specific COPS server:
Console> (enable) clear cops server my_server1
All COPS servers cleared.
Console> (enable)
This example shows how to clear the COPS domain name:
Console> (enable) clear cops domain-name
Domain name cleared.
Console> (enable)
Related Comma nds set cops
show cops
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
2-20
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear counters
To clear MAC counters, Ethe rCh annel MAC counters, por t count ers, a nd th e cha nn el tra ffic percentile ,
use the clear counters command.
clear counters [all | mod/ports]
clear counters
Syntax Description
all (Optional) Specifies all ports.
mod/ports (Option al) Num be r o f th e mo dul e a nd the p orts on the modul e.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Usage Guidelines If you do not specify a range of ports to be cleared, then all ports on the switch are cleared.
Examples This example shows how to reset MAC and port counters to zero:
Console> (enable) clear counters
This command will reset all MAC and port counters reported in CLI and SNMP.
Do you want to continue (y/n) [n]? y
MAC and Port counters cleared.
Console> (enable)
This example shows how to reset MAC and port counters to zero for a speci fic module and por t:
Console> (enable) clear counters 5/1
This command will reset MAC and port counters reported by the CLI for port(s) 5/1.
Do you want to continue (y/n) [n]? y
MAC and Port counters cleared.
Console> (enable)
Related Comma nds restore counters
show port counters
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-21
clear crypto key rsa
clear crypto key rsa
To remove all RSA public-key pairs, use the clear crypto key rsa command.
clear crypto key rsa
Syntax Descri ption This command ha s no keywords or a rgumen ts.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Usage Guidelines The cr ypt o co mmand s a re s uppo rte d o n syst em s th at run the se i mage ty pe s onl y:
• supk9 image—for example , cat600 0-supk9 .6-1- 3.bin
• supcvk9 image—for example, cat 6000-su pcvk9.6- 1-3.b in
Examples This example shows how to clear RSA key pairs:
Console> (enable) clear crypto key rsa
Do you really want to clear RSA keys (y/n) [n]? y
RSA keys has been cleared.
Console> (enable)
Related Comma nds set crypto key rsa
show crypto key
2-22
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear dot1x config
To disable dot1x on all ports and return values to the default settings, use the clear dot1x config
command.
clear dot1x config
Syntax Description Th is comm a nd ha s n o keywords or a rguments .
Defaults This command has no default settings.
Command Types Switch comm and.
clear dot1x config
Command Modes Privileged.
Examples This example shows how to disab le dot 1x a nd ret ur n values to the d efaul t set tin gs:
Console> (enable) clear dot1x config
This command will disable Dot1x and take values back to factory default.
Do you want to continue (y/n) [n]? y
Dot1x config cleared.
Console> (enable)
Related Comma nds set port dot1x
show dot1x
show port dot1x
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-23
clear dot1x guest-vlan
clear dot1x guest-vlan
To remove any active 802.1x auto ports from the guest VLAN, use the clear dot1x gue st-vl an co mma nd .
clear dot1x guest-vlan
Syntax Descri ption This command ha s no keywords or a rgumen ts.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Examples This example shows how to clear the guest VLAN:
Console> (enable) clear dot1x guest-vlan
This command will deactivate all the ports on dot1x guest-vlan
Do you wnat to continue (y/n) [n]? y
Dot1x guest-vlan cleared
Console> (enable)
Related Comma nds set dot1x
set port dot1x
show dot1x
show port dot1x
2-24
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear gmrp statistics
To clear all the GMRP statistics information from a specif ied VLAN or all VLA Ns, us e the clear gmrp
statistics command.
clear gmrp statistics {vlan | all}
clear gmrp statistics
Syntax Description
vlan Number of the VL AN; va lid va lues are from 1 to 1000 and from 1025 to 4094.
all Specifies all VLANs.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Examples This example shows how to clear GMRP statistical information from all VLANs:
Console> (enable) clear gmrp statistics all
GMRP statistics cleared.
Console> (enable)
This example shows how to clear GMRP statistical information from VLAN 1:
Console> (enable) clear gmrp statistics 1
GMRP statistics cleared from VLAN 1.
Console> (enable)
Related Comma nds show gmrp statistics
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-25
clear gvrp statistics
clear gvrp statistics
To clear all the GVRP statistics information, use the clear gvrp statistics command.
clear gvrp st ati st i cs {mod/port | all}
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Syntax Descri ption
mod/port Number of the module and po rt.
all Specifies all ports.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Examples This example shows how to clear all GVRP statistical information:
Console> (enable) clear gvrp statistics all
GVRP statistics cleared for all ports.
Console> (enable)
This example shows how to clear GVRP statistical information for module 2, port 1:
Console> (enable) clear gvrp statistics 2/1
GVRP statistics cleared on port 2/1.
Console> (enable)
Related Comma nds set gvrp
show gvrp configuration
Catalyst 6500 Series Switch Command Reference—Release7.6
2-26
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear igmp statistics
To clear IGMP snoo pi ng st atis tica l inf orm atio n, use t he clear igmp sta tistics command.
clear igmp statistics
Syntax Description Th is comm a nd ha s n o argume nts or keyword s.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
clear igmp statistics
Examples This example shows how to clear IGMP statistical information:
Console> (enable) clear igmp statistics
IGMP statistics cleared.
Console> (enable)
Related Comma nds set igmp
show igmp statistics
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-27
clear ip alias
clear ip alias
To clear IP aliases that were set using the set ip alias command, use the clear ip alias command.
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
clear ip alias {name | all}
Syntax Descri ption
name IP address alias to delete.
all Specifies that all previously set IP address aliases be deleted.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Examples This example shows how to delete a pr eviously de fined IP alia s nam ed b ab ar:
Console> (enable) clear ip alias babar
IP alias deleted.
Console> (enable)
Related Comma nds set ip alias
show ip alias
2-28
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear ip dns domain
To clear the default DNS domain name, use the clear ip dns domain command.
clear ip dns domain
Syntax Description Th is comm a nd ha s n o argume nts or keyword s.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
clear ip dns domain
Examples This example shows how to clear the default DNS domain name:
Console> (enable) clear ip dns domain
Default DNS domain name cleared.
Console> (enable)
Related Comma nds set ip dns domain
show ip dns
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-29
clear ip dns server
clear ip dns server
To remove a DNS server from the DNS server listing, use the clear ip dns server command.
clear ip dns server {ip_addr | all}
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Syntax Descri ption
ip_addr IP addre ss of t he D NS se rver yo u want to r emove. An IP a lias o r a
host name that can be resol ved t hro ugh DN S can a lso be use d.
all Specifies all the IP addresses in the DNS server listing to be
removed.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Examples This example shows how to remove the DNS server a t I P a ddr ess 19 8. 92.30. 32 from the DN S se rver
listing:
Console> (enable) clear ip dns server 198.92.30.32
198.92.30.32 cleared from DNS table.
Console> (enable)
This example shows how to remove all DNS servers from the DNS server listing:
Console> (enable) clear ip dns server all
All DNS servers cleared
Console> (enable)
Related Comma nds set ip dns server
show ip dns
Catalyst 6500 Series Switch Command Reference—Release7.6
2-30
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear ip permit
To remove a specified IP address and mask or all IP addresses and masks from the permit list, use the
clear ip permit command.
clear ip permit all
clear ip permit {ip_addr} [mask] [telnet | ssh | snmp | all]
clear ip permit
Syntax Description
ip_addr IP addre ss to be clea red. An IP alias or a host nam e that can be resolved
through DNS ca n al so be use d.
mask (Optional) Subnet mask of the specified IP address.
telnet (Optional) Clears the entries in the Telnet permit list.
ssh (Optional) Clears the entries in the SSH permit list.
snmp (Optional) Clears the entries in the SNMP permit list.
all (Optional) Clears all permit lists.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Usage Guidelines The clear ip permit all command clea rs th e perm it list but do es not ch an ge t he st at e of t he I P p er mit
feature. A warning is displayed if all IP addresses are cleared from the permit list, and the feature is
enabled. If a mask other than the default (255.255.255.255) has been configured, you must provide both
the address and mask to clear a specific entry.
If the telnet, ssh, snmp, or all keyword is not specified, the IP address is removed from both the SNMP
and Telnet permit lists.
Examples These examples show how to remove IP addresses:
Console> (enable) clear ip permit 172.100.101.102
172.100.101.102 cleared from IP permit list.
Console> (enable)
Console> (enable) clear ip permit 172.160.161.0 255.255.192.0 snmp
172.160.128.0 with mask 255.255.192.0 cleared from snmp permit list.
Console> (enable)
Console> (enable) clear ip permit 172.100.101.102 telnet
172.100.101.102 cleared from telnet permit list.
Console> (enable)
Catalyst 6500 Series Switch Command Reference—Release 7.6
78-15328-01
2-31
clear ip permit
Console> (enable) clear ip permit all
IP permit list cleared.
WARNING
IP permit list is still enabled.
Console> (enable)
Related Comma nds set ip permit
show ip permit
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
2-32
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear ip route
To delete IP routing table entries, use the clear ip route command.
clear ip route destination gateway
clear ip route
Syntax Description
destination IP address of the ho st or networ k. A n IP al ia s or a h ost n ame tha t
can be resolved through DN S can also be used.
gateway IP address or alias of the gateway router.
Defaults The default is destination. If the destination is not the active default gateway, the actual destination is
the default.
Command Types Switch comm and.
Command Modes Privileged.
Examples This example shows how to delete the routing table entries using the clear ip route command:
Console> (enable) clear ip route 134.12.3.0 elvis
Route deleted.
Console> (enable)
Related Comma nds set ip route
show ip route
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-33
clear kerberos clients mandatory
clear kerberos clients mandatory
To disable mandatory Kerberos authentication for services on the network, use the clear kerberos
clients mandatory command.
clear kerberos clients mandatory
Syntax Descri ption This command ha s no argume nts o r keywords .
Defaults Kerberos clients are not set to mandatory.
Command Types Switch comm and.
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Command Modes Privileged.
Usage Guidelines If you do not make Kerberos authentication mandatory and Kerberos authentication fails, the application
attempts to authen ticate users usi ng the default method of authenti cati on for that network servi ce. For
example, Telnet prompts for a password.
Examples This example shows how to clear mandatory Kerberos authentication:
Console> (enable) clear kerberos clients mandatory
Kerberos clients mandatory cleared
Console> (enable)
Related Comma nds set kerberos clients mandatory
show kerberos
2-34
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear kerberos credentials forward
To disable credentials forwarding, use the clear kerberos credentials forward command.
clear kerberos credentials forward
Syntax Description Th is comm a nd ha s n o argume nts or keyword s.
Defaults The default is forwarding is disabled.
Command Types Switch comm and.
Command Modes Privileged.
clear kerber os cr ed ent ia ls fo rw ar d
Usage Guidelines If you have a ticket granting ticket (TGT) and are authenticated to a Kerberized switch, you can use the
TGT to authenticate to a host on the network. If forwarding is not enabled and you try to list credentials
after authenticating to a host, the output will show no Kerberos credentials are present.
Examples This example shows how to disab le Kerber os cred enti als forward ing:
Console> (enable) clear kerberos credentials forward
Kerberos credentials forwarding disabled
Console> (enable)
Related Comma nds set kerberos clients mandatory
set kerberos credentials forward
show kerberos
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-35
clear kerberos creds
clear kerberos creds
To delete all the Kerberos credentials, use the clear kerberos creds command.
clear kerberos creds
Syntax Descri ption This command ha s no argume nts o r keywords .
Defaults The command has no defau lt setti ngs.
Command Types Switch comm and.
Command Modes Privileged.
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Usage Guidelines If you have a TGT and are au thenticated to a Kerber ize d switch, you can use the TGT to authe nti cate to
a host on the network.
Examples This example shows how to dele te all Kerberos cr eden tia ls:
Console> (enable) clear kerberos creds
Console> (enable)
Related Comma nds set kerberos credentials forward
show kerberos
2-36
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear kerberos realm
T o cl ear a n entry t hat m aps the nam e of a K erb eros rea lm to a D NS do main name or a h ost na me , use the
clear kerb eros rea lm command.
clear kerb eros rea lm {dns_domain | host} kerberos_realm
clear kerb eros realm
Syntax Description
dns_domain DNS domai n name to map to a Kerberos re alm.
host IP address or name to map to a Kerberos realm.
kerberos_realm IP address or name of a Kerberos realm.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Usage Guidelines Y ou can map t he name of a K erb ero s re alm to a DNS do main na me or a ho st n ame with the se t k erber o s
realm command.
Examples This example shows how to cl ear a n en tr y mappi ng a Kerber os r eal m to a dom ain name :
Console> (enable) clear kerberos realm CISCO CISCO.COM
Kerberos DnsDomain-Realm entry CISCO - CISCO.COM deleted
Console> (enable)
Related Comma nds set kerberos lo ca l- realm
set kerberos rea lm
show kerberos
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-37
clear kerberos server
clear kerberos server
To clear a specified Key Distribution Center (KDC) entry, use the clear kerberos server command.
clear kerberos s erver kerberos_realm {hostname | ip_address} [port_number]
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Syntax Descri ption
kerberos_realm Name of a Kerberos realm.
hostname Na me of the host ru nning the KD C.
ip_address IP address of the host running the KDC.
port_number (Optional) Number of the port on the module.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Usage Guidelines Y ou can s pecify to the s witch which K DC to use in a Ker beros rea lm. This comm and clears a serve r entry
from the table.
Examples This example shows how to cle ar a K DC ser ver ent ere d on the swi tch:
Console> (enable) clear kerberos server CISCO.COM 187.0.2.1 750
Kerberos Realm-Server-Port entry CISCO.COM-187.0.2.1-750 deleted
Console> (enable)
Related Comma nds set kerberos server
show kerberos
Catalyst 6500 Series Switch Command Reference—Release7.6
2-38
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear key config-key
To remove a private 3DES key, use the clea r key config-ke y command.
clear key config-key string
clear key config-key
Syntax Description
string Name of the 3DES key; the name should be no lo nger than 8 bytes.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Examples This example shows how to remove a p rivate 3DES key:
Console> (enable) clear key config-key abcd
Kerberos config key deleted
Console> (enable)
Related Comma nds set key config-key
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-39
clear l2protocol-tunnel cos
clear l2protocol-tunnel cos
To clear the L aye r 2 p rotocol tunnel ing CoS value fo r al l i ngre ss tu nne ling por ts, use the c lea r
l2protocol-tunnel cos command.
clear l2protocol-tunnel cos
Syntax Descri ption This command ha s no argume nts o r keywords .
Defaults The CoS value is res tor ed to 5.
Command Types Switch comm and.
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Command Modes Privileged.
Examples This example shows how to clear the La yer 2 p rotoc ol tunne ling CoS value:
Console> (enable) clear l2protocol-tunnel cos
Default Cos set to 5.
Console> (enable)
Related Comma nds clear l2protocol-tunnel statistics
set l2protocol-tunnel cos
set port l2protocol-tunnel
show l2protocol-tunnel statistics
show port l2protocol-tunnel
2-40
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear l2protocol-tunnel statistics
To clear Lay er 2 pr otoc ol t u nnel ing stat ist ics on a po rt or o n all tun ne lin g p orts, us e t he c lea r
l2protocol-tunnel statistics command.
clear l2protocol-tunnel statistics [mod/port]
clear l2protocol-tunnel statisti cs
Syntax Description
mod/port (Optiona l) Numb er of the mod ule and port on the modul e. See the “Usag e
Guidelines” section for more information.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Usage Guidelines If you do not specify a module and port number, the Layer 2 protocol tunneling statistics for all tunneling
ports and all VLANs are cleared.
Examples This example shows how to clear the Layer 2 protocol tunnel ing statis tics for a singl e port:
Console> (enable) clear l2protocol-tunnel statistics 7/1
Layer 2 Protocol Tunneling statistics cleared on port 7/1.
Console> (enable)
Related Comma nds clear l2protocol-tunnel cos
set l2protocol-tunnel cos
set port l2protocol-tunnel
show l2protocol-tunnel statistics
show port l2protocol-tunnel
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-41
clear lacp-channel statist ics
clear lacp-channel statistics
T o clear Link Aggregation Control Protocol (LACP) statistical information, use the clear lacp-channel
statistics command.
clear lacp-channel statistics
Syntax Descri ption This command ha s no keywords or a rgumen ts.
Defaults This command has no default settings.
Command Types Switch comm and.
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Command Modes Normal.
Usage Guidelines For differences between P AgP and LA CP, refer to the “Guidelines for Port Configuration” section of the
“Configuring EtherChan ne l” cha pter of the Cataly st 650 0 Se ries Switch Soft ware Configuration Guide.
Examples This example shows how to clear LACP statistical information:
Console> (enable) clear lacp-channel statistics
LACP channel counters are cleared.
Console> (enable)
Related Comma nds set channelprotocol
set lacp-channel system-priority
set port lacp-channel
set spantree channelcost
set spantree channelvlancost
show lacp-channel
show port lacp-channel
2-42
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear lda
To remove the accelerated server load balancing (ASLB) MLS entries or MAC addresses from the
switch, use the clear lda command.
clear lda mls
clear lda mls [destination ip_addr_spec ] [source ip_addr_ spec ] [protocol protocol
src-port src_port dst-port dst_port]
clear lda vip {all | vip | vip tcp_port}
clear lda mac {all | router_mac_address}
clear lda
Syntax Description
mls Removes an LDA MLS entry.
destination
ip_addr_spec
source
ip_addr_spec
protocol
protocol
src-port
src_port
dst-port
dst_port
vip all Rem oves all VIP couples (set usi ng the set lda command).
vip vip Specifies a VIP.
vip vip
tcp_port
mac all Clears all ASLB router MAC addresses.
mac
router_mac_
address
(Optional) Full destination IP address or a subnet address in these
formats: ip_addr, ip_addr/netmask, or ip_addr/mask bit.
(Optional) Full source IP address or a subne t address in these
formats: ip_addr, ip_addr/netmask, or ip_addr/mask bit.
(Optional) Specifies additional flow information (protocol family
and protocol port pair) to be matched; valid values include tcp, udp,
icmp, or a decimal nu mb er fo r ot her pro toco l fam ili es.
(Optional) Specifies the number of the TCP/UDP source port
(decimal). Used with dst-port to specify the port pair if the protocol
is tcp or udp. 0 indicat es “do not care .”
(Optional) Specifies the number of the TCP/UDP destination port
(decimal). Us ed with src-port to specify the port pair if the protocol
is tcp or udp. 0 indicat es “do not care .”
Specifies a VIP and port coupl e.
Clears a specific router MAC address.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-43
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
clear lda
Usage Guidelines This comm a nd is sup por ted on ly o n swi tc hes c onfigure d wi th the Super vi sor Engi ne 1 w ith La yer 3
Switching Engine WS-F6K-PFC (Policy Feature Ca rd).
Entering the destination keyword specifies the en tries matching the destination IP addr ess specifi cation,
entering th e source keyword specifies the entries matching the source IP address specification, and
entering an ip_addr_sp ec ca n s peci fy a f ull I P a ddr ess or a su bnet a dd ress. If yo u d o not s peci fy a
keyword, it is treated as a wildcard, and all entries are displayed.
When enter ing the ip_a ddr_ spec, us e the fu ll IP address or a subnet address i n one of the foll owing
formats: ip_addr, ip_addr/netmask, or ip_addr/m askbit.
If you do not enter any keywords, the LD is remove d from the switch and th e LD conf igurati on is
removed from NVR AM .
If you do not e nte r any keywords wi th t h e clear lda mls command, all ASLB MLS entries are cleared.
Examples This example shows how to clear the ASLB MLS entry at a specific destination address:
Console> (enable) clear lda mls destination 172.20.26.22
MLS IP entry cleared.
Console> (enable)
This example shows how to delete a VIP and port pair (VIP 10.0.0 .8, port 8):
Console> (enable) clear lda vip 10.0.0.8 8
Successfully deleted vip/port pairs.
Console> (enable)
This example shows how to clear all ASLB router MAC addresses:
Console> (enable) clear lda mac all
Successfully cleared Router MAC address.
Console> (enable)
This example sh ows how to clear a sp ecific AS LB rou ter M AC address:
Console> (enable) clear lda mac 1-2-3-4-5-6
Successfully cleared Router MAC address.
Console> (enable)
Related Comma nds commit lda
set lda
show lda
2-44
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear localuser
To delete a local user account from the switch, use the clear localuser command.
clear localuser name
clear localuser
Syntax Description
name Specifies the local user ac count.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Examples This example shows how to delete a local user account:
Console> (enable) clear localuser troy
Local user cleared.
Console> (enable)
Related Comma nds set localuser
show localuser
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-45
clear log
clear log
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
To delete module, syst em error log, or dump l og entries, use the c lear l og co mmand .
clear log [mod]
clear log dump
Syntax Descri ption
mod (Optional) Module num be r.
dump Clears dump log entries.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Usage Guidelines If you do not specify a module num ber, the system error lo g for the entire system is er ased .
Examples This example shows how to clear the system error log:
Console> (enable) clear log
System error log cleared.
Console> (enable)
This example shows how to clear the dump log:
Console> (enable) clear log dump
Console> (enable)
Related Comma nds show log
Catalyst 6500 Series Switch Command Reference—Release7.6
2-46
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear log command
To clear the command log entry table, use the clear log command command.
clear log command [mod]
clear log command
Syntax Description
mod (Optional) Number of the module.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Usage Guidelines The command log entry table is a history log of th e comman ds sen t to t he swi tc h f rom t h e cons ole or Tel net.
Examples This example shows how to clear the command log table for the switch:
Console> (enable) clear log command
Local-log cleared
Console> (enable)
This example shows how to clear the command log table for a specific module:
Console> (enable) clear log command 3
Module 3 log cleared.
Console> (enable)
Related Comma nds show log command
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-47
clear logging buffer
clear logging buffer
To clear the system logging buffer, use the clear loggin g buffer command.
clear logging buffer
Syntax Descri ption This command ha s no argume nts o r keywords .
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Examples This example shows how to clear the system logging buffer:
Console> (enable) clear logging buffer
System logging buffer cleared.
Console> (enable)
Related Comma nds show logging buffer
2-48
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear logging level
To reset the logging level for a facility or for all facilities to their default settings, use the clear logging
level command.
clear logging level {facility | all}
Syntax Description facility Name of the facility to reset; facility types are listed in Table 2-1.
all Resets all facilities.
Tabl e 2-1 Fac i lity Ty p es
Facility Name Definition
all All facilities
acl acces s cont rol l ist
cdp Cisco Discovery Protocol
cops C ommon Open Policy Service Protocol
dtp Dynamic Trunking Protocol
dvlan Dynamic VLAN
earl Enhanced Address Recogni tion Lo gic
filesys file system facility
gvrp GARP VLAN Registration Protocol
ip Inte rnet Prot ocol
kernel Kernel
ld ASLB facility
mcast Multicast
mgmt Manage me nt
mls Multilayer Switching
pagp Port Aggregation Protocol
protfilt Protocol Filter
pruning VTP pr un i ng
privatevlan Private VLAN facility
qos Quality of Service
radius Remote Access Dial-In User Service
rsvp ReSerVation Protocol
security Security
snmp Simple Network Management Protocol
clear logging level
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-49
clear logging level
Table 2-1 Facility Types (continued)
Facility Name Definition
spantree Spanning Tree Protocol
sys System
tac Terminal Access Controller
tcp Transmission Control Protocol
telnet Te rmina l Emulatio n Protocol
tftp Trivial File Transfer Protocol
udld User Datagram Protocol
vmps VLAN Membership Policy Server
vtp Virtual Terminal Protocol
Defaults This command has no default settings.
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Command Types Switch comm and.
Command Modes Privileged.
Examples This example shows how to reset a specific facility back to its default settings:
Console> (enable) clear logging level dtp
Current session and default severities of facility <dtp> set to factory default values.
Console> (enable)
This example shows how to reset all facilities back to their default settings:
Console> (enable) clear logging level all
Current session and default severities of all facilities set to factory default values.
Console> (enable)
Related Comma nds set logging level
show logging
2-50
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear logging server
To delete a syslog server from the system log server table, use the clear logging server command.
clear loggi ng server ip_ad dr
clear logging server
Syntax Description
ip_addr IP address of the syslog server to be deleted.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Examples This example shows how to dele te a sys lo g s erver f rom the con figurat ion:
Console> (enable) clear logging server 171.69.192.207
System log server 171.69.192.207 removed from system log server table.
Console> (enable)
Related Comma nds set logging s erver
show logging
78-15328-01
Catalyst 6500 Series Switch Command Reference—Release 7.6
2-51
clear mls cef
clear mls cef
To clear CEF summary statistics, use the clear mls cef command.
clear mls cef
Syntax Descri ption This command ha s no argume nts o r keywords .
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Usage Guidelines This comm a nd i s sup port ed on Ca taly st 65 00 ser ies swi tches con figured with the Su pervis or E ng ine 2
with Layer 3 Switching Engine II (PFC2) only.
Examples This example shows how to cle ar CE F s ummar y infor ma tion:
Console> (enable) clear mls cef
CEF statistics cleared.
Console> (enable)
Related Comma nds show mls cef summary
2-52
Catalyst 6500 Series Switch Command Reference—Release7.6
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear mls entry
To clear MLS entries in the Catalyst 6500 series switches, use the clear mls entry command.
clear mls entry [ip | ipx] all
clear mls entry ip destination ip_addr_spec [source ip_addr_spec] [protocol protocol]
[src-port src_port] [dst-port dst_port]
clear mls entry ipx destination ipx_addr_spec
clear mls entry
Syntax Description
Defaults This command has no default settings.
ip (Optional) Specifies IP MLS.
ipx (Optional) Specifies IPX MLS.
all Clears all MLS entries.
destination Specifies the destination IP address.
ip_addr_spec Full IP address or a subnet address in these formats: ip_addr,
ip_addr/netmask, or ip_addr/ maskbit .
source ip_addr_spec (Optional) Specifies the source IP address.
protocol protocol (Optional) Specifies additional flow information (protocol family and
protocol port pair) to be matche d; valid va lues are 0 to 255 or ip, ipinip,
icmp, igmp, tcp, and udp.
src-port src_port (Optional) Specifies the source port IP address; valid values are 1 to 65535,
dns, ftp, smtp, telnet, x (X-Windows), www.
dst-port dst_port (Optional) Specifies the destination port IP address; valid values are 1 to
65535, dns, ftp, smtp, telnet, x (X-Windows), www.
ipx_addr_spec Full IPX address or a subnet address in these formats: src_net/[mask],
dest_net.dest_no de, or dest_ne t/mask .
Command Types Switch comm and.
Command Modes Privileged.
Usage Guidelines This comm a nd is no t sup por ted on sys tems c onfigured w it h the Superv i sor Engi ne 2 w ith L a yer 3
Switching Engine II ( PFC2). To clear entries on systems configured w it h the Superv isor E ngine 2 wi th
Layer 3 Switching Engine II (PFC2), yo u must enter t he clea r mls entry ce f adjace ncy command.
When entering th e IPX addres s synta x, use th e following format :
• IPX net address—1..FFFFFFFE
• IPX node address—x.x.x where x is 0..FFFF
• IPX address—ipx_net.ipx_ node (f or example 3.003 4.1245 .AB45 , A43.000 0.0000 .0001)
Catalyst 6500 Series Switch Command Reference—Release 7.6
78-15328-01
2-53
clear mls entry
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Up to 16 routers can be included explicitly as MLS-RPs.
To use a router as an MLS, you must meet these conditions:
• The router must be included (either explicitly or automatically) in the MLS-SE.
• The MLS feature must be enabled in the Catalyst 6500 series switches.
• The Catalyst 6500 series switches m ust know the rout er’s MAC-VLAN pairs.
Use the following syntax to specify an IP subnet address:
• ip_subnet_addr—This i s the sho rt su bnet addr e ss form at. T he t rail ing de cim al n umbe r 0 0 in an IP
address YY.YY.YY.00 specifies the boun dary for an IP subnet add ress. For example, 172. 22.36.00
indicates a 24-bit sub ne t a ddress (su bnet m ask 1 72.22. 36. 00/2 55.255 .25 5. 0), a nd 17 3.2 4. 00.00
indicates a 16-bit subnet address (subnet mask 173.24.00.00/255.255.0.0). However, this format can
identify only a sub ne t a ddress of 8 , 1 6, or 2 4 b its.
• ip_addr/subnet_mask—Thi s is the long subn et addre ss forma t. For example,
172.22.252.00/2 55.255.25 2.00 in dicate s a 22-bit subn et addre ss. This for mat can spec ify a subnet
address of any bit number. To provide more flexibility, the ip_addr is a full host addr ess, such as
172.22.253.1/255.2 55. 252.00 .
• ip_addr/maskbits—This is the simplified long subnet address format. The mask bits specify the
number of bits of the network mask s. For example, 172. 22.252.00 /22 indic ates a 22-b it subnet
address. The ip_addr is a full host addre ss, such as 193.2 2.253.1/ 22, whi ch has the same subnet
address as the ip_ subn et_a ddr.
If you do not use the al l argument in the clear mls entry command, you must specify at le as t o ne of th e
other three keywords (source, destination, or protocol) and its ar gumen ts.
If no value or 0 is en te red fo r src_port and dest_port, all entries are cleared.
When you remove a Multilayer Switch Module (MSM) from the C atalyst 6500 series switch, it is
removed immediately from the inclusion list and all the MLS entries for the MSM are removed.
Examples This example shows how to clear the MLS entries with destination IP address 172.20.26.22:
Console> (enable) clear mls entry destination 172.20.26.22
Multilayer switching entry cleared.
Console> (enable)
This example shows how to cle ar sp ec ific IP M LS ent rie s for de stin ation I P a ddress 17 2.2 0.2 6.22:
Console> (enable) clear mls entry ip destination 172.20.26.22 source 172.20.22.113 protocol tcp 520 320
Multilayer switching entry cleared
Console> (enable)
This example shows how to clear specific IPX MLS entries for a destination IPX address:
Console> (enable) clear mls entry ipx destination 1.00e0.fefc.6000 source 3.0034.1245.AB45
IPX Multilayer switching entry cleared
Console> (enable)
Related Comma nds show mls entry
Catalyst 6500 Series Switch Command Reference—Release7.6
2-54
78-15328-01
Chapter 2 Catalyst 65 00 Series Switch and ROM Monit or Commands
clear mls entry cef adjacency
To clear CEF adjacency statistics, use the clear mls entry cef adjacency command.
clear mls entry cef adjacency
clear mls entry cef ip [[ip_addr/]mask_len] adjacency
clear mls entry cef ipx [[ipx_addr/]mask_len] adjacency
clear mls entry cef adjacency
Syntax Description
ip Specifies IP entries.
ipx Specifies IPX entries.
ip_addr (Optional) IP address of the entry.
mask_len (Optional) Mask length associated with the IP or IPX address of
the entry; valid values are from 0 to 32.
ipx_addr (Optional) IPX address of the entry.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Usage Guidelines This comm a nd i s sup por ted on Ca taly st 65 00 ser ies swi tches con figured with t he Su pervi so r Eng in e 2
with Layer 3 Switching Engi ne II (PFC 2).
To clear MLS e ntrie s on syste ms c onfigured w ith th e Sup er visor Engi ne 1 wi th L aye r 3
Switching Engine WS-F6 K-PFC (Policy Feature Ca rd), ent er the cl ear m ls entr y comm and.
The ipx_addr value is entered as 32-bit hexadecimal digits.
Examples This example shows how to clear all adjacencies associated with CEF entries:
Console> (enable) clear mls cef entry adjacency
Adjacency statistics has been cleared.
Console> (enable)
Related Comma nds show mls entry cef
Catalyst 6500 Series Switch Command Reference—Release 7.6
78-15328-01
2-55
clear mls exclude protoc ol
clear mls exclude protocol
To remove a protocol port that has been excluded fr om shortcutting using th e set mls exclude protocol
command, use th e clear mls exclude protocol command .
clear mls ex cl ud e p rotocol tcp | udp | both port
Chapter 2 Catalyst 6500 Series Switch and ROM Monitor Commands
Syntax Descri ption
tcp Specifies a TCP port.
udp Sp ecifies a UDP por t.
both Specifies that the port be applied to both TCP and UDP traffic.
port Number of the port.
Defaults This command has no default settings.
Command Types Switch comm and.
Command Modes Privileged.
Examples This example shows how to set TCP packe ts i n a pro t ocol po rt to be h ardware swi tch ed:
Console> (enable) clear mls exclude protocol tcp 25
TCP packets with protocol port 25 will be MLS switched.
Console> (enable)
Related Comma nds set mls exclude protocol
show mls exclude protocol
Catalyst 6500 Series Switch Command Reference—Release7.6
2-56
78-15328-01
