AN298

CS485xx Firmware User’s Manual:

General Overview and Common Firmware Modules

Contents

 Document Strategy  Overview  Firmware Messaging  OS Firmware Module  Audio Manager Firmware Module  PCM Firmware Module  Low Power Mode  Watchdog Timer  Document Revisions

Overview

AN298 provides a description of the operation of firmware for the CS485xx family of DSPs. This document gives a general overview to the family of CS485xx Firmware User’s Manuals designated by the general name AN298[X][Y]; where [X] = MPM (Matrix Processing Module), VPM (Virtual Processing Module), PPM (Post Processing Module), and [Y] = A,B,C, etc. Note that the CS485xx family of DSPs does not contain a compressed data decoder.

More specifically, the purpose of this document is to serve as an introduction to the various DSP Firmware designed specifically to run on the CS485xx DSP. This document will attempt to explain frequently used term in olog y and, at the same time, systematically explain the OS operation and communication for the CS485xx.

http://www.cirrus.com

CS485xx Block Diagram

AN298RC14

MAR '13

1 Document Strategy

The CS485xx has been designed with an inherent flexibility in terms of firmware usage. Each instance of operation of the CS485xx can potentially use a different mix of DSP firmware depending on the need of the end user. As such, the strategy adopted to document the various DSP firmware is based on a single General Overview coupled with an individual Firmware User’s Manual for each DSP firmware module offered by Cirrus Logic. AN298 is the General Overview to the family of CS485xx Firmware User’s Manuals.

The individual Firmware User’s Manuals, mentioned in the abov e paragraph, each follow as an extension of AN298. These manuals have been named in such a way so as to classify them into one of the following categories:

• Operating System and General Overview

• Matrix Processing Module (MPM)

• Virtual Processing Module (VPM)

• Post Processing Module (PPM)

Furthermore, since each classification (e.g., Post Processing Module) may contain several associated DSP firmware, an incremental letter assignment (e.g., A, B, C etc.) was given to index each DSP firmware within a given category. As an example, the table below outlines the general naming conventions for several firmware modules.

Table 1-1. Naming Conventions

DSP Firmware Module Base Name Overlay Type Index Reference Number

General Overview, Op erating System & Common

Firmware Modules

Delay Module AN298 Post Processing Module (PPM) a AN298PPMA

Crossbar Mixer Module AN298 Matrix Processing Module (MPM) c AN298MPMC

Dolby Headphone 2 AN298 Virtual Processing Module (VPM) a AN298VPMA

AN298 (General) - AN298

For a further breakdown of the available CS485xx firmware modules and their respective Firmware User’s Guide document number, see Section 2.4. For the latest code updates and availability, contact your local field applications engineer (FAE).

2 AN298RC14

Mid-Processor O ver l a y

PCM Output s

Post-Processor O ver l ay (wit h APP loaded)

ID = 0x83

ID = 0xD9

ID = 0xD5ID = 0xD4

Tone Control Module

Re-Eq

Module

Bass

Management

Module

Parametric

Module

Delay

Module

Audio Manager

Module

Includes:

Ga in (mas ter) Mute (mas ter ) Channel Trim Channel Remap

Up-sampler

Mid-Processor Module

e.g. P L II, PLIIx, N e o6, Cros s b a r,

Viva+, COMS2, Neur al Sur r ound,

Circl e Surr ound 2

Virtualizer-Processor

Module

e.g. DVS2, DH2, SRS TSXT,

Audistry

Virtual izer-Processor Overlay

Mid-Processor O ve rlay

PCM input s

Down-

sampler

2 Overview

The firmware that runs on this device expects a stereo or multi-channel PCM input source. This section describes the different overlays as well as the functionality of the various processor module overlays.

Figure 2-1. CS485xx Firmware Block Diagram

2.1 Firmware Overlays

The data flows through a series of four firmware overlays that contain one or more firmware modules. A firmware module provides the specific application affectionately and is controlled by the host via a Firmware Mana ger that defines the control interface. The overlays segment the firmware module functionality into four independent groups depending on function:

OS Overlay

• Manages the overall operation of the DSP. Also handles host communication, data inputs and outputs and various

other critical internal tasks.

Matrix Processing Module Overlay

• Performs additional channel generation, upmixing, downmixing. This segment is where algorithms such as Pro

Logic

Virtual Processing Module Overlay

• Performs stereo virtualizing to simulate multi-channel systems, such as Dolby

Dolby Virtual Surround

Post Processing Module Overlay

• This segment specifically caters to firmware that performs post-processing tasks. It allows the system designer

flexibility in “tweaking” the system for optimal audio performance and effects. This is also the segment in which firmware modules such as the Audio Manager, Bass Manager, Tone Control, Delay, THX Module will reside.

AN298RC14 3

IIx, Neo6™, and COMS2 reside.

Audistry®, Dolby Headphone®, and

, and Parametric-EQ

2.2 Code Image (.uld) Files

Each overlay is a separate code image file (.uld) that is loaded individually into the DSP. To ch ange the functionality of the application, only the overlay of interest needs to be loaded. For example the Post Pro cessin g overlay can be exch anged from SPP to APP by reloading only the Post Processing overlay. This reduces the system response time to user changes as well as the code image storage requirements.

Note: There are 4 different memory configurations pertaining to the program RAM size (most code is in ROM). The

different memory configurations are denoted by p2, p4, p6, a nd p8 (p for prog ram memory, 2, 4, 6, a nd 8 are the number of kilo-words, 1 word = 32 bits). Increasing P RAM decreases Y RAM. Each overlay is denoted with the p2, p4, p6, or p8 in the .uld file name to indicate which memory configuration is used.

WARNING: Memory configuration must be consistent across all overlays (OS, MPM, VPM, and PPM).

2.2.1 .uld File Naming Conventions

A generic template for representing .uld file can be represented by the following file name:

AA_48BBB_pC_DD_EE_rcFF.uld

2.2.1.1 .uld File Name Variables

•

AA = Technology name (os, mb, app, spp, …)

• BBB = minimum chip required to run the firmware loaded by the .uld file (520, 560, dv2, au2)

• 520 means this will run on a 520, 540, & 560

• 540 means this will run on a 540 & 560 (Not on a 520)

• 560 means this will run on a 560 (Not on a 520 or 540)

• dv2 means this will run on a CS48DV2x DSP only

• au2 mean this will run on a CS48AU2B only

• C = memory configuration (2, 4, 6, or 8)

This is the amount of PRAM in Kilowords (1 word = 32-bits). More PRAM means less YRAM. The memory configurations can be broken down into the following categories:

• P2

• X Memory - 8kx32 SRAM, 8kx32 DROM

• Y Memory - 14kx32 SRAM, 8kx32 DROM

• P Memory - 2kx32 SRAM, 32kx32 DROM

• P4

• X Memory - 8kx32 SRAM, 8kx32 DROM

• Y Memory - 12kx32 SRAM, 8kx32 DROM

• P Memory - 4kx32 SRAM, 32kx32 DROM

• P6

• X Memory - 8kx32 SRAM, 8kx32 DROM

• Y Memory - 10kx32 SRAM, 8kx32 DROM

• P Memory - 6kx32 SRAM, 32kx32 DROM

• P8

• X Memory - 8kx32 SRAM, 8kx32 DROM

• Y Memory - 8kx32 SRAM, 8kx32 DROM

• P Memory - 8kx32 SRAM, 32kx32 DROM

• DD = Firmware version

4 AN298RC14

2.3 Download Sequence

This variable is the specific memory map for the various overlays and can be specific to a particular version of ROM Current Firmware versions are:

• 01 = CS485xx

• 02 =CS48DV2A

• 03 = CS48DV2B

• 04 = CS485xx

• 05 = CS485xx

• 06 = CS48AU2B

• 09 = CS485xx

• EE = This variable indicates a major revision, increments when rc99 -> rc1

• FF = This Variable indicates a minor revision, increments by one for each new .uld build

2.2.1.2 Example of .uld file name

An example of a .uld file name:

os_48520_p2_48520_01_01_rc5.uld

• AA = os (DSPP operating system)

• BBB = CS48520 (this .uld will run on CS48520, CS48540, and CS48560)

• C = p2

• DD = 01 (all other overlays that are loaded on the DSP must be 01 overlays)

• EE = 01 (have not made over 100 of these)

• FF = rc5

2.3 Download Sequence

A standard procedure to download firmware to the DSP follows the following structure at system power-up:

1. Download OS Overlays to DSP

2. (optional) Download Matrix Processing Module Overlay (Crossbar Mixer, Pro Logic IIx, DTS Neo6 etc.)

3. (optional) Download Virtual Processing Module Overlay (COMS2)

4. (optional) Download Post Processing Module Overlay (Audio Manager, Bass Manager, Delay, Parametric EQ, etc.)

AN298RC14 5

Step 2 (optional): Download a matrix processing module

(e.g. Crossbar Mixer, Pro Logic IIx, DTS Neo6 etc.) Automatically fills the Matrix Processing Overlay.

Step 3 (optional): Download a virtual processing module

(e.g. Dolby Headphone, Dolby Virtual Speaker etc.) Automatically fills the Virtual Processing Overlay.

Step 4: Download a post processor module group

(e.g. SPP, APP) Automatically fills the Post Processing Overlay. If SPP or APP is not required , then the bare

requirement for this overlay is the Audio Manager module.

Step 1: Download the firmware OS_p*_**.uld

Automatically fills the OS Overlay. (*2, 4, 6, or 8 for memory map; **device and version)

2.3 Download Sequence

Figure 2-2. Download Sequence

6 AN298RC14

AN298RC14 7

2.4 Firmware Modules and Associated Application Notes

Table 2-1. Firmware Module Read and Write Addresses with Associated Application Note Reference

DSP Firmware Module /

(Application Note Name)

General:

OS Manager (AN298)

Matrix Processing Overlay:

Firmware Version/Memory Map(s)

Supported

See Table 2-2 for a list of Firmware versions/ memory maps associated with the various CS48xxx products.

Write Request Read Request Read Response

0x8100HHHH 0xhhhhhhhh 0x81C0HHHH 0x01C0HHHH 0xhhhhhhhh

Dolby Pro Logic IIx (AN298MPMA) V01, V03 0xBF00HHHH 0xhhhhhhhh 0xBFC0HHHH 0x3FC0HHHH 0xhhhhhhhh DTS Neo6

V01 0xB500HHHH 0xhhhhhhhh 0xB5C0HHHH 0x35C0HHHH 0xhhhhhhhh

(AN298MPMB) Crossbar

V01 0xDB00HHHH 0xhhhhhhhh 0xDBC0HHHH; 0x5BC0HHHH 0xhhhhhhhh

(AN298MPMC) BBE Viva Plus

V01 0x6000HHHH 0xhhhhhhhh 0x60C0HHHH 0x20C0HHHH 0xhhhhhhhh

(AN298MPMD) BBE Mach3Bass Manager

V01 0x6100HHHH 0xhhhhhhhh 0x61C0HHHH 0x21C0HHHH 0xhhhhhhhh

(AN298MPMD)

SRS

Circle Surround II

V01 0xB300HHHH 0xhhhhhhhh 0xB3C0HHHH 0x33C0HHHH 0xhhhhhhhh

(AN298MPMG) Signal Generator

V01 0x9A00HHHH 0xhhhhhhhh 0x9AC0HHHH 0x1AC0HHHH 0xhhhhhhhh

(AN298MPMH) Cirrus Original Multi-channel

V01 0xD300HHHH 0xhhhhhhhh 0xD3C0HHHH 0x53C0HHHH 0xhhhhhhhh

Surround 2 (COMS-2) (AN298MPMJ)

Dolby Pro Logic II

V01 0xB200HHHH 0xhhhhhhhh 0xB2C0HHHH 0x32C0HHHH 0xhhhhhhhh

(AN298MPMM) Neural-THX Dolby Headphone 2

Surround V02 0xC400HHHH 0xhhhhhhhh 0xC4C0HHHH 0x54C0HHHH 0xhhhhhhhh

V03, V06 0xC000HHHH 0xhhhhhhhh 0xC0C0HHHH 0x40C0HHHH 0xhhhhhhhh

(AN298VPMK) Dolby Virtual Speaker 2

V03, V06 0xC100HHHH 0xhhhhhhhh 0xC1C0HHHH 0x41C0HHHH 0xhhhhhhhh

(AN298VPML)

Virtualizer-Processor Overlay:

Audistry by Dolby

V01 0xE500HHHH 0xhhhhhhhh 0xE5C0HHHH 0x65C0HHHH 0xhhhhhhhh

(AN298VPMA)

AN298RC14 8

T able 2-1. Firmware Module Read and Write Addresses with Associated Application Note Reference (Cont.)

DSP Firmware Module /

(Application Note Name)

Virtualizer-Processor Overlay: (Continued)

SRS TruSurround XT

(AN298VPMH) Dolby Headphone 2

(AN298VPMK) Dolby Virtual Speaker 2

(AN298VPML) SRS® TruSurround HD4™ Modules

(with WOW HD (AN298VPMM) Cirrus Virtualization Tec hnology

(CVT) - Virtualizer Processor Module (AN298VPMN)

Post Processing Overlays:

Audio Manager (AN298)

PCM Manager (AN298)

Delay (AN298PPMA)

Bass Manager (AN298PPMB)

Cirrus Band XpandeR (BXR) (AN298PPMC)

Cirrus Dynamic Volume Lev eler (DVL) (AN298PPMD)

EQ Module with PEQ and Direct Coefficient Mode (11-bands)

(AN298PPME) Tone Control

(AN298PPMF) Dolby Volume

AN298PPMN

Firmware Version/Memory Map(s)

Supported

V01 0xBA00HHHH 0xhhhhhhhh 0xBAC0HHHH 0x3AC0HHHH 0xhhhhhhhh

V01 0xC000HHHH 0xhhhhhhhh 0xC0C0HHHH 0x40C0HHHH 0xhhhhhhhh

V01 0xC100HHHH 0xhhhhhhhh 0xC1C0HHHH 0x41C0HHHH 0xhhhhhhhh

V04, V09 0xB300HHHH 0xhhhhhhhh 0xB3C0HHHH 0x33C0HHHH 0xhhhhhhhh

V05 0xC100HHHH 0xhhhhhhhh 0xC1C0HHHH 0x41C0HHHH 0xhhhhhhhh

All

V03 0xE000HHHH 0xhhhhhhhh 0xE0C0HHHH 0x60C0HHHH 0xhhhhhhhh

Write Request Read Request Read Response

0x8300HHHH 0xhhhhhhhh 0x83c0HHHH 0x03c0HHHH 0xhhhhhhhh

0x9B00HHHH 0xhhhhhhhh 0x9BC0HHHH 0x1BC0HHHH 0xhhhhhhhh

0xD900HHHH 0xhhhhhhhh 0xD9C0HHHH 0x59C0HHHH 0xhhhhhhhh

0xD700HHHH 0xhhhhhhhh 0xD7C0HHHH 0x57C0HHHH 0xhhhhhhhh

0xE700HHHH 0xhhhhhhhh 0xE7C0HHHH 0x67C0HHHH 0xhhhhhhhh

0xE600HHHH 0xhhhhhhhh 0xE6C0HHHH 0x67C0HHHH 0xhhhhhhhh

0xD500HHHH 0xhhhhhhhh 0xD5C0HHHH 0x55C0HHHH 0xhhhhhhhh

0xD400HHHH 0xhhhhhhhh 0xD4C0HHHH 0x54C0HHHH 0xhhhhhhhh

AN298RC14 9

T able 2-1. Firmware Module Read and Write Addresses with Associated Application Note Reference (Cont.)

DSP Firmware Module /

(Application Note Name)

Post Processing Overlays: (Continued)

Cinema Re-EQ (AN298PPMK)

SRS TruVolume™ Module (was Volume IQ™ Module)

(AN298PPMO) MaxxBass

Module

(AN298PPMP) Audyssey Dynamic Volume

Audyssey Dynamic EQ

™

and

™

(AN298PPMQ) Audyssey EQ

™

(AN298PPMR) Audyssey BassXT

™

(AN298PPMS) Cirrus Bass Enhancer

(AN298PPMU)

Firmware Version/Memory Map(s)

Supported

All

V02, V09 0xE000HHHH 0xhhhhhhhh 0xE0C0HHHH 0x60C0HHHH 0xhhhhhhhh

V01 0xE800HHHH 0xhhhhhhhh 0xE8C0HHHH 0x68C0HHHH 0xhhhhhhhh

V06 0xC700HHHH 0xhhhhhhhh 0xC7C0HHHH 0x47C0HHHH 0xhhhhhhhh

V06 0xC800HHHH 0xhhhhhhhh 0xC8C0HHHH 0x48C0HHHH 0xhhhhhhhh

V06 0xC900HHHH 0xhhhhhhhh 0xC9C0HHHH 0xC9C0HHHH 0xhhhhhhhh

All

Write Request Read Request Read Response

0xDC00HHHH 0xhhhhhhhh 0xDCC0HHHH 0x5CC0HHHH 0xhhhhhhhh

0xED00HHHH 0xhhhhhhhh 0xEDC0HHHH 0x6DC0HHHH 0xhhhhhhhh

AN298RC14 10

T able 2-1. Firmware Module Read and Write Addresses with Associated Application Note Reference (Cont.)

DSP Firmware Module /

(Application Note Name)

Audyssey Adaptive Bass eXtension (ABX) Module

(ANPPMT) SPP (Standard Post Processing) in

DSP Composer Module Processing Order:

1. Tone Control

2. BM

3. Delay

4. AM (Refer to Individual Module

Application Notes APP (Advanced Post Processing) in

DSP Composer Module Processing Order:

1. Tone Control

2. ReEQ

3. BM

4. EQ

5. Delay

6. AM Refer to Individual Module Application

Notes

Firmware Version/Memory Map(s)

Supported

V06 0xC900HHHH 0xhhhhhhhh 0xC9CNHHHH 0x49C0HHHH 0xhhhhhhhh

V01

Write Request Read Request Read Response

1.Dolby Headphone 2 and Dolby Virtual Speaker 2 are only available as Matrix Processing Modules on the CS48AU2A, CS48DV2B, and CS48DV2B DSPs. Dolby Headphone 2 and Dolby Virtual Speaker 2 are usually implemented as Virtualizer Processing Modules. See Table 2-2 for description of supported firmware versions/memory maps.

2.“All” --These modules are implemented through the “Custom PPM” in DSP Composer that allows these modules to be inclu ded as an object (.o) file and compiled into an .uld file, which is loaded onto the DSP.

9* = 2, 4, or 6 for the three different memory maps ** = revision number for code

2.4 Firmware Modules and Associated Application Notes

Table 2-2. OS Version/Memory Map by Product

Product OS OS Version/Memory Map Supported

CS48560 V01, V02, V04, V05, V09 CS48540 V01, V02, V04, V05, V09

CS48520 V01, V02, V04, V05, V09 CS48AU2B V06 CS48DV2A V03 CS48DV2B V06

AN298RC14 11

3 Firmware Messaging

While using the CS485xx, it is necessary to communicate with the DSP in order to control or monitor the various downloaded firmware modules. We refer to this process of communication firmware messaging. The purpose of this section is to cover the types and formats of these fir mware messages. In gene ral, with firmware messagin g, the user can control the firmware module running on the DSP and subsequently perform various tasks such as:

• Configure the module after firmware download (e.g. Kickstarting the DSP, etc.)

• Change runtime parameters (e.g. adjusting the Volume, switching Pro Logic II modes, etc.)

• Obtain information from the DSP (e.g. current state of the firmware registers, data stream information, etc.)

3.1 Communication Overview

From a “micro-programmer” point of view, the CS485xx firmware modu les can be th ought of as a blocks of se veral 32 -bit registers (variables) that either control the behavior of the firmware or store information about the state of the firmware at the time of operation. Each register has a unique index. Access to the register involves a combination of a specified opcode for that firmware module together with the register index. For each firmware module, the followin g opcod es are ava ilable :

• Write Opcode - Issues a command to write to a specific module.

• Read Opcode - Issues a command to read from a specific module.

• Read Response Opcode - Indicates module and index that has been read.

These available opcodes permit the following types of communication with the CS485xx DSP:

• Writing to the DSP

• Solicited read from the DSP

• Unsolicited read from the DSP

The following sub-sections cover the communication types listed above.

3.1.1 Writing to the DSP

A write session with the CS485xx consists of one 8-byte message from the host to the CS485xx. In essence, the write message consists of a 32-bit command word followed by a 32-bit data word (that is, data to be written to the register). The command word is formed by combining the write opcode for that module together with th e index of the register that needs to be written. The 32-bit Data Word is the value of the data intended to fill that register.

The following diagram shows the format of a write message:

Write Command Word:

313029282726252423222120191817161514131211109876543210

OPCODE[31:16] INDEX[15:0]

Write Data Word:

313029282726252423222120191817161514131211109876543210

DATA WORD[31:0]

3.1.2 Solicited Read

A solicited read can be thought of as a request to read the contents of a specific register. This is comprised of a 32-bit solicited read command word which is a request to read a specific index (register) in a given module. The DSP, upon receiving this message, responds by sending back a 32-bit Read Response opcode and the requested 32-bit data word contained in the register.

12 AN298RC14

3.1 Communication Overview

The following diagram provides shows the format of a solicited read message:

Read Command Word:

313029282726252423222120191817161514131211109876543210

OPCODE[31:16] INDEX[15:0]

Read-Response Command Word:

313029282726252423222120191817161514131211109876543210

OPCODE[31:16] INDEX[15:0]

Read-Response Data Word:

313029282726252423222120191817161514131211109876543210

DATA WORD[31:0]

3.1.3 Unsolicited Message

The DSP needs to inform the host when the PLL is out of lock or th ere is a runtime memory allocation error (Malloc Failure). Note that this type of message is an unsolicited message because it was initiated by the CS485xx rather than the host. The PLL out of lock message is sent out on a best-efforts basis.

This message will come from the CS485xx to indicate a change in the system that must be addressed. The 8-byte unsolicited read messages from the CS485xx consist of a 4-byte read command word which defines the type of unsolicited message and an associated 4-byte data word that contains more information describing a system condition. The host senses that an unsolicited message is ready to be read because the IRQ pin for the port being used goes low (SCP1_IRQ or PCP_IRQ

). Every time the existence of a message is detected, the host should read out the 8-byte unsolicited read

message.

Unsolicited Read Command Word:

313029282726252423222120191817161514131211109876543210

OPCODE[31:16] INDEX[15:0]

Unsolicited Read Data Word:

313029282726252423222120191817161514131211109876543210

DATA WORD[31:0]

AN298RC14 13

4 Operating System (OS) Firmware Module

Indices of the Firmware Module can differ in properties that are important to the system firmware programmer. Indices marked by a ‘†’ can be modified after ki ck-star ting the application. However, indices not marked by a ‘†’ must be

configured by the system host controller before the kick-start message is sent to begin decoding. For these indices, changes after kick-starting the application will not have the desired effect and can potentially cause the application to become unstable.

All indices are reinitialized to the default values after downloading the overlay and soft-resetting the overlay.

4.1 Overview

Table 4-1 contains the API used to control the OS firmware module.

4.2 OS Manager

Index = 0xHHHH, data value = 0xhhhhhhhh Write = 0x8100HHHH 0xhhhhhhhh Read Request = 0x81C0HHHH Read Response = 0x01C0HHHH 0xhhhhhhhh

14 AN298RC14

4.2 OS Manager

T able 4-1. OS Module API

Index Variable Description

0x0000 KICKSTART Bit 22: 0/1 Disable/Enable unsolicited message on sampling frequency change

0x0001 IO_CONFIG Select Input and Output Ports

0x0002 OUTPUT_MODE_CONTROL

detection. It is strongly recommended that both Bit 21 and Bit 22 be enabled or both be cleared/disabled. Bit 22 is only available on CS48AU2B, CS48DV2B, and CS48DV6B DSPs.

Bit 21: 0/1 Disable/Enable continual check and re-evaluation of sampling frequency. If the sampling frequency does change, a process similar to what happens after a malloc failure event occurs. De pending on the Bit 22 setti ng, an unsolicited message, 0x81000003FF00000s, is issued to the microcontroller where “s” is the new sampling frequency. The OS then waits for this unsolicited message to be picked up before waiting for a fresh kick-start to commence audi o playback. It is strongly recommended that both Bit 21 and Bit 22 be enabled or both be cleared/disabled.

Note: See OS MCV Index 0x0003 for all possible sampling frequency values. For example, 48KHz = 0; 44.1KHz = 1 and 32KHz = 2. Bit 21 is only available on CS48AU2B, CS48DV2B, and CS48DV6B DSPs.

Bit 20: 0/1 Disable/Enable one-shot sampling frequency detection and auto update of OS MCV Index 0x0003 (HOST_SAMPLING_FREQUENCY). This occurs immediately after kick-start is received. Bit 20 is only available on CS48AU2B, CS48DV2B, and CS48DV6B DSPs.

Bit 16: 0/1 Disable/Enable Malloc Failure Reporting. Bit 13: 0/1 Disable/Enable Continual GPIO updating. Note: Only applicable is Bit 12 is set.

Bit 12: 0/1 Disable/Enable GPIO updates. Bit 9: 0/1 Disable/Enable No Hardware Watchdog re-kick. Bit 8: 0/1 Disable/Enable Hardware Watchdog. Bit 4: 0/1 Disable/Enable Upsampling: back-end up sampling by 2 x (max 96kHz). Bit 0: Kick-start: Set to 1 to trigger Kick-start

Default = 0x00000000

Bit 2: 0/1 Disable/Enable PCM 8-channel input Mode (Valid only on the CS48560)

Bit 1: 0/1 Disable/Enable PCM: 2 Channel Input Mode Bit 0: 0/1 Disable/Enable PCM: 4/8/12-channel Input Mode where the number of

channels is determined by the DSP product number as follows:

• 4 channels for CS48520

• 8 channels for CS48540

• 12 channels for CS48560 Note: 2 Channel Input Mode must be disabled when using Multi-Channel Input

Mode. Valid settings are either 0x00000001, 0x00000002, or 0x0000000 4. Default = 0x00000002 (2 Channel Input)

† Bits 3:0 Output Mode (number of speakers present in the system)

0x0 = 2/0 Lt, Rt Dolby Surround compatible 0x1 = 1/0 C 0x2 = 2/0 L/R 0x3 = 3/0 L/C/R 0x4 = 2/1 L/R/S 0x5 = 3/1 L/C/R/S 0x6 = 2/2 L/R/Ls/Rs 0x7 = 3/2 L/C/R/Ls/Rs 0x8 = 3/3 L/C/R/Ls/Rs/Cs 0x9 = 3/4 L/C/R/Ls/Rs/Sbl/Sbr 0xA = 2/3 L/R/Ls/Rs/Cs 0xB = 2/4 L/R/Ls/Rs/Sbl/Sbr

Default = 0x00000007

AN298RC14 15

Table 4-1. OS Module API (Cont.)

Index Variable Description

0x0003 SAMPLE_RATE† Set by host

Bits 3:0 Sample Rate

0x0 = 48 kHz 0x1 = 44.1 kHz 0x2 = 32 kHz 0x3 = <Reserved> 0x4 = 96 kHz 0x5 = 88.2 kHz 0x6 = 64 kHz 0x7 = <Reserved> 0x8 = 24 kHz 0x9 = 22.05 kHz 0xA = 16 kHz 0xB = <Reserved> 0xC = 192 kHz 0xD = 176.4 kHz 0xE = 128 kHz 0xF = <Reserved>

Default = 0x00000000 (48kHz)

0x0004–0x0008 Reserved Reserved

0x0009 SOFTBOOT

0x000A–0x003A Reserved Reserved

0x003B GPIO_D GPIO Data register.

0x003C GPIO_OE GPIO Data Direction register.

0x003D GPIO_MUX GPIO MUX Selector register.

0x003E–0x0043 Reserved Reserved

† Bit 4: 1 = Engage Low Power Mode.

Bit 0: 0/1 disable/initiate soft boot sequence. Once a soft boot is initiated, the OS will send a 0x00000005 (SOFT_BOOT_ACK)

to the host. The host can then use the standard boo t protocol to download one or more overlays. After a soft boot is initiated, the OS will respond to boot protocol messages only.

The bit is reset to 0 after the soft boot is complete. Default = 0x00000000

Bits 31:0

Bit[i] corresponds to pin GPIO[i] (i = 0,...,31). Note: Both the GPIO_OE and GPIO_MUX must be set to 1 for a particular bit

before that bit can be written. Bit 13 to 1 (enabled).

Bits 31:0

When Bit[i] is 1, pin GPIO[i] is configured as an output. Wh en Bit[i] is 0, pin GPIO[i] is configured as an input. (i = 0,...,31).

Bits 31:0

When Bit[i] is 1, pin GPIO[i] is a GPIO function. When Bit[i] is 0, pin GPIO[i] is overwritten by the other function on that pin. Also, when Bit[i] is 0, Bit[i] of the GPIO_D register is not writable

4.2 OS Manager

and 12 of KICKSTART variable must be set

16 AN298RC14

4.3 OS Manager in DSP Composer

Table 4-1. OS Module API (Cont.)

Index Variable Description

0x0044 PLL_STANDARD_CONFIG Bits 11:4 Reference Clock Frequency - Frequency of clock attached to XTI pin,

0x0045 PLL_CUSTOM_CONFIG0 Bits 31:0 PLL Custom Configuration 0:

0x0046 PLL_CUSTOM_CONFIG1 Bits 31:0 PLL Custom Configuration 1:

0x0047–0x0051 Reserved Reserved

0x0052 ZERO_LSB_MASK Mask value used to zero DAO output. V alid only if bit 8 of Audio Manager Control

0x0053–0x0054 Reserved Reserved

0x0055 MALLOC_SUCCESS_AND_

ATTEMPT_COUNTS

0x0056 Reserved Reserved

must be set:

0x00 = 12.288 MHz 0x01 = 24.576 MHz 0x02–0x0F = Reserved 0x10 = 18.432 MHz 0x11 = 27 MHz 0x12–0xFF = Reserved

Bits 3:0 DSP core speed

0x0 = Custom speed* 0x1 = 101 MHz 0x3 = 122 MHz 0x5 = 152 MHz 0x2, 0x4, 0x6–0xF = Reserved

* Custom configuration uses the values specified in the PLL_CUST OM_ CONFIG_0 and PLL_CUSTOM_CONFIG_1 variables.

Default = 0x00000011

0x00002402 - 11.2896 MHz - 101 Core Speed 0x00002B02 - 11.2896 MHz - 122 Core Speed 0x00002302 - 11.2896 MHz - 130 Core Speed 0x00002802 - 11.2896 MHz - 152 Core Speed 0x00002002 - 12.288 MHz - 130 Core Speed 0x00001502 - 18.432 MHz - 130 Core Speed 0x80000000 - 24.576 MHz - 130 Core Speed 0x74000000 - 27.000 MHz - 130 Cord Speed

0x00000333 - 101 or 122 Core Speed 0x00000233 - 130 Core Speed

Word is 1. For example, to restrict DAO to 24bit output, ZERO_LSB_MASK=0xFFFFFF00.

Bits 31:16 Number of successful mallocations Bits 15:0 Number of mallocations attempt s

4.3 OS Manager in DSP Composer

Most configuration information described in Section 4.2 can be controlled in DSP Composer. The OS Manager indices are available in the Audio In, Audio Out, and System blocks. To insert these, simply drag the Audio In, Audio Out, and System blocks to the workspace. Once Audio In, Audio Out, and System blocks are on the workspace the pre-kick and runtime controls are accessible by double-clicking in there corresponding blocks. The controls are adjustable during runtime to interact with the DSP in a similar way as would a host-microcontroller in an actual system. Fig. 5-4 shows when you initially drag the Audio In block onto the workspace, the Audio In Device Properties automatically pops up, prompting to the user to select the input source and data format. This is also accessible by right-clicking the Audio In block.

4.4 Unsolicited Messages

Index = 0xHHHH, data value = 0xhhhhhhhh No Write Message. No Read Request. Unsolicited Read Response = 0x8100HHHH 0xhhhhhhhh

AN298RC14 17

Table 4-2. Unsolicited Messages

Index Message Description

0x0000 MALLOC_FAILURE Bits 19:16

1 = MALLOC_ERROR_REQ_LIST_OVERFLOW—too many requests. 2 = MALLOC_ERROR_NO_FREE_BLOCK— no non-modulo free block was available to service

next request)

3 = MALLOC_ERROR_NO_MOD_FREE_BLOCK—no modulo free block was available to service

next request)

0x0002 PLL_OUT_OF_LOCK Bit 23 = 1.

Bits 22:0 = Reserved.

4.4 Unsolicited Messages

18 AN298RC14

5 Audio Manager Firmware Module

5.1 Overview

The Audio Manager Firmware module provides the ability for the microcontroller to easily manage general audio controls such as gain, mute, trim and channel remap.

5.2 Audio Manager

Index = 0xHHHH, data value = 0xhhhhhhhh Write = 0x8300HHHH 0xhhhhhhhh Read Request = 0x83c0HHHH Read Response = 0x03c0HHHH 0xhhhhhhhh

Table 5-1. Audio Manager

Index Variable Description

0x0000 GAIN

0x0001 MUTE

0x0002 CHAN_0_TRIM† 0x00000000–0x80000000 (0.0 to 1.0)

0x0003 CHAN_1_TRIM

0x0004 CHAN_2_TRIM

0x0005 CHAN_3_TRIM

0x0006 CHAN_4_TRIM

0x0007 CHAN_5_TRIM

† 0x00000000–0x7FFFFFFF (-inf. to +24 dB). Overall System Gain. Signed value wit h decimal

point to the right of bit 27. Range is zero to (16-2 phase of all the outputs.

Default = 0x08000000 (+0 dB)

† 0/1 = Unmute/Mute Audio

Default = 0x00000000 (unmuted)

Volume trim for channel 0 (Left Channel) Default = 0x80000000

† 0x00000000–0x80000000 (0.0 to 1.0)

Volume trim for channel 1 (Center Channel) Default = 0x80000000

† 0x00000000–0x80000000 (0.0 to 1.0)

Volume trim for channel 2 (Right Channel) Default = 0x80000000

† 0x00000000–0x80000000 (0.0 to 1.0)

Volume trim for chann el 3 (Left Surround Channel) Default = 0x80000000

† 0x00000000–0x80000000 (0.0 to 1.0)

Volume trim for channel 4 (Right Surround Channel) Default = 0x80000000

† 0x00000000–0x80000000 (0.0 to 1.0)

Volume trim for channel 5 (Left Surround Back Channel) Default = 0x80000000

-27

). Negative values can be used to invert the

0x0008 CHAN_6_TRIM

0x0009 CHAN_7_TRIM

0x000A Reserved Reserved 0x000B Reserved Reserved

0x000C Reserved Reserved

† 0x00000000–0x80000000 (0.0 to 1.0)

Volume trim for chann el 6 (Right Surround Back Channel) Default = 0x80000000

† 0x00000000–0x80000000 (0.0 to 1.0)

Volume trim for chann el 7 (LFE0 Channel) Default = 0x80000000

AN298RC14 19

Table 5-1. Audio Manager (Cont.)

Index Variable Description

0x000D Reserved Reserved 0x000E CHAN_8_TRIM† 0x00000000–0x80000000 (0.0 to 1.0)

Volume trim for channel 8 (Left Downmix Channel) Default = 0x80000000

0x000F CHAN_9_TRIM† 0x00000000–0x80000000 (0.0 to 1.0)

Volume trim for channel 9 (Right Downmix Channel) Default = 0x80000000

0x0010 CHAN_10_TRIM† 0x00000000–0x80000000 (0.0 to 1.0)

Volume trim for chann el 10 (Left Auxiliary Channel) Default = 0x80000000

0x0011 CHAN_11_TRIM† 0x00000000–0x80000000 (0.0 to 1.0)

Volume trim for channel 11 (Right Auxiliary Channel) Default = 0x80000000

5.2 Audio Manager

0x0012 DAO1_DATA0_L_REMAP

0x0013 DAO1_DATA0_R_REMAP

0x0014 DAO2_DATA0_L_REMAP

DAO1_DATA1_L_

REMAP

0x0015 DAO2_DATA0_R_REMAP

DAO1_DATA1_R_

REMAP

0x0016 DAO1_DATA2_L_

REMAP

0x0017 DAO1_DATA2_R_

REMAP

0x0018 DAO1_DATA3_L_REMAP

XMT_LEFT_REMAP

0x0019 DAO1_DATA3_R_REMAP

XMT_RIGHT_REMAP

†**

† Selects which internal channel (0-11) is routed to DAO1 channel 0. A single internal channel

may be mapped to multiple outputs. Default = 0x00000000 (Left Channel Audio Data)

† Selects which internal channel (0-11) is routed to DAO1 channel 1. A single internal channel

may be mapped to multiple outputs. Default = 0x00000002 (Right Channel Audio Data)

Selects which internal channel (0-11) is routed to DAO1 channel 2. A single internal channel

†*

may be mapped to multiple outputs. Default = 0x00000003 (Left Surround Channel Audio Data)

Selects which internal channel (0-11) is routed to DAO1 channel 3. A single internal channel

†*

may be mapped to multiple outputs. Default = 0x00000004 (Right Surround Channel Audio Data)

Selects which internal channel (0-11) is routed to DAO1 channel 4. A single internal channel may be mapped to multiple outputs.

Default = 0x00000001 (Center Channel Audio Data) Selects which internal channel (0-11) is routed to DAO1 channel 5. A single internal channel

may be mapped to multiple outputs. Default = 0x00000007 (LFE Channel Audio Data)

Selects which internal channel (0-11) is routed to DAO1 channel 6. A single internal channel may be mapped to multiple outputs.

Default = 0x00000005 (Left Surround Back Channel Audio Data) Selects which internal channel (0-11) is routed to DAO1 channel 7. A single internal channel

may be mapped to multiple outputs. Default = 0x00000006 (Right Surround Back Channel Audio Data)

0x001A DAO2_DATA0_L_REMAP Selects which internal channel (0-11) is routed to DAO2 channel 0. A single internal channel

0x001B DAO2_DATA0_R_REMAP Selects which internal channel (0-11) is routed to DAO2 channel 1. A single internal channel

0x001C Reserved Reserved 0x001D Reserved Reserved 0x001E Reserved Reserved

may be mapped to multiple outputs. Default = 0x0000000c (Left DualZone Channel Audio Data)

may be mapped to multiple outputs. Default = 0x0000000d (Right DualZone Channel Audio Data)

20 AN298RC14

5.3 Audio Manager in DSP Composer Environment

Table 5-1. Audio Manager (Cont.)

Index Variable Description

0x001F Reserved Reserved

0x0020 DAO2_DATA1_L_REMAP*** Selects which internal channel (0-11) is routed to DAO2 channel 2. A si ngle internal channel

0x0021 DAO2_DATA1_R_REMAP*** Selects which internal channel (0-11) is routed to DAO2 channel 3. A single internal channel

* This is only available on the CS48520. ** This is only available on the CS48540 and CS48560. *** This is only available on the CS48560.

may be mapped to multiple outputs. Default = 0x0000000e (Left Auxiliary Channel Audio Data)

may be mapped to multiple outputs. Default = 0x0000000f (Right Auxiliary Channel Audio Dat a)

5.3 Audio Manager in DSP Composer Environment

All configuration information described in Section 5.2 can be controlled in DSP Composer. The Audio Manager is included with the (SPP) Standard Post Processing Overlay as well as the (APP) Advanced Post Processing Overlay Post Processing Modules. To insert the Audio Manager, drag the Post Processing Modules folde r to the workspace and select either SPP or APP. Once the SPP or APP Module is on the workspace, the runtime controls for Audio Manager can be accessed by double-clicking the SPP or APP Module. The runtime control for the Audio Manager Module is shown in

Fig. 5-1, for Remap for the cs48520 in Fig. 5-2, and Remap for the cs48540 in Fig. 5-3. Remap is part of Audio Manager,

but has been separated into the system block to centralize chann el mapping co ntrols. The con trols are a djustable d uring runtime to interact with the DSP in a similar way as would a host-microcontroller in an actual system.

Figure 5-1. DSP Composer Audio Manager Runtime Control Panel

Figure 5-2. DSP Composer DAO Remap for CS48520

Figure 5-3. DSP Composer DAO Remap for CS48540

AN298RC14 21

5.4 DSP Composer Sample Projects

Sample projects for various firmware applications have been provided in DSP Composer. Go to File > Open and browse to CirrusDSP\CS485xx\projects\. There are several sample projects that exercise other modules. Open ‘pcm_spp.cpa’. This project is configured for PCM processing, as shown in Fig. 5-4.

Figure 5-4. Audio Manager Sampl e Project

22 AN298RC14

Product Number

I/O_Config (See Table 4-1, Index 0x0001)

Bit 2 Bit 1 Bit 4

CS49860 Supported Not Supported Not Applicable CS48540 Supported Supported Not Applicable CS48520 Supported Not Supported Supported

6 PCM Firmware Module

6.1 Overview

The PCM firmware module provides routing and control functions for stereo and multi-channel PCM input. The PCM firmware is co-resident with the OS module. There are two main modes of PCM operation, stereo and multi-channel.

6.2 PCM Manager

Index = 0xHHHH, data value = 0xhhhhhhhh Write = 0x9B00HHHH 0xhhhhhhhh Read Request = 0x9BC0HHHH Read Response = 0x1BC0HHHH 0xhhhhhhhh

T a ble6-1. PCM Manager

Index Variable Description

0x0000 PCM_ENABLE Bit 16 = Disable/Enable decimation by 4 = 0/1

Bit 8 = Disable/Enable Decimation by 2 = 0/1 Note: This setting is valid for stereo and multi-channel PCM inputs. When decimator

(down sampler) is enabled, set SAMPLE_RATE (index 0x03) in OS Manager as follows:

0 = 96 kHz in 48 kHz out 1 = 88.2 kHz in 44.1 kHz out 2 = 64 kHz in 32 kHz out

Sample rate conversion is supported only for stereo and 8-channel inputs.

Bit 4 = Disable/Enable De-emphasis = 0/1 Bit 0 = Disable/Enable PCM Module = 0/1

Default = 0x00000001

0x0001 IO_BUFF_CH0_SOURCE Input Source for Channel 0 IO Buffer (Left) (see Table 2-1)

Default = 0x00000000 (DAI0 Left)

0x0002 IO_BUFF_CH1_SOURCE Input Source for Channel 1 IO Buffer (Center) (see Table 2-1)

Default = 0x00000004 DAI2 Left)

0x0003 IO_BUFF_CH2_SOURCE Input Source for Channel 2 IO Buffer (Right) (see Table 2-1)

Default = 0x00000001 (DAI0 Right)

0x0004 IO_BUFF_CH3_SOURCE Input Source for Channel 3 IO Buffer (Left Surround) (see Table 2-1)

Default = 0x00000002 (DAI1 Left)

0x0005 IO_BUFF_CH4_SOURCE* Input Source for Channel 4 IO Buffer (Right Surround) (see Table 2-1)

Default = 0x00000003 (DAI1 Right)

0x0006 IO_BUFF_CH5_SOURCE* Input Source for Channel 5 Left IO Buffer (Surround Back) (see Table 2-1)

Default = 0x00000006 (DAI3 Left)

0x0007 IO_BUFF_CH6_SOURCE* Input Source for Channel 6 IO Buffer (Surround Back Right) (see Table 2-1)

Default = 0x00000007 (DAI3 Right)

AN298RC14 23

Table 6-1. PCM Manager (Cont.)

Index Variable Description

0x0008 IO_BUFF_CH7_SOURCE* Input Source for Channel 7 IO Buffer (LFE0) (see table 2)

Default = 0x00000005 (DAI2 Right)

0x0009 IO_BUFF_CH8_SOURCE** Input Source for Channel 8 IO Buffer (Left DualZone) (see table 2)

Default = 0x08000000 (no source)

0x000A IO_BUFF_CH9_SOURCE** Input Source for Channel 9 IO Buffer (Right DualZone) (see table 2)

Default = 0x08000000 (no source)

0x000B IO_BUFF_CH10_SOURCE** Input Source for Channel 10 IO Buffer (Left Auxiliary) (see table 2)

Default = 0x08000000 (no source)

0x000C IO_BUFF_CH11_SOURCE** Input Source for Channel 11 IO Buffer (Right Auxiliary) (see table 2)

Default = 0x08000000 (no source) 0x000D Reserved Reserved 0x000E PCM_INPUT_MODE Bit 31: 0/1 Disable/Enable LFE processing thru PCM input

Bits 3:0 Input Mode (number of input channels present in the system)

Default = 0x00000002

* Not available on the CS48520. ** Not available on the CS48520 and CS48540.

6.2 PCM Manager

24 AN298RC14

6.3 PCM Manager in DSP Composer

All configuration information described in Section 6.2 can be controlled in DSP Composer. Note that IO Buffer Channel availability is device specific. The PCM Manager is part of the System block. To insert System block, drag in onto the workspace. Once the System block is on the workspace the runtime and pre-kick controls for the PCM Manager can be accessed by double-clicking the System block. When the System Block is first dragged onto the workspace the user is prompted to select device and input mode as seen in Fig. 6-1. These settings can also be accessed by right-clicking the System block and selecting Device Properties.

Figure 6-1. DSP Composer System Block Device Properties

The runtime controls are accessed by double-clicking the System Block as seen below in Fig. 6-2.

Figure 6-2. DSP Composer PCM Manager Runtime Controls

For the IO Buffer Channel Remap on the CS48520, see Fig. 6-3.

Note: This is different for each device.

Figure 6-3. DSP Composer IO Buffer Remap for cs48520

AN298RC14 25

Table 6-2. Valid IO_BUFF_*_SOURCE Values

6.4 PCM Module Notes

Value Source (multichannel mode)

0 DAI1_D0 Left DAI Left 1 DAI1_D0 Right DAI Right 2 DAI1_D1 Left None 3 DAI1_D1 Right None 4 DAI1_D2 Left None 5 DAI1_D2 Right None 6 DAI1_D3 Left None 7 DAI1_D3 Right None 8 DAI1_D4 Left None

9 DAI1_D4 Right None 10 DAI2_D0 Left None 11 DAI2_D0 Right None

0x08000000 None None

Source

(Stereo mode)

The following are the possible PCM input modes:

• Stereo Mode: Stereo PCM into DAI_D4. 2 Channel Mode set in IO_CONFIG in the OS Manager.

• Multi-channel Mode: PCM into DAI_D0 thru DAI_D3. Multi-Channel Mode set in IO_CONFIG in the OS Manager.

Stereo and Multi-channel input modes above are mutually exclusive and must be configured prior to runtime (pre-kick-start). At runtime, switching between modes is not allowed.

26 AN298RC14

7 Low Power Mode

7Low Power Mode

Note: The Low Power Mode section will be moving to the CS485xx Hardware User’s Manual in the next revision of that

manual.

The CS485xx has a low power mode to enable power savings when not in use. Low power mode is entered during the softboot procedure.

7.1 Low Power Mode Messaging

One message is relevant to the low power mode p rocedure fo r the CS485xx. This message is SOFTBOOT_LP. The host must read any ACK and prior messages before low power mode may commence.

Mnemonic Value

SOFTBOOT_LP 0x81000009

0x00000011

7.2 Low Power Mode Steps

1. The system controller should send the SOFTBOOT_LP message (0x81000009 0x00000011).

2. The CS485xx is now in low power mode.

3. To test that the CS485xx is in low power mode, the host controller can send a message and verify that there is no response. Additionally all the GPIO pins will be set to inputs in low power mode with weak pull-ups so their state can be checked to verify low power mode is active.

7.3 Getting Out of Low Power Mode

1. Set DSP_RESET low.

2. Set DSP_RESET high.

3. Send the SLAVE_BOOT message (0x80000000).

4. Read the BOOT_START message (0x00000001).

5. Send the WAKEUP_*.ULD file.

Note: This is dependent on the current memory configuration. For example: if loading os_48520_p2_*.uld, then send

wakeup_p2.uld. If loading os_48520_p4_*.uld, then send wake up_p4.uld, and so forth. See Table 7-1.

6. Read the BOOT_SUCCESS message (0x00000002).

7. Send the SOFT_RESET message (0x40000000).

8. Read the APP_START message (0x00000004).

9. Send Hardware Configuration messages.

10.Send Software Configuration messages.

11.Send the KICKSTART messag e.

AN298RC14 27

Table 7-1. wakeup_uld

.uld Options Values

WAKEUP_P2.ULD 08004409

00000002 00000000 b485aa01

ffffffff

437a11f5

WAKEUP_P4.ULD 08004409

00000002 00000001 b485aa01

ffffffff

437a11f4

WAKEUP_P6.ULD 08004409

00000002 00000002 b485aa01

ffffffff

437a11f3

7.3 Getting Out of Low Power Mode

WAKEUP_P8.ULD 08004409

00000002 00000003 b485aa01

ffffffff

437a11f2

28 AN298RC14

8 Watchdog Timer

The CS485xx has an integrated hardware watchdog timer that ac ts as a “health” monitor for the DSP. The watchdog timer must be reset by the DSP before the counter expires, or the entire chip is reset. This peripheral ensure s that the CS485xx will reset itself in the event of a temporary system failure. In standalone mode (no host MCU), the DSP will reboot from external FLASH. In slave mode (host MCU present), all GPIOs will be pulled high to signal the host that the watchdog has expired and the DSP should be rebooted and reconfigured. The watchdog timer is disabled upon reset. There are thr ee important registers that the host uses for config u rin g th e wat ch dog time r. Th e y are KICKST ART , WDG _R ELOAD, and WDG_COUNT.

Note: The enabling of the watchdog timer happens post-kick-start.

8.1 Watchdog Timer Messaging

The KICKSTART message is shown below, to enable the watchdog set bit 8 (a = 1). To enable no watchdog re-kicking, set bit 9 as well (a = 3). No watching re-kicking is only used as a test hook to verify that the reset occurs when the timer expires.

Mnemonic Value

KICKSTART 0x81000000

0x00000a00

The WDG_COUNT message is shown below and reflects the watchdog state at last timer ISR. The default is abcdefgh = FFFFFFFF.

Mnemonic Value

WDG_COUNT 0x81000018

0xabcdefgh

The WDG_RELOAD message is used to set the watchdog reload time and is shown in the table below. The default is abcdefgh = 00BB800, which is a 1 second reload time at 12.288 MHz.

Mnemonic Value

WDG_RELOAD 0x81000019

0xabcdefgh

The equation to calculate the watchdog reload time is shown below:

Watchdog reload time = MCLK / WDG_RELOAD

AN298RC14 29

Contacting Cirrus Logic Support

For all product questions and inquiries, contact a Cirrus Logic Sales Representative. To find the one nearest you, go to www.cirrus.com.

IMPORTANT NOTICE

Cirrus Logic, Inc. and its subsidiaries (“Cirrus”) believe that the information contained in this document is accurate and reliable. However, the information is subject to change without notice and is pr ov i de d “A S I S” wi t hou t war r an ty of a ny k i nd ( ex p res s o r impl i ed ). Cus to mer s ar e adv ise d to obtain the l at est ver sion of relev ant inf or mati on to veri fy, before placing orders, that information being relied on is current and compl ete. All products are sold subject to the terms and conditio ns of sal e suppl i ed at t he ti me of or de r acknowledgment, including those pertaining to warranty, indemnification, and limitation of liability. No responsibility is assumed by Cirrus for the use of th is information, including use of this information as the b asis fo r manufacture or sale of any items, or for infringement of patents or other rights of third parties. This document is the property of Cirrus and by furnishi ng thi s i nformation, Cirrus gran ts no license, express or implied under any patents, mask work rights, copyrights, trademarks, tr a de se c re ts o r ot he r intellectual proper ty rig hts. Cirr us owns t he co pyri ght s ass ociat ed with the i nf ormati on c onta ine d here in a nd giv es c onse nt f or copies to be made of the information only for use within your organiz ation with respect to Cirrus integrat ed circuits or othe r products of Cirrus . This consent does not extend to other copying such as copying for general distribution, advertising or promotional pu rp oses, or for creating any work for resale.

CERTAIN APPLICATIONS USING SEMICONDUCTOR PR ODUCTS MAY INVOLVE POTENTIAL RISKS OF DEATH, PERSONAL INJURY, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE (“CRITICAL APPLICATI ONS”). CIRRUS PRODUCTS ARE NOT DESIGNED, AUTHORIZED OR WARRANTED FOR USE IN PRODUCTS SURGICALLY IMPLANTED INTO THE BODY, AUTOMOTIVE SAFETY OR SECURITY DEVICES, LIFE SUPPORT PRODUCTS OR OTHER CRITICAL APPLICATIONS. INCLUSION OF CIRRUS PRODUCTS IN SUCH APPLICATIONS IS UNDERSTOOD TO BE FULLY AT THE CUSTOMER’S RISK AND CIRRUS DISCLAIMS AND MAKES NO WARRANTY, EXPRESS, STATUTORY OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE, WITH REGARD TO ANY CIRRUS PRODUCT THAT IS USED IN SUCH A MANNER. IF THE CUSTOMER OR CUSTOMER’S CUSTOMER USES OR PER MITS THE USE OF CIRRUS PRODUCTS IN CRITICAL APPLICATION S, CUSTOMER AGRE ES, BY SUCH USE, TO FULLY INDEMNIFY CIRRUS, ITS OFFICERS, DIRECTORS, EMPLOYEES, DISTRIBUTORS AND OTHER AGENTS FROM ANY AND ALL LIABILITY, INCLUDING ATTORNEYS’ FEES AND COSTS, THAT MAY RESULT FROM OR ARISE IN CONNECTION WITH THESE USES.

Cirrus Logic, Cirrus, the Cirrus Logic logo designs, DSP Composer, and Intelligent Room Calibration are trademarks of Cirrus Logic, Inc. All other brand and product names in this document may be trademarks or service marks of their respective owners.

Dolby, the “doubl e-D” logo, Dolby Digital, Audistry , Dolby Headphone, Dolby V irtual Surround, and Pro Logic are regis tered trademarks of Dolby Laboratories, Inc. AAC is a trademark of Dolby Laboratories, Inc. Supply of an implementation of Dolby Technology does not convey a license nor imply a right under any patent, or any other industrial or Intellectual Property Right of Dolby Laboratories, to use the Implementation in any finished end-user or ready-to-use final product. It is hereby notified that a license for such use is required from Dolby Labo ra to ries.

DTS is a registered trademark of the Digital Theater Systems, Inc. DTS NEO:6 is a trademark of Digital Theater Systems, Inc. It is hereby notified that a third-party license from DTS is necessary to distribute software of DTS in any finished end-user or ready-to-use final product.

THX® Technology by Lucasarts Entertainm en t Com p an y Corporation. THX is a registered trademark of Lucasa rts En terta inment Company Corporation. SRS, Circle Surround, Trusurround, Trusurround XT, and TruBass are registered trademarks of SRS Labs, Inc. Circle Surround, Trusurround, Trusurround XT, and TruBass

technologies are incorporated under license from SRS Labs, Inc. The Circle Surround, Trusurround, Trusurround XT, and TruBass technology/solution rights incorporated in the CS485xx are owned by SRS Labs, a U.S. Corporation and licensed to Cirrus Logic, Inc. Purchaser of CS485xx mu st sign a license for use of the chip and display of the SRS Labs trademarks. Any pro ducts incorpor ating the CS485x x must be sent to SRS La bs for review. SRS Circle Surroun d, Trusurrou nd, Trusurround XT, and TruBass technologies are protected under US and foreign patents issued and/or pending. Circle Surround, Trusurround, Trusurround XT, TruBass, SRS and (O) symbol are trademarks of SRS Labs, Inc. in the United St ates and s elected foreig n countri es. Ne ither t he purch ase of the CS4 85xx, no r the cor respond ing sal e of audi o enhanc ement equip ment conveys the right to sell commercialized recordings made with any SRS technology/solution. SRS Labs requires all set makers to comply with all rules and regulations as outlined in the SRS Trademark Usage Manual.

9 Document Revisions

Revision Date Changes

RC1 December, 2006 Initial Release RC2 September, 2007 Updated KICKSTART and PLL_STANDARD_CONFIG; added PLL_CUSTOM_CONFIG0, PLL_CUSTOM_

RC3 December, 2007 Updated Legal Notice. Removed Softboot procedure that was duplicated in Chapter 2 of the

RC4 July, 2008 Updated Table 2-1 with read and write address information for firmware modules listed in that ta ble. Updated

RC5 October, 2008 Added Bits 20, 21, and 22 to the KICKSTART variable in Table 4-1. Changed product family number from

RC6 October, 2008 Added Section 2.2, which describes .uld files. Updated Table 2-1, adding Audyssey Dynamic Volume and

RC7 December, 2008 Modified Section 7. RC8 August, 2009 Updated Table 2-1. Added Table 2-2. Updated bit definitions for index 0x0001, IO_CONFIG. Updated bit

RC9 September, 2009 Added Cirrus Bass Enhancer to Table 2-1.

RC10 September, 2009 Added “†” symbol for indices 0x0012 to 0x001 9 in Table 5-1, indicating that the indices ca n be modif ied af ter

RC11 December, 2010 Added definition of Bit 8 to CONTROL_WORD variable in Table 5-1. Added index 0x0052 to Table 4-1. RC12 November, 2011 Added information regarding PLL out of lock message to Section 3.1.3. RC13 November, 2012 Updated PCM Manager Controls screenshot in Fig. 6-2. RC14 March, 2013 Updated Index 0x000a–0x0021 and removed 0x0022 in Table 5-1.

CONFIG1, and MALLOC_FAILURE.

CS485xxHardware User’s Manual.

implementation status and defini tions of GPIO_D, GPIO_OE, and GPI O_MUX variables in Table 4-1. Added DAI_CLOCK_SOURCE variable in Table 4-1.

CS485xx to CS48xxxxx, which now covers the CS485xx, CS48AU2B, and CS48DV2B products.

Dynamic EQ, Audyssey EQ, and Audyssey EQ firmware modules to the table.

definitions for index 0x0000, PCM_ENABLE.

kick-start.

30 AN298RC14

Cirrus Logic AN298 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1 Document Strategy

2 Overview

2.1 Firmware Overlays

2.2 Code Image (.uld) Files

2.2.1 .uld File Naming Conventions

2.3 Download Sequence

2.4 Firmware Modules and Associated Application Notes

3 Firmware Messaging

3.1 Communication Overview

3.1.1 Writing to the DSP

3.1.2 Solicited Read

3.1.3 Unsolicited Message

4 Operating System (OS) Firmware Module

4.1 Overview

4.2 OS Manager

4.3 OS Manager in DSP Composer

4.4 Unsolicited Messages

5 Audio Manager Firmware Module

5.1 Overview

5.2 Audio Manager

5.3 Audio Manager in DSP Composer Environment

5.4 DSP Composer Sample Projects

6 PCM Firmware Module

6.1 Overview

6.2 PCM Manager

6.3 PCM Manager in DSP Composer

6.4 PCM Module Notes

7 Low Power Mode

7.1 Low Power Mode Messaging

7.2 Low Power Mode Steps

7.3 Getting Out of Low Power Mode

8 Watchdog Timer

8.1 Watchdog Timer Messaging

9 Document Revisions
