MULTIMETER CURRENT CLAMP
CPM
(Code: M80430)
INSTRUCTION MANUAL
( M98111201-03-10A )
CIRCUTOR S.A.
--------- MULTIMETER CURRENT CLAMP
CPM
-------- PG No. 1
-
CPM ANALYZER INDEX page no.
SAFETY NOTES
Before using the equipment please read the user manual, paying special attention to
the SAFETY REQUIREMENTS section.
The symbol on the equipment means "CONSULT THE INSTRUCTION
MANUAL". It can also appear as a symbol of warning or caution in this manual.
WARNING and CAUTION statements can appear throughout this manual to avoid
hazard to persons or damage to equipment or other property.
1.- OVERVIEW
1.1.- Description
The CPM Current clamp provides functions for the measurement of voltage,
current, resistance, continuity sound alarm, diode test, as well as frequency
measurement.
Three push buttons allow for the selection of functions such as measurement
hold (HOLD), maximum value (MAX) and reset for current measurement DC (DCA
ZERO).
--------- MULTIMETER CURRENT CLAMP
CPM
-------- PG No. 2
-
The analyzer is powered by a 9 V battery. Its design and its double insulation
makes the CPM a robust and secure instrument.
--------- MULTIMETER CURRENT CLAMP
CPM
-------- PG No. 3
-
1.2.- Specifications
Display
3 ½ digit LCD display with a maximum
reading of 1999.
Display functions
Hold
MAX
Measurement value hold.
Maximum measurement value hold.
Polarity
Automatic, positive by default and indication
of negative polarity (-).
Overrange
(OL) or (-OL) appears on the display.
Zero
Automatic
Low battery indication
The“ “indicator appears when the battery
voltage is below the level of operation.
Reading rate
2.5 measurements a second, nominal.
--------- MULTIMETER CURRENT CLAMP
CPM
-------- PG No. 4
-
Power Supply
9 V, IEC 6F22 battery.
Battery life
Typically 200 hours for a zinc-carbon
battery
Environmental conditions
Operating temperature
Storage temperature
0 °C to 40 °C (H.R. 0-70%)
20 °C to 60 °C, (H.R. 0-80%) with the
battery removed
Dimensions
250 (W) x 100 (H) x 46 mm. (D.)
Weight
380 g, including the battery.
Accessories
A pair of test probes
Transport case
Reference conditions
Referring to environmental conditions:
23 °C ± 5 °C, HR < 75%.
--------- MULTIMETER CURRENT CLAMP
CPM
-------- PG No. 5
-
DC Voltage
Range
Accuracy
Input impedance
Overload protection
600 V
± (0.5% read. + 1 digit)
10 MΩ
600 V DC or AC rms
AC Voltage (50-500 Hz)
Ranges
Accuracy
Input impedance
Overload protection
200 V, 600 V
± (1.2% read. + 4 digits)
10 MΩ
600 V DC or AC rms
Resistance
Ranges
Accuracy
Open circuit voltage
Overload protection
2 kΩ, 200 kΩ
± (1.2% read. + 1 digit)
0.3 V DC
600 V DC or AC rms
Frequency (Autoranging)
Ranges
Accuracy
Sensitivity
Overload protection
2 kHz, 20 kHz
± 0.1% read. + 3 digits.
80 V rms minimum
600 V DC or AC rms
