Cilo C-101 User Manual

OPERATION MANUAL

Cilo C-101 DVD-Player

Tableofcontents

Before use

Table of contents 3

Safety precautions 4

Important safety notices 5

Important information 7

Suitable discs 8

Disc protection 9

Control and connection

Programme 15

Zoom 15

NTSC/PAL 16

Volume and Mute 16

Mode 16

Menu 16

Title 16

Angle 16

Audio 16

Normal connection 10

Front panel 12

Remote control 13

Normal playback

Preparation 14

Normal playback 14

Pause 14

Stop playback 14

Rewind and forward 14

Fast forward and rewind 14

Advanced playback

V. Mode 15

OSD 15

Subtitle 15

Step 15

Time 15

Repeat 15

A-B repeat 15

Special features

JPEG 17

Mp3 discs 17

Reference

System setup 18

Troubleshooting 22

DVD characteristics 23

DVD, special functions 24

Functions supported by DVDs 24

Technical data 25

Rights 26

Own notes 27

Safety precautions

A triangle with a lightning symbol draws the user's attention

to “dangerous voltage” without insulation in the housing

which may be high enough to entail a risk of electric shock.

A triangle with an exclamation mark draws the user's

attention to important instructions for use and maintenance

in the accompanying manual which should be studied.

Symbol for Class II (double insulation).

WARNING:

CAUTION:

TO MINIMISE THE RISK OF FIRE AND ELECTRIC SHOCK,DO NOT EXPOSE

DEVICE TO RAIN OR MOISTURE. DO NOT OPEN THE HOUSING AS IT

CONTAINS DANGEROUS VOLTAGE. ONLY SKILLED TECHNICIANS ARE

ALLOWED TO CARRY OUT REPAIR AND SERVICE.

If the power cord plug is to be replaced, it is important that the replacement is identical

to the plug to be replaced, or that the new plug has been recommended by the

manufacturer.

TO AVOID THE RISK OF ELECTRIC SHOCK, IT IS IMPORTANT TO INSERT THE

PLUG CORRECTLY INTO THE SOCKET.

This DVD player includes a laser system.

There is a risk of dangerous radiation from the laser beam if buttons, controls and

procedures are not used or carried out as described in this manual. To avoid contact

with the laser beam, do not open the device.

DO NOT LOOK DIRECTLY INTO THE LASER BEAM.

Important safety notices

WARNING: IT IS IMPORTANT THAT YOU STUDY AND OBSERVE BOTH THE INSTRUCTIONS IN THIS MANUAL AND THE INSTRUCTIONS ON THE DEVICE. KEEP THIS MANUAL FOR FUTURE USE.

This device was developed and made with a view to providing maximum safety for the user. Incorrect use of the device may cause electric shock or fire. The protection built into this device will protect the user if the procedure below is observed in connection with installation, use and repair. This device is fully electronic and contains no parts which can be repaired by the user.

THE HOUSING MUST NOT BE REMOVED. RISK OF DANGEROUS VOLTAGE. ONLY SKILLED TECHNICIANS ARE ALLOWED TO REPAIR THE DEVICE.

Read the manual

On unpacking the device, please read the manual carefully and observe all instructions given.

Power supply

Only the power supply indicated on the rating plate must be used for this device. If you are not sure which power supply you have, please contact the distributor or the local electricity supplier.

Earthing or polarization

If the plug cannot be inserted properly into the socket, or if the plug does not fit, the device must not be used in your country.

Ventilation

The housing is provided with slots and openings to ensure ventilation and reliable operation and protect the device against overheating. Do not block or cover these openings. The openings must never be blocked, for example by placing the device on a bed, a sofa, a carpet or similar surface.

Heat

Do not place the device near sources of heating such as radiator, register, stove or other heat-producing devices (including amplifiers).

Water and moisture

The device must not be placed close to water, such as bath tub, wash basin, kitchen sink or wash tub, in a damp cellar or close to a swimming pool, etc.

Cleaning

Unplug the device before cleaning. Do not use liquid detergents and aerosol cleaning agents. Use a dry cloth.

Power cords

Wiring must be organised to prevent people from stepping on the cables and to avoid pinching by objects placed on or beside them. Take special care around sockets and plug boxes and where the cable leaves the device.

Overloading

Make sure that sockets, extension flexes and plug boxes are not overloaded as this may lead to fire or electric shock.

Important safety notices

Lightning

Unplug the device for additional protection during thunder or when the device is not used for prolonged periods. This will prevent damage to the device from lightning and surges.

Penetration of objects and liquid

Never push any objects through the openings into the device, as they may touch dangerous voltage points or short circuit parts and cause fire or electric shock. Do not spill liquid on the DVD player.

Accessories

The device must not be placed on unstable surfaces such as a trolley, stand, tripod, shelf or table. The device may fall and injure children or adults or be damaged. Use only trolley, stand, tripod, shelf or table which are very stable or provided with the device. The Device must be installed in accordance with the manufacturer's instructions and by means of installation equipment recommended by the manufacturer. If the device is placed on a trolley, the trolley must be moved carefully. Sudden stops, unnecessary force and uneven surfaces may cause the trolley to turn over.

Discs

Do not use scratched, deformed or repaired discs. Such discs will break easily and may cause serious injury and damage to the device.

Damage

Unplug the device and contact skilled technicians in the following cases:

A) If power cord or plug is damaged. B) If liquid has been spilled on the device or objects

have fallen into the device. C) If the device has been exposed to rain or water. D) If the device does not work properly after

adhering to the instructions in the user manual.

Make only the setups mentioned in the manual, as

incorrect setup may cause damage and will often

make it difficult for a skilled technician to make the

device work properly again. E) If the device has been dropped or damaged in any

other way. F) When the operation of the device changes drastically, the device requires service.

Service

Do not attempt to carry out any service work yourself. By opening or removing the housing, you will be exposed to dangerous voltage, etc. Any service work should be carried out by skilled technicians.

Disc drive

Keep your hands off the drive when it closes to avoid trapping your fingers.

Loads

Do not place heavy loads on the DVD player, and do not step on it. The load may fall and cause serious injury or damage to the device.

Spare parts

If spare parts are required, make sure that the technician uses spare parts specified by the manufacturer or with the same characteristics as the original component. Unauthorised spare parts may cause fire, electric shock, etc.

Safety check

After service or repairs on the DVD player, ask the service technician to carry out a safety check to ensure that the device is ready for use.

Important information

Handling instructions

The DVD player's top and back panel may become warm after prolonged use. This is not due to a defect.

When the DVD player is not used, remove the disc and turn off the device.

If the DVD player is not used for a long period, its function may deteriorate. Therefore, the DVD player should be turned on and used now and then.

Protect the power cord

Follow the instructions below to avoid irregular function, electric shock, fire, or injury:

Hold the plug firmly when inserting it into the socket Avoid heat-producing devices Do not place objects on the power cord Do not carry out service work on or change the power cord

Condensation

Condensation may occur in the following cases:

When the DVD player is moved directly from a cold to a warm place.

When the DVD player is used in a room where the radiator has just been switched on or where the cold air from the air condition plant is directed at the device.

If the DVD player is used in the summer in a warm and humid room just after it has been removed from an air conditioned room.

If there is steam or a high level of humidity in the room.

In case of condensation, the DVD player will not work properly. Remove the disc and turn off the device. Unplug the device and leave it for 2-3 hours. The DVD player will then have adapted to the environment and any condensation will have disappeared.

Positioning

Do not place the device in any of the following places: In sunlight, close to heat-producing devices and in a closed trolley At high temperatures (40ºC or above) or high relative humidity (90% or more) In dirty places as some internal parts may be damaged

Do not put your fingers or any other objects into the device

Touching the internal parts is dangerous and may cause injury or damage. Do not open the housing. Do not place foreign matter on the drive.

Interference

Placing the DVD player near a television set, radio or video player may cause poor picture and sound quality. In that case, move the DVD player further from television set, radio or video player.

NOTE:

An Ø may appear on the screen when the device is turned on. This means that the required operation is not available.

suitable discs

The following discs can be used:

DISC’S MARKING CONTENTS DIMENSION

DivX

No other discs than those mentioned above cannot be used. Non-standard discs cannot be used, not even when marked as above. The quality of a CD-R, CD-RW, DVD-R, DVD+R, DVD-RW, DVD+RW, or DVD-RAM depends on the way the CD was recorded. In some cases, the quality can be very poor.

DivX version: 3.11, 4.xx, 5,xx

Disc protection and accessories

Disc handling

Do not touch the playback side of the disc Do not put paper or tape on the disc

Cleaning the discs

Finger prints and dust may cause poor sound and picture quality. Wipe the disc with a dry, soft cloth. Wipe from the centre out. The disc should always be clean.

Storing the discs

Do not store the discs where they may be exposed to direct sunlight or where they are close to sources of heat. Do not store the discs where they may be exposed to moist or dust, for example in a bathroom or close to a humidifier. Store the discs standing in a cassette. If the cassettes are stacked or an object is placed on the cassettes, the discs may become uneven.

Organisation of discs

Normally, DVD discs are divided into titles, and the titles are then divided into chapters. Music CDs are divided into tracks.

If the dust cannot be removed with a soft cloth, wipe the disc carefully with a moist cloth and then with a dry cloth. Do not use any type of solvents such as thinner, petrol, commercial detergents and anti-static spray for vinyl records. These may damage the disc.

Each title, chapter and track has been given a number, designated title number, chapter number and track number, respectively.
