CHRYSLER STRATUS User Manual
SECTION PAGE
1
INTRODUCTION
2
LOCKING AND UNLOCKING
3
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS
4
INSTRUMENTS AND CONTROLS
5
STARTING AND DRIVING
6
FOR PLEASANT DRIVING
7
VEHICLE CARE
8
EMERGENCIES
9
MAINTENANCE
.............................................................251
.............................................................261
TABLE OF CONTENTS
.............................................................3
..................................................21
..........................55
.............................................103
...................................................141
...................................................205
...........................................................309
1
2
3
4
5
6
7
8
9
10
11
12
SPECIFICATIONS
IF YOU NEED CONSUMER ASSISTANCE
INDEX
...................................................................381
...........................................................363
.......................................371
10
11
12
CONTENTS
INTRODUCTION
1
m Introduction
m How To Use This Manual
...........................4
.................4
m Warnings, Cautions And Notes
m Vehicle Identification Number
.............5
..............5
4 INTRODUCTION
INTRODUCTION
This manual has been prepared with the assistance of
service and engineering specialists to acquaint you with
the operation and maintenance of your new vehicle. It is
supplemented by a Warranty Information Booklet and
various customer oriented documents. You are urged to
read these publications carefully. Following the instructions and recommendations in this manual will help
assure safe and enjoyable operation of your vehicle.
NOTE:
After you read the manual, it should be stored
in the vehicle for convenient reference and remain with
the vehicle when sold.
When it comes to service, remember that your manufacturers dealer knows your vehicle best, has the factorytrained technicians and genuine Mopart parts, and is
interested in your satisfaction.
This manual includes instructions for standard and optional equipment available at the time this manual was
printed. The manufacturer reserves the right to make
changes in design and specifications and to make additions or improvements in its product without imposing
any obligations upon itself to install them on previously
manufactured products.
HOW TO USE THIS MANUAL
Consult the table of contents to determine which section
contains the information you desire.
The detailed index, at the rear of this manual, contains a
complete listing of all subjects.
INTRODUCTION 5
WARNINGS, CAUTIONS AND NOTES
This manual contains WARNINGS against operating
procedures which could result in an accident or bodily
injury. It also contains CAUTIONS against procedures
which could result in damage to your vehicle. If you do
not read this entire manual you may miss important
information. Observe all Warnings and Cautions. Notes
are provided as helpful information.
VEHICLE IDENTIFICATION NUMBER
Vehicle Identification Number (VIN) is found on a
stamped plate located on the driver’s front corner of the
instrument panel, visible through the windshield. This
number also appears on the vehicle registration or title.
WARNING!
This product contains or emits chemicals known to
the State of California to cause birth defects or other
reproductive harm.
1
6 INTRODUCTION
Overview - Instruments and controls
1. Instrument cluster → p. 106
2. Ignition switch → p. 147
3. Supplemental restraint system-air bag
(For driver’s seat) → p. 89
Horn switch → p. 132
4. Hazard warning flasher switch → p. 123
5. Windshield wiper and washer switch → p. 126
6. Vents → p. 233
7. Supplemental restraint system-air bag
(For front passenger’s seat) → p. 89
8. Audio
9. Rear window defroster switch → p. 125
10. Air conditioning → p. 234
11. Fog light switch (if so equipped) → p. 123
12. Hood release lever → p. 41
13. Instrument panel light dimmer control → p. 124
14. Combination headlight, dimmer and turn-signal
lever → p. 119
15. Cruise control lever → p. 113
16. Accessory socket → p. 209
17. Parking brake lever → p. 167
18. Gearshift or selector lever → p. 151, 156
INTRODUCTION 7
Interior
1. Seat belt → p. 68
Adjustable seat belt shoulder anchor (for front
seats) → p. 73
2. Remote trunk lid release → p. 37
3. Power window switch → p. 43
4. Window lock switch → p. 45
5. Electric remote-controlled outside mirror
switch → p. 186
6. Power door lock switch → p. 34
7. Sun visor → p. 207
8. Sunroof switch (for vehicles with sunroof) → p. 46
Dome light (for vehicles without sunroof) → p. 129
9. Inside day/night rearview mirror → p. 175
Electrochromic inside rearview mirror (if so equipped)
→ p. 176
Dome light (for vehicles with sunroof)
10. Vanity mirror → p. 208
11. Glove compartment → p. 212
12. Cup holder (for rear seat) → p. 210
13. Rear seat → p. 66
14. Center console with lid → p. 213
15. Supplemental restraint system-side air bag → p. 89
(for front seats, if so equipped)
16. Cup holder (for front seats) → p. 210
17. Front seat
18. Ash receptacle receiver.
1
8 INTRODUCTION
Outside
1. Engine compartment → p. 257
Engine hood → p. 41
2. Windshield wiper and washer → p. 126
3. Sunroof (if so equipped) → p. 46
4. Outside rear-view mirrors → p. 186
5. Whip antenna → p. 217
6. Front turn signal lights and parking lights
→ p. 119, 295
7. Fog lights (if so equipped) → p. 120
8. Headlights → p. 119, 292
9. Front side marker lights → p. 298
10. Tire inflation pressure → p. 332
Changing tires → p. 268
Tire rotation → p. 336
Tire chains → p. 337
Wheel covers (if so equipped) → p. 266
11. Locking and unlocking → p. 26
Keyless entry system → p. 29
12. High-mounted stop lights → p. 300
13. Trunk lid → p. 35
14. License plate lights → p. 300
15. Back up lights → p. 291
16. Stop and tail lights → p. 291
17. Rear turn signal lights →p. 291
18. Rear side-marker lights → p. 291
19. Fuel filler → p. 39
INTRODUCTION 9
Trunk Area
1. Inside emergency trunk release handle → p. 37
2. Trunk light → p. 303
3. Jack → p. 265
4. Spare tire → p. 265
5. Tools → p. 264
1
10 INTRODUCTION
QUICK INDEX
If this warning light comes on…
NOTE:
These warning lights will illuminate for a few seconds for a bulb check when the ignition key is first turned on.
Warning light Do this Ref. page
·Park the vehicle in a safe place and turn off the engine.
Test the system as described on page 113.
·If the light does not go out after the test, or if it illumi-
Anti-lock braking system
Brake warning light
Oil pressure warning light
nates again, have your vehicle inspected at an authorized dealer.
·When this light comes on, the anti-lock braking system is
not functioning and only the ordinary braking system is
functioning.
·If this light comes on while driving, check to see that the
parking brake is fully released.
·If this light stays on after releasing the parking brake,
stop and check the brake fluid level is correct.
·If the brake fluid level is correct, call an authorized
dealer for assistance.
·If this light comes on while driving, park your vehicle in
a safe place and stop the engine immediately.
Call an authorized dealer for assistance.
P. 113
P. 117
P. 114
If this warning light comes on…
Warning light Do this Ref. page
Charging system warning light
“N” indicator light in the
instrument cluster flashes rapidly
(twice per second)
·Park the vehicle in a safe place and turn off the engine.
Check the alternator belt.
If the belt is loose, broken, missing, or if the light remains
on when the ignition key is turned back on, call an
authorized dealer for assistance.
·Park the vehicle in a safe place.
Idle the engine until the warning light goes off. If the
light does not go off, have your vehicle inspected at an
authorized dealer.
INTRODUCTION 11
1
P. 114
P. 159
12 INTRODUCTION
If this warning light comes on…
Warning light Do this Ref. page
“N” indicator light in the
instruemnt cluster flashes slowly
(once per second)
Malfunction indicator light
(“SERVICE ENGINE SOON”)
SRS
Air bag warning light
Traction control system warning light
·Have the vehicle inspected at an authorized dealer as
soon as possible.
·Your vehicle will usually be drivable and not need
towing, have the engine system checked at an authorized
dealer as soon as possible.
If the vehicle is not drivable, contact Emergency
Roadside Service (ERS), authorized dealer, or local
towing company for assistance.
·Have the air bag system checked at an authorized dealer. P. 116
·
It is not necessary to stop the vehicle immediately but we
recommend that you have the system checked at an
authorized dealer as soon as possilble.
P. 159
P. 115
P. 118
If you hear the sound…
Sound Do this Ref. page
If you hear a chime constantly when
the driver’s door is opened.
“Key reminder chime”
A chime will sound if the driver’s door is opened while
the ignition key is in the “LOCK” or “ACC” position.
Remove the key to stop the chime.
OR
“Headlight reminder chime”
A chime will sound if the driver’s door is opened when
the ignition key is in the “LOCK” or “ACC” position or
removed from the ignition switch with the lights on.
If the driver’s door is closed, the chime will stop
INTRODUCTION 13
1
N50B001D
P. 27, 148
P. 120
14 INTRODUCTION
If you hear the sound…
Sound Do this Ref. page
If you hear a metallic sound (squeal)
when you depress the brake pedal
while driving.
If you hear a chime from the engine
compartment continuously while the
engine is on.
“Brake pad wear alarm”
The brake pads have worn down near the serviceable
limit.
Have the brake pads replaced at an authorized dealer.
“Brake system (hydraulic brake booster) warning chime
(Vehicle with anti-lock braking system)”
The brake circuit may not be operating correctly.
If this chime does not stop after a few minutes, carefully
stop the vehicle in a safe location and contact your nearest
authorized dealer.
P. 170
P. 117
INTRODUCTION 15
If you hear the sound…
Sound Warning light Do this Ref. page
If you hear a
chime while
the engine is
on, see the
warning light
in the
instrument
cluster.
“Seat belt reminder/warning chime”
If the driver’s seat belt remains unfastened 1 minute later,
the chime will sound intermittently (12 times). If the
driver’s seat belt remains unfastened while the vehicle is
being driven, the chime will sound as a warning each
time the vehicle stops and starts.
“Low-fuel warning chime ”
Fuel is low. Add fuel as soon as possible.
P. 118
P. 40, 113
1
“Washer fluid level chime”
The windshield washer level is low. Add fluid.
“Door-ajar warning chime”
Door or trunk is not properly shut.
If you shut the door or trunk, the chime will stop.
“Trunk-ajar warning chime”
Trunk is not properly shut.
If you shut the trunk, the chime will stop.
P. 119
P. 27, 112
P. 36
16 INTRODUCTION
If this problem occurs…
Problem Do this Ref. Page
Cannot turn the key
(1)“LOCK” to “ACC”
Turn the key while slightly turning the steering wheel
right and left.
(2)”ACC” to “LOCK”
Vehicle with automatic transaxle
Check the position of gear selector lever.
The key cannot be removed unless the gear selector
lever is set to the “P” (PARK) position.
Vehicle with manual transaxle
Place the key at the ‘‘ACC’’ position. Push the key in
and turn it.
P. 149
Cannot shift the gear selector lever
from the “P” (PARK) position
The windows are fogged up.
Shift the gear selector lever while depressing the brake
pedal. Check if the ignition key is in the “ON” position.
1.Set the heater/air conditioning mode selection dial to
the “
2.Turn on the blower.
”or“ ” position.
P. 152, 157
P. 242
If this problem occurs…
Problem Do this Ref. page
The engine does not start.
The lights do not come on or dim.
The horn does not honk or weak sound.
The engine coolant temperature gauge
indicator enters the “H” (hot) position.
Steam comes out of the engine
compartment.
INTRODUCTION 17
The battery may have a weak charge. P. 277
The engine is overheated.
Carefully stop the vehicle in a safe place.
If necessary call for roadside assistance.
P. 276
1
18 INTRODUCTION
If this problem occurs…
Problem Do this Ref. page
The vehicle is stuck in sand, mud, or
snow.
The brakes are not functioning
properly after crossing a puddle or
stream.
1. Carefully rock the vehicle by shifting the transmission
from low to reverse.
WARNING
1.When attempting to rock your vehicle out of a stuck
position, be sure that no one is near the vehicle. The
rocking motion may cause the vehicle to suddenly lurch
forward or backward, and injure bystanders.
2.Avoid racing the engine or spinning the wheels.
Prolonged efforts to free a stuck vehicle may result in
overheating and transaxle failure.
If the vehicle remains stuck after several rocking
attempts, have a towing service pull the vehicle out.
Dry out the brakes by driving slowly while lightly
depressing the brake pedal.
P. 261
—
If this problem occurs…
Problem Do this Ref. page
The automatic transaxle does not shift
when accelerating and/or the vehicle
does not easily begin to move.
A tire is punctured.
There may be a problem in the automatic transaxle.
Have the vehicle inspected by an authorized dealer.
1.Vehicles with automatic transaxle
Shift the lever into “2” (SECOND) position when
starting the vehicle. If the vehicle is on a level road, shift
the lever back to “D” (DRIVE) position.
2.Vehicles with Autostick automatic transaxle
Shift the lever into 2nd gear of the Autostick mode
when starting the vehicle. If the vehicle is on a level
road, shift the lever back to “D” (DRIVE) position.
(These methods may or may not work depending on the
contents of malfunction.)
1.Park the vehicle in a safe place where the surface is flat
and level.
2.Replace the flat tire with the spare tire.
INTRODUCTION 19
1
P. 156, 164
P. 268
LOCKING AND UNLOCKING
CONTENTS
m Keys
m Sentry Key
m Door locks (Manual)
m Keyless entry system (if so equipped)
m Power door locks
.................................23
............................23
.....................26
▫ To lock the door without using the key .......26
▫ To lock the door with the key ..............27
▫ To lock the door from the inside ............28
........29
▫ Confirmation function ...................29
▫ Using the panic alarm ...................31
▫ Procedure for replacing keyless transmitter
battery ..............................32
........................34
▫ Locking and unlocking with the door lock
switch...............................34
▫ Locking and unlocking with key or inside lock
knob................................35
▫ Locking by means of the inside lock knob .....35
m Trunk lid
▫ Remote trunk lid release..................37
▫ Inside emergency trunk release .............37
m Fuel filler
m Engine hood release
m Power windows
▫ Driver switch..........................44
..............................35
.............................39
......................41
........................43
2
22 LOCKING AND UNLOCKING
▫ Passenger switch .......................45
m Sunroof (if so equipped)
..................46
▫ To tilt up.............................46
▫ To tilt down ..........................46
▫ To open..............................46
▫ To close..............................46
▫ Sunshade ............................47
m Theft-alarm system (if so equipped)
..........48
▫ Armed stage ..........................49
▫ Alarm stage...........................50
▫ Disarmed stage ........................52
▫ Testing the theft-alarm system..............52
LOCKING AND UNLOCKING 23
KEYS
F11A1100
Two keys are provided.
The keys fit all locks. Keep one in a safe place as a spare
key.
NOTE
: The key number (A) is stamped on the plate as
shown in the illustration.
Make a record of the key number and store the key and
key number plate in a separate place so that you can
order a key from your authorized dealer if the original
keys are lost.
SENTRY KEY
The sentry key is designed to significantly reduce the
possibility of vehicle theft. The purpose of the system is
to immobilize the vehicle if an invalid start is attempted.
A valid start attempt can only be achieved (subject to
certain conditions), using a key 9registered9 to the sentry
key system.
All of the keys provided with your new vehicle have
been programmed to the vehicle electronics.
2
24 LOCKING AND UNLOCKING
F30A0210
NOTE
1. In the following cases, the vehicle may not be able to
receive the registered ID code from the key. This
means the engine will not start even when the registered key is turned to the 9START9 position:
•
When the key comes into contact with a metallic or
magnetic object.
•
When the key comes into contact with another
immobilizing key, or with some other transponder.
In case like these, the theft-alarm indicator (located in
the instrument cluster) will blink after 10 seconds. The
theft-alarm indicator will flash for approximately 30
seconds and then go off.
Remove the above object from the key and turn the
key back to the 9ACC9 or 9LOCK9 position. Then try
again to start the engine. If the engine does not start,
consult an authorized dealer.
2. Since there is a transponder built into the key, be
careful not to cause shock to the key, such as by dropping
it or by putting heavy objects on top of it.
3. Do not leave the key where it may be exposed to heat
caused by the high temperature and high humidity.
4. Sentry key is not compatible with remote starting
systems. Use of these systems may result in vehicle
starting problems and a loss of security protection.
5. A system failure is suspected when the ignition key is
turned to the 9START9 position, the engine does not start.
In such a case, consult an authorized dealer.
LOCKING AND UNLOCKING 25
CAUTION!
Do not make any alterations or additions to the
sentry key system. Any alterations or additions
could cause failure of the sentry key.
Replacement keys
NOTE
:
Only keys that have been programmed to the vehicle
electronics can be used to start the vehicle.
If you lose the key, you can order a key from your
authorized dealer by referring to the key number.
You will also need to register the key ID code.
Your dealer can register the key ID’s or you can follow
the 9Customer Key Programming9 procedure.
You are provided with 2 keys, but you may add up to 6
more keys, for a total of 8 registered to the vehicle.
Customer Key Programming
You can program new keys to the system if you have two
valid keys by doing the following:
NOTE
:
A valid key is one that will start and run the vehicle.
1. Insert the first valid key into the ignition and turn the
ignition to the 9ON9 position for 5 seconds.
2. Turn the ignition to the 9OFF9 position and remove the
first key.
3. Insert the second valid key and switch the ignition in
the 9ON9 position within 7 seconds.
Theft-alarm indicator will blink twice.
Turn the ignition to the 9OFF9 position and remove the
second key.
4. Insert a blank Sentry Key into the ignition and switch
the ignition in the 9ON9 position within 7 seconds.
The theft-alarm indicator will illuminate for about 3
seconds when the registration is completed.
2
26 LOCKING AND UNLOCKING
If an error occurs, the indicator will flash 3 times.
5. Repeat step 4 if you want to register additional keys.
Be sure to complete the entire registration process within
30 seconds after the theft-alarm indicator flashes in step
3.
General Information
Your sentry key operates on a radio frequency subject to
Federal Communications Commission (FCC) Rules. This
device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions.
•
This device may not cause harmful interference.
•
This device must accept any interference, including
interference that may cause undesired operation.
DOOR LOCKS (MANUAL)
To lock the door without using the key
F12A2370
To lock the door, set the inside lock knob to the locked
position, and close the door.
Be sure the keys are not inside the vehicle before closing
the door.
LOCKING AND UNLOCKING 27
Key reminder chime
After the ignition switch is off, if the driver’s door is
opened while the ignition key is in the ignition, a chime
will sound to remind you to remove the key.
Forgotten-key prevention mechanism
If the inside lock knobs on the doors are set to the locked
position and the driver’s door or passenger’s door is
closed while the key is still in the ignition switch, the lock
will automatically be released.
Door-ajar warning chime
When the vehicle is moving at more than 5 mph (8 km/h)
and the door or the trunk is open, a chime will sound to
inform the driver that the door is not properly shut.
To lock the door with the key
Lock
Unlock
F12A2330
Rotate the key toward the front of the vehicle to lock the
door. After checking that the door is locked, turn the key
back to the center and remove it from the lock cylinder.
2
28 LOCKING AND UNLOCKING
To lock the door from the inside
F12A1720
Move the inside lock knob to the locked position (so that
the red mark cannot be seen) to lock the door. All doors
should be kept locked while driving.
The locked front driver’s side door can be opened by
pulling its inside door handle without unlocking the
inside lock knob. This feature is applicable to the driver’s
door only.
CAUTION!
•
Make sure the doors are closed; driving with
doors not completely closed is very dangerous.
•
Never leave a child in the vehicle unattended.
LOCKING AND UNLOCKING 29
KEYLESS ENTRY SYSTEM (IF SO EQUIPPED)
LOCK
button
UNLOCK
button
TRUNK
button
F12D0350T
Press the keyless transmitter button(s), and all doors will
be locked or unlocked as desired. The PANIC button can
also help you signal for attention.
To lock the doors
Press the LOCK button, and all doors will be locked.
When they are locked with the reading light in the “OFF”
position, the reading light blinks twice. All turn signal
lights also blink twice and the horn sounds once.
To unlock the doors
Pressing the UNLOCK button once will unlock the
driver’s door only. Press the UNLOCK button one more
time, and all doors will be unlocked.
When the driver’s door only, or all doors are unlocked
with the reading light in the “OFF” position, the reading
light will illuminate for 30 seconds.
All turn signal lights will also blink once.
To unlock the trunk lid
Press the TRUNK button twice within five seconds and
the trunk lid will be unlocked. The trunk lid must be
closed manually after it has been unlocked.
Confirmation function
The confirmation functions provided by the horn and
turn signal lights after operation of the keyless entry
system can each be turned ON or OFF as desired. The
following procedures must be performed with the key
removed from the ignition switch. At the end of each
procedure, a chime sounds once if the function has been
turned ON or twice if the function has been turned OFF.
2
30 LOCKING AND UNLOCKING
Horn deactivation/reactivation
The confirmation function can be set in the following
three ways.
Each time the confirmation function is set, a buzzer will
sound to tell you the condition of the confirmation
function.
One buzzer: The horn will sound if the doors are locked
with the keyless entry system. The horn will sound
regardless of whether the doors are locked or unlocked.
Two buzzers: The horn will not sound, even if the doors
are locked with the keyless entry system.
Three buzzers: The horn will sound if the doors are
already locked and the keyless entry system is used
again.
In this mode, the horn will only sound when the keyless
entry LOCK switch is pressed again to reconfirm that the
doors are locked.
1. Press the LOCK switch (1) for 4 to 10 seconds and
press the UNLOCK switch (2) during this period.
2. Release the LOCK and UNLOCK switches at the same
time.
Turn signal light feature–ON/OFF
The confirmation function provided by the turn signal
lights when the doors are locked and the confirmation
function provided when they are unlocked can be
deactivated/reactivated separately.
At the end of each procedure, a buzzer sounds once if the
function has been reactivated or twice if the function has
been deactivated.
1. Press the UNLOCK button for 4 to 10 seconds and
press the LOCK button within this period.
2. To turn ON/OFF the function provided when the
doors are locked, release the LOCK button and then
release the UNLOCK button.
3. To turn ON/OFF the function provided when the
doors are unlocked, release the UNLOCK button and
then release the LOCK button.
Loading...
