Chrysler Aspen Hybrid 2009 Owner's Manual

JOBNAME: 146224AspenHEV 2009 PAGE: 1 SESS: 9 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/ifc

IMPORTANT MESSAGE REGARDING YOUR

MAINTENANCE BOOK AND WARRANTY COVERAGE

Vehicle Identification Number

Warranty Start Date

Your New Vehicle Limited Warranty requires that you perform
the scheduled maintenance at the time or metrage shown in
your Owner’s Manual. If you do not do so, and your vehicle
fails as a result of your failure to maintain it properly, repairs
may not be covered under your warranty.

Chrysler recommends that you use this Maintenance Service
Schedule Book to keep a written record of maintenance
performed on your vehicle.

Selling Retailer Code

Moving?

• Name and address changes ............................. page 5

• How to get service ................................... page 15

For 24-hour Roadside Assistance

Dial 1-800-363-4869

• Give us your Vehicle Identification Number, licence plate
number and odometer reading.

• Tell us where you are and the number from which you are
calling.

See page 20 for details.

JOBNAME: 146224AspenHEV 2009 PAGE: 1 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/ibc

MAINTENANCE

performance and reliability. The limited warranties in the warranty booklet DO NOT COVER
repairs required due to improper maintenance. We strongly suggest you keep track of scheduled
maintenance and keep receipts or other documents. Use only recommended Mopart Lubricants
and genuine Mopart Parts. In the event that a condition arises between maintenance intervals,
please contact your retailer. AVOID PROLONGED PERIODS OF IDLING.

NOTE: WHERE TIME (MONTHS) AND METRAGE ARE INDICATED, FOLLOW THE

INTERVAL THAT OCCURS FIRST.

INTRODUCTION
The oil change indicator system will remind you
that it istime to take your vehicle in for scheduled
maintenance. Based on engine operation condi­tion the oil change indicator message will illumi­nate, this means that service is required for your
vehicle. Have your vehicle serviced as soon as
possible, within the next 800 km. The oil change
indicator message will not monitor the time since
the last oil change. Change your vehicles oil if it
has been 6 months since your last oil change even
if the oil change indicator message is NOT illu­minated. Change your engine oil more often if
you drive your vehicle off-road for an extended

Scheduled maintenance must be completed to provide the best vehicle

period of time. Under no circumstances should

oil change intervals exceed 10,000 km or
6 months, whichever comes first. Your dealer

will reset the oil change indicator message after
completing the scheduled oil change. If this
scheduled oil change is performed by someone
other than your dealer the message can be reset by
referring to the steps described in the Owner’s
Manual.

The performance of all scheduled service work is
required to maintain your vehicle in good operat­ing condition. Chrysler Canada Inc. reserves the
right to deny warranty coverage if the vehicle has
not been properly maintained. While we do not
insist that such work be performed by factory
authorized retailers, we strongly recommend that
an authorized Chrysler, Jeept or Dodge Retailer
perform this work.

AT EACH STOP FOR FUEL

• Check the engine oil level about 5 minutes
after a fully warmed engine is shut off. Check­ing the oil level while the vehicle is on level
ground will improve the accuracy of the oil
level reading. Add oil only when the level is at
or below the ADD or MIN mark.

• Check the windshield washer solvent and add
if required.

ONCE A MONTH

• Check tire pressure and look for unusual wear
or damage.

• Inspect the battery and clean and tighten the
terminals as required.

• Check the fluid levels of coolant reservoir,
brake master cylinder, power steering and
transmission and add as needed.

• Check all lights and other electrical items for
correct operation.

• Check and clean wiper blades. Replace if
required.

AT EACH OIL CHANGE

• Change the engine oil filter.

• Inspect the brake hoses and lines.

VISUAL INSPECTIONS —

INSPECT FOR SIGNS OF COMPONENT

DETERIORATION AND PHYSICAL DAMAGE.

JOBNAME: 146224AspenHEV 2009 PAGE: 1 SESS: 35 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

TO OUR CUSTOMERS:

This booklet explains the maintenance schedule, the limited warranties, and optional
service contracts that apply to your new vehicle. It explains exactly what’s covered,
how long each warranty lasts, and what you must do to keep the warranties in force.
Please read the warranties and other information in this booklet carefully.

T

HIS BOOKLET SHOULD BE KEPT IN YOUR VEHICLE

In this booklet, 9Chrysler Retailer9 means any authorized retailer who sells and services
Chrysler, Jeep

9Chrysler9 and 9Chrysler Canada9 mean Chrysler Canada Inc.
9Chrysler parts9 mean Mopar

vehicles by Chrysler Motors LLC.

Chrysler and Dodge are registered trademarks of Chrysler Canada Inc., a wholly owned subsidiary of Chrysler LLC.
Jeep is a registered trademark of Chrysler LLC used under licence by Chrysler Canada Inc. Mopar is a registered
trademark of Chrysler LLC. Autopar is a registered trademark of Chrysler Canada Inc.

or Dodge vehicles.

t

or Autopar™ brand parts designed for Chrysler, Jeeptand Dodge

t

.

CONTENTS

Warranty Information...............4

Your rights and responsibilities ..........4

About your warranties ...............6

3/60 Basic Warranty.................7

5/100 Powertrain Warranty .............8

5/100 Diesel Engine Warranty ...........9

8/130 Hybrid System Warranty ..........9

Corrosion Warranty .................9

Emission Warranties ................10

What is not covered ................12

How to get service.................15

Other things you should know ..........16

Customer Assistance ...............18

Arbitration .....................19

5/100 Roadside Assistance Program .....20

Optional Service Contracts ...........24

Maintenance Service Schedule Coupons

3

JOBNAME: 146224AspenHEV 2009 PAGE: 2 SESS: 30 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

YOUR RIGHTS AND RESPONSIBILITIES

The limited warranties in this booklet are the only express warranties made
by Chrysler Canada Inc. applicable to this vehicle. Any implied warranty
or condition of merchantability or fitness for a particular purpose appli­cable to this vehicle is limited in duration to the duration of these limited

WARRANTY

INFORMATION

YOUR RIGHTS AND RESPONSIBILITIES

All of the warranties in this booklet are limited warranties and they give
you specific legal rights. You may also have other rights which vary from
province to province. Some provinces do not allow the exclusion or
limitation of incidental or consequential damages, or limitation of how long
an implied warranty lasts or who is eligible for coverage, so the stated
limitations or exclusions may not apply to you.

warranties.
Chrysler Canada Inc. shall not be liable for commercial loss, special or

consequential damages resulting from breach of these written warranties or
of any implied warranty or condition.

O

PERATION ANDMAINTENANCE

It is your responsibility under the terms of these warranties to operate and
maintain your vehicle as recommended in the Owner’s Manual. Regular
scheduled maintenance, described in your Owner’s Manual and herein, is
essential to trouble-free operation.

We strongly recommend that you return to your selling retailer for all
service, both during and after the warranty periods. Chrysler Canada
Retailers are best equipped and trained to provide all levels of service and
maintenance for your vehicle.

4

JOBNAME: 146224AspenHEV 2009 PAGE: 3 SESS: 34 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

YOUR RIGHTS AND RESPONSIBILITIES

High-tech diagnostic equipment is sometimes needed to service a vehicle
efficiently and accurately. Chrysler Canada Retailers have unique diagnos­tic computers and electronic and mechanical tools, specially designed to
service our cars and trucks, and we provide special technical training so
their technicians can render the skilled care your vehicle needs.

W

ARRANTY SERVICE

Warranty service must be done by an authorized Chrysler or Dodge
Retailer. We recommend that you return to your selling retailer for this
service; however, you may request warranty service for your vehicle from
any Chrysler Retailer. See “How to get service” on page 15.

N

AME AND ADDRESS CHANGES

The Canadian Motor Vehicle Safety Act requires vehicle manufacturers
to notify owners if the correction of a safety-related defect becomes
necessary. If you change your name or address, or if you are a subsequent
owner of this vehicle, please call the Chrysler Canada Customer Records
Department at 1-800-373-1474. You can also request to have these changes
completed by any authorized Chrysler Canada retailer.

5

JOBNAME: 146224AspenHEV 2009 PAGE: 4 SESS: 30 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

ABOUT YOUR WARRANTIES

C

ABOUT YOUR WARRANTIES

W

ARRANTY START DATE

Time and distance limitations for all warranty coverage are measured from
the vehicle’s 9warranty start date,9 which is the date when the vehicle was
originally delivered or first used, whichever occurred first.

V

EHICLES COVERED

The warranties in this booklet cover new vehicles only which are built for
sale in Canada and are registered and normally operated in Canada. The
warranties apply to all owners of the vehicle.

OVERED REPAIRS

The warranties in this booklet cover repairs to factory-installed Chrysler
parts and equipment (that is, Chrysler parts or equipment installed by
Chrysler or by the selling retailer before the vehicle was delivered to the
first owner), if the repairs were necessary because of a defect in material
or workmanship. Covered repairs will be done without charge, using new
or remanufactured Chrysler parts (see page 16).

T

OWING IS COVERED

If your vehicle has to be towed because a part covered by warranty failed,
towing to the nearest Chrysler or Dodge Retailer will be covered by the
Roadside Assistance Program (for details, see page 20).

Important: Some vehicles have special towing requirements. See your
Owner’s Manual for towing instructions.

6

JOBNAME: 146224AspenHEV 2009 PAGE: 5 SESS: 28 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

3/60 BASIC WARRANTY

3/60 BASIC WARRANTY

If required because of a defect in material or workmanship, the 3/60 Basic
Warranty will cover the adjustment, repair or replacement of any factory­installed part of your vehicle except tires for 3 years or 60,000 kilometres,
whichever occurs first. The following items are exceptions; they are only
covered (if defective) for 1 year or 20,000 kilometres, whichever occurs
first:

• light bulbs and fuses

• wiper blades

• clutch discs

• brakes (rotors, pads, linings and drums)

• windshield and rear window

• wheel alignment and wheel balancing

Tires are warranted by the tire manufacturers, not by Chrysler. For details,
see the tire manufacturer’s warranty booklet in your glovebox. Your
Chrysler Retailer may be able to assist you if you experience a problem
with a factory-installed tire.

Tires and spare tire should be replaced after six years, regardless of the
remaining tread. Failure to follow this warning can result in sudden tire
failure. You could lose control and have an accident resulting in serious
injury or death.

Your Koss headphones (if equipped) are warranted by the manufacturer,
not by Chrysler. For details, see the Koss manufacturer’s warranty card in
your glovebox.

7

JOBNAME: 146224AspenHEV 2009 PAGE: 6 SESS: 29 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

5/100 POWERTRAIN WARRANTY

5/100 POWERTRAIN WARRANTY

The following powertrain components are covered for 5 years or 100,000
kilometres, whichever occurs first, measured from the vehicle’s original

warranty start date.
Vehicles placed in taxi, limousine, postal or ambulance service and all SRT

vehicles are excluded from the 5-year or 100,000-kilometre Powertrain
Warrantyand are covered only under the 3-year or 60,000-kilometre Basic
Warranty.

• Engine -

timing case, timing chain, timing belt, gears and sprockets; vibration damper;
oil pump; water pump and housing; intake and exhaust manifolds; flywheel
with starter ring gear; core plugs; valve covers; oil pan; turbocharger housing
and internal parts; turbocharger wastegate actuator; supercharger; serpentine
belt tensioner; seals and gaskets for listed components only.

• Front-Wheel Drive (If equipped) - Transaxle case and all internal parts;

axle shaft assemblies; constant velocity joints and boots; differential
cover; oil pan; transaxle speed sensors; transaxle solenoid assembly;
PRNDL position switch; transaxle electronic controller; torque con­verter; seals and gaskets for listed components only.

Note: Manual transmission clutch parts are not covered at any time.

8

Cylinder block and all internal parts; cylinder head assemblies;

• Rear-Wheel Drive (If equipped) - Transmission case and all internal

parts; torque converter, drive/flex plate; transmission range switch;
transmission control module; bell housing; oil pan; seals and gaskets for
listed components only. Rear axle housing and all internal parts; axle
shafts; axle shaft bearings; driveshaft assemblies; driveshaft centre
bearings; universal joints and yokes; seals and gaskets for listed
components only.

• 4-Wheel Drive (4x4) (If equipped) - Transfer case and all internal parts;

transfer case control module and shift mode motor assembly; axle
housing and all internal parts; axle shafts; axle shaft bearings; driveshaft
assemblies (front and rear); driveshaft centre bearings; universal joints
and yokes; disconnect housing assembly; seals and gaskets for listed
components only.

• All-Wheel Drive (AWD) (If equipped) - Power transfer unit and all

internal parts; driveshaft and axle shaft assemblies; constant velocity
joints and boots; axle housing and all internal parts; differential carrier
assembly and all internal parts; output ball bearing; output flange; end
cover; viscous converter clutch; overrunning clutch; vacuum motor;
torque tube; pinion spacer and shim; seals and gaskets for these parts
only.

JOBNAME: 146224AspenHEV 2009 PAGE: 7 SESS: 36 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

5/100 DIESEL ENGINE / 8/130 HYBRID SYSTEM / CORROSION WARRANTIES

5/100 DIESEL ENGINE WARRANTY

(IF EQUIPPED)
The diesel engine parts are covered for 5 years or 100,000 kilometres,

whichever occurs first.

• Diesel Engine -

assemblies; core plugs; fuel injection pump and injectors; intake and exhaust
manifolds; oil pan; oil pump; timing gear drive belts and/or chains and cover;
turbocharger housing and internal parts; valve covers; water pump and
housing; seals and gaskets for listed components.

Cylinder block and all internal parts; cylinder head

8/130 HYBRID SYSTEM WARRANTY

(IF EQUIPPED)
These hybrid system parts are covered for 8 years or 160,000 kilometres,

whichever occurs first.

• Transmission and all internal components

• TPIM Fan

• TPIM Pump

• TPIM Assembly

• APM Assembly

• HV AC Cables

• HV DC cables

• Hybrid Battery

CORROSION WARRANTY

For 3 years, regardless of distance driven, your Corrosion Warranty
covers any body sheet metal panel which develops a hole caused by
corrosion.

In addition, outer body panels are covered against holes caused by
corrosion up to 5 years or 160,000 kilometres, whichever occurs first. An
outer body panel is a sheet metal panel which can be seen while walking
around the vehicle, and which is painted body colour.

This warranty applies only to holes caused by corrosion. Cosmetic or
surface corrosion (resulting from stone chips or scratches in the paint, for
example) will not be repaired under this warranty.

If corrosion damage is obviously neglected and allowed to worsen until a
hole develops, this warranty will not cover the repair.

9

JOBNAME: 146224AspenHEV 2009 PAGE: 8 SESS: 29 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

EMISSION WARRANTIES

EMISSION WARRANTIES

Chrysler Canada warrants that your new vehicle was designed, built and
equipped to conform at the time of sale with applicable federal and
provincial emissions standards, and that the vehicle is, at the time of sale,
free from defects in material and workmanship which would cause it to fail
to conform to the applicable emission standards within the warranty
periods specified. A covered defect is one which causes your vehicle to fail
to meet applicable emission control regulations.

Tokeep your vehicle operating properly and in conformance with emission
regulations, see the 9Scheduled Maintenance9 instructions in your Owner’s
Manual and herein. Only Chrysler parts should be used for maintenance
and repair of your vehicle’s emission control systems.

10

You should keep any receipts for maintenance service and pass them on to
the next owner of your vehicle, in case questions arise concerning
maintenance. Chrysler Canada has the right to deny warranty coverage if
your vehicle has not been properly maintained, or if repairs are needed
because parts other than Chrysler parts were used; however, denial will not
be based on the lack of maintenance records alone.

Warranty service must be performed by an authorized Chrysler or Dodge
Retailer.

If emergency warranty service is required and an authorized retailer is not
available, contact Chrysler Canada Customer Assistance (page 18) and
request emission warranty service help.

JOBNAME: 146224AspenHEV 2009 PAGE: 9 SESS: 28 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

EMISSION DEFECT WARRANTY / EMISSION PERFORMANCE WARRANTY

EMISSION DEFECT WARRANTY

The 3/60 Basic Warranty covers all emission control components for
3 years or 60,000 kilometres, whichever occurs first. The Emission Defect
Warranty provides longer coverage for specified components.

The Defect Warranty covers the following major emission control parts, if
so equipped, for 8 years or 130,000-kilometres, whichever occurs first:

• catalytic converter

• powertrain control module

EMISSION PERFORMANCE WARRANTY

The Emission Performance Warranty only applies to cars and trucks with
a GVW less than 3,855 kg (8,500 lb).

For 2 years or 40,000 kilometres, whichever occurs first, the Performance
Warranty will cover the cost of repairing or adjusting any components or
parts of your vehicle that might be necessary to pass an approved
provincial Inspection/Maintenance (I/M) program’s emissions test, but
only if:

• your vehicle failed an approved provincial I/M emissions test; and

• your vehicle was properly maintained and operated until it failed the

test; and

• warranty service is required in order for your vehicle to pass the
provincial I/M test

Provincial test fees, if any, are not covered by this warranty.

H

OW TO GET SERVICE UNDER THIS WARRANTY

If your vehicle fails an approved I/M emissions test within the Emission
Performance Warranty period, take it to an authorized Chrysler or Dodge
Retailer as soon as possible. Give the service representative the printout
that shows your vehicle failed the test. If possible, bring all service receipts,
maintenance logs and records to prove that your vehicle has been properly
maintained.

11

JOBNAME: 146224AspenHEV 2009 PAGE: 10 SESS: 29 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

WHAT IS NOT COVERED

WHAT IS NOT COVERED

D

AMAGE FROM MISUSE OR ACCIDENT

The warranties in this booklet do not cover repairs required due to fire,
accidents, abuse, negligence, objects striking your vehicle, carrying corro­sive materials (such as chemicals, acids and fertilizers), misuse (such as
driving over curbs, overloading, spinning wheels, etc.), racing or partici­pating in a racing event, improper disconnection of components, modifying
the exhaust system, tampering or making adjustments which do not comply
with Chrysler specifications.

Disconnecting, tampering with or changing the reading of the odometer
will void your warranties.

D

AMAGE FROM THE ENVIRONMENT

The warranties in this booklet do not cover fading or deterioration caused
by exposure to the elements, or repairs required due to airborne fallout,
acid rain, chemicals, tree sap, insects, bird or insect droppings, salt, sand,
gravel, road hazards, hail, windstorms, lightning, floods or any other event
of nature.

12

Road salt, car washes, scuffs and scratches, and everyday abrasion from
sand and dirt can affect the appearance of a vehicle’s wheels (steel, chrome
and aluminum) and other undercarriage parts. Some surface corrosion with
use is normal; it is not a defect and is not covered by any warranty.

N

ORMAL MAINTENANCE AND WEAR

The warranties in this booklet do not cover normal maintenance services,
such as oil and filter changes, general lubrication, tire rotation, engine
tune-ups and replacing spark plugs. Required maintenance services are
described in detail in your Owner’s Manual and herein. The warranties also
do not cover worn wiper blades, clutch discs, brake rotors, pads, linings or
drums, windshield and rear window, wheel alignment and wheel balancing
(unless they are defective, see page 7).

JOBNAME: 146224AspenHEV 2009 PAGE: 11 SESS: 28 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

WHAT IS NOT COVERED

D

AMAGE FROM IMPROPER MAINTENANCE

The warranties in this booklet do not cover repairs required due to
improper maintenance, lack of maintenance, use of contaminated or dirty
fuels or failure to use the proper fuels and lubricants recommended in the
Owner’s Manual and herein.

E

XTRA EXPENSES

The warranties in this booklet do not cover incidental or consequential
damages such as loss of use of your vehicle, loss of time, inconvenience,
expense for fuel, telephone, travel, rental car, overnight accommodation,
loss or damage to your personal property, commercial loss, loss of
income, etc.

NON-C

HRYSLER MODIFICATIONS

The warranties in this booklet do not cover repairs required because of
non-Chrysler modifications, installation of special equipment or accesso­ries, or use of special materials, fuels or additives. This includes special
bodies, body conversions, fuel system conversions, trailer hitches, window
tints, sunroofs, theft alarms, etc. Non-Chrysler modifications do not by
themselves void your warranty, but they are not covered by your warranty.

NON-C

HRYSLER PARTS

The warranties in this booklet do not cover parts, equipment, materials or
additives not supplied by Chrysler or not certified for use on your vehicle.
Performance and racing parts are considered to be non-Chrysler parts.

13

JOBNAME: 146224AspenHEV 2009 PAGE: 12 SESS: 28 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

WHAT IS NOT COVERED

T

EXPORTED VEHICLES

EXCEPT WHERE SPECIFICALLY REQUIRED BY LAW,
THERE IS NO WARRANTY COVERAGE ON THIS VE­HICLE IF IT IS SOLD IN OR REGISTERED IN COUN­TRIES OTHER THAN CANADA.

This policy does not apply to vehicles that have received
authorization for export from Chrysler Canada. Retailers may
not give authorization for export. You should consult an
authorized retailer to determine this vehicle’s warranty cover­age if you have any questions.

This policy does not apply to vehicles registered to Canadian
Government officials or military personnel on assignment
outside of Canada.

(See also page 15.)

OTAL LOSS AND SALVAGE VEHICLES

Any vehicle that is declared to be a total loss by any insurance company,
or is rebuilt after being declared to be a total loss, or is otherwise
designated as 9salvage,99scrap,99rebuilt9 or words of similar impact will no
longer have any warranty coverage.

Chrysler Canada will deny warranty coverage without notice if it learns
that a vehicle is ineligible for coverage for any of these reasons.

R

ESTRICTED WARRANTY

Chrysler Canada may restrict the warranty on your vehicle if the vehicle is
not properly maintained, or if it is abused or neglected and the abuse or
neglect interferes with the proper functioning of the vehicle. If the warranty
is restricted, coverage may be denied or subject to approval by Chrysler
Canada before repairs are performed.

14

JOBNAME: 146224AspenHEV 2009 PAGE: 13 SESS: 28 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

HOW TO GET SERVICE

HOW TO GET SERVICE

INC

ANADA

:

Warrantyservice must be done by an authorized Chrysler or Dodge Retailer.If you
move or are travelling in Canada, warranty service may be requested from any
authorized Chrysler Retailer, but preferably one who sells the same Chrysler or
Dodge brand vehicle as yours.

I

N THEUNITEDSTATES(INCLUDING

)

TERRITORIES

If you are travelling temporarily in the United States or Mexico, and your
vehicle remains registered in Canada, your Chrysler Canada Warranty will
still apply. Service may be requested at any authorized Chrysler or Dodge
Retailer.

I

N A FOREIGN COUNTRY OUTSIDE OFNORTHAMERICA

If you are travelling temporarily outside of North America, and your
vehicle remains registered in Canada, you should take your vehicle to an
authorized Chrysler or Dodge Retailer. If the authorized retailer charges
you for repairs which you feel should be covered under your warranty,
please get a detailed receipt for the work done. When your vehicle returns

ANDMEXICO

:

U.S. P

OSSESSIONS AND

:

to Canada, contact the Chrysler Canada Customer Assistance Centre
(page 18) for reimbursement consideration. Reimbursement will not be
considered if the vehicle does not return to Canada.

I

F YOU MOVE

If you are moving to another country, be sure to contact the customs
department of the destination country before you move. Vehicleimportation
rules vary considerably from country to country.

If you are moving to the United States, be sure to also contact the Chrysler
Motors Customer Assistance office at 1-800-992-1997 to obtain the
necessary documentation to register your vehicle and to determine war­ranty eligibility in the U.S.

N

OTICE

If your vehicle is registered outside of Canada, and you have not followed
the procedure set out above, your vehicle will no longer be eligible for
warranty coverage of any kind. (Vehicles registered to Canadian Govern­ment officials or military personnel on assignment outside of Canada will
continue to be covered by the Basic Warranty.)

:

:

15

JOBNAME: 146224AspenHEV 2009 PAGE: 14 SESS: 30 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

OTHER THINGS YOU SHOULD KNOW

P

OTHER THINGS YOU SHOULD KNOW

O

PTIONAL SERVICE CONTRACT

Chrysler Canada has a service contract specially designed for most new
vehicles, to cover repair costs beyond your vehicle’s warranty. Protection
is available for almost every operating part of your vehicle, and at
reasonable cost.

Chrysler Canada stands fully behind its service contracts. Be sure that the
contract you buy is a genuine Chrysler Service Contract. We are not
responsible for other companies’ contracts. See page 24 for details on
available service contracts.

A

PPEARANCE ITEMS

Defects or damage to sheet metal, paint, trim and other appearance items
are normally found and corrected during new vehicle inspection. For your
protection, if you find any such defect or damage, you should tell your
selling retailer immediately, because if the problem worsens due to use and
exposure, repairs will not be covered by any warranty.

RODUCTION CHANGES

Chrysler Canada and its retailers reserve the right to make changes in
vehicles built and/or sold at any time without incurring any obligations to
make the same or similar changes on vehicles which were built and/or sold
previously.

E

XCHANGE PARTS

To reduce the amount of time your vehicle is out of service due to repairs,
Chrysler may offer exchange service on some parts. Mopar
brand exchange parts may be new, remanufactured, reconditioned or
repaired, but all meet Chrysler standards and are warranted the same as
new parts. Examples of parts that may be serviced by exchange include
engines, transmissions, instrument clusters, radios, tape and CD players,
speedometers and various electronic modules.

or Autopar™

t

16

JOBNAME: 146224AspenHEV 2009 PAGE: 15 SESS: 29 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

OTHER THINGS YOU SHOULD KNOW

R

ECLAIMED REFRIGERANT

To help control suspected ozone-depleting agents, regulations require the
capture, purification and reuse of automotive refrigerant gases. As a result,
any repairs to the sealed portion of your air conditioning system, if so
equipped, may involve the installation of purified reclaimed refrigerant.

C

ASSETTE TAPES AND CDS

There are some things you should know about cassette tapes and non­commercial CDs. Labels applied to tape cassettes and home-recorded CDs
may curl, buckle or peel off. This can result in ejection failure, and repairs
required to remove a 9stuck9 CD or cassette are not covered by warranty.
In addition, some home-recorded CDs of the CD-R and CD-RW formats
may not be compatible with automotive CD players and may skip or
produce error messages. If you encounter this, check your CD player by
using a commercial CD which is known to be playable. If a CD is not
compatible with the player, replacing or servicing the player will not solve
the problem.

17

JOBNAME: 146224AspenHEV 2009 PAGE: 16 SESS: 28 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

CUSTOMER ASSISTANCE

CUSTOMER ASSISTANCE

We want you to be completely satisfied with your Chrysler vehicle. If you
have a warranty or service problem that has not been resolved to your
complete satisfaction, please follow these steps:

1. Discuss the matter with the Service Manager of your Chrysler Retailer;
then with the General Manager or owner, if necessary.

2. Give your retailer a reasonable length of time or number of opportunities
to satisfy you. In fact, your retailer may contact Chrysler on your behalf.

3. If the problem still has not been resolved, please contact us at the address
or toll-free number shown and give us an opportunity to review your
situation. When you contact us, please provide the following informa­tion:

18

❏ Your name, address and phone number
❏ The name of your retailer
❏ Your Vehicle Identification Number (VIN)
❏ Your vehicle’s odometer reading (kilometres)

Customer Assistance Centre

Chrysler Canada Inc.

P.O. Box 1621

Windsor, Ontario N9A 4H6

1-800-465-2001

JOBNAME: 146224AspenHEV 2009 PAGE: 17 SESS: 28 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

ARBITRATION

ARBITRATION

If you are still not satisfied after following the three steps on the previous
page, you have yet another option.

Chrysler Canada participates in an arbitration program administered by the
Canadian Motor Vehicle Arbitration Plan (CAMVAP). CAMVAP will
advise you about how your complaint may be reviewed and resolved by an
independent third party through binding arbitration.

Our goal and that of our retailers is your complete satisfaction. Chrysler
Canada’s participation in CAMVAP makes a valuable contribution to our
achievement of that goal. There is no charge for using CAMVAP.
CAMVAP results are fast, fair and final, as the award is binding on both
you and Chrysler Canada.

CAMVAP has been implemented in all provinces and territories. For more
information, you can call CAMVAP directly or call our Customer Assis­tance Centre. Please provide your Vehicle Identification Number (VIN).

CAMVAP

1-800-207-0685

19

JOBNAME: 146224AspenHEV 2009 PAGE: 18 SESS: 29 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

ROADSIDE ASSISTANCE

• NEED A TOW? If your vehicle cannot be driven because of mechanical
breakdown, it will be towed to the nearest authorized Chrysler Canada

ROADSIDE

ASSISTANCE

5/100 ROADSIDE ASSISTANCE PROGRAM

Weare pleased to provide this 24-hour Roadside Assistance Program for all
new 2009 vehicles which have a 3-year or 60,000-kilometre Basic
Warrantyand a 5-year or 100,000-kilometre Powertrain Warranty. Eligible
vehicles must be registered in Canada and are covered for 5 years or
100,000 kilometres, whichever occurs first, from the vehicle’s warranty
start date. Vehicles placed in taxi, limousine, postal or ambulance service
and all SRT vehicles, are covered for roadside assistance for 3 years or
60,000 kilometres only (whichever occurs first). Roadside Assistance
service will be provided to the owner or driver of an eligible vehicle.

Retailer which services your brand of vehicle (or to the Chrysler Canada
Retailer of your choice, provided it is within a 35-kilometre distance of the
point of breakdown).

• STUCK? If your vehicle is stuck in a ditch or snow on or adjacent to a
public roadway and appears to be undamaged, and the tow facility has
access, it will be winched to the nearest road surface. If your vehicle is
unable to proceed under its own power and a tow is required once the
winch is performed, you will be responsible for paying the service facility
for the winch and the tow.

• DEAD BATTERY? If your battery is dead, jump-start assistance will be
dispatched to your location. In the event that your vehicle fails to start, your
vehicle will be towed to the nearest Chrysler Retailer (or to the Chrysler
Retailer of your choice provided it is within a 35-kilometre distance of the
point of breakdown).

• LOCKED OUT? If your keys are locked in your vehicle or your locks
are frozen, help will be sent to your location. (Service is limited to
providing access to the seating area only and does not include the cost of
replacing keys.)

20

JOBNAME: 146224AspenHEV 2009 PAGE: 19 SESS: 29 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

ROADSIDE ASSISTANCE

• FLAT TIRE? If you have a flat tire, the service facility will remove it

and install your spare tire. The spare tire must be inflated and in sound
operating condition. Tire repairs are not covered.

• OUT OF FUEL? If your vehicle runs out of fuel, a small amount of

gasoline will be delivered to your location, where regulations permit. In all
other cases, including alternate fuels, your vehicle will be towed to the
nearest re-fuelling centre. In these instances, the cost of fuel purchased will
be your responsibility.

Please read (About Roadside Assistance( (page 22) because there are
some limitations that may affect the service available to you.

T

O REQUEST ASSISTANCE(SEE ALSO INSIDE FRONT COVER

If your vehicle requires any of the services provided by the program, call
this toll-free number anytime, from any location in Canada or the United
States: 1-800-363-4869 (this number does not ring at Chrysler Canada).
Please identify yourself as a Chrysler vehicle owner and be ready to provide:

❏ Your Vehicle Identification Number
❏ Your licence plate number
❏ Your odometer reading (kilometres)
❏ The location of your vehicle and the phone number where you can

be reached

❏ Type of service needed (tow, flat tire, battery boost, etc.)

)

Note: • In severe weather, some delays may be expected.

• You will have to personally authorize the service provided by the

tow company

• If your vehicle is towed to a retailer, you are responsible for
contacting the retailer to authorize the service

T

OWING AFTER THE PROGRAM EXPIRES

Coverage under the Roadside Assistance Program expires at 5 years or
100,000 kilometres (or at 3 years or 60,000 kilometres, if applicable),

whichever occurs first. If you call the toll-free number for assistance after
the Program expires, you will have to pay for the service provided.

Some emissions coverage lasts longer than the Roadside Assistance
Program.* For warranted emission system repairs after the program
expires, towing (only) will be provided on a reimbursement basis. Call the
toll-free number and service will be dispatched, but you will have to pay
for the tow. For reimbursement consideration, see your authorized retailer
for further details.

* See page 10.

21

JOBNAME: 146224AspenHEV 2009 PAGE: 20 SESS: 29 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

ROADSIDE ASSISTANCE

A

BOUT ROADSIDE ASSISTANCE

The Chrysler Canada Roadside Assistance Program is not a warranty, but
the coverage is concurrent with the Basic and Powertrain Warranties.

Covered service must be provided in Canada or the Continental United
States and is limited to plated and insured vehicles that use public
roadways.

Service will not be provided free if you have driven into an area that is
inaccessible to the service vehicle or is not a regularly travelled and
maintained public road (such as beaches, recreational areas, construction
sites, open fields, private and seasonal roads). Cross-country, logging, auto
cross and any other form of off-road use is not covered.

The program does not cover winching or towing for vehicles that become
stuck while plowing snow.

The program does not cover repeat calls for the same problem (if avoidance
of the problem is within the control of the driver or owner), or towing from
one retailer to another, or service if the driver appears to be under the
influence of alcohol or drugs.

22

The program does not pay for parts, tires, repairs, labour or vehicle storage.
Parts, repairs, or labour covered under a vehicle warranty will be provided
by your Chrysler Canada Retailer.

The program does not pay for towing required because of an accident.

For example, if a vehicle is winched from a ditch or snowbank and is then
determined to need a tow because of damage suffered when it left the road,
the tow will not be covered.

The program does not cover any 9incidental or consequential damages9
connected with the failure of your vehicle or providing services to you.
Such damages include lost time, inconvenience, loss of use of your vehicle,
rental cars, fuel, telephone, travel or lodging, loss of personal or commer­cial property, loss of revenue, etc.

All service providers are independent contractors and are not employees or
agents of Chrysler Canada. Any loss or damage to your vehicle or personal
property resulting from providing roadside service is the responsibility of
the roadside service provider (the towing company, for example).

Report any damage or loss to the manager of the service provider and to
your own insurance company within 24 hours and before any repairs are
performed.

JOBNAME: 146224AspenHEV 2009 PAGE: 21 SESS: 29 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

ROADSIDE ASSISTANCE

Chrysler Canada reserves the right to limit services or reimbursement
claims for any vehicle, if in our opinion there is abuse of the services or
requests for service become unreasonable or too frequent.

The program may be amended or cancelled at any time without refund.

I

N REMOTE LOCATIONS

If your vehicle suffers a warrantable mechanical breakdown at a consid­erable distance from a Chrysler Canada Retailer, we reserve the right to
engage a nearby non-Chrysler service facility to repair your vehicle, to
minimize inconvenience to you.

In very remote areas, if your vehicle cannot be taken by road to the
servicing retailer, transportation by rail or water may be necessary. The
program will cover a tow to the dock or rail terminal and also to the retailer
at the end of the trip, but special transportation by rail or water must be
arranged for and paid by you. We will reimburse you for special
transportation costs, up to $300 per incident.

I

F YOU HAVE TO PAY

If you have to pay for a service that is normally covered by the program,
you may claim reimbursement under the following conditions:

• You must have called the toll-free number first for assistance

• Towing claims must be accompanied by the original detailed repair bill

and towing invoice

• Reimbursement will be limited to the local Roadside Assistance
contractor rates, to a maximum of $100 per incident, unless otherwise
noted

• Only original receipts, bills and/or charge card copies submitted by you
will be accepted for consideration for reimbursement. Originals will be
returned upon request

• Mail your claims to:
Chrysler Canada Roadside Assistance
248 Pall Mall, P.O. Box 5845
London, Ontario N6A 4T4

Chrysler Canada reserves the right to decline any claim presented for
payment later than 30 days from the date the service was performed, or if
service was provided by an unlicensed garage or individual.

23

JOBNAME: 146224AspenHEV 2009 PAGE: 22 SESS: 29 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

OPTIONAL CHRYSLER CANADA SERVICE CONTRACTS

As complete as our new warranty is, it may not give you total protection
for your ownership period, nor does it provide the regular maintenance
which is required to keep your new vehicle at its optimal operating

OPTIONAL

CHRYSLER CANADA

SERVICE

CONTRACTS

condition. If you lease a vehicle, you should be aware of your obligation to
maintain and repair the vehicle.

Chrysler Canada Service Contracts can enhance your new vehicle’s factory
warranty from the day of delivery and provide mechanical coverage on
most major components
types of plans available for purchase to suit most needs and the average
length of ownership.

Vehicles placed in police, taxi, limousine, postal or ambulance service and
all SRTvehicles may qualify for a service contract. Please see your selling
retailer for 9Special Use9 Service Contract availability.

††

Subject to limitations. Details available at your selling retailer.

††

when your factory warranty expires. There are 3

24

JOBNAME: 146224AspenHEV 2009 PAGE: 23 SESS: 30 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

OPTIONAL CHRYSLER CANADA SERVICE CONTRACTS

1. P

OWERTRAIN PLANS

Powertrain plans complement the factory powertrain warranty by provid­ing enhanced roadside coverage and car rental allowance if your vehicle is
not drivable and must be kept overnight. Certain plans also provide
additional distance coverage.

Major components covered are:

• engine • transmission • front-wheel drive • rear-wheel drive

• 4-wheel drive (4x4) • all-wheel drive vehicles

2. (G

OLD(PLANS

Each plan provides full mechanical repair protection to non-powertrain
(Gold) components. Certain plans also provide full mechanical protection
against powertrain component repairs beyond your vehicle’s powertrain
warranty coverage. Contracts are available with or without a deductible.

Major components covered are:

• steering • air conditioning • engine cooling and fuel • front suspension

• rear suspension • electrical • hydraulic brake components • anti-lock

brakes
* Maximum terms available on new vehicles registered in Canada only.

*

*

3. (G

OLDPLUS(PLANS

The most complete protection available for your new vehicle is a 9Gold
Plus9 Service Contract which combines the benefits of Gold component
coverage (see 9Gold9 Plans), plus, the most important vehicle maintenance
functions:

• Engine oil and oil filter changes

• Tire rotation every other service

• 9Peace-of-Mind9 motoring with Tire Road Hazard Protection

which provides full, or pro-rata, replacement of the original four
tires, or their repair

• Rental car allowance for same-day warranty repairs - your vehicle
need not be kept overnight before eligibility for the rental allow­ance is met

*

25

JOBNAME: 146224AspenHEV 2009 PAGE: 24 SESS: 29 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

OPTIONAL CHRYSLER CANADA SERVICE CONTRACTS

T

FEATURES AND BENEFITS

Chrysler Service Contracts also provide these additional features and
benefits:

E

NHANCED ROADSIDE ASSISTANCE

• Travel planning

• Trip interruption

C

AR RENTAL ALLOWANCE

For the duration of the plan selected, the plan covers up to $50 per day
(five days maximum), any time a covered component fails and repairs
take overnight

N

ORTHAMERICA-WIDE SERVICE

Chrysler Retailers are located throughout Canada and the Continental
United States.

RANSFERABLE AT NO COST

The unexpired portion of the plan coverage may be transferred to the
subsequent retail purchaser at no cost, within 30 days of the date of sale.
(Ask your retailer for details.)

P

OSSIBLE HIGHER RESALE VALUE

The Chrysler Service Contract may enhance the resale value of your
vehicle.

N

O COMMITMENT FOR60DAYS

The first 60 days are considered a trial period. Should you decide to
cancel within this period, you will receive full reimbursement of your
plan purchase price, less any paid claims.

26

JOBNAME: 146224AspenHEV 2009 PAGE: 25 SESS: 31 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

OPTIONAL CHRYSLER CANADA SERVICE CONTRACTS

W

HEN PLAN COVERAGE STARTS AND ENDS

All new vehicle plans commence from the warranty start date (the original
in-service date of the vehicle) and from zero metrage.

Substitute transportation coverage begins on the date the contract is
purchased, subject to acceptance by Chrysler Canada. Plan expiration is
specified in your plan provision.

E

LIGIBLE VEHICLES

Chrysler Canada vehicles which have 3/60 Basic and/or 5/100 Powertrain
Warrantyand are less than four years in service, and have accumulated less
than 80,000 kilometres, may be eligible for service contracts.

I

NELIGIBLE VEHICLES

Vehicles involved in an accident to the extent of becoming an insurance
write-off; vehicles not registered in Canada; vehicles placed in taxi,
limousine or delivery services; vehicles used to plow snow or used in
postal or dump truck services; vehicles used off-road; vehicles altered or
converted from specified original Chrysler equipment; vehicles used in
emergency services (police, ambulance, towing); and motor homes are not
eligible for a Chrysler Canada Service Contract.

Vehicles used in any competition event, pulling a trailer that exceeds the
rated capacity of the vehicle, or failing to adhere to the requirements for
vehicles used to pull a trailer as outlined in the Owner’s Manual are not
eligible.

27

JOBNAME: 146224AspenHEV 2009 PAGE: 26 SESS: 29 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty

OPTIONAL CHRYSLER CANADA SERVICE CONTRACTS

P

ERSONALIZED TERMS AND CONDITIONS WELCOME KIT

Upon receipt and acceptance of your application by Chrysler, as submitted
by your selling retailer, you will be mailed a personalized welcome letter
confirming your entitlement to the benefits of the contract you purchased,
a member’s card and the Terms and Conditions outline. This will identify
you and your vehicle to any Chrysler Retailer in Canada, or the United
States, as being eligible for plan services for the period of the terms
selected. The member’s card is to be presented to the retailer when
requesting plan services.

O

WNER’S RESPONSIBILITY

The owner’s responsibility is to properly operate, care for and maintain the
vehicle as prescribed in the Owner’s Manual supplied by Chrysler with
each new vehicle and herein.

P

LAN SERVICE/TOLL-FREE NUMBER

Plan service will be provided by the retailer who sold you the plan.
In the event that you cannot return to the selling retailer for service, you

may request plan service from any Chrysler Retailer in the United States or
Canada. If you are unable to obtain plan service from an authorized retailer,
you can call the toll-free number to receive service instructions.

Chrysler Canada stands fully behind its service contracts. Be sure that
the contract you buy is a genuine Chrysler Service Contract. We are not
responsible for other companies’ contracts.

28

JOBNAME: 146224AspenHEV 2009 PAGE: 1 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
10,000 km or 6 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

6 Months or

10,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 2 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

10,000 km or 6 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 3 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
20,000 km or 12 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty or off-road conditions;

replace if necessary.

❏ Inspect the brake linings; replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

12 Months or

20,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 4 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty

or off-road conditions; replace if necessary.

❏ Inspect the brake linings; replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

20,000 km or 12 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 5 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
30,000 km or 18 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the front and rear axle fluid; change if using your vehicle for any of the

following: police, taxi, fleet, off-road or frequent trailer towing.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

18 Months or

30,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 6 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the front and rear axle fluid; change if using your

vehicle for any of the following: police, taxi, fleet, off-road
or frequent trailer towing.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

30,000 km or 18 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 7 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
40,000 km or 24 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty or off-road conditions;

replace if necessary.

❏ Inspect the front suspension components, tie rod ends and boot seals; replace if

necessary.

❏ Inspect the brake linings; replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

24 Months or

40,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 8 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty

or off-road conditions; replace if necessary.

❏ Inspect the front suspension components, tie rod ends and

boot seals; replace if necessary.

❏ Inspect the brake linings; replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

40,000 km or 24 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 9 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
50,000 km or 30 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Replace the engine air filter.
❏ Inspect the transfer case fluid.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

30 Months or

50,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 10 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Replace the engine air filter.
❏ Inspect the transfer case fluid.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

50,000 km or 30 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 11 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
60,000 km or 36 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty or off-road conditions;

replace if necessary.

❏ Inspect the front and rear axle fluid; change if using your vehicle for any of the

following: police, taxi, fleet, off-road or frequent trailer towing.

❏ Inspect the brake linings; replace if necessary.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

36 Months or

60,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 12 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty

or off-road conditions; replace if necessary.

❏ Inspect the front and rear axle fluid; change if using your

vehicle for any of the following: police, taxi, fleet, off-road
or frequent trailer towing.

❏ Inspect the brake linings; replace if necessary.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

60,000 km or 36 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 13 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
70,000 km or 42 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

42 Months or

70,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 14 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

70,000 km or 42 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 15 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
80,000 km or 48 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty or off-road conditions;

replace if necessary.

❏ Inspect the front suspension components, tie rod ends and boot seals; replace if

necessary.

❏ Inspect the brake linings; replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

48 Months or

80,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 16 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty

or off-road conditions; replace if necessary.

❏ Inspect the front suspension components, tie rod ends and

boot seals; replace if necessary.

❏ Inspect the brake linings; replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

80,000 km or 48 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 17 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
90,000 km or 54 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the front and rear axle fluid; change if using your vehicle for any of the

following: police, taxi, fleet, off-road or frequent trailer towing.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

54 Months or

90,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 18 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the front and rear axle fluid; change if using your

vehicle for any of the following: police, taxi, fleet, off-road
or frequent trailer towing.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

90,000 km or 54 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 19 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
100,000 km or 60 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Replace the engine air filter.
❏ Inspect the transfer case fluid; change if using your vehicle for any of the following:

police, taxi, fleet or frequent trailer towing.

❏ Inspect the brake linings; replace if necessary.
❏ Flush and replace the engine coolant at 60 months if not done at 170 000 km.
❏ Change the automatic transmission fluid and filter if using your vehicle for any of

the following: police, taxi, fleet or frequent trailer towing.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

60 Months or

100,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 20 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Replace the engine air filter.
❏ Inspect the transfer case fluid; change if using your vehicle

for any of the following: police, taxi, fleet or frequent
trailer towing.

❏ Inspect the brake linings; replace if necessary.
❏ Flush and replace the engine coolant at 60 months if not

done at 170 000 km.

❏ Change the automatic transmission fluid and filter if using

your vehicle for any of the following: police, taxi, fleet or
frequent trailer towing.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

100,000 km or 60 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 21 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
110,000 km or 66 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

66 Months or

110,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 22 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

110,000 km or 66 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 23 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
120,000 km or 72 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty or off-road conditions;

replace if necessary.

❏ Inspect the front and rear axle fluid; change if using your vehicle for any of the

following: police, taxi, fleet, off-road or frequent trailer towing.

❏ Inspect the front suspension components, tie rod ends and boot seals; replace if

necessary.

❏ Inspect the brake linings; replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

72 Months or

120,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 24 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty

or off-road conditions; replace if necessary.

❏ Inspect the front and rear axle fluid; change if using your

vehicle for any of the following: police, taxi, fleet, off-road
or frequent trailer towing.

❏ Inspect the front suspension components, tie rod ends and

boot seals; replace if necessary.

❏ Inspect the brake linings; replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

120,000 km or 72 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 25 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
130,000 km or 78 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

78 Months or

130,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 26 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

130,000 km or 78 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 27 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
140,000 km or 84 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty or off-road conditions;

replace if necessary.

❏ Inspect the brake linings; replace if necessary.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

84 Months or

140,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 28 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty

or off-road conditions; replace if necessary.

❏ Inspect the brake linings; replace if necessary.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

140,000 km or 84 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 29 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
150,000 km or 90 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Replace the engine air filter.
❏ Inspect the front and rear axle fluid; change if using your vehicle for any of the

following: police, taxi, fleet, off-road or frequent trailer towing.

❏ Inspect the transfer case fluid.
❏ Inspect the PCV valve; replace if necessary.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

90 Months or

150,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 30 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Replace the engine air filter.
❏ Inspect the front and rear axle fluid; change if using your

vehicle for any of the following: police, taxi, fleet, off-road
or frequent trailer towing.

❏ Inspect the transfer case fluid.
❏ Inspect the PCV valve; replace if necessary.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

150,000 km or 90 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 31 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
160,000 km or 96 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty or off-road conditions;

replace if necessary.

❏ Inspect the front suspension components, tie rod ends and boot seals; replace if

necessary.

❏ Inspect the brake linings; replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

96 Months or

160,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 32 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty

or off-road conditions; replace if necessary.

❏ Inspect the front suspension components, tie rod ends and

boot seals; replace if necessary.

❏ Inspect the brake linings; replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

160,000 km or 96 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 33 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
170,000 km or 102 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Flush and replace the engine coolant if not done at 60 months.
❏ Flush and replace the traction power inverter module (TIPM) coolant.
❏ Replace the spark plugs.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

102 Months or

170,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 34 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Flush and replace the engine coolant if not done at

60 months.

❏ Flush and replace the traction power inverter module

(TIPM) coolant.

❏ Replace the spark plugs.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

170,000 km or 102 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 35 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
180,000 km or 108 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty or off-road conditions;

replace if necessary.

❏ Inspect the front and rear axle fluid; change if using your vehicle for any of the

following: police, taxi, fleet, off-road or frequent trailer towing.

❏ Inspect the brake linings; replace if necessary.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

108 Months or

180,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 36 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Inspect the engine air filter if using your vehicle in dusty

or off-road conditions; replace if necessary.

❏ Inspect the front and rear axle fluid; change if using your

vehicle for any of the following: police, taxi, fleet, off-road
or frequent trailer towing.

❏ Inspect the brake linings; replace if necessary.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

180,000 km or 108 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 37 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
190,000 km or 114 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

114 Months or

190,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 38 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

190,000 km or 114 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 39 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At
200,000 km or 120 Months

❏ Change the engine oil and oil filter. Under no circumstances should the oil change

interval exceed 10 000 km or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Replace the engine air filter.
❏ Inspect the front suspension components, tie rod ends and boot seals; replace if

necessary.

❏ Inspect the transfer case fluid; change if using your vehicle for any of the following:

police, taxi, fleet or frequent trailer towing.

❏ Inspect the brake linings; replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Change the automatic transmission fluid and filter.
❏ Replace the accessory drive belt(s).

* Oil changes that are prompted by the oil change indicator system prior to this

schedule maintenance interval can be recorded in the oil change log section.

Perform Maintenance

At

120 Months or

200,000 km

Odometer Reading

Date

................................................................................................

Retailer Copy

Remove and attach to Repair Order

JOBNAME: 146224AspenHEV 2009 PAGE: 40 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals

Perform Maintenance At

❏ Change the engine oil and oil filter. Under no circum-

stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*

❏ Rotate tires.
❏ Replace the engine air filter.
❏ Inspect the front suspension components, tie rod ends and

boot seals; replace if necessary.

❏ Inspect the transfer case fluid; change if using your vehicle

for any of the following: police, taxi, fleet or frequent
trailer towing.

❏ Inspect the brake linings; replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Change the automatic transmission fluid and filter.
❏ Replace the accessory drive belt(s).

* Oil changes that are prompted by the oil change indicator

system prior to this schedule maintenance interval can be
recorded in the oil change log section.

200,000 km or 120 Months

Odometer Reading

Date

Repair Order No.

CHRYSLER

RETAILER STAMP

Signature of authorized Chrysler Canada Retailer

................................................................................................
