Chrysler 300 2011 User Manual

300

O W N E R ’ S M A N U A L

2 0 1 1

VEHICLES SOLD IN CANADA

With respect to any Vehicles Sold in Canada, the name
Chrysler Group LLC shall be deemed to be deleted and
the name Chrysler Canada Inc. used in substitution
therefore.

DRIVING AND ALCOHOL

Drunken driving is one of the most frequent causes of
accidents.

Your driving ability can be seriously impaired with blood
alcohol levels far below the legal minimum. If you are
drinking, don’t drive. Ride with a designated non-drinking
driver, call a cab, a friend, or use public transportation.

WARNING!

Driving after drinking can lead to an accident. Your
perceptions are less sharp, your reflexes are slower,
and your judgment is impaired when you have been
drinking. Never drink and then drive.

This manual illustrates and describes the operation of
features and equipment that are either standard or op­tional on this vehicle. This manual may also include a
description of features and equipment that are no longer
available or were not ordered on this vehicle. Please
disregard any features and equipment described in this
manual that are not on this vehicle.

Chrysler Group LLC reserves the right to make changes
in design and specifications, and/or make additions to or
improvements to its products without imposing any
obligation upon itself to install them on products previ­ously manufactured.

Copyright © 2010 Chrysler Group LLC

SECTION PAGE

1

INTRODUCTION

2

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

3

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

4

UNDERSTANDING YOUR INSTRUMENT PANEL

5

STARTING AND OPERATING

6

WHAT TO DO IN EMERGENCIES

7

MAINTAINING YOUR VEHICLE

8

MAINTENANCE SCHEDULES

9

IF YOU NEED CONSUMER ASSISTANCE

TABLE OF CONTENTS

............................................................3

..............................9

............................. 87

..................................241

................................................299

............................................. 391

..............................................415

.................................................473

........................................ 491

1

2

3

4

5

6

7

8

9

10

INDEX

...................................................................501

10

CONTENTS

INTRODUCTION

1

䡵 Introduction ........................... 4

䡵 How To Use This Manual .................. 4

䡵 Warnings And Cautions ................... 6

䡵 Vehicle Identification Number .............. 6

䡵 Vehicle Modifications/Alterations ............ 7

4 INTRODUCTION

INTRODUCTION

Congratulations on selecting your new Chrysler Group
LLC vehicle. Be assured that it represents precision
workmanship, distinctive styling, and high quality - all
essentials that are traditional to our vehicles.

This Owner’s Manual has been prepared with the assis­tance of service and engineering specialists to acquaint
you with the operation and maintenance of your vehicle.
It is supplemented by Warranty Information, and various
customer-oriented documents. Please take the time to
read these publications carefully. Following the instruc­tions and recommendations in this manual will help
assure safe and enjoyable operation of your vehicle.

NOTE: After reviewing the owner information, it
should be stored in the vehicle for convenient referenc­ing and remain with the vehicle when sold.

When it comes to service, remember that your authorized
dealer knows your vehicle best, has factory-trained tech­nicians and genuine MOPAR威 parts, and cares about
your satisfaction.

HOW TO USE THIS MANUAL

Consult the Table of Contents to determine which section
contains the information you desire.

Since the specification of your vehicle depends on the
items of equipment ordered, certain descriptions and
illustrations may differ from your vehicle’s equipment

The detailed index at the back of this Owner’s Manual
contains a complete listing of all subjects.

Consult the following table for a description of the
symbols that may be used on your vehicle or throughout
this Owner’s Manual:

INTRODUCTION 5

1

6 INTRODUCTION

WARNINGS AND CAUTIONS

This Owner’s Manual contains WARNINGS against op-
erating procedures that could result in a collision or
bodily injury. It also contains CAUTIONS against proce­dures that could result in damage to your vehicle. If you
do not read this entire manual, you may miss important
information. Observe all Warnings and Cautions.

VEHICLE IDENTIFICATION NUMBER

The Vehicle Identification Number (VIN) is on the left
front corner of the instrument panel. The VIN is visible
from outside of the vehicle through the windshield. This
number also appears on the Automobile Information
Disclosure Label affixed to a window on your vehicle, the
vehicle registration, and the title.

VIN Location

NOTE: It is illegal to remove or alter the VIN.

VEHICLE MODIFICATIONS/ALTERATIONS

INTRODUCTION 7

WARNING!

Any modifications or alterations to this vehicle could
seriously affect its roadworthiness and safety and
may lead to a accident resulting in serious injury or
death.

1

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

CONTENTS

䡵 A Word About Your Keys ................. 12

▫ Keyless Ignition Node (Kin) .............. 12

▫ KeyFOB ........................... 13

▫ Ignition Or Accessory On Message ......... 14

䡵 Sentry Key威 .......................... 15

▫ Replacement Keys ..................... 16

▫ Customer Key Programming ............. 17

▫ General Information ................... 17

䡵 Vehicle Security Alarm — If Equipped ........ 17

2

▫ Rearming Of The System ................ 17

▫ To Arm The System ................... 18

▫ To Disarm The System ................. 18

䡵 Illuminated Entry — If Equipped ........... 19

䡵 Remote Keyless Entry (RKE) .............. 20

▫ To Unlock The Doors .................. 20

▫ To Lock The Doors .................... 21

▫ To Unlatch The Trunk .................. 22

▫ Using The Panic Alarm ................. 22

10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

▫ Programming Additional Transmitters ...... 22

▫ Wind Buffeting ....................... 38

▫ Transmitter Battery Replacement .......... 23

▫ General Information ................... 24

䡵 Remote Starting System — If Equipped ....... 24

▫ How To Use Remote Start ............... 25

䡵 Door Locks ........................... 27

▫ Manual Door Locks ................... 27

▫ Power Door Locks .................... 28

▫ Child-Protection Door Lock System — Rear

Doors ............................. 30

䡵 Keyless Enter-N-Go ..................... 31

䡵 Windows ............................ 36

▫ Power Windows ...................... 36

䡵 Trunk Lock And Release ................. 39

䡵 Trunk Safety Warning ................... 40

▫ Trunk Emergency Release ............... 40

䡵 Occupant Restraints ..................... 41

▫ Lap/Shoulder Belts .................... 44

▫ Lap/Shoulder Belt Untwisting Procedure .... 49

▫ Seat Belts In Passenger Seating Positions ..... 50

▫ Automatic Locking Retractor Mode (ALR) —

If Equipped ......................... 50

▫ Energy Management Feature ............. 51

▫ Seat Belt Pretensioner .................. 52

▫ Enhanced Seat Belt Use Reminder System

(BeltAlert威) ......................... 52

▫ Seat Belts And Pregnant Women .......... 54

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11

䡵 Safety Tips ........................... 80

▫ Seat Belt Extender ..................... 54

▫ Supplemental Restraint System (SRS) —

Airbags ............................ 54

▫ Airbag Deployment Sensors And Controls . . . 61

▫ Event Data Recorder (EDR) .............. 68

▫ Child Restraints ...................... 69

䡵 Engine Break-In Recommendations .......... 80

▫ Transporting Passengers ................ 80

▫ Exhaust Gas ......................... 81

▫ Safety Checks You Should Make Inside The

Vehicle ............................. 82

▫ Periodic Safety Checks You Should Make

Outside The Vehicle ................... 84

2

12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

A WORD ABOUT YOUR KEYS

Your vehicle uses a keyless ignition system. This system
consists of a Key Fob with Remote Keyless Entry (RKE)
transmitter and a Keyless Ignition Node (KIN).

Keyless Enter-N-Go Feature

This vehicle is equipped with the Keyless Enter-N-Go
feature, refer to “Starting Procedure” in “Starting And
Operating” for further information.

Keyless Ignition Node (KIN)

This feature allows the driver to operate the ignition
switch with the push of a button, as long as the Remote
Keyless Entry (RKE) transmitter is in the passenger
compartment.

The Keyless Ignition Node (KIN) has four operating
positions, three of which are labeled and will illuminate
when in position. The three positions are OFF, ACC, and
ON/RUN. The fourth position is START, during start
RUN will illuminate.

NOTE: In case the ignition switch does not change with
the push of a button, the RKE transmitter (Key Fob) may
have a low or dead battery. In this situation a back up
method can be used to operate the ignition switch. Put
the nose side (side opposite of the emergency key) of the
Key Fob against the ENGINE START/STOP button and
push to operate the ignition switch.

Keyless Ignition Node (KIN)

1 — OFF
2 — ACC (ACCESSORY)
3 — ON/RUN

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13

Key Fob

The Key Fob also contains the Remote Keyless Entry
(RKE) transmitter and an emergency key, which stores in
the rear of the Key Fob.

The emergency key allows for entry into the vehicle
should the battery in the vehicle or the Key Fob go dead.
The emergency key is also for locking the glove box. You
can keep the emergency key with you when valet park­ing.

2

14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To remove the emergency key, slide the mechanical latch
on the back of the Key Fob sideways with your thumb
and then pull the key out with your other hand.

Emergency Key Removal

NOTE: You can insert the double-sided emergency key

into the lock cylinders with either side up.

Ignition Or Accessory On Message

Opening the driver’s door when the ignition is in ACC or
ON (engine not running), a chime will sound to remind
you to cycle the ignition to OFF. In addition to the chime,
the ignition or accessory on message will display in the
cluster.

NOTE: With the Uconnect Touch™ system, the power
window switches, radio, power sunroof (if equipped),
and power outlets will remain active for up to 10 minutes
after the ignition is cycled to the OFF position. Opening
either front door will cancel this feature. The time for this
feature is programmable. Refer to “Uconnect Touch™
Settings” in “Understanding Your Instrument Panel” for
further information.

WARNING!

•

Never leave children alone in a vehicle. Leaving
unattended children in a vehicle is dangerous for a
number of reasons. A child or others could be
seriously or fatally injured. Do not leave the
ignition in the ACC or RUN position. A child
could operate power windows, other controls, or
move the vehicle.

•

Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build-up may
cause serious injury or death.

CAUTION!

An unlocked car is an invitation to thieves. Always
remove the Key Fob from vehicle, cycle the ignition
OFF and lock all doors when leaving the vehicle
unattended.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15

SENTRY KEY姞

The Sentry Key威 Immobilizer system prevents unauthor­ized vehicle operation by disabling the engine. The
system does not need to be armed or activated. Operation
is automatic, regardless of whether the vehicle is locked
or unlocked.

The system uses a Key Fob with Remote Keyless Entry
(RKE) transmitter, a Keyless Ignition Node (KIN) and a
RF receiver to prevent unauthorized vehicle operation.
Therefore, only Key Fobs that are programmed to the
vehicle can be used to start and operate the vehicle.

After cycling the ignition switch to the ON/RUN posi­tion, the Vehicle Security Light will turn on for three
seconds for a bulb check. If the light remains on after the
bulb check, it indicates that there is a problem with the
electronics. In addition, if the light begins to flash after
the bulb check, it indicates that someone used an invalid

2

16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Key Fob to start the engine. Either of these conditions will
result in the engine being shut off after two seconds.

If the Vehicle Security Light turns on during normal
vehicle operation (vehicle running for longer than 10 sec­onds), it indicates that there is a fault in the electronics.
Should this occur, have the vehicle serviced as soon as
possible by an authorized dealer.

Replacement Keys

NOTE: Only Key Fobs that are programmed to the
vehicle electronics can be used to start and operate the
vehicle. Once a Key Fob is programmed to a vehicle, it
cannot be programmed to any other vehicle.

CAUTION!

CAUTION!

The Sentry Key威 Immobilizer system is not compat­ible with some after-market remote starting systems.
Use of these systems may result in vehicle starting
problems and loss of security protection.

All of the Key Fobs provided with your new vehicle have
been programmed to the vehicle electronics.

Always remove the keys from the vehicle and lock all
doors when leaving the vehicle unattended.

At the time of purchase, the original owner is provided
with a four-digit Personal Identification Number (PIN).
Keep the PIN in a secure location. This number is
required for authorized dealer replacement of Key Fobs.
Duplication of Key Fobs may be performed at an autho­rized dealer, this procedure consists of programming a
blank Key Fob to the vehicle electronics. A blank Key Fob
is one that has never been programmed.

NOTE: When having the Sentry Key威 Immobilizer
system serviced, bring all vehicle Key Fobs with you to
an authorized dealer.

Customer Key Programming

Programming Key Fobs or RKE transmitters may be
performed at an authorized dealer.

General Information

The Sentry Key威 system complies with FCC rules Part 15
and with RSS-210 of Industry Canada. Operation is
subject to the following conditions:

•

This device may not cause harmful interference.

•

This device must accept any interference that may be
received, including interference that may cause unde­sired operation.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17

VEHICLE SECURITY ALARM — IF EQUIPPED

The Vehicle Security Alarm monitors the vehicle doors
for unauthorized entry and the Keyless Enter-N-Go
Start/Stop button for unauthorized operation. While the
Vehicle Security Alarm is armed, interior switches for
door locks and decklid release are disabled. If something
triggers the alarm, the Vehicle Security Alarm will pro­vide the following audible and visible signals: the horn
will pulse, the headlights, park lamps and/or turn sig­nals will flash, and the Vehicle Security Light in the
instrument cluster will flash.

Rearming Of The System

If something triggers the alarm, and no action is taken to
disarm it, the Vehicle Security Alarm will turn the horn
off after three minutes, turn all of the visual signals off
after 15 additional minutes, and then the Vehicle Security
Alarm will rearm itself.

2

18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To Arm The System

Press the Keyless Enter-N-Go Start/Stop button until the
Electronic Vehicle Information Center (EVIC) indicates
that the vehicle ignition is ⬙OFF⬙ (refer to “Starting
Procedures” in “Starting And Operating” for further
information). Then either press the power door LOCK
switch while the driver or passenger door is open, press
the Remote Keyless Entry (RKE) transmitter LOCK but­ton or press the Passive Entry Door Handle LOCK button
(refer to “Keyless Enter-N-Go” in “Things To Know
Before Starting Your Vehicle” for further information).

To Disarm The System

Either press the UNLOCK button on the RKE transmitter
or grasp the Passive Entry Unlock Door Handle (refer to
“Keyless Enter-N-Go” in “Things To Know Before Start­ing Your Vehicle” for further information), press the
Keyless Enter-N-Go Start/Stop button (requires at least
one valid Key Fob in the vehicle).

NOTE:

•

The Vehicle Security Alarm remains armed during
trunk entry. Pressing the RKE transmitter or Passive
Entry TRUNK button will not disarm the Vehicle
Security Alarm. If someone enters the vehicle through
the trunk, and opens any door, the alarm will sound.

•

When the Vehicle Security Alarm is armed, the interior
power door lock switches will not unlock the doors.

The Vehicle Security Alarm is designed to protect your
vehicle; however, you can create conditions where the
Vehicle Security Alarm will give you a false alarm. If one
of the previously-described arming sequences has oc­curred, the Vehicle Security Alarm will arm regardless of
whether you are in the vehicle or not. If you remain in the
vehicle and open a door, the alarm will sound. If this
occurs, disarm the Vehicle Security Alarm.

If the Vehicle Security Alarm is armed and the battery
becomes disconnected the Vehicle Security Alarm will
remain armed when the battery is reconnected. The
exterior lights will flash, the horn will sound, and the
ignition will not start the vehicle. If this occurs, disarm
the Vehicle Security Alarm.

Tamper Alert

If something has triggered the Vehicle Security Alarm in
your absence, the horn will sound three times when you
disarm the Vehicle Security Alarm. Check the vehicle for
tampering.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19

ILLUMINATED ENTRY — IF EQUIPPED

The courtesy lights will turn on when you use the
Remote Keyless Entry (RKE) transmitter or unlock any
door.

This feature also turns on the approach lighting in the
outside mirrors (if equipped). Refer to “Mirrors” in
“Understanding The Features Of Your Vehicle” for fur­ther information.

The lights will fade to off after approximately 30 seconds
or they will immediately fade to off once the ignition
switch is cycled from the OFF position.

NOTE: None of the courtesy lights will operate if the
dimmer control is in the “defeat” position (extreme
downward position), unless the overhead map/reading
lights are turned on manually.

2

20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

REMOTE KEYLESS ENTRY (RKE)

The RKE system allows you to lock or unlock the doors,
open the trunk, or activate the Panic Alarm from dis­tances up to approximately 66 ft (20 m) using a hand-held
Key Fob with RKE transmitter. The RKE transmitter does
not need to be pointed at the vehicle to activate the
system.

NOTE: Driving at speeds 5 mph (8 km/h) and above
disables the system from responding to all RKE transmit­ter buttons for all RKE transmitters.

Key Fob With RKE Transmitter

To Unlock The Doors

Press and release the UNLOCK button on the RKE
transmitter once to unlock the driver’s door or twice
within five seconds to unlock all doors. The turn signal
lights will flash to acknowledge the unlock signal. The
illuminated entry system will also turn on.

If the vehicle is equipped with Passive Entry, refer to
“Keyless Enter-N-Go” under “Things To Know Before
Starting Your Vehicle” for further information.

Remote Key Unlock, Driver Door/All Doors 1st
Press

This feature lets you program the system to unlock either
the driver’s door or all doors on the first press of the
UNLOCK button on the RKE transmitter. To change the
current setting, refer to “Uconnect Touch™ Settings” in
“Understanding Your Instrument Panel” for further
information.

Flash Lights With Remote Key Lock

This feature will cause the turn signal lights to flash when
the doors are locked or unlocked with the RKE transmit­ter. This feature can be turned on or turned off. To change
the current setting, refer to “Uconnect Touch™ Settings”
in “Understanding Your Instrument Panel” for further
information.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21

Turn Headlights On With Remote Key Unlock

This feature activates the headlights for up to 90 seconds
when the doors are unlocked with the RKE transmitter.
The time for this feature is programmable on vehicles
equipped through Uconnect Touch™. To change the
current setting, refer to “Uconnect Touch™ Settings” in
“Understanding Your Instrument Panel” for further
information.

To Lock The Doors

Press and release the LOCK button on the RKE transmit­ter to lock all doors. The turn signal lights will flash and
the horn will chirp to acknowledge the signal.

If the vehicle is equipped with Passive Entry, refer to
“Keyless Enter-N-Go” under “Things To Know Before
Starting Your Vehicle” for further information.

Sound Horn With Remote Key Lock

This feature will cause the horn to chirp when the doors
are locked with the RKE transmitter. This feature can be

2

22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

turned on or turned off. To change the current setting,
refer to “Uconnect Touch™ Settings” in “Understanding
Your Instrument Panel” for further information.

To Unlatch The Trunk

Press the TRUNK button on the RKE transmitter two
times within five seconds to unlatch the trunk.

If the vehicle is equipped with Passive Entry, refer to
“Keyless Enter-N-Go” under “Things To Know Before
Starting Your Vehicle” for further information.

Using The Panic Alarm

To turn the Panic Alarm feature on or off, press and hold
the PANIC button on the RKE transmitter for at least one
second and release. When the Panic Alarm is on, the
headlights and park lights will flash, the horn will pulse
on and off, and the interior lights will turn on.

The Panic Alarm will stay on for three minutes unless
you turn it off by either pressing the PANIC button a
second time or drive the vehicle at a speed of 15 mph
(24 km/h) or greater.

NOTE:

•

The interior lights will turn off if you cycle the ignition
switch to the ACC or ON/RUN position while the
Panic Alarm is activated. However, the exterior lights
and horn will remain on.

•

You may need to be less than 35 ft (11 m) from the
vehicle when using the RKE transmitter to turn off the
Panic Alarm due to the radio frequency noises emitted
by the system.

Programming Additional Transmitters

Programming Key Fobs or RKE transmitters may be
performed at an authorized dealer.

Transmitter Battery Replacement

The recommended replacement battery is one CR2032
battery.

NOTE:

•

Perchlorate Material — special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate

•

Do not touch the battery terminals that are on the back
housing or the printed circuit board.

1. Remove the emergency key by sliding the mechanical
latch on the back of the RKE transmitter sideways with
your thumb and then pull the key out with your other
hand.

2. Insert the tip of the emergency key or a #2 flat blade
screwdriver into the slot and gently pry the two halves of
the RKE transmitter apart. Make sure not to damage the
seal during removal.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23

2

3. Remove the battery by turning the back cover over
(battery facing downward) and tapping it lightly on a
solid surface such as a table or similar, then replace the
battery. When replacing the battery, match the + sign on
the battery to the + sign on the inside of the battery clip,
located on the back cover. Avoid touching the new

24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

battery with your fingers. Skin oils may cause battery
deterioration. If you touch a battery, clean it with rubbing
alcohol.

4. To assemble the RKE transmitter case, snap the two
halves together.

General Information

This device complies with Part 15 of the FCC rules and
RSS 210 of Industry Canada. Operation is subject to the
following conditions:

•

This device may not cause harmful interference.

•

This device must accept any interference received,
including interference that may cause undesired
operation.

NOTE: Changes or modifications not expressly ap­proved by the party responsible for compliance could
void the user’s authority to operate the equipment.

If your RKE transmitter fails to operate from a normal
distance, check for these two conditions:

1. A weak battery in the RKE transmitter. The expected
life of the battery is a minimum of three years.

2. Closeness to a radio transmitter such as a radio station
tower, airport transmitter, and some mobile or CB radios.

REMOTE STARTING SYSTEM — IF EQUIPPED

This system uses the Key Fob Remote Keyless
Entry (RKE) transmitter to start the engine
conveniently from outside the vehicle while
still maintaining security. The system has a

range of approximately 300 ft (91 m).

NOTE:

•

The vehicle must be equipped with an automatic
transmission to be equipped with Remote Start.

•

Obstructions between the vehicle and the Key Fob
may reduce this range.

How To Use Remote Start

All of the following conditions must be met before the
engine will remote start:

•

Shift lever in PARK

•

Doors closed

•

Hood closed

•

Trunk closed

•

HAZARD switch off

•

BRAKE switch inactive (brake pedal not pressed)

•

Battery at an acceptable charge level

•

RKE PANIC button not pressed.

•

System not disabled from previous remote start event

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25

•

Vehicle theft alarm not active

•

Ignition in OFF state

WARNING!

•

Do not start or run an engine in a closed garage or
confined area. Exhaust gas contains Carbon Mon­oxide (CO) which is odorless and colorless. Car­bon Monoxide is poisonous and can cause serious
injury or death when inhaled.

•

Keep Remote Keyless Entry (RKE) transmitters
away from children. Operation of the Remote Start
System, windows, door locks or other controls
could cause serious injury or death.

2

26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Remote Start Abort Message On Electronic Vehicle
Information Center (EVIC) — If Equipped

The following messages will display in the EVIC if the
vehicle fails to remote start or exits remote start prema­turely:

•

Remote Start Aborted — Door Ajar

•

Remote Start Aborted — Hood Ajar

•

Remote Start Aborted — Fuel Low

•

Remote Start Disabled — Start Vehicle to Reset

The EVIC message stays active until the ignition is cycled
to the ON/RUN position.

To Enter Remote Start Mode

Press and release the REMOTE START button
on the RKE transmitter twice, within five sec­onds. The vehicle doors will lock, parking
lights will flash and the horn will chirp twice (if

programmed). Then, the engine will start and the vehicle
will remain in the Remote Start mode for a 15-minute
cycle.

NOTE:

•

If an engine fault is present or fuel level is low, the
vehicle will start and then shutdown in 10 seconds.

•

The park lamps will turn on and remain on during
Remote Start mode.

•

For security, power window and power sunroof op­eration (if equipped) are disabled when the vehicle is
in the Remote Start mode.

•

The engine can be started two consecutive times (two
15-minute cycles) with the RKE transmitter. However,
the ignition must be cycled to the RUN position before
you can repeat the start sequence for a third cycle.

To Exit Remote Start Mode Without Driving The
Vehicle

Press and release the REMOTE START button one time or
allow the engine to run for the entire 15 minute cycle.

NOTE: To avoid unintentional shutdowns, the system
will disable the one time press of the REMOTE START
button for two seconds after receiving a valid Remote
Start request.

To Exit Remote Start Mode And Drive The Vehicle

Before the end of 15 minute cycle, press and release the
UNLOCK button on the RKE transmitter to unlock the
doors and disarm the Vehicle Security Alarm (if
equipped). Then, prior to the end of the 15 minute cycle,
press and release the START/STOP button.

NOTE: The message “Push Start Button” will display in
the EVIC until you push the START button.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27

DOOR LOCKS
Manual Door Locks

To lock each door, push the door lock knob on each door
trim panel downward. To unlock each door, pull the door
lock knob on each door trim panel upward.

Door Lock Knob

2

28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

If the door lock knob is down when you shut the door,
the door will lock. Therefore, make sure the key is not
inside the vehicle before closing the door.

WARNING!

•

For personal security and safety in the event of an
accident, lock the vehicle doors before you drive as
well as when you park and leave the vehicle.

•

When leaving the vehicle, always remove the key
from the ignition and lock your vehicle. Unsuper­vised use of vehicle equipment may cause severe
personal injuries or death.

•

Never leave children alone in a vehicle. Leaving
unattended children in a vehicle is dangerous for a
number of reasons. A child or others could be
seriously or fatally injured. Don’t leave the key in
the ignition. A child could operate power win­dows, other controls, or move the vehicle.

Power Door Locks

A power door lock switch is on each front door trim
panel. Use this switch to lock or unlock the doors.

Power Door Lock Switch

The doors can also be locked and unlocked with the
Keyless Enter-N-Go (Passive Entry) system. For further
information, refer to “Keyless Enter-N-Go” in “Things To
Know Before Starting Your Vehicle”.

If you press the power door lock switch while the Key
Fob is in the vehicle, and any front door is open, the
power locks will not operate. This prevents you from
accidentally locking the Key Fob in the vehicle. Remov­ing the Key Fob or closing the door will allow the locks to
operate.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29

NOTE: Use the Automatic Door Locks feature in accor­dance with local laws.

Automatic Unlock Doors On Exit

The doors will unlock automatically on vehicles with
power door locks if:

1. The Automatic Unlock Doors On Exit feature is en­abled.

2. The transmission was in gear and the vehicle speed
returned to 0 mph (0 km/h).

2

Automatic Door Locks

The doors will lock automatically on vehicles with power
door locks if the vehicle speed is above 15 mph
(24 km/h).

The Auto Door Lock feature can be enabled or disabled
by your authorized dealer. See your authorized dealer for
service.

3. The transmission is in NEUTRAL or PARK.

4. The driver door is opened.

5. The doors were not previously unlocked.

6. The vehicle speed is 0 mph (0 km/h).

30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To change the current setting, refer to “Uconnect Touch™
Settings” in “Understanding Your Instrument Panel” for
further information.

NOTE: Use theAutomatic Unlock Doors On Exit feature
in accordance with local laws.

Child-Protection Door Lock System — Rear Doors

To provide a safer environment for small children riding
in the rear seats, the rear doors are equipped with
Child-Protection Door Lock system.

To engage or disengage the Child-Protection Door
Lock system

1. Open the rear door.

2. Insert the tip of the emergency key into the lock and
rotate to the LOCK or UNLOCK position.

3. Repeat steps 1 and 2 for the opposite rear door.

Child-Protection Door Lock Location

Child-Protection Door Lock Function

WARNING!

Avoid trapping anyone in a vehicle in a collision.
Remember that the rear doors can only be opened
from the outside when the Child-Protection locks are
engaged (locked).

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31

NOTE: For emergency exit from the rear seats when the
Child-Protection Door Lock System is engaged, manually
raise the door lock knob to the unlocked position, roll
down the window, and open the door using the outside
door handle.

KEYLESS ENTER-N-GO

The Passive Entry system is an enhancement to the
vehicle’s Remote Keyless Entry (RKE) system and a
feature of Keyless Enter-N-Go. This feature allows you to
lock and unlock the vehicle’s door(s) without having to
press the RKE transmitter lock or unlock buttons.

NOTE:

•

Passive Entry may be programmed ON/OFF, refer to
“Uconnect Touch™ Settings” in “Understanding Your
Instrument Panel” for further information.

•

If a passive entry door handle has not been used for
72 hours, the passive entry feature for the handle may

2

32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

time out. Pulling the deactivated front door handle
will reactivate the door handle’s passive entry feature.

•

If wearing gloves on your hands, or if it has been
raining on the passive entry door handle, the unlock
sensitivity can be affected, resulting in a slower re­sponse time.

•

If you unlock the doors using the passive entry door
handles, but do NOT pull the handle, the doors will
automatically lock after 60 seconds.

To Unlock From The Driver’s Side:

With a valid Passive Entry RKE transmitter within 5 ft
(1.5 m) of the driver’s door handle, grab the front driver
door handle to unlock the driver’s door automatically.
The interior door panel lock knob will raise when the
door is unlocked.

Grabbing The Driver’s Door Handle

NOTE: If “Unlock All Doors 1st Press” is programmed

all doors will unlock when you grab hold of the front
driver’s door handle. To select between “Unlock Driver
Door 1st Press” and “Unlock All Doors 1st Press”, refer to
“Uconnect Touch™ Settings” in “Understanding Your
Instrument Panel” for further information.

To Unlock From The Passenger Side:

With a valid Passive Entry RKE transmitter within 5 ft
(1.5 m) of the passenger door handle, grab the front
passenger door handle to unlock all four doors automati­cally. The interior door panel lock knob will raise when
the door is unlocked.

NOTE: All doors will unlock when the front passenger
door handle is grabbed regardless of the driver ’s door
unlock preference setting (“Unlock Driver Door 1st
Press” or “Unlock All Doors 1st Press”).

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33

Preventing Inadvertent Locking Of Passive Entry RKE
Transmitter In Vehicle

To minimize the possibility of unintentionally locking a
Passive Entry RKE transmitter inside your vehicle, the
Passive Entry system is equipped with an automatic door
unlock feature which will function if there is no Key Fob
present in the vehicle.

If one of the vehicle doors is open and the door panel
switch is used to lock the vehicle, once all open doors
have been closed, the vehicle checks the inside and
outside of the vehicle for any valid Passive Entry RKE
transmitters. If one of the vehicle’s Passive Entry RKE
transmitters is detected inside the vehicle, and no other
valid Passive Entry RKE transmitters is detected outside
the vehicle, the Passive Entry System automatically un­locks all vehicle doors and chirps the horn three times (on
the third attempt ALL doors will lock and the Passive
Entry RKE transmitter can be locked in the vehicle).

2

34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To Enter The Trunk

With a valid Passive Entry RKE transmitter within 3 ft
(1.0 m) of the deck lid, press the button on the left side of
CHMSL, (Center High Mounted Stop Light) which is
located on the deck lid.

Trunk Passive Entry Button

NOTE: If you inadvertently leave your vehicle’s Passive

Entry RKE transmitter in the trunk and try to close the
deck lid, the deck lid will automatically unlatch, unless
another one of the vehicle’s Passive Entry RKE transmit­ters is outside the vehicle and within 3 ft (1.0 m) of the
deck lid.

To Lock The Vehicle’s Doors

With one of the vehicle’s Passive Entry RKE transmitters
within 5 ft (1.5 m) of the driver or passenger front door
handles, press the door handle LOCK button to lock all
four doors.

Outside Door Handle Lock Button

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35

NOTE:

•

After pressing the door handle LOCK button, you
must wait two seconds before you can lock or unlock
the doors, using either passive entry door handle. This
is done to allow you to check if the vehicle is locked by
pulling the door handle, without the vehicle reacting
and unlocking.

•

The passive entry system will not operate if the RKE
transmitter battery is dead.

The vehicle doors can also be locked by using the RKE
transmitter lock button or the lock button located on the
vehicle’s interior door panel.

2

36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WINDOWS
Power Windows

The window controls on the driver’s door control all the
door windows.

Power Window Switches

There are single window controls on each passenger door
trim panel, which operate the passenger door windows.
The window controls will operate only when the ignition
is in the ACC or ON/RUN position.

NOTE: For vehicles equipped with the Uconnect
Touch™, the power window switches will remain active
for up to 10 minutes after the ignition switch is cycled to
the OFF position. Opening either front door will cancel
this feature. The time is programmable. Refer to
“Uconnect Touch™ Settings” in “Understanding Your
Instrument Panel” for further information.

WARNING!

Never leave children in a vehicle with the Key Fob.
Occupants, particularly unattended children, can be­come entrapped by the windows while operating the
power window switches. Such entrapment may re­sult in serious injury or death.

AUTO-Down Feature

The driver door power window switch and some model
passenger door power window switches have an AUTO­down feature. Press the window switch to the second
detent, release, and the window will go down automati­cally.

To open the window part way, press the window switch
to the first detent and release it when you want the
window to stop.

To stop the window from going all the way down during
the AUTO-down operation, pull up on the switch briefly.

AUTO-Up Feature With Anti-Pinch Protection — If
Equipped

Lift the window switch to the second detent, release, and
the window will go up automatically.

To stop the window from going all the way up during the
AUTO-up operation, push down on the switch briefly.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37

To close the window part way, lift the window switch to
the first detent and release it when you want the window
to stop.

NOTE:

•

If the window runs into any obstacle during auto­closure, it will reverse direction and then go back
down. Remove the obstacle and use the window
switch again to close the window.

•

Any impact due to rough road conditions may trigger
the auto-reverse function unexpectedly during auto­closure. If this happens, pull the switch lightly to the
first detent and hold to close the window manually.

WARNING!

There is no anti-pinch protection when the window
is almost closed. Be sure to clear all objects from the
window before closing.

2

38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Reset Auto Up

Should the Auto Up feature stop working, the window
probably needs to be reset. To reset Auto Up:

1. Pull the window switch up to close the window
completely and continue to hold the switch up for an
additional two seconds after the window is closed.

2. Push the window switch down firmly to the second
detent to open the window completely and continue to
hold the switch down for an additional two seconds after
the window is fully open.

Window Lockout Switch

The window lockout switch on the driver’s door trim
panel allows you to disable the window controls on the
passenger doors. To disable the window controls, press
and release the window lockout button (setting it in the
DOWN position). To enable the window controls, press
and release the window lockout button again (setting it in
the UP position).

Window Lockout Switch

Wind Buffeting

Wind buffeting can be described as the perception of
pressure on the ears or a helicopter-type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down, or the sunroof (if equipped) in certain

open or partially open positions. This is a normal occur­rence and can be minimized. If the buffeting occurs with
the rear windows open, then open the front and rear
windows together to minimize the buffeting. If the
buffeting occurs with the sunroof open, then adjust the
sunroof opening to minimize the buffeting.

TRUNK LOCK AND RELEASE

The trunk lid can be released from inside the vehicle by
pressing the TRUNK RELEASE button located on the
instrument panel to the left of the steering wheel.

NOTE: The transmission must be in PARK before the
button will operate.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39

The trunk lid can be released from
outside the vehicle by pressing the
TRUNK button on the Remote
Keyless Entry (RKE) transmitter
twice within five seconds.

Trunk Release

Button

With the ignition switch in the ON/RUN position, the
Trunk Open symbol will display in the instrument cluster
indicating that the trunk is open. The odometer display
will reappear once the trunk is closed.

With the ignition switch in the OFF position or the key
removed from the ignition switch, the Trunk Open sym­bol will display until the trunk is closed.

2

40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Refer to “Keyless Enter-N-Go” in “Things To Know
Before Starting Your Vehicle” for more information on
trunk operation with the Passive Entry feature.

TRUNK SAFETY WARNING

WARNING!

Do not allow children to have access to the trunk,
either by climbing into the trunk from outside, or
through the inside of the vehicle. Always close the
trunk lid when your vehicle is unattended. Once in
the trunk, young children may not be able to escape,
even if they entered through the rear seat. If trapped
in the trunk, children can die from suffocation or
heat stroke.

Trunk Emergency Release

The trunk of your vehicle is equipped with an emergency
release handle. It is located on the inside of the trunk lid,
near the latch, and is coated so that it glows in a darkened
trunk. Pull on the handle to open the trunk.

Trunk Emergency Release

OCCUPANT RESTRAINTS

Some of the most important safety features in your
vehicle are the restraint systems:

•

Three-point lap and shoulder belts for the driver and
all passengers

•

Advanced Front Airbags for driver and front passen­ger

•

Supplemental Driver Side Knee Airbag

•

Supplemental Side Airbag Inflatable Curtains (SABIC)
for the driver and passengers seated next to a window

•

Supplemental Seat-Mounted Side Airbags (SAB)

•

An energy-absorbing steering column and steering
wheel

•

Knee bolsters/blockers for front seat occupants

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41

•

Front seat belts incorporate pretensioners that may
enhance occupant protection by managing occupant
energy during an impact event

Please pay close attention to the information in this
section. It tells you how to use your restraint system
properly, to keep you and your passengers as safe as
possible.

If you will be carrying children too small for adult-sized
seat belts, the seat belts or the Lower Anchors and Tether
for CHildren (LATCH) feature also can be used to hold
infant and child restraint systems. For more information
on LATCH, see Lower Anchors and Tether for CHildren
(LATCH).

Here are some simple steps you can take to minimize the
risk of harm from a deploying airbag:

1. Children 12 years old and under should always ride

buckled up in a rear seat.

2

42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!

Infants in rear facing child restraints should never
ride in the front seat of a vehicle with a passenger
Advanced Front Airbag. An airbag deployment can
cause severe injury or death to infants in that posi­tion.

Children that are not big enough to wear the vehicle seat
belt properly (see section on Child Restraints) should be
secured in the rear seat in child restraints or belt­positioning booster seats. Older children who do not use
child restraints or belt-positioning booster seats should
ride properly buckled up in the rear seat. Never allow
children to slide the shoulder belt behind them or under
their arm.

If a child from 1 to 12 years old (not in a rear facing child
seat) must ride in the front passenger seat, move the seat
as far back as possible and use the proper child restraint.
(Refer to “Child Restraints”)

You should read the instructions provided with your
child restraint to make sure that you are using it properly.

2. All occupants should always wear their lap and

shoulder belts properly.

3. The driver and front passenger seats should be
moved back as far as practical to allow the Advanced
Front Airbags room to inflate.

4. Do not lean against the door or window. Your vehicle
has Supplemental Side Airbag Inflatable Curtains
(SABIC) or Supplemental Seat-Mounted Side Airbags
(SAB), and deployment occurs, the SABIC and SAB
airbags will inflate forcefully into the space between
you and the door.

5. If the airbag system in this vehicle needs to be
modified to accommodate a disabled person, contact
the Customer Center. Phone numbers are provided
under ⴖIf You Need Assistanceⴖ.

WARNING!

•

Relying on the airbags alone could lead to more
severe injuries in a collision. The airbags work
with your seat belt to restrain you properly. In
some collisions, the airbags won’t deploy at all.
Always wear your seat belts even though you have
airbags.

(Continued)

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43

WARNING! (Continued)

•

Being too close to the steering wheel or instrument
panel during Advanced Front Airbag deployment
could cause serious injury, including death. Air­bags need room to inflate. Sit back, comfortably
extending your arms to reach the steering wheel or
instrument panel.

•

Supplemental Side Airbag Inflatable Curtain
(SABIC) and Seat-Mounted Side Airbags (SAB)
also need room to inflate. Do not lean against the
door or window. Sit upright in the center of the
seat.

•

In an accident, you and your passengers can suffer
much greater injuries if you are not properly
buckled up. You can strike the interior of your
vehicle or other passengers, or you can be thrown
out of the vehicle. Always be sure you and others
in your vehicle are buckled up properly.

2

44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Buckle up even though you are an excellent driver, even
on short trips. Someone on the road may be a poor driver
and cause an accident that includes you. This can happen
far away from home or on your own street.

Research has shown that seat belts save lives, and they
can reduce the seriousness of injuries in an accident.
Some of the worst injuries happen when people are
thrown from the vehicle. Seat belts reduce the possibility
of ejection and the risk of injury caused by striking the
inside of the vehicle. Everyone in a motor vehicle should
be belted at all times.

Lap/Shoulder Belts

All seating positions in your vehicle are equipped with
lap/shoulder belts.

The belt webbing retractor is designed to lock during
very sudden stops or impacts. This feature allows the
shoulder part of the belt to move freely with you under

normal conditions. However, in an accident, the belt will
lock and reduce your risk of striking the inside of the
vehicle or being thrown out.

WARNING!

•

Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat
belts.

•

Be sure everyone in your vehicle is in a seat and
using a seat belt properly.

•

Wearing a seat belt incorrectly is dangerous. Seat
belts are designed to go around the large bones of
your body. These are the strongest parts of your
body and can take the forces of an accident best.

(Continued)

WARNING! (Continued)

•

Wearing your belt in the wrong place could make
your injuries in an accident much worse. You
might suffer internal injuries, or you could even
slide out of part of the belt. Follow these instruc­tions to wear your seat belt safely and to keep your
passengers safe, too.

•

Two people should never be belted into a single
seat belt. People belted together can crash into one
another in an accident, hurting one another badly.
Never use a lap/shoulder belt or a lap belt for more
than one person, no matter what their size.

Lap/Shoulder Belt Operating Instructions

1. Enter the vehicle and close the door. Sit back and
adjust the front seat.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45

2

Pulling Out the Lap/Shoulder Belt Latch Plate

2. The seat belt latch plate is above the back of your seat.
Grasp the latch plate and pull out the belt. Slide the latch
plate up the webbing as far as necessary to make the belt
go around your lap.

46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

3. When the belt is long enough to fit, insert the latch
plate into the buckle until you hear a “click.”

Inserting Latch Plate Into Buckle

WARNING!

•

A belt that is buckled into the wrong buckle will
not protect you properly. The lap portion could
ride too high on your body, possibly causing
internal injuries. Always buckle your belt into the
buckle nearest you.

•

A belt that is too loose will not protect you
properly. In a sudden stop, you could move too far
forward, increasing the possibility of injury. Wear
your seat belt snugly.

(Continued)

WARNING! (Continued)

•

A belt that is worn under your arm is dangerous.
Your body could strike the inside surfaces of the
vehicle in an accident, increasing head and neck
injury. A belt worn under the arm can cause
internal injuries. Ribs aren’t as strong as shoulder
bones. Wear the belt over your shoulder so that
your strongest bones will take the force in a
collision.

•

A shoulder belt placed behind you will not protect
you from injury during an accident. You are more
likely to hit your head in a collision if you do not
wear your shoulder belt. The lap and shoulder belt
are meant to be used together.

4. Position the lap belt across your thighs, below your
abdomen. To remove slack in the lap belt portion, pull up
a bit on the shoulder belt. To loosen the lap belt if it is too

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47

tight, tilt the latch plate and pull on the lap belt. A snug
belt reduces the risk of sliding under the belt in an
accident.

2

Removing Slack from Belt

48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!

•

A lap belt worn too high can increase the risk of
internal injury in an accident. The belt forces
won’t be at the strong hip and pelvic bones, but
across your abdomen. Always wear the lap belt as
low as possible and keep it snug.

•

A twisted belt will not protect you properly. In a
collision, it could even cut into you. Be sure the
belt is straight. If you can’t straighten a belt in
your vehicle, take it to your authorized dealer
immediately and have it fixed.

5. Position the shoulder belt on your chest so that it is
comfortable and not resting on your neck. The retractor
will withdraw any slack in the belt.

6. To release the belt, push the red button on the buckle.
The belt will automatically retract to its stowed position.
If necessary, slide the latch plate down the webbing to
allow the belt to retract fully.

WARNING!

A frayed or torn belt could rip apart in an accident
and leave you with no protection. Inspect the belt
system periodically, checking for cuts, frays, or loose
parts. Damaged parts must be replaced immediately.
Do not disassemble or modify the system. Seat belt
assemblies must be replaced after an accident if they
have been damaged (bent retractor, torn webbing,
etc.).

Adjustable Upper Shoulder Belt Anchorage

In the driver and front passenger seats, the shoulder belt
can be adjusted upward or downward to position the belt
away from your neck. Push and fully depress the button

above the webbing to release the anchorage, then move it
up or down to the position that fits you best.

Adjusting Upper Shoulder Belt

As a guide, if you are shorter than average you will
prefer a lower position, and if you are taller than average

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49

you will prefer a higher position. When you release the
anchorage try to move it up and down to make sure that
it is locked in position.

In the rear seat, move toward the center of the seat to
position the belt away from your neck.

Lap/Shoulder Belt Untwisting Procedure

Use the following procedure to untwist a twisted lap/
shoulder belt.

1. Position the latch plate as close as possible to the
anchor point.

2. At about 6 to 12 in (15 to 30 cm) above the latch plate,
grasp and twist the belt webbing 180 degrees to create a
fold that begins immediately above the latch plate.

3. Slide the latch plate upward over the folded webbing.
The folded webbing must enter the slot at the top of the
latch plate.

2

50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

4. Continue to slide the latch plate up until it clears the
folded webbing.

Seat Belts In Passenger Seating Positions

The seat belts in the passenger seating positions are
equipped with Automatic Locking Retractors (ALR)
which are used to secure a child restraint system. For
additional information refer to “Installing Child Re­straints Using The Vehicle Seat Belt” under the “Child
Restraints” section. The chart below defines the type of
feature for each seating position.

Driver Center Passenger

First Row N/A N/A ALR

Second Row ALR ALR ALR

•

N/A — Not Applicable

•

ALR — Automatic Locking Retractor

If the passenger seating position is equipped with an
ALR and is being used for normal usage:

Only pull the belt webbing out far enough to comfortably
wrap around the occupants mid-section so as to not
activate the ALR. If the ALR is activated you will hear a
ratcheting sound as the belt retracts. Allow the webbing
to retract completely in this case and then carefully pull
out only the amount of webbing necessary to comfort­ably wrap around the occupants mid-section. Slide the
latch plate into the buckle until you hear a ⬙click.⬙

Automatic Locking Retractor Mode (ALR) — If Equipped

In this mode, the shoulder belt is automatically pre­locked. The belt will still retract to remove any slack in
the shoulder belt. The Automatic Locking Mode is avail­able on all passenger-seating positions with a combina­tion lap/shoulder belt. Use the Automatic Locking Mode
anytime a child safety seat is installed in a seating
position that has a belt with this feature. Children
12 years old and under should always be properly
restrained in the rear seat.

How To Engage The Automatic Locking Mode

1. Buckle the combination lap and shoulder belt.

2. Grasp the shoulder portion and pull downward until
the entire belt is extracted.

3. Allow the belt to retract. As the belt retracts, you will
hear a clicking sound. This indicates the safety belt is
now in the Automatic Locking Mode.

How To Disengage The Automatic Locking Mode

Unbuckle the combination lap/shoulder belt and allow it
to retract completely to disengage the Automatic Locking
Mode and activate the vehicle sensitive (emergency)
locking mode.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51

WARNING!

•

The belt and retractor assembly must be replaced
if the seat belt assembly Automatic Locking Re­tractor (ALR) feature or any other seat belt func­tion is not working properly when checked ac­cording to the procedures in the Service Manual.

•

Failure to replace the belt and retractor assembly
could increase the risk of injury in collisions.

Energy Management Feature

This vehicle has a safety belt system with an Energy
Management feature in the front seating positions to help
further reduce the risk of injury in the event of a head-on
accident. This safety belt system has a retractor assembly
that is designed to release webbing in a controlled
manner. This feature is designed to help reduce the belt
force acting on the occupant’s chest.

2

52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Seat Belt Pretensioner

The seat belts for both front seating positions are
equipped with pretensioning devices that are designed to
remove slack from the seat belt in the event of an
accident. These devices may improve the performance of
the seat belt by assuring that the belt is tight about the
occupant early in an accident. Pretensioners work for all
size occupants, including those in child restraints.

NOTE: These devices are not a substitute for proper seat
belt placement by the occupant. The seat belt still must be
worn snugly and positioned properly.

The pretensioners are triggered by the Occupant Re­straint Controller (ORC). Like the airbags, the pretension­ers are single use items. A deployed pretensioner or a
deployed airbag must be replaced immediately.

Enhanced Seat Belt Use Reminder System
(BeltAlert姞)

BeltAlert威 is a feature intended to remind the driver and
front passenger (if equipped with front passenger
BeltAlert威) to fasten their seatbelts. This feature is active
whenever the ignition is on. If the driver or front seat
passenger is unbelted, the Seat Belt Reminder Light will
turn on and remain on until both front seatbelts are
fastened. BeltAlert威 triggers within 60 seconds of vehicle
speed over 5 mph (8 km/h). The reminder sequence lasts
for 96 seconds or until the respective seatbelts are fas­tened. After the sequence completes, the Seat Belt Re­minder Light remains illuminated until front belts are
fastened. The driver should instruct all other occupants
to fasten their seatbelts. If a front seatbelt is unbuckled
while traveling at speeds greater than 5 mph (8 km/h),
BeltAlert威 will chime as a single notification and illumi­nate the Seat Belt Reminder Light, then will proceed to
the 96 second reminder sequence.

The front passenger seat BeltAlert威 is not active when the
front passenger seat is unoccupied. BeltAlert威 may be
triggered when an animal or heavy object is on the front
passenger seat or when the seat is folded flat (if
equipped). It is recommended that pets be restrained in
the rear seat in pet harnesses or pet carriers that are
secured by seat belts, and cargo is properly stowed.

BeltAlert威 Programming

NOTE: Chrysler Group LLC does not recommend de-

activating the BeltAlert威.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53

2. Turn the ignition switch to the ON/RUN position, but
do not start the engine. Wait for the Seat Belt Reminder
Light to turn off and then proceed to the next step.

NOTE: You must perform the following steps within
60 seconds of turning the ignition switch to the ON/RUN
position.

3. Within 60 seconds of turning the ignition switch to the
ON/RUN position, unbuckle and then re-buckle the
driver’s seat belt at least three times within 10 seconds,
ending with the seat belt buckled.

2

The BeltAlert威 can be enabled or disabled by your
authorized dealer or by performing the following steps:

1. With all doors closed, and the ignition switch in any
position except ON/RUN or START, buckle the driver’s
seat belt.

NOTE: Watch for the Seat Belt Reminder Light to turn
on while unbuckling the seat belt and turn off while
re-buckling the seat belt. It may be necessary to retract
the seat belt.

4. Turn the ignition switch to the OFF position. A single
chime will sound to signify that you have successfully
completed the programming.

54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

BeltAlert威 can be reactivated by repeating this procedure.

NOTE: Although BeltAlert威 has been deactivated, the
Seat Belt Reminder Light will continue to illuminate as
long as the driver’s seat belt is unbuckled.

dealer can provide you with a seat belt extender. This
extender should be used only if the existing belt is not
long enough. When it is not required, remove the ex­tender and store it.

Seat Belts And Pregnant Women

We recommend that pregnant women use the seat belts
throughout their pregnancy. Keeping the mother safe is
the best way to keep the baby safe.

Pregnant women should wear the lap part of the belt
across the thighs and as snug across the hips as possible.
Keep the belt low so that it does not come across the
abdomen. That way the strong bones of the hips will take
the force if there is an accident.

Seat Belt Extender

If a seat belt is too short even when fully extended and
when the adjustable upper shoulder belt anchorage (if so
equipped) is in its lowest position, your authorized

WARNING!

Using a seat belt extender when not needed can
increase the risk of injury in an accident. Only use
when the seat belt is not long enough when it is worn
low and snug and in the recommended seating posi­tions. Remove and store the extender when not
needed.

Supplemental Restraint System (SRS) — Airbags

This vehicle has Advanced Front Airbags for both the
driver and front passenger as a supplement to the seat
belt restraint systems. The driver’s Advanced Front Air­bag is mounted in the center of the steering wheel. The
passenger’s Advanced Front Airbag is mounted in the

instrument panel, above the glove compartment. The
words SRS AIRBAG are embossed on the airbag covers.
In addition, the vehicle is equipped with a Supplemental
Driver Side Knee Airbag mounted in the instrument
panel below the steering column.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55

Advanced Front Airbag And Knee Bolster Locations

1 — Driver And Passenger Ad­vanced Front Airbags
3 — Supplemental Driver Side
Knee Airbag

2 — Knee Bolster

NOTE: These airbags are certified to the new Federal
regulations for Advanced Airbags.

2

56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

The Advanced Front Airbags have a multistage inflator
design. This allows the airbag to have different rates of
inflation based on the severity and type of collision.

This vehicle may be equipped with driver and/or front
passenger seat track position sensors that may adjust the
inflation rate of the Advanced Front Airbags based upon
seat position.

This vehicle may be equipped with a driver and/or front
passenger seat belt buckle switch that detects whether
the driver or front passenger seat belt is fastened. The
seat belt buckle switch may adjust the inflation rate of the
Advanced Front Airbags.

This vehicle is equipped with Supplemental Side Airbag
Inflatable Curtains (SABIC) to protect the driver, front,
and rear passengers sitting next to a window. The SABIC
airbags are located above the side windows and their
covers are also labeled: SRS AIRBAG.

This vehicle is equipped with Supplemental Seat­Mounted Side Airbags (SAB) to provide enhanced pro­tection for an occupant during a side impact. The Supple­mental Seat-Mounted Side Airbags are located in the
outboard side of the front seats.

NOTE:

•

Airbag covers may not be obvious in the interior trim;
but they will open during airbag deployment.

•

After any accident, the vehicle should be taken to an
authorized dealer immediately.

Airbag System Components

Your vehicle may be equipped with the following airbag
system components:

•

Occupant Restraint Controller (ORC)

•

Airbag Warning Light

•

Steering Wheel and Column

•

Instrument Panel

•

Supplemental Driver Side Knee Airbag

•

Knee Impact Bolster

•

Driver Advanced Front Airbag

•

Passenger Advanced Front Airbag

•

Supplemental Seat-Mounted Side Airbags (SAB)

•

Supplemental Side Airbag Inflatable Curtains (SABIC)

•

Front and Side Impact Sensors

•

Front Seat Belt Pretensioners, Seat Belt Buckle Switch,
and Seat Track Position Sensors

Advanced Front Airbag Features

The Advanced Front Airbag system has multistage driver
and front passenger airbags. This system provides output
appropriate to the severity and type of collision as

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57

determined by the Occupant Restraint Controller (ORC),
which may receive information from the front impact
sensors.

The first stage inflator is triggered immediately during an
impact that requires airbag deployment. This low output
is used in less severe collisions. A higher energy output is
used for more severe collisions.

WARNING!

•

No objects should be placed over or near the
airbag on the instrument panel, because any such
objects could cause harm if the vehicle is in a
collision severe enough to cause the airbag to
inflate.

(Continued)

2

58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING! (Continued)

•

Do not put anything on or around the airbag
covers or attempt to open them manually. You may
damage the airbags and you could be injured
because the airbags may no longer be functional.
The protective covers for the airbag cushions are
designed to open only when the airbags are inflat­ing.

•

Do not drill, cut or tamper with the knee bolster in
any way.

•

Do not mount any accessories to the knee bolster
such as alarm lights, stereos, citizen band radios,
etc.

side impact. The Supplemental Seat-Mounted Side Air­bag is marked with an airbag label sewn into the out­board side of the front seats.

Supplemental Seat-Mounted Side Airbags (SAB)

Supplemental Seat-Mounted Side Airbags may provide
enhanced protection to help protect an occupant during a

Supplemental Seat-Mounted Side Airbag Label

When the airbag deploys, it opens the seam between the
front and side of the seat’s trim cover. Each airbag

deploys independently, that is a left side impact deploys
the left airbag only and a right-side impact deploys only
the right airbag.

Supplemental Side Airbag Inflatable Curtain
(SABIC)

SABIC airbags may offer side-impact protection to front
and rear seat outboard occupants in addition to that
provided by the body structure. Each airbag features
inflated chambers placed adjacent to the head of each
outboard occupant that reduce the potential for side­impact head injuries. The curtains deploy downward,
covering both windows on the impact side.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59

Supplemental Side Airbag Inflatable Curtains (SABIC)

Label Location

NOTE:

•

Airbag covers may not be obvious in the interior trim;
but they will open during airbag deployment.

•

Being too close to the side airbags during deployment
could cause you to be severely injured or killed.

2

60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

The system includes side impact sensors adjacent to both
front and rear seat occupants that are calibrated to deploy
the side airbags during impacts that require airbag
occupant protection.

Supplemental Driver Side Knee Airbag

The Supplemental Driver Side Knee Airbag provides
enhanced protection and works together with the Driver
Advanced Front Airbag during a frontal impact.

WARNING!

•

Your vehicle is equipped with left and right
Supplemental Side Airbag Inflatable Curtain
(SABIC), do not stack luggage or other cargo up
high enough to block the location of the SABIC.
The area where the SABIC is located should re­main free from any obstructions.

•

Do not use accessory seat covers or place objects
between you and the side airbags; the performance
could be adversely affected and/or objects could
be pushed into you, causing serious injury.

Knee Impact Bolsters

The Knee Impact Bolsters help protect the knees of the
driver and the front passenger, and position front occu­pants for the best interaction with the Advanced Front
Airbags.

Along with seat belts and pretensioners, Advanced Front
Airbags work with the Supplemental Driver Side Knee
Airbag and the passenger side knee bolster to provide
improved protection for the driver and front passenger.
Side airbags also work with seat belts to improve occu­pant protection.

Airbag Deployment Sensors And Controls

Occupant Restraint Controller (ORC)

The ORC is part of a Federally regulated safety system
required for this vehicle.

The ORC determines if deployment of the front and/or
side airbags in a frontal or side collision is required.
Based on the impact sensors signals, a central electronic
ORC deploys the Advanced Front Airbags, SABIC air­bags, SAB, Supplemental Driver Side Knee Airbag, and
front seat belt pretensioners, as required, depending on
the severity and type of impact.

Advanced Front Airbags and Supplemental Driver Side
Knee Airbag are designed to provide additional protec­tion by supplementing the seat belts in certain frontal
collisions depending on the severity and type of collision.
Advanced Front Airbags are not expected to reduce the
risk of injury in rear, side, or rollover collisions.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61

The Advanced Front Airbags and Supplemental Driver
Side Knee Airbag will not deploy in all frontal collisions,
including some that may produce substantial vehicle
damage — for example, some pole collisions, truck
underrides, and angle offset collisions. On the other
hand, depending on the type and location of impact,
Advanced Front Airbags may deploy in crashes with
little vehicle front-end damage but that produce a severe
initial deceleration.

The side airbags will not deploy in all side collisions. Side
airbag deployment will depend on the severity and type
of collision.

Because airbag sensors measure vehicle deceleration over
time, vehicle speed and damage by themselves are not
good indicators of whether or not an airbag should have
deployed.

2

62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Seat belts are necessary for your protection in all acci­dents, and also are needed to help keep you in position,
away from an inflating airbag.

turns on the Airbag Warning Light, either momentarily
or continuously. A single chime will sound if the light
comes on again after initial startup.

The ORC monitors the readiness of the electronic parts of
the airbag system whenever the ignition switch is in the
START or ON/RUN position. If the key is in the OFF
position, in the ACC position, or not in the ignition, the
airbag system is not on and the airbags will not inflate.

The ORC contains a backup power supply system that
may deploy the airbags even if the battery loses power or
it becomes disconnected prior to deployment.

Also, the ORC turns on the Airbag Warning
Light in the instrument panel for approxi­mately four to eight seconds for a self-check

when the ignition is first turned on. After the
self-check, the Airbag Warning Light will turn off. If the
ORC detects a malfunction in any part of the system, it

It also includes diagnostics that will illuminate the instru­ment cluster Airbag Warning Light if a malfunction is
noted that could affect the airbag system. The diagnostics
also record the nature of the malfunction.

WARNING!

Ignoring the Airbag Warning Light in your instru­ment panel could mean you won’t have the airbags to
protect you in a collision. If the light does not come
on as a bulb check when the ignition is first turned
on, stays on after you start the vehicle, or if it comes
on as you drive, have an authorized dealer service the
airbag system immediately.

Driver And Passenger Advanced Front Airbag
Inflator Units

The Driver and Passenger Advanced Front Airbag Infla­tor Units are located in the center of the steering wheel
and the right side of the instrument panel. When the
ORC detects a collision requiring the Advanced Front
Airbags, it signals the inflator units. A large quantity of
non-toxic gas is generated to inflate the Advanced Front
Airbags. Different airbag inflation rates are possible,
based on the collision type and severity. The steering
wheel hub trim cover and the upper right side of the
instrument panel separate and fold out of the way as the
airbags inflate to their full size. The airbags fully inflate in
about 50 to 70 milliseconds. This is about half of the time
it takes to blink your eyes. The airbags then quickly
deflate while helping to restrain the driver and front
passenger.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63

The Advanced Front Airbag gas is vented through the
vent holes in the sides of the airbag. In this way, the
airbags do not interfere with your control of the vehicle.

Supplemental Driver Side Knee Airbag Inflator
Unit

The Supplemental Driver Side Knee Airbag unit is lo­cated in the instrument panel trim beneath the steering
column. When the ORC detects a collision requiring the
airbag, it signals the inflator units. A large quantity of
non-toxic gas is generated to inflate the Supplemental
Driver Side Knee Airbag. The trim cover separates and
folds out of the way allowing the airbag to inflate to the
full size. The airbag fully inflates in about 15 to 20
milliseconds. The Supplemental Driver Side Knee Airbag
gas is vented through small vent holes in the side of
airbag.

2

64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Supplemental Seat-Mounted Side Airbag (SAB)
Inflator Units

The Supplemental Seat-Mounted Side Airbags (SAB) are
designed to activate only in certain side collisions.

The ORC determines if a side collision requires the side
airbags to inflate based on the severity and type of
collision.

Based on the severity and type of collision, the side
airbag inflator on the crash side of the vehicle may be
triggered, releasing a quantity of non-toxic gas. The
inflating SAB exits through the seat seam into the space
between the occupant and the door. The SAB fully inflate
in about 10 milliseconds. The side airbag moves at a very
high speed and with such a high force, that it could injure
you if you are not seated properly, or if items are
positioned in the area where the side airbag inflates. This
especially applies to children.

Supplemental Side Airbag Inflatable Curtain
(SABIC) Inflator Units

During collisions where the impact is confined to a
particular area of the side of the vehicle, the ORC may
deploy the SABIC airbags, depending on the severity and
type of collision. In these events, the ORC will deploy the
SABIC only on the impact side of the vehicle.

A quantity of non-toxic gas is generated to inflate the side
curtain airbag. The inflating side curtain airbag pushes
the outside edge of the headliner out of the way and
covers the window. The airbag inflates in about 30
milliseconds (about one-quarter of the time that it takes
to blink your eyes) with enough force to injure you if you
are not belted and seated properly, or if items are
positioned in the area where the side curtain airbag
inflates. This especially applies to children. The side
curtain airbag is only about 3-1/2 in (9 cm) thick when it
is inflated.

Because airbag sensors estimate deceleration over time,
vehicle speed and damage are not good indicators of
whether or not an airbag should have deployed.

Front And Side Impact Sensors

In front and side impacts, impact sensors can aid the
ORC in determining appropriate response to impact
events.

Enhanced Accident Response System

In the event of an impact causing airbag deployment, if
the communication network remains intact, and the
power remains intact, depending on the nature of the
event the ORC will determine whether to have the
Enhanced Accident Response System perform the follow­ing functions:

•

Cut off fuel to the engine.

•

Flash hazard lights as long as the battery has power or
until the ignition key is turned off.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65

•

Turn on the interior lights, which remain on as long as
the battery has power, until the ignition key is re­moved or the ignition switch is changed to OFF using
the Keyless Go Start/Stop button.

•

Unlock the doors automatically.

If A Deployment Occurs

The front airbags are designed to deflate immediately
after deployment.

NOTE: Front and/or side airbags will not deploy in all
collisions. This does not mean something is wrong with
the airbag system.

If you do have a collision which deploys the airbags, any
or all of the following may occur:

•

The nylon airbag material may sometimes cause abra­sions and/or skin reddening to the driver and front
passenger as the airbags deploy and unfold. The
abrasions are similar to friction rope burns or those

2

66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

you might get sliding along a carpet or gymnasium
floor. They are not caused by contact with chemicals.
They are not permanent and normally heal quickly.
However, if you haven’t healed significantly within a
few days, or if you have any blistering, see your doctor
immediately.

•

As the airbags deflate, you may see some smoke-like
particles. The particles are a normal by-product of the
process that generates the non-toxic gas used for
airbag inflation. These airborne particles may irritate
the skin, eyes, nose, or throat. If you have skin or eye
irritation, rinse the area with cool water. For nose or
throat irritation, move to fresh air. If the irritation
continues, see your doctor. If these particles settle on
your clothing, follow the garment manufacturer’s in­structions for cleaning.

Do not drive your vehicle after the airbags have de­ployed. If you are involved in another collision, the
airbags will not be in place to protect you.

WARNING!

Deployed airbags and seat belt pretensioners cannot
protect you in another collision. Have the airbags,
seat belt pretensioners, and the front seat belt retrac­tor assemblies replaced by an authorized dealer im­mediately. Also, have the Occupant Restraint Con­troller (ORC) system serviced as well.

Maintaining Your Airbag System

WARNING!

•

Modifications to any part of the airbag system
could cause it to fail when you need it. You could
be injured if the airbag system is not there to
protect you. Do not modify the components or
wiring, including adding any kind of badges or
stickers to the steering wheel hub trim cover or the
upper right side of the instrument panel. Do not
modify the front bumper, vehicle body structure,
or add aftermarket side steps or running boards.

•

It is dangerous to try to repair any part of the
airbag system yourself. Be sure to tell anyone who
works on your vehicle that it has an airbag system.

(Continued)

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67

WARNING! (Continued)

•

Do not attempt to modify any part of your airbag
system. The airbag may inflate accidentally or may
not function properly if modifications are made.
Take your vehicle to an authorized dealer for any
airbag system service. If your seat including your
trim cover and cushion needs to be serviced in any
way (including removal or loosening/tightening of
seat attachment bolts), take the vehicle to your
authorized dealer. Only manufacturer approved
seat accessories may be used. If it is necessary to
modify the airbag system for persons with dis­abilities, contact your authorized dealer.

2

68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Airbag Warning Light

You will want to have the airbags ready to

inflate for your protection in a collision. The

Airbag Warning Light monitors the internal

circuits and interconnecting wiring associated
with airbag system electrical components. While the
airbag system is designed to be maintenance free, if any
of the following occurs, have an authorized dealer ser­vice the airbag system immediately.

•

The Airbag Warning Light does not come on during
the four to eight seconds when the ignition switch is
first turned to the ON/RUN position.

•

The Airbag Warning Light remains on after the four to
eight-second interval.

•

The Airbag Warning Light comes on intermittently or
remains on while driving.

NOTE: If the speedometer, tachometer, or any engine
related gauges are not working, the Occupant Restraint
Controller (ORC) may also be disabled. The airbags may
not be ready to inflate for your protection. Promptly
check the fuse block for blown fuses. Refer to the label
located on the inside of the fuse block cover for the
proper airbag fuses. See your authorized dealer if the
fuse is good.

Event Data Recorder (EDR)

This vehicle is equipped with an event data recorder
(EDR). The main purpose of an EDR is to record, in
certain crash or near crash-like situations, such as an air
bag deployment or hitting a road obstacle, data that will
assist in understanding how a vehicle’s systems per­formed. The EDR is designed to record data related to
vehicle dynamics and safety systems for a short period of
time, typically 30 seconds or less. The EDR in this vehicle
is designed to record such data as:

•

How various systems in your vehicle were operating;

•

Whether or not the driver and passenger safety belts
were buckled/fastened;

•

How far (if at all) the driver was depressing the
accelerator and/or brake pedal; and,

•

How fast the vehicle was traveling.

These data can help provide a better understanding of
the circumstances in which crashes and injuries occur.

NOTE: EDR data are recorded by your vehicle only if a
non-trivial crash situation occurs; no data are recorded by
the EDR under normal driving conditions and no per­sonal data (e.g. name, gender, age, and crash location) are
recorded. However, other parties, such as law enforce­ment, could combine the EDR data with the type of
personally identifying data routinely acquired during a
crash investigation.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69

To read data recorded by an EDR, special equipment is
required, and access to the vehicle or the EDR is needed.
In addition to the vehicle manufacturer, other parties
such as law enforcement, that have the special equip­ment, can read the information if they have access to the
vehicle or the EDR.

Child Restraints

Everyone in your vehicle needs to be buckled up all the
time, including babies and children. Every state in the
United States and all Canadian provinces require that
small children ride in proper restraint systems. This is the
law, and you can be prosecuted for ignoring it.

Children 12 years and younger should ride properly
buckled up in a rear seat, if available. According to crash
statistics, children are safer when properly restrained in
the rear seats rather than in the front.

2

70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!

In a collision, an unrestrained child, even a tiny baby,
can become a projectile inside the vehicle. The force
required to hold even an infant on your lap could
become so great that you could not hold the child, no
matter how strong you are. The child and others
could be badly injured. Any child riding in your
vehicle should be in a proper restraint for the child’s
size.

There are different sizes and types of restraints for
children from newborn size to the child almost large
enough for an adult safety belt. Always check the child
seat Owner’s Manual to ensure you have the correct seat
for your child. Use the restraint that is correct for your
child.

Infants And Child Restraints

Safety experts recommend that children ride

•

rearward-facing in the vehicle until they are at least
one year old and weigh at least 20 lbs (9 kg). Two types
of child restraints can be used rearward-facing, infant
carriers and convertible child seats.

•

The infant carrier is only used rearward-facing in the
vehicle. It is recommended for children who weigh up
to about 20 lbs (9 kg). Convertible child seats can be
used either rearward-facing or forward-facing in the
vehicle. Convertible child seats often have a higher
weight limit in the rearward-facing direction than
infant carriers do, so they can be used rearward-facing
by children who weigh more than 20 lbs (9 kg) but are
less than one year old. Both types of child restraints are
held in the vehicle by the lap/shoulder belt or the
LATCH child restraint anchorage system. Refer to
“Lower Anchors and Tether for CHildren (LATCH)”.

WARNING!

Rearward-facing child seats must never be used in
the front seat of a vehicle with the front passenger
airbag unless the airbag is turned off. An airbag
deployment could cause severe injury or death to
infants in this position.

Older Children And Child Restraints

Children who weigh more than 20 lbs (9 kg) and who are
older than one year can ride forward-facing in the
vehicle. Forward-facing child seats and convertible child
seats used in the forward-facing direction are for children
who weigh 20 to 40 lbs (9 to 18 kg) and who are older
than one year. These child seats are also held in the
vehicle by the lap/shoulder belt or the LATCH child
restraint anchorage system. Refer to “Lower Anchors and
Tether for CHildren (LATCH)”.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71

The belt-positioning booster seat is for children weighing
more than 40 lbs (18 kg), but who are still too small to fit
the vehicle’s seat belts properly. If the child cannot sit
with knees bent over the vehicle’s seat cushion while the
child’s back is against the seatback, they should use a
belt-positioning booster seat. The child and belt­positioning booster seat are held in the vehicle by the
lap/shoulder belt.

Children Too Large For Booster Seats

Children who are large enough to wear the shoulder belt
comfortably and whose legs are long enough to bend
over the front of the seat when their back is against the
seatback should use the lap/shoulder belt in a rear seat.

•

Make sure that the child is upright in the seat.

•

The lap portion should be low on the hips and as snug
as possible.

2

72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

•

Check belt fit periodically. A child’s squirming or
slouching can move the belt out of position.

•

If the shoulder belt contacts the face or neck, move the
child closer to the center of the vehicle. Never allow a
child to put the shoulder belt under an arm or behind
their back.

NOTE: For additional information, refer to
www.seatcheck.org or call 1–866–SEATCHECK. Cana­dian residents, should refer to Transport Canada’s web­site for additional information. http://www.tc.gc.ca/
roadsafety/safedrivers/childsafety/index.htm

WARNING!

•

Improper installation can lead to failure of an
infant or child restraint. It could come loose in a
collision. The child could be badly injured or
killed. Follow the manufacturer’s directions ex­actly when installing an infant or child restraint.

•

A rearward-facing child restraint should only be
used in a rear seat. A rearward-facing child re­straint in the front seat may be struck by a deploy­ing passenger airbag, which may cause severe or
fatal injury to the infant.

Here are some tips on getting the most out of your child
restraint:

•

Before buying any restraint system, make sure that it
has a label certifying that it meets all applicable Safety
Standards. Chrysler Group LLC also recommends that

you make sure that you can install the child restraint in
the vehicle where you will use it before you buy it.

•

The restraint must be appropriate for your child’s
weight and height. Check the label on the restraint for
weight and height limits.

•

Carefully follow the instructions that come with the
restraint. If you install the restraint improperly, it may
not work when you need it.

•

Buckle the child into the seat according to the child
restraint manufacturer’s directions.

WARNING!

When your child restraint is not in use, secure it in
the vehicle with the seat belt or remove it from the
vehicle. Do not leave it loose in the vehicle. In a
sudden stop or accident, it could strike the occupants
or seatbacks and cause serious personal injury.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73

Lower Anchors and Tether for CHildren (LATCH)

Your vehicle’s rear seat is equipped with the child
restraint anchorage system called LATCH. The LATCH
system provides for the installation of the child restraint
without using the vehicle’s seat belts, instead securing
the child restraint using lower anchorages and upper
tether straps from the child restraint to the vehicle
structure.

LATCH-compatible child restraint systems are now avail­able. However, because the lower anchorages are to be
introduced over a period of years, child restraint systems
having attachments for those anchorages will continue to
have features for installation using the vehicle’s seat
belts. Child restraints having tether straps and hooks for
connection to the top tether anchorages, have been
available for some time. For some older child restraints,
many child restraint manufacturers offer add-on tether

2

74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

strap kits or retrofit kits. You are urged to take advantage
of all the available attachments provided with your child
restraint in any vehicle.

All three rear-seating positions have lower anchorages
that are capable of accommodating LATCH-compatible
child seats. You should never install LATCH-compatible
child seats so that two seats share a common lower
anchorage. If installing child seats in adjacent rear­seating positions, or if your child restraints are not
LATCH-compatible, install the restraints using the vehi­cle’s seat belts.

LATCH Anchorages

Installing The LATCH-Compatible Child Restraint
System

We urge you to follow the manufacturer’s directions
carefully when installing your child restraint. Not all
child restraint systems will be installed as described here.

Again, carefully follow the installation instructions that
are provided with the child restraint system.

The rear seat lower anchorages are round bars

located at the rear of the seat cushion where it

meets the seatback and are just visible when

you lean into the rear seat to install the child
restraint. You will easily feel them if you run your finger
along the intersection of the seatback and seat cushion
surfaces.

In addition, there are tether strap anchorages

behind each rear seating position located in the

panel between the rear seatback and the rear

window. These tether strap anchorages are
under a plastic cover with this symbol on it.

Many, but not all restraint systems will be equipped with
separate straps on each side, with each having a hook or
connector for attachment to the lower anchorage and a

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75

means of adjusting the tension in the strap. Forward­facing toddler restraints and some rear-facing infant
restraints will also be equipped with a tether strap, a
hook for attachment to the tether strap anchorage and a
means of adjusting the tension of the strap.

You will first loosen the child seat adjusters on the lower
straps and on the tether strap so that you can more easily
attach the hooks or connectors to the vehicle anchorages.
Next, attach the lower hooks or connectors over the top
of the seat cover material. Then rotate the tether anchor­age cover directly behind the seat where you are placing
the child restraint and attach the tether strap to the
anchorage, being careful to route the tether strap to
provide the most direct path between the anchor and the
child restraint. Finally, tighten all three straps as you
push the child restraint rearward and downward into the
seat, removing slack in the straps according to the child
restraint manufacturer’s instructions.

2

76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

For center seating position route the tether strap over the
seatback and adjustable headrest then attach the hook to
the tether anchor located in the panel between the rear
seatback and the rear window.

Adjustable Headrest

Adjustable Headrest Release Push Button

WARNING!

An incorrectly anchored tether strap could lead to
increased head motion and possible injury to the
child. Use only the anchor positions directly behind
the child seat to secure a child restraint top tether
strap.

NOTE:

•

Ensure that the tether strap does not slip into the
opening between the seatbacks as you remove slack in
the strap.

•

When using the LATCH attaching system to install a
child restraint, please ensure that all seat belts not
being used for occupant restraints are stowed and out
of reach of children. It is recommended that before
installing the child restraint, buckle the seat belt so the
seat belt is tucked behind the child restraint and out of
reach. If the buckled seat belt interferes with the child

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77

restraint installation, instead of tucking the seat belt
behind the child restraint, route the seat belt through
the child restraint belt path and then buckle it. This
should stow the seat belt out of the reach of an
inquisitive child. Remind all children in the vehicle
that the seat belts are not toys and should not be
played with, and never leave your child unattended in
the vehicle.

WARNING!

Improper installation of a child restraint to the
LATCH anchorages can lead to failure of an infant or
child restraint. The child could be badly injured or
killed. Follow the manufacturer’s directions exactly
when installing an infant or child restraint.

2

78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Installing Child Restraints Using The Vehicle Seat
Belts

The seat belts in the passenger seating positions are
equipped with an Automatic Locking Retractor (ALR) to
secure a Child Restraint System (CRS). These types of
seatbelts are designed to keep the lap portion of the seat
belt tight around the child restraint so that it is not
necessary to use a locking clip. The ALR will make a
ratcheting noise if you extract the entire belt from the
retractor and then allow the belt to retract into the
retractor. For additional information on ALR, refer to
“Automatic Locking Mode”. The chart below defines the
seating positions with an Automatic Locking Retractor
(ALR) or a cinching latch plate.

Driver Center Passenger

CRS Lock CRS Lock CRS Lock

First Row N/A N/A ALR

Second Row ALR ALR ALR

•

N/A — Not Applicable

•

ALR — Automatic Locking Retractor

To attach a child restraint tether strap:

1. Rotate the cover over the anchor directly behind the
seat where you are placing the child restraint.

Tether Strap Mounting

1 — Cover A — Tether Strap Hook
3 — Attaching Strap B — Tether Anchor

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79

2. Route the tether strap to provide the most direct path
for the strap between the anchor and the child seat.

3. Attach the tether strap hook (A) of the child restraint to
the anchor (B) and remove slack in the tether strap
according to the child restraint manufacturer’s instruc­tions.

NOTE: Ensure that the tether strap does not slip into the
opening between the seatbacks as you remove slack in
the strap.

WARNING!

An incorrectly anchored tether strap could lead to
increased head motion and possible injury to the
child. Use only the anchor positions directly behind
the child seat to secure a child restraint top tether
strap.

2

80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Transporting Pets

Airbags deploying in the front seat could harm your pet.
An unrestrained pet will be thrown about and possibly
injured, or injure a passenger during panic braking or in
an accident.

Pets should be restrained in the rear seat in pet harnesses
or pet carriers that are secured by seat belts.

ENGINE BREAK-IN RECOMMENDATIONS

A long break-in period is not required for the engine and
drivetrain (transmission and axle) in your vehicle.

Drive moderately during the first 300 miles (500 km).
After the initial 60 miles (100 km), speeds up to 50 or
55 mph (80 or 90 km/h) are desirable.

While cruising, brief full-throttle acceleration within the
limits of local traffic laws, contributes to a good break-in.
Wide-open throttle acceleration in low gear can be detri­mental and should be avoided.

The engine oil installed in the engine at the factory is a
high-quality energy conserving type lubricant. Oil
changes should be consistent with anticipated climate
conditions under which vehicle operations will occur. For
the recommended viscosity and quality grades refer to
“Maintenance Procedures” in “Maintaining Your Ve­hicle”. NON-DETERGENT OR STRAIGHT MINERAL
OILS MUST NEVER BE USED.

A new engine may consume some oil during its first few
thousand miles (kilometers) of operation. This should be
considered a normal part of the break-in and not inter­preted as an indication of difficulty.

SAFETY TIPS
Transporting Passengers

NEVER TRANSPORT PASSENGERS IN THE CARGO
AREA.

WARNING!

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81

Exhaust Gas

•

Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build-up may
cause serious injury or death.

•

It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seri­ously injured or killed.

•

Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat
belts.

•

Be sure everyone in your vehicle is in a seat and
using a seat belt properly.

WARNING!

Exhaust gases can injure or kill. They contain carbon
monoxide (CO), which is colorless and odorless.
Breathing it can make you unconscious and can
eventually poison you. To avoid breathing (CO)
follow these safety tips:

Do not run the engine in a closed garage or in confined
areas any longer than needed to move your vehicle in or
out of the area.

If it is necessary to sit in a parked vehicle with the engine
running, adjust your heating or cooling controls to force
outside air into the vehicle. Set the blower at high speed.

2

82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

If you are required to drive with the trunk/liftgate open,
make sure that all windows are closed and the climate
control BLOWER switch is set at high speed. DO NOT
use the recirculation mode.

The best protection against carbon monoxide entry into
the vehicle body is a properly maintained engine exhaust
system.

Whenever a change is noticed in the sound of the exhaust
system, when exhaust fumes can be detected inside the
vehicle, or when the underside or rear of the vehicle is
damaged, have a competent mechanic inspect the com­plete exhaust system and adjacent body areas for broken,
damaged, deteriorated, or mispositioned parts. Open
seams or loose connections could permit exhaust fumes
to seep into the passenger compartment. In addition,
inspect the exhaust system each time the vehicle is raised
for lubrication or oil change. Replace as required.

Safety Checks You Should Make Inside The Vehicle

Seat Belts

Inspect the belt system periodically, checking for cuts,
frays, and loose parts. Damaged parts must be replaced
immediately. Do not disassemble or modify the system.

Front seat belt assemblies must be replaced after a
collision. Rear seat belt assemblies must be replaced after
a collision if they have been damaged (i.e., bent retractor,
torn webbing, etc.). If there is any question regarding belt
or retractor condition, replace the belt.

Airbag Warning Light

The light should come on and remain on for four to eight
seconds as a bulb check when the ignition switch is first
turned ON. If the light is not lit during starting, see your
authorized dealer. If the light stays on, flickers, or comes
on while driving, have the system checked by an autho­rized dealer.

Defroster

Check operation by selecting the defrost mode and place
the blower control on high speed. You should be able to
feel the air directed against the windshield. See your
authorized dealer for service if your defroster is
inoperable.

Floor Mat Safety Information

Always use floor mats designed to fit the foot well of
your vehicle. Use only floor mats that leave the pedal
area unobstructed and that are firmly secured so that
they cannot slip out of position and interfere with the
pedals or impair safe operation of your vehicle in other
ways.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83

WARNING!

Pedals that cannot move freely can cause loss of
vehicle control and increase the risk of serious per­sonal injury.

•

Always make sure that floor mats are properly
attached to the floor mat fasteners.

•

Never place or install floor mats or other floor
coverings in the vehicle that cannot be properly
secured to prevent them from moving and inter­fering with the pedals or the ability to control the
vehicle.

•

Never put floor mats or other floor coverings on
top of already installed floor mats. Additional
floor mats and other coverings will reduce the size
of the pedal area and interfere with the pedals.

(Continued)

2

84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING! (Continued)

•

Check mounting of mats on a regular basis. Al­ways properly reinstall and secure floor mats that
have been removed for cleaning.

•

Always make sure that objects cannot fall into the
driver foot well while the vehicle is moving.
Objects can become trapped under the brake pedal
and accelerator pedal causing a loss of vehicle
control.

•

If required, mounting posts must be properly
installed, if not equipped from the factory.

Failure to properly follow floor mat installation or
mounting can cause interference with the brake
pedal and accelerator pedal operation causing loss
of control of the vehicle.

Periodic Safety Checks You Should Make Outside The Vehicle

Tires

Examine tires for excessive tread wear and uneven wear
patterns. Check for stones, nails, glass, or other objects
lodged in the tread. Inspect the tread and sidewall for
cuts and cracks. Check the wheel nuts for tightness.
Check the tires (including spare) for proper pressure.

Lights

Have someone observe the operation of exterior lights
while you work the controls. Check turn signal and high
beam indicator lights on the instrument panel.

Door Latches

Check for positive closing, latching, and locking.

Fluid Leaks

Check area under vehicle after overnight parking for fuel,
engine coolant, oil, or other fluid leaks. Also, if gasoline
fumes are detected or if fuel, power steering fluid, or
brake fluid leaks are suspected, the cause should be
located and corrected immediately.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 85

2

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CONTENTS

䡵 Mirrors .............................. 94

▫ Power Mirrors ....................... 96

3

▫ Automatic Dimming Mirror .............. 94

▫ Outside Mirrors ...................... 94

▫ Outside Mirrors Folding Feature —

If Equipped ......................... 95

▫ Driver’s Automatic Dimming Mirror —

If Equipped ......................... 95

▫ Outside Mirrors With Turn Signal And

Approach Lighting — If Equipped ......... 95

▫ Tilt Mirrors In Reverse — If Equipped ...... 96

▫ Power Folding Outside Mirrors —

If Equipped ......................... 97

▫ Heated Mirrors — If Equipped ............ 98

▫ Illuminated Vanity Mirrors — If Equipped . . . 98

䡵 Uconnect™ Touch 8.4/8.4 NAV ............ 98

▫ Uconnect™ Phone .................... 98

▫ Operation ......................... 101

▫ Phone Call Features .................. 112

88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

▫ Uconnect™ Phone Features ............. 117

▫ Ventilated Seats — If Equipped .......... 144

▫ Advanced Phone Connectivity ........... 122

▫ Things You Should Know About Your

Uconnect™ Phone .................... 122

▫ General Information .................. 131

䡵 Uconnect™ Voice Command 8.4/8.4 NAV .... 131

▫ Uconnect™ Voice Command System

Operation .......................... 131

▫ Uconnect™ Voice Commands ........... 133

▫ Voice Tree ......................... 135

䡵 Seats .............................. 139

▫ Power Seats — If Equipped ............. 139

▫ Power Lumbar — If Equipped ........... 141

▫ Heated Seats — If Equipped ............ 142

▫ Head Restraints ..................... 145

▫ Folding Rear Seat .................... 148

䡵 Driver Memory Seat — If Equipped ........ 150

▫ Programming The Memory Feature ....... 151

▫ Linking And Unlinking The Remote Keyless

Entry Transmitter To Memory ........... 152

▫ Memory Position Recall ................ 152

▫ Easy Entry/Exit Seat (Available With

Memory Seat Only) ................... 153

䡵 To Open And Close The Hood ............ 154

䡵 Lights ............................. 156

▫ Headlight Switch .................... 156

▫ Automatic Headlights — If Equipped ...... 157

▫ Headlights On With Wipers (Available With

Automatic Headlights Only) ............ 157

▫ Headlight Time Delay ................. 157

▫ Smartbeam™ — If Equipped ............ 158

▫ Daytime Running Lights (DRL) .......... 158

▫ Lights-On Reminder .................. 159

▫ Fog Lights — If Equipped .............. 159

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89

▫ Interior Lights ...................... 162

䡵 Windshield Wipers And Washers .......... 164

▫ Intermittent Wiper System .............. 165

▫ Mist Feature ........................ 165

3

▫ Windshield Washers .................. 165

▫ Headlights On With Wipers (Available With

Automatic Headlights Only) ............ 166

▫ Multifunction Lever .................. 160

▫ Turn Signals ........................ 161

▫ Lane Change Assist ................... 161

▫ High/Low Beam Switch ............... 161

▫ Flash-To-Pass ....................... 161

▫ Map/Reading Lights .................. 161

▫ Rain Sensing Wipers — If Equipped ....... 166

䡵 Tilt/Telescoping Steering Column .......... 168

䡵 Power Tilt/Telescoping Steering Column —

If Equipped .......................... 169

䡵 Heated Steering Wheel — If Equipped ...... 170

䡵 Adjustable Pedals — If Equipped .......... 171

䡵 Electronic Speed Control — If Equipped ..... 173

90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

▫ To Activate ......................... 174

▫ ToTurnOff ........................ 183

▫ To Set A Desired Speed ................ 174

▫ To Deactivate ....................... 174

▫ To Resume Speed .................... 175

▫ To Vary The Speed Setting .............. 175

▫ To Accelerate For Passing .............. 175

䡵 Adaptive Cruise Control (ACC) —

If Equipped .......................... 176

▫ Adaptive Cruise Control (ACC) Operation . . 178

▫ Activating Adaptive Cruise Control (ACC) . . 179

▫ To Activate ......................... 180

▫ To Set A Desired ACC Speed ............ 181

▫ To Cancel .......................... 182

▫ To Resume Speed .................... 183

▫ To Vary The Speed Setting .............. 183

▫ Setting The Following Distance In ACC .... 184

▫ Adaptive Cruise Control (ACC) Menu ..... 186

▫ Display Warnings And Maintenance ....... 188

▫ Precautions While Driving With ACC ...... 191

▫ General Information .................. 195

▫ Normal (Fixed Speed) Cruise Control

Mode ............................. 195

▫ Forward Collision Warning — If Equipped . . 198

䡵 Parksense威 Rear Park Assist — If Equipped . . . 200

▫ Parksense威 Sensors ................... 201

▫ Parksense威 Warning Display ............ 201

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91

䡵 Garage Door Opener — If Equipped ........ 213

▫ Parksense威 Display ................... 202

▫ Enabling And Disabling Parksense威 ....... 205

▫ Service The Parksense威 Rear Park Assist

System ............................ 206

▫ Cleaning The Parksense威 System ......... 206

▫ Parksense威 System Usage Precautions ...... 206

䡵 Parkview威 Rear Back Up Camera —

If Equipped .......................... 209

▫ Turning Parkview威 On Or Off — With Touch

Screen Radio ....................... 211

䡵 Overhead Console ..................... 212

▫ Courtesy/Reading Lights .............. 212

▫ Sunglasses Storage ................... 213

▫ Programming HomeLink威 .............. 214

▫ Gate Operator/Canadian Programming .... 217

▫ Using HomeLink威 ................... 218

3

▫ Reprogramming A Single HomeLink威

Button ............................ 218

▫ Security ........................... 218

▫ Troubleshooting Tips .................. 219

▫ General Information .................. 219

䡵 Power Sunroof — If Equipped ............ 220

▫ Opening Sunroof — Express ............ 221

▫ Opening Sunroof — Manual Mode ........ 221

▫ Closing Sunroof — Express ............. 221

92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

▫ Closing Sunroof — Manual Mode ........ 221

▫ Opening Power Shade – Express ......... 225

▫ Pinch Protect Feature ................. 221

▫ Pinch Protect Override ................ 222

▫ Venting Sunroof — Express ............. 222

▫ Sunshade Operation .................. 222

▫ Wind Buffeting ...................... 222

▫ Sunroof Maintenance ................. 223

▫ Ignition Off Operation ................. 223

䡵 Command View Sunroof With Power Shade —

If Equipped .......................... 223

▫ Opening Sunroof – Express ............. 224

▫ Venting Sunroof – Express .............. 224

▫ Closing Sunroof – Express .............. 225

▫ Closing Power Shade – Express .......... 225

▫ Sunroof And Power Shade Movement –

Manual ........................... 226

▫ Pinch Protect Feature ................. 226

▫ Pinch Protect Override ................ 226

▫ Pinch Protect Override Cancellation ....... 226

▫ Wind Buffeting ...................... 227

▫ Sunroof Maintenance ................. 227

▫ Ignition Off Operation ................. 227

▫ Sunroof Fully Closed .................. 227

䡵 Electrical Power Outlets ................. 227

䡵 Cupholders .......................... 231

▫ Front Seat Cupholders ................. 231

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93

䡵 Cargo Area Features ................... 238

▫ Rear Seat Cupholders ................. 233

䡵 Storage ............................. 234

▫ Glovebox Storage .................... 234

▫ Console Features .................... 235

▫ Door Storage ....................... 236

▫ Row Armrest Storage — If Equipped ...... 236

▫ Cargo Area — Vehicles Equipped With 60/40

Split-Folding Rear Seat ................ 237

▫ Trunk Mat — If Equipped .............. 238

䡵 Rear Window Features .................. 238

▫ Rear Window Defroster ................ 238

3

䡵 Load Leveling System — If Equipped ....... 239

䡵 Power Sunscreen — If Equipped ........... 239

94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

MIRRORS
Automatic Dimming Mirror

This mirror automatically adjusts for headlight glare
from vehicles behind you.

Automatic Dimming Mirror

CAUTION!

To avoid damage to the mirror during cleaning, never
spray any cleaning solution directly onto the mirror.
Apply the solution onto a clean cloth and wipe the
mirror clean.

Outside Mirrors

To receive maximum benefit, adjust the outside mirror(s)
to center on the adjacent lane of traffic and a slight
overlap of the view obtained from the inside mirror.

NOTE: The passenger side convex outside mirror will
give a much wider view to the rear, and especially of the
lane next to your vehicle.

WARNING!

Vehicles and other objects seen in the passenger side
convex mirror will look smaller and farther away
than they really are. Relying too much on your
passenger side convex mirror could cause you to
collide with another vehicle or other object. Use your
inside mirror when judging the size or distance of a
vehicle seen in the passenger side convex mirror.

Outside Mirrors Folding Feature — If Equipped

Some models have outside mirrors that are hinged. The
hinge allows the mirror to pivot forward and rearward to
resist damage. The hinge has three detent positions: full
forward, full rearward and normal.

Driver’s Automatic Dimming Mirror — If Equipped

The driver’s outside mirror will automatically adjust for
glare from vehicles behind you. This feature is controlled
by the inside automatic dimming mirror and can be

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95

turned on or off by pressing the button at the base of the
inside mirror. The mirror will automatically adjust for
headlight glare when the inside mirror adjusts.

NOTE: This feature is also available on the passenger’s
side when equipped with turn signal and approach
lighting.

Outside Mirrors With Turn Signal And Approach Lighting — If Equipped

Driver and passenger outside mirrors with turn signal
and approach lighting contain four LEDs, which are
located in the upper outer corner of each mirror.

Three of the LEDs are turn signal indicators, which flash
with the corresponding turn signal lights in the front and
rear of the vehicle. Turning on the Hazard Warning
flashers will also activate these LEDs.

The fourth (uppermost) LED supplies illuminated entry
lighting, which turns on in both mirrors when you use

3

96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

the Remote Keyless Entry (RKE) transmitter or open any
door. This LED shines outward to illuminate the front
and rear door handles. It also shines downward to
illuminate the area in front of the doors.

The Illuminated Entry lighting fades to off after about
30 seconds or it will fade to off immediately once the
ignition is placed into the RUN position.

vehicle is shifted out of the REVERSE position. Each
stored memory setting will have an associated Tilt Mir­rors in Reverse position.

NOTE: The Tilt Mirrors in Reverse feature can be turned
on and off using the Uconnect™ Touch System, refer to
“Uconnect™ Touch Settings” in “Understanding Your
Instrument Panel” for further information.

NOTE: The approach lighting will not function when
the shift lever is moved out of the PARK position.

Tilt Mirrors In Reverse — If Equipped

Tilt Mirrors in Reverse provides automatic outside mirror
positioning which will aid the driver ’s view of the
ground rearward of the front doors. The outside mirrors
will move slightly downward from the present position
when the vehicle is shifted into REVERSE. The outside
mirrors will then return to the original position when the

Power Mirrors

The power mirror controls are located on the driver-side
door trim panel.

Power Mirror Control

The power mirror controls consist of mirror select but­tons and a four-way mirror control switch. To adjust a
mirror, press the mirror select button for the mirror that
you want to adjust. Using the mirror control switch, press
on any of the four arrows for the direction that you want
the mirror to move.

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97

NOTE: A light in the select button will illuminate
indicating the mirror is activated and can be adjusted.

Power mirror preselected positions can be controlled by
the optional Memory Seat Feature. Refer to “Driver
Memory Seat” in “Understanding the Features of Your
Vehicle” for further information.

Power Folding Outside Mirrors — If Equipped

The switch for the power folding mirrors is located
between the power mirror switches L (left) and R (right).
Press the switch once and the mirrors will fold in,
pressing the switch a second time will return the mirrors
to the normal driving position.

NOTE: Pressing the power folding mirror switch for
more than four seconds, or if the vehicle speed is greater
than 5 mph (8 km/h) will disable the folding feature.

If the mirrors are in the folded position, and vehicle
speed is equal or greater than 5 mph (8 km/h), they will
automatically unfold.

3

98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Heated Mirrors — If Equipped

These mirrors are heated to melt frost or ice. This

feature is activated whenever you turn on the rear
window defroster. Refer to “Rear Window Features” in
“Understanding T he Features of Your Vehicle” for fur­ther information.

Illuminated Vanity Mirrors — If Equipped

An illuminated vanity mirror is located on the sun visor.
To use the mirror, rotate the sun visor downward and
swing the mirror cover upward. The light turns on
automatically. Closing the mirror cover turns off the light.

UCONNECT™ TOUCH 8.4/8.4 Nav
Uconnect™ Phone

Uconnect™ Phone is a voice-activated, hands-free, in­vehicle communications system. Uconnect™ Phone al­lows you to dial a phone number with your mobile
phone.

Uconnect Phone supports the following features:

Voice Activated Features:

Hands Free dialing via Voice (“Call John Smiths Mo-

•

bile” or, “Dial 248 555-1212”).

•

Hands Free text to speech listening of your incoming
SMS messages.

•

Hands Free text messaging (“Send a message to John
Smiths Mobile”).

•

Redialing last dialed numbers (“Redial”).

•

Calling Back the last incoming call number (“Call
Back”).

•

View Call logs on screen (“Show incoming calls”,
“Show Outgoing calls”, “Show missed Calls”, “Show
Recent Calls”).

•

Searching Contacts phone number (“Search for John
Smith Mobile”).
