chiliGREEN W251BUQ User Manual
V11.1.00
Preface
Notice
The company reserves the right to revise this publication or to change its contents without notice. Information
contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or
any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear
in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse)
of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted or reduced to any machine readable form without prior consent from the vendor, manufacturer or creators
of this publication, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered trademarks of their respective companies. They are mentioned for identification purposes only and are not intended
as an endorsement of that product or its manufacturer.
©January 2011
Trademarks
AMD® is a trademark of Advanced Micro Devices, Inc.
I
Preface
R&TTE Directive
This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Directive 1999/5/EC.
This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Luxembourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland,
United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slovenia.
EuP-Standby and Off Mode Power Consumption Statement:
The figures below note the power consumption of this computer in compliance with European Commission (EC)
regulations on power consumption in off mode or standby mode:
• Standby Mode < 2W
• Off Mode < 1W
II
Preface
CE Marking
This device has been tested to and conforms to the regulatory requirements of the European Union and has attained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies
to products regulated by certain European health, safety and environmental protection legislation. The CE Mark
is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his
product in the European market.
This product conforms to the essential requirements of the R&TTE directive 1999/5/EC in order to attain CE
Marking. A notified body has determined that this device has properly demonstrated that the requirements of the
directive have been met and has issued a favorable certificate of expert opinion. As such the device will bear the
notified body number 0560 after the CE mark.
The CE Marking is not a quality mark. Foremost, it refers to the safety rather than to the quality of a product.
Secondly, CE Marking is mandatory for the product it applies to, whereas most q uality marking s are vo lu ntary.
III
Preface
FCC Statement
(Federal Communications Commission)
You are cautioned that changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Re orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the service representative or an experienc ed radio/TV technician for help.
Operation is subject to the following two conditions:
1. This device may not cause interference.
And
2. This device must accept any interference, including interfer ence that may cause undesired operation of the
device.
IV
FCC RF Radiation Exposure Statement:
Warning
Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the
equipment.
If your purchase option includes both Wireless LAN and 3.75G modules, then the appropriate antennas will be installed.
Note that In order to comply with FCC RF exposure compliance requirements, the antenna must not be co-located or operate
in conjunction with any other antenna or transmitter.
Important Notice - 3.75G/HSPA & Bluetooth/Wireless LAN Modules
In order to comply with FCC regulations you should NOT operate the 3.75G/HSPA module and the Bluetooth/Wireless LAN
modules at the same time as this may disrupt radio frequency, and cause interference. When the 3.75G/HSPA module is
powered on, make sure that the Bluetooth/Wireless LAN modules are powered off.
1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator
and your body.
Preface
V
Preface
IMPORTANT SAFETY INSTRUCTIONS
Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury
to persons when using any electrical equipment:
1. Do not use this product near water, for example n ear a ba th tub, wash bowl, kitchen sink or laundry tu b, in a wet
basement or near a swimming pool.
2. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There
may be a remote risk of electrical shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special disposal instructions.
5. This product is intended to be supplied by a Listed Power Unit:
• Models A&B - Full Range AC/DC Adapter - AC Input 100 - 240V, 50 - 60Hz, DC Output 19V, 1.58A (30W) mini-
mum.
• Model C - Full Range AC/DC Adapter - AC Input 100 - 240V, 50 - 60Hz, DC Ou tput 19V, 3.42A or 18.5V, 3.5A
(65W) minimum.
This Computer’s Optical Device is a Laser Class 1 Product
VI
Preface
Instructions for Care and Operation
The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
Do not expose the computer
to any shock or vibration.
Do not place it on an unstable
surface.
Do not place anything heavy
on the computer.
2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-
ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.
Do not expose it to excessive
heat or direct sunlight.
Do not leave it in a place
where foreign matter or moisture may affect the system.
Don’t use or store the computer in a humid environment.
Do not place the computer on
any surface that will block the
Vents/Fan Intakes.
VII
Preface
3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other
strong magnetic fields. These can hinder proper performance and damage your data.
4. Follow the proper workin g procedu res for t he computer. Shut th e comp uter down pro per ly and don’t for ge t
to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.
Do not turn off the power
until you properly shut down
all programs.
Do not turn off any peripheral
devices when the computer is
on.
5. Take care when using peripheral devices.
Use only approved brands of
peripherals.
VIII
Do not disassemble the computer by yourself.
Unplug the power cord befor e
attaching peripheral devices.
Perform routine maintenance
on your computer.
Power Safety
Power Safety
Warning
Before you undertake
any upgrade procedures, make sure that
you have turned off the
power, and disconnected all peripherals
and cables (including
telephone lines). It is
advisable to also remove your battery in
order to prevent accidentally turning the
machine on.
The computer has specific power requirements:
• Only use a power adapter approved for use with this computer.
• Your AC/DC adapter may be designed for international travel but it still requires a
steady , uninterru pted power suppl y. If you are unsure of your local power specifications,
consult your service representative or local power company.
• The power adapter may have either a 2-prong or a 3-prong grounded plug. The third
prong is an important safety feature; do not defeat its purpose. If you do not have access
to a compatible outlet, have a qualified electrician install one.
• When you want to unplug the power cord, be sure to disconnect it by the plug head, not
by its wire.
• Make sure the socket and any extension cord(s) you use can support the total current
load of all the connected devices.
• Before cleaning the computer, make sure it is disconnected from any external power
supplies (i.e. AC/DC adapter or car adapter).
Do not plug in the power
cord if you are wet.
Do not use the power cord if
it is broken.
Do not place heavy objects
on the power cord.
Preface
IX
Preface
Polymer Battery Precautions
Note the following information which is specific to polymer batteries only, and where applicable, this overrides
the general battery precaution information overleaf.
• Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha-
nism and is not a cause for concern.
• Use proper handling procedures when using polymer batteries. Do not use polymer batteries in high ambient tempera-
ture environments, and do not store unused batteries for extended periods.
See also the general battery precautionary information overleaf for further information.
X
Battery Precautions
Battery Disposal & Caution
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life,
under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with
your local solid waste officials for details in your area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the
manufacturer. Discard used battery according to the manufacturer’s instructions.
• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.
• Do not remove any batteries from the computer while it is powered on.
• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even
if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly
result in fire.
• If you do not use the battery for an extended period, then remove the battery from the computer for storage.
• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pack repa ir or replacemen t to you r service repre sentati ve or qu al-
ified service personnel.
• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteri es
may explode or leak if exposed to fire, or improperly handled or discarded.
• Keep the battery away from metal appliances.
• Affix tape to the battery contacts before disposing of the battery.
• Do not touch the battery contacts with your hands or metal objects.
Preface
XI
Preface
Removal Warning
When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and
screw(s) before turning the computer on.
Cleaning
Do not apply cleaner directly to the computer; use a soft clean cloth.
Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.
Servicing
Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the
computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the
power supply. Then refer servicing to qualified service personnel under any of the following conditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to rain or other liquids.
• If the computer does not work normally when you follow the operating instructions.
• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your computer.
XII
Preface
Power Off Before Traveling
Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s)/outlet(s) to be blocked. To prev ent your
computer from overheating make sure nothing blocks the vent(s)/fan intake(s)/outlet(s) while the computer is in use.
Travel Considerations
Packing
As you get ready for your trip, run through this list to make sure the system is ready to go:
1. Check that the battery pack and any spares are fully charged.
2. Power off the computer and peripherals.
3. Close the display panel and make sure it’s latched.
4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.
5. The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,
check with your travel agent to see if you need any socket adapters.
6. Put the notebook in its carrying bag and secure it with the bag’s straps.
7. If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters
and/or cables.
8. Anticipate customs - Some jurisdictions may have import restrictions or req uire proof of ownersh ip for both hard -
ware and software. Make sure your documents are prepared.
XIII
Preface
On the Road
In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting,
keep these points in mind:
Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very
common. Don’t check it with normal luggage. Baggage handlers may not be sufficiently careful. Avoid knocking the computer against hard objects.
Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the computer, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and
disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note:
Some airports also scan luggage with these devices.
Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight.
These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make
sure it’s secure. Contents may shift and/or fall out when the compartment is opened.
Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies)
charged.
Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer.
Wait a few minutes before turning it on so that any moisture can evaporate.
XIV
Preface
Developing Good Work Habits
Developing good work habits is important if you need to work in fron t of the computer for long periods of time.
Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or
other joints. The following are some tips to reduce the strain:
• Adjust the height of the chair and/or desk so that the keyboard is at or slightly below the
level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.
• Your knees should be slightly higher than your hips. Place your feet flat on the floor or on
a footrest if necessary.
• Use a chair with a back and adjust it to support your lower back comfortably.
• Sit straight so that your knees, hips and elbows form approximately 90-degree angles when
you are working.
• Take periodic breaks if you are using the computer for long periods of time.
Remember to:
• Alter your posture frequently.
• Stretch and exercise your body several times a day.
• Take periodic breaks when you work at the computer for long periods of time. Frequent
and short breaks are better than fewer and longer breaks.
XV
Preface
Lighting
Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and
shoulders.
• Position the display to avoid glare or reflections from overhead lighting or outside sources of light.
• Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.
• Position the display directly in front of you at a comfortable viewing distance.
• Adjust the display-viewing angle to find the best position.
LCD Screen Care
To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for
an extended period of time) take the following precautions:
• Set the Windows Power Plans to turn the screen off after a few minutes of screen idle time.
• Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long).
• Rotate desktop background images every few days.
• Turn the monitor off when the system is not in use.
XVI
Contents
Notice .................................................................................I
EuP-Standby and Off Mode Power Consumption State-
ment: .................................................................................II
FCC Statement ................................................................IV
FCC RF Radiation Exposure Statement: ......................... V
Instructions for Care and Operation ..............................VII
Power Safety ...................................................................IX
Polymer Battery Precautions ........................................... X
Battery Precautions ...................................................... ...XI
Cleaning .........................................................................XII
Servicing ........................................................................XII
Travel Considerations .................................................. XIII
Quick Start Guide
Overview ........................................................................1-1
Advanced Users .............................................................1-2
Beginners and Not-So-Advanced Users ........................1-2
Warning Boxes ..............................................................1-2
Not Included ..................................................................1-3
System Startup ...............................................................1-4
System Software ........... .................................................1-5
Model Differences .........................................................1-6
System Map: LCD Panel Open - Model A Design I .....1-7
Preface
System Map: LCD Panel Open - Model A Design II ....1-8
System Map: LCD Panel Open - Models B & C ...........1-9
LED Indicators .............................................................1-10
Hot Key Buttons & Keyboard -
Model A Design I Only ...............................................1-11
Keyboard - Model A ....................................................1-12
Keyboard - Models B & C ...........................................1-13
Function/Hot Key Indicators .......................................1-14
System Map: Front & Left Views ................................1-15
System Map: Right & Rear Views ..............................1-16
System Map: Bottom View - Model A ........................1-18
System Map: Bottom View - Models B & C ...............1-19
Windows 7 Start Menu & Control Panel .....................1-20
Video Features ............................................................. 1-21
Power Options ........................................ .... ..................1-24
Features & Components
Overview ........................................................................2-1
Hard Disk Drive .............................................................2-2
Optical (CD/DVD) Device ............................................2-3
Loading Discs ................................................................2-3
Handling CDs or DVDs .................................................2-4
DVD Regional Codes ....................................................2-5
XVII
Preface
Multi-In-1 Card Reader .................................................2-6
Touchpad and Buttons/Mouse .......................................2-7
Gestures and Device Settings ........................................2-8
Audio Features .............................................................2-11
Setup for Audio Recording ..........................................2-12
Adding a Printer ...........................................................2-13
USB Printer ..................................................................2-13
Parallel Printer .............................................................2-13
Power Management
Overview ........................................................................3-1
The Power Sources ........................................................3-2
AC/DC Adapter .............................................................3-2
Battery ............................................................................3-2
Turning On the Computer ..............................................3-3
Power Plans ...................................................................3-4
Power-Saving States ......................................................3-6
Sleep ..............................................................................3-6
Hibernate ........................................................................3-7
Shut down ......................................................................3-7
Configuring the Power Buttons .....................................3-8
Resuming Operation ......................................................3-9
Energy Star Power Saving ...........................................3-10
Battery Information .....................................................3-11
Battery Power .............................................. .... .... ........3-11
Conserving Battery Power ...........................................3-12
Battery Life ..................................................................3-13
New Battery .................................................................3-13
Recharging the Battery with the AC/DC Adapter .......3-13
Proper handling of the Battery Pack ............................3-14
Battery FAQ .................................................................3-15
Drivers & Utilities
What to Install ........................................................... .....4-1
Module Driver Installation .............................................4 -1
Driver Installation ..........................................................4-2
Updating/Reinstalling Individual Drivers ......................4-4
User Account Control ....................................................4-4
Windows Security Message ...........................................4-4
New Hardware Found ....................................................4-5
Driver Installation Procedure ......................................... 4-5
Video (VGA) .................................................................4-5
LAN ...............................................................................4-6
CardReader ....................................................................4-6
TouchPad .......................................................................4-6
Hot Key ..........................................................................4-6
Audio .............................................................................4-6
Windows Experience Index ...........................................4-7
Optional Drivers ............................................................4-8
PC Camera Module ........................................................4-8
XVIII
Preface
Wireless LAN Module ...................................................4-8
3.75G/HSPA Module .....................................................4-8
BIOS Utilities
Overview ........................................................................5-1
The Setup Utility .................................................. .... ......5-2
Failing the POST ...........................................................5-3
Fatal Errors ....................................................................5-3
Non-Fatal Errors ............................................................5-3
Setup Screens .................................................................5-4
Main Menu .....................................................................5-5
Advanced Menu .............................................................5-7
Security Menu ..............................................................5-10
Boot Menu ...................................................................5-12
Exit Menu ....................................................................5-14
Upgrading The Computer
Overview ........................................................................6-1
When Not to Upgrade ....................................................6-2
Removing the Battery ....................................................6-3
Upgrading the Hard Disk Drive ..................................... 6-4
Upgrading the Optical (CD/DVD) Device ....................6-7
Removing the Optical Device for Model A Computers 6-8
Removing the Optical Device for Model B Computers ..610
Upgrading the System Memory (RAM) ......................6-11
Modules & Options
Overview ........................................................................7-1
PC Camera Module ........................................................7-2
PC Camera Driver Installation .......................................7-3
Wireless LAN Module .................................................7-10
802.11b/g/n Driver Installation ....................................7-11
Connecting to a Wireless Network in Windows 7 .......7-12
Windows Mobility Center ...........................................7-15
Bluetooth & Wireless LAN Combo Module ...............7-16
3rd Party Bluetooth Combo Driver Installation ...........7-17
Bluetooth & WLAN Combo Settings ..........................7-18
Bluetooth Networking Setup .......................................7-21
Bluetooth & WLAN Combo Module Configuration ...7-22
Standard Bluetooth Configuration in Windows 7 ........7-25
3.75G/HSPA Module ...................................................7-29
BandLuxe HSDPA Utility ...........................................7-33
BandLuxe HSDPA Utility Installation ........................7-33
BandLuxe HSDPA - Connection Manager ..................7-34
Creating a Profile .........................................................7-37
Choosing a Profile .......................................................7-40
Editing a Profile ...........................................................7-41
Text Messaging Service (SMS) ...................................7-42
Setting ..........................................................................7-45
XIX
Preface
Statistics & Information ...............................................7-51
Wireless Manager ................................................ .... ....7-52
Wireless Manager Installation .....................................7-52
Wireless Manager Application ....................................7-53
Profiles .........................................................................7-56
Settings ........................................................................7-60
Text Messaging Service (SMS) ...................................7-63
SMS Utility ..................................................................7-63
Sending a Text Message ..............................................7-65
Phonebook ...................................................................7-68
SMS Settings ........................................................... ....7-71
Troubleshooting
Overview ........................................................................8-1
Basic Hints and Tips ......................................................8-2
Backup and General Maintenance .................................8-3
Viruses ...........................................................................8-4
Upgrading and Adding New Hardware/Software ..........8-5
Problems and Possible Solutions ...................................8-7
Bluetooth Connection Problems ..................................8-13
Interface (Ports & Jacks)
Overview .......................................................................A-1
Notebook Ports and Jacks .............................................A-2
AMD Video Driver Controls
Video Driver Installation ..............................................B-1
Video (VGA) ................................................................B-1
Catalyst™ Control Center ............................................B-2
Catalyst™ Control Center Preferences .........................B-3
Display Devices & Options ..........................................B-7
Configuring an External Display In the CCC ...........B-8
Configuring an External Display In Windows 7 ....B-13
HDMI Audio Configuration .......................................B-17
Specifications
Processor ....................................................................... C-2
Core Logic ....................................................................C-2
Memory .........................................................................C-2
Display .......................................................................... C-2
Video .............................................................................C-2
BIOS .............................................................................C-3
Storage ..........................................................................C-3
Audio ............................................................................C-3
Keyboard & Pointing Device ........................................C-3
Interface ........................................................................C-3
Slots ..............................................................................C-3
Card Reader ..................................................................C-3
Communication .............................................................C-3
XX
Communication .............................................................C-4
Power Management ......................................................C-4
Power ............................................................................ C-4
Security ......................................................................... C-4
Indicators ...................................................................... C-4
Design Feature ..............................................................C-4
Operating System ..........................................................C-4
Environmental Spec ......................................................C-4
Dimensions & Weight ..................................................C-5
Preface
XXI
Preface
XXII
Quick Start Guide
Chapter 1: Quick Start Guide
Overview
This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the
computer and to getting your system started. The remainder of the manual covers the following:
• Chapter 2 A guide to using some of the main features of the computer e.g. the storage devices (hard disk,
optical device, Multi-in-1 card reader), TouchPad & Mouse, Audio & Printer.
• Chapter 3 The computer’s power saving options.
• Chapter 4 The installation of the drivers and utilities essential to the operation or improvement of some of the
computer’s subsystems.
• Chapter 5 An outline of the computer’s built-in software or BIOS (Basic Input Output System).
• Chapter 6 Instructions for upgrading your computer.
• Chapter 7 A quick guide to the computer’s PC Camera, Wireless LAN, Combo Bluetooth & WLAN and
3.75G/HSPA modules (some of which may be optional depending on your purchase configuration).
• Chapter 8 A troubleshooting guide.
• Appendix A Definitions of the interface, ports/jacks which allow your computer to communicate with external
devices.
• Appendix B Information on the AMD Video driver controls.
• Appendix C The computer’s specification.
1
Overview 1 - 1
1
Notes
Check the light colored
boxes with the mark
above to find detailed information about the computer’s features.
Quick Start Guide
Advanced Users
If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful
to refer to “What to Install” on page 4 - 1, “BIOS Utilities” on page 5 - 1 and “Upgrading The Computer” on
page 6 - 1 in the reminder of the User’s Manual. You may also find the notes marked with a
of interest to you.
Beginners and Not-So-Advanced Users
If you are new to computers (or do not have an advanced knowledge of them) then
the information contained in the Quick Start Guide should be enough to get you up
and running. Eventually you should try to look through all the documentation (more
detailed descriptions of the functions, setup and system controls are covered in the
remainder of the User’s Manual), but do not worry if you do not understand everything the first time. Keep this manual nearby and refer to it to learn as you go. You
may find it useful to refer to the notes marked with a
as indicated in the margin.
For a more detailed description of any of the interface ports and jacks see “Interface
(Ports & Jacks)” on page A - 1.
Warning Boxes
No matter what your level please pay careful attention to the warning and safety information indicated by the
symbol. Also please note the safety and handling instructions as indicated in the Preface.
1 - 2 Overview
Quick Start Guide
Drivers
If you are installing new system software, or are re-configuring your computer for a different system, you will need to install
the drivers listed in “Drivers & Utilities” on page 4 - 1. Drivers are programs which act as an interface between the computer and a hardware component e.g. a wireless network module. It is very important that you install the drivers in the order
listed. You will be unable to use most advanced controls until the necessary drivers and utilities are properly installed. If
your system hasn’t been properly configured (your service representative may have already done that for you); refer to
Chapter 4 for installation instructions.
Ports and Jacks
See “Notebook Ports and Jacks” on page A - 2 for a description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc.
Not Included
Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs)
have their own manuals, so please consult the appropriate manuals.
1
Overview 1 - 3
1
Shutdown
Note that you should always shut your computer down by choosing the
Shut Down command
from the bottom right of
the Start menu in Win-
dows. This will help
prevent hard disk or
system problems.
130°
Quick Start Guide
System Startup
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports.
4. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an
outlet, and connect the AC power cord to the AC/DC adapter.
5. Use one hand to raise the
hand (as illustrated in Figure 1 - 1 below) to support the base of the computer (Note: Never lift the computer by
the lid/LCD).
lid/LCD to a comfortable viewing angle (
Figure 1 - 1 - Opening the Lid/LCD & Computer with AC/DC Adapter Plugged-In
do not exceed 130 degrees
);
use the other
1 - 4 System Startup
Quick Start Guide
System Software
Your computer may already come with system software pre-installed. Where this is not the case, or where you
are re-configuring your computer for a different system, you will find that this manual refers to the Windows 7
operating system.
1
System Startup 1 - 5
1
Quick Start Guide
Model Differences
This notebook series includes three different models that vary slightly in design style, color and general appearance (Model A has two distinct design styles as pictured on the following pages). Note that though your computer may look slightly different from that pictured throughout this manual, all ports, jacks and general functions
are the same for all the design styles (see “Specifications” on page C - 1 for further details of any differences
between the models).
Feature Model A Model B Model C
Processor
Display Type
Supported
Video
AC/DC Adapter
Battery
Dimensions &
Weight
14.0” / 35.56cm HD (1366 * 768), 16:9
Removable 3 Cell Smart Lithium Ion Battery Pack 24.42WH
340mm (w) * 238mm (d)
* 13.9 - 31.8mm (h)
2.05 kg with 3 Cell Battery & ODD
1 - 6 System Startup
Panel
Processor Types (see “Processor” on page C - 2)
15.6” / 39.62cm HD (1366 * 768), 16:9
Panel
ATI Integrated APU AMD Mobility Radeon™ HD6370M
30 Watts AC/DC Adapter 65 Watts AC/DC Adapter
374mm (w) * 250mm (d)
* 14.3 - 34.1mm (h)
2.25 kg with 3 Cell Battery & ODD
15.6” / 39.62cm HD (1366 * 768) / HD+
(1600 * 900), 16:9 Panel
Removable 6 Cell Smart Lithium Ion
Battery Pack 48.84WH
374mm (w) * 250mm (d)
* 14.3 - 34.1mm (h)
2.3 kg with 6 Cell Battery & ODD
Table 1 - 1 - Model Differences
Loading...
