chiliGREEN P150HM User Manual

V10.1.10

Preface

Notice

The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication. This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted or reduced to any machine readable form without prior consent from the vendor, manufacturer or creators of this publication, except for copies kept by the user for backup purposes. Brand and product names mentioned in this publication may or may not be copyrights and/or registered trademarks of their respective companies. They are mentioned for identification purposes only and are not intended as an endorsement of that product or its manufacturer. ©December 2010

Trademarks

Intel and Intel Core are trademarks/registered trademarks of Intel Corporation.

Preface

R&TTE Directive

This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Directive 1999/5/EC.

This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Luxembourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slovenia.

EuP-Standby and Off Mode Power Consumption Statement:

The figures below note the power consumption of this computer in compliance with European Commission (EC) regulations on power consumption in off mode or standby mode:

• Standby Mode < 2W

• Off Mode < 1W

Preface

CE Marking

This device has been tested to and conforms to the regulatory requirements of the European Union and has attained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation. The CE Mark is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his product in the European market.

This product conforms to the essential requirements of the R&TTE directive 1999/5/EC in order to attain CE Marking. A notified body has determined that this device has properly demonstrated that the requirements of the directive have been met and has issued a favorable certificate of expert opinion. As such the device will bear the notified body number 0560 after the CE mark.

The CE Marking is not a quality mark. Foremost, it refers to the safety rather than to the quality of a product. Secondly, CE Marking is mandatory for the product it applies to, whereas most q uality marking s are vo lu ntary.

III

Preface

FCC Statement

(Federal Communications Commission)

You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Re orient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the service representative or an experienc ed radio/TV technician for help.

Operation is subject to the following two conditions:

1. This device may not cause interference. And

2. This device must accept any interference, including interfer ence that may cause undesired operation of the

device.

Preface



Warning

Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the equipment.

FCC RF Radiation Exposure Statement:

1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This

equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

Preface

IMPORTANT SAFETY INSTRUCTIONS

Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment:

1. Do not use this product near water, for example n ear a ba th tub, wash bowl, kitchen sink or laundry tu b, in a wet

basement or near a swimming pool.

2. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There

may be a remote risk of electrical shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may

explode. Check with local codes for possible special disposal instructions.

5. This product is intended to be supplied by a Listed Power Unit:

• Model A - Full Range AC/DC Adapter - AC Input 100 - 240V, 50 - 60Hz, DC Output 19V, 9.47A (180W) minimum.

• Model B - Full Range AC/DC Adapter - AC Input 100 - 240V, 50 - 60Hz, DC Output 19V, 6.3A (120W) minimum.

• Model C - Full Range AC/DC Adapter - AC Input 100 - 240V, 50 - 60Hz, DC Output 19V, 11.57A (220W) minimum.

This Computer’s Optical Device is a Laser Class 1 Product

Preface

Instructions for Care and Operation

The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:

1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.

Do not expose the computer to any shock or vibration.

Do not place it on an unstable surface.

Do not place anything heavy on the computer.

2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-

ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.

Do not expose it to excessive

heat or direct sunlight.

Do not leave it in a place where

foreign matter or moisture may

affect the system.

Don’t use or store the computer

in a humid environment.

Do not place the computer on

any surface that will block the

Vents/Fan Intakes.

VII

Preface

3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other

strong magnetic fields. These can hinder proper performance and damage your data.

4. Follow the proper workin g procedu res for t he computer. Shut the computer down properly and don’t forget

to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.

Do not turn off the power until you properly shut down all programs.

Do not turn off any peripheral devices when the computer is on.

5. Take care when using peripheral devices.

Use only approved brands of peripherals.

VIII

Do not disassemble the computer by yourself.

Unplug the power cord befor e attaching peripheral devices.

Perform routine maintenance on your computer.

Power Safety



Power Safety

Warning

Before you undertake any upgrade procedures, make sure that you have turned off the power, and disconnected all peripherals and cables (including telephone lines). It is advisable to also remove your battery in order to prevent accidentally turning the machine on.

The computer has specific power requirements:

• Only use a power adapter approved for use with this computer.

• Your AC/DC adapter may be designed for international travel but it still requires a

steady , uninterru pted power suppl y. If you are unsure of your local power specifications, consult your service representative or local power company.

• The power adapter may have either a 2-prong or a 3-prong grounded plug. The third

prong is an important safety feature; do not defeat its purpose. If you do not have access to a compatible outlet, have a qualified electrician install one.

• When you want to unplug the power cord, be sure to disconnect it by the plug head, not

by its wire.

• Make sure the socket and any extension cord(s) you use can support the total current

load of all the connected devices.

• Before cleaning the computer, make sure it is disconnected from any external power

supplies (i.e. AC/DC adapter or car adapter).

Do not plug in the power cord if you are wet.

Do not use the power cord if it is broken.

Do not place heavy objects on the power cord.

Preface

Polymer Battery Precautions

Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf.

• Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha-

nism and is not a cause for concern.

• Use proper handling procedures when using polymer batteries. Do not use polymer batteries in high ambient tempera-

ture environments, and do not store unused batteries for extended periods.

See also the general battery precautionary information overleaf for further information.

General Battery Precautions



Battery Disposal & Caution

The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life, under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with your local solid waste officials for details in your area for recycling options or proper disposal.

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the manufacturer. Discard used battery according to the manufacturer’s instructions.

• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.

• Do not remove any batteries from the computer while it is powered on.

• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even

if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

• If you do not use the battery for an extended period, then remove the battery from the computer for storage.

• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.

• Do not try to repair a battery pack. Refer any battery pack repa ir or replacemen t to you r service repre sentati ve or qu al-

ified service personnel.

• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries

may explode or leak if exposed to fire, or improperly handled or discarded.

• Keep the battery away from metal appliances.

• Affix tape to the battery contacts before disposing of the battery.

• Do not touch the battery contacts with your hands or metal objects.

Preface



Removal Warning

When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and screw(s) before turning the computer on.

Cleaning

Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.

Servicing

Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply. Then refer servicing to qualified service personnel under any of the following conditions:

• When the power cord or AC/DC adapter is damaged or frayed.

• If the computer has been exposed to rain or other liquids.

• If the computer does not work normally when you follow the operating instructions.

• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).

• If there is an unusual odor, heat or smoke coming from your computer.

XII

Preface



Power Off Before Traveling

Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a notebook which is powered on in a travel bag may cause the Vents/Fan Intakes to be blocked. To pre vent your computer from overheating make sure nothing blocks the Vent/Fan Intakes while the computer is in use.

Travel Considerations

Packing

As you get ready for your trip, run through this list to make sure the system is ready to go:

1. Check that the battery pack and any spares are fully charged.

2. Power off the computer and peripherals.

3. Close the display panel and make sure it’s latched.

4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.

5. The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,

check with your travel agent to see if you need any socket adapters.

6. Put the notebook in its carrying bag and secure it with the bag’s straps.

7. If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters

and/or cables.

8. Anticipate customs - Some jurisdictions may have import restrictions or req uire proof of ownersh ip for both hard -

ware and software. Make sure your “papers” are handy.

XIII

Preface

On the Road

In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind:

Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common. Don’t check it with “normal” luggage. Baggage handlers may not be sufficiently careful. Avoid knocking the computer against hard objects.

Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the computer, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note: Some airports also scan luggage with these devices.

Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight. These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make sure it’s secure. Contents may shift and/or fall out when the compartment is opened.

Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies) charged.

Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer. Wait a few minutes before turning it on so that any moisture can evaporate.

XIV

Preface

Developing Good Work Habits

Developing good work habits is important if you need to work in fron t of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints. The following are some tips to reduce the strain:

• Adjust the height of the chair and/or desk so that the keyboard is at or slightly below the

level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.

• Your knees should be slightly higher than your hips. Place your feet flat on the floor or on

a footrest if necessary.

• Use a chair with a back and adjust it to support your lower back comfortably.

• Sit straight so that your knees, hips and elbows form approximately 90-degree angles

when you are working.

• Take periodic breaks if you are using the computer for long periods of time.

Remember to:

• Alter your posture frequently.

• Stretch and exercise your body several times a day.

• Take periodic breaks when you work at the computer for long periods of time. Frequent

and short breaks are better than fewer and longer breaks.

Preface

Lighting

Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue.

• Position the display to avoid glare or reflections from overhead lighting or outside sources of light.

• Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

• Position the display directly in front of you at a comfortable viewing distance.

• Adjust the display-viewing angle to find the best position.

LCD Screen Care

To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for an extended period of time) take the following precautions:

• Set the Windows Power Plans to turn the screen off after a few minutes of screen idle time.

• Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long).

• Rotate desktop background images every few days.

• Turn the monitor off when the system is not in use.

Cable TV Safety

If you have included a TV Tuner in your purchase option then pay careful attention to the following:

• Make sure that your CATV system installer has connected the Coaxial cable shield to the grounding system of the

building, as close to the point of cable entry as practical.

• This reminder is provided to call the CATV system installer’s attention to Article 820-93 of the NEC (Section 54, Part

I of the Canadian Electrical Code).

• The TV antenna supplied with any TV Tuner module is intended for indoor use only. Please do not use your TV Tuner

module outdoors.

XVI

Contents

Notice .................................................................................I

EuP-Standby and Off Mode Power Consumption State-

ment: .................................................................................II

FCC Statement ................................................................IV

FCC RF Radiation Exposure Statement: ......................... V

Instructions for Care and Operation ..............................VII

Power Safety ...................................................................IX

Polymer Battery Precautions ........................................... X

General Battery Precautions ...........................................XI

Cleaning .........................................................................XII

Servicing ........................................................................XII

Travel Considerations .................................................. XIII

Quick Start Guide

Overview ........................................................................1-1

Advanced Users .............................................................1-2

Beginners and Not-So-Advanced Users ........................1-2

Warning Boxes ..............................................................1-2

Not Included ..................................................................1-3

System Software ............................................................1-4

Model Differences .........................................................1-5

System Startup ...............................................................1-6

System Map: LCD Panel Open - Models A & B ...........1-7

Preface

System Map: LCD Panel Open - Model C ....................1-8

LED Indicators ...............................................................1-9

Keyboard ......................................................................1-10

Function Keys & Visual Indicators .............................1-11

System Map: Front & Rear Views ...............................1-12

System Map: Right View .............................................1-13

System Map: Left View ...............................................1-14

System Map: Bottom View - Models A & B ...............1-15

System Map: Bottom View - Model C ........................1-16

Windows 7 Start Menu & Control Panel .....................1-17

Video Features .............................................................1-18

Screen Resolution ........................................................1-19

NVIDIA Control Panel ................................................1-20

Power Options ........................................ .... ..................1-21

Storage Devices, Mouse, Audio & Printer

Overview ........................................................................2-1

Hard Disk Drive .............................................................2-2

Optical Device ...............................................................2-3

Loading Discs ................................................................2-3

Handling CDs or DVDs .................................................2-4

DVD Regional Codes ....................................................2-5

XVII

Preface

Multi-in-1 Card Reader ..................................................2-6

Audio Features ...............................................................2-7

Setup for Audio Recording ............................................2-8

Setup for 5.1 or 7.1 Surround Sound .............................2-9

Audio Notes for Model C Computers (Fn + 5) ...........2-11

TouchPad and Buttons/Mouse .....................................2-12

Gestures and Device Settings ......................................2-14

Adding a Printer ...........................................................2-17

USB Printer ..................................................................2-17

Install Instructions: ......................................................2-17

Parallel Printer .............................................................2-17

Power Management

Overview ........................................................................3-1

The Power Sources ........................................................3-2

AC/DC Adapter .............................................................3-2

Battery ............................................................................3-2

Turning On the Computer ..............................................3-3

Power Plans ...................................................................3-4

Power-Saving States ......................................................3-6

Sleep ..............................................................................3-6

Hibernate ........................................................................3-7

Shut down ......................................................................3-7

Configuring the Power Buttons .....................................3-8

Resuming Operation ......................................................3-9

Battery Information ......................................................3-10

Conserving Battery Power ...........................................3-11

Battery Life ..................................................................3-12

New Battery .................................................................3-12

Recharging the Battery with the AC/DC Adapter .......3-12

Proper handling of the Battery Pack ............................3-13

Battery FAQ .................................................................3-14

Drivers & Utilities

What to Install ........................................................... .....4-1

Module Driver Installation .............................................4 -1

Driver Installation ..........................................................4-2

Manual Driver Installation ............................................. 4 -4

Updating/Reinstalling Individual Drivers ......................4-4

User Account Control ....................................................4-5

Windows Security Message ...........................................4-5

New Hardware Found ....................................................4-5

Driver Installation Procedure ......................................... 4-6

Chipset ...........................................................................4-6

Video (VGA) .................................................................4-6

LAN ...............................................................................4-6

Card Reader ...................................................................4-7

TouchPad .......................................................................4-7

Hot Key ..........................................................................4-7

USB 3.0 ..........................................................................4-7

XVIII

Preface

MEI Driver .....................................................................4-7

Audio .............................................................................4-7

Windows Experience Index ...........................................4-8

Optional Drivers ............................................................4-9

PC Camera ...................................................................4-10

Wireless LAN ...................................... ........................4-10

Fingerprint Reader Module ..........................................4-10

3.75G/HSPA Module (Models A & B Only) ..............4-10

Consumer Infrared

(for TV Tuner Remote - Model C Only) .....................4-10

THX TruStudio AP ......................................................4-10

Intel Rapid Storage Technology Driver .......................4-10

BIOS Utilities

Overview ........................................................................5-1

The Power-On Self Test (POST) ................................... 5-2

Failing the POST ...........................................................5-3

Fatal Errors ....................................................................5-3

Non-Fatal Errors ............................................................5-3

The Setup Utility .................................................. ..........5-4

Entering Setup ...............................................................5-4

Setup Screens .................................................................5-5

Main Menu .....................................................................5-6

System Time & Date (Main Menu) ...............................5-6

SATA Port # (Main Menu) ............................................5-7

System/Extended Memory: (Main Menu) .....................5-7

MB Series / BIOS Revision / KBC/ EC firmware Revision / VGA Card etc. (Main Menu) ..5-7

Advanced Menu .............................................................5-8

Advanced Chipset Control (Advanced Menu) ...............5-8

Bluetooth Power Setting (Advanced Menu >

Advanced Chipset Control) ...........................................5 -9

SATA Mode (Advanced Menu) ....................................5-9

Legacy USB Support: (Advanced Menu) ......................5-9

Boot Logo: (Advanced Menu) .....................................5-10

Power On Boot Beep (Advanced Menu) .....................5-10

Battery Low Alarm Beep: (Advanced Menu) ..............5-10

Security Menu ..............................................................5-11

Set Supervisor Password (Security Menu) ..................5-11

Boot Menu ...................................................................5-13

Boot Sequence (Boot Menu) ........................................5-14

Exit Menu ....................................................................5-15

Upgrading The Computer

Overview ........................................................................6-1

When Not to Upgrade ....................................................6-2

Removing the Battery ....................................................6-3

Upgrading the Optical Device (Model A/B) ..................6-4

Upgrading the Optical Device (Model C) ......................6-5

Upgrading the Hard Disk Drive(s) .................................6-6

XIX

Preface

Upgrading the System Memory (RAM) ......................6-14

Replacing the Primary System Memory Modules .......6-15

Modules

Overview ........................................................................7-1

Setting Up SATA RAID Mode ......................................7-2

AHCI Mode ...................................................................7-2

RAID ..............................................................................7-2

Intel® Rapid Storage Technology Application .............7-2

SATA RAID Setup Procedure (BIOS) ..........................7-4

RAID Setup (Intel Matrix) .............................................7-5

Intel Rapid Storage Technology ....................................7-8

IRST Driver Installation ................................................7-8

RAID Volume Data Verification and Repair ..............7-11

Replacing and Reverting Recovery and

Master Volumes ...........................................................7-11

PC Camera Module ......................................................7-14

PC Camera Driver Installation .....................................7-15

PC Camera Audio Setup ..............................................7-16

Wireless LAN Module .................................................7-22

Intel® Wi-Fi Link Series Driver Installation ...............7-23

802.11b/g/n Driver Installation ....................................7-23

Connecting to a Wireless Network in Windows 7 .......7-24

Intel® My WiFi Configuration ....................................7-27

Intel WLAN & Bluetooth Combo Module

High-Speed Data Transfer Configuration ....................7-39

Windows Mobility Center ...........................................7-41

Fingerprint Reader Module ..........................................7-42

Fingerprint Reader Driver Installation .........................7-43

User Enrollment ...........................................................7-44

Fingerprint Control Center Features ............................7-47

Bluetooth Module ........................................................7-48

3rd Party Bluetooth Combo Driver Installation ...........7-49

3rd Party Bluetooth & WLAN Combo Settings ..........7-50

3rd Party Bluetooth Networking Setup ........................7-53

3rd Party Bluetooth & WLAN Combo

Module Configuration ..................................................7-54

Intel Bluetooth Combo Driver Installation ..................7-57

Standard Bluetooth Configuration in Windows 7 ........7-58

3.75G/HSPA Module ...................................................7-62

3.75G/HSPA Module USIM Card Installation ............7-63

BandLuxe HSDPA Utility ...........................................7-66

BandLuxe HSDPA Utility Installation ........................7-66

BandLuxe HSDPA - Connection Manager ..................7-67

Creating a Profile .........................................................7-70

Choosing a Profile .......................................................7-73

Editing a Profile ...........................................................7-74

Text Messaging Service (SMS) ...................................7-75

Setting ..........................................................................7-78

Statistics & Information ...............................................7-84

Preface

TV Tuner Module ........................................................7-85

Consumer Infrared Driver ............................................7-86

Digital TV Broadcast Signal ........................................7-87

TV Recording and Power Plans ................................... 7-87

Remote Control Unit ....................................................7-87

THX TruStudio Pro Audio ..........................................7-88

THX TruStudio AP Installation ...................................7-88

THX TruStudio Pro Activation ...................................7-89

THX TruStudio Pro Application .................................7-89

Troubleshooting

Overview ........................................................................8-1

Basic Hints and Tips ......................................................8-2

Backup and General Maintenance .................................8-3

Viruses ...........................................................................8-4

Upgrading and Adding New Hardware/Software ..........8-5

Problems & Possible Solutions ...................................... 8-7

Bluetooth Connection Problems ..................................8-13

Intel® Centrino Advanced 6230 WLAN &

Bluetooth V3.0+HS Combo Modules .........................8-17

Installing Windows 7 (pre Service Pack 1) for

RAID Systems with Advanced Format Disks .............8-18

Interface (Ports & Jacks)

Overview .......................................................................A-1

Ports and Jacks ..............................................................A-2

Card Reader ..................................................................A-2

Cable (CATV) Antenna Jack (Model C Only) .............A-2

Consumer Infrared Transceiver ....................................A-2

DC-In Jack ..................................... ...............................A-2

DVI-Out Port ................................................................A-2

e-SATA / USB 2.0 Combo Port ....................................A-3

HDMI-Out Port .............................................................A-3

Headphone-Out Jack .....................................................A-3

Line-In Jack ..................................................................A-3

Microphone-In Jack ......................................................A-3

Mini-IEEE 1394a Port ..................................................A-4

RJ-45 LAN Jack ............................................................A-4

S/PDIF-Out Jack ...........................................................A-4

Security Lock Slot ........................................................A-4

USB Ports .....................................................................A-5

NVIDIA Video Driver Controls

NVIDIA Video Driver Installation ...............................B-1

NVIDIA Control Panel (Win 7) ....................................B-2

Display Devices ............................................................B-5

Display Modes ..............................................................B-6

Attaching Other Displays (Win 7) ..............................B-10

XXI

Preface

Specifications

Processor .......................................................................C-2

Core Logic ................................................... .... .... .........C-2

Memory .........................................................................C-2

Display .......................................................................... C-2

Video Adapter Options .................................................C-3

BIOS ............................................................................. C-3

Storage .......................................................................... C-3

Audio ............................................................................C-3

Keyboard & Pointing Device ........................................C-4

Interface ........................................................................ C-4

Slots ..............................................................................C-4

Card Reader ..................................................... .............C-4

Communication .............................................................C-4

Communication .............................................................C-5

Security ......................................................................... C-5

Operating System ..........................................................C-5

Power Management ......................................................C-5

Power ............................................................................ C-5

Environmental Spec ......................................................C-5

Physical Dimensions & Weight .................................... C-5

XXII

Quick Start Guide

Chapter 1: Quick Start Guide

Overview

This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following:

• Chapter 2 A guide to using some of the main features of the computer e.g. the storage devices (hard disk,

optical device, card reader), TouchPad & Mouse, Audio Features & Printer.

• Chapter 3 The computer’s power management options.

• Chapter 4 The installation of the drivers and utilities essential to the operation or improvement of some of the

computer’s subsystems.

• Chapter 5 An outline of the computer’s built-in software or BIOS (Basic Input Output System).

• Chapter 6 Instructions for upgrading your computer.

• Chapter 7 A quick guide to the computer’s PC Camera, Wireless LAN, Fingerprint, Bluetooth & WLAN

Combo and 3.75G modules (some of which may be optional depending on your purchase configu- ration).

• Chapter 8 A troubleshooting guide.

• Appendix A Definitions of the interface, ports/jacks which allow your computer to communicate with external

devices.

• Appendix B Information on the NVIDIA Video driver controls.

• Appendix C The computer’s specification.

Overview 1 - 1



Notes

Check the light colored boxes with the mark above to find detailed information about the computer’s features.

Quick Start Guide

Advanced Users

If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “Drivers & Utilities” on page 4 - 1, “BIOS Utilities” on page 5 - 1 and “Upgrading The Computer”

on page 6 - 1 in the User’s Manual. You may also find the notes marked with a

 of interest to you.

Beginners and Not-So-Advanced Users

If you are new to computers (or do not have an advanced knowledge of them) then the information contained in this Quick Start Guide should be enough to get you up and running. Eventually you should try to look through all the documentation (more detailed descriptions of the functions, setup and system controls are covered in the remainder of the User’s Manual), but do not worry if you do not understand everything the first time. Keep this manual nearby and refer to it to learn as you go. You may find it useful to refer to the notes marked with a

 as indicated in the margin.

For a more detailed description of any of the interface ports and jacks see “Interface

(Ports & Jacks)” on page A - 1.

Warning Boxes

No matter what your level please pay careful attention to the warning and safety information indicated by the

 symbol. Also please note the safety and handling instructions as indicated in the Preface.

1 - 2 Overview

Quick Start Guide



Drivers

If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the appropriate drivers. Drivers are programs which act as an interface between the computer and a hardware component e.g. a wireless network module. It is very important that you install the drivers in the order listed in Table 4 - 1, on page 4

- 3. You will be unable to use most advanced controls until the necessary drivers and utilities are properly installed. If your

system hasn’t been properly configured (your service representative may have already done that for you), refer to “Drivers

& Utilities” on page 4 - 1 for installation instructions.

Ports and Jacks

See “Ports and Jacks” on page A - 2 for a description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc.

Not Included

Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.

Overview 1 - 3

Quick Start Guide

System Software

Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the Windows 7 operating system is supported.

Note: In order to run Windows 7 without limitations or decreased performance, your computer requires a mini- mum 1GB of system memory (RAM).

1 - 4 Overview

Quick Start Guide

Model Differences

This notebook series includes three different model types that mainly differ as indicated in the table below. Note that your model may appear slightly different from those pictured in this manual.

Feature Model A Model B Model C

Case Color

CPU Type

Supported

Core Logic

Display Type

Supported

Video Cards

Supported

Power

Supply

15.6" (39.62cm) FHD (1920 * 1080)

Full Range AC adapter 180W, AC in

Rubber Style Paint Standard Paint

See “Specifications” on page A - 1 for more details

Intel® HM65 Chipset Intel® HM67 Chipset

15.6" (39.62cm) HD+ (1600 * 900)

16:9 Panel

See “Specifications” on page A - 1 for more details

100~240V, 50~60Hz, DC output

19V, 9.47A

Full Range AC adapter 120W, AC

in 100~240V, 50~60Hz, DC output

16:9 Panel

19V, 6.3A

17.3" (43.94cm) FHD (1920 * 1080) 16:9 Panel

Full Range AC adapter 220W, AC

in 100~240V, 50~60Hz, DC output

19V, 11.57A

Table 1 - 1 - Model Differences

See “Specifications” on page A - 1 for more details (note that only Model C supports RAID level 0/1).

Model Differences 1 - 5



Shutdown

Note that you should always shut your computer down by choosing the Shut Down command from the Start menu in Windows 7. This will help prevent hard disk or system problems.

135

Quick Start Guide

System Startup

1. Remove all packing materials, and place the comput er on a stable surfac e.

2. Securely attach any peripherals you want to use with the n otebook (e.g. keyboard and mouse) to their ports.

3. Attach the AC/DC adapter to the DC-In jack at th e rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.

4. Use one hand to raise the the other hand (as illustrated in Figure 1 - 1 below) to support the base of the computer (Note: Never lif t the computer by the lid/LCD).

5. Raise the lid/LCD to a comfortable viewing an gle, a nd pre ss the power bu tton on th e top left of the computer for

about 2 - 3 seconds to turn the computer “on” (note that the power LED on the front of the computer will turn from orange to green when the computer powers on).

Figure 1 - 1 - Computer with AC/DC Adapter Plugged-In/Opening the Lid/LCD

1 - 6 System Startup

lid/LCD to a comfortable viewing angle (it is preferable not to exceed 135 degrees);

use

+ 238 hidden pages
