CHAPTER 1

Preface

1-2

Preface

Table of Content

Preface

Table of Content............................................................................................................................ 1-2

Regulations Information............................................................................................................... 1-5

FCC-B Radio Frequency Interference Statement .................................................................... 1-5

FCC Conditions ........................................................................................................................ 1-6

CE Conformity .......................................................................................................................... 1-6

Safety Instructions........................................................................................................................ 1-7

Safety Guideline for Using Lithium Battery ..............................................................................1-11

WEEE Statement ......................................................................................................................... 1-15

Optical Drive Device Notice ....................................................................................................... 1-22

Trademarks.................................................................................................................................. 1-22

Reversion History ....................................................................................................................... 1-22

Introductions

Manual Map ................................................................................................................................... 2-2

Unpacking...................................................................................................................................... 2-3

Specification.................................................................................................................................. 2-4

Product Overview ......................................................................................................................... 2-8

Top-Open View ......................................................................................................................... 2-8

Front Side View ...................................................................................................................... 2-14

1-3

Preface

Right Side View ...................................................................................................................... 2-16

Left Side View......................................................................................................................... 2-18

Rear Side View....................................................................................................................... 2-19

Bottom Side View ................................................................................................................... 2-21

Getting Started

Exclusive Functions ..................................................................................................................... 3-2

NVIDIA OC Tool........................................................................................................................ 3-2

SLM Setting .............................................................................................................................. 3-4

Power Management ...................................................................................................................... 3-5

Connecting the AC Power ........................................................................................................ 3-5

Using the Battery Power........................................................................................................... 3-7

ECO Power Saving Function.................................................................................................. 3-13

Power Management in Windows OS ..................................................................................... 3-15

Energy Saving Tips................................................................................................................. 3-17

Basic Operations ........................................................................................................................ 3-18

Safety and Comfort Tips.........................................................................................................3-18

Having a Good Work Habit..................................................................................................... 3-19

Knowing the Keyboard ........................................................................................................... 3-20

Knowing the Touchpad........................................................................................................... 3-27

About Hard Disk Drive ............................................................................................................ 3-30

Using the Optical Storage Device........................................................................................... 3-31

Connecting the External Devices.............................................................................................. 3-34

1-4

Preface

Connecting the Peripheral Devices ........................................................................................ 3-34

Connecting the Communication Devices ............................................................................... 3-38

Components Replacement and Upgrade ................................................................................. 3-41

BIOS Setup

About BIOS Setup......................................................................................................................... 4-2

When to Use BIOS Setup......................................................................................................... 4-2

How to Run BIOS Setup...........................................................................................................4-2

Control Keys............................................................................................................................. 4-3

BIOS Setup Menu.......................................................................................................................... 4-4

Main menu................................................................................................................................ 4-5

Advanced menu........................................................................................................................ 4-7

Boot menu ................................................................................................................................ 4-9

Security menu......................................................................................................................... 4-10

Save & Exit menu ................................................................................................................... 4-12

RAID Level 0 Introduction .......................................................................................................... 4-13

RAID0 Setup .......................................................................................................................... 4-14

1-5

Preface

Regulations Information

FCC-B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and

radiates radio frequency energy, and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and receiver.

 Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

 Consult the dealer or an experienced radio TV technician for help.

NOTE

 The changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

1-6

Preface

 Shield interface cables and AC power cord, if any, must be used in order to comply with the

emission limits.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

 This device may not cause harmful interference.

 This device must accept any interference received, including interference that may cause

undesired operation.

CE Conformity

This device is in compliance with the essential safety requirements and other relevant

provisions set out in the European Directive.

1-7

Preface

Safety Instructions

Read the safety instructions carefully and thoroughly.

All cautions and warnings on the equipment or user’s manual should be noted.

Keep the User’s Guide that comes with the package for future reference.

Keep this equipment away from humidity and high temperature.

Lay this equipment on a stable surface before setting it up.

The openings on the enclosure are used for air convection and to prevent the

equipment from overheating. Do not cover the openings.

 Do not leave the equipment in an unconditioned environment with a storage

temperature above 60°C (140°F) or below 0°C (32°F), which may damage the

equipment.

 The unit should be operate under maximum ambient temperature of 40°C (120°F).

1-8

Preface

 Make sure the power voltage is within safety range and has been adjusted

properly to the value of 100~240V before connecting the equipment to the

power outlet.

 Always unplug the AC power cord before installing any add-on card or module

to the equipment.

 Always disconnect the AC power cord or uninstall the battery pack or switch off

the wall socket if the equipment would be left unused for a certain time to

achieve zero energy consumption.

Never pour liquid into the opening that could damage the equipment or cause an

electrical shock.

Place the power cord in a way that people are unlikely to step on it. Do not place

anything on top of the power cord.

Always keep the strong magnetic or electrical objects away from the equipment.

1-9

Preface

 When installing the coaxial cable to the TV Tuner, it is necessary to ensure that

the metal shield is reliable connected to protective earthing system of the

building.

 Cable distribution system should be grounded (earthed) in accordance with

ANSI/NFPA 70, the National Electrical Code (NEC), in particular Section

820.93, Grounding of Outer Conductive Shield of a Coaxial Cable.

 To prevent explosion caused by improper battery replacement, use the same or

equivalent type of battery recommended by the manufacturer only.

 Always keep the battery in a safe place.

If any of the following situations arises, get the equipment checked by a service

personnel:

 The power cord or plug is damaged.

 Liquid has penetrated into the equipment.

 The equipment has been exposed to moisture.

 The equipment has not worked well or you can not get it work according to

User’s Manual.

 The equipment was dropped and damaged.

 The equipment has obvious signs of breakage.

1-10

Preface

Green Product Features

 Reduced energy consumption during use and stand-by

 Limited use of substances harmful to the environment and health

 Easily dismantled and recycled

 Reduced use of natural resources by encouraging recycling

 Extended product lifetime through easy upgrades

 Reduced solid waste production through take-back policy

Environmental Policy

 The product has been designed to enable proper reuse of parts and recycling

and should not be thrown away

 Users should contact the local authorized point of collection for recycling and

disposing of their end-of-life products.

1-11

Preface

Safety Guideline for Using Lithium Battery

(English) CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the sam e or equivalent type

recommended by the equipment manufacturer. Discard used batteries according to manufacturer’s instructions.

(French) (Français) ATTENTION: II y a danger d’explosion s’il y a remplacement incorrect de la batterie. Remplacer

uniquement avec une batterie du meme type ou d’un type équivalent recommandé par le constructeur. Mettre au rebut

les batteries usages conformément aux instructions du fabricant.

(German) (Deutsch) VORSICHT: Explosionsgefahr bei unsachgemäßem Austausch der Batterie. Ersatz nur durch

denselben oder einen vom Hersteller empfohlenen gleich-wertigen Typ. Entsorgung gebrauchter Batterien nach

Angaben des Herstellers.

(Spanish) (Español) PRECAUCIÓN: Peligro de explosión si la batería es reemplazada incorrectamente. Cámbiela solo

por la misma o un tipo equivalente recomendado por el fabricante. Descarte usar baterías usadas de acuerdo con las

instrucciones del fabricante.

(Italian) (Italiano) ATTENZIONE: Pericolo di esplosione della batteria se sostituita in modo non corretto. Sostituire solo

con la stesso tipo o con uno equivalente come indicato nel manuale del produttore. Smaltire le batterie usate come da

istruzioni del produttore.

(Russian) (Русский) Внимание: Существует опасность взрыва батареи в случае неправильной замены. Для

замены всегда используйте такую же или эквивалентную, рекомендованную производителем оборудования.

Следуйте инструкциям производителя при утилизации использованных батарей.

1-12

Preface

(Turkish) (Türkçe) UYARI: Pil yanlıs yerleştirilirse patlayabilir. Aynı ya da muadili bir pille degistiriniz. Kullanılmış pilleri

üreticinin talimatlarına göre degerlendiriniz.

(Greek) (Ελληνικά) ΠΡΟΣΟΧΗ: Κίνδυνος έκρηξης εάν η μπαταρία τοποθετηθεί λανθασμένα. Να αντικαθιστάτε μόνο με

τον ίδιο ή αντίστοιχο τύπο με αυτό που συνιστά ο κατασκ ευαστής του εξοπλισμού. Να απορρίπτετε τις χρησιμοποιημένες

μπαταρίες ως απορρίμματα σύμφωνα με τις οδηγίες του κατασκευαστή.

(Polish) (Polski) OSTRZEŻENIE: Nieprawidłowa wymiana może spowodować eksplozję baterii. Zamianę można wykonać

wyłącznie na baterię tego samego lub równoważnego typu zalecaną przez producenta urządzenia. Zużyte baterie można

wyrzucać zgodnie z instrukcjami producenta.

(Hungarian) (Magyar) VIGYÁZAT: A nem megfelelő akkumul tor haszn lata robban svesz lyes. Kizárólag ugyanolyan,

vagy a berendezés gyártója által ajánlott, egyenértékű típust használjon. Az elhasznált akkumulátorokat a gyártó

utasításának megfelelően ártalmatlanítsák.

(Czech) (Čeština) UPOZORNĚNÍ: Nebezpečí výbuchu při chybné výměně baterie. Nahraďte pouze stejným nebo

ekvivalentním typem doporučeným výrobcem zařízení. Použité baterie zlikvidujte podle pokynů výrobce

(Traditional Chinese ) 󰚸󰦐󰂁 󰇞󰐵󰂯󰠉󰒏󰎸󰢽󰇞

󰒏󰎸󰎳󰇞

(Simplified Chinese ) (简体中文) 注意 电池若未正确更换，可能会爆炸。请用原厂建议之同款或同等级的电池来更换。请

依原厂指示处理废弃电池。

(Japanese) (日本語) 警告：バッテリーの取り扱いを誤ると、液漏れや破裂などにより生命や財産に重大な影響を及ぼす

恐れがあります。指定された型番以外のバッテリーは使用しないでください。バッテリーを廃棄する場合は、各自治体

の規則に従って適切に処理して下さい。

1-13

Preface

(Korean) (한국어) 주의: 배터리를 올바로 교체하지 않으면 폭발할 위험이 있습니다. 타입이 장치 제조업체에서

권장하는 것과 동일하거나 동등한 배터리로만 교체하십시오. 사용한 배터리는 제조업체의 지침에 따라

폐기하십시오.

(Vietnamese) (Tieng Viet) LƯU Ý: Thay thế pin không tương thích có thể dẫn đến nguy cơ bị nổ. Chỉ thay thế bằng pin

cùng loại hoặc loại tương ứng khuyên dùng bởi nhà sản xuất thiết bị. Vứt bỏ pin đã sử dụng theo hướng dẫn của nhà sản

xuất.

(Thai) (ไทย) ขอควรระวัง: ถาใสแบตเตอรี่อยางไมถูกตอง อาจมีอันตรายจากการระเบิดขึ้นได ใชเฉพาะแบตเตอรี่ชนิดเดียวกัน

หรือเทียบเทา ที่แนะนําโดยผูผลิตอุปกรณเทานั้น ทิ้งแบตเตอรี่ที่ใชแลวตามคําแนะนําของผูผลิต

(Indonesian) (Bahasa Indonesia) PERHATIAN: Bahaya ledakan dapat terjadi jika salah memasang baterai. Ganti

baterai hanya dengan jenis yang sama atau setara sesuai rekomendasi pabrik peralatan tersebut. Buang baterai bekas

sesuai petunjuk pabrik

(Serbian) (Srpski) OPREZ: Ukoliko baterija nije ispravno postavljena, postoji opasnost od eksplozije. Zamenu izvršite

koristeći isključivo istu ili ekvivalentnu bateriju koju preporučuje proizvođač opreme. Odbacite iskorišćene baterije u

skladu sa uputstvima proizvođača.

(Netherlands) (Nederlands) LET OP: Er is explosiegevaar als de batterij niet goed geplaatst wordt. Uitsluitend te

vervangen door een batterij van hetzelfde of een gelijkwaardig type,zoals aanbevolen door de fabrikant. Gooi batterijen

weg volgens de plaatselijke instructies.

(Romanian) (Română) AT ENŢIE: Pericol de explozie dacă bateria este înlocuită incorect. Înlocuiţi doar cu acelaşi tip sau

echivalent recomandat de fabricantul echipamentului. Evacuaţi bateriile folosite conform instrucţiunilor fabricantului.

1-14

Preface

(Portuguese) (Português) ADVERTÊNCIA: Perigo de explosão se a bateria é substituída incorrectamente. Substitua

somente com o mesmo tipo ou equivalente recomendado por o fabricante do seu equipamento. Descarte as baterias

utilizadas de acordo com as instruções do fabricante.

(Swedish) (Svenska) VARNING: Explosionsfara vid felaktigt batteribyte. Använd samma batterityp eller en ekvivalent

typ som rekommenderas av apparattillverkaren. Kassera använt batteri enligt fabrikantens instruction.

(Finnish) (Suomi) VAROITUS: Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda paristo ainoastaan

valmistajan suosittelemaan tyyppiin. Hävitä käytetty paristo valmistajan ohjeiden mukaisesti.

(Slovak) (Slovenčina) UPOZORNENIE: V prípade nesprávnej výmeny batérie existuje nebezpečenstvo výbuchu.

Vymeňte iba za rovnakú batériu alebo za rovnocenný typ batérie, ktorý odporúča výrobca zariadenia. Batérie zneškodnite

podľa pokynov výrobcu.

(Slovenian) (Slovenščina) POZOR: V primeru nepravilne zamenjave baterije obstaja nevarnost njene eksplozije.

Baterijo zamenjajte le z enako ali ekvivalentno vrsto, k i jo priporoča proizvajalec. Odpadne baterije odstranite skladno z

navodili proizvajalca.

(Danish) (Dansk) ADVARSEL! Lithiumbatteri --- Eksplosionsf are ved fejlagtig håndtering. Udskiftning må kun ske med

batteri af same fabrikat og type. Levé det brugte batteri tilbage til leverandøren.

(Norwegian) (Norsk) ADVARSEL: Eksplosjonsfare ved feilaktig skifte av batteri. Benytt same batteritype eller en

tilsvarende type anbefalt av apparatfabrikanten. Brukte batterier kasseres I henhold til fabrikantens instruksjoner.

(Bulgarian) (български) ВНИМАНИЕ: Опасност от експлозия ако батерията бъд е неправилно поставена. Поставете

батерия от същия вид или еквивалентна батерия, която се препоръчва от производителя. Изхвърлете

използваните батерии като спазвате указанията на производителя.

1-15

Preface

(Croatian) (Hrvatski) OPREZ: Opasnost od eksplozije ako se baterija zamijeni neprikladnom. Zamijenite je samo

jednakom ili nadomjesnom vrstom prema preporuci proizvođača. Istrošene baterije zbrinite u skladu s uputama

proizvođača.

(Estonian) (Eesti) ETTEVAATUST! Plahvatusoht, kui aku on valesti paigaldatud. Asendage ainult sama või tootja poolt

soovitatud võrdväärse akuga. Hävitage kasutatud aku vastavalt tootja juhistele.

(ﻲﺳرﺎﻓ) (Persian)

ﺪﻴﻳﺎﻤﻧ ﻩدﺎﻔﺘﺳا .ﺪﻴﻳﺎﻤﻧ ﻞﻤﻋ ﻩﺪﻨﻨﮐ ﺪﻴﻟﻮﺗ ﺖﮐﺮﺷ ﯽﻳﺎﻤﻨهار ﻖﺒﻃ ﺮﺑ و ﺪﻴﻨﮐ ﯼراددﻮﺧ ﯼﺮﺗﺎﺑ ﻦﺘﺧاﺪﻧا رود زا.

ﺮﻳﺬﺤﺗ :ﺮﻄﺧ، ﻒﻠﺘﻟاو رﺎﺠﻔﻧﻼﻟ ﺔﻳرﺎﻄﺒﻟا ضﺮﻌﺘﺗ ﺪﻗ اذإ ﻢﺗﺒﺘﺳا ﺎﻬﻟاﺪﻰﻠﺻأ ﺮﻴﻏ عﻮﻨﺑ . لﺪﺒﺘﺳأﻰﺻوأ ﺊﻓﺎﻜﻣ عﻮﻧ وأ ﺲﻔﻨﺑ ﻂﻘﻓ ﻪﺑ ﻞﺒﻗ ﻦﻣ

ﺞﺘﻨﻣزﺎﻬﺠﻟا . تﺎﻳرﺎﻄﺒﻟا ﻞهﺎﺠﺗﺔﻠﻤﻌﺘﺴﻤﻟا ﺎﻘﻓو تادﺎﺷرﻹ ﺔآﺮﺸﻟا ﺔﻌﻨﺼﻤﻟا.

WEEE Statement

(English) Under the European Union ("EU") Directive on Waste Electrical and Electronic Equipment, Directive

2002/96/EC, which takes effect on August 13, 2005, products of "electrical and electronic equipment" cannot be d iscarded

as municipal waste anymore and manufacturers of covered electronic equipment will be obligated to take back such

products at the end of their useful life.

ارﺎﻄﺧ :ﺑ رﺎﺠﻔﻧا لﺎﻤﺘﺣا ،ﯼﺮﺗﺎﺑ ﺢﻴﺤﺻ ﯼراﺬﮔ ﺎﺟ و ﺐﺼﻧ مﺪﻋ ترﻮﺻ رددراد دﻮﺟو ﯼﺮﺗﺎ . ﻩﺪﻨﻨﮐ ﺪﻴﻟﻮﺗ ﺖﮐﺮﺷ ﯼدﺎﻬﻨﺸﻴﭘ ﯼﺎﻬﻳﺮﺗﺎﺑ زا ﺎﻬﻨﺗ ،ﯼﺮﺗﺎﺑ ﺾﻳﻮﻌﺗ ترﻮﺻ رد

)Arabic ()ﺔﻴﺑﺮﻌﻟا(

1-16

Preface

(French) (Français) Au sujet de la directive européenne (EU) relative aux déchets des équipement électriques et

électroniques, directive 2002/96/EC, prenant effet le 13 août 2005, que les produits électriques et électroniques ne

peuvent être déposés dans les décharges ou tout simplement mis à la poubelle. Les fabricants de ces équipements

seront obligés de récupérer certains produits en fin de vie.

(German) (Deutsch) Gemäß der Richtlinie 2002/96/EG über Elektro- und Elektronik-Altgeräte dürfen Elektro- und

Elektronik-Altgeräte nicht mehr als kommunale Abfälle entsorgt werden, die sich auf 13.August, 2005 wirken. Und der

Hersteller von bedeckt Elektronik-Altgeräte gesetzlich zur gebrachte n Produkte am Ende seines Baruchbarkeitsdauer

zurückzunehmen.

(Spanish) (Español) Bajo la directiva 2002/96/EC de la Unión Europea en materia de desechos y/o equipos electrónicos,

con fecha de rigor desde el 13 de agosto de 2005, los productos clasificados como "eléctricos y equipos electrónicos" no

pueden ser depositados en los contenedores habituales de su municipio, los fa bricantes de equipos electrónicos, están

obligados a hacerse cargo de dichos productos al termino de su período de vida.

(Italian) (Italiano) In base alla Direttiva dell’Unione Europea (EU) sullo Smaltimento dei Materiali Elettrici ed Elettronici,

Direttiva 2002/96/EC in vigore dal 13 Agosto 2005, prodotti appartenenti alla categoria dei Materiali Elettrici ed Elettronici

non possono più essere eliminati come rifiuti municipali: i produttori di detti materiali saranno obbligati a ritirare ogni

prodotto alla fine del suo ciclo di vita.

(Russian) (Русский) В соответствии с директивой Европейского Союза (ЕС) по предотвращению загрязнения

окружающей среды использованным электрическим и электронным оборудованием (директива WEEE

2002/96/EC), вступающей в силу 13 августа 2005 год а, изделия, относящиеся к электрическом у и электронному

оборудованию, не могут рассматриваться как бытовой мусор, поэтому производители вышеперечисленного

электронного оборудования обязаны принимать его для переработки по окончании

срока службы.

1-17

Preface

(Turkish) (Türkçe) Avrupa Birliği (AB) Kararnamesi Elektrik ve Elektronik Malzeme Atığı, 2002/96/EC Kararnamesi altında

13 Ağustos 2005 tarihinden itibaren geçerli olmak üzere, elektrikli ve elektronik malzemeler diğer atıklar gibi çöpe

atılamayacak ve bu elektonik cihazların üreticileri, cihazların kullanım süreleri bittikten sonra ürünleri geri toplamakla

yükümlü olacaktır.

(Greek) (Ελληνικά) Σύμφωνα με την Οδηγί α 2002/96/ΕΚ της Ευρωπαϊκής Ένωσης («ΕΕ») περί Απόρριψης Ηλεκτρικού

και Ηλεκτρονικού Εξοπλισμού (WEEE), η οποία λαμβάνει ισχύ στις 13 Αυγούστου 2005, τα προϊόντα «ηλεκτρικού και

ηλεκτρονικού εξοπλισμού» δεν είναι δυνατόν να απορριφθούν πλέον ως κοινά απορρίμματα και οι κατασκευαστ ές

κεκαλυμμένου ηλεκτρονικού εξοπλισμού είναι υποχρεωμένοι να πάρουν πίσω αυτά

ζωής τους.

(Polish) (Polski) Zgodnie z Dyrektywą Unii Europejskiej ("UE") dotyczącą odpadów produktów elektrycznych i

elektronicznych (Dyrektywa 2002/96/EC), która wchodzi w życie 13 sierpnia 2005, tzw. “produkty oraz wyposażenie

elektryczne i elektroniczne " nie mogą być traktowane jako śmieci komunalne, tak więc producenci tych produktów będą

zobowiązani do odbierania ich w momencie gdy produkt jest wycofywany z użycia.

(Hungarian) (Magyar) Az Európai Unió („EU") 2005. augusztus 13-án hatályba lépő, az elektromos és elektronikus

berendezések hulladékairól szóló 2002/96/EK irányelve szerint az elektr omos és elektronikus berendezések többé nem

kezelhetőek lakossági hulladékként, és az ilyen elektronikus berendezések gyártói kötelessé válnak az ilyen termékek

visszavételére azok hasznos élettartama végén.

(Czech) (Čeština) Podle směrnice Evropské unie ("EU") o likvidaci elektrických a elektronických výrobků 2002/96/EC

platné od 13. srpna 2005 je zakázáno likvidovat " elektrické a elektronické výrobky" v běžném komunálním odpadu a

výrobci elektronických výrobků, na které se tato směrnice vztahuje, budou povinni odebírat takové výrobk y zpět po

skončení jejich životnosti.

τα προϊόντα στο τέλος της ωφέλιμης

1-18

Preface

(Traditional Chinese ) 󰚸󰦐󰏼󰄊󰡣󰎳󰇞󰕓󰇞      

󰇞󰕓󰇞󰎳󰡣󰇞󰌚󰀫󰈣



(Simplified Chinese ) (简体中文) 欧盟已制订有关废电机电子设备法令，亦即自  年 月  日生效的 2002/96/EC，明

文规定「电机电子设备产品」不可再以都市废弃物处理，且所有相关电子设备制造商，均须在产品使用寿命结束后进行回

收。

(Japanese) (日本語)     に EU 加盟国を流通する電気・電子製品には WEEE 指令によりゴミ箱に×印のリサ

イクルマークの表示が義務づけられており、廃棄物として捨てることの禁止とリサイクルが義務づけられています。

(Korean) (한국어) 2005 년 8 월 13 일자로 시행된 폐전기전자제품에 대한 유럽연합("EU") 지침, 지침 2002/96/EC 에

의거하여, "전기전자제품"은 일반 쓰레기로 폐기할 수 없으며 제품의 수명이 다하면 해당 전자제품의 제조업체가

이러한 제품을 회수할 책임이 있습니다.

(Vietnamese) (Tieng Viet) Theo Hướng dẫn của Liên minh Châu Âu ("EU") về Thiết bị điện & điện tử đã qua sử dụng,

Hướng dẫn 2002/96/EC, vốn đã có hiệu lực vào ngày 13/8/2005, các sản phẩm thuộc "thiết bị điện và điện tử" sẽ không

còn được vứt bỏ như là rác thải đô thị nữa và các nhà sản xuất thiết bị điện tử tuân thủ h

sản phẩm này vào cuối vòng đời.

(Thai) (ไทย) ภายใตขอกําหนดของสหภาพยุโรป ("EU") เกี่ยวกับของเสียจากอุปกรณไฟฟา และอิเล็กทรอนิกส เลขที่ 2002/96/EC

ซึ่งมีผลบังคับใชตั้งแตวันที่ 13 สิงหาคม 2005 ผูใชไมสามารถทิ้งผลิตภัณฑที่เปน "อุปกรณไฟฟาและอิเล็กทรอนิกส"

ปะปนกับของเสียทั่วไปของชุมชนไดอีกตอไป และผูผลิตอุปกรณอิเล็กทรอนิกสดังกลาวจะถูกบังคับให

สิ้นสุดอายุการใชงานของผลิตภัณฑ

ướng dẫn sẽ phải thu hồi các

นําผลิตภัณฑดังกลาวกลับคืนเมื่อ

1-19

Preface

(Indonesian) (Bahasa Indonesia) Sesuai dengan Regulasi Uni Eropa ("UE") perihal WEEE (Limbah Peralatan Listrik dan

Elektronik), Directive 2002/96/EC, yang berlaku sejak 13, 2005, pr oduk "peralatan listrik dan elektronik" tidak lagi dapat

dibuang sebagai sampah umum dan pabrik peralatan elektronik diwajibkan untuk mengambil kembali produk tersebut

pada saat masa pakainya habis.

(Serbian) (Srpski) Po Direktivi Evropske unije ("EU") o odbačenoj ekektronskoj i električnoj opremi, Direktiva 2002/96/EC,

koja stupa na snagu od 13. Avgusta 2005, proizvodi koji spadaju pod "elektronsku i električnu opremu" ne mogu više biti

odbačeni kao običan otpad i proizvođači ove opreme biće prinuđeni da uzmu natrag ove proizvode na kraju njihovog

uobičajenog veka trajanja.

(Netherlands) (Nederlands) De richtlijn van de Europese Unie (EU) met betrekking tot Vervuiling van Electrische en

Electronische producten (2002/96/EC), die op 13 Augustus 2005 in zal gaan kunnen niet meer beschouwd worden als

vervuiling. Fabrikanten van dit soort producten worden verplicht om producten retour te nemen aan het eind van hun

levenscyclus..

(Romanian) (Română) În baza Directivei Uniunii Europene ("UE") privind Evacuarea Echipamentului Electric şi Electronic,

Directiva 2002/96/EC, care intră în vigoare pe 13 august, 2005, pro dusele din categoria "echipament electric şi electronic"

nu mai pot fi evacuate ca deşeuri municipale, iar fabricanţii echipamentului electronic vizat vor fi obligaţi să primească

înapoi produsele respective la sfârşitul duratei lor de utilizare.

(Portuguese) (Português) De acordo com a Directiva 2002/96/EC de Resíduos de Equipamentos Eléctricos e

Electrónicos da União Europeia (UE), efectiva desde o 13 de Agosto do ano 2005, os produtos de "equipamento eléctrico

e electrónico" não podem ser descartados como resíduo municipal e os fabricantes do equipamento electrónico sujeitos a

esta legislação estarão obligados a recolhar estes produtos ao finalizar sua vida útil.

1-20

Preface

(Swedish) (Svenska) Under Europeiska unionens ("EU") Weee-direktiv (Waste Electrical and Electronic Equipment),

Direktiv 2002/96/EC, vilket trädde i kraft 13 augusti, 2005, kan inte produkter från "elektriska och elektroniska

utrustningar" kastas i den vanliga hushållssoporna längre och tillverkare av inbyggd elektronisk utrustning kommer att

tvingas att ta tillbaka sådan produkter när de är förbrukade.

(Finnish) (Suomi) Euroopan unionin (EU) 13.8.2005 voimaan tulleen sähkö- ja elektroniikkalaiteromua koskevan

direktiivin 2002/96/EY mukaisesti ”sähkö- ja elektroniikkalaitteita” ei saa enä ä hävittää talousjätteiden mukana. Direktiivin

alaisen sähkö- tai elektroniikkalaitteen valmistajan on otettava laitteet takaisin niiden käyttöiän päättyessä.

(Slovak) (Slovenčina) Na základe smernice Európskej únie („EU“) o elektrických a elektronických zariadeniach číslo

2002/96/ES, ktorá vstúpila do platnosti 13. augusta 2005, výrobky, ktorými sú „elektrické a elektronické zariadenia” nesmú

byť zneškodňované spolu s komunáln ym odpadom a výrobcovia patričných elektronických zariadení sú povinní takéto

výrobky na konci životnosti prevziať naspäť.

(Slovenian) (Slovenščina) Skladno z določili direktive Evropske unije ("EU") o odpadni električni in elektronski opremi,

Direktiva 2002/96/ES, ki je veljavna od 13. avgusta, izdelkov "električne in elektronske opreme" ni dovoljeno odstranjevati

kot običajne komunalne odpadke, proizvajalci zadevne elektronske opreme pa so zavezani, da tovrstne izdelke na koncu

njihove življenjske dobe sprejmejo nazaj.

(Danish) (Dansk) I henhold til direktiv fra den europæiske union (EU) vedrørende elektrisk og elektronisk affald , Direktiv

2002/96/EC, som træder i kraft den 13. august 2005, må produkter som "elektrisk og elektronisk udstyr" ikke mere

bortskaffes som kommunalt affald. Producenter af det pågældende, elektroniske udstyr vil være forpligtet til at tage disse

produkter tilbage ved afslutningen på produkternes levetid.

1-21

Preface

(Norwegian) (Norsk) Under den europeiske unionens ("EU") direktiv om deponering av elektronisk og elektrisk utstyr,

direktiv 2002/96/EC, som trer i effekt 13. august 2005, kan ikk e produkter av "elektronisk og elektrisk ustyr" lenger

deponeres som husholdningsavfall og fabrikantene av disse produktene er forpliktet å ta tilbake slike produkter ved

slutten av produktets levetid.

(Bulgarian) (български) Според директивата на Европейския съюз относно отпадъците от електрическо и

електронно оборудване, директива 2002/96/EC, важаща от 13 август, 2005 г., електриче ско и електронно

оборудване не може да се изхвърля заедно с битовите отпа дъци и производителите на та кова оборудване са

задължени да приемат обратно съответните продукти в края на експлоатационния им пер иод.

(Croatian) (Hrvatski) U okviru Direktive Europske Unije ("EU") o Otpadnim električnim i elektroničkim uređajima, Direktiva

2002/96/EC, koja je na snazi od 13. kolovoza 2005., "električni i elektronički uređaji" se ne smiju više bacati zajedno s

kućnim otpadom i proizvođači su obvezni zbrinuti takve proizvode na kraju njihovog životnog vijeka.

(Estonian) (Eesti) Vastavalt Euroopa Liidu ("EL") direktiivile 2002/96/EÜ (elektri- ja elektroonikaseadmete jäätmete kohta),

mis jõustus 13. augustil 2005, on keelatud kodumajapidamiste "elektri- ja elektroonikaseadmete" jäätmete hävitamine

koos majapidamisjäätmetega, ja elektri- ja elektroonikaseadmete tootjad on kohustatud sellised tooted pärast nende

kasutuselt kõrvaldamist tagasi võtma.

(ﻲﺳرﺎﻓ) (Persian)

ﺎﻗ ﻖﺒﻃ ﺮﺑﻮﻧ ﯽﮑﻴﻧوﺮﺘﮑﻟا و ﯽﮑﻳﺮﺘﮑﻟا ﯼﺎه ﻪﻟﺎﺑز ﻊﻓد ن) ﺪﻨﺑ 2002/96/EC ﺎﭘورا ﻪﻳدﺎﺤﺗا ( ﺦﻳرﺎﺗ زا ﻪﮐ13 لﺎﺳ ﺖﺳﻮﮔﺁ 2005 ﯼﺎه ﺖﮐﺮﺷ ﻪﻴﻠﮐ ، ﺖﺳاﺮﺟا ﻞﺑﺎﻗ ﯼدﻼﻴﻣ

ﻊﻤﺟ ﻪﺑ ﻒﻇﻮﻣ ﻩﺪﻨﻨﮐ ﺪﻴﻟﻮﺗﺪﻨﺷﺎﺑ ﯽﻣ فﺮﺼﻣ ﻩرود نﺎﻳﺎﭘ زا ﺲﭘ دﻮﺧ تﻻﻮﺼﺤﻣ ﻪﻟﺎﺑز ﯼروﺁ.

ﻲﺑروﻷا دﺎﺤﺗﻹا ﺔﻴﻗﺎﻔﺗا رﺎﻃإ ﻲﻓ")ﻲﺑروﻷا دﺎﺤﺗﻹا (" ﻪﻴﺟﻮﺗ ،ﺔﻴﻧوﺮﺘﻜﻟﻹاو ﺔﻴﺋﺎﺑﺮﻬﻜﻟا ةﺰﻬﺟﻷا و تاﺪﻌﻤﻟا تﺎﻳﺎﻔﻧ نﺄﺸﺑ ﻪﻴﺟﻮﺘﻟا2002/96/EC

،ﺔﻴﺑروﻷا ﺔﻋﻮﻤﺠﻤﻠﻟىﺬﻟا ﻲﻓ لﻮﻌﻔﻤﻟا يرﺎﺳ ﺢﺒﺻأ 13 ﺲﻄﺴﻏأ/ ،بﺁ2005 تﺎﺠﺘﻨﻣ نا ،"ﺔﻴﻧوﺮﺘﻜﻟإو ﺔﻴﺋﺎﺑﺮﻬآ ةﺰﻬﺟأ " ﻲﻠﺨﺘﻟا ﻦﻜﻤﻳ ﻻ

ﺎﻬﺘﻴﺣﻼﺻ ةﺪﻣ ﺔﻳﺎﻬﻧ ﻲﻓ تﺎﺠﺘﻨﻤﻟا ﻩﺬه ﻞﺜﻣ دادﺮﺘﺳا ﻢﻬﻴﻠﻋ ﺎﻣاﺰﻟ نﻮﻜﻴﺳ ﺔﻴﻧوﺮﺘﻜﻟﻻا تاﺪﻌﻤﻟا

ﻮﺠﺘﻨﻣو ،تﺎﻳﺎﻔﻧ ﺎﻬﻔﺻﻮﺑ ﺎﻬﻨﻋ.

)Arabic ()ﺔﻴﺑﺮﻌﻟا(

1-22

Preface

Optical Drive Device Notice

CAUTION: This appliance contains a laser system and is classified as a “CLASS 1 LASER

PRODUCT.” To use this model properly, read the instruction manual carefully and keep this manual

for your future reference. In case of any trouble with this model, please contact your nearest

“AUTHORIZED service station.” To prevent direct exposure to the laser beam, do not try to

disassemble the enclosure.

Trademarks

 All trademarks are the properties of their respective owners.

 THX and THX TruStudio Pro are trademarks of THX Ltd. which may be registered in some

Revision History

Version Revision History Date

1.0 First Released 11, 2010

CHAPTER 2

Introductions

2-2

Introductions

Congratulations on becoming an user of this notebook, the finely designed notebook. This

brand-new exquisite notebook will give you a delightful and professional experience in using

notebook. We are proud to tell our users that this notebook is thoroughly tested and certified by our reputation for unsurpassed dependability and customer satisfaction

Manual Map

This User’s Manual provides instructions and illustrations on how to operate this notebook. It is

recommended to read this manual carefully before using this notebook.

Chapter 1, Preface

this notebook. It is recommended to read these information or caution when using this notebook

for the first time.

Chapter 2, Introductions

recommended to check out that if you have all the accessories included when you open the packing

box. If any of these accessories is damaged or missing, please contact the vendor where you

purchased this notebook. Also, this chapter provides the specification of this notebook, and

introduces the function buttons, quick launch sensors, connectors, LEDs and externals of this

notebook.

Chapter 3, Getting Started

hard disk drive, and optical storage drive. Beside, the steps of installing and uninstalling the

battery; and the procedures of connecting the various external devices, communication devices,

and so on, are also provided to help users getting familiar with this notebook.

, gives users the basic safety information and caution that is interrelated to using

, includes the descriptions of all the accessories of this notebook. It is

, gives the basic operation instructions on using keyboard, touchpad,

2-3

Introductions

Chapter 4, BIOS Setup, provides information on BIOS Setup program and allows you to configure

the system for optimum use.

Unpacking

First, unpack the shipping carton and check all items carefully. If any item contained is damaged or

missing, please contact your local dealer immediately. Also, keep the box and packing materials in

case you need to ship the unit in the future. The package should contain the following items:

These accessories listed

above may change without

notice.

Notebook

High-capacity Li-ion battery

Quick Start Manual

AC/DC adapter and AC power

cord

Carry bag (optional)

All-in-one application disk, containing the full version of user’s manual,

drivers, utilities, and optional recovery function, etc.

2-4

Introductions

Specification

Physical Characteristic

Dimension 395 (W) x 278 (D) x 45 (H) mm

Weight <3.5 kg (with 9-cell battery)

CPU

Processor Type Intel® Sandy Bridge

Support Processor Intel® Huron River

L2/ L3 Cache UP to 8MB

Special Notification The actual processor preinstalled in the notebook depends on

the model you purchased. Please contact the local dealer for

detailed information.

Core Chips

Chipset Intel® HM67

Special Notification The actual core chip(s) preinstalled in the notebook depends

on the model you purchased. Please contact the local dealer

for detailed information.

2-5

Introductions

Memory

Technology DDR3 1066/ 1333 MHz

Memory DDR3 SO-DIMM X 4 slots

Maximum up to 16 GB

Power

AC/DC Adapter 150W, 19V

Input: 100~240V 50~60Hz

Output: 19.5V Battery Type 9-cell

RTC Battery Yes

Special Notification The actual AC/DC Adapter and battery pack that come with the

package may vary without notice.

7.7A

Storage

HDD form factor 2.5”

7200RPM 500 GB (optional) / 5400RPM 640 GB (optional)

Optical Drive Device Super Multi/ BD DVD Writable (optionally supported)

Special Notification The actual HDD and ODD preinstalled in the notebook

depends on the model you purchased.

2-6

Introductions

I/O Port

Monitor (VGA) 15 pin D-Sub x 1

USB x 4

E-SATA x 1

HDMI x 1

Mic-in x 1

Line-in x 1

Line-out x 1

Headphone out / S/PDIF out x 1

Internal Microphone x 1

RJ45 x 1

Card Reader x 1 (XD/ SD/ SDHC/ SDXC/ MMC/ MS/ MS Pro)

The supported memory cards may vary without notice.

Communication Port (Items listed here may vary without notice)

LAN Giga LAN

Wireless LAN 802.11b/g/n (optional)

Bluetooth Supported (optional)

Audio

Internal Speaker 2 speakers + 1 sub-woofer

Sound Volume Adjust by K/B hot-key & SW

2-7

Introductions

Video

Graphics Discrete

Display

LCD Type 15.6” LED LCD (optional)

Brightness Adjustment Supported

WebCam

WebCam HD Camera

Software & BIOS

USB Flash Boot Yes, USB floppy boot up DOS only

BIOS Fast Boot Support --- Yes

Others

Kensington Lock Hole x 1

Compliance WHQL

The figures show here are

for reference onl y.

2-8

Introductions

Product Overview

This section provides the description of basic aspects of the notebook. It will help you to know

more about the appearance of this notebook before using it. Please be aware that the notebook

shown in this section may vary from the actual one that users purchased.

Top-open View

The figure of top-open view and description shown below will lead you to browse the main operating

area of your notebook.

1. Internal Microphone

2. WebCam / Webcam LED

3. Stereo Speakers

4. Power Button / Power LED

5. Quick Launch Touch Sensors

6. Keyboard

7. Touchpad

2-9

Introductions

1. Internal Microphone

The built-in speaker and array microphone increase the accuracy of speech recognition

feature, allow inputs to be combined into a single, higher-quality source.

2. Webcam/ Webcam LED (optional)

 This built-in Webcam can be used for picture taking, video recoding or conferencing, and

any other interactive applications.

 Webcam LED indicator, next to the webcam, glows amber when webcam function is

activated; LED goes out when this function is turned off.

3. Stereo Speakers

Give high quality sound blaster with stereo system and Hi-Fi function supported.

4. Power Button / Power LED

 Press the power button to turn the notebook power ON and OFF.

 Glowing white when the notebook power is turned on.

5. Quick Launch Touch Sensors

Press the quick launch touch sensor to activate the specific applications or tools. With the

help of these sensors, users will be able to do work more efficiently.

Cinema

Pro

 Press this sensor to launch the Cinema Pro application.

2-10

Introductions

Windows Start

Turbo

Cooler Boost

Up Hotkey

 Connect the AC power and press the TURBO sensor to raise a

higher performance. The TURBO LED indicators lights when this

function is ON or goes out when OFF.

Note

 This notebook is designed to support overclocking function.

However, please make sure your components are able to tolerate

such abnormal setting while doing overclocking. Any attempt to

operate beyond CPU and system specifications may cause

damages. We do not guarantee the damages or risks caused by

inadequate operation or beyond product specifications.

 The overclocking value may vary depending on the CPU you use.

 Factory warranty will be void if the original equipped CPU or DRAM

is replaced.

 Press this sensor to activate fan to run at full speed to cool down

overall temperature.

 Press this sensor repeatedly to turn the Cooler Boost function on

or off recurrently.

 Press this sensor to avoid mispressing Windows Start Up Hotkey

and disturbing ongoing game.

 Press this sensor repeatedly to turn the Windows Start Up Hotkey

function on or off recurrently.

2-11

Introductions

ECO

ECO Engine

(Power Saving)

LED Mode

Switch

6. Keyboard

The built-in keyboard provides all the functions of a standard keyboard.

Quick Launch [Fn] Buttons

Use the [Fn] buttons on the keyboard to activate the specific applications or tools. With the help of these quick launch buttons, users will be able to work more efficiently.

 Press this sensor repeatedly to turn the WLAN function on or off

recurrently.

 Press this sensor repeatedly to turn the Bluetooth function on or off

recurrently.

 Press this sensor repeatedly to switch among these five different

power saving modes – Gaming mode, Movie mode, Presentation

mode, Office mode, and Turbo Battery mode provided by ECO

Engine, or to turn this function off recurrently.

 Refer to the Power Management section in chapter 3 of this manual

for the detailed information of this ECO Engine, Power Saving

Function.

 Press this sensor repeatedly to turn on or off all decorate LED

around panel and lower cover.

2-12

Introductions

Cinema

Pro

ECO Engine

(Power Saving)

Webcam

WLAN (WiFi)

(optional)

 Press and hold the Fn button, and then press the F4 button to

launch the Cinema Pro function.

 Press and hold the Fn button, and then press the F5 button

repeatedly to switch among various power saving modes provided

by ECO Engine, or to turn this function off recurrently.

 Refer to the Power Management section in chapter 3 of this

manual for the detailed information of this ECO Engine, Power

Saving Function.

 Press and hold the Fn button, and then press the F6 button to turn

the Webcam function on. Press again to turn it off.

 Press and hold the Fn button, and then press the F8 button

repeatedly to turn the Wireless LAN (WiFi) function on or off recurrently.

2-13

Introductions

Bluetooth

(optional)

 Press and hold the Fn button, and then press the F9 button to turn

the Bluetooth function on. Press again to turn it off.

 Press and hold the Fn button, and then press the F10 button to turn

the 3G function on. Press again to turn it off.

(optional)

 This 3G function is optional supported depending on the model

users purchased. This function button will not be available when

the 3G function is not supported.

 Note that the function is not supported by this model.

7. Touchpad

This is a pointing device of the notebook.

2-14

Introductions

Front View

1. Status LED

Bluetooth

Wireless LAN

1. Status LED

Bluetooth and Wireless LAN:

 Wireless LAN LED indicator glows amber when Wireless LAN function is

enabled.

 Bluetooth LED indicator glows amber when Bluetooth function is enabled.

 Both LED indicators go out when both functions are disabled.

 Warning : For flight safety consideration, make sure these two LED

indicators go out when you are in flight.

 Note: The Bluetooth function may be optional supported depending on

the model users purchased.

2-15

Introductions

Battery Status:

 Glowing amber when the battery is being charged.

 Glowing blue when the battery is in low battery status.

 Blinking blue if the battery fails and it is recommended to replace a new

battery. Consult the local dealer for purchasing an equivalent type of

battery recommended by the manufacturer.

 Battery LED goes out when it is fully charged or when the AC/DC adapter

is disconnected.

Sleep State:

 Blinking amber when the system is in Sleep state.

 LED goes out when the system is turned off.

Hard Disk/ Optical Drive Device In-use: Blinking amber when the system is accessing the hard disk drive or the optical

drive device.

2-16

Introductions

Right Side View

1. Audio Port Connectors

Make high quality sound blaster with stereo system and Hi-Fi function supported. Connect your

speakers to the proper connectors as shown below.

Headphone out/ SPDIF-out: Used for speakers or headphones. The S/PDIF connector is also provided for

digital audio transmission to external speakers through an

optical fiber cable.

Connect the Front speakers here.

Mic In: Used for an external microphone. Connect the Center and Subwoofer speakers here.

Line In: Used for an external audio device. Connect the Rear speakers here.

Line Out: A connector for speakers. Connect the Surround speakers here.

1. Audio Port Connectors

2. USB Port

3. Optical Drive Device

2-17

Introductions

2. USB Port

The USB 2.0 port allows you to connect USB-interface peripheral devices, such as the mouse,

keyboard, modem, portable hard disk module, printer and more.

3. Optical Drive Device

The optical drive device allows you to use the CD/ DVD/ Blu-ray disc for installing software,

accessing data and playing music/movie on the computer.

2-18

Introductions

Left Side View

1. Ventilator

The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation.

2. USB Port

The USB 2.0 port allows you to connect USB-interface peripheral devices, such as the mouse,

keyboard, modem, portable hard disk module, printer and more.

3. Card Reader

The built-in card reader may support various types of memory card, such as MMC (Multi-Media

Card), XD (eXtreme Digital), SD (Secure Digital), SDHC (SD High Capacity), MS (Memory

Stick), MS Pro (Memory Stick Pro), or SDXC(extended Capacity) cards. Contact the local dealer

for further and correct information and be noted that the supported memory cards may vary

without notice.

1. Ventilator

2. USB Port

3. Card Reader

2-19

Introductions

Rear Side View

1. Kensington Lock

This notebook provides a Kensington Lock hole, which allows users to secure the notebook in

place with a key or some mechanical PIN device and attached through a rubberised metal cable.

The end of the cable has a small loop which allows the whole cable to be looped around a

permanent object, such as a heavy table or other similar equipment, thus securing the notebook

in place.

2. Power Connector

To connect the AC/ DC adapter and supply power to the notebook.

3. RJ-45 Connector

The Ethernet connector is used to connect a LAN cable for network connection.

1. Kensington Lock

2. Power Connector

3. RJ-45 Connector

4. VGA Port

5. E-SATA Connector

6. HDMI Connector

7. Ventilator

2-20

Introductions

4. VGA Port

The 15-pin D-sub VGA port allows you to connect an external monitor or other standard

VGA-compatible device (such as a projector) for a great view of the computer display.

5. E-SATA Connector

The E-SATA Connector allows you to connect an external Serial ATA device. Users can now

utilize shielded cable outside the notebook to take advantage of the benefits the SATA interface

brings to storage.

6. HDMI Connector

HDMI (High Definition Multimedia Interface) is a new interface standard for PCs, displays and

consumer electronics devices that supports standard, enhanced and high-definition video, plus

multi-channel digital audio on a single cable.

7. Ventilator

The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation.

2-21

Introductions

Bottom Side View

1. Battery Lock/ Unlock Button

Battery cannot be moved when the button is positioned on lock status. Once the button is slid to

unlock position, the battery is removable.

2. Battery Pack

This notebook will be powered by the battery pack when the AC/ DC adapter is disconnected.

3. Battery Release Button

It is a bounce-back device as a preparation for releasing the battery pack. Slide it with one hand

and pull the battery pack carefully with the other.

1. Battery Lock/ Unlock Button

2. Battery Pack

3. Battery Release Button

4. Ventilator

2-22

Introductions

4. Ventilator

The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation.

CHAPTER 3

Getting Started

3-2

Getting Started

Exclusive Functions

This model has following exclusive functions.

NVIDIA OC Tool

This tool can activate TDE (Turbo Drive Engine) technology, thus further enable GPU OC function.

Note:

 The nVidia Over Clock Tool is only available on graphic solution only.

 The preinstalled MXM card may differ depending on the model user purchased.

 This notebook is designed to support overclocking function. However, please make sure your

components are able to tolerate such abnormal setting while doing overclocking. Any attempt to

operate beyond CPU and system specifications may cause damages. We do not guarantee the

damages or risks caused by inadequate operation or beyond product specifications.

 The overclocking value may vary depending on the CPU you use.

Factory warranty will be void if the original equipped CPU or DRAM is replaced.

1. To use the TDE – over-clocking function, follow the instructions below:

Connect the AC power and press the TURBO sensor to raise a higher

Turbo

performance. The TURBO LED indicators lights when this function is

ON or goes out when OFF.

3-3

Getting Started

2. Right-click the NVIDIA OC icon once on tool bar.

3. Select “Enable” or “Disable” to activate GPU Over Clock Function.

With this TDE function activated, the system will raise the over-clocking

setting to achieve a higher performance,

and the icon on behalf of TDE function enabled will appear on the display.

The icon on behalf of TDE function disabled will appear on the display when

this function is turn off.

4. Select “About” to know the version of NVIDIA OC tool,

or click “Exit” to leave the application.

3-4

Getting Started

SLM Setting (System LED Manager)

SLM tool can adjust the LED behavior around panels and base side. Users can decide which

side of LED light to be visible, whereas others invisible, yet to choose the lighting effects mode.

1. User may call tool up to desktop either by

left-clicking twice or right-clicking once and

select “Setting” option.

2. SLM screen shows as follows.

Audio Mode

Breathing Mode

Default Mode

LED lights along with music or any sound from notebook.

LED lights as frequency of human breathing.

LED lights following factory settings.

3-5

Getting Started

Power Management

Connecting the AC power

Please be noted that it is strongly recommended to connect the AC/DC adapter and use the AC

power while using this notebook for the first time. When the AC/DC adapter is connected, the

battery is being charged immediately.

Note that the AC/DC adapter included in the package is approved for your notebook; using other

adapter model may damage either the notebook or other devices attached to it.

Do not cover the AC/DC adapter since it may produce a certain heat while in use. Always be

aware of heat coming from the AC/DC adapter in use.

3-6

Getting Started

Connecting the AC Power

1. Unpack the package to find the AC/DC adapter and power cord.

2. Attach the power cord to the connector of the AC/DC adapter.

3. Plug the DC end of the adapter to the notebook, and the male end of the power cord to the

electrical outlet.

Disconnecting the AC Power

When you disconnect the AC/DC adapter, you should:

4. Unplug the power cord from the electrical outlet first.

5. Unplug the connector from the notebook.

6. Disconnect the power cord and the connector of AC/DC adapter.

7. When unplugging the power cord, always hold the connector part of the cord. Never pull the

cord directly!

3-7

Getting Started

Using the Battery Power

This notebook is equipped with a high-capacity Li-ion battery pack. The rechargeable Li-ion battery

pack is an internal power source of the notebook.

Be aware of that this battery pack may be damaged if users try to disassemble the battery pack on

their own. Also, note that the limited warranty to the battery pack may also lose its efficacy when

this battery pack is disassembled not by an authorized machinist.

To prevent explosion caused by improper battery replacement, use the same or equivalent type of

battery recommended by the manufacturer only.

Always keep the battery which is not in use in a safe place.

Please follow your local laws and regulations to recycle the unused battery pack.

3-8

Getting Started

Installing the Battery Pack

To insert the battery pack, following the steps below:

1. Align and place the battery to the

battery tray with correct orientation.

2. Press down the battery pack to fasten

the battery pack in the battery tray.

3. Press the lock/unlock button to the

Lock position to make sure the battery

pack is securely fastened.

3-9

Getting Started

Releasing the Battery Pack

It is always recommended to have another battery pack in reserve for enough power supply.

Please contact your local dealer to purchase a battery pack that is compliant to your notebook.

To remove the battery pack, following the steps below:

1. Make sure the notebook is turned off, and the AC power is disconnected.

2. Press the lock/unlock button to the unlocked position.

3. Locate the battery release button on the bottom side.

4. Push and hold the release button to the battery releasing direction as shown on the bottom

side.

5. Dig the edge of battery pack out of the battery tray with your finger tip. Be careful with your

finger while trying to take out the battery pack.

6. And then pull the battery pack out.

3-10

Getting Started

3-11

Getting Started

Battery Safety Tips

Replacing or handling the battery incorrectly may present a risk of fire or explosion, which could

cause serious injury.

 Only replace the main battery pack with the same or equivalent type of battery.

 Do not disassemble, short-circuit or incinerate batteries or store them to temperatures above

+60° C (+140° F).

 Do not temper with batteries. Keep away from the reach of children.

 Do not use rusty or damaged batteries.

 Dispose of batteries according to local regulations. Check with your local solid waste

officials for details about recycling options or for proper disposal in your area.

Conserving Battery Power

Efficient battery power is critical to maintain a normal operation. If the battery power is not

managed well, the saved data and customized settings may be lost.

To optimize battery life and avoid a sudden power loss, read the tips below:

 Suspend system operation if the system will be idle for a while or shorten the suspend timer’s

time period.

 Turn off the system if you won’t be using it for a period of time.

 Disable unnecessary settings or remove idle peripherals.

 Connect an AC/DC adapter to the system whenever possible.

3-12

Getting Started

Charging the Battery Pack

The battery pack can be recharged while it is installed in the notebook. Please pay attention to the

following tips before recharging the battery:

 If a charged battery pack is not available, save your work and close all running programs and

shut down the system or Save-to-Disk.

 Plug in an external AC/DC adapter.

 You can use the system, suspend system operation or shut down and turn off the system

without interrupting the charging process.

 The battery pack uses Lithium-ion battery cells that have no “memory effect.” It is

unnecessary to discharge the battery before recharging. However, to optimize the life of

battery, we suggest that consuming the battery power completely once a month is necessary.

 If you do not use the notebook for a long time, it is suggested to remove the battery pack from

your notebook. This may be helpful to extend your battery life.

 The actual charging time will be determined by the applications in use.

3-13

Getting Started

ECO Power Saving Function (Optionally Supported)

Enabling the ECO Engine

ECO Engine, the outstanding and unique power saving function, provides various power saving

modes – Gaming mode, Movie mode, Presentation mode, Office mode, and Turbo Battery

mode, to extend the battery running time while performing different tasks with this notebook.

Read the instructions bellow to activate the ECO Engine power saving function:

1. Press and hold the Fn button.

2. Press the F5 button repeatedly to switch among the different modes of ECO Engine, or to turn

this ECO Engine off recurrently.

3. To learn which power saving mode is activated presently, read the icon on behalf of each mode

appearing on the display when selected.

Gaming Mode Select this mode while performing game applications.

Movie Mode

Select this mode while playing multimedia applications

3-14

Getting Started

Presentation Mode

Select this mode while performing presentation applications.

Office Mode

Select this mode while dealing with office documentation tasks.

Tur bo Ba tt ery Mode

Select this mode to maximize the battery running time.

ECO Off

Selected to disable ECO Engine.

3-15

Getting Started

Power Management in Windows OS

Power management of personal computers (PCs) and monitors has the potential to save significant

amounts of electricity as well as deliver environmental benefits. To be energy efficient, turn off your

display or set your PC to sleep or hibernate mode after a period of user inactivity.

Follow the instructions below to adjust the power management settings in Windows OS:

1. “Power Options” selection in Windows OS allows you to control the power management

features of your display, hard drive, and battery. Go to the Start menu and click on the Control

Panel. Click on the “System and Security”.

2. Then click on the “Power Options”.

3. Then “Select a power plan” that meets your personal needs.

4. The “Shut down” Computer menu will present various relative options as following.

5. The computer should be able to wake up from power saving mode in response to a command

from any of following:

 the power button,

 the mouse,

 the keyboard.

3-16

Getting Started

3-17

Getting Started

Energy Saving Tips

 Activate the ECO power saving function to manage the computer’s energy consumption.

 Turn off the monitor after a period of user inactivity.

 Utilize the Fn and F12 sleep mode keys to turn into power saving mode.

 Tune the settings in Power Options under Windows OS to optimize the computer’s power

management.

 Always disconnect the AC power cord or uninstall the battery pack or switch off the wall socket if

the computer would be left unused for a certain time to achieve zero energy consumption.

3-18

Getting Started

Basic Operations

If you are a beginner to the notebook, please read the following instructions to assure your own

safety, and make yourself comfortable during the operations.

Safety and Comfort Tips

The notebook is a portable platform that allows you to work anywhere. However, choosing a good

workspace is important if you have to work with your notebook for a long period of time.

 Your work area should have enough illumination.

 Choose the proper desk and chair and adjust their height to fit your posture when operating.

 When sitting on the chair, adjust the chair’s back (if available) to support your back

comfortably.

 Place you feet flat and naturally on the floor, so that your knees and elbows have the proper

position (about 90-degree) when operating.

 Put your hands on the desk naturally to support your wrists.

 Adjust the angle/position of the LCD panel to have an optimal view.

 Avoid using your notebook in the space where may cause you discomfort (such as on the

bed).

 The notebook is an electrical device, please treat it with great care to avoid personal injury

3-19

Getting Started

1. Keep your hands and feet with

optimal comfort.

2. Adjust the angle and position of LCD

panel.

3. Adjust the desk’s height.

4. Sit straight and keep a good posture.

5. Adjust the chair’s height.

Having a Good Work Habit

Have a good work habit is important if you have to work with your notebook for long periods of time;

otherwise, it may cause discomfort or injury to you. Please keep the following tips in mind when

operating.

 Change your posture frequently.

 Stretch and exercise your body regularly.

 Remember to take a break after working for a period of time.

3-20

The keyboard shown here

may vary from the actual

one, depending on which

county users purchase the

notebook.

Getting Started

Knowing the Keyboard

This notebook provides a full-functioned keyboard. This keyboard can be divided into four

categories: Typ ew riter keys, Cursor keys, Numeric keys and Function keys.

Typewriter keys

Numeric keys

Cursor keys /

Function keys

3-21

Getting Started

Typewriter Keys

In addition to providing the major function of the keyboard, these typewrite keys also provide several

keys for special purposes, such as [Ctrl,] [Alt,] and [Esc] key.

When the lock keys are pressed, the corresponding LEDs will light up to indicate their status:

 Num Lock: Press the Num Lock key to toggle the Num Lock on and off. When this function is

activated, you can use the numeric keys that are embedded in the typewriter keys.

 Caps Lock: Press the Caps Lock key to toggle the Caps Lock on and off. When this function

is activated, the letters you type are kept in uppercase.

 Scroll Lock: Press the Scroll Lock key to toggle the Scroll Lock on and off. This function is

defined by individual programs, and is usually used under DOS.

Numeric Keys

Find the numeric keys among the keyboard, and activate the Num Lock function to use these

numeric keys to enter numbers and calculations.

3-22

Getting Started

Cursor Keys

The four cursor (arrow) keys and [Home], [PgUp], [PgDn], [End] keys are used to control the cursor movement.

Move the cursor right for one space.

Move the cursor left for one space.

Move the cursor up for one line.

Move the cursor down for one line.

Move to the previous page.

Move to the next page.

Move to the beginning of the line (or document).

Move to the end of the line (or document).

3-23

Getting Started

The Backspace key, [Ins] and [Del] keys at upper right corner are use for editing purpose.

This key is used to switch the typing mode between “insert” and “overtype”

modes.

Press this key to delete one character to the right of the cursor and move the

following text left for one space.

Press this key to delete one character to the left of the cursor and move the

following text left for one space.

Function Keys

 Windows Keys

You can find the Windows Logo key (

keyboard, which are used to perform Windows-specific functions, such as opening the Start

menu and launching the shortcut menu. For more information of the two keys, please refer to

your Windows manual or online help.

 [Fn] Key

Switch the display output mode between the LCD, external monitor and

both.

) and one Application Logo key ( ) on the

3-24

Getting Started

Decrease the LCD brightness.

Enable or disable the touchpad function.

Increase the LCD brightness.

Decrease the built-in speaker’s volume.

Increase the built-in speaker’s volume.

Disable the computer’s audio function.

Force the computer into sleep state (depending on the system

configuration).

3-25

Getting Started

 Quick Launch [Fn] Buttons

Use the [Fn] buttons on the keyboard to activate the specific applications or tools.

With the help of these quick launch buttons, users will be able to do work more efficiently.

Cinema

Pro

ECO Engine

(Power Saving)

Webcam

WLAN (WiFi)

(optional)

 Press and hold the Fn button, and then press the F4 button to

launch the Cinema Pro function.

 Press and hold the Fn button, and then press the F5 button

repeatedly to switch among various power saving modes provided

by ECO Engine, or to turn this function off recurrently.

 Refer to the Power Management section in chapter 3 of this

manual for the detailed information of this ECO Engine, Power

Saving Function.

 Press and hold the Fn button, and then press the F6 button to turn

the Webcam function on. Press again to turn it off.

 Press and hold the Fn button, and then press the F8 button

repeatedly to turn the Wireless LAN (WiFi) function on or off recurrently.

3-26

Getting Started

Bluetooth

(optional)

 Press and hold the Fn button, and then press the F9 button to turn

the Bluetooth function on. Press again to turn it off.

 Press and hold the Fn button, and then press the F10 button to turn

the 3G function on. Press again to turn it off.

 This 3G function is optional supported depending on the model

users purchased. This function button will not be available when the 3G function is not supported.

3-27

Getting Started

The touchpad figures shown

here are for referen ce only,

and may be different from

the notebook that users

purchased.

Knowing the Touchpad

The touchpad integrated in your notebook is a pointing device that is compatible with standard

mouse, allowing you to control the notebook by pointing the location of the cursor on the screen and

making selection with its two buttons.

1. Cursor Movement Area

This pressure-sensitive area of the touchpad,

allows you to place your finger on and

control the cursor on the screen by moving

one of your finger.

2. Right / Left Buttons

Acts as the mouse’s right/ left button.

3-28

Getting Started

Using the Touchpad

Read the following description to learn how to use the touchpad:

 Configuring the Touchpad

You can customize the pointing device to meet your personal needs. For example, if you are a

left-handed user, you may want to swap the functions of the two buttons. In addition, you can

change the size, shape, moving speed and other advanced features of the cursor on the screen.

To configure the touchpad, you can use the standard Microsoft or IBM PS/2 driver in your

Windows operating system. The Mouse Properties in Control Panel allows you to change the configuration.

 Positioning and Moving

Place your finger on the touchpad (usually using the forefinger), and the rectangular pad will act

as a miniature duplicate of your display. When you move your fingertip across the pad, the

cursor on the screen will move simultaneously to the same direction. When your finger

reaches the edge of the pad, lift your finger and place it on a proper location of the touchpad to

continue the movement.

 Point and Click

When you have moved and placed the cursor over an icon, a menu item or a command that you

want to execute, simply tap slightly on the touchpad or press the left button to select. This

procedure, called as point and click is the basics of operating your notebook. Unlike the

traditional pointing device such as the mouse, the whole touchpad can act as a left button, so

3-29

Getting Started

that your each tap on the touchpad is equivalent to pressing the left button. Tapping twice

more rapidly on the touchpad is to execute a double-click.

 Drag and Drop

You can move files or objects in your notebook by using drag-and-drop. To do so, place the

cursor on the desired item and slightly tap twice on the touchpad, and then keep your fingertip in

contact with the touchpad on the second tap. Now, you can drag the selected item to the

desired location by moving your finger on the touchpad, and then lift your finger from the

touchpad to drop the item into place. Alternately, you can press and hold the left button when

you select an item, and then move your finger to the desired location; finally, release the left

button to finish the drag-and-drop operation.

1. Move the cursor by sliding

your fingertip.

2. Put your wrist on the desk

comfortably.

3-30

Getting Started

About Hard Disk Drive

Your notebook is equipped with a 2.5-inch hard disk drive. The hard disk drive is a storage device

with much higher speed and larger capacity than other storage devices, such as the floppy disk drive

and optical storage device. Therefore, it is usually used to install the operating system and

software applications.

To avoid unexpected data loss in your system, please backup your critical files regularly.

Do not turn off the notebook when the hard disk In-use LED is on.

Do not remove or install the hard disk drive when the notebook is turned on. The replacement of

hard disk drive should be done by an authorized retailer or service representative.

3-31

Getting Started

Using the Optical Storage Device

Your notebook is equipped with an optical storage device. The actual device preinstalled in your

notebook depends on the model you purchased.

 DVD Super Multi: This device allows you to read DVD and CD, and record CD format.

 Blu-ray: It is a high-capacity optical disc that holds 4.5 hours of high-definition video (HD) on a

single-sided, single-layer 25GB disk. Blu-ray supports the more advanced H.264 and VC-1

video encoding algorithms (codecs) as well as MPEG-2, which is used for DVD. It also supports

1080p, the highest HDTV resolution.

3-32

1. Confirm that the disk is

placed correctly and

securely in the tray

before closing the tray.

2. Do not leave the disk

tray open.

Getting Started

Inserting the Disk

The following instructions describe the

general procedure when operating the

optical storage device:

1. Confirm that the notebook is turned on.

2. Press the eject button on the panel and

the disk tray will slide out partially.

3. Gently pull the tray out until fully

extended.

4. Place your disk in the tray with its label

facing up. Slightly press the center of

the disk to secure it into place.

5. Push the tray back into the drive.

3-33

Getting Started

Removing the Disk

Follow the instructions below to remove the

disk that is placed in the optical storage

device:

6. Press the eject button on the drive’s

panel and the disk tray will slide out

partially.

7. Gently pull the tray out until fully

extended.

8. Hold the disk by its edge with your

fingers and lift it up from the tray.

9. Push the tray back into the drive.

3-34

Getting Started

The devices shown in the

reference figures here may

be different from the devices

users have.

Connecting the External Devices

The I/O (input/output) ports on the notebook allow you to connect peripheral devices. All devices

listed here are for reference only.

Connecting the Peripheral Devices

Connecting the USB devices

This notebook provides USB ports for connecting various USB devices, such as mouse, keyboard,

digital camera, webcam, printer, and external optical storage device, ete.. To connect these

devices, install the drivers for each device first if necessary, and then connect the device to the

notebook. This notebook is capable to auto detect the USB devices installed, and if there is no

detection of the devices, please manually enable the USB devices by going to Start Menu / Control

Panel / Add Hardware to add the new device.

3-35

Getting Started

Connecting the External Display Devices

This notebook provides a VGA port for connecting a larger display with higher resolution.

The 15-pin D-sub VGA port allows users to connect an external monitor or other standard

VGA-compatible device (such as a projector) for a great view of the notebook display.

3-36

Getting Started

This notebook provides a HDMI port for connecting a larger display with higher resolution. HDMI

(High Definition Multimedia Interface) is a new interface standard for PCs, displays and consumer

electronics devices that supports standard, enhanced and high-definition video, plus multi-channel

digital audio on a single cable.

To connect the external display, make sure the notebook and the external display are both powered

off, and then connect the display to the notebook.

Once the display is connected to the notebook, power on the notebook and the external display

should respond by default. If not, you can switch the display mode by pressing [Fn]+[F2].

Alternately, you can change the display mode by configuring the settings in Display Properties of Windows operating system.

3-37

Getting Started

Connecting the External SATA Hard Disk device

The E-SATA Connector allows you to connect an external Serial ATA hard disk device. Users can

now utilize shielded cable outside the notebook to take advantage of the benefits the SATA

interface brings to storage.

The E-SATA standard interface supports “plug-and-play” technology, so that you can connect and

remove the E-SATA devices without turning off the notebook.

To connect the E-SATA hard disk device, simply connect the cable of the device to the E-SATA

Connector of your notebook.

3-38

Getting Started

Connecting the Communication Devices

Using the LAN

The RJ-45 connector of the notebook allows you to connect the LAN (local area network) devices,

such as a hub, switch and gateway, to build a network connection.

For more instructions or detailed steps on connecting to the LAN, please ask your MIS staff or

network manager for help.

3-39

Getting Started

Using Wireless LAN Connection (optionally supported)

This notebook is equipped with wireless LAN module which allows users to perform fast data

transmission with the standard IEEE 802.11 for wireless LAN. This gives users the mobility to

move around within a broad coverage area and still be connected to the network.

By using the 64-bit/128-bit Wired Equivalent Privacy (WEP) encryption technology and Wi-Fi

Protected Access feature, the optional built-in wirelesses LAN is capable to achieve a more efficient

and a more secure solution to the wireless communication.

For more instructions or detailed steps on connecting to the Wireless LAN, please ask your MIS staff

or network manager for help.

3-40

Getting Started

Using Bluetooth Connection (optionally supported)

This notebook is equipped with Bluetooth module which allows users to connect various

Bluetooth-enabled devices to the notebook. Bluetooth provides a way to connect and exchange

information between devices such as mobile phones, personal computers, printers, GPS receivers,

PDAs, digital cameras, and video game consoles through a secure, globally unlicensed Industrial,

Scientific and Medical (ISM) 2.4 GHz short-range radio frequency bandwidth.

For more instructions or detailed steps on using the Bluetooth function, please ask your MIS staff or

network manager for help.

3-41

Getting Started

Components Replacement and Upgrade

Please be noticed that the memory, hard disk drive, Wireless LAN/ Bluetooth module and battery

pack preinstalled in the product users purchased may be upgradable or replaceable by user’s

request depending on the models users purchased.

3-42

Getting Started

This notebook is equipped with a high-capacity Li-ion battery

pack, and the battery pack is replaceable by users.

To replace the battery pack, please refer to the section of

Using the Battery Power

This notebook is equipped with a wireless LAN / Bluetooth

module, and the module may be upgradable and replaceable

by authorized dealer or service center.

This notebook is equipped with a hard disk drive, and this

storage device may be upgradable and replaceable by the authorized dealer or service center.

Additional memory module may be installed, by the authorized

dealer or service center, to increase the performance of this notebook, depending on the specification limitation.

for details.

3-43

Getting Started

To learn more about upgrade limitation, please refer to the specification in the User’s Manual

provided. For any further information about the product users purchased, please contact the local

dealer.

Do not attempt to upgrade or replace any component of the product, if you are not an authorized

dealer or service center, since it may cause the warranty void. It is strongly recommended to contact

the authorized dealer or service center for any upgrade or replace service.

This notebook is equipped with an optical drive device, and

this storage device may be upgradable and replaceable by the authorized dealer or service center.

CHAPTER 4

BIOS Setup

4-2

BIOS Setup

About BIOS Setup

When to Use BIOS Setup?

You may need to run the BIOS Setup when:

 An error message appears on the screen during the system booting up and is requested to

run SETUP.

 You want to change the default settings for customized features.

 You want to reload the default BIOS settings.

How to Run BIOS Setup?

To run the BIOS Setup Utility, turn on the notebook and press the [Del] key during the POST

procedure.

If the message disappears before you respond and you still wish to enter Setup, either restart the

system by turning it OFF and ON, or simultaneously pressing [Ctrl]+[Alt]+[Delete] keys to restart.

Be noted that the screen snaps and setting options in this chapter are for your references only.

The actual setting screens and options on your Notebook may be different because of BIOS update.

4-3

BIOS Setup

Control Keys

You can use only the keyboard to control the cursor in the BIOS Setup Utility.

Press left arrow to select one

menu title.

Press up arrow to select one item

under the menu title.

Increase the setting value or make changes.

Decrease the setting value or make changes.

1) Open the selected item to change setting options.

2) Bring up a sub-menu when available.

In some items, press this key to change setting field.

Bring up help screen providing the information of control keys.

1) Exit the BIOS Setup Utility.

2) Return to the previous screen in a sub-menu.

Press right arrow to select one

menu title.

Press down arrow to select one

item under the menu title.

The BIOS items and

figures shown here are

for reference onl y.

4-4

BIOS Setup

BIOS Setup Menu

Once you enter the BIOS Setup Utility, the Main Menu will appear on the screen. Select the tags to

enter the other menus.

Main Menu

Show system overview information about BIOS version, CPU features, memory

size and setting of system time and date.

Advanced Menu Adjust the advanced settings, such as RAID level 0, power consumption, USB/

PCI devices, of the notebook in order to achieve a better performance.

Boot Menu

Set up boot type and boot sequence.

Security Menu

Install or clear the password settings for supervisor and user.

Save & Exit Menu

Save or discard the changes before leaving the BIOS Setup Menu.

4-5

BIOS Setup

Main Menu

 System Date

This item allows you to set the system date. The date format is

[day:month:date:year].

Day

Month

Date

Yea r

 System Time

This item allows you to set the system time. The system clock will go on

no matter you shut down the PC or get into sleep mode. The time format

is [hour:minute:second].

 SATA Information

These items display the types of the SATA devices installed in the notebook.

Press [Enter] to bring up a window showing the detailed information of the device, including the device name, vendor, LBA mode, PIO mode and

more.

Day of the week, from Sun to Sat, which is determined by

BIOS (read-only).

The month from 01 (January) to 12 (December).

The date from 01 to 31.

The year can be adjusted by users.

4-6

BIOS Setup

 System Information

This item provides the information about the firmware, processor, and

system memory.

4-7

BIOS Setup

Advanced Menu

 Intel(R) SpeedStep(tm)

This item allows you to enable or disable Intel SpeedStep technology.

When set to Disabled, the system always operates in a conserve power

mode. If you want optimize the processor, set this item to Enabled, so that the processor’s speed will be controlled by the use of your operating

system and applications. Setting options: Enabled, and Disabled.

 SATA Mode Selection

Use this item to change the SATA Mode. Setting options: IDE, AHCI and

RAID.

 PCI Latency Timer

This item controls how long each PCI device can hold the bus before

another takes over. When set to higher values, every PCI device can

conduct transactions for a longer time and thus improve the effective PCI

bandwidth.

For better PCI performance, you should set the item to higher values.

Setting options: 32, 64, 96, 128, 160, 192, 224, and 248.

4-8

BIOS Setup

 iCharger Function

This notebook supports iCharger function. "iCharger" is the application

used to detect if the iPad is connected and you can use it to charge iPad in

Windows OS.

 System Performance

Select this item to enhance system performance.

 USB Configuration

Select this item to enter the sub-menu:

-- Legacy USB Support

Selecting Enabled allows users to use USB devices, such as mouse,

keyboard, or portable disk, in DOS system; or allows users to boot the

system by USB device. Setting options: Enabled, Disabled and

Auto.

4-9

BIOS Setup

Boot Menu

 Set Boot Priority

Configure settings during system boot.

 Boot Option #1, #2, #3, #4

These items allow you to set the sequence of boot devices where BIOS

attempts to load the disk operating system.

4-10

BIOS Setup

Security Menu

 Supervisor Password / User Password

When this item is selected, a message box shall appear on the screen as

below:

Enter New Password

Type a maximum of twenty-digit password and press [Enter]. The password typed now will replace any previously set password from CMOS

memory. You may also press [ESC] to abandon new password setting.

When the Supervisor Password is set, new items User Password

Password Check

Select User Password

Note that Supervisor Password field allows users to enter and change the

settings of the BIOS SETUP UTILITY, while User Password field only allows users to enter the BIOS SETUP UTILITY without having the

authorization to make any change.

will be added in the menu.

to give or to abandon password.

and

4-11

BIOS Setup

The Password Check item is used to specify the type of BIOS password protection that is implemented. Settings are described below:

Setup

The password is required only when users try to access to

BIOS SETUP UTILITY.

The password is required every time when the Notebook is

Always

powered on or when users try to access to BIOS SETUP

UTILITY.

To clear a set Supervisor Password/ User Password, just press [Enter]

under Supervisor Password/ User Password field when you are prompted to enter the password. Please note that when Supervisor

Password has been cleared, User Password will be cleared as well. A

message box will pop up confirming password will be disabled. Once the

password is disabled, the system will boot and user can enter setup without

entering password.

4-12

BIOS Setup

Save & Exit Menu

 Save Changes and Reset

Save the changes you have made and reset the utility

 Discard Changes and Exit

Ignore the previous configuration and exit the BIOS setup utility.

 Load Setup Defaults

Select this item to load the default settings.

RAID function may be

optionally supported by

model.

4-13

BIOS Setup

RAID Level 0 Introduction (Optionally Supported)

RAID level 0 is normally used to increase performance, which splits data evenly across two or more

disks with no parity information for redundancy. This allows one of the drives to read data while the

other drive is searching for and reading the next block.

NOTE: A RAID level 0 can be created with disks of different sizes, but the storage space added to

the array by each disk is limited to the size of the smallest disk.

CAUTION: RAID level 0 provides no redundancy. Therefore, a failure of one drive results in the loss

of all data. Regular backup helps data protection.

chiliGREEN MS-16F2 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
