chiliGREEN M730T User Manual [en, de, es, fr, it]
Introduction (English)
This Concise User’s Guide introduces the main features
of your computer. The English version of this guide begins on page 1. The expanded User’s Manual is on the
Device Drivers & Utilities + User’s Manual disc.
Einführung (Deutsch)
Dieses Ausführliche Benutzerhandbuch führt Sie in die
Hauptfunktionen des Notebooks ein. Die deutsche Version des Handbuchs beginnt auf Seite 43. Das erweiterte
Benutzerhandbuch finden Sie auf der Disc für die Gerätetreiber und Hilfsprogramme (Disc Device Drivers &
Utilities + User's Manual).
Présentation (Français)
Ce Guide Utilisateur Concis présente les fonctionnalités
principales de votre ordinateur. La version française de
ce guide commence à la page 85. Le Manuel de l'Utilisa-
teur étendu se trouve sur le disque de Pilotes & Utilitaires + Manuel de l'Utilisateur (disque Device Drivers &
Utilities + User's Manual).
Introducción (Español)
Esta Guía del Usuario Concisa le presenta las características principales de su ordenador. La versión española de
esta guía comienza en la página 127. El Manual del usua-
rio completo se encuentra en el disco de Controladores
del dispositivo y Utilidades + Manual del usuario (disco
Device Drivers & Utilities + User's Manual).
Introduzione (Italiano)
La presente Guida Rapida per l'Utente introduce le caratteristiche principali del computer. La versione italiana di
questa guida inizia da pagina 169. Il Manuale utente
completo si trova nel disco contenente driver e utilità +
Manuale utente (disco Device Drivers & Utilities +
User's Manual).
I
Contents
Notice .............................. ... ...... ....... ...... ...... .... ...... ...... ...... .... ...... ...... ....... ...... .1
About this Concise User Guide ..................................... ... ..............................2
Instructions for Care and Operation .................. ... ......................................... .3
System Startup ................................................................................................6
Model Differences ................................................ ... ... ... .................................7
System Software .............................................................................................8
Operating System Setup .................... ... ......................................... .................9
System Map: Front View with LCD Panel Open (Model A) .......................10
System Map: Front View with LCD Panel Open (Model B) .......................11
LED Indicators .............................................................................................12
Hot-Key Buttons & Keyboard ......................................................................13
System Map: Front & Rear Views ...............................................................15
System Map: Left View ................................................................................16
System Map: Right View .............................................................................17
System Map: Bottom View ..........................................................................18
Windows Vista Start Menu & Control Panel ...............................................19
Video Features ..............................................................................................20
Power Management Features ........................................................................21
Audio Features ..............................................................................................22
Driver Installation .............................. ... ......................................... ...............23
Wireless LAN Module ..................................................................................25
PC Camera ....................................................................................................26
3.5G Module ......................... ... .... .................................................................28
Fingerprint Reader ........................................................................................33
Intel Turbo Memory Module ........................................................................35
Bluetooth Configuration ...............................................................................36
Troubleshooting .................... ................................ ............................... ......... 38
Specifications ................................................................................................3 9
Inhalt
Hinweis ................................... ......................... .......................... ................... 43
Über das Ausführliche Benutzerhandbuch ...................................................44
Hinweise zu Pflege und Betrieb ................................................................... 45
Schnellstart ...................................................................... ............................. 48
Modellunterschiede ...................................................................................... 49
Systemsoftware .......................... ... ... .......................................... ...................50
Einrichten des Betriebssystems ....................................................................51
Systemübersicht: Ansicht von vorne mit geöffnetem
LCD-Bildschirm (Modell A) ........................................................................52
Systemübersicht: Ansicht von vorne mit geöffnetem
LCD-Bildschirm (Modell B) ........................................................................ 53
LED-Anzeigen ........................ ............. ............ ............. ............. ......... .......... 54
Hot-Key-Tasten & Tastatur .......................................................................... 55
Systemübersicht: Vorder- und Rückansicht .................................................57
Systemübersicht: Ansicht von links ............................................................. 58
Systemübersicht: Ansicht von rechts ............................................................59
Systemübersicht: Ansicht von unten ............................................................ 60
Windows Vista Startmenü und Systemsteuerung ......................................... 61
Grafikfunktionen .......................................................................................... 62
Energieverwaltungsfunktionen ........ .......................... ......................... .......... 63
Audiofunktionen ..................... ......................... ...................... ....................... 64
Installation der Treiber .................................... ... .... ...................................... 65
Wireless LAN ............................................................................................... 67
PC-Kamera ...................................................................... ............................. 68
3.5G-Modul .................................................................................................. 70
Fingerabdruckleser ....................................................................................... 75
Intel Turbo Memory-Modul .........................................................................77
Bluetooth-Konfiguration .............................................................................. 78
Fehlerbehebung ............................................................................................ 80
Technische Daten ......................................................................................... 81
II
Sommaire
Avertissement .......................... ................................................................... ..85
A propos de ce Guide Utilisateur Concis ..................................................... 86
Instructions d’entretien et d’utilisation .........................................................87
Guide de démarrage rapide ...........................................................................90
Différences entre modèles ............................................................................91
Logiciel système ...........................................................................................92
Configuration du système d'exploitation ......................................................93
Carte du système : Vue de face avec l’écran
LCD ouvert (Modèle A) ...............................................................................94
Carte du système : Vue de face avec l’écran
LCD ouvert (Modèle B) ...............................................................................95
Indicateurs ....................................................................................................96
Boutons Hot-Key & Clavier ........ ......................................... ........................97
Carte du système : Vues de face & arrière ...................................................99
Carte du système : Vue gauche ...................................................................100
Carte du système : Vue droite .....................................................................101
Carte du système : Vue de dessous .............................................................102
Menu Démarrer & Panneau de configuration de Windows Vista ..............103
Caractéristiques vidéo .................................................................................104
Caractéristiques de gestion de l’alimentation .............................................105
Caractéristiques Audio ...............................................................................106
Installation du pilote ...................................................................................107
Module LAN sans fil ..................................................................................109
Caméra PC ..................................................................................................110
Module 3.5G ...............................................................................................112
Lecteur d'empreintes digitales .................................... ... ... ..........................117
Module de mémoire Intel Turbo .................................................................119
Configuration Bluetooth . ............................................................................120
Dépannage .................................................................................................. 122
Spécifications ..............................................................................................123
Contenidos
Aviso .......................................................................................................... 127
Acerca de esta Guía del Usuario Concisa ...................................................128
Instrucciones para el cuidado y funcionamiento ........................................ 129
Guía rápida para empezar ...........................................................................132
Diferencias de modelos ..............................................................................133
Software de sistema ....................................................................................134
Configuración del sistema operativo ..........................................................135
Mapa del sistema: Vista frontal con panel
LCD abierto (Modelo A) ............................................................................ 136
Mapa del sistema: Vista frontal con panel
LCD abierto (Modelo B) ............................................................................137
Indicadores LED ........ .... ... ...................................... ... ... .............................. 138
Botones Hot-Key & teclado .......................................................................139
Mapa del sistema: Vistas frontal y posterior .............................................. 141
Mapa del sistema: Vista izquierda .......... ......................................... ... ........142
Mapa del sistema: Vista derecha .. ......................................... .... .................143
Mapa del sistema: Vista inferior ...................... ... ........................................ 144
Menú Inicio y Panel de control de Windows Vista .................................... 145
Parámetros de vídeo ........................................................ ........................... 146
Funciones de administración de energía .....................................................147
Características de audio ............................. ... ......................................... ... .. 148
Instalación de controladores ............ .... ......................................... ..............149
Módulo LAN Wireless ...............................................................................151
Cámara PC ..................................................................................................152
Módulo 3.5G ..............................................................................................154
Lector de huellas digitales .......................................................................... 159
Módulo de Turbo Memoria Intel ................................................................161
Configuración de Bluetooth ....................................................................... 162
Solución de problemas ............................................................................... 164
Especificaciones .................................................................... ..................... 165
III
Sommario
Avviso ................................ ................ ................... ................... ...................169
Informazioni sulla Guida Rapida per l'Utente ............................................170
Istruzioni per la custodia e il funzionamento ..............................................17 1
Guida di avvio rapido .................................................................................174
Differenze dei modelli ................................................................................175
Software del sistema ...................................................................................176
Installazione del sistema operativo .............................................................177
Descrizione del sistema: Vista anteriore con pannello
LCD aperto (Modello A) ............................................................................178
Descrizione del sistema: Vista anteriore con pannello
LCD aperto (Modello B) ............................................................................179
Indicatori LED ............................................................................................180
Pulsanti Hot-Key & tastiera ........................................................................181
Descrizione del sistema: Vista anteriore e posteriore .................................183
Descrizione del sistema: Vista sinistra .......................................................184
Descrizione del sistema: Vista destra .........................................................185
Descrizione del sistema: Vista inferiore .....................................................186
Menu Start e Pannello di controllo di Windows Vista ...............................187
Funzioni video ................................................ ............................................188
Funzioni di risparmio energetico ............. ......................................... ... .......189
Funzionalità audio ......................................................................................190
Installazione driver .................................. ... ......................................... .......191
LAN Wireless ....................................................... ......................................193
Camera PC ..................................................................................................194
Modulo 3.5G ......... ...................................... .... ... ...................................... ...196
Lettore d’impronte digitali ........... ......................................... ......................201
Modulo Intel Turbo Memory ......................................................................203
Configurazione Bluetooth ............... ... ......................................... ................204
Risoluzione dei problemi ............................................................................206
Specifiche tecniche .....................................................................................207
IV
Concise User’s Guide
Notice
The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this
publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted
or reduced to any machine readable form without prior consent from the vendor, manufacturer or creators of this publication, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or m ay not be copyrights and/or registe red trademarks
of their respective companies. They are mentioned for identification purposes only and are not intended as an endorsement of that product or its manufacturer.
©
August 2008
Trademarks
Intel and Intel Core are trademarks/registered trademarks of Intel Corporation.
English
Notice - 1
Concise User’s Guide
About this Concise User Guide
This quick guide is a brief introduction to getting your system started. This is a supplement, and not a substitute for
the expanded English language User’s Manual in Adobe Acrobat format on the Device Drivers & Utilities + User’s
Manual disc supplied with your computer. This disc also contains the drivers and utilities necessary for the proper
English
operation of the computer.
Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure
(or re-install) portions of the system, refer to the expanded User’s Manual. The Device Drivers & Utilities + User’s
Manual disc does not contain an operating system.
Regulatory Information
Regulatory notices and information are contained in the expanded User’s Manual on the Device Drivers & Utilities
+ User’s Manual disc.
Wireless Device Operation Aboard Aircraft
The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the wireless modules
are OFF if you are using the computer ab oa rd airc ra ft.
2 - About this Concise User Guide
Concise User’s Guide
Instructions for Care and Operation
The computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
• Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
• Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating element.
This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.
• A void interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag-
netic fields. These can hinder proper performance and damage your data.
• Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to
save your work. Remember to periodically save your data as data may be lost.
• Take care when using peripheral devices.
Servicing
Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply. Then refer servicing to qualified service personnel under any of the following conditions:
• When the power cord is damaged or frayed.
• If the computer has been exposed to any liquids.
• If the computer does not work no rmally when you follow the operating instructions.
• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your computer.
English
Instructions for Care and Operation - 3
Concise User’s Guide
Power Safety
The computer has specific power requirements:
• Only use an AC/DC adapter ap proved for use with this computer.
• Your AC/DC adapter may be designed for in ternational travel but it still requires a steady, uninterrupted power supply.
English
If you are unsure of your local power specifications, consult your service representative or local power company.
• The AC/DC adapter may have either a 2-prong or a 3-prong grounded plug. The third prong is an important safety feature; do not defeat its purpose. If you do not have access to a compatible outlet, have a qualified electrician install one.
• When you want to unplug the power cord, be sure to disconnect it by the plug head, not by its wire.
• Make sure the socket and any extension cord(s) you use can support the total current load of all the connected devices.
• Before cleaning the computer, make sure it is disconnected from any external power supplies.
Power Safety Warning
Before you undertake any upgrade procedures, make sure that you have turned off the power, and disconnected all peripherals and cables
(including telephone lines). It is advisable to also remove your battery in order to prevent accidentally turning the machine on.
Power Off Before Traveling
Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a notebook which
is powered on in a travel bag may cause the vent(s) to be blocked. To prevent your computer from overheating make sure nothing blocks
the vent(s) while the computer is in use.
Cleaning
Do not apply cleaner directly to the computer, use a soft clean cloth. Do not use volatile (petroleum distillates) or
abrasive cleaners on any part of the computer.
4 - Instructions for Care and Operation
Concise User’s Guide
Battery Precautions
• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.
• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way.
Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pac k repair or replacement to your servi ce representative or qualified service personnel.
• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully . Batteries
may explode or leak if exposed to fire, or improperly handled or discarded.
• Keep the battery away from metal appliances.
• Affix tape to the battery contacts before disposing of the battery.
• Do not touch the battery contacts with your hands or metal objects.
Battery Disposal & Caution
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life, under various
state and local laws, it may be illegal to dispose of this battery into the municipal waste stream. Check with your local solid waste officials
for details in your area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer.
Discard used battery according to the manufacturer’s instructions.
English
Instructions for Care and Operation - 5
Concise User’s Guide
System Startup
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports.
4. Attach the AC/DC adapter to the DC-In jack on the left of the computer (see page 7), then plug the AC power cord into an
English
outlet, and connect the AC power cord to the AC/DC adapter.
5. Use one hand to carefully raise the lid/LCD to a comfortable viewing angle
hand (as illustrated in Figure 1) to support the base of the computer (Note: Never lift the computer by the lid/LCD).
6. Press the power button to turn the computer “on” .
(do not exceed 130 degrees)
Shut Down
, while using the other
Note that you should always shut your computer down by choosing the Shut Down command from the Lock
Button Menu in Windows Vista. This will help prevent hard disk or system problems.
Figure 1 - Opening the Lid/LCD/Computer with AC/DC Adapter Plugged-In
6 - System Startup
Concise User’s Guide
Inserting the AC/DC Adapter Cable
Take care when connecting the AC/DC adapter cable
into the DC-In jack on the computer. The combination of
some case designs and AC/DC adapters will expose part
of the end of the adapter cable when connected to the
DC-In jack (see Figure 1 on page 6); this is a normal situation.
DO NOT insert the adapter cable into the DC-In jack any
further than necessary (i.e. until you meet resistance),
otherwise you may cause damage to the computer. The
LED indicator will be orange when the adapter
is connected.
Model Differences
This notebook series may include different design styles.
The exact outward appearance and some of the Hot-Key
buttons may appear slightly different from those illustrated in this manual, however all the ports, components and
functions etc. are the same for each design style.
Aluminum Covers
Note that this computer series includes some model designs with aluminum top covers. In order to clean this
type of cover use a soft, clean, slightly damp cloth to
carefully wipe of any marks (e.g. fingerprints). DO NOT
use volatile (petroleum distillates) or abrasive cleaners
on any part of the computer.
LED Backlight LCD (Optional for Model B Computers)
An LED Backlight LCD is available as an option for
Model B computers. These type of LCDs allow for greater color quality and consume less power than conventional fluorescent LCDs, and therefore can save
significant battery life.
English
Model Differences - 7
Concise User’s Guide
System Software
Your computer may already come with system software
pre-installed. Where this is not the case, or where you are
re-configuring your computer for a different system, you
English
will find this manual refers to the Microsoft Windows
Vista operating system
the drivers and utilities is available in Chapters 4 & 7 of
the expanded User’s Manual on the Device Drivers &
Utilities + User’s Manual disc.
If you are installing/re-installing new system software, you
will need to install the appropriate drivers. Drivers are programs which act as an interface between the computer and
a hardware component e.g. a wireless network module. It is
very important that you install the drivers in the order listed
in Table 5, on page 23. You will be unable to use most advanced controls until the necessary drivers and utilities are
properly installed.
. Further information on installing
Drivers
Operating Systems Supported
Operating
System
Windows XP
(Home Edition or
Professional)
Windows Vista
with Service
Pack 1 (64-bit)
Home Basic/
Home Premium/
Business/
Enterprise/
Ultimate Editions
For information on the Windows XP
OS see the Device Drivers & Utilities +
User’s Manual disc.
Make sure you install Windows Vista
Service Pack 1 (or a Windows Vista
version which includes Service Pack 1)
before installing any drivers. Go to
the Microsoft website for download
details, or contact your service center.
In order to run Windows V ist a without
limitations or decreased performance,
your computer requires a minimum
1GB of system memory (RAM).
Note
Not Included
Operating Systems (e.g. Windows Vista/Windows XP)
and applications (e.g. word processing, spreadsheet and
database programs) have their own manuals, so please
consult the appropriate manuals.
8 - System Software
Concise User’s Guide
Operating System Setup
If you are installing new system software, or are re-configuring your computer for a different system, make sure you
configure the appropriate OS setting in the BIOS before installing a new operating system.
1. Start-up the computer and press <F2> to enter the BIOS.
2. Go to the Advanced menu, select "Installed O/S" and make sure the appropriate operating system is selected.
3. Go to the Exit menu and select "Exit Saving Changes" (or press F10) and press Enter to exit the BIOS and
reboot the computer.
Main Advanced Security Boot Exit
Advanced Chipset Control
Installed O/S: [Vista]
SATA Mode Selection: [AHCI]
DFOROM(Robson) Support: [Disabled]
Reset Configuration Data: [No]
Boot-time Diagnostic Screen: [Disabled]
Legacy OS Boot: [Enabled]
Power On Boot Beep [Disabled]
Battery Low Alarm Beep: [Disabled]
FAN Control: [Automatic]
Only available if Windows Vista
is selected as the O/S.
F1 Help Select Item -/+ Change Values F9 Setup Defaults
Esc Exit Select Menu Enter Select Sub-Menu F10 Save and Exit
Phoenix SecureCore(tm) Setup Utility
Advanced
Item Specific Help
Select options for
Advanced Chipset
features.
SATA Mode Selection & Intel Turbo
Memory Module
If you select the Vista O/S then the SATA
Mode Selection menu will become avail-
able.
If you have included an Intel Turbo Memory
module in your purchase configuration you
will need to enable
Support
" and then install the driver (see
“Intel Turbo Memory Module” on
page 35).
"DFOROM (Robson)
English
Figure 2 - BIOS (Operating System Selection)
Operating System Setup - 9
Concise User’s Guide
Figure 3
Front View with LCD
Panel Open (Model A)
1. Built-In PC Camera
English
(Optional)
2. LCD
3. Speakers
4. Power Button
5. Hot-Key Buttons
6. LED Status Indicators
7. Keyboard
8. Touchpad & Buttons
9. LED Power &
Communication
Indicators
10. Fingerprint Module
(Optional)
11. Built-In Microphone
Note the cleaning instructions for aluminum covers - see page 7.
System Map:
(Model A)
3
8
Front View with LCD Panel Open
1
Operation Aboard Aircraft
2
3
6
4
5
7
The use of any portable electronic
transmission devices aboard aircraft is
usually prohibited. Make sure the wire-
less modules are OFF if you are using the computer aboard aircraft.
Use the appropriate function key combination (see
toggle power to the wireless modules
(3.5G/WLAN/Bluetooth), and check the
LED indicator / to see if the
modules are powered on or not (see
Table 2, on page 12).
Wireless Device
Table 4, on page 14) to
6
9
10
11
10 - System Map: Front View with LCD Panel Open (Model A)
5
4
Concise User’s Guide
System Map:
Front View with LCD Panel Open
(Model B)
Wireless Device
Operation Aboard Aircraft
The use of any portable electronic transmi ssi on
devices aboard aircraft is usually prohibited.
Make sure the wireless modules are OFF if
you are using the computer aboa rd aircra ft.
Use the appropriate function key combination
(see
Table 4, on page 14) to toggle power to the
wireless modules (3.5G/WLAN/Bluetooth), and
check the LED indicator
modules are powered on or not (see
page 12
).
7
TouchPad buttons
(valid operation area)
/ to see if the
Table 2, on
Front View with LCD
Figure 4
English
Panel Open (Model B)
1. Built-In PC Camera
(Optional)
2. LCD
3. Power Button
4. Hot-Key Buttons
5. LED Status Indicators
6. Keyboard
7. Touchpad & Buttons
8. LED Power &
Communication
Indicators
9. Fingerprint Module
(Optional)
10. Built-In Microphone
10
1
2
3
4
5
6
Note the cleaning in-
7
structions for aluminum covers - see
8
9
page 7.
System Map: Front View with LCD Panel Open (Model B) - 11
Concise User’s Guide
LED Indicators
The two sets of LED indicators (LED Status Indicators
and LED Power & Communication Indicators) on the
computer display helpful information about the current
English
status of the computer.
Icon Color Description
Green Silent Mode Activated (see over)
Off
Green Hard Disk Activity
Green Number Lock Activated
Green Caps Lock Activated
Green Scroll Lock Activated
Normal Mode Activated (see
over)
Table 1 - LED Status Indicators
Icon Color Description
Orange DC Power is Plugged In
Green The Computer is On
Blinking Green
Orange The Battery is Charging
Green The Battery is Fully Charged
Blinking Orange
Green
Orange
Green
The Computer is in Sleep
Mode
The Battery Has Reached
Critically Low Power Status
The (optional) Wireless LAN
Module is Powered On
The (optional) Bluetooth
Module is Powered On
The (optional) 3.5G Module
is Powered On
Table 2 - LED Power & Communication Indicators
12 - LED Indicators
Concise User’s Guide
Hot-Key Buttons & Keyboard
The Hot-Key buttons give instant access to the default Internet browser and e-mail program, and allow you to toggle the Silent Mode on/off with one quick button press.
Hot-Key Button Function
Activate the Default E-Mail Browser
Activate the Default Internet Program
Toggle *Silent Mode (for power sav-
ing)
Table 3 - Hot-Key Buttons
*When enabled, Silent Mode will reduce fan noise and
save power consumption. Note this may reduce computer
performance.
The keyboard has a numeric keypad for easy numeric
data input, and features function keys to allow you to
change operational features instantly.
Keypad
Function Keys
NumLk &
ScrLk
Numeric Keypad
Fn Key
3.5G
Module
Power
Toggle
Figure 5 - Keyboard
Special Characters
Some software applications allow the number-keys to be
used with Alt to produce special characters. These special
characters can only be produced by using the numeri c keypad. Regular number keys (in the upper row of the keyboard) will not work. Make sure that NumLk is on.
English
Hot-Key Buttons & Keyboard - 13
Concise User’s Guide
Function Keys & Visual Indicators
The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the
basic function key combinations; visual indicators (see the table below) are available when the hot key utility is installed (see “Hot Key” on page 24). After installing the driver an icon will appear in the taskbar.
English
Keys Function/Visual Indicators Keys Function/Visual Indicators
Fn + ~ Play/Pause (in Audio/Video Programs) Fn +F8/F9
Fn +
Fn + F1 TouchPad Toggle Fn + F11
Fn + F2
Fn + F3 Mute Toggle Fn + NumLk Number Lock (Numeric Keypad) Toggle
Fn + F4 Sleep Toggle Fn + ScrLk Scroll Lock Toggle
Fn +
F5/F6
Fn + F7 Display Toggle
3.5G Module
Power Toggle
Turn LCD Backlight Off (Press a key to or use
TouchPad to turn on)
Volume Decrease/
Increase
14 - Hot-Key Buttons & Keyboard
Brightness
Decrease/Increase
Fn + F10
Fn + F12
PC Camera Power
Toggle
WLAN Module
Power Toggle
Bluetooth Module
Power Toggle
Silent Mode Toggle
Table 4 - Function Keys & Visual Indicators
Concise User’s Guide
System Map: Front & Rear Views
1
2
1
2
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) /
MS Pro (Memory Stick Pro) / MS Duo (requires PC adapter) /
Mini SD (requires PC adapter) / RS MMC (requires PC adapter)
Front
3
5
4
Rear
Model A
Front
Rear
Model B
6
6
7-in-1 Card Reader
4
3
5
Figure 6
Front & Rear Views
1. LED Power & Communication Indicators
2. 7-in-1 Card Reader
3. S/PDIF-Out Jack
4. Microphone-In Jack
5. Headphone-Out Jack
6. Battery
English
System Map: Front & Rear Views - 15
Concise User’s Guide
Figure 7
Left View
1. DC-In Jack
2. RJ-45 LAN Jack
3. External Monitor Port
English
4. Vent
5. 2 * USB 2.0 Ports
6. ExpressCard/54(34)
Slot
System Map: Left View
2
1
2
1
Overheating
To prevent your computer from overheating make sure nothing blocks the
vent while the computer is in use.
3
3
Model A
Model B
The ExpressCard slot accepts either ExpressCard/34 or ExpressCard/54 formats.
4
4
ExpressCard Slot
5
6
5
5
6
5
16 - System Map: Left View
Concise User’s Guide
System Map: Right View
Model A
1
2
Model B
1
2
CD Emergency Eject
If you need to manually eject a CD/
DVD (e.g. due to an unexpected power
interruption) you may push the end of a
straightened paper clip into the emergency eject hole. Do not use a sharpened pencil or similar object that may
break and become lodged in the hole.
Media Warning
Don’t try to remove a floppy disk/CD/
DVD while the system is accessing it.
This may cause the system to “crash”.
Go to the Control Panel and double-click Device
Manager (Hardware and Sound), then click the +
next to DVD/CD-ROM drives. Double-click on the
DVD-ROM device to bring up the Properties dialog
box, and select the DVD Region (tab) to bring up the
control panel to allow you to adjust the reg ional cod e.
DVD region detection is device dependent, not OSdependent. You can select your module’s region code
5 times. The fifth selection is permanent. This cannot
be altered even if you change your operating system
or you use the module in another computer.
3
3
4
5
5
4
Changing DVD Regional Codes
Figure 8
RIght View
1. Optical Device Drive
Bay
2. Emergency Eject Hole
3. USB 2.0 Port
4. RJ-11 Modem Jack
5. Security Lock Slot
English
System Map: Right View - 17
Concise User’s Guide
Figure 9
Bottom View
1. Battery
2. Hard Disk Bay Cover
English
(3.5G Module/Intel
Turbo Memory Module
Location)
3. RAM & CPU Bay Cover
4. Vent
5. Speakers
System Map: Bottom View
1
2
3
Model A
CPU
The CPU is not a user serviceable part. Accessing the CPU in any way may violate
your warranty.
Overheating
To prevent your computer from overheating
make sure nothing blocks the vent while the
computer is in use.
Always completely discharge, then fully
charge, a new battery before using it.
Completely discharge and charge the
battery at least once every 30 days or after about 20 partial discharges.
2
5
Battery Information
Model B
1
3
4
4
5
18 - System Map: Bottom View
Concise User’s Guide
Windows Vista Start Menu & Control Panel
Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive,
and a shortcut will usually be placed in the Start menu and/or the desktop. Right-click the Start menu icon , and
then select Properties if you want to customize the appearance of the Start menu.
Click here to toggle Classic View
Figure 10 - Start Menu & Control Panel
In many instances throughout this manual you will see an instruction to open the Control Panel. The Control Panel
is accessed from the Start menu, and it allows you to configure the settings for most of the key features in Windows
(e.g. power, video, network, audio etc.). Windows Vista provides basic controls for many of the features, however
many new controls are added (or existing ones are enhanced) when you install the drivers listed in Table 5, on
page 23. To see all controls it may be necessary to toggle to Classic View.
English
Windows Vista Start Menu & Control Panel - 19
Concise User’s Guide
Video Features
You can switch display devices, and configure display options, from the Display Settings control panel (in Personalization) in Windows Vista.
To access Windows Vista Display Settings:
English
1. Click Start, and click Control Panel (or point to Settings and click
Control Panel).
2. Click Adjust screen resolution under th e Appear ance and
Personalization menu (or double-click Personalization > Display
Settings).
3. Move the slider to the preferred setting in Resolution: .
4. Click the arrow, and scroll to the preferred setting in Colors: .
5. Click Advanced Settings (button) to bring up the Advanced
Settings tabs.
6. Click Graphics Properties (button) to access the Intel GMA
control panel (this control panel can also be accessed by doubleclicking Intel(R) GMA Driver for mobile in Classic View).
7. The Intel GMA control panel can also be accessed by clicking the icon
in the taskbar and selecting Graphics Properties from the menu.
3
4
1
2
1
Figure 11
Display
Settings
Desktop
2
3
4
Display Devices & Options
Besides the built-in LCD, you can also use an external VGA monitor (CRT) or external Flat Panel Display
connected to the external monitor port as your display device.
20 - Video Features
Concise User’s Guide
Power Management Features
The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 19) allows you to
configure power management features for your computer. You can conserve power by means of power plans
and configure the options for the power button, sleep button, computer lid (when closed), display and sleep
mode from the left menu. Note that the Power saver plan may have an affect on computer performance.
Click to select one of the existing plans, or click Create a power plan in the left menu and select the options to
create a new plan. Click Change Plan Settings and click Change advanced power settings to access further
configuration options.
Note: Sleep is the default power saving state in Windows Vista
English
Figure 12 - Power Options
Power Management Features - 21
Concise User’s Guide
English
The sound volume level is
set using the volume control within Windows (and
the volume function keys
on the computer). Click
the Volume icon in the
taskbar to check the setting.
Sound Volume
Adjustment
Figure 13
Realtek Audio
Manager
Audio Features
You can configure the audio options on your computer from the Sound control panel
in Windows, or from the Realtek HD Audio Manager
trol panel (right-click the taskbar icon to bring up an audio menu). The volume may
also be adjusted by means of the Fn + F5/F6 key combination.
Right-click the icon
to access the menu
above.
/ icon in the taskbar/con-
22 - Audio Features
Concise User’s Guide
Driver Installation
The Device Drivers & Utilities + User’s Manual disc
contains the drivers and utilities necessary for the proper
operation of the computer. Insert the disc and click In-
stall Drivers (button), or Option Drivers (button) to ac-
cess the Optional driver menu.
Install the drivers in the order indicated in Table 5. After installing each driver it will become grayed out (if you
need to reinstall any driver, click Unlock).
Manual Driver Installation
Click the Browse CD button in the Drivers Installer application and browse to the executable file in the appropriate driver folder.
Windows Update
After installing all the drivers make sure you enable
Window Update in order to get all the latest security updates etc. (all updates will include the latest hotfixes
from Microsoft).
Driver - Windows Vista with SP 1 Page#
English
Chipset page 24
Video page 24
Audio page 24
Modem page 24
LAN page 24
Touchpad page 24
CardReader page 24
Hotkey page 24
Wireless LAN Module (Optional) page 25
PC Camera (Optional) page 26
3.5G Module (Optional) page 28
Fingerprint Reader (Optional) page 33
Intel Turbo Memory Module (Optional) page 35
Bluetooth Module (Optional)
Note: No driver installation required (see page 36)
Enable Windows Update (see left)
Table 5 - Driver Installation
Driver Installation - 23
Concise User’s Guide
New Hardware Found
If the
Found New Hardware
stallation procedure, click Cancel to close the window,
and follow the installation procedure as directed.
wizard appears
during the in-
English
Chipset
1. Click 1.Install Chipset Driver > Yes.
2. Click Next > Yes > Next > Next.
3. Click Finish.
Video
1. Click 2.Install Video Driver > Yes.
2. Click Next > Yes > Next > Next.
3. Click Finish to restart the computer.
Audio
1. Click 3.Install Audio Driver > Yes.
2. Click Next.
3. Click Finish to restart the computer.
Modem
1. Click 4.Install Modem Driver > Yes.
2. Click OK.
3. The modem is ready for dial-up configuration.
LAN
1. Click 5.Install LAN Driver > Yes.
2. Click Next > Install.
3. Click Finish.
TouchPad
1. Click 6.Instal l Touchpad Driver > Yes.
2. Click Next.
3. Click Finish > Restart Now to restart the computer.
CardReader
1. Click 7.Install CardReader Driver > Yes.
2. Click Next > Install.
3. Click Finish.
Hot Key
1. Click 8.Install Hotkey Driver > Yes.
2. Click Next > Install.
3. Click Finish > Finish to restart the computer.
24 - Driver Installation
Loading...
