INSTALLATION INSTRUCTIONS
Universal Wall Mounting Bracket
PAC392
PAC392 Installation Instructions
DISCLAIMER
Milestone AV Technologies, and its affiliated corporations and
subsidiaries (collectively, "Milestone"), intend to make this
manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Milestone
makes no representation of warranty, expressed or implied,
regarding the in formation cont ai ned her ein. Mil estone assu mes
no responsibility for accuracy, completeness or sufficiency of
the information contained in this document.
Chief® is a regist ered t rademark of Mil estone AV Technol ogies .
All rights reserved.
WARNING: Failure to read, thoroughly understand, and
follow all instructions can result in serious personal injury,
damage to equipment , or voi ding of f act ory wa rrant y! It is the
installer’s responsibility to make sure all components are
properly assembl ed and installed using the instructions
provided.
WARNING: Failure to provide adequate structural strength
for this component can result in serious personal injury or
damage to equipment! It is the installer’s responsibility to
make sure the structure to which this component is attached
can support five t imes the combi ned wei ght of al l equ ipment.
Reinforce the structure as required before installing the
component.
IMPORTANT WARNINGS AND
CAUTIONS!
WARNING: A WARNING alerts you to the possibility of
serious injury or death if you do not follow the instructions.
CAUTION: A CAUTION alerts you to the possibility of
damage or destruction of equipment if you do not follow the
corresponding instructions.
LEGEND
Tighten Fastener
Apretar elemento de fijación
Befestigungsteil festziehen
Apertar fixador
Serrare il fiss aggio
Bevestiging vas tdraaien
Serrez les fixations
Loosen Fastener
Aflojar elemento de fijación
Befestigungsteil lösen
Desapertar fixador
Allentare il fissaggio
Bevestiging losdraaien
Desserrez les fixations
WARNING: Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make s ure the combined we ight of
all components attached to this bracket does not exceed the
weight rating of the rail mount attached to this bracket.
Adjust
Ajustar
Einstellen
Ajustar
Regolare
Afstellen
Ajuster
Remove
Quitar
Entfernen
Remover
Rimuovere
Verwijderen
Retirez
Hex-Head Wrench
Llave de cabeza hexagonal
Sechskantschlüssel
Chave de cabeça sextavada
Chiave esagonale
Zeskantsleut el
Clé à tête hexagonale
Open-Ended Wrench
Llave de boca
Gabelschlüssel
Chave de bocas
Chiave a punte aperte
Steeksleutel
Clé à fourche
2
Installation Instructions PAC392
REQUIRED TOOLS AND INCLUDED PARTS
34.16
1/2"
1/8"
(Provided)
C (4)
A (2)
B (4)
5/16"
5/16"
DIMENSIONS
12.49
.492
203.20
8.000
130.91
5.154
101.60
4.000
76.20
3.000
69.85
2.750
1.345
13.22
.520
152.40
6.000
143.12
5.635
D (1)
1/8"
25.40
1.000
3
PAC392 Installation Instructions
INSTALLATION
WARNING: FAILURE TO PROVIDE ADEQUATE
STRUCTURAL STRENGTH FOR THIS COMPONENT CAN
RESULT IN SERIOUS PERSONAL INJURY OR DAMAGE
TO EQUIPMENT! It is the installer’s responsibility to make
sure the structure to which this component is attached can
support five times the combined weight of all equipment.
Reinforce the structure as required before installing the
component.
NOTE: The PAC392 is compatible with the following wall
mounts: RMF2, RMT2, RLF2, RLT2.
1. Verify mounting brackets on wall bracket (A) can move
freely. (See Figure 1)
(A)
1
x 4
2
4
(A)
(A)
3
4
Figure 2
5. Tighten two upper and lower button head cap screws to
secure wall bracket (A) to wall. (See Figure 3)
6. Repeat for second wal l bracket (A).
Figure 1
2. Locate desired installation location and slide upper
mounting plate into wall making sure bracket is seated in
channel bottom. (See Figure 2)
3. Let lower mounting plate rest against wall.
4. Using 1/2" socket , tighten tension screw until lower
mounting plate slides into channel in wall and continue
tightening until resistance is felt. (See Figure 2)
A
x4
5
5
Figure 3
4
Installation Instructions PAC392
IMPORTANT ! : If the display being installed has a recessed
mounting surface, the display must be assembled to the mount
prior to mount installation. See the installation instructions
included with the mount.
7. Install mount to PAC-392 using four 5/16" flat washers (B)
and four 5/16" lock nuts (C). (See Figure 4)
Slat wall
(A)
(C) x 4
8. Attach display to mount.
Mount
(B) x 4
Figure 4
5
PAC392 Installation Instructions
6
Installation Instructions PAC392
7
PAC392 Installation Instructions
Chief Manufactur ing, a products division
of Milestone AV Technologies
8834-002001 Rev00
©2010 Milestone AV Technologies, a
Duchossois Group Company
www.chiefmfg.com
07/10
