CHIEF MTMPU User Manual

INSTALLATION INSTRUCTIONS

FUSION PORTRAIT MEDIUM TILT MOUNT

Spanish Product Description

German Product Description

Portuguese Product Description

Italian Product Description

Dutch Product Description

French Product Description

MTMPU

MTMPU Installation Instructions

DISCLAIMER

Milestone AV Technologies, and its affiliated corporations and
subsidiaries (collectively “Milestone”), intend to make this
manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Milestone
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Milestone assumes
no responsibility for accuracy, completeness or sufficiency of
the information contained in this document.

WARNING: Never operate this mounting system if it is

damaged. Return the mounting system to a service center for
examination and repair.

WARNING: Do not use this product outdoors.

IMPORTANT ! :

mounted to an 8" concrete, 8"x8"x16" concrete block or 2" x 4"
wood studs (16" on center) wall.

The MTMPU mounts are designed to be

--SAVE THESE INSTRUCTIONS--

Chief® is a registered trademark of Milestone AV Technologies.
All rights reserved.

IMPORTANT SAFETY INSTRUCTIONS!

WARNING: A WARNING alerts you to the possibility of

serious injury or death if you do not follow the instructions.

CAUTION: A CAUTION alerts you to the possibility of

damage or destruction of equipment if you do not follow the
corresponding instructions.

WARNING: Failure to read, thoroughly understand, and

follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all components are
properly assembled and installed using the instructions
provided.

WARNING: Failure to provide adequate structural strength

for this component can result in serious personal injury or
damage to equipment! It is the installer’s responsibility to
make sure the structure to which this component is attached
can support five times the combined weight of all equipment.
Reinforce the structure as required before installing the
component. The wall to which the mount is being attached
may have a maximum drywall thickness of 5/8” (1.6cm) for
wood studs.

WARNING: Exceeding the weight capacity can result in

serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components located between the MTMPU up to (and
including) the display does not exceed 125 lbs (56.7 kg).

WARNING: Use this mounting system only for its intended

use as described in these instructions. Do not use
attachments not recommended by the manufacturer.

2

Installation Instructions MTMPU

18.57

471.7

00.

0

0

0.0

3.81

96.8

+10.5

MAX TILT

-3

MIN TILT

4.86

123.4

7.00

177.8

0.32

8.1
0

NOTES:

MINIMUM HORIZONTAL MOUNTING PATTERN 3.937" [100 mm]

MAXIMUM HORIZONTAL MOUNTING PATTERN WITHOUT SWITCHING KNOB, 15.75" [400 mm]

MAX HORIZONTAL MOUNTING PATTERN WITH SWITCHING KNOB, 18.10" [460 mm]

FOR RECESSED APPLICATIONS, MINIMUM VERTICAL LIFT FOR HOOK ENGAGEMENT IS .58" [14.7 mm]

OVERALL MOUNT DEPTH AT 0

OF TILT IS 2.40" [61 mm]

MAXIMUM VERTICAL MOUNTING PATTERN IS 23.6" [600 mm]

MAX MOUNTING PATTERN IS 21.6" (548.6 mm) WITHOUT REVERSING UPRIGHTS
MAX MOUNTING PATTERN IS 26.2" (665.5 mm) WITH REVERSING UPRIGHTS

FOR RECESSED APPLICATIONS, MINIMUM VERTICAL LIFT FOR HOOK
ENGAGEMENT IS .42" (10.7 mm)

RAILS CAN BE SLID LEFT OR RIGHT FOR OFFSET APPLICATIONS
MOUNT IS 1.99" (50.5 mm) DEEP WHEN FLAT TO THE WALL

MEASUREMENTS IN: [MILLIMETERS]
INCHES

Tighten Fastener

Apretar elemento de fijación
Befestigungsteil festziehen
Apertar fixador
Serrare il fissaggio
Bevestiging vastdraaien
Serrez les fixations

Loosen Fastener

Aflojar elemento de fijación
Befestigungsteil lösen
Desapertar fixador
Allentare il fissaggio
Bevestiging losdraaien
Desserrez les fixations

Hex-Head Wrench

Llave de cabeza hexagonal
Sechskantschlüssel
Chave de cabeça sextavada
Chiave esagonale
Zeskantsleutel
Clé à tête hexagonale

Pencil Mark

Marcar con lápiz
Stiftmarkierung
Marcar com lápis
Segno a matita
Potloodmerkteken
Marquage au crayon

Drill Hole

Perforar
Bohrloch
Fazer furo
Praticare un foro
Gat boren
Percez un trou

By Hand

A mano
Von Hand
Com a mão
A mano
Met de hand
À la main

DIMENSIONS

LEGEND

3

MTMPU Installation Instructions

#2

7/32” (5.5mm) Wood Stud
3/8” (9.5mm) Concrete

3/16” (included)

M5 (included)

D3 (6)

D5 (6)

A (1)

B (1)

D1 (8)
M4x16mm

D2 (6)
M4x20mm

M4x25mm

D4 (6)
M5x16mm

M5x20mm

D6 (6)
M5x25mm

D7 (6)
M6x16mm

D8 (6)
M6x25mm

D15 (1)
M5

D9 (6)
M8x20mm

D10 (6)
M8x30mm

D11 (4)
M8x50mm

D13 (8)
.750x.323x.250

D14 (8)
.750x.344x.500

D12 (8)

E1 (4)
UX10

E3 (4)
5/16”

E2 (4)
5/16” x 2 1/2”

D (1)

[Wall Mount]

[Right Upright]

C (1)
[Left Upright]

[Universal
Washer]

E (1)

F (1)

3/16 x 6"

TOOLS REQUIRED FOR INSTALLATION

PARTS

4
