Cherry MW 2310 2.0 User Manual

CHERRY MW 2310 2.0

Wireless Mouse

Key Benefits

• 6-button mouse: Optical sensor and adjustable resolution

(1000/1600/2400 dpi)

• Nano USB receiver: can stay plugged into in the notebook

permanently

• Long battery lifespan thanks to energy-efficient infrared

sensor

• Optimized for both left-handed and right-handed operation

• Elegant touch due to the chrome plated scroll wheel with non-

slip rubber coating

• Easy to install, requiring no technical knowledge

• Interference-free, wireless 2.4 GHz technology (with a range

of approx. 10 m)

Models may vary from the image shown

Wireless freedom – battery life of up to 3
years

The CHERRY MW 2310 2.0 is a versatile 6-button wireless mouse
with 2.4 GHz technology and an ergonomic design.

Its nano USB receiver is so small that it can safely stay inside the
notebook even when you're on the move – the mouse is always
ready for use.

The CHERRY MW 2310 2.0 has an optical sensor with 3 adjustable
resolutions (1000/1600/2400 DPI). Using the DPI switch on the
top of the mouse, the resolution can be selected at the touch of a
button. An LED indicates the selected DPI.

The technical concept makes the successor to the legendary
CHERRY MW 2310 especially energy-efficient. With just one set of
the supplied batteries (2 x AA), the mouse can be operated for up
to 3 years before they have to be changed. The mouse has an
On/Off switch on the bottom so it can be switched off completely
when not in use.

Advanced materials, a comfortable feel and great versatility make
the CHERRY MW 2310 2.0 what it is – the CHERRY mouse for
superior performance at a surprisingly low price.

Technical Data

Weight (product)

approx. 122 g/4.3 oz (mouse with battery)
approx.

Total weight (with packaging)

approx. 158 g / approx. 5.57 oz

Transmission range

approx. 10 m / approx. 33 ft

Frequency range

2.400 GHz - 2.4835 GHz

Storage Temperature

-40 °C to 55 °C / -40° F to 131° F

Operating Temperature

0 °C to 40 °C / 32° F to 104° F

Current Consumption

Mouse: typ. 7 mA, Receiver: typ. 26 mA

Interface

USB

Product approvals

• CE

• cTUVus

• FCC

System requirements

USB connection

Delivery Volume

• CHERRY MW 2310 2.0

• 2 batteries (type AA)

• Operating instructions

• 1 nano USB transmission receiver

2 g/ 0.07 oz

(receiver)

1 / 2 © Cherry Americas • 5732 95th Avenue, Suite 850 • Kenosha, WI 53144 • USA
Phone: [phone] • [e-mail] • cherryamericas.com • 2019-05-17

Errors, technical changes and delivery possibilities excepted.

CHERRY MW 2310 2.0

Wireless Mouse

Dimensions (product)

119,96 x 75,52 x 38,32 mm / 4.72 x 2.97 x 1.51 in (Mouse)
18 x 13,1 x 5,7 mm / 0.71 x 0.52 x 0.22 in (Receiver)

Packaging dimensions

130 x 94 x 50 mm / 5.12 x 3.70 x 1.97 in

Mouse

• Scanning: optical

• Resolution: 1000/1600/2400 dpi (adjustable)

• Number of Keys: 6

• Mouse wheel design: Scroll wheel with key function

• Design: Symmetrical

• Connection: wireless

• Housing colour: black

• Key colour: black

Packaging Unit

• Number of products in the master package: 10

• Number of master packages per pallet: 108

Technical information refers only to the specifications of the
products. Features may differ from the information provided.

Warranty

We put a lot of dedication and hard work into the development of
our products and we are proud of their quality. This is why, in
addition to the statutory guarantee mentioned in the operating
instructions, we are granting an expanded manufacturer’s
guarantee that is subject to the conditions stated below.
For the first two years after delivery, the statutory warranty
applies. In the third year after delivery, CHERRY voluntarily grants
an additional warranty according to the following conditions
("extended warranty"). In the event of a defect, please contact
the seller of your CHERRY product. Do not carry out any repairs
on your own and do not open the product. There is no warranty if
unauthorized changes to the product cause a defect.

Conditions for the extended warranty
In the case of a defect after the first 2 years after delivery of the
CHERRY product, CHERRY grants its customers for the additional
period of one year the right to assert claims for cure, i.e. demand
that the defect is remedied or a thing free of defects is supplied.
The extended warranty is to be asserted against the seller of the
CHERRY product upon presentation of the original invoice, proof
of purchase or a comparable proof of the time of purchase.
CHERRY, and the seller of the CHERRY product, where applicable,
shall remedy the defect in the event the customer has justified
claims for cure under the terms of the extended warranty.
Excluded from the extended warranty are damages caused by
improper use, in particular by the effects of chemical substances,
other damages caused by external influences, as well as normal
wear and tear and optical changes, in particular discoloration or
abrasion of shiny areas. Also excluded from the extended
warranty are accessories and other parts which are not an
integral part of the purchased item.

Models

Product name Order number EAN-Code

1 CHERRY MW 2310 2.0

2 / 2 © Cherry Americas • 5732 95th Avenue, Suite 850 • Kenosha, WI 53144 • USA
Phone: [phone] • [e-mail] • cherryamericas.com • 2019-05-17

JW-T0320

4025112089978
