Cherry JW-T0310 Product Data Sheet

CHERRY MW 2310

Models may vary from the image shown

Keep navigating and clicking for more than 3 years without needing to change batteries

The CHERRY MW 2310 is multi-purpose CHERRY technology in an ergonomic design. Reliable, practical and flexible. The sophisticated wireless mouse from CHERRY. For people looking for superior performance at an affordable price.

Key benefits

• 5-button mouse: infrared sensor and adjustable resolution (1000/1500/2000 dpi)

• Nano USB receiver: able to stay in the notebook permanently

• Long battery lifespan* thanks to energy-efficiency infrared sensor (*Using the supplied batteries, each with 2200mAh, allows a service life of 733 hours (at 6 mA) to be achieved. Assuming the mouse is used constantly for one hour a day and 230 work days a year, you will only need to change the battery after approx. 3 years)

• Optimised for both left-handed and right-handed operation

• Elegant touch due to the chrome plated scroll wheel with non-slip rubber coating

• Simple installation; no technical knowledge required

• Almost interference-free wireless 2.4 GHz technology (range of up to 10 metres)

Technical Data:

Weight (product):

approx. 122 g (mouse with battery), approx. 2 g (receiver)

Total weight (with packaging):

approx. 158 g

Transmission range:

approx. 10 m

Frequency range:

2.400 GHz - 2.4835 GHz

Storage Temperature:

-40°C to 55°C

Operating Temperature:

0°C to 40°C

Current Consumption:

max. 7 mA (mouse), max. 40 mA (receiver)

Interface:

• USB

Product approvals:

• c-tick

• CE

• FCC

• cTUVus

System requirements:

• USB connection

Delivery Volume:

• CHERRY MW 2310

• 2 batteries (type AA)

• Operating instructions in hard copy

• 1 nano USB transmission receiver

Dimensions (product):

119.96 x 75.52 x 38.32 mm (mouse), 18 x 13.1 x 5.7 mm (receiver)

Packaging dimensions:

130 x 94 x 50 mm

Reliability:

• MTBF (90) > 80,000 hours

Mouse:

• Scanning: Infrared

• Resolution: 1000 / 1500 / 2000 dpi (adjustable)

• Number of Keys: 5

• Mouse wheel design: Scroll wheel with key function

• Design: Symmetrical

• Connection: wireless

• Housing colour: black

• Key colour: black

Packaging Unit:

• Number of products in the master package: 10

• Number of master packages per pallet: 108

Warranty:

2 years

1/3

Errors, technical changes and delivery possibilities excepted. Technical information refers only to the specifications of the products. Features may differ from the information provided.
