The Intimidator Trio Quick Reference Guide (QRG) has basic product
information such as mounting, menu options, and DMX values. Download
the User Manual from www.chauvetlighting.com for more details.
Disclaimer
The information and specifications contained in this QRG are subject to
Safety Notes
These Safety Notes include important information about installation, use, and
maintenance.
•Only connect this product to a grounded and protected circuit.
Do not touch this product when it is operating because it may be hot.
• The voltage of the outlet to which you are connecting this product must
by unplugging it.
Contact
Outside the U.S., United Kingdom, Ireland, Mexico, or Benelux contact your
Visit
www.chauvetlighting.com for contact information.
What is
• Intimidator Trio
Hardware
• Power Cord
• Quick Reference Guide
To Begin
Unpack your Intimidator Trio and make sure you have received all parts in
good condition. If the box or contents appear damaged, notify the carrier
immediately, not Chauvet.
Guide
change without notice.
• Always disconnect from power before cleaning or replacing the fuse.
• Do not look at the light source when the product is on.
• Make sure the power cord is not crimped or damaged.
• Never disconnect th is product from power by pulling on the cord.
• When mounting this product overhead, use a safety cable.
• Do not allow flammable materials close to the unit while operatin g.
•
be within the range stated on the decal or rear panel of the product.
• This product is for indoor use only! (IP20) To prevent risk of fire or
shock, do not expose this product to rain or moisture.
• Always mount this product in a location with adequate ventilation, at
least 20 in (50 cm) from adjacent surfaces.
• Be sure that no ventilation slots on the unit’s housing are blocked.
• Never connect this p ro duct to a dimmer or rheostat.
• Replace the fuse with another of the same type and rating.
• Only use the handles or attached mounting clamp of appropriate weight
capacity to carry this product.
• The maximum ambient temperat ure is 104 °F (40 °C). Do not operate
this product at higher temperatures.
• In the event of a serious operating problem, stop using immediately.
• Do not open this product. It contains no user-serviceable parts.
• To eliminate unneccesary wear and improve its lifespan, during periods
of non-use completely disconnect the product from power via breaker or
distributor to request support or return a product.
Included
•Hanging Bracket with Mounting
2
•Warranty Card
Intimidator Trio QRG EN
Description
The Intimidator Trio i s a feature-packed compact moving head e ffect light
color RGBW LEDs.
,
.
color LCD display. Generate a synchronized show in Master/Slave mode
remote
DMX control. The Intimidator
Trio fits best in the CHS-50 VIP Gear Bag available from Chauvet.
LCD Display
Control
Buttons
Indicator Light
Yoke
Back Panel View
Power Out
DMX In
DMX Out
Fuse
Holder
Power In
Front View
with beam, wash and effect features. It has 6 quadMotorized zoom allows short-throw and long-throw applications
continuously rotating honeycomb delivers the excitement of an effect light
Simple navigation and full text readout is displayed on a high-contrast, full-
with easy-to-access, built -in automated programs. The optional IRC-6
from Chauvet offers convenient, wireless non-
Overview
3
IR Sensor
Intimidator Trio QRG EN
AC Power
that can work with an input
Power Linking
products that you can power
Fuse
Replacement
1. Disconnect the product from power.
4. Re-insert the fuse holder and reconnect power.
Infrared Remote
6
)
The Intimidator Tr io i s compa t ibl e with the Infrared Remote Control 6 (IRC-6)
from Chauvet.
This product has an auto-ranging power supply
voltage range of 100 to 240 VAC, 50/60 Hz.
For the maximum number of Intimidator Trio
link at each voltage, see the User Manual or the sticker on the product.
2. Using a flat-head screwdriver, loosen the fuse holder and pull straight out.
3. Remove the blown fuse from the holder and replace with a fuse of the
exact same type and rating.
Control
(IRC-6
The following IRC-6 buttons are used with the Intimidator Trio:
• <BLACKOUT> - turns LED on/off
• <AUTO> - selects auto program mode (scrolling)
• <SOUND> - selects Sound-Active mode
• <STROBE> - strobing (0 –20 Hz)
• <SPEED> - Pan/Tilt auto program speed
• <SENSITIVITY> - selects sound sensitivity
• <%> - LED dimmer
• <FADE/SNAP> - Press once for F ade color change/Press twice for Snap
• <MANUAL> - manual control
• <R> - red LED manual control
• <G> - green LED manual control
• <B> - blue LED manual control
• <W> - white LED manual control
• <UV> - Zoom/rotating manual adjustment
• <A> - Pan/Tilt manual adjustment
• <+> - Increase
• <-> - Decrease
• <0> to <9> - Select auto program by number
4
Intimidator Trio QRG EN
Mounting
When using o nly one mou nting cla mp , be sure to use a clamp with a
captive bol t to prevent accidental loosening.
Control Panel
Description
<MENU>
Exits from the current menu or function
Navigates upwards through the menu list and increases the
numeric value when in a function
Navigates downwards through the menu list and decreases the
numeric value when in a function
Enables the currently displayed menu or sets the currently
selected value into the selected function
Mounting Clamp
clamp from Chauvet)
Safety Cable
Mounting Holes for
bracket
Safety Cable
Mounting Hole for
Before mounting this product, read the Safety Notes.
(works with CLP-15 or CLP-15N
Mounting Bracket
Mounting
Diagram
Rubber Feet (x4)
for floor mounting
Mounting Clamp
Button Function
<UP>
<DOWN>
<ENTER>
5
Handle (x2)
Hanging/Mounting
Pass Through
Intimidator Trio QRG EN
Address
001–512
Sets the DMX starting address
15CH
30CH
Slave
Slave 1–4
Selects Slave mode
Auto
Selects Auto mode
Sound
Selects Sound-Active mode
IR
Selects infrared control
Pan
000–255
Manual Pan control
Tilt
000–255
Manual Tilt control
P/T Speed
000–255
Manual Pan/Tilt Speed control
Color
000–255
Manual Color control
Rotate
000–255
Manual Rotate control
Zoom
000–255
Manual Zoom control
Dimmer
000–255
Manual Dimmer control
Shutter
000–255
Manual Shutter control
OFF
Normal pan operation
ON
Reverse pan operation
OFF
Normal tilt operation
ON
Reverse tilt operation
540
Selects the 540° pan angle range
360
Selects the 360° pan angle range
180
Selects the 180° pan angle range
270
Selects the 270° tilt angle range
180
Selects the 180° tilt angle range
90
Selects the 90° tilt angle range
OFF
Normal Mode
UP
Totem Mod e Base Up
DOWN
Totem Mod e Base Down
Normal
Fast
Slow
Auto
Sets fan speed according to temperature
Full
Fan speed set to full speed
Display background light turns off after
inactivity
ON
Display background light stays on
OFF
Normal display
ON
Reverse display
Square
I Squa
SCurve
Linear
Fast
Smooth
Menu Options
Main Function Programming Levels Description
Run Mode
Setup
DMX
Manual
Pan Reverse
Tilt Reverse
Pan Angle
Tilt Angle
Totem Mode
P/T Speed
Selects DMX mode
Selects the panning/tilting speed
Display
Screen Rev
Dimmer Curve
Dimmer Speed
Fans
OFF
Selects the dimmer curve mode
Selects the dimmer speed
6
Intimidator Trio QRG EN
RED
GREEN
BLUE
WHITE
Sensitivity
001–100
Sets sound sensitivity
Reset
Resets the product
Factory Set
Loads factory defaults
Ver V_
Displays the softw a r e ve rsion
Running Mode _ _ _ _ _
Displays the current running mode
DMX Address _ _ _
Displays the current DMX address
Temperature _ _ _
Displa ys the LED tem perature i n C elsius
DMX Linking
DMX
Instructions for connecting and configuring this product
If you are not familiar with
Starting
Address
To ensure full access to all channels in each DMX mode, the highest
Master/Slave
Connection
tion for its Master/Slave
mode. Instructions for connecting and configuring this product for
Main Function Programming Levels Description
Color Balance
Setup
(cont.)
Sys Info
The Intimidator Trio can work with a DMX controller when linked by
serial connections.
for DMX operation are in the User Manual.
DMX, download the DMX Primer from www.chauvetlighting.com.
recommended DMX address is 483.
The Intimidator Trio uses the DMX data connec
Master/Slave operati on are in the User Manual.
Selects color balance (100 to 255)
7
Intimidator Trio QRG EN
30-CH
1
Pan
000 ó 255
0 to 540°
2
Fine Pan
000 ó 255
Fine control of panning
3
Tilt
000 ó 255
0 to 270°
4
Fine Tilt
000 ó 255
Fine control of ti lting
5
Speed
000 ó 255
Pan/Tilt speed (fast to slow)
6
Red
000 ó 255
0 to 100%
7
Green
000 ó 255
0 to 100%
8
Blue
000 ó 255
0 to 100%
9
White
000 ó 255
0 to 100%
10
Red
000 ó 255
0 to 100%
11
Green
000 ó 255
0 to 100%
12
Blue
000 ó 255
0 to 100%
13
White
000 ó 255
0 to 100%
14
Red
000 ó 255
0 to 100%
15
Green
000 ó 255
0 to 100%
16
Blue
000 ó 255
0 to 100%
17
White
000 ó 255
0 to 100%
18
No function
000 ó 255
No function (Preset)
19
No function
000 ó 255
No function (Preset)
20
No function
000 ó 255
No function (Preset)
21
No function
000 ó 255
No function (Preset)
2
3
3
DMX Values
Channel Function Value Percent/Setting
Zone 1
Zone 2
Zone 3
Intimidator Trio
Zones of Control
1
2
1
8
Intimidator Trio QRG EN
30-CH
000 ó 004
No function
005 ó 009
Color 1
010 ó 014
Color 2
015 ó 019
Color 3
020 ó 024
Color 4
025 ó 029
Color 5
030 ó 034
Color 6
035 ó 039
Color 7
040 ó 044
Color 8
045 ó 049
Color 9
050 ó 054
Color 10
055 ó 059
Color 11
060 ó 064
Color 12
065 ó 069
Color 13
070 ó 074
Color 14
075 ó 079
Color 15
080 ó 084
Color 16
085 ó 089
Color 17
090 ó 094
Color 18
095 ó 099
Color 19
100 ó 104
Color 20
105 ó 109
Color 21
110 ó 114
Color 22
115 ó 119
Color 23
120 ó 124
Color 24
125 ó 129
Color 25
130 ó 134
Color 26
135 ó 139
Color 27
140 ó 144
Color 28
145 ó 149
Color 29
150 ó 154
Color 30
155 ó 159
Color 31
160 ó 164
Color 32
165 ó 169
Color 33
170 ó 174
Color 34
175 ó 179
No function
180 ó 201
Clockwise color change (fast to slow)
202 ó 207
Stop (color stays in the current color)
Counter-clockwise color change
(fast to slow)
230 ó 234
No function
235 ó 249
Color jump (fast to slow)
250 ó 255
Sound-Active co l o rs
Channel Function Value Percent/Setting
(cont.)
22 Colors
208 ó 229
9
Intimidator Trio QRG EN
30-CH
000 ó 015
No function
016 ó 031
Zone macro 1
032 ó 047
Zone macro 2
048 ó 063
Zone macro 3
064 ó 079
Zone macro 4
080 ó 095
Zone macro 5
096 ó 111
Zone macro 6
112 ó 127
Built-in 7 (zone macros 1—6)
128 ó 143
Built-in Auto 1
144 ó 159
Built-in Auto 2
160 ó 175
Built-in Auto 3
176 ó 191
Built-in Auto 4
192 ó 207
Built-in Auto 5
208 ó 223
Built-in Auto 6
224 ó 239
Built-in Auto 7
240 ó 255
Built-in 8 (built-in auto 1—7)
Zone macros and built-in auto speed (slow to
fast)
25
Dimmer
000 ó 255
0 to 100%
000 ó 019
Closed
020 ó 024
Open
025 ó 064
Strobe effect (decreasing speed)
065 ó 069
Open
070 ó 084
Fast on, slow off (decreasing speed)
085 ó 089
Open
090 ó 104
Slow on, fast off (decreasing speed)
105 ó 109
Open
110 ó 124
Random shutter (decreasing speed)
125 ó 129
Open
130 ó 144
Random fast on, slow off (decreasing speed)
145 ó 149
Open
150 ó 164
Random slow on, fast off (decreasing speed)
165 ó 169
Open
170 ó 184
Pulse effect 1 (decreasing speed)
185 ó 189
Open
190 ó 204
Pulse effect 2 (decreasing speed)
205 ó 209
Open
210 ó 224
Gradually on and off (decreasing speed)
225 ó 229
Open
230 ó 244
Pulse effect 3 (decreasing speed)
245 ó 255
Open
27
Zoom
000 ó 255
Zoom in and out
Channel Function Value Percent/Setting
(cont.)
23 Built-in Control
24 Built-in Speed
26 Shutter
000 ó 255
10
Intimidator Trio QRG EN
30-CH
000 ó 009
No function
010 ó 014
Blackout while pannin g/ti lting
015 ó 019
No function
020 ó 049
Reserved for future use
050 ó 054
Reset pan
055 ó 059
Reset tilt
060 ó 064
Reset zoom
065 ó 069
Reset rotation
070 ó 074
Reset all
075 ó 079
No function
080 ó 084
Reverse pan/tilt
085 ó 089
Reverse pan
090 ó 094
Reverse tilt
095 ó 099
Cancel reverse pan
100 ó 104
Cancel reverse tilt
105 ó 109
Cancel reverse pan/tilt
110 ó 114
Pan/Tilt normal speed
115 ó 119
Pan/Tilt fast speed
120 ó 124
Pan/Tilt slow speed
125 ó 129
Fan (full speed)
130 ó 134
Fan (auto)
135 ó 139
Dimmer, fast
140 ó 144
Dimmer, smooth
145 ó 255
No function
000 ó 007
No function
008 ó 023
Automatic movement macro 1
024 ó 039
Automatic movement macro 2
040 ó 055
Automatic movement macro 3
056 ó 071
Automatic movement macro 4
072 ó 087
Automatic movement macro 5
088 ó 103
Automatic movement macro 6
104 ó 119
Automatic movement macro 7
120 ó 135
Automatic movement macro 8
136 ó 151
Sound-Active movement macro 1
152 ó 167
Sound-Active movement macro 2
168 ó 183
Sound-Active movement macro 3
184 ó 199
Sound-Active movement macro 4
200 ó 215
Sound-Active movement macro 5
216 ó 231
Sound-Active movement macro 6
232 ó 247
Sound-Active movement macro 7
248 ó 255
Sound-Active movement macro 8
000 ó 063
Rotating Chase
Rotating Small Shake (Slow
to Fast)
Rotating Large Shake (Slow
to Fast)
128 ó 191
Rotating (slow to fast)
Reverse Rotating (slow to
fast)
Channel Function Value Percent/Setting
(cont.)
28 Control Functions
29 Movement Macros
30 Rotating
064 ó 095
096 ó 127
192 ó 255
11
When Ch-27 (Zoom) value is
above 150
Intimidator Trio QRG EN
15-CH
1
Pan
000 ó 255
0 to 540°
2
Tilt
000 ó 255
0 to 270°
3
Speed
000 ó 255
Pan/Tilt (fast to slow)
4
Red
000 ó 255
0 to 100%
5
Green
000 ó 255
0 to 100%
6
Blue
000 ó 255
0 to 100%
7
White
000 ó 255
0 to 100%
000 ó 015
No function
016 ó 031
Zone macro 1
032 ó 047
Zone macro 2
048 ó 063
Zone macro 3
064 ó 079
Zone macro 4
080 ó 095
Zone macro 5
096 ó 111
Zone macro 6
112 ó 127
Built-in 7 (zone macros 1—6)
128 ó 143
Built-in Auto 1
144 ó 159
Built-in Auto 2
160 ó 175
Built-in Auto 3
176 ó 191
Built-in Auto 4
192 ó 207
Built-in Auto 5
208 ó 223
Built-in Auto 6
224 ó 239
Built-in Auto 7
240 ó 255
Built-in 8 (built-in auto 1—7)
9
Built-in Speed
000 ó 255
Zones and built-in auto speed (slow to fast)
10
Dimmer
000 ó 255
0 to 100%
Channel Function Value Percent/Setting
8 Built-in Control
12
Intimidator Trio QRG EN
15-CH
000 ó 019
Closed
020 ó 024
Open
025 ó 064
Strobe effect (decreasing speed)
065 ó 069
Open
070 ó 084
Fast on, slow off (decreasing speed)
085 ó 089
Open
090 ó 104
Slow on, fast off (decreasing speed)
105 ó 109
Open
110 ó 124
Random shutter (decreasing speed)
125 ó 129
Open
130 ó 144
Random fast on, slow off (decreasing speed)
145 ó 149
Open
150 ó 164
Random slow on, fast off (decreasing speed)
165 ó 169
Open
170 ó 184
Pulse effect 1 (decreasing speed)
185 ó 189
Open
190 ó 204
Pulse effect 2 (decreasing speed)
205 ó 209
Open
210 ó 224
Gradually on and off (decreasing speed)
225 ó 229
Open
230 ó 244
Pulse effect 3 (decreasing speed)
245 ó 255
Open
12
Zoom
000 ó 255
Zoom in and out
Channel Function Value Percent/Setting
(cont.)
11 Shutter
13
Intimidator Trio QRG EN
15-CH
000 ó 009
No function
010 ó 014
Pan/Tilt blackout
015 ó 019
No function
020 ó 049
Reserved for future use
050 ó 054
Reset pan
055 ó 059
Reset tilt
060 ó 064
Reset zoom
065 ó 069
No function
070 ó 074
Reset all
075 ó 079
No function
080 ó 084
Reverse Pan/Tilt
085 ó 089
Reverse pan
090 ó 094
Reverse tilt
095 ó 099
Cancel reverse pan
100 ó 104
Cancel reverse tilt
105 ó 109
Cancel reverse pan/tilt
110 ó 114
Pan/Tilt normal speed
115 ó 119
Pan/Tilt fast speed
120 ó 124
Pan/Tilt slow speed
125 ó 129
Fan (full speed)
130 ó 134
Fan (auto)
135 ó 139
Dimmer, fast
140 ó 144
Dimmer, smooth
145 ó 255
No function
000 ó 007
No function
008 ó 023
Automatic movement macro 1
024 ó 039
Automatic movement macro 2
040 ó 055
Automatic movement macro 3
056 ó 071
Automatic movement macro 4
072 ó 087
Automatic movement macro 5
088 ó 103
Automatic movement macro 6
104 ó 119
Automatic movement macro 7
120 ó 135
Automatic movement macro 8
136 ó 151
Sound-Active movement macro 1
152 ó 167
Sound-Active movement macro 2
168 ó 183
Sound-Active movement macro 3
184 ó 199
Sound-Active movement macro 4
200 ó 215
Sound-Active movement macro 5
216 ó 231
Sound-Active movement macro 6
232 ó 247
Sound-Active movement macro 7
248 ó 255
Sound-Active movement macro 8
000 ó 063
Rotating Chase
064 ó 095
Rotating Small Shake (Slow to Fast)
096 ó 127
Rotating Large Shake (Slow to Fast)
128 ó 191
Rotating (slow to fast)
192 ó 255
Reverse Rotating (slow to fast)
Channel Function Value Percent/Setting
(cont.)
13 Control Functions
14 Movement Macros
15 Rotating
When Ch27 (Zoom)
value is
above 150
14
Intimidator Trio GRR ES
Acerca de
La guía de re feren c ia ráp id a (GRR ) d el Inti mi dat or Tr io conti en e inf or maci ón b ási ca
sobre el prod ucto, como montaje, opciones d e menú y valor es DMX. Desc argue el
manual de usua ri o de www.chauvetlighting.com para una información más detallada.
Exención de
responsabilidad
La información y especificaciones contenidas en esta GRR están sujetas a
cambio sin previo aviso.
Notas de seguridad
Estas notas de seguridad incluyen información importante sobre el montaje,
uso y mantenimiento.
• Conecte este producto solo a un circuito con toma de tierra y protegido.
• No toque este producto cuando esté en funcionamiento, pues podría estar caliente.
• La tensión del enchufe al que conecte este producto ha de estar en el rango
solo las asas o una abr azadera de montaje acoplada de la resistencia
desenchufándolo durante periodos en que no se use.
Contacto
Fuera de EE. UU., Reino Unido, Irlanda, México o Benelux póngase en
contacto con su distribuidor para solicitar asistencia o devolver un producto.
Visite www.chauvetlighting.com para información de contacto.
Qué va
• Intimidator Trio
montaje
• Cable de alimentación
• Guía de referencia rápida
Para empezar
Desembale su Intimid ator Trio y asegúrese d e que ha reci bido t odas las partes
en buen estado. Si la caja o los componentes parecen dañados, notifíqueselo
inmediatamente al transportista, no a Chauvet.
esta guía
• Desconecte siempre de la alimentación antes de la limpieza o sustitución del fusible.
• No mire a la fuente de lu z cuando el producto esté encendido.
• Asegúrese de que el cable de alimentación no está ret orcido ni estropeado.
• Nunca desconecte este producto de la alimentación tirando del cable.
• Cuando monte este producto en alto, use un cable de seguridad.
• No permita la presencia d e materiales inflamables cerca de la unidad
cuando esté en funcionamiento.
establecido en el grabado o en el panel posterior del producto .
• ¡Este producto es pa r a us o e n int e riore s s olam e nt e! ( IP20) Par a e v it a r rie sg os
de incendio o desca r ga , no e x ponga e s te pr oduc to a l a ll uv ia o la humedad.
• Monte siempre este producto en una ubicación con ventilación adecuada,
al menos a 20 in (50 cm) de sup erficies adyacentes.
• Asegúrese de que nin guna ranura de ventilación en la carcasa de la unidad
queda bloqueada.
• Nunca conecte este producto a un atenuador o reostato.
• Sustituya el fusible con otro del mismo tipo y categoría.
• Utilice
al peso adecuada para tras ladar este producto.
• La temperatura ambiente máxima es de 104 °F (40 °C). No haga funcionar
este producto a temperaturas más altas.
• En caso de un problema grave de fun cio nami ent o, deje de usa rlo inm edi ata me nte.
• No abra este producto. No contiene piezas reparables por el usuario.
• Para evitar un desgaste innecesario y alargar su vida útil, desconecte
completamente el producto de la alimentación medi ante el interruptor o
incluido
•Soporte para colgar con material de
15
•Tarjeta de garantía
Intimidator Trio GRR ES
Descripción
El Intimidator Trio es un efecto de luz de cab eza móvil co mpacto y cargado
de características, equipado con haz, baño de luz y efectos. Tiene 6 LED
RGBW de cuatro color es. El zoom motorizado permite aplicaci ones de co rto
emoción de
un efecto de ilu minación. Experimente una navegaci ón sencilla con lectura
completa de texto gracias la pantalla LCD de alto contraste a todo color.
Genere un espectáculo sincronizado en modo maestro/esclavo con programas
6 de Chauvet le
DMX sin cables. El Intimidator Trio cabe
perfectamente en la bolsa de material CHS-50 VIP disponible en Chauvet.
Pantalla LCD
Botones
control
Luz del
indicator
Yugo
Vista del panel
Salida de
Entrada
DMX
Salida
DMX
Porta-
fusibles
Entrada de
alimentación
Vista frontal
y largo alcance, y el nido de abeja en rotación con tinua aporta la
automatizados de fácil acceso. El mando a distancia IRCproporciona un práctico control no-
Vista general
de
16
posterior
Sensor IR
alimentación
Intimidator Trio GRR ES
Corriente
alterna
Este producto tiene un a fuente de alimentaci ón co n detecció n automática q ue
puede funcionar con un rango de tensión de entrada de 100 a 240 VCA,
Alimentación en
cadena
Sustitución del
fusible
1. Desconecte el producto de la alimentación.
4. Vuelva a insertar el portafusibles y conecte de nuevo la alimentación.
Control remoto
por infrarrojos 6
)
El Intimidator Trio es compatible con el mando a distancia por infrarrojos 6
(IRC-6) de Chauvet.
50/60 Hz.
Para ver el máximo número de productos Intimidator Trio que se pueden
alimentar en cadena, consulte el manual de usuario o la etiqueta del producto
2. Con ayuda de un destornillador de cabeza plana, afloje el portafusibles y
extráigalo directamente.
3. Quite el fusible fundido del portafusibles y sustituya el fusible con otro
del mismo tipo y categoría.
(IRC-6
Los siguientes botones del IRC-6 se usan con el Intimidator Trio:
• <BLACKOUT>: apaga/enciende el LED
• <AUTO>: selecciona el modo de programa automático (desplazamiento)
• <SOUND>: selecciona el modo Activo por sonido
• <STROBE>: estroboscopio (0–20 Hz)
• <SPEED>: velocidad de Despl azamien to lateral/Inclinación del programa
• <SENSITIVITY>: selecciona la sensibilidad al sonido
• <%>: atenuador de LED
• <MANUAL>: control manual
• <FADE/SNAP>: pulse una vez para cambio de color de Fade/pulse dos
• <R>: control manual del LED rojo
• <G>: control manual del LED verde
• <B>: control manual del LED azul
• <W>: control manual del LED blanco
• <UV>: ajuste manual del zoom/rotación
• <A>: ajuste manual de d esplazamiento lateral/ in clinación
• <+>: aumentar
• <->: disminuir
• <0> a <9>: seleccionar programa automático por número
automático
veces para cambio rápi do
17
Intimidator Trio GRR ES
Montaje
Vista general
Cuando use una abrazadera de montaje, asegúrese de usar una
abrazadera con tornillo prisionero para evitar que se afloje
accidentalmente.
Descripción
panel de
<MENU>
Sale del menú o función actual
Navega hacia arriba por la lista de menú y aumenta el valor
numérico cuando está en una función
Navega hacia abajo por la lista de menú y disminuye el valor
numérico cuando está en una función
Habilita el menú actualmente en pantalla o configura el valor
seleccionado actualmente dentro de la función seleccionada
Abrazadera de montaje
CLP-15N de Chauvet
Cable de
seguridad
Agujeros de montaje
colgar/montar
Pies de goma (x4)
suelo
Paso del cable
Soporte de
montaje
Agujero de montaj e
para abrazadera de
montaje
Antes de montar este producto, lea las Notas de seguri dad.
(sirve la abrazadera CLP-15 o
del
control
para montaje en
Botón Función
<UP>
<DOWN>
<ENTER>
para soporte para
18
Asa (x2)
de seguridad
Intimidator Trio GRR ES
Address
001–512
Configura la dirección inicial DMX
15CH
30CH
Slave
Slave 1–4
Selecciona el modo Maestro/Esclavo
Auto
Selecciona el modo automático
Sound
Selecciona el modo Activo por sonido
IR
Selecciona el control por infrarrojos
Pan
000–255
Ajuste manual de desplazamiento lateral
Tilt
000–255
Ajuste manual de inclinación
P/T Speed
000–255
Ajuste manual de velocidad lateral/inclinación
Color
000–255
Ajuste manual de colores
Rotate
000–255
Ajuste manual de rotación
Zoom
000–255
Ajuste manual de zoom
Dimmer
000–255
Ajuste manual de atenuador
Shutter
000–255
Ajuste manual de obturador
Funcionamiento de desplazamiento lateral
normal
Invierte el funcionamiento del desplazamiento
lateral
OFF
Funcionamiento inclinación normal
ON
Invierte el funcionamiento de la inclinación
Selecciona el rango de desplazamiento lateral
de 540°
Selecciona el rango de desplazamiento l ateral
de 360°
Selecciona el rango de desplazamiento lateral
de 180°
270
Selecciona el rango de inclinación de 270°
180
Selecciona el rango de inclinación de 180°
90
Selecciona el rango de inclinación de 90°
OFF
Modo normal
UP
Modo columna de soporte, base hacia arriba
DOWN
Modo columna de soporte, base hacia abajo
Normal
Fast
Slow
Configu ra la velocidad de ventilador según la
temperatura
Full
Velocidad del ventilador al máximo
La luz de la pantalla se apaga después de la
inactividad
ON
La luz de la pantalla se queda encendida
OFF
Pantalla normal
ON
Invierte la pantalla
Opciones de menú
Función principal Niveles de programación Descripción
Run Mode
Setup
DMX
Manual
Pan Reverse
Tilt Reverse
Pan Angle
Tilt Angle
Selecci ona el modo de ejecución DMX
OFF
ON
540
360
180
Totem Mode
P/T Speed
Fans
Display
Screen Rev
Selecciona la velocidad de desplazamiento
lateral/inclinación
Auto
OFF
19
Intimidator Trio GRR ES
Square
I Squa
SCurve
Linear
Fast
Smooth
RED
GREEN
BLUE
WHITE
Sensitivity
001–100
Selecciona el equilibrio de color (100 a 255)
Reset
Resets the product
Factory Set
Carga los valores por defecto de fábrica
Ver V_
Muestra en pantalla la versión de software
Running Mode _ _ _ _ _
Muestra el modo de ejecución ac t ual
DMX Address _ _ _
Muestra la direcc ión DMX actual
Temperature _ _ _
Muestra la temperatura del LED en Celsius
Enlace DMX
El Intimidator Trio puede funcionar con un controlador DMX cuando se
enlaza por conexiones serie DMX. Las instrucciones para conectar y
configurar este producto para funcionamiento DMX están en el Manual de
gue el Manual DMX de
Dirección de
inicio
Para asegurarse acceso total a todos los canales en cada modo DMX, la
Conexión
Intimidator Trio usa la conexión de datos DMX para su modo
Maestro/Esclavo. Las instru cciones p ara con ectar y configu rar est e pr oducto
Función principal Niveles de programación Descripción
Dimmer Curve
Dimmer Speed
Setup
(cont.)
Color Balance
Sys Info
usuario. Si no está familiarizado con DMX, descar
www.chauvetlighting.com.
dirección DMX más reco mendable es 483.
El
Maestro/Esclavo
para funcionamiento Maestro/Esclavo están en el manual de usuario.
Selecciona el modo de curva del atenuador
Selecciona el valor del atenuador
Selecciona el equilibrio de color (100 a 255)
20
Intimidator Trio GRR ES
30CH
Desplazamiento
lateral
Desplazamiento
lateral fin o
3
Inclinación
000 ó 255
0 a 270°
4
Inclinación fina
000 ó 255
Control f ino de la inclinació n
Velocidad de desplazamiento
lateral/inclinación (rápido a lento)
6
Rojo
000 ó 255
0 a 100%
7
Verde
000 ó 255
0 a 100%
8
Azul
000 ó 255
0 a 100%
9
White
000 ó 255
0 a 100%
10
Blanco
000 ó 255
0 a 100%
11
Verde
000 ó 255
0 a 100%
12
Azul
000 ó 255
0 a 100%
13
Blanco
000 ó 255
0 a 100%
14
Rojo
000 ó 255
0 a 100%
15
Verde
000 ó 255
0 a 100%
16
Azul
000 ó 255
0 a 100%
17
Blanco
000 ó 255
0 a 100%
18
Sin función
000 ó 255
Sin función (preconfigurado)
19
Sin función
000 ó 255
Sin función (preconfigurado)
20
Sin función
000 ó 255
Sin función (preconfigurado)
21
Sin función
000 ó 255
Sin función (preconfigurado)
Valores DMX
Canal Función Valor Porcentaje/Configuración
1
2
5 Velocidad
Zonas de control del
Intimidator Trio
000 ó 255 0 a 540°
000 ó 255 Control fino del desplazamiento lateral
000 ó 255
Zona 1
Zona 2
Zona 3
1
3
2
2
3
1
21
Intimidator Trio GRR ES
30CH
000 ó 004
Sin función
005 ó 009
Color 1
010 ó 014
Color 2
015 ó 019
Color 3
020 ó 024
Color 4
025 ó 029
Color 5
030 ó 034
Color 6
035 ó 039
Color 7
040 ó 044
Color 8
045 ó 049
Color 9
050 ó 054
Color 10
055 ó 059
Color 11
060 ó 064
Color 12
065 ó 069
Color 13
070 ó 074
Color 14
075 ó 079
Color 15
080 ó 084
Color 16
085 ó 089
Color 17
090 ó 094
Color 18
095 ó 099
Color 19
100 ó 104
Color 20
105 ó 109
Color 21
110 ó 114
Color 22
115 ó 119
Color 23
120 ó 124
Color 24
125 ó 129
Color 25
130 ó 134
Color 26
135 ó 139
Color 27
140 ó 144
Color 28
145 ó 149
Color 29
150 ó 154
Color 30
155 ó 159
Color 31
160 ó 164
Color 32
165 ó 169
Color 33
170 ó 174
Color 34
175 ó 179
Sin función
Desplazamiento de color en sentido horario
(rápid o a lento)
202 ó 207
Parada (el color se queda en el color actual)
Desplazamiento de color en sentido
antihorario (rápido a lento)
230 ó 234
Sin función
235 ó 249
Salto de color (lento a rápido)
250 ó 255
Colores activos por sonido
Canal Función Valor Porcentaje/Configuración
(cont.)
22 Colores
180 ó 201
208 ó 229
22
Intimidator Trio GRR ES
30CH
000 ó 015
Sin función
016 ó 031
Macro zona 1
032 ó 047
Macro zona 2
048 ó 063
Macro zona 3
064 ó 079
Macro zona 4
080 ó 095
Macro zona 5
096 ó 111
Macro zona 6
112 ó 127
Integrado 7 (macros de zona 1—6)
128 ó 143
Auto integrado 1
144 ó 159
Auto integrado 2
160 ó 175
Auto integrado 3
176 ó 191
Auto integrado 4
192 ó 207
Auto integrado 5
208 ó 223
Auto integrado 6
224 ó 239
Auto integrado 7
240 ó 255
Auto int egrado 8 (au to integrado 1—7)
Velocidad
integrada
Velocidad auto integrado y macros de zona
(lento a rápido)
25
Atenuador
000 ó 255
0 a 100%
000 ó 019
Cerrado
020 ó 024
Abierto
025 ó 064
Efecto estroboscopio (velocidad decreciente)
065 ó 069
Abierto
Encender rápido, apagar lento (velocidad
decreciente)
Gradualmente encender y apagar (velocidad
decreciente)
225 ó 229
Abierto
230 ó 244
Efecto pulso 3 (vel ocidad decreciente)
245 ó 255
Abierto
Gradualmente encender y apagar (velocidad
decreciente)
Canal Función Valor Porcentaje/Configuración
(cont.)
070 ó 084
090 ó 104
11 Obturador
12 Zoom
130 ó 144
150 ó 164
210 ó 224
000 ó 255
26
Intimidator Trio GRR ES
15-CH
000 ó 009
Sin función
010 ó 014
Blackout Desplazamiento lateral/Inclinación
015 ó 019
Sin función
020 ó 049
Reservado para usos futur os
050 ó 054
Reiniciar desplazamiento latera
055 ó 059
Reiniciar inclinación
060 ó 064
Reiniciar zoom
065 ó 069
Sin función
070 ó 074
Reiniciar todo
075 ó 079
Sin función
080 ó 084
Invertir desplazamiento lateral/inclinación
085 ó 089
Invertir desplazamiento lateral
090 ó 094
Invertir inclinación
095 ó 099
Cancelar invertir desplazamiento lateral
100 ó 104
Cancelar invertir inclinación
105 ó 109
Cancelar invertir movimiento lateral/inclinación
110 ó 114
Desplazamiento lateral/i nclinació n velocidad nor mal
115 ó 119
Desplazamiento lateral/i nclinació n velocidad rápi da
120 ó 124
Desplazamiento lateral/inclinación velocidad lento
125 ó 129
Ventilador (velocidad máxima)
130 ó 134
Ventilador (automático)
135 ó 139
Atenuador, rápido
140 ó 144
Atenuador, suave
145 ó 255
Sin función
000 ó 007
Sin función
008 ó 023
Macro de movimiento automático 1
024 ó 039
Macro de movimiento automático 2
040 ó 055
Macro de movimiento automático 3
056 ó 071
Macro de movimiento automático 4
072 ó 087
Macro de movimiento automático 5
088 ó 103
Macro de movimiento automático 6
104 ó 119
Macro de movimiento automático 7
120 ó 135
Macro de movimiento automático 8
136 ó 151
Macro de movimiento Activo por Sonido 1
152 ó 167
Macro de movimiento Activo por Sonido 2
168 ó 183
Macro de movimiento Activo por Sonido 3
184 ó 199
Macro de movimiento Activo por Sonido 4
200 ó 215
Macro de movimiento Activo por Sonido 5
216 ó 231
Macro de movimiento Activo por Sonido 6
232 ó 247
Macro de movimiento Activo por Sonido 7
248 ó 255
Macro de movimiento Activo por Sonido 8
000 ó 063
Secuencia giratoria
27
Vibración giratoria pe qu eña (l ent a
a rápida)
Vibración giratoria gr an de (lenta
a rápida)
128 ó 191
Rotación (lenta a rápida )
192 ó 255
Rotación inversa (lenta a rápida)
Canal Función Valor Porcentaje/Configuración
(cont.)
13
14
Functiones de
control
Macros de
movimiento
15 Rotación
064 ó 095
096 ó 127
27
Cuando el
valor de C-(zoom) es
mayor de 150
Intimidator Trio MR FR
A propos de
Le Manuel de Référence (MR) du Intimidator Trio Quick reprend des
informations de base sur cet appareil notamment en matière de montage, d'options
de menu et de val eurs DMX. V euillez télé charger le man uel d'utili sation à parti r
du site internet www.chauvetlighting.com pour plus de dé ta il s .
Clause de non
Responsabilité
Les informations et caractéristiques contenues dans ce MR sont sujettes à
modification sa ns pr é a v i s .
Consignes de
Sécurité
Ces consignes de sécurité contiennent des informations importantes en matière
d'installation, d'utilisation et d'entretien.
• Cet appareil doit être relié à un circuit mis à la terre et p rotégé.
ci pouvant être très chaud.
• La tension de la source d'énergie à laquelle est connecté cet appareil doit être
débranchant de l'alimentation électrique ou en coupant le disjoncteur.
Nous
En dehors des États-Unis, du Royaume-Uni, de l'Irlande, du Mexique ou du
Benelux, contactez votre fournisseur si vous avez besoin d'assistance ou pour
retourner un appareil. Veuillez consulter le site internet
www.chauvetlighting.com pour obt e nir de s inf or mations pour nous contacter.
ce manuel
• Toujours débrancher l'appareil de la source d'alimentation avant de le
nettoyer ou de remplacer son fusible.
• Ne pas exposer directement les yeux à la source de lumière lorsque le produit est allumé.
• Veillez à ce que le cordon d'alime ntation ne soit jama is pincé ou endomm agé.
• Ne débranchez jamais cet appareil en tirant sur le cordon d'alimentation.
• En cas de montage de l'app ar eil en hauteur, veillez à t oujours utiliser un
câble de sécurité.
• Ne laissez aucun produit inflammable à proximité de l 'appareil lorsque
celui-ci fonctionne.
• Ne pas toucher au boîtier de l'appareil lorsqu'il est en fonctionnement, celui-
dans la plage indiquée sur l'étiquette ou sur le panneau arrière de l'appareil.
• Cet appareil doit uniquement être utilisé en intérieur ! (IP20) Afin d'éviter
tout risque d'incendie ou de décharge électrique, veillez à n'exposer cet
appareil ni à la pluie ni à l 'humidité.
• Installez toujours cet appareil dans un endroit bien ventilé à au moins 50 cm
(20 po) des surfaces adjacentes.
• Assurez-vous qu'aucune fente de ventilation de l'appareil n'est obstruée.
• Ne connectez jamais cet appareil à un variateur ou un rhéostat.
• Lors du remplacement du fusible, utilisez le même type et le même ampérage.
• N'utilisez que les poignées ou une pince de fixation installée do nt la
capacité en charge est suffisante pour transpo rter cet appareil.
• La température ambiante maximale est de 40 °C (104 °F). Ne faites pas
fonctionner cet app ar eil à des températures plus élevées.
• En cas de sérieux problèmes de fonctionnement, arrêtez l'appareil immédiatement.
• Ne pas ouvrir cet appareil. Il ne contient aucune pièce réparable par l'utilisateur.
• Durant les périodes de non-utilisation, pour éviter toute usure inutile et pour
prolonger la durée de vie, déconnectez entièrement l'appareil en le
contacter
28
Intimidator Trio MR FR
Contenu
• Intimidator Trio
de montage
• Cordon d'alimentation
• Manuel de référence
Préalable
Déballez votre Inti midator Trio et assu rez-vous que vous avez reçu toutes les
pièces en bon état. Si la boîte et/ou son contenu semble endommagés,
contactez immédiatement le transporteur, et non pas Chauvet.
Description
Le Intimidator Trio une lampe à effets à tête mobile bourrée de
fonctionnalités et équ ipée d'un faisceau, d'une l ampe de type wash ainsi que
d'une multitude d'effets. Il est équipé de 6 LEDs RGBW quadricolores. Le
zoom motorisé permet des utilisations en projection aussi bien sur des courtes
distances tandis que le nid d'abeille en rotation
constante délivre des effets dynamisants. Affichage à navigation simple et
intégralement en mode texte sur un écran LCD couleur à contraste élevé.
e aux
6
en option de Chauvet permet de contrôler l'appareil de manière pratique sans
50 VIP vend u
par Chauvet est recommandé po ur l'Intimidator Trio.
Écran LCD
Boutons de
commande
Voyants
d'indication
Étrier
Vue du panneau
arrière
Sortie
d'alimentation
Entrée DMX
Sortie
DMX
Porte-fusible
Entrée
d'alimentation
Vue frontale
• Fixation de suspension avec matériel
• Fiche de garantie
distances que des longues
Créez un spectacle synchronisé en mode maître/esclave grâc
programmes automatisés i ntégrés et faciles d'accès. La télécommande I RC-
fil et sans l'aide du protocole DMX. Le sac de transport CHS-
Vue d'ensemble
29
Capteur IR
Intimidator Trio MR FR
Alimentation
CA
Cet appareil est doté d'une alimentation universelle qui peut prendre en
Chaînage
électrique
savoir combien d'appareils Intimidator Trio peuvent être chainés au
maximum selon le voltage, veuillez consulter le manuel de l'utilisateur ou
Remplacement
du fusible
1. Débranchez l'appareil.
4. Remettez le porte-fusible en place puis rebranchez.
Télécommande
rouge 6
6)
L'Intimidator Trio est compatible avec la téléco mmande IRC-6 de Chauvet.
charge toute tension d'entrée comprise entre 100 et 240 VCA, 50/60 Hz.
Pour
l'autocollant appo sé s ur l'appareil.
2. Avec un tournevis à tête plate, desserrez le porte-fusible et retirez-le
directement.
3. Enlevez le fusible grillé du porte fusible et remplacez-le par un fusible de
même type et de même ampérage.
infra-
(IRC-
Les boutons suivants de l'IRC-6 sont utilisés avec l'Intimidator Trio :
• <BLACKOUT> - Allumage/extinction des LED
• <AUTO> - Sélection du mode programme automatique (défilement)
• <SOUND> - Sélection du mode d'activation par le son
• <STROBE> - Activation de l'effet stroboscopique (0–20 Hz)
• <SPEED> - Vitesse de basculement /balayage du programme auto matique
• <SENSITIVITY> - Sélection de la sensibilité au son
• <%> - Gradateur LED
• <MANUAL> - Contrôle manuel
• <FADE/SNAP> - Appuyer une fois pour le changement de la couleur de
• <R> - Contrôle manuel de la LED rouge
• <G> - Contrôle manuel de l a LED verte
• <B> - Contrôle manuel de la LED bleue
• <W> - Contrôle manuel de la LED blanche
• <UV> - Réglage manuel du zoom/de l a rotation
• <A> - Réglage manuel du balayage/basculement
• <+> - Augmenter
• <-> - Diminuer
• <0> à <9> - Sélection d'un programme automatique par son numéro.
fondu. Appuyer deux fois pour l'accroche (Snap).
30
Intimidator Trio MR FR
Montage
Schéma de
Lorsque vous n'utilisez qu'une seule fixation de montage, veillez à
utiliser un boulon d' a ncrage à go ujon captif pour empêcher tout
desserrage accidentel.
Description du
panneau de
commande
<MENU>
Permet de sortir du menu ou de la fonction en cours
Permet de naviguer vers le haut dans la liste du menu et
d'incrémenter une valeur numérique dans une fonction.
Permet de naviguer vers le bas dans la liste du menu et de
décrémenter une valeur numérique dans une fonction.
Active l'entrée de menu actuellement affichée ou confirme la valeur
actuellement sélectionnée pour la fonction en cours de sélection.
Pince de montage
ou CLP-15N de Chauvet)
Câble de sécurité
Trous de montage pour
suspension/fixation
Pieds en caoutchouc
Passage du
sécurité
Support de
montage
Trou de montage
fixation
Avant de monter cet appar eil, veuillez lire les cons ignes de sécurité.
(fonctionne avec la pince CLP-15
montage
(x4)
pour installation au
sol
le bras de
pour pince de
Bouton Fonction
<UP>
<DOWN>
<ENTER>
31
Poignée (x2)
câble de
Intimidator Trio MR FR
Address
001–512
Permet de définir l'adresse DMX de départ
15CH
30CH
Slave
Slave 1–4
Permet de s élection ner le mode esclave
Auto
Permet de sélectionner le mode automatique
Permet de sélectionner le mode d'activation
par le son
IR
Activat ion du cont rôle par infra-rouge
Pan
000–255
Réglage manuel du balayage
Tilt
000–255
Réglage manuel du basculement
P/T Speed
000–255
Réglage manuel du balayage/basculement vitesse
Color
000–255
Réglage manuel du couleurs
Rotate
000–255
Réglage manuel du rotation
Zoom
000–255
Réglage manuel du zoom
Dimmer
000–255
Réglage manuel du gradateur
Shutter
000–255
Réglage manuel du obturateur
OFF
Fonctionnement normal du balayage
ON
Fonctionnement inversé du balayage
OFF
Fonctionnement normal du basculement
ON
Fonctionnement inversé du basculement
Sélection de la plage de balayage sur un
angle de 540°
Sélection de la plage de balayage sur un
angle de 360°
Sélection de la plage de balayage sur un
angle de 180°
Sélection de la plage de basculement sur un
angle de 270°
Sélection de la plage de basculement sur un
angle de 180°
Sélection de la plage de basculement sur un
angle de 90°
OFF
Mode normal
UP
Mode totem base haut
DOWN
Mode totem base bas
Normal
Fast
Slow
Réglage de la vitesse du ventilateur en
fonction de la temp érature
Full
Vitesse du ventilateur à la vitesse maximale
Le rétro-éclairage de l'affichage s'éteint après
un délai d'inactivité
ON
Le rétro-éclairage de l'affichage reste allumé
OFF
Affichage normal
ON
Affichage inversé
Options du menu
Fonction principale Niveaux de programmation Description
Run Mode
DMX
Manual
Pan Reverse
Tilt Reverse
Pan Angle
Tilt Angle
Activation du mode DMX
Sound
540
360
180
270
180
Setup
Totem Mode
P/T Speed
Fans
Display
Screen Rev
90
Sélect ion de la vit es se de
basculement/balayage
Auto
OFF
32
Intimidator Trio MR FR
Square
I Squa
SCurve
Linear
Fast
Smooth
RED
GREEN
BLUE
WHITE
Sensitivity
001–100
Permet de configurer la sensibilité au son
Reset
Réinitialisation de l'appareil
Factory Set
Chargement des paramètres par défaut
Ver V_
Affiche la version du logiciel.
Running Mode _ _ _ _ _
Affiche le mode d'exécution c ourant.
DMX Address _ _ _
Affiche l'adresse DMX courante
Affiche la température des LEDs en degrés
Celsius
Chaînage DMX
L'Intimidator Trio peut fonctionner avec un contrôleur DMX lorsqu'il est
relié par des connexions séries DMX. Les instructions pour la connexion et
la configuration de cet appareil pour le fonctionnement en DMX sont
Si vous n'êtes pas familier avec le
protocole DMX, vou s pouvez téléch arger l'intro duction au DM X à l'adresse
Adresse de
départ
haque mode DMX,
Connexion
'Intimidator Trio utilise une connexion de données DMX pour le
fonctionnement de son mode maître/esclave. Les instructions pour la
appareil pour le fonctionnement en
Fonction principale Niveaux de programmation Description
Dimmer Curve
Dimmer Speed
Setup
(suite)
Color Balance
Sys Info
Temperature _ _ _
indiquées dans le manuel d'utilisation.
www.chauvetlighting.com.
Pour permettre un accès à l'ensemble des canaux de c
l'adresse DMX maximale recommandée est 483.
L
maître/esclave
connexion et la configuration de cet
maître/esclave sont indiquées dans le manuel d'utilisation.
Permet de sélectionner le mode de courbe de
gradation
Permet de sélectionner la vitesse de gradation
Permet de sélectionner la balance de couleur
(100 à 255)
33
Intimidator Trio MR FR
30-CH
1
Balayage
000 ó 255
0 à 540°
2
Balayage fin
000 ó 255
Contrôle précis du balayage
3
Basculement
000 ó 255
0 à 270°
4
Basculement fin
000 ó 255
Contrôle précis du basculement
Vitesse de balayage/basculement (rapide à
lent)
6
Rouge
000 ó 255
0 à 100%
7
Vert
000 ó 255
0 à 100%
8
Bleu
000 ó 255
0 à 100%
9
Blanc
000 ó 255
0 à 100%
10
Rouge
000 ó 255
0 à 100%
11
Vert
000 ó 255
0 à 100%
12
Bleu
000 ó 255
0 à 100%
13
Blanc
000 ó 255
0 à 100%
14
Rouge
000 ó 255
0 à 100%
15
Vert
000 ó 255
0 à 100%
16
Bleu
000 ó 255
0 à 100%
17
Blanc
000 ó 255
0 à 100%
18
Aucune fonction
000 ó 255
Aucune fonction (préréglage)
19
Aucune fonction
000 ó 255
Aucune fonction (préréglage)
20
Aucune fonction
000 ó 255
Aucune fonction (préréglage)
21
Aucune fonction
000 ó 255
Aucune fonction (préréglage)
Valeurs DMX
Canal Fonction Valeur Pourcentage/Paramétrage
5 Vitesse
Intimidator Trio
Zones de contrôle
000 ó 255
Zone 1
Zone 2
Zone 3
1
3
2
2
3
1
34
Intimidator Trio MR FR
30-CH
000 ó 004
Aucune fonction
005 ó 009
Couleur 1
010 ó 014
Couleur 2
015 ó 019
Couleur 3
020 ó 024
Couleur 4
025 ó 029
Couleur 5
030 ó 034
Couleur 6
035 ó 039
Couleur 7
040 ó 044
Couleur 8
045 ó 049
Couleur 9
050 ó 054
Couleur 10
055 ó 059
Couleur 11
060 ó 064
Couleur 12
065 ó 069
Couleur 13
070 ó 074
Couleur 14
075 ó 079
Couleur 15
080 ó 084
Couleur 16
085 ó 089
Couleur 17
090 ó 094
Couleur 18
095 ó 099
Couleur 19
100 ó 104
Couleur 20
105 ó 109
Couleur 21
110 ó 114
Couleur 22
115 ó 119
Couleur 23
120 ó 124
Couleur 24
125 ó 129
Couleur 25
130 ó 134
Couleur 26
135 ó 139
Couleur 27
140 ó 144
Couleur 28
145 ó 149
Couleur 29
150 ó 154
Couleur 30
155 ó 159
Couleur 31
160 ó 164
Couleur 32
165 ó 169
Couleur 33
170 ó 174
Couleur 34
175 ó 179
Aucune fonction
Changement de couleur dans le sens horaire
(rapide à lent)
202 ó 207
Arrêt (la couleur actuellement affichée reste)
Changement de couleur dans le sens
antihoraire (rapide à lent)
230 ó 234
Aucune fonction
235 ó 249
Saut de couleur (rapide à lent)
250 ó 255
Couleurs activées par le son
Canal Fonction Valeur Pourcentage/Paramétrage
(suite)
22 Couleurs
180 ó 201
208 ó 229
35
Intimidator Trio MR FR
30-CH
000 ó 015
Aucune fonction
016 ó 031
Macro de zone 1
032 ó 047
Macro de zone 2
048 ó 063
Macro de zone 3
064 ó 079
Macro de zone 4
080 ó 095
Macro de zone 5
096 ó 111
Macro de zone 6
112 ó 127
Intégr é 7 (macros de zone 1 à 6)
128 ó 143
Intégr é auto 1
144 ó 159
Intégr é auto 2
160 ó 175
Intégr é auto 3
176 ó 191
Intégr é auto 4
192 ó 207
Intégr é auto 5
208 ó 223
Intégr é auto 6
224 ó 239
Intégr é auto 7
240 ó 255
Intégr é 8 (intégré auto 1 à 7)
Macros de zones et vitesse automatique
intégrée (lent à rapide)
25
Gradateur
000 ó 255
0 à 100%
000 ó 019
Fermé
020 ó 024
Ouvert
025 ó 064
Effet stroboscopique (vitesse en diminution)
065 ó 069
Ouvert
070 ó 084
Marche rapide/arrêt lent (vitesse en diminution)
085 ó 089
Ouvert
090 ó 104
Marche lente/arrêt rapide (vitesse en diminution)
105 ó 109
Ouvert
110 ó 124
Obturateur aléatoire (vitesse en diminution)
125 ó 129
Ouvert
Marche rapide/arrêt lent aléatoire (vitesse en
diminution)
145 ó 149
Ouvert
Marche lente/arrêt rapide aléatoire (vitesse
en diminution)
165 ó 169
Ouvert
170 ó 184
Effet pulsa tion 1 (vit es se en dimi nution)
185 ó 189
Ouvert
190 ó 204
Effet pulsation 2 (vitesse en diminution)
205 ó 209
Ouvert
210 ó 224
Marche/arrêt progressif (vitesse en diminution)
225 ó 229
Ouvert
230 ó 244
Fermé
245 ó 255
Ouvert
27
Zoom
000 ó 255
Zoom avant et arrière
Canal Fonction Valeur Pourcentage/Paramétrage
(suite)
23 Contrôle intégré
24 Vitesse i n tégrée
26 Obturateur
000 ó 255
130 ó 144
150 ó 164
36
Intimidator Trio MR FR
30-CH
000 ó 009
Aucune fonction
010 ó 014
Noir général pendant le balayage/basculement
015 ó 019
Aucune fonction
020 ó 049
Réservé pour utilisation future
050 ó 054
Réinitialisation du bal a ya ge
055 ó 059
Réinitialisation du ba sculement
060 ó 064
Réinitialisation du zo om
065 ó 069
Réinitialisation de la rotation
070 ó 074
Réinitialisation tot al e
075 ó 079
Aucune fonction
080 ó 084
Balayage/basculement inverse
085 ó 089
Balayage inverse
090 ó 094
Basculement inversé
095 ó 099
Annulation du balayage inverse
100 ó 104
Annulation du basculement inverse
105 ó 109
Annulation du balayage/basculement inverse
110 ó 114
Vitesse normale balayage/basculement
115 ó 119
Vitesse rapide balayage/basculement
120 ó 124
Vitesse lente balayage/basculement
125 ó 129
Ventilateur (vitesse maximale)
130 ó 134
Ventilateur (automatique)
135 ó 139
Gradateur, rapide
140 ó 144
Gradateur, doux
145 ó 255
Aucune fonction
000 ó 007
Aucune fonction
008 ó 023
Macro de mouvement automatique 1
024 ó 039
Macro de mouvement automatique 2
040 ó 055
Macro de mouvement automatique 3
056 ó 071
Macro de mouvement automatique 4
072 ó 087
Macro de mouvement automatique 5
088 ó 103
Macro de mouvement automatique 6
104 ó 119
Macro de mouvement automatique 7
120 ó 135
Macro de mouvement automatique 8
136 ó 151
Macro de mouvement activé par le son 1
152 ó 167
Macro de mouvement activé par le son 2
168 ó 183
Macro de mouvement activé par le son 3
184 ó 199
Macro de mouvement activé par le son 4
200 ó 215
Macro de mouvement activé par le son 5
216 ó 231
Macro de mouvement activé par le son 6
232 ó 247
Macro de mouvement activé par le son 7
248 ó 255
Macro de mouvement activé par le son 8
000 ó 063
Chenillard en rotation
dessus de
Petit tremblemen t en rotation
(lent à rapide)
Grand tremblement en rotation
(lent à rapide)
128 ó 191
Rotation (lent à rapide)
192 ó 255
Rotation inverse (lent à rapide)
Canal Fonction Valeur Pourcentage/Paramétrage
(suite)
Fonctions de
28
contrôle
Macros de
29
mouvements
30 Rotation
064 ó 095
096 ó 127
37
Lorsque la
valeur du
canal 27
(Zoom) est
au-
150
Intimidator Trio MR FR
15-CH
1
Balayage
000 ó 255
0 à 540°
2
Basculement
000 ó 255
0 à 270°
3
Vitesse
000 ó 255
Balayage/basculement (rapide à lent)
4
Rouge
000 ó 255
0 à 100%
5
Vert
000 ó 255
0 à 100%
6
Bleu
000 ó 255
0 à 100%
7
Blanc
000 ó 255
0 à 100%
000 ó 015
Aucune fonction
016 ó 031
Macro de zone 1
032 ó 047
Macro de zone 2
048 ó 063
Macro de zone 3
064 ó 079
Macro de zone 4
080 ó 095
Macro de zone 5
096 ó 111
Macro de zone 6
112 ó 127
Intégr é 7 (macros de zo ne 1 à 6)
128 ó 143
Intégr é auto 1
144 ó 159
Intégr é auto 2
160 ó 175
Intégr é auto 3
176 ó 191
Intégr é auto 4
192 ó 207
Intégr é auto 5
208 ó 223
Intégr é auto 6
224 ó 239
Intégr é auto 7
240 ó 255
Intégr é 8 (intégré auto 1 à 7)
Zones et v itesse aut omatique intégrée ( lent à
rapide)
10
Gradateur
000 ó 255
0 à 100%
Canal Fonction Valeur Pourcentage/Paramétrage
8 Contrôle intégré
9 Vitesse i n tégrée
000 ó 255
38
Intimidator Trio MR FR
15-CH
000 ó 019
Fermé
020 ó 024
Ouvert
025 ó 064
Effet stroboscopique (vitesse en diminution)
065 ó 069
Ouvert
Marche rapide/arrêt lent (vitesse en
diminution)
085 ó 089
Ouvert
Marche lente/arrêt rapide (vitesse en
diminution)
105 ó 109
Ouvert
110 ó 124
Obturateur aléatoire (vitesse en diminution)
125 ó 129
Ouvert
Marche rapide/arrêt lent aléatoire (vitesse en
diminution)
145 ó 149
Ouvert
Marche lente/arrêt rapide aléatoire (vitesse
en diminution)
165 ó 169
Ouvert
170 ó 184
Effet pulsation 1 (vitesse en diminution)
185 ó 189
Ouvert
190 ó 204
Effet pulsation 2 (vitesse en dim inution)
205 ó 209
Ouvert
Marche/arrêt progressif (vitesse en
diminution)
225 ó 229
Ouvert
230 ó 244
Effet pulsation 3 (vitesse en diminution)
245 ó 255
Ouvert
12
Zoom
000 ó 255
Zoom avant et arrière
Canal Fonction Valeur Pourcentage/Paramétrage
(suite)
070 ó 084
090 ó 104
11 Obturateur
130 ó 144
150 ó 164
210 ó 224
39
Intimidator Trio MR FR
15-CH
000 ó 009
Aucune fonction
010 ó 014
Noir général balayage/basculement
015 ó 019
Aucune fonction
020 ó 049
Réservé pour utilisation future
050 ó 054
Réinitialisation du bal a ya ge
055 ó 059
Réinitialisation du ba sculement
060 ó 064
Réinitialisation du zo om
065 ó 069
Aucune fonction
070 ó 074
Réinitialisation tot al e
075 ó 079
Aucune fonction
080 ó 084
Balayage/basculement inverse
085 ó 089
Balayage inverse
090 ó 094
Basculement inversé
095 ó 099
Annulation du balayage inverse
100 ó 104
Annulation du basculement inverse
105 ó 109
Annulation du balayage/basculement inverse
110 ó 114
Vitesse normale balayage/basculement
115 ó 119
Vitesse rapide balayage/basculement
120 ó 124
Vitesse lente balayage/basculement
125 ó 129
Ventilateur (vitesse maximale)
130 ó 134
Ventilateur (automatique)
135 ó 139
Gradateur, rapide
140 ó 144
Gradateur, doux
145 ó 255
Aucune fonction
000 ó 007
Aucune fonction
008 ó 023
Macro de mouvement automatique 1
024 ó 039
Macro de mouvement automatique 2
040 ó 055
Macro de mouvement automatique 3
056 ó 071
Macro de mouvement automatique 4
072 ó 087
Macro de mouvement automatique 5
088 ó 103
Macro de mouvement automatique 6
104 ó 119
Macro de mouvement automatique 7
120 ó 135
Macro de mouvement automatique 8
136 ó 151
Macro de mouvement activé par le son 1
152 ó 167
Macro de mouvement activé par le son 2
168 ó 183
Macro de mouvement activé par le son 3
184 ó 199
Macro de mouvement activé par le son 4
200 ó 215
Macro de mouvement activé par le son 5
216 ó 231
Macro de mouvement activé par le son 6
232 ó 247
Macro de mouvement activé par le son 7
248 ó 255
Macro de mouvement activé par le son 8
000 ó 063
Chenillard en rotation
valeur du canal
Petit tremblement en rotat i on
(lent à rapide)
Grand tremblement en rotation
(lent à rapide)
128 ó 191
Rotation (lent à rapide)
192 ó 255
Rotation inverse (lent à rapide)
Canal Fonction Valeur Pourcentage/Paramétrage
(suite)
13
14
Fonctions de
contrôle
Macros de
mouvements
15 Rotation
064 ó 095
096 ó 127
40
Lorsque la
27 (Zoom) est
au-dessus de
150
Intimidator Trio SAL DE
Über diese
In der Schnellanleitung des Intimidator Trio finden Sie die wesentlichen
Produktinformationen, wie etwa über die Montage, Menüoptionen und
Werte des Geräts. Laden Si e für weiterführende Info rmationen unter
www.chauvetlighting.com das Benutz e r ha n dbuch herunter.
Haftungsausschluss
Die in dieser Anleitung aufgeführten Informationen und Spezifikationen
können ohne vorherige Ankündigung geändert werden.
Sicherheitshinweise
Diese Sicherheitshinweise enthalten wichtige Informationen über die
Montage, Verwendung und Wartung des Geräts.
• Schließen Sie dieses Produkt nur an einen geerdeten und geschützten
• Nicht während des Betriebs das Gehäus e berühren, da dieses sehr heiß wird.
• Die Spannung der Schukosteckdose, a n die Sie das Ge rät anschl ieße n, m uss
oder durch Herausziehen des Steckers aus der Steckdose.
Schnellanleitung
DMX-
Stromkreis an.
• Trennen Sie das Gerät von der Stromquelle, bevor Sie es reinigen oder
die Sicherung auswechseln.
• Nicht in die Lichtquel le schauen, während das Gerät eingeschaltet ist.
• Stellen Sie sicher, dass das Netzkabel nicht gequetscht oder beschädigt ist.
• Ziehen Sie beim Trennen des Geräts von der Stromversorgung nie am Kabel.
• Bei Montage über Kopf immer ein Sicherungsseil verwenden.
• Keine entflammbaren Mater ialien während des Betr iebs in der Nähe
des Geräts lagern.
sich innerhalb des Spannungsbere iches befinde n, der auf dem
Hinweisschild oder dem rückwärtigen Be dienfel d des Geräts angeg eben ist.
• Dieses Gerät darf nur i m Innenbereich verwendet werden. (IP20) Um
das Risiko von Bränden oder elektrischen Schlägen zu vermeiden,
dürfen Sie das Gerät nicht Regen oder Feuchtigkeit aussetzen.
• Installieren Sie das Gerät an einem Ort mit ausreichender Belüftung
und mit einem Abstand von 50 cm zu den angrenzenden Flächen.
• Stellen Sie sicher, dass die Lüftungsöffnungen im Gehäuse des Gerät s
nicht verschlossen sind.
• Schließen Sie dieses Gerät niemals an einen Dimm er oder Regelwiderstand an.
• Achten Sie beim Auswechseln der Sicherung darau f, den gleichen Typ
mit den gleichen Werten zu verwenden.
• Das Gerät nur an Griffen oder montierten Befestigungsbügeln mit der
für dieses Gerät entsprechenden Tragkraft tragen .
• Die maximal zulässige Umgeb ungstemperatur beträgt 40 °C. Nehmen
Sie das Gerät nicht bei höheren Temperaturen in B etrieb.
• Bei ernsthaften Betriebsproblemen stoppen Sie umgehend die
Verwendung des Geräts.
• Dieses Gerät nicht öffnen. Die eingebauten Komponenten sind für den
Kunden wartungsfrei.
• Um unnötigen Verschleiß zu vermeiden und die Lebensdauer des
Geräts zu verlängern, trennen Sie während längerer Perioden des
Nichtgebrauchs das Gerät vom Stromnetz – entweder p er Trennschalter
41
Intimidator Trio SAL DE
Kontakt
Kunden auße r ha l b de r U SA, GB, Irla nd , Me xiko oder der B enelux-Staaten wenden sich
an ihren Lieferanten, um den Kundensupport in Anspruch zu nehmen oder ein Produkt
zurückzuschicken. Kontaktinf ormationen fin den Sie unte r www.chauvetlighting.com.
Packungsinhalt
• Intimidator Trio
• Netzkabel
Schnellanleitung
Start
Packen Sie Ihren Intimidator Trio aus und überprüfen Sie, ob Sie alle Teile
haben. Wenn die Verpackung beschädigt ist,
benachrichtigen Sie umgehend das Transportunte rnehmen, nicht jedoch Cha uvet.
Beschreibung
Der Intimid ator Trio ist ein mi t zahlreich en Funktionen au sgestatteter, kompakter
weiteren Effekten. Er verfügt über 6
LEDs. Der motorbetriebene Zoom erlaubt kurze und lange
Projektionsdistanzen und ein kontinuierlich rotierendes Wabengitter sorgt für einen
Anzeige
ermögli cht ein einf aches Nav igieren und eine vol lständ ige Textan zeige. Er erzeugt
Modus mit integrierten automatischen
50 VIP Gear Bag von Chauvet lässt sich der Intimidator Trio bequem transportieren.
LCD- Anzeige
Steuerungstasten
Anzeigeleuchte
Joch
Ansicht des
Bedienfelds
Stromausgang
DMX Eingang
DMX-
Ausgang
Stromzufuhr
Vorderansicht
• Hängebügel mit
Befestigungsmaterial
• Garantiekarte
•
unbeschädigt erhalten
Moving Head mit Strahlen-, Wash- und
vierfarbige RGBW-
aufregenden Beleuchtungseffekt. Die kontrastreiche, farbige LCD-
synchronisierte Show im Master/SlaveProgrammen, auf die bequem zugegriffen werden kann. Die optionale IR-6Fernbedienung von Chauvet ermöglicht eine Bedienung ohne DMX. Mit dem CHS-
Übersicht
Sicherungshalter
42
IR Sensor
rückwärtigen
Intimidator Trio SAL DE
Wechselstrom
Dieses Gerät verfügt üb er ein Vors chaltgerät , das au tomatisch d ie anl iegende
Spannung erkennt , sobald der Netzstecker in die Schukos teckdose gesteckt
wird, und kann mit einer Eingangsspannung von 100 bis 240 V AC, 50/60
Serienschaltung
der Geräte
Geräte, die in
Serie geschaltet werden können, finden Sie in der Bedienungsanleitung oder
Auswechseln
der Sicherung
1. Trennen Sie das Gerät vom Stromnetz.
Gerät an das Stromnetz an.
Infrarot-
Fernbedienung
6)
Der Intimidator Trio ist vollständig kompatibel mit der InfrarotFernbedienung 6 (IRC-6) von Chauvet.
Hz arbeiten.
Informationen zur maximalen Anzahl der Intimidator Trio-
auf dem Typenschild am Gerät.
2. Mithilfe eines Flachkopfschraubendrehers lockern Sie den
Sicherungshal te r un d zi e he n ihn gerade heraus.
3. Entfernen Sie die durchgebrannte Sicherung von der Klemme, und
ersetzen Sie diese du rch eine Sicherung des gleichen Typs und mit den
gleichen Werten.
4. Stecken Sie den Sicherungshalter wieder zurück, und schließen Sie das
6 (IRC-
Die folgenden Tasten der I R C-6-Fernbedienung werden für den Intimidator
Trio verwendet:
• <BLACKOUT> - schaltet die LED ein/aus
• <AUTO> - wählt den Auto-Programm-Modus aus (scrollen)
• <SOUND> - wählt den Musiksteuerungs-Modus aus
• <STROBE> - Stroboskopeffekt (0–20 Hz)
• <SPEED> - Geschwindigkeit des Auto-Programms (Schwenkung und
Neigung)
• <SENSITIVITY> - wählt die Musikempfindlichkeit aus
• <%> - LED-Dimmer
• <MANUAL> - manuelle Steuerung
• <FADE> - für Fade-Farbwechsel einmal drücken, für Sn ap zweimal
drücken
• <R> - manuelle Steuerun g der roten LED
• <G> - manuelle Steuerung der grünen LED
• <B> - manuelle Steuerung der blauen LED
• <W> - manuelle Steuerung der weißen LED
• <UV> - manuelle Einstellung des Zooms/der Rotation
• <A> - manuelle Einstellung von Schwenkung und Neigung
• <+> - erhöhen
• <+> - senken
• <0> bis <9> - wählt das Auto-Programm nach der Nummer aus
43
Intimidator Trio SAL DE
Montage
Montageansicht
Versichern Sie sich, dass bei Verwendung von nur einer
Befestigungsklemme eine Sicherungsschraube zum Einsatz kommt, um
ein unbeabsichtigtes Lösen zu verhindern.
Beschreibung
des
<MENU>
Damit verlassen Sie das aktuelle Menü oder die Funktion.
Damit navigieren Sie sich durch die Menüpunkte nach oben und
erhöhen den numerischen Wert der entsprechenden Funktion.
Damit navigieren Sie sich durch die Menüpunkte nach unten und
verringern den numerischen Wert der entsprechenden Funktion.
Damit wird das aktuell angezeigte Menü aktiviert oder der aktuell
ausgewählte Wert einer Funktion eingestellt.
Befestigungsschelle
oder CLP-15N von Chauvet)
Montagebohrungen für
/Befestigungsbügel
Durchschlaufung
Montagebohrung
Lesen Sie vor der Montage dieses Geräts in jedem Fall die Sicherheitshinweise.
(funktioniert mit Schelle CLP-15
Befestigungsbügel
Bedienfeldes
Gummifüße (x4)
für Befestigung am
für
Taste Funktion
<UP>
<DOWN>
<ENTER>
44
Sicherheitskabel
Griff (x2)
Hänge-
Sicherheitskabel-
Intimidator Trio SAL DE
Address
001–512
Stellt die DMX-Startadresse ein
15CH
30CH
Slave
Slave 1–4
Wählt den Slave-Modus aus
Auto
Wählt das Auto-Modus aus
Sound
Wählt den Musiksteuerungs-Modus aus
IR
Wählt eine Infrarot-Steuerung
Pan
000–255
Manuelle Einstellung von Schwenkung
Tilt
000–255
Manuelle Einstellung von Neigung
Manuelle Einstellung von Schwenkung und
Neigung Geschwindigkeit
Color
000–255
Manuelle Einstellung von Farben
Rotate
000–255
Manuelle Einstellung von Rotierend
Zoom
000–255
Manuelle Einstellung von Zoom
Dimmer
000–255
Manuelle Einstellung von Dimmer
OFF
Normaler Schwenk-Modus
ON
Umgekehrter Schwenk-Modus
OFF
Normaler Neigungs-Modus
ON
Umgekehrter Neigungs-Modus
540
Wählt den 540°-Schwenkwinkelbereich aus
360
Wählt den 360°-Schwenkwinkelbereich aus
180
Wählt den 180°-Schwenkwinkelbereich aus
270
Wählt den 270°-Neigungswinkelbereich aus
180
Wählt den 180°-Neigungswinkelbereich aus
90
Wählt den 90°-Neigungswinkelbereich aus
OFF
Normal-Modus
UP
Totem-Mo dus "Base Up "
DOWN
Totem-Modus "Base Down"
Normal
Fast
Slow
Stellt die Lüfterdrehzahl nach der Temperatur
ein
Full
Lüfterdrehzahl auf volle Drehzahl
Hintergrundbeleuchtung der Anzeige schaltet
nach Inaktivität aus
Hintergrundbeleuchtung der Anzeige bleibt
immer an
OFF
Normale Anzeige
ON
Umgekehrte Anzeige
Square
I Squa
SCurve
Linear
Menüoptionen
Hauptfunktion Programmierebenen Beschreibung
Run Mode
Setup
DMX
P/T Speed 000–255
Manual
Pan Reverse
Tilt Reverse
Pan Angle
Tilt Angle
Totem Mode
P/T Speed
Wählt den DMX-Modus aus
Wählt die Geschwindigkeit der
Schwenkung/Neigung aus
Fans
Display
Screen Rev
Dimmer Curve
Auto
OFF
ON
Wählt die Dimmungskurve aus
45
Intimidator Trio SAL DE
Fast
Smooth
RED
GREEN
BLUE
WHITE
Sensitivity
001–100
Stellt d ie Musikem pfindlichkeit ei n
Reset
Setzt das Gerät zurück
Factory Set
Lädt Werkseinstellung
Ver V_
Zeigt die Software-Version an
Running Mode _ _ _ _ _
Zeigt den aktuellen Betriebsmodus an
DMX Address _ _ _
Zeigt die aktuelle DMX-Adresse an
Temperature _ _ _
Zeigt die LED-Temperatur in Grad Celsius an
DMX-
Controller betrieben werden,
Serienschaltung zum Einsatz kommt. Anweisungen zum
Zusammenschluss und der Konfiguration dieses Geräts für den Betrieb im
mit DMX nicht
Eine Einführung" unter
Startadresse
Modus zu
Master/Slave-
um Zusammenschluss und der
Modus finden
Hauptfunktion Programmierebenen Beschreibung
Dimmer Speed
Setup
(Fortsetzung)
Sys Info
Color Balance
Der Intimidator Trio kann mit einem DMX-
Verbindung
wenn eine DMX-
DMX-Modus finden Sie im Benutzerhandbuch. Wenn Sie
vertraut sind, laden Sie "DMX -
www.chauvetlighting.com herunter.
Um einen vollständigen Zugang zu allen Kanälen in jed em DMXgewährleisten, beträgt die höchste empfohlene DMX-Adresse 483.
Der Intimidator Trio verwend et für seinen Master /Slave-Modus eine DMX-
Schaltung
Datenverbindung. Anweisungen z
Konfiguration dieses Geräts für den B etrieb im Master/SlaveSie im Benutzerhandbuch.
Wählt die Dimmergeschwindigkeit aus
Wählt die Farbbalance aus (100 bis 255)
46
Intimidator Trio SAL DE
30CH
1
Schwenkung
000 ó 255
0 bis 540°
2
Schwenkung fein
000 ó 255
Feinkontrolle der Schwenkung
3
Neigung
000 ó 255
0 bis 270°
4
Neigung fein
000 ó 255
Feinkontrolle der Neigung
Geschwindigkeit der Schwenkungs- und
Neigungsbewegung (schnell bis langsam)
6
rot
000 ó 255
0 bis 100%
7
grün
000 ó 255
0 bis 100%
8
blau
000 ó 255
0 bis 100%
9
weiß
000 ó 255
0 bis 100%
10
rot
000 ó 255
0 bis 100%
11
grün
000 ó 255
0 bis 100%
12
blau
000 ó 255
0 bis 100%
13
weiß
000 ó 255
0 bis 100%
14
rot
000 ó 255
0 bis 100%
15
grün
000 ó 255
0 bis 100%
16
blau
000 ó 255
0 bis 100%
17
weiß
000 ó 255
0 bis 100%
18
Keine Funktion
000 ó 255
Keine Funktion (Voreinstellung)
19
Keine Funktion
000 ó 255
Keine Funktion (Voreinstellung)
20
Keine Funktion
000 ó 255
Keine Funktion (Voreinstellung)
21
Keine Funktion
000 ó 255
Keine Funktion (Voreinstellung)
DMX Werte
Kanal Funktion Wert Prozent/ Einstellung
5 Geschwindigkeit
Intimidator Trio Steuerungszonen
000 ó 255
Zone 1
Zone 2
Zone 3
1
3
2
2
3
1
47
Intimidator Trio SAL DE
30CH
000 ó 004
Keine Funktion
005 ó 009
Farbe 1
010 ó 014
Farbe 2
015 ó 019
Farbe 3
020 ó 024
Farbe 4
025 ó 029
Farbe 5
030 ó 034
Farbe 6
035 ó 039
Farbe 7
040 ó 044
Farbe 8
045 ó 049
Farbe 9
050 ó 054
Farbe 10
055 ó 059
Farbe 11
060 ó 064
Farbe 12
065 ó 069
Farbe 13
070 ó 074
Farbe 14
075 ó 079
Farbe 15
080 ó 084
Farbe 16
085 ó 089
Farbe 17
090 ó 094
Farbe 18
095 ó 099
Farbe 19
100 ó 104
Farbe 20
105 ó 109
Farbe 21
110 ó 114
Farbe 22
115 ó 119
Farbe 23
120 ó 124
Farbe 24
125 ó 129
Farbe 25
130 ó 134
Farbe 26
135 ó 139
Farbe 27
140 ó 144
Farbe 28
145 ó 149
Farbe 29
150 ó 154
Farbe 30
155 ó 159
Farbe 31
160 ó 164
Farbe 32
165 ó 169
Farbe 33
170 ó 174
Farbe 34
175 ó 179
Keine Funktion
Farbänderung im Uhrzeigersinn (schnell bis
langsam)
202 ó 207
Stopp (Farbe bleibt aktuelle Farbe)
Farbänderung entgegen dem Uhrzeigersinn
(schnell bis langsam)
230 ó 234
Keine Funktion
235 ó 249
Farbspr ung (schn ell bis langsam)
250 ó 255
Musiksteuerungs-Farben
Kanal Funktion Wert Prozent/ Einstellung
(Forts.)
22 Farben
180 ó 201
208 ó 229
48
Intimidator Trio SAL DE
30CH
000 ó 015
Keine Funktion
016 ó 031
Zonenmakro 1
032 ó 047
Zonenmakro 2
048 ó 063
Zonenmakro 3
064 ó 079
Zonenmakro 4
080 ó 095
Zonenmakro 5
096 ó 111
Zonenmakro 6
112 ó 127
Integr iert 7 (Zone nmakros 1—6)
128 ó 143
Integriertes Auto 1
144 ó 159
Integriertes Auto 2
160 ó 175
Integriertes Auto 3
176 ó 191
Integriertes Auto 4
192 ó 207
Integriertes Auto 5
208 ó 223
Integriertes Auto 6
224 ó 239
Integriertes Auto 7
240 ó 255
Integr iert 8 (int egriertes Auto 1 bis 7)
Integrierte
Geschwindigkeit
Zonen-Makros und integrie rte AutoGeschwindigkeit (langsam bis schnell)
25
Dimmer
000 ó 255
0 bis 100%
000 ó 019
Geschlossen
020 ó 024
Offen
025 ó 064
Stroboskopeffekt (sinkende Geschw indig kei t)
065 ó 069
Offen
Schnell ein, langsam aus (sinkende
Geschwindigkeit)
085 ó 089
Offen
Langsam ein, schnell aus (sinkende
Geschwindigkeit)
105 ó 109
Offen
110 ó 124
Zufalls-Shutter (sinkende Geschwindi gkeit)
125 ó 129
Offen
Zufall schnell ein, langsam aus (sinkende
Geschwindigkeit)
145 ó 149
Offen
Zufall langsam ein, schnell aus (sinkende
Geschwindigkeit)
165 ó 169
Offen
170 ó 184
Pulse-Effekt 1 (sinkende Geschwindigkeit)
185 ó 189
Offen
190 ó 204
Pulse-Effekt 2 (sinkende Geschwindigkeit)
205 ó 209
Offen
Stufenweise ein und aus (sinkende
Geschwindigkeit)
225 ó 229
Offen
230 ó 244
Pulse-Effekt 3 (sinkende Geschwindigkeit)
245 ó 255
Offen
27
Zoom
000 ó 255
Vergrößern und verkleinern
Kanal Funktion Wert Prozent/ Einstellung
(Forts.)
Integrierte
23
Steuerung
24
26 Shutter
000 ó 255
070 ó 084
090 ó 104
130 ó 144
150 ó 164
210 ó 224
49
Intimidator Trio SAL DE
30CH
000 ó 009
Keine Funktion
010 ó 014
Verdunkelung während der Schwen kung/ Ne igu ng
015 ó 019
Keine Funktion
020 ó 049
Für künftige Verwendung reserviert
050 ó 054
Schwenkung zurück set z en
055 ó 059
Neigung zurückset zen
060 ó 064
Zoom zurücksetzen
065 ó 069
Rotation zurückset zen
070 ó 074
Alle zurücksetzen
075 ó 079
Keine Funktion
080 ó 084
Umgekehrte Schwenkung/Neigung
085 ó 089
Umgekehrte Schwenkung
090 ó 094
Umgekehrte Neigung
095 ó 099
Umgekehrte Schwenkung abbrechen
100 ó 104
Umgekehrte Neigu ng ab br echen
105 ó 109
Umgekehrte Schwenkung/Neigung abbrechen
110 ó 114
Normale Schwenkungs-/Neigungsgeschwindigkeit
115 ó 119
Hohe Schwenkungs-/Neigungsgeschwindigkeit
120 ó 124
Niedrige Schwenkungs-/Neigungsgeschwindigkeit
125 ó 129
Lüfter (volle Drehzahl)
130 ó 134
Lüfter (automatisch )
135 ó 139
Dimmer, hohe Geschwindigkeit
140 ó 144
Dimmer, niedrige Geschwindigkeit
145 ó 255
Keine Funktion
000 ó 007
Keine Funktion
008 ó 023
Makro für automatische Bewegung 1
024 ó 039
Makro für automatische Bewegung 2
040 ó 055
Makro für automatische Bewegung 3
056 ó 071
Makro für automatische Bewegung 4
072 ó 087
Makro für automatische Bewegung 5
088 ó 103
Makro für automatische Bewegung 6
104 ó 119
Makro für automatische Bewegung 7
120 ó 135
Makro für automatische Bewegung 8
136 ó 151
Makro für musikgesteuerte Bewegung 1
152 ó 167
Makro für musikgesteuerte Bewegung 2
168 ó 183
Makro für musikgesteuerte Bewegung 3
184 ó 199
Makro für musikgesteuerte Bewegung 4
200 ó 215
Makro für musikgesteuerte Bewegung 5
216 ó 231
Makro für musikgesteuerte Bewegung 6
232 ó 247
Makro für musikgesteuerte Bewegung 7
248 ó 255
Makro für musikgesteuerte Bewegung 8
000 ó 063
Rotierender Chase
Rotierender kleiner Shake (langsam
bis schnell)
Rotierender großer Shake (langsam
bis schnell)
128 ó 191
Rotierend (von lan gsa m nach sc hn ell )
In umgekehrter Richtung rotierend
(von langsam nach schnell)
Kanal Funktion Wert Prozent/ Einstellung
(Forts.)
28 Steuerfunktionen
29 Bewegungsmakros
30 Rotierend
064 ó 095
096 ó 127
192 ó 255
50
(Wenn der
Wert für
Kanal 27
(Zoom)
über 150
liegt
Intimidator Trio SAL DE
15CH
1
Schwenkung
000 ó 255
0 bis 540°
2
Neigung
000 ó 255
0 bis 270°
3
Geschwindigkeit
000 ó 255
Schwenkung/Neigung (schnell bis langsam)
4
rot
000 ó 255
0 bis 100%
5
grün
000 ó 255
0 bis 100%
6
blau
000 ó 255
0 bis 100%
7
weiß
000 ó 255
0 bis 100%
000 ó 015
Keine Funktion
016 ó 031
Zonenmakro 1
032 ó 047
Zonenmakro 2
048 ó 063
Zonenmakro 3
064 ó 079
Zonenmakro 4
080 ó 095
Zonenmakro 5
096 ó 111
Zonenmakro 6
112 ó 127
Integr iert 7 (Zone nmakros 1—6)
128 ó 143
Integriertes Auto 1
144 ó 159
Integriertes Auto 2
160 ó 175
Integriertes Auto 3
176 ó 191
Integriertes Auto 4
192 ó 207
Integriertes Auto 5
208 ó 223
Integriertes Auto 6
224 ó 239
Integriertes Auto 7
240 ó 255
Integr iert 8 (int egriertes Auto 1 bis 7)
Integrierte
Geschwindigkeit
Zonen und integrierte Auto-Geschwindigkeit
(langsam bis schnell)
10
Dimmer
000 ó 255
0 bis 100%
Kanal Funktion Wert Prozent/ Einstellung
Integrierte
8
Steuerung
9
000 ó 255
51
Intimidator Trio SAL DE
15CH
000 ó 019
Geschlossen
020 ó 024
Offen
025 ó 064
Stroboskopeffekt (sinkende Geschw indig kei t)
065 ó 069
Offen
Schnell ein, langsam aus (sinkende
Geschwindigkeit)
085 ó 089
Offen
Langsam ein, schnell aus (sinkende
Geschwindigkeit)
105 ó 109
Offen
110 ó 124
Zufalls-Shutter (sinkende Geschwindi gkeit)
125 ó 129
Offen
Zufall schnell ein, langsam aus (sinkende
Geschwindigkeit)
145 ó 149
Offen
Zufall langsam ein, schnell aus (sinkende
Geschwindigkeit)
165 ó 169
Offen
170 ó 184
Pulse-Effekt 1 (sinkende Geschwindigkeit)
185 ó 189
Offen
190 ó 204
Pulse-Effekt 2 (sinkende Geschwindigkeit)
205 ó 209
Offen
Stufenweise ein und aus (sinkende
Geschwindigkeit)
225 ó 229
Offen
230 ó 244
Pulse-Effekt 3 (sinkende Geschwindigkeit)
245 ó 255
Offen
12
Zoom
000 ó 255
Vergrößern und verkleinern
Kanal Funktion Wert Prozent/ Einstellung
(Forts.)
070 ó 084
090 ó 104
11 Shutter
130 ó 144
150 ó 164
210 ó 224
52
Intimidator Trio SAL DE
15CH
000 ó 009
Keine Funktion
010 ó 014
Schwenkungs- und Nei g un gve rd unkelung
015 ó 019
Keine Funktion
020 ó 049
Für künftige Verwendung reserviert
050 ó 054
Schwenkung zurück set z en
055 ó 059
Neigung zurückset zen
060 ó 064
Zoom zurücksetzen
065 ó 069
Keine Funktion
070 ó 074
Alle zurücksetzen
075 ó 079
Keine Funktion
080 ó 084
Umgekehrte Schwenkung/Neigung
085 ó 089
Umgekehrte Schwenkung
090 ó 094
Umgekehrte Neigung
095 ó 099
Umgekehrte Schwenkung abbrechen
100 ó 104
Umgekehrte Neigu ng ab br echen
105 ó 109
Umgekehrte Schwenkung/Neigung abbrechen
110 ó 114
Normale Schwenkungs-/Neigungsgeschwindigkeit
115 ó 119
Hohe Schwenkungs-/Neigungsgeschwindigkeit
120 ó 124
Niedrige Schwenkungs-/Neigungsgeschwindigkeit
125 ó 129
Lüfter (volle Drehzahl)
130 ó 134
Lüfter (automatisch )
135 ó 139
Dimmer, hohe Geschwindigkeit
140 ó 144
Dimmer, niedrige Geschwindigkeit
145 ó 255
Keine Funktion
000 ó 007
Keine Funktion
008 ó 023
Makro für automatische Bewegung 1
024 ó 039
Makro für automatische Bewegung 2
040 ó 055
Makro für automatische Bewegung 3
056 ó 071
Makro für automatische Bewegung 4
072 ó 087
Makro für automatische Bewegung 5
088 ó 103
Makro für automatische Bewegung 6
104 ó 119
Makro für automatische Bewegung 7
120 ó 135
Makro für automatische Bewegung 8
136 ó 151
Makro für musikgesteuerte Bewegung 1
152 ó 167
Makro für musikgesteuerte Bewegung 2
168 ó 183
Makro für musikgesteuerte Bewegung 3
184 ó 199
Makro für musikgesteuerte Bewegung 4
200 ó 215
Makro für musikgesteuerte Bewegung 5
216 ó 231
Makro für musikgesteuerte Bewegung 6
232 ó 247
Makro für musikgesteuerte Bewegung 7
248 ó 255
Makro für musikgesteuerte Bewegung 8
000 ó 063
Rotierender Chase
(Wenn der
Rotierender kleiner Shake (langsam
bis schnell)
Rotierender großer Shake (langsam
bis schnell)
128 ó 191
Rotierend (von lan gsa m nach sc hn ell )
In umgekehrter Richtung rotierend
(von langsam nach schnell)
Kanal Funktion Wert Prozent/ Einstellung
(Forts)
13 Steuerfunktionen
14 Bewegungsmakros
15 Rotierend
064 ó 095
096 ó 127
192 ó 255
53
Wert für
Kanal 27
(Zoom)
über 150
liegt
Intimidator Trio GR IT
Informazioni
La Guida Rapida di Intimidator Trio contiene informazioni di base sul
prodotto quali montaggio, opzioni menù e valori DMX. Per maggiori
dettagli, scaricare il M anuale Utente dal sito www.chauvetlighting.com
Esclusione di
responsabilità
Le informazioni e le specifiche contenute in questa guida possono essere
Note di Sicurezza
Le Note di Sicurezza includono informazioni importanti circa il montaggio,
l'uso e la manutenzione.
• Collegare questa unità SOLTANTO ad un circuito dotato di messa a terra e protetto.
• NON toccare l'unità durante il funzionamento perché potre bbe essere molto calda.
• La tensione della pr es a a muro cui si collega l'apparecchiatura deve
l'apposito interruttore, se inutilizzata per lunghi periodi.
Contatti
Per richiedere assistenza o restituire l'apparecchiatura, al di fuori di Stati Uniti,
Regno Unito, Irlanda, Messico o Benelux contattare il distributore locale. Per
informazioni sui contatti, visitare il sito Web www.chauvetlighting.com.
Che cosa è
• Intimidator Trio
relativi accessori
• Cavo di alimentazione
• Guida Rapida
Per iniziare
Disimballare Intimidator Trio ed accertarsi di aver ricevuto tutti i componenti
integri. Se l'imballo appare danneggiato, farlo immediatamente presente al
trasportatore e non a Chauvet.
sulla Guida
modificate senza preavviso.
• Prima di effettuare la pulizia o sostituire il fusibile, scollegare sempre
l'unità dall'alimentazione elettrica.
• NON guardare la sorgente luminosa quando l'unità è in funzione.
• Assicurarsi che il cavo di alimentazione non si a piegato o danneggiato.
• Non scollegare mai questa apparecchiatura dall'alimentazione elettrica
tirando il cavo.
• Per il montaggio in alto dell'unità utilizzare SEMPRE un cavo di sicurezza.
• NON collocare materiale infiammabile vicino all'unità mentre è in funzione.
trovarsi entro il campo specificato sull'etichetta o sul pannello post er iore.
• Questa apparecchiatura deve essere utilizzata soltanto in interni (IP20)!
Per evitare il rischio di incendio o di folgorazione non esporre
l'apparecchiatura alla pioggia o all'umidità.
• Montare sempre l'unità in posizione ben ventilata, ad almeno 50 cm.
(20") da qualsiasi sup erficie.
• Assicurarsi che nessuna apertura di ventilazione dell'unità sia ost ruita.
• Non collegare mai ad un dimmer o ad un reostato
• Sostituire il fusibile con un altro dello stesso tipo e classe.
• Prendere e trasportare l'unità solo per mezzo delle maniglie o di un
morsetto di montaggio con portata adeguata.
• Massima temperatura ambi ente ammessa: 40 °C (104 °F). Non utilizzare
l'apparecchiatura a temperature superiori.
• In caso di gravi problemi di funz io nam ento sos pe ndere im m ediata me nte l 'ut ili zz o.
• NON aprire l'unità. Non contiene parti riparabili dall'utente.
• Per evitarne l'eccessiva usura e migliorarne l a durata nel tempo,
scollegare l'unità dalla presa elettrica o disat tivare l'alimentazione tramite
incluso
•Staffa per montaggio sospeso con
54
•Scheda di garanzia
Intimidator Trio GR IT
Descrizione
Intimidator Trio è un versatile proiettore a testa mobile con raggio, wash ed
oom motorizzato ne
throw, mentre la trama
a nido d'ape in continua rotazione assicura tutta l'emozione di un effetto luce.
È inoltre dotato di schermo LCD full color a contrasto elevato per facile
gazione e visualizzazion e completa del testo. Possibilità di creare sho w
sincronizzati in modalità master/slave grazie ai programmi automatizzati
6 di Chauvet
à in modalità wireless non DMX.
Intimidator Spot Trio è adatto alla borsa CHS-50 VIP di Chauvet.
Display LCD
Pulsanti di
controllo
Indicatore
luminoso
Forcella
Vista pannello posteriore
Uscita
alimentazione
Ingresso DMX
Uscita DMX
Portafusibile
Ingresso
alimentazione
Vista anteriore
effetti, dotato di 6 LED quad-color RGBW. Lo z
consente l'utilizzo in applicazioni short-throw o long-
navi
integrati di facile accesso Grazie al telecomando IRC(opzionale), è possibile controllare l'unit
Vista d'insieme
Sensore IR
55
Intimidator Trio GR IT
Alimentazione
CA
Questa apparecchiatu ra è dotata di alimentatore a co mmutazione automatica
Collegamento
Per il numero massimo di apparecchiature che è possibile collegare su
ciascuna presa elettrica, fare riferimento alle note riportate sull'etichetta
4. Reinserire il portafusibile e ricollegare l'alimentazion e elettrica.
Telecomando a
infrarossi 6
6)
Intimidator Trio è compatibile con il telecomando a infrarossi 6 (IRC-6) di
Chauvet.
Premere una volta per cambi o colore Fade/Premere due
con tensione in ingress o di 100~240 V CC - 50/60 Hz.
apposta sul prodotto o al Manuale Utente.
f
(IRC-
2. Utilizzando un giravite a testa piatta, allentare il portafusibile e tirarlo
3. Rimuovere il fusibile bruciato e sostituirlo con uno identico.
Con Intimidator Trio vengono utilizzati i seguenti pulsanti del telecomando:
• <BLACKOUT> - Attiva e disattiva i LED
• <AUTO> - Seleziona la modalità programma automatico (scorrimento)
• <SOUND> - Seleziona la mod alità Attivazione sonora
• <STROBE> - Attiva lo strobo (0–20 Hz)
• <SPEED> - Velocità programma aut omatico rotazione/brandeggio
• <SENSITIVITY> - Seleziona la sensibilità sonora
• <%> - Dimmer LED
• <MANUAL> - Controllo manuale
• <FADE/SNAP> -
• <R> - Controllo manuale LED Rosso
• <G> - Controllo manuale LED Verde
• <B> - Controllo manuale LED Blu
• <W> - Controllo manuale LED Bianco
• <UV> - Regolazione manuale zoom/rotazione
• <A> - Regolazione manuale rotazione/brandeggio
• <+> - Aumento
• <-> - Diminuzione
• Da <0> a <9> - Selezion e pr ogramma automatico in base al numero
verso l'esterno.
volte per Snap
56
Intimidator Trio GR IT
Montaggio
Quando si utilizza un solo morsetto di montaggio, assicurarsi di
utilizzarne uno con prigioniero per evitare che si allenti accidentalmente.
Descrizione
del pannello di
controllo
<MENU>
Consente di uscire dal menù o dalla funzione corrente.
Consente di spostarsi verso l'alto nell'elenco menù e di aumentare
il valore numerico all'interno di una funzione.
Consente di spostarsi verso il basso nell'elenco menù e di
diminuire il valore numerico all'interno di una funzione.
Consente di attivare il menù visualizzato o impostare il valore
selezionato nella funzione selezionata.
Morsetto di montaggio
o CLP-15N di Chauvet)
Fori per staffa di
aggio/montaggio
Foro passante
sicurezza
Staffa di
montaggio
Foro di montaggio
Prima di montare l'un ità, leggere le Note di Sicurezza.
(funziona con i morsetti CLP-15
Schema
di montaggio
4 x Piedino in
gomma
per morsetto
Pulsante Funzione
<UP>
<DOWN>
<ENTER>
57
Cavo di sicurezza
Maniglia (x2)
mont
sospeso
per cavo di
Intimidator Trio GR IT
Address
001–512
Imposta l'indirizzo DMX iniziale
15CH
30CH
Slave
Slave 1–4
Seleziona la modalità Slave
Auto
Seleziona i modalità Auto
Sound
Seleziona la modalità Attivazione sonora
IR
Seleziona il controllo a infrarossi
Pan
000–255
Regolazione manuale pan (rotazione)
Tilt
000–255
Regolazione manuale brandeggio
Regolazione manuale velocità
rotazione/brandeggio
Color
000–255
Regolazione manuale colori
Rotate
000–255
Regolazione manuale rotazione
Zoom
000–255
Regolazione manuale zoom
Dimmer
000–255
Regolazione manuale dimmer
Pan
000–255
Regolazione manuale otturatore
OFF
Funzionamento in rotazione normale
ON
Funzionamento in rotazione inversa
OFF
Funzionamento in brandeggio normale
ON
Funzionamento in brandeggio inverso
540
Seleziona l'angolo di rotazione 540°
360
Seleziona l'angolo di rotazione 360°
180
Seleziona l'angolo di rotazione 180°
270
Seleziona l'angolo di brandeggio di 270°
180
Seleziona l'angolo di brandeggio di 180°
90
Seleziona l'angolo di brandeggio di 90°
OFF
Modalità normale
UP
Modalit à Totem bas e v erso l'alto
DOWN
Modalit à Totem bas e v erso il bass o
Normal
Fast
Slow
Seleziona la velocità della ventola in base alla
temperatura
Full
Velocità massima della ventola
Disattivazione retroilluminazione del display
dopo inattività
ON
Retroilluminazione del display attiva
OFF
Visualizzazione normale
ON
Visualizzazione inversa
Square
I Squa
SCurve
Linear
Opzioni del menù
Funzioni principali Livelli di programmazione Descrizione
Run Mode
DMX
P/T Speed 000–255
Manual
Pan Reverse
Tilt Reverse
Pan Angle
Tilt Angle
Totem Mode
Seleziona la modalità DMX
Setup
P/T Speed
Fans
Display
Screen Rev
Dimmer Curve
Seleziona la velocità di rotazione/brandeggio
Auto
OFF
Seleziona la modalità curva dimmer
58
Intimidator Trio GR IT
Fast
Smooth
RED
GREEN
BLUE
WHITE
Sensitivity
001–100
Imposta la sensibilità sonora
Reset
Reimposta l'unità
Factory Set
Carica le impostazioni standard
Ver V_
Visualizza la versione del software
Visualizza la modalità di funzionamento
corrente
DMX Address _ _ _
Visualizza l'indirizzo DMX corrente
Temperature _ _ _
Visualizza la temperatura LED in gradi Celsius
Collegamento
Intimidator Trio può funzionare con un controller DMX quando collegato
tramite connessioni seriali DMX. Le istruzioni per il collegamento e la
configurazione di questa unità sono contenute nel Manuale Utente. Se non si
DMX Primer all'indirizzo
Indirizzo iniziale
Per assicurare il co mpleto accesso a tutt i i can ali in ciascu n a modali tà DM X,
Collegamento
Master/Slave
In modalità Master/Slave, Intimidator Trio utilizza il collegamento dati
DMX. Le istruzioni per il collegamento e la configurazione di questa unità
Funzioni principali Livelli di programmazione Descrizione
Dimmer Speed
Setup
(cont.)
Sys Info
Color Balance
Running Mode _ _ _ _ _
DMX
ha familiarità con il DMX, scaricare
www.chauvetlighting.com.
l'indirizzo maggiorment e r accomandato è 483.
per il funzionamento M aster/Slave sono contenute nel Manuale Utent
Seleziona la velocità dimmer
Seleziona il bilanciamento colore (da 100 a
255)
59
Intimidator Trio GR IT
30CH
1
Rotazione
000 ó 255
da 0 a 540°
2
Rotazione fine
000 ó 255
Controllo fine della rotazione
3
Brandeggio
000 ó 255
da 0 a 270°
4
Brandeggio fine
000 ó 255
Controllo fine del brandeggio
Velocità rotazione/brandeggio (da rapida a
lenta)
6
Rosso
000 ó 255
da 0 a 100%
7
Verde
000 ó 255
da 0 a 100%
8
Blu
000 ó 255
da 0 a 100%
9
Bianco
000 ó 255
da 0 a 100%
10
Rosso
000 ó 255
da 0 a 100%
11
Verde
000 ó 255
da 0 a 100%
12
Blu
000 ó 255
da 0 a 100%
13
Bianco
000 ó 255
da 0 a 100%
14
Rosso
000 ó 255
da 0 a 100%
15
Verde
000 ó 255
da 0 a 100%
16
Blu
000 ó 255
da 0 a 100%
17
Bianco
000 ó 255
da 0 a 100%
18
Nessuna funzione
000 ó 255
Nessuna funzione (pre-impostato)
19
Nessuna funzione
000 ó 255
Nessuna funzione (pre-impostato)
20
Nessuna funzione
000 ó 255
Nessuna funzione (pre-impostato)
21
Nessuna funzione
000 ó 255
Nessuna funzione (pre-impostato)
Valori DMX
Canale Funzione Valore Percentuale/Impostazione
5 Velocità
Zone di controllo
Intimidator Trio
000 ó 255
Zona 1
Zona 2
Zona 3
1
3
2
2
3
1
60
Intimidator Trio GR IT
30CH
000 ó 004
Nessuna funzione
005 ó 009
Colore 1
010 ó 014
Colore 2
015 ó 019
Colore 3
020 ó 024
Colore 4
025 ó 029
Colore 5
030 ó 034
Colore 6
035 ó 039
Colore 7
040 ó 044
Colore 8
045 ó 049
Colore 9
050 ó 054
Colore 10
055 ó 059
Colore 11
060 ó 064
Colore 12
065 ó 069
Colore 13
070 ó 074
Colore 14
075 ó 079
Colore 15
080 ó 084
Colore 16
085 ó 089
Colore 17
090 ó 094
Colore 18
095 ó 099
Colore 19
100 ó 104
Colore 20
105 ó 109
Colore 21
110 ó 114
Colore 22
115 ó 119
Colore 23
120 ó 124
Colore 24
125 ó 129
Colore 25
130 ó 134
Colore 26
135 ó 139
Colore 27
140 ó 144
Colore 28
145 ó 149
Colore 29
150 ó 154
Colore 30
155 ó 159
Colore 31
160 ó 164
Colore 32
165 ó 169
Colore 33
170 ó 174
Colore 34
175 ó 179
Nessuna funzione
Cambio colore in senso orario (da veloce a
lento)
202 ó 207
Interruzione (il colore rimane quello corrente)
Cambio colore in senso antiorario
(da veloce a lento)
230 ó 234
Nessuna funzione
235 ó 249
Salto colore (da veloce a lento)
250 ó 255
Colori ad Attivazione sonora
Canale Funzione Valore Percentuale/Impostazione
(cont.)
22 Colori
180 ó 201
208 ó 229
61
Intimidator Trio GR IT
30CH
000 ó 015
Nessuna funzione
016 ó 031
Zona macro 1
032 ó 047
Zona macro 2
048 ó 063
Zona macro 3
064 ó 079
Zona macro 4
080 ó 095
Zona macro 5
096 ó 111
Zona macro 6
112 ó 127
Integr ata 7 (zona macro 1—6)
128 ó 143
Automatico 1 inte grato
144 ó 159
Automatico 2 integrato
160 ó 175
Automatico 3 inte grato
176 ó 191
Automatico 4 inte grato
192 ó 207
Automatico 5 inte grato
208 ó 223
Automatico 6 inte grato
224 ó 239
Automatico 7 inte grato
Automatico 8 inte grato (automatico integrato
1—7)
Macro di zona e veloc ità automatica inte grata
(da lenta a veloce)
25
Dimmer
000 ó 255
Da 0 a 100%
000 ó 019
Chiuso
020 ó 024
Aperto
025 ó 064
Effetto st r o b o (velocità decrescente)
065 ó 069
Aperto
070 ó 084
Veloce on, lento off (velocità decrescente)
085 ó 089
Aperto
090 ó 104
Lento on, veloce off (velocità crescente)
105 ó 109
Aperto
110 ó 124
Otturatore casuale (velocità decrescente)
125 ó 129
Aperto
Veloce ca suale on, lento off (velocità
decrescente)
145 ó 149
Aperto
Lento casuale on, veloce off (velocità
decrescente)
165 ó 169
Aperto
170 ó 184
Effett o impulso 1 (velocità decrescente)
185 ó 189
Aperto
190 ó 204
Effett o impulso 2 (velocità decrescente)
205 ó 209
Aperto
210 ó 224
Gradualmente on e of f (velocit à decresce nte)
225 ó 229
Aperto
230 ó 244
Effett o impulso 3 (velocità decrescente)
245 ó 255
Aperto
27
Zoom
000 ó 255
Zoom avanti e indietro
Canale Funzione Valore Percentuale/Impostazione
(cont.)
23 Controllo integrato
240 ó 255
24 Velocità integrata
26 Otturatore
000 ó 255
130 ó 144
150 ó 164
62
Intimidator Trio GR IT
30CH
000 ó 009
Nessuna funzione
010 ó 014
Oscuramento durante ro t a zione/brandeggio
015 ó 019
Nessuna funzione
020 ó 049
Per utilizzo futuro
050 ó 054
Reimpostazione rotazione
055 ó 059
Reimpostazione brandeggio
060 ó 064
Reimpostazione zo om
065 ó 069
Reimpostazione rotazione
070 ó 074
Reimpostazione generale
075 ó 079
Nessuna funzione
080 ó 084
Inversione rotazione / br an de ggi o
085 ó 089
Inversione rotazione
090 ó 094
Brandeggio inverso
095 ó 099
Annulla inversione rotazione
100 ó 104
Annulla brandeggio inverso
105 ó 109
Annulla inversione rotazione/brandeggio
110 ó 114
Velocità normale rotazione/brandeggio
115 ó 119
Rotazione/brandeggio veloci
120 ó 124
Rotazione/brandeggio lenti
125 ó 129
Ventola (massima velocità)
130 ó 134
Ventola (automatica)
135 ó 139
Dimmer, veloce
140 ó 144
Dimmer, morbido
145 ó 255
Nessuna funzione
000 ó 007
Nessuna funzione
008 ó 023
Macro 1 movimento autom atico
024 ó 039
Macro 2 movimento autom atico
040 ó 055
Macro 3 movimento autom atico
056 ó 071
Macro 4 movimento autom atico
072 ó 087
Macro 5 movimento autom atico
088 ó 103
Macro 6 movimento autom atico
104 ó 119
Macro 7 movimento autom atico
120 ó 135
Macro 8 movimento autom atico
136 ó 151
Macro 1 movimento ad attivazione sonora
152 ó 167
Macro 2 movimento ad attivazione sonora
168 ó 183
Macro 3 movimento ad attivazione sonora
184 ó 199
Macro 4 movimento ad attivazione sonora
200 ó 215
Macro 5 movimento ad attivazione sonora
216 ó 231
Macro 6 movimento ad attivazione sonora
232 ó 247
Macro 7 movimento ad attivazione sonora
248 ó 255
Macro 8 movimento ad attivazione sonora
000 ó 063
Chase in rotazione
Piccolo scuotimento in
rotazione (da lento a veloce)
Grande scuotimento in
rotazione (da lento a veloce)
128 ó 191
Rotazione (da lento a veloce)
Rotazione inversa (da lento a
veloce)
Canale Funzione Valore Percentuale/Impostazione
(cont.)
Funzioni di
28
controllo
Macro di
29
movimento
30 Rotazione
064 ó 095
096 ó 127
192 ó 255
63
Quando il
valore Ch-27 (Zoom) è
superiore a
150
Intimidator Trio GR IT
15-CH
1
Rotazione
000 ó 255
da 0 a 540°
2
Brandeggio
000 ó 255
da 0 a 270°
3
Velocità
000 ó 255
Rotazione/brandeggio (da veloce a lento)
4
Rosso
000 ó 255
da 0 a 100%
5
Verde
000 ó 255
da 0 a 100%
6
Blu
000 ó 255
da 0 a 100%
7
Bianco
000 ó 255
da 0 a 100%
000 ó 015
Nessuna funzione
016 ó 031
Zona macro 1
032 ó 047
Zona macro 2
048 ó 063
Zona macro 3
064 ó 079
Zona macro 4
080 ó 095
Zona macro 5
096 ó 111
Zona macro 6
112 ó 127
Integr ata 7 (zona macro 1—6)
128 ó 143
Automatico 1 inte grato
144 ó 159
Automatico 2 inte grato
160 ó 175
Automatico 3 inte grato
176 ó 191
Automatico 4 inte grato
192 ó 207
Automatico 5 inte grato
208 ó 223
Automatico 6 inte grato
224 ó 239
Automatico 7 inte grato
Automatico 8 integrato (automatico integrato
1—7)
9
Velocità integrata
000 ó 255
Zone e velocità integrata (da lenta a veloce)
10
Dimmer
000 ó 255
da 0 a 100%
Canale Funzione Valore Percentuale/Impostazione
8 Controllo integrato
240 ó 255
64
Intimidator Trio GR IT
15-CH
000 ó 019
Chiuso
020 ó 024
Aperto
025 ó 064
Effetto strobo (velocità decrescente)
065 ó 069
Aperto
070 ó 084
Veloce on, lento off (velocità decrescente)
085 ó 089
Aperto
090 ó 104
Lento on, veloce off (velocità crescente)
105 ó 109
Aperto
110 ó 124
Otturatore casuale (velocità decrescente)
125 ó 129
Aperto
Veloce ca suale on, lento off (velocità
decrescente)
145 ó 149
Aperto
Lento casuale on, veloce off (velocità
decrescente)
165 ó 169
Aperto
170 ó 184
Effett o impulso 1 (velocità decrescente)
185 ó 189
Aperto
190 ó 204
Effett o impulso 2 (velocità decrescente)
205 ó 209
Aperto
210 ó 224
Gradualmente on e of f (velocit à decresce nte)
225 ó 229
Aperto
230 ó 244
Effett o impulso 3 (velocità decrescente)
245 ó 255
Aperto
12
Zoom
000 ó 255
Zoom avanti e indietro
Canale Funzione Valore Percentuale/Impostazione
(cont.)
11 Otturatore
130 ó 144
150 ó 164
65
Intimidator Trio GR IT
15-CH
000 ó 009
Nessuna funzione
010 ó 014
Interruzione rota zione/ brandeggio
015 ó 019
Nessuna funzione
020 ó 049
Per utilizzo futuro
050 ó 054
Reimpostazione rotazione
055 ó 059
Reimpostazione brandeggio
060 ó 064
Reimpostazione zo om
065 ó 069
Nessuna funzione
070 ó 074
Reimpostazione generale
075 ó 079
Nessuna funzione
080 ó 084
Inversione rotazione / br an de ggi o
085 ó 089
Inversione rotazione
090 ó 094
Brandeggio inverso
095 ó 099
Annulla inversione rotazione
100 ó 104
Annulla brandeggio inverso
105 ó 109
Annulla inversione rotazione/brandeggio
110 ó 114
Velocità normale rotazione/brandeggio
115 ó 119
Rotazione/brandeggio veloci
120 ó 124
Rotazione/brandeggio lenti
125 ó 129
Ventola (massima velocità)
130 ó 134
Ventola (automatica)
135 ó 139
Dimmer, veloce
140 ó 144
Dimmer, morbido
145 ó 255
Nessuna funzione
000 ó 007
Nessuna funzione
008 ó 023
Macro 1 movimento autom atico
024 ó 039
Macro 2 movimento autom atico
040 ó 055
Macro 3 movimento autom atico
056 ó 071
Macro 4 movimento autom atico
072 ó 087
Macro 5 movimento autom atico
088 ó 103
Macro 6 movimento autom atico
104 ó 119
Macro 7 movimento autom atico
120 ó 135
Macro 8 movimento autom atico
136 ó 151
Macro 1 movimento ad attivazione sonora
152 ó 167
Macro 2 movimento ad attivazione sonora
168 ó 183
Macro 3 movimento ad attivazione sonora
184 ó 199
Macro 4 movimento ad attivazione sonora
200 ó 215
Macro 5 movimento ad attivazione sonora
216 ó 231
Macro 6 movimento ad attivazione sonora
232 ó 247
Macro 7 movimento ad attivazione sonora
248 ó 255
Macro 8 movimento ad attivazione sonora
000 ó 063
Chase in rotazione
Piccolo scuotimento in rotazione
(da lento a veloce)
Grande scuotimento in rotazione
(da lento a veloce)
128 ó 191
Rotazione (da lento a veloce)
192 ó 255
Rotazione inversa (d a lento a v eloce )
Canale Funzione Valore Percentuale/Impostazione
(cont.)
13
14
Funzioni di
controllo
Macro di
movimento
15 Rotazione
064 ó 095
096 ó 127
66
Quando il
valore Ch-27 (Zoom)
è superiore
a 150
Intimidator Trio BH NL
Over Deze
De Intimidator Trio Beknopte Handleiding (BH) bevat basisinformatie over
waarden. Download de
User Manual van www.chauvetlighting.com voor meer details.
Disclaimer
De informatie en specificaties in deze BH kunnen zonder voorafgaande
kennisgeving worden gewijzigd.
Veiligheidsinstructies
Deze veiligheidsinstructies bevatten belangrijke informatie over de
installatie, het gebruik en het onderhoud.
• Sluit dit product uitsluitend op een geaard en beveiligd circuit.
altijd de stekker van het pr oduct
Raak het product niet a a n wa nnee r he t in werking omdat het da n he e t zij n.
• De spanning van he t s topc ont a c t wa a r op u dit pr od uc t a a ns lui t m oe t binne n
stroomschakelaar of de stekker te ontkoppel en.
Contact
Van buiten de VS, Verenigd Koninkrijk, Ierland, of Mexico of de Benelux, kunt u
contact opnemen met de distributeur of om ondersteuning vragen dan wel het
product retourneren. Ga naar www.chauvetlighting.com voor contactinformatie.
Wat is
• Intimidator Trio
montagemateriaal
•Stroomkabel
Beknopte Handleiding
Handleiding
het product, zoals montage, menu-opties en DMX-
• Haal voor het vervangen van de zekering
uit het stopcontact.
• Kijk niet in de lichtbro n wanneer het apparaat is ingesch akel d.
• Zorg ervoor dat de stroomkabel niet gesmolten of beschadigd is.
• Ontkoppel het product nooit van het stopcontact door aan het snoer te trekken.
• Gebruik een veiligheidskabel wanneer het p roduct boven lichaamshoogte
wordt gemonteerd.
• Er mogen ge en bra ndbare mat erialen in de buurt van de unit k omen t ijdens gebru ik.
•
het vermelde bere ik op de sticker of achte rk a nt va n he t pr oduc t z ijn.
• Het product is alleen voor gebruik binnenshuis! (IP20) Om risico op
brand of elektrische schokken te voorkomen, mag dit product niet aan
regen of vocht worden blootgesteld.
• Monteer dit product altijd op een plek met voldoende ventilatie, minstens
20 inch (50 cm) van de aangrenzende oppervlakken.
• Zorg ervoor dat er geen vent ilatie-openingen van de behuizing van het
product worden geblokkeerd.
• Sluit dit product nooit aan op een dimmer of een regelweerstand.
• Vervang de zekering met een van hetzelfde type en met dezelfde waarde.
• Gebruik alleen de handvatten of de toegevoegde montageklem met de
juiste capaciteit om dit product te dragen.
• De maximale omgevingstemperatuur bedra a g t 104 °F (40 °C). Gebruik
dit product niet bij hog e r e temperaturen.
• Stop in het geval van ernstige operationele problemen onmiddellijk met het gebruik.
• Open het product niet . Het bevat geen te onderhouden onderdelen.
• Om onnodige slijtage te voorkomen en de levensduur te verengen, dient
u tijdens stilstand het product volledig loskoppelen van de stroom d.m.v.
Inbegrepen
•Ophangbeugel met
67
• Garantiekaart
•
Intimidator Trio BH NL
Om te
Pak uw Intimidator Trio uit en zorg ervoor dat u alle onderdelen in goede
onmiddellijk aan de bezorger, niet aan Chauvet.
Beschrijving
De Intimidator Trio is een veelzijdig moving head lichteffect met lichtstraal,
kleurige RGBW
toepassingen, continu draaiende honeycomb zorgt voor de opwinding
van een lichteffect. Gemakkelijke navigatie en een volledige tekst uit lezing
color LCD scherm Genereer een
gesynchroniseerde show in de Master/Slave stand met toegankelijke,
6
DMC
50 VIP Gear Bag, ook
verkrijgbaar via Chauvet.
LCD Scherm
Bedieningsknoppen
Indicatielamp
Span
Achteraanzicht
Vermogensuit
DMX Ingang
DMX Uitgang
Stroomingang
Vooraanzicht
Beginnen
staat hebt ontvangen. Als de doos of de inhoud beschadigd lijkt, meldt het
schijnwerper en verschillende effecten. Het heeft 6 vierLEDs. Gemotoriseerde zoom kan gebruikt worden voor short-throw en longthrow-
wordt getoond op een hoog-contrast, full-
ingebouwde automatische programma's. De optionele IRCafstandsbediening van Chauvet biedt makkelijke, draadloze nonbesturing. De Intimidator Trio past het best in de CHS-
Overzicht
Zekeringhouder
IR Sensor
68
Intimidator Trio BH NL
AC Power
bereik voeding die kan werken met een
Power Linking
producten die via power linking
kan worden gekoppeld bij elke spanning, zie de gebruikershandleiding of de
Zekering
1. Ontkoppel het apparaat van de stroom.
4. Breng de zekeringhouder opnieuw in en zet het apparaat weer aan.
Infrarood
Afstands
bediening 6
De Intimidator Trio is compatibel met de infrarood afstandsbediening 6
(IRC-6) van Chauvet.
Dit product heeft een autoingangsspanning van 100 tot 240 VAC, 50/60 Hz.
Voor het maximum aantal Intimidator Trio
sticker op het product.
Vervangen
(IRC-6)
2. Met behulp van een platte schroevendraaier , draai de zekeringhouder en
trek deze er recht uit.
3. Verwijder de defecte zekering en vervan g deze door een goede zekerin g
van hetzelfde type.
De volgende IRC-6 knoppen worden gebruikt met de Intimidator Trio:
• <BLACKOUT> - Schakelt LED aan/ uit
• <AUTO> - selecteert automatische programma modus (scrolling)
• <SOUND> - Selecteert Sound-Active stand
• <STROBE> - Stroboscoop (0–20 Hz)
• <SPEED> - Pan/Tilt auto programma snelheid
• <SENSITIVITY> - stelt geluidsgevoeligheid in
• <%> - LED dimmer
• <MANUAL> - Handmatige besturing
• <FADE/SNAP> - Druk eenmaal voor Fade kleurverandering/druk
tweemaal voor Snap
• <R> - rode LED handmatige besturing
• <G> - groene LED handmatige besturing
• <B> - blauwe LED handmatige besturing
• <W> - witte LED handmatige besturing
• <UV> - Zoom/draaien handmatige instelling
• <A> - Pan/Tilt handmatige instelling
• <+> - Verhoog
• <-> - Verlaag
• <0> tot <9> - Selecteer auto program per nummer
69
Intimidator Trio BH NL
Montage
Montage
Diagram
Bij het gebruik van slechts één bevestigingsklem, mo e t u een klem
gebruiken met een penschiettoestel per ong eluk losraken te voorkomen.
Montageklem
klem van Chauvet)
Bevestigingsgaten voor
/Montagebeugel
Doorgang voor de
Bevestigingsbeugel
Bevestigingsgat voor
Montageklem
Voordat u dit product monteert, lees eerst de Veiligheidsinstructies.
(werkt met CLP-15 of CLP-15N
Rubberen voetstuk (x4)
voor vloermontage
70
Veiligheidskabel
Handvat (x2)
Hang-
Veiligheidskabel
Intimidator Trio BH NL
Configuratie-
scherm
Beschrijving
<MENU>
Uitgangen van het huidige menu of functie
Navigeert omhoog via het menu of verhoogt de numerieke
waarde wanneer in een functie
Navigeert omlaag via het menu of verlaagt de numerieke
waarde wanneer in een functie
Schakelt het huidige weergegeven menu in of stelt de
functie in
Address
001–512
Stelt het DMX startadres in
15CH
30CH
Slave
Slave 1–4
Selecteert Slave modus
Auto
Selecteert Automatisch modus
Sound
Selecteert Geluidsactieve modus
IR
Selecteert infrarood besturing
Pan
000–255
Pan handmatige instelling
Tilt
000–255
Tilt handmatige instelling
P/T Speed
000–255
Pan/Tilt snelheid handmatige instelling
Color
000–255
Kleuren handmatige instelling
Rotate
000–255
Rotatie handmatige instelling
Zoom
000–255
Zoom handmatige instelling
Dimmer
000–255
Dimmer handm atige i nst elling
Pan
000–255
Sluiter handmatige instelling
OFF
Normale pan optie
ON
Terugwerkende pan optie
OFF
Normale tilt optie
ON
Terugwerkende tilt optie
540
Selecteert de 540° pan hoekbereik
360
Selecteert de 360° pan hoekbereik
180
Selecteert de 180° pan hoekbereik
270
Selecteert de 270° tilt hoekbereik
180
Selecteert de 180° tilt hoekbereik
90
Selecteert de 90° tilt hoekbereik
OFF
Normale Stand
UP
Totem Sta nd Base Up
DOWN
Totem Sta nd Base Down
Normal
Fast
Slow
Stelt de ventilator snelheid in afhankelijk van
de temperatuur
Full
Ventilator snelheid ingesteld op volle snelheid
OFF
Scherm achtergrond dooft na inactiviteit
ON
Scherm achtergrond blijft aan
Toets Functie
<UP>
<DOWN>
<ENTER>
momenteel geselecteerde waarde in de geselecteerde
Menu Opties
Hoofdfunctie Programmeerniveaus Beschrijving
DMX
Run Mode
Manual
Pan Reverse
Tilt Reverse
Pan Angle
Selecteert DMX modus
Tilt Angle
Setup
Totem Mode
P/T Speed
Fans
Auto
Display
Selecteert de pan/tilt snelheid
71
Intimidator Trio BH NL
OFF
Normaal scherm
ON
Omgekeerd scherm
Square
I Squa
SCurve
Linear
Fast
Smooth
RED
GREEN
BLUE
WHITE
Sensitivity
001–100
Stelt de geluidsgevoeligheid in
Reset
Reset het product
Factory Set
Laad de fabrieksinstellingen
Ver V_
Toont de software versie
Running Mode _ _ _ _ _
Toont de huidige actieve stand
DMX Address _ _ _
Toont huidige DMX adres
Temperature _ _ _
Toont de LED temperatuur in Celsius
DMX Linking
De Intimidator Trio kan werken met een DMX besturing wanneer het is
verbonden door DMX seriële verbindingen. Instructies voor het aansluiten
en configureren van dit product voor DMX werking staan in de
, download dan de
Startadres
modus te garanderen is
Master/Slave
dataverbinding voor haar
modus. Instructies voor het aansluiten en configureren van dit
Hoofdfunctie Programmeerniveaus Beschrijving
Screen Rev
Dimmer Curve
Setup
(vervolg)
Sys Info
Dimmer Speed
Color Balance
gebruikershandleiding. Als u niet bekend bent met DMX
DMX Primer van www.chauvetlighting.com.
Om volledige toegang tot alle kanalen in elke DMXhet hoogste aanbevolen DMX-adres voor dit product 483.
De Intimidator Trio maakt gebruik van de DMX-
Verbinding
Master-/Slaveproduct voor master/slave werking staan in de gebruikershandleiding.
Selecteert de dimmer curve stand
Selecteert de dimmer snelheid
Selecteert de kleurbalans (100 tot 255)
72
Intimidator Trio BH NL
30-CH
1
Pan
000 ó 255
0 tot 540°
2
Subtiele Pan
000 ó 255
Subtiele bediening voor pan
3
Tilt:
000 ó 255
0 tot 270°
4
Subtiele Tilt
000 ó 255
Subtiele bediening voor tilt
5
Snelheid
000 ó 255
Pan/TIlt snelheid (langzaam naar snel)
6
Rood
000 ó 255
0 naar 100%
7
Groen
000 ó 255
0 naar 100%
8
Blauw
000 ó 255
0 naar 100%
9
Wit
000 ó 255
0 naar 100%
10
Rood
000 ó 255
0 naar 100%
11
Groen
000 ó 255
0 naar 100%
12
Blauw
000 ó 255
0 naar 100%
13
Wit
000 ó 255
0 naar 100%
14
Rood
000 ó 255
0 naar 100%
15
Groen
000 ó 255
0 naar 100%
16
Blauw
000 ó 255
0 naar 100%
17
Wit
000 ó 255
0 naar 100%
18
Geen functie
000 ó 255
Geen functie (Voorinstelling)
19
Geen functie
000 ó 255
Geen functie (Voorinstelling)
20
Geen functie
000 ó 255
Geen functie (Voorinstelling)
21
Geen functie
000 ó 255
Geen functie (Voorinstelling)
2
3
3
DMX Waarden
Kanaal Functie Waarde Percentage/Instelling
Zone 1
Zone 2
Zone 3
Intimidator Trio
Bedieningszones
1
2
1
73
Intimidator Trio BH NL
30-CH
000 ó 004
Geen func tie
005 ó 009
Kleur 1
010 ó 014
Kleur 2
015 ó 019
Kleur 3
020 ó 024
Kleur 4
025 ó 029
Kleur 5
030 ó 034
Kleur 6
035 ó 039
Kleur 7
040 ó 044
Kleur 8
045 ó 049
Kleur 9
050 ó 054
Kleur 10
055 ó 059
Kleur 11
060 ó 064
Kleur 12
065 ó 069
Kleur 13
070 ó 074
Kleur 14
075 ó 079
Kleur 15
080 ó 084
Kleur 16
085 ó 089
Kleur 17
090 ó 094
Kleur 18
095 ó 099
Kleur 19
100 ó 104
Kleur 20
105 ó 109
Kleur 21
110 ó 114
Kleur 22
115 ó 119
Kleur 23
120 ó 124
Kleur 24
125 ó 129
Kleur 25
130 ó 134
Kleur 26
135 ó 139
Kleur 27
140 ó 144
Kleur 28
145 ó 149
Kleur 29
150 ó 154
Kleur 30
155 ó 159
Kleur 31
160 ó 164
Kleur 32
165 ó 169
Kleur 33
170 ó 174
Kleur 34
175 ó 179
Geen func tie
Kleurverandering met de klok mee (snel naar
langzaam)
202 ó 207
Stop (kleur blijft de huidige kleur)
Kleurverandering tegen de klok in (snel naar
langzaam)
230 ó 234
Geen func tie
235 ó 249
Kleurverspringing (snel naar langzaam)
250 ó 255
Sound-Active kl e u ren
Kanaal Functie Waarde Percentage/Instelling
(vervolg)
22 Kleuren
180 ó 201
208 ó 229
74
Intimidator Trio BH NL
30-CH
000 ó 015
Geen func tie
016 ó 031
Zone macro 1
032 ó 047
Zone macro 2
048 ó 063
Zone macro 3
064 ó 079
Zone macro 4
080 ó 095
Zone macro 5
096 ó 111
Zone macro 6
112 ó 127
Ingebouwde 7 (zone macro's 1—6))
128 ó 143
Ingebouwde Auto 1
144 ó 159
Ingebouwde Auto 2
160 ó 175
Ingebouwde Auto 3
176 ó 191
Ingebouwde Auto 4
192 ó 207
Ingebouwde Auto 5
208 ó 223
Ingebouwde Auto 6
224 ó 239
Ingebouwde Auto 7
240 ó 255
Ingebouwd 8 (Ingebouwde auto 1—7)
Ingebouwde
Snelheid
Zone macro's en ingebouwde auto snelheid
(langzaam naar snel)
25
Dimmer
000 ó 255
0 naar 100%
000 ó 019
Dicht
020 ó 024
Open
025 ó 064
Stroboscoop effect (afnemende snelheid)
065 ó 069
Open
070 ó 084
Snel aan, langzaam uit (afnemende snelheid)
085 ó 089
Open
Langzaam aan, snel uit (afnemende
snelheid)
105 ó 109
Open
110 ó 124
Willekeurige shutter (afnemende snelheid)
125 ó 129
Open
Willekeurig snel aan, langzaam uit
(afnemende snelheid)
145 ó 149
Open
Willekeurig langzaam aan, snel uit
(afnemende snelheid)
165 ó 169
Open
170 ó 184
Pulse effect 1 (afnemende snelheid)
185 ó 189
Open
190 ó 204
Pulse effect 2 (afnemende snelheid)
205 ó 209
Open
210 ó 224
Geleidelijk aan en uit (afnemende snelheid)
225 ó 229
Open
230 ó 244
Pulse effect 3 (afnemende snelheid)
245 ó 255
Open
27
Zoom
000 ó 255
Zoom in en uit
Kanaal Functie Waarde Percentage/Instelling
(vervolg)
Ingebouwde
23
bediening
24
26 Sluiter
000 ó 255
090 ó 104
130 ó 144
150 ó 164
75
Intimidator Trio BH NL
30-CH
000 ó 009
Geen functie
010 ó 014
Blackout tijdens pan/tilt
015 ó 019
Geen functie
020 ó 049
Gereserveerd voor toekomstig gebruik
050 ó 054
Herstart pan
055 ó 059
Herstart tilt
060 ó 064
Reset zoom
065 ó 069
Reset rotatie
070 ó 074
Reset alles
075 ó 079
Geen functie
080 ó 084
Omgedraaide pan/tilt
085 ó 089
Omgedraaide pan
090 ó 094
Omgedraaide tilt
095 ó 099
Annuleer de omgedraaide pan
100 ó 104
Annuleer de omgedraaide tilt
105 ó 109
Annuleer de omgedraaide pan/tilt
110 ó 114
Pan/Tilt normale snelheid
115 ó 119
Pan/Tilt snelle snelheid
120 ó 124
Pan/Tilt langzame snelheid
125 ó 129
Ventilator (volledige snelheid)
130 ó 134
Ventilator (automatisch)
135 ó 139
Dimmer, snel
140 ó 144
Dimmer, vloeiend
145 ó 255
Geen functie
000 ó 007
Geen functie
008 ó 023
Automatische bewegingsmacro 1
024 ó 039
Automatische bewegingsmacro 2
040 ó 055
Automatische bewegingsmacro 3
056 ó 071
Automatische bewegingsmacro 4
072 ó 087
Automatische bewegingsmacro 5
088 ó 103
Automatische bewegingsmacro 6
104 ó 119
Automatische bewegingsmacro 7
120 ó 135
Automatische bewegingsmacro 8
136 ó 151
Sound-Active bewegi ngs m ac ro 1
152 ó 167
Sound-Active bewegi ngs m ac ro 2
168 ó 183
Sound-Active bewegi ngsm acro 3
184 ó 199
Sound-Active bewegi ngs m ac ro 4
200 ó 215
Sound-Active bewegi ngs m ac ro 5
216 ó 231
Sound-Active bewegi ngs m ac ro 6
232 ó 247
Sound-Active bewegi ngs m ac ro 7
248 ó 255
Sound-Active bewegi ngs m ac ro 8
000 ó 063
Opvolgende Rotatie
Rotatie Kleine Schudding
(Langzaam naar Snel)
Rotatie Grote Schudding
(Langzaam naar Snel)
128 ó 191
Rotatie (langzaam naar snel)
Omgekeerde rotati e
(langzaam naar snel)
Kanaal Functie Waarde Percentage/Instelling
(vervolg)
28 Besturingsfuncties
29 Bewegingsmacro's
30 Rotatie
064 ó 095
096 ó 127
192 ó 255
76
Als Ch-27 (Zoom)
waarde boven
150 is
Intimidator Trio BH NL
15-CH
1
Pan
000 ó 255
0 tot 540°
2
Tilt:
000 ó 255
0 tot 270°
3
Snelheid
000 ó 255
Pan/Tilt (langzaam naar snel)
4
Rood
000 ó 255
0 naar 100%
5
Groen
000 ó 255
0 naar 100%
6
Blauw
000 ó 255
0 naar 100%
7
Wit
000 ó 255
0 naar 100%
000 ó 015
Geen func tie
016 ó 031
Zone macro 1
032 ó 047
Zone macro 2
048 ó 063
Zone macro 3
064 ó 079
Zone macro 4
080 ó 095
Zone macro 5
096 ó 111
Zone macro 6
112 ó 127
Ingebouwde 7 (zone macro's 1—6))
128 ó 143
Ingebouwde Auto 1
144 ó 159
Ingebouwde Auto 2
160 ó 175
Ingebouwde Auto 3
176 ó 191
Ingebouwde Auto 4
192 ó 207
Ingebouwde Auto 5
208 ó 223
Ingebouwde Auto 6
224 ó 239
Ingebouwde Auto 7
240 ó 255
Ingebouwd 8 (Ingebouwde auto 1—7)
Ingebouwde
Snelheid
Zonesen ingebouwde auto snelheid
(langzaam naar snel)
10
Dimmer
000 ó 255
0 naar 100%
Kanaal Functie Waarde Percentage/Instelling
Ingebouwde
8
bediening
9
000 ó 255
77
Intimidator Trio BH NL
15-CH
000 ó 019
Dicht
020 ó 024
Open
025 ó 064
Stroboscoop effect (afnemende snelheid)
065 ó 069
Open
070 ó 084
Snel aan, langzaam uit (afnemende snelheid)
085 ó 089
Open
Langzaam aan, snel uit (afnemende
snelheid)
105 ó 109
Open
110 ó 124
Willekeurige shutter (afnemende snelheid)
125 ó 129
Open
Willekeurig snel aan, langzaam uit
(afnemende snelheid)
145 ó 149
Open
Willekeurig langzaam aan, snel uit
(afnemende snelheid)
165 ó 169
Open
170 ó 184
Pulse effect 1 (afnemende snelheid)
185 ó 189
Open
190 ó 204
Pulse effect 2 (afnemende snelheid)
205 ó 209
Open
210 ó 224
Geleidelijk aan en uit (afnemende snelheid)
225 ó 229
Open
230 ó 244
Pulse effect 3 (afnemende snelheid)
245 ó 255
Open
12
Zoom
000 ó 255
Zoom in en uit
Kanaal Functie Waarde Percentage/Instelling
(vervolg)
090 ó 104
11 Sluiter
130 ó 144
150 ó 164
78
Intimidator Trio BH NL
15-CH
000 ó 009
Geen functie
010 ó 014
Pan/Tilt blackout
015 ó 019
Geen functie
020 ó 049
Gereserveerd voor toekomstig gebruik
050 ó 054
Herstart pan
055 ó 059
Herstart tilt
060 ó 064
Reset zoom
065 ó 069
Geen functie
070 ó 074
Reset alles
075 ó 079
Geen functie
080 ó 084
Omgedraaide Pan/Tilt
085 ó 089
Omgedraaide pan
090 ó 094
Draai tilt om
095 ó 099
Annuleer de omgedraaide pan
100 ó 104
Annuleer de omgedraaide tilt
105 ó 109
Annuleer de omgedraaide pan/tilt
110 ó 114
Pan/Tilt normale snelheid
115 ó 119
Pan/Tilt snelle snelheid
120 ó 124
Pan/Tilt langzame snelheid
125 ó 129
Ventilator (volledige snelheid)
130 ó 134
Ventilator (automatisch)
135 ó 139
Dimmer, snel
140 ó 144
Dimmer, vloeiend
145 ó 255
Geen functie
000 ó 007
Geen functie
008 ó 023
Automatische bewegingsmacro 1
024 ó 039
Automatische bewegingsmacro 2
040 ó 055
Automatische bewegingsmacro 3
056 ó 071
Automatische bewegingsmacro 4
072 ó 087
Automatische bewegingsmacro 5
088 ó 103
Automatische bewegingsmacro 6
104 ó 119
Automatische bewegingsmacro 7
120 ó 135
Automatische bewegingsmacro 8
136 ó 151
Sound-Active bewegi ngsm acro 1
152 ó 167
Sound-Active bewegi ngs m ac ro 2
168 ó 183
Sound-Active bewegi ngs m ac ro 3
184 ó 199
Sound-Active bewegi ngs m ac ro 4
200 ó 215
Sound-Active bewegi ngs m ac ro 5
216 ó 231
Sound-Active bewegi ngs m ac ro 6
232 ó 247
Sound-Active bewegi ngs m ac ro 7
248 ó 255
Sound-Active bewegi ngs m ac ro 8
000 ó 063
Opvolgende Rotatie
Rotatie Kleine Schudding
(Langzaam naar Snel)
Rotatie Grote Schudding
(Langzaam naar Snel)
128 ó 191
Rotatie (langzaam naar snel)
Omgekeerde rotati e
(langzaam naar snel)
Kanaal Functie Waarde Percentage/Instelling
(vervolg)
13 Besturingsfuncties
14 Bewegingsmacro's
15 Rotatie
064 ó 095
096 ó 127
192 ó 255
79
Als Ch-27 (Zoom)
waarde boven
150 is
Intimidator Trio QRG Multi-Language
Contact
USA WORLD HEADQUARTERS
General Information
Technical Support
www.chauvetlighting.com
EUROPE
General Information
Voice: +32 9 388 93 97
Technical Support
General Information
Fax: +44 (0)1773 511110
Technical Support
MEXICO
General Information
Voice: +52 (728) 285-5000
Technical Support
Outside the U.S., United Kingdom, Ireland, Mexico, or Benelux, contact the dealer of
website for contact details.
