Certa Ctcircsawxa User Manual
Description of Symbols
Caution
Read the operating instructions to reduce the risk of injury
Wear ear-muffs
The impact of prolonged exposure to loud noise can cause damage to
hearing.
Wear a breathing mask.
Dust is injurious to health, and will be generated when working on wood
and other materials.
Never use the device to work on any materials containing asbestos!
Wear safety goggles.
Sparks, splinters, chips and dust emitted by the device during use can
cause loss of sight.
GENERAL SAFETY INSTRUCTIONS
WARNING! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool.
1) Work area
a) Keep work area clean and well lit. Cluttered and dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence
of flammable liquids, gases or dust. Power tools create sparks which may ignite
the dust or fumes.
c) Keep Children and bystanders away while operating a power tool. Distractions
can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do
not use any adapter plugs with earthed (grounded) power tools. Unmodified
plugs and matching outlets will reduce risk of shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric shock if
your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering the power
tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
e) When using a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of electric
shock.
3) Personal safety
a)
Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inattention while operating power
tools may result in serious personal injury.
b)
Use safety equipment. Always wear eye protection. Safety equipment such as
dust mask, non-skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries
c)
Avoid accidental starting. Ensure the switch is in the off-position before
plugging in. Carrying power tools with your fingers on the switch or plugging in
power tools that have the switch in invites accidents.
d)
Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of a power tool may result in personal
injury.
e)
Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
f)
Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or long
hair can get caught in moving parts.
g)
If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of these devices
can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and safer at the rate for which it is
designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power
tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the
power tool before making any adjustments, changing accessories, or storing
power tools. Such preventative safety measures reduce the risk of starting power
tools accidentally.
d) Store idle power tools out of reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tools
operation. If damaged, have the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these
instructions and in the manner intended for the particular type of power tool,
taking into account the working conditions and the work to be performed. Use
of the power tool for operations different from those intended could result in a
hazardous situation
5) Service
Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
Contact the Kogan customer support team for information.
SPECIAL SAFETY INSTRUCTIONS
a)
DANGER: Keep hands away from cutting area and the blade. Keep your
second hand on auxiliary handle, or motor housing.
If both hands are holding
the saw, they cannot be cut by the blade.
b)
Do not reach underneath the workpiece.
The guard cannot protect you from the
blade below the workpiece.
c)
Adjust the cutting depth to the thickness of the workpiece.
Less than a full
tooth of the blade teeth should be visible below the workpiece.
d)
Never hold the piece being cut in your hands or across your leg. Secure the
workpiece to a stable platform.
It is important to support the work properly to
minimize body exposure, blade binding, or loss of control.
e)
Hold power tool by insulated gripping surfaces when performing an
operation where the cutting tool may contact hidden wiring or its own cord.
Contact with a "live" wire will also make exposed metal parts of the power tool "live"
and shock the operator.
f)
When ripping always use a rip fence or straight edge guide.
This improves the
accuracy of cut and reduces the chance of blade binding.
g)
Always use blades with correct size and shape (diamond versus round) of
arbour holes.
Blades that do not match the mounting hardware of the saw will run
eccentrically, causing loss of control.
h)
Never use damaged or incorrect blade washers or bolt.
The blade washers
and bolt were specially designed for your saw, for optimum performance and safety
of operation.
Further safety instructions
Causes and operator prevention of kickback:
-
Kickback is a sudden reaction to a pinched, bound or misaligned saw blade,
causing an uncontrolled saw to lift up and out of the workpiece toward the operator;
-
When the blade is pinched or bound tightly by the kerf (gap in a cut) closing, the
blade stalls and the motor reaction drives the unit rapidly back toward the operator;
-
If the blade becomes twisted or misaligned in the cut, the teeth at the back edge of
the blade can dig into the top surface of the wood causing the blade to climb out of
the kerf and jump back toward the operator.
Kickback is the result of saw misuse and/or incorrect operating procedures or
conditions and can be avoided by taking proper precautions as given below.
a)
Maintain a firm grip with both hands on the saw and position your arms to
resist kickback forces. Position your body to either side of the blade, but not
in line with the blade.
Kickback could cause the saw to jump backwards, but
kickback forces can be controlled by the operator, if proper precautions are taken.
b)
When blade is binding, or when interrupting a cut for any reason, release the
trigger and hold the saw motionless in the material until the blade comes to
a complete stop. Never attempt to remove the saw from the work or pull the
saw backward while the blade is in motion or kickback may occur.
Investigate
and take corrective actions to eliminate the cause of blade binding.
c)
When restarting a saw in the workpiece, centre the saw blade in the kerf and
check that saw teeth are not engaged into the material.
If saw blade is binding,
it may walk up or kickback from the workpiece as the saw is restarted.
d)
Support large panels to minimise the risk of blade pinching and kickback.
Large panels tend to sag under their own weight. Supports must be placed under
the panel on both sides, near the line of cut and near the edge of the panel.
e)
Do not use dull or damaged blades.
Unsharpened or improperly set blades
produce a narrow kerf, causing excessive friction, blade binding and kickback.
f)
Blade depth and bevel adjusting locking levers must be tight and secure
before making cut.
If blade adjustment shifts while cutting, it may cause binding
and kickback.
g)
Use extra caution when making a "plunge cut" into existing walls or other
blind areas.
The protruding blade may cut objects that can cause kickback.
