Celestron TrailSeeker User Manual [de]

BINOCULARS | JUMELLE

BINOCULARES | FERNGLAS

BINOCOLI

ENGLISH .................................2

FRANÇAIS ..............................11

ESPAÑOL ................................21

DEUTSCH ................................31

ITALIANO ................................41

ENGLISH

BINOCULARS

CELEStRON® tRAILSEEkER BINOCUL ARS

Thank you for purchasing a Celestron TrailSeeker binocular. We trust this binocular will provide you
with years of enjoyment and faithful service. Please read the instructions carefully before using your
binocular to ensure proper use and care.

Eyepiece

Rainguard

Objective

Lens Caps

WARN ING: Never look at the sun while using your binocular.

Looking at the sun can cause permanent eye damage.

2 I ENGLISH

Eyecup

Diopter

Adjustment Ring

Objective

Lens

Focus
Wheel

Fig 1

Tripod Adapter Threads - (under cap)

AdJUStING thE INtERpUpILLARy dIStANCE

The interpupillary distance, or the distance
between the pupils, varies from person to
person. The binocular must be correctly aligned
(adjusted) to the distance between your pupils
to achieve a single, clear image. To adjust
this distance, lift the binocular up to your eyes
(using both hands) and look through them
at an object in the distance. Move the two
barrels (halves) of the binocular closer together
or further apart until you see a single, clear
image (Fig. 2). Check that the interpupillary
distance is set correctly every time you use your
binocular.

Fig 2

ENGLISH I 3

SEttING thE dIOptER / FOCUSING

To ensure a crisp, sharp image the focusing
system of the binocular must be set to
compensate for any differences in your eyesight.
This is achieved by setting the diopter (located
on the right eyepiece) before use. To set the
binocular to your eyesight follow the instructions
below.

1. View an object in the distance through the
binocular.

2. Cover the right objective lens with your hand
or the objective lens cap.

3. Rotate the focus wheel until the image
viewed with your left eye is clear and sharp.

4. Cover the left objective lens with your hand
or objective lens cap.

5. Viewing the same object, adjust the diopter

ring until the image viewed with your right
eye is clear and sharp.

4 I ENGLISH

6. Your binocular is now adjusted to your eyes
and focusing on any object can now be
achieved by simply turning the focus wheel.

TIp: Eyeglasses worn for nearsightedness should be worn when using

binoculars as you may not be able to obtain focus at infinity without
them.

Diopter

Adjustment Ring

Focus
Wheel

Fig 3

EyECUp AdJUStMENt

The TrailSeeker features twist-up eyecups to
accommodate both eyeglass and non-eyeglass
wearers. If you do not wear eyeglasses, twist
the eyecups counterclockwise until they reach
the up position. If you wear eyeglasses, make
sure that the eyecups are in the down position
to obtain the maximum field of view. The
eyecups can be set at positions between fully
up and down which may suit some users better.

Fig 4

ENGLISH I 5

tRIpOd AdAptABILIty

The TrailSeeker binoculars feature built-in
threads that allow the binocular to be attached
to a tripod using a binocular tripod adapter.
These threads can be accessed by unscrewing
the logo plate found on the front of the hinge
(Fig. 5). To attach the binocular to a tripod,
thread the adapter into the binocular and attach
the other end of the adapter to a photographic
tripod. Mounting the binocular on a tripod
allows for added stability and comfort during
prolonged viewing.

WAtERpROOF / FOGpROOF

The TrailSeeker series binoculars are waterproof and filled with dry nitrogen gas to prevent the
housing from fogging internally.

6 I ENGLISH

Fig 5

CARE ANd StORAGE

Your Celestron binocular will provide you years of dependable service if it is cared for and
stored properly.

1. Protect the binocular from impact and do not
force any of the moving parts beyond their
limits.

2. Protect the optics of your binocular by
putting on all lens caps when not in use.

3. Store your binocular in a cool, dry place
whenever possible.

5. Do not leave the binocular in a car on a hot/
sunny day or near anything that generates
heat as this may cause damage.

6. Clean any dust, dirt or water that may get
on the binocular or inside moving parts as
soon as possible to prevent any unforeseen
damage.

4. When storing for an extended period of time,
place the binocular in a plastic bag or airtight
container with a desiccant.

ENGLISH I 7

CLEANING

Proper cleaning of the lenses is essential
to maintaining the optical integrity of your
binocular. Dirty lenses diminish the amount of
light transmitted through the binocular and your
overall viewing experience.

1. Remove any dust on the lenses with a soft
lens brush or can of pressurized air.

2. Remove any fingerprints, stains or smudges
from the lens surface with a soft, clean lens

SERvICE ANd REpAIR

If warranty problems arise or repairs are
necessary, contact the Celestron customer
service department if you live in the United
States or Canada. If you live outside of

8 I ENGLISH

cloth or lens tissue by rubbing in a circular
motion. Start in the middle of the lens and
work your way to the edges. Breathe lightly
on the lens to provide moisture if needed.

3. For a more thorough cleaning we recommend
the use of a lens/optics cleaning kit available
at most photo or optical shops. Follow the
directions supplied with the cleaning kit for
best results.

these countries, please contact the dealer
you purchased your binocular from or the
Celestron distributor in your country. A list of
our distributors can be found on our website.

WARR ANty

Your binocular is covered under the Celestron
Limited Lifetime Warranty. Celestron warrants
these binoculars to be free from defects in
materials and workmanship for the binocular’s
usable lifetime to the original owner. Celestron
will repair or replace the binoculars which, upon
inspection by Celestron, are found to be defective
in materials or workmanship and within the
definitions of the limits described below.

This warranty does not cover products that
have been subject to abuse, misuse, physically
damaged, altered, or had unauthorized repairs
or modifications. This warranty does not cover
defects due to normal wear and tear and other
conditions.

This warranty is valid to U.S.A. and Canadian
customers who have purchased their binocular
from an authorized Celestron dealer in the U.S.A.
or Canada. For products purchased outside

of the U.S.A. or Canada please contact your
local Celestron Distributor or authorized Dealer
for applicable warranty information. Additional
warranty information and eligibility details can be
found on the Celestron website.

This product is designed and intended for use by those 14 years of age and older.

Product design and specifications are subject to change without prior notification.

For complete specifications and product
information, visit: www.celestron.com

2835 Columbia Street • Torrance, CA 90503 U.S.A
Tel: [phone]

ENGLISH I 9

FRANCAIS

JUMELLE

JUMELLES tRAILSEEkER dE CELEStRON

Nous vous remercions d’avoir acheté les jumelles TrailSeeker de Celestron. Nous espérons que
cette paire de jumelles vous donnera des années de plaisir et de loyaux services. Veuillez lire
attentivement les instructions avant d’utiliser vos jumelles pour vous assurer d’une utilisation
appropriée.

Protection

contre la pluie

Objectif lentille

capuchon

Œilleton

Bague de réglage

dioptrique

Oculaire

Molette de
focalisation

AVERTISSEMENT: Ne jamais regarder le soleil pendant l’utilisation

de vos jumelles. Regarder vers le soleil peut
causer des lésions oculaires permanentes.

12 I FRANÇAIS

Adaptateur de trépied filetage

Objectif

Fig 1

RÉGLAGE dE L’ÉCARt INtERpUpILLAIRE

L’écart interpupillaire, ou la distance entre les
pupilles, varie d’une personne à l’autre. Les
jumelles doivent être correctement alignées
(ajusté) à la distance entre vos pupilles afin
de créer une seule image claire. Pour régler
cette distance, soulevez les jumelles jusqu’à vos
yeux (en utilisant les deux mains) et regardez à
travers eux un objet distant. Déplacez les deux
barillets (moitiés) des jumelles le plus près
possible ou éloigné jusqu’à ce que vous voyiez
une seule image claire (Fig. 2). Vérifiez que
l’écart interpupillaire soit défini correctement
chaque fois que vous utilisez vos jumelles.

Fig 2

FRANÇA IS I 13

RÉGLAGE dU dIOptRE/FOCALISAtION

Afin d’assurer une image nette, le système de
focalisation de jumelles doit être réglé pour
compenser les différences éventuelles de votre
vision. Ceci est réalisé en réglant le dioptre
(situé sur l’oculaire droit) avant utilisation. Pour
régler les jumelles à votre vision, suivez les
instructions ci-dessous.

1. Visualisez un objet distant à travers les
jumelles.

2. Couvrez la lentille droite avec votre main ou
le capuchon d’objectif.

3. Tournez la molette de focalisation jusqu’à ce
que l’image avec votre œil gauche soit claire
et nette.

4. Couvrez la lentille gauche avec votre main ou
le capuchon d’objectif.

5. Visualisez le même objet, ajustez la bague de
réglage dioptrique

14 I FRANÇAIS

jusqu’à ce que l’image avec votre œil droit soit
claire et nette.

6. Les jumelles sont maintenant réglé pour vos
yeux et la focalisation de n’importe quel objet
peut maintenant être obtenue en tournant
simplement la molette de focalisation.

ASTucE: Les lunettes de vision pour la myopie devraient être portées lors

de l’utilisation de jumelles puisque vous ne pourrez peut-être
pas être en mesure d’obtenir la mise au point à l’infini sans
celles-ci.

Bague de réglage

dioptrique

Molette de
focalisation

Fig 3
