Cecilware HC600 User Manual

Cecilware Corporation 43-05 20th. Avenue, LIC NY 11105

Tel: [phone]

/ 718.932.1414 • Fax: [phone]

®

Since 1911

®

Since 1911

www.cecilware.com

NR32A (00/07)

Espresso Grinder

Instruction Manual

Model: HC-600

2

Contents

1) Preface Pg. 3

2) Technical Specications Pg. 3

3) General Description Pg. 3

4) Unpacking and installation Pg. 4

5) Operation Pg. 4

6) Safety devices Pg. 5

7) Safety instructions Pg. 6

8) Maintenance and service Pg. 6

9) Cleaning Pg. 6

10) Schematic Pg. 7

10) Parts List Pg. 8

3

1) Preface

Congratulations for purchasing the HC-600 grinder-doser. The HC-600 is a commercial appliance to be used in
coffee shops, espresso bars, hotels, restaurants, etc. The HC-600 will grind whole been coffee into variable, user
selectable (from super ne to course) coffee powder and will dose it to your espresso machine's Porta-Filter. Read
this manual from cover to cover before using the appliance as it contains important instructions for the safety,
operation, and maintenance of the appliance. Keep the manual in a safe place for future use and reference. The
manufacturer reserves the right to modify the appliance and the manual accordingly.

2) Technical Specifications HC-600:

Dimensions:

Height: 22"
Width: 8.5"
Length: 13"
Weight: 30 lbs
Stainless Steel Burrs Diameter: 64mm
Hopper capacity: 3 lbs. of beans
Timer: 5 min

Electrical Specications:

USA 110V/60Hz
Power: 350w @1600RPM
Duty Cycle: 50%

Materials

Metallic: Aluminum alloy cast.
Stainless steel screws and metal-sheet.
Brass alloy cast
Steel Blades
Non metallic: ABS, PC, PP

3) General Description

Bean Hopper Lid

Bean Hopper

Hopper Safety Screw

Grinding Dial

Grinder Body

Doser Handle

Indication Lamp

Main Switch / Timer

Bean Hopper Door

Doser Lid

Coffee Outlet Guard

Dosing Adjusting Screw

Dosing Feeding Mechanism

Coffee Press

Porta Handle Support

Residue Tray
