Cecilware H50NL User Manual

CAUTION: Read these instructions before operating the dispenser.
This dispenser is designed for commercial use only. Personnel
operating the warmer should be thoroughly familiar with the
dispenser before using it.

ADD ONE QUART OF WATER BEFORE TURNING ON WARMER.

Each unit has been thoroughly tested in our plant to insure proper operation before it reaches
our Customers.

The pump is adjusted to dispense 1 oz. of condiment per stroke. (See instructio n sheet on
"How to Adjust".)
THE WARMER IS DESIGNED FOR USE WITH A #10 CAN ONLY.
Check water level frequently, as water evaporates when heated. Be sure cheese or fudge is
sufficiently heated before pumping.

PUMP MODELS:

• Loosen the two knurled screws and turn latches 90.

• Remove pump from well area.

ALL MODELS:

• Fill the well area up to the water line:

• Open #10 can and peel off label.

• Place the #10 can into the well on top of metal spring or spacer provided.

• Plug in the warmer, turn toggle switch to the "ON" position which starts thermostat and light.

• Pre-heat cheese or fudge approximately 45 minutes with setting between 7 and 10, stirring
every 10 minutes, before inserting pump or ladle. Reset to 3 when ready.

WARRANTY
Every Cecilware product has been carefully inspected before shipment. The finest of materials and the highest standards

of workmanship have been built in to the equipment.
Within 1 year of purchase, should any Cecilware product show defect in factory workmanship or material, we agree to
repair, at our option or replace without cost to user such parts which prove upon factory inspection to have been so
defective. All equipment must be shipped transportation charges prepaid for acceptance. This warranty covers
replacement parts only, labor charges are cove red for 90 days after installation.

This warranty does not apply under the following conditions: Neglect or abuse of equipment.

Excessive lime condition Improper installation
Any outside modification to equipment

Every Cecilware urn body is covered for three years. This warranty covers stainless steel bodies and stainless steel liners.
Portable equipment such as Electric Fryers, Food Warmers, Electric Stoves, Dispensers, Plug-In Urns, Coffee Brewers and
Warmers must be returned to the factory of manufa cture or brought to an authorized service station for repair.

No other warranty, written or verbal, other than the foregoing is authorized. This warranty is voided if repairs are not
done at an authorized service station.

CECILWARE HOT NACHO CHEESE/ FUDGE

DISPENSERS

MODELS: H-50NP, H-50NHS, H-50NL

INSTALLATION AND OPERATING INSTRUCTIONS

PUMP MODELS

• Insert pump. (Be sure that the spout is cradled on the spout warmer, if Heated Spout Model.)

• Hold pump lever in "DOWN" position for approximately 40 seconds to "PRIME".

• Return latches to "LOCK" position and tighten knurled screws.

• WARNING: Thermostat does not turn heat completely off. Turn off toggle switch in back of unit
to turn off sign as well as thermostat.

THERMOSTAT CONTROL
Your Cecilware Hot Dispenser utilizes a thermostat heat control.
The Temperature should be set from #3 to #5. The normal working temperature should be
approximately 145ºF

To increase temperature, turn knob to the right.
To decrease temperature, turn knob to the left.
Do not leave temperature on high heat for long periods. This could cause the Nacho Cheese or
Fudge to overcook.

MODEL H-33 (PUMP)

ADJUSTMENT FOR PORTION CONTROL

1. Remove lever thumb screw (#2) and lift up handle.

2. To decrease amount dispensed, turn fulcrum (#3) clockwise. To increase, turn counter-cl ockwise.

3. Lines on lower shield (#4) are for reference only.

4. Return handles to slot in fulcrum. Be sure screw (#2) is put back through non-threaded hole first.

CLEANING INSTRUCTIONS

Disassemble pump daily and clean all parts with hot, soapy water as follows:

1. Remove cup lock spring (#6), turn and pull cup (#10) down.

2. Remove Ball (#7) out of delivery tube.

3. Wash all parts thoroughly in hot, soapy water and rinse. Re-assemble pump. Dispense h ot, clean water
through pump.

4. Use brush to clean inside of delivery tube.
