CDA SC309 User Manual

SC309 Gas Oven

Manual for Installation, Use and Maintenance

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY

T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu

BEFORE USE

Please ensure that all packing has been removed from the appliance before switching on.

Dear Customer Thank you for choosing one of our appliances, carefully designed and built by

our specialist staff and thoroughly tested to satisfy your cooking requirements. We suggest that you read this Instruction Booklet so that you will understand

fully how to operate your appliance. Please keep the booklet handy. You may wish to refer to it at a later date.

CDA

The marking confirms that the appliance conforms to the following EU directives:

- safety requirements of EEC Directive “Gas” 90/396;

- safety requirements of EEC Directive “Low voltage” 2006/95/EC;

- protection requirements of EEC Directive “EMC” 89/336;

- requirements of EEC Directive 93/68.

INSTALLATION

The oven must be installed in accordance with the installation instructions contained in this booklet. Connection to the electricity supply must be made by a competent electrician.

Warning this appliance must be earthed.

Electrical supply to your oven

IMPORTANT: Installation must be carried out according to the manufacturer's instructions. Incorrect installation may cause harm and damage to people, animals or property, for which the manufacturer accepts no responsibility. Before carrying out any work on the electrical section of the appliance, it must be disconnected from the mains. Connection to a good earth wiring system is absolutely essential. The manufacturer accepts no responsibility for any inconvenience caused by failure to comply with this rule.

DETAILS

✓

Connection to the electric power supply must be carried out by a qualified technician and following the appropriate safety regulations.

✓

Before carrying out the connection to the power supply, the voltage rating of the appliance (stamped on the appliance identification plate) must be checked for correspondence to the available mains supply voltage, and the mains electric wiring should be capable of handling the appliance’s power rating (also indicated on the identification plate).

Figure 1

Green & Yellow

Earth

3 amp fuse

Blue Neutral Brown Live

✓

CONNECTION BY A THREE PIN SOCKET (Fig. 1)

➜ The appliance must be connected to a 220-240 volts 50 cycle AC supply by means

of a three pin socket, suitably earthed and should be protected by a 3 amp fuse.

➜ If the mains plug is unsuitable for the socket outlet in your home or is removed for

any other reason, then the cut off plug should be disposed of safely to prevent the hazard of electric shock.

➜ There is a danger of electric shock if the cut off plug is inserted into any 13 amp

socket outlet.

✓

CONNECTION USING FIXED WIRING (Fig. 2)

➜ It is possible to connect the appliance directly to the mains supply by means of a

heavy duty switch with 3 mm minimum distance between the contacts.

➜ A double pole switch must be provided no further than 2 metres from the appli-

ance to the electrical supply. All supply current and earth conductors must be able to withstand an ambient temperature of 75°C.

➜ The appliance must be protected by a 3 amp fuse.

Figure 2

DOUBLE POLE SWITCHED

FUSED SPUR OUTLET

FUSE

✓

The power supply cord must not touch against any hot surfaces and must be placed so that its temperature does not exceed 75°C at any point along its length.

✓

After having installed the appliance, the power switch or power plug must always be in a accessible position.

✓

The appliance must have its own supply; any other appliances installed near it must be supplied separately.

✓

N.B. For connections to the mains power supply, never use adaptors, reductions or multiple power points as these may overheat and catch fire.

✓

In the event that installation should require modifications to the mains supply wiring system or if the power plug is not suitable for the type of power point available, it is recommended that a qualified technician be called to carry out substitution. The technician will also have to verify that the cross-section of the electric cables on the power point match the appliance’s power rating.

✓

If the supply cord is damaged, it must be replaced by a special cord by a qualified electrical technician in order to avoid a hazard.

GENERAL NOTES

✓ The wires in the mains lead on this appliance are coloured in accordance with the

following code:

Green and Yellow - Earth Blue – Neutral Brown – Live

✓ As the colours may not correspond with the markings identifying the terminals in

your plug or in your spur box, proceed as follows:

➜ The green and yellow wire must be connected to the terminal which is marked

with the letter E or with the earth symbol or coloured green and yellow.

➜ The blue wire must be connected to the terminal marked N or coloured black. ➜ The brown wire must be connected to the terminal marked L or coloured red.

FEEDER SPECIAL CABLE SECTION Type “HO5RR-F”

230 VAC 50 Hz 3 x 0,75 mm

✓ The supply cable must be replaced with a cable of

the same type.

✓ The electrical cable must be connected to the

terminal board following the diagrams of Fig. 3.

Figure 3

230 V

L1 N(L2)

Gas supply requirements

IMPORTANT NOTE

This appliance is supplied for use on NATURAL GAS or LPG (check the gas regulation label attached on the appliance). 4Appliances supplied for use on NATURAL GAS: they are adjusted for this gas only and

cannot be used on any other gas (LPG) without modification. The appliances are manufactured for conversion to LPG.

4Appliances supplied for use on LPG: they are adjusted for this gas only and cannot be used

on any other gas (NATURAL GAS) without modification. The appliances are manufactured for conversion to NATURAL GAS.

If the NATURAL GAS/LPG conversion kit is not supplied with the appliance this kit can be purchased by contacting the After-Sales Service.

INSTALLATION & SERVICE REGULATIONS (UNITED KINGDOM)

It is a legal requirement that all gas appliances are Installed & Serviced by a competent person in accordance with the current editions of the following Standards & Regulations or those regulations appropriate to the geographical region in which they are to be installed:

= Gas Safety (Installation & Use) Regulations = Building Regulations = British Standards = Regulations for Electrical Installation

Installation and service of any gas product must be made by a suitably qualified person competent on the type of product being installed or serviced and holding a valid certificate of competence for the work being carried out. Currently the proof of competence is the Accredited Certification Scheme (ACS) or S/NVQ that has been aligned to the ACS.

It is also a requirement that all businesses or self employed installers are members of a class of person approved by the Health and Safety Executive. Currently the only body with such approval is CORGI.

Failure to install the appliance correctly could invalidate any manufacturers warranty and lead to prosecution under the above quoted regulation.

GAS CONNECTION

The installation of the gas appliance to Natural Gas or LP Gas must be carried out by a C.O.R.G.I. registered installer. Installers shall take due account of the provisions of the relevant British Standards Code of Practice, the Gas Safety Regulations and the Building Standards (Scotland)(Consolidation) Regulations issued by the Scottish Development Department.

INSTALLATION TO NATURAL GAS

Installation to Natural Gas must conform to the Code of Practice, etc. The supply pressure for Natural Gas is 20 mbar.

The installation must conform to the relevant British Standards.

INSTALLATION TO LP GAS

When operating on Butane gas a supply pressure of 28-30 mbar is required. When using Propane gas a supply pressure of 37 mbar is required. The installation must conform to the relevant British Standards.

CDA are not legally able to provide any assistance in the installation of gas appliances except to Corgi registered installers. Any Corgi registered fitter requiring help must provide name, address and registration number. Information supplied will be validated before help is provided.

Warning: Only a C.O.R.G.I. registered installer, also with technical knowledge of electricity

should install the appliance. He should observe the Regulations and Codes of Practice governing such installation of gas appliances. Note: It is recommended that the gas connection to the appliance is installed with a flexible connecting tube made to BS5386.

Notes:

Flexible hoses can be used where the sited ambient temperature of the hose does not exceed 70°C. These hoses must be manufactured in accordance with BS669 part 1 and be of the correct construction for the type of gas being used.

Gas hoses designed for natural gas MUST NOT be used for supplying LPG gas (LPG gas hoses can be identified by a either a red band or stripe on the rubber outer coating of the hose).

The hose should not be crushed or trapped or be in contact with sharp or abrasive edges.

If installation is to be carried out using a flexible connector (to BS669), then the following points must be adhered to:

Note: The gas installation pipes and the final connection to the appliance connecting pipe shall be sufficient size to maintain the heat output of the appliance as specified under installation.

1. The appliance flexible connector should not be subject to undue forces, either in normal use whilst being connected or disconnected.

2. The appliance flexible connector should not be subject to excessive heat by direct exposure to flue products or by contact with hot surfaces.

3. The socket into which the plug of the appliance flexible connector fits should be permanently attached to a firmly fixed gas installation pipe and positioned such that the hose hangs freely downwards.

4. The appliance flexible connector should be positioned such that it will not suffer mechanical damage; eg abrasion from the surrounding kitchen furniture which may be moved in use, such as a door or drawer, or by being trapped by a stability device.

5. The plug-in connector should be accessible for disconnection after moving the appliance.

6. Using a suitable leak detection fluid solution (e.g. Rocol) check each

gas connection one at a time by brushing the solution over the

connection. The presence of bubbles will indicate a leak. If there is a leak, tighten the fitting and then recheck for leaks.

IMPORTANT! Do not use a naked flame to test for leaks.

The oven is designed to fit into a cabinet of 600 mm width. The oven can be built in or built under the kitchen units, but you must ensure that it is properly ventilated.

In the diagram the built in oven is ventilated by means of a space at the top of the kitchen cabinet. There are many other methods of ventilating your oven. Consult a qualified engineer for advice.

IMPORTANT: If the oven is being installed into a built under oven housing unit ensure that the front rail at the top of the unit is not installed as it will restrict ventilation.

Ventilation

The appliance should be installed into a room or space with an air supply in accordance with

BS 5440-2: 2000. For rooms with a volume of less than 5 m - permanent ventilation of 100 cm free area will be required. For rooms with a volume of between 5 m and 10 m a permanent ventilation of 50 cm free area will be required unless the room has a door which opens directly to the outside air in which case no permanent ventilation is required. For rooms with a volume greater than 10 m - no permanent ventilation is required.

NB. Regardless of room size, all rooms containing the appliance must have direct access to the outside air via an openable window or equivalent.

Where there are other fuel burning appliances in the same room, BS 5440-2: 2000 should be consulted to determine the correct amount of free area ventilation requirements.

The above requirements allow also for use of a gas oven and grill but if there are other gas burning appliances in the same room, consult a qualified engineer.

3 2

3 3 2

Location

The appliance may be installed in a kitchen, Kitchen/diner or a bed sitting room, but not in a room or space containing a bath or a shower. The appliance must not be installed in a bed-sitting room of less than 20 m . The appliance is designed and approved for domestic use only and should not be installed in a commercial, semi commercial or communal environment. Your product will not be guaranteed if installed in any of the above environments and could affect any third party or public liability insurances you may have.

How to install your oven

Ensure that air can flow freely around the housing area. If the oven is being installed into a fully enclosed built under oven housing unit it may be necessary to cut a small slot in the top of the plinth fitted under the unit. Cut a section 400 mm wide and a minimum of 15 mm high to allow air to pass under the unit.

Failure to allow adequate ventilation to the appliance may result in over heating or damage to adjacent units.

560

591

594

540

555

min.

550

560

585

Figure 4

Lift the oven carefully into position on the shelf, taking care NOT to lift it by the door handle. If you lower the oven door, you will see 4 screw holes, 2 on each side of the oven. The oven should then be secured to the housing by fitting screws into these holes. Remember the housing should not be free standing but secured to the wall and/or adjacent fittings.
