GUÍA DEL

USUARIO

5U000524C0A REV.00

USER GUIDE

User Guide

CHAPTER 1. BEFORE USING

BEFORE USING ...............................................................................................7

INSIDE THE PACKAGE ................................................................................................8

HANDSET DESCRIPTIONS .........................................................................................9

DISPLAY INDICATORS ............................................................................................ 12

FEATURE OVERVIEW ............................................................................................. 20

INSTALLING THE SIM CARD AND BATTERY ........................................................... 21

REMOVING THE BATTERY ......................................................................................24

CHARGING THE BATTERY.......................................................................................25

BATTERY HANDLING INFORMATION ..................................................................... 26

USING A MEMORY CARD ....................................................................................................28

CONNECTING TO THE HEADSET JACK ................................................................................. 29

CHAPTER 2. BASIC OPERATION

BASIC OPERATION ........................................................................................31

TURNING THE PHONE ON AND OFF....................................................................... 32

MENU ACCESS ....................................................................................................... 32

MENU SUMMARY.................................................................................................. 33

MAKING A CALL..................................................................................................... 40

ABOUT PUSH TO TALK ........................................................................................... 40

TURNING PTT ON/OF .............................................................................................41

USING A PUSH TO TALK (PTT) ALERT .................................................................... 41

USING A PUSH TO TALK (PTT) BARGE ...................................................................42

ANSWERING CALLS ............................................................................................... 43

ANSWERING PTT CALLS ........................................................................................43

ENDING A CALL ..................................................................................................... 44

MISSED CALL NOTIFICATION .................................................................................44

WAIT/PAUSE .......................................................................................................... 44

MAKING AN INTERNATIONAL CALL ......................................................................45

3 WAY CALLING .....................................................................................................45

CALL WAITING .......................................................................................................46

VOLUME QUICK ADJUSTMENT .............................................................................. 46

CALLER ID .............................................................................................................. 46

VIBRATE MODE ......................................................................................................47

MUTE FUNCTION ................................................................................................... 47

SPEAKERPHONE .................................................................................................... 47

FLASHLIGHT ..........................................................................................................47

VOICE DICTATION ................................................................................................... 48

TEXT TO SPEECH .................................................................................................... 48

AVAILABLE OPTIONS DURING A CALL ................................................................... 49

MAKING AN EMERGENCY CALL ............................................................................50

MOTION DETECTION .............................................................................................. 50

CHAPTER 3. MEMORY FUNCTION

MEMORY FUNCTION .....................................................................................53

STORING A PHONE NUMBER .................................................................................54

TEXT INPUT ............................................................................................................ 60

USING THE TEXT INPUT MODE .............................................................................. 61

ONE, TWO, THREE DIGIT SPEED DIALING .............................................................. 63

CHAPTER 4. MENU FUNCTION

MENU FUNCTION..........................................................................................67

CONTACTS .............................................................................................................. 68

MESSAGING ........................................................................................................... 76

RECENT CALLS ....................................................................................................... 88

MEDIA CENTER ......................................................................................................92

VZ NAVIGATOR ....................................................................................................... 98

SETTINGS & TOOLS ................................................................................................ 99

CHAPTER 5. SAFETY AND WARRANTY

SAFETY AND WARRANTY ...........................................................................145

SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES .............................146

GENERAL SAFETY ................................................................................................ 151

SAFETY INFORMATION FOR FCC RF EXPOSURE ..................................................155

SAR INFORMATION ..............................................................................................156

HEARING AID COMPATIBILITY (HAC) FOR WIRELESS TELECOMMUNICATIONS

DEVICES ............................................................................................................... 158

TELETYPEWRITER (TTY) DEVICES .......................................................................160

FDA CONSUMER UPDATE .................................................................................... 160

EMERGENCY CALLS .............................................................................................169

COMPLIANCE WITH OTHER FCC REGULATIONS ..................................................171

AVOID POTENTIAL HEARING LOSS ......................................................................171

FCC COMPLIANCE INFORMATION ........................................................................ 174

RECYCLE YOUR CELL PHONE! ..............................................................................175

12 MONTH LIMITED WARRANTY ........................................................................176

CHAPTER 1. BEFORE USING

INSIDE THE PACKAGE

HANDSET DESCRIPTIONS

DISPLAY INDICATORS

FEATURE OVERVIEW

INSTALLING THE SIM CARD AND BATTERY

REMOVING THE BATTERY

CHARGING THE BATTERY

BATTERY HANDLING INFORMATION

USING A MEMORY CARD

CONNECTING TO THE HEADSET

This chapter provides important information about using the Ravine®

Ravine®2 including:

BEFORE USING

Standard

Battery

SIM Card

(Pre-installed)

PRODUCT SAFETY & WARRANTY GUIDE

Handset QRG

(Quick Reference

Guide)

Product Safety &

Warranty Guide

Battery Cover Wall/USB

Charger

USB Cable Global Support

Kit

HANDSET DESCRIPTIONS

1. Earpiece:

Allows you to hear

the other caller.

2. Main Display Screen

: Displays all the information needed to operate your phone.

3. [ B ] Directional Keys

: Allows you to scroll through phone menu options and provides a shortcut to phone functions from idle mode.

4. [ C ] Left Soft Key

: Press to access the Messaging menu or access the function listed above the key.

5. [ E ]

Camera/Video Key:

In idle mode, press once to start taking a picture. If pressed one more time, it toggles to the video recording mode.

6. [ G ] SEND Key

: Press to make or receive a call. In idle mode, press to access the All Calls list.

14 13

12 11

INSIDE THE PACKAGE

This package should include all items pictured below. If any are missing or different, immediately contact the retailer where you purchased the phone.

a call or browser session. Within a menu, press to return to idle mode.

. [ F ] Speakerphone / Flashlight Key

: With the flip open, press to turn

speakerphone on or off. Press and hold to turn the flashlight on or off.

. [ A ] Center Select Key

: Press to access the MENU from idle mode. It also

allows you to accept choices when navigating through the menu.

. [ D ] Right Soft Key

: Press to access the Contacts menu in idle mode or

access the function listed above the key.

. Microphone

: Allows the other caller to hear you.

. External Speaker

: Allows you to listen to music, sounds or ringtones.

17.

Front Display Screen

: Displays incoming calls, messages, signal, battery

strength, time and date.

7. [ 1 ] Voicemail Key

: In idle mode, press and hold to automatically connect

to your voicemail box.

8. [ K ] Shift Key

: Press to enter an asterisk (*) character for calling features. In text entry mode, press to change the character input type. Press and hold to display the plus sign (+) for international dialing.

9. [ J ] Vibrate Mode Key

: Press and hold to activate/deactivate vibrate mode in idle mode. Press to enter the (#) character for calling features. In text entry mode, press to add a space.

. [ I ] CLR Key

: Press to clear a character from the display. Press and hold to clear all characters. Within a menu, press to return to the previous menu. Press and hold to activate the G’zGEAR function in idle mode.

11.

[ H ] END/PWR Key

: Press and hold to turn the phone on/off or press to end

18 19

Main Indicator Icons

GPRS Signal Strength

: GPRS service is available.

3G Signal Strength

: 3G service is available.

Airplane Mode

: Transmitting and receiving information is restricted.

Roaming

: The phone is outside of the home service area.

Femto Cell

: The phone is connected to the network extender.(Femto

Cell).

SSL (Secured Socket Layer)

: Indicates that secure communication between client and server has been established during data communication using encryption.

Voice Privacy

: Indicates Voice Privacy mode is active.

Data Call

: Data Session is in progress.

Dormant

: Phone is in a dormant state during a data call. Phone reverts to Dormant mode when there hasn’t been activity on a page for some time. The connection is still active and you can make and receive calls.

No Service

: Phone cannot receive a signal from the system.

TTY

: TTY mode is active.

Voice Call

: A call is in progress.

* No icon indicates the phone is in idle mode.

E911

: Location Service of your phone is E911.

18.

Camera Lens

: Built-in camera lens.

19.

Flashlight

: Built-in flashlight

20.

Sim Card Slot

: Allows you to insert a SIM card. The SIM Card comes pre-

installed in the device (located under the battery).

21.

Headset Jack

: Allows you to plug in an optional headset for convenient,

hands-free conversations.

22.

[N] PTT Key / Red Side Key

: In PTT Mode, press to access the PTT Contact List or press and hold to make a PTT Call. When not in PTT Mode, press to access the selected shortcut application.

23.

[

L M

] Volume Keys

: Press to adjust the master volume in idle mode or adjust

the voice volume during a call.

24.

Voice Commands Key

: Press to activate the voice command function in idle

mode.

25.

Charging / Data Port

: Connects to the USB cable for data transferring or

charging when attached to the Wall/USB Charger.

26.

microSD Card Slot

: Allows you to insert a microSD card.

27.

Charging Terminals

DISPLAY INDICATORS

Main Indicator Icons

1X Signal Strength

: 1X service is available.

D Signal Strength

: Digital service is available.

GSM Signal Strength

: GSM service is available.

Main Indicator Icons

Speaker

: Speakerphone mode is active.

Urgent Message

: Indicates you have an urgent message.

Urgent Voicemail

: Indicates you have an urgent voicemail.

Missed Calls

: Indicates you have missed calls.

Message

: Indicates you have a new message.

CMAS Alert

: Indicates you have a CMAS message.

Calendar Appointment

: Event Alarm is active.

Mobile Email

: Indicates you have an email.

Voicemail

: Indicates you have voicemail messages.

Alarm On

: Appears when an alarm is set.

PTT Icons

PTT Alert

PTT Connected To Enterprise Group

PTT Connected To Group

Main Indicator Icons

Location On

: Location Service of your phone is Location On.

Bluetooth

: Indicates Bluetooth mode.

Bluetooth Active

: Indicates Bluetooth Active mode.

Bluetooth Connected

: Indicates a Bluetooth Device is connected.

Battery Level

: Battery charging level - the more blocks, the stronger

the charge.

AVR Active

: AVR mode is active.

AVR Listening

: Indicates AVR listening.

PTT In Use

: Indicates you have a PTT call.

1x and PTT services are available.

3G and PTT services are available.

SIM Card

: Indicates SIM Card memory in use.

All Sounds O

: All sounds are set to o.

Alarm Only

: Phone will alert you only with an alarm alert.

Vibrate Only

: Phone will vibrate when call is received.

PTT Icons

PTT Individual Do Not Disturb

PTT Individual Received

PTT Listening To Enterprise Group

PTT Listening To Group

PTT Listening To Individual

PTT Missed Call

PTT Talking To Enterprise Group

PTT Talking To Group

PTT Talking To Individual

PTT Unavailable

Recent Call Icons

Dialed Call Missed Call

Received Call

PTT Icons

PTT Connected To Individual

PTT Connecting To Enterprise Group

PTT Connecting To Group

PTT Connecting To Individual

PTT Enterprise Group

PTT Enterprise Group Dialed

PTT Enterprise Group Do Not Disturb

PTT Enterprise Group Received

PTT Group Available

PTT Group Dialed

PTT Group Do Not Disturb

PTT Group Received

PTT Individual Available

PTT Individual Dialed

Message Icons

Opened/Read Message Unread CMAS

Message Delivered Read CMAS

Incomplete Delivery Unread EMS

Sent Message Delivery Failed

Read EMS

Message Locked Sent Message

Text Message Draft Received Message

Picture Message Draft Unread WAP Push

Priority Read WAP Push

Unopened MMS Notication

Multiple Message Delivered

Opened MMS Notication Multiple Message Failed

Corrupt Message Multiple Message Pending

Pending Message Sent

Multiple Message Incomplete

Unread MMS

Multiple Message Sent

New Contact Icons

Mobile1 Speed Dial

Mobile2 Home/Work Address

Home Company

Business Title

Personal Email Birthday

Business Email Notes!

Group WL Messenger

Picture AIM

Ringtone Yahoo!

Message Tone IM Screen Name

FAX

Message Icons

New/Unread Message Read MMS

• Your handset can be rinsed with clean water when dirty. To ensure water resistance, make sure that all covers are securely closed before rinsing.

• Periodically, clean the Charging Terminals and Battery Terminals with a dry cloth

or cotton swab. Dust may cause electrical connection problems. Avoid wiping with excessive force, which can damage the terminals.

OPERATION TEMPERATURE

0 - 50 ◦C (without adaptor), 0 - 45 ◦C (with adaptor)

Charging Terminals

Battery Terminals

CAUTION

• Do not clean terminals inside the handset, or they may be damaged.

• If mud or sand is adhered to the handset, do not use it until wiping completely.

• Do not place the handset directly on sand. If sand gets into the Earpiece or Speaker,

sounds may be difficult to hear. Sand getting into the handset’s hinge can cause problems such as overheating.

INSTALLING THE SIM CARD AND BATTERY

Your wireless device comes with a SIM card installed which along with a Global Feature on your account, enables you to make calls and access email in GSM Networks while traveling overseas. Should your SIM card be lost or damaged, please follow these instructions for the installation of your new SIM.

FEATURE OVERVIEW

WATER RESISTANCE

The Ravine®2 is water resistant. It provides reliable performance for outdoor activities and in wet conditions such as driving rain or high humidity. The tested device meets the requirements of the MIL-STD-810G (Rain & immersion 1m, 30min) standard.

CAUTION:

The Water Resistance feature does not guarantee protection against the usage of this device underwater. Do not use the handset underwater. We do not take responsibility for waterlogging due to the negligence of the user.

To maintain water resistance:

• Securely close the Charging/Data Port cover,

microSD™

card cover and the Headset

Jack cover.

• Completely close the battery cover and slide the battery cover lock to the LOCK

position.

• Make sure that the handset is completely dried up before you open any cover. When

wet, clean the handset with a dry cloth, swish water from the handset, and dry it thoroughly before use.

SHOCK RESISTANCE

The rugged construction of the Ravine®2 provides outstanding shock and vibration resistance. The tested device meets the requirements of the MIL-STD-810G (Drop 1.5m) standard.

CAUTION:

The shock and vibration resistance features do not guarantee protection against every type of shock and vibration. Your handset may be damaged or malfunction depending on the severity of the shock or vibration.

DUST RESISTANCE

For additional peace of mind, the Ravine®2 is also dust resistant. The device was tested using silica flour at a temperature of 95°F and meets the MIL-STD-810G (DUST) standard.

3. Insert the battery cover into the slots (1) and press the battery cover in the direction of the arrow (2).

4. Press down firmly on the side of the battery cover at each arrow point, as shown in the figure.

5. Slide the battery cover latch to the LOCK position in the direction of the arrow shown in the figure.

CAUTION

• Do not twist the battery cover as shown in the figure below. Doing so can damage

the handset and the battery cover.

• Do not press hard on the battery cover with the battery cover tabs running over the

handset because you may damage the battery cover tabs.

• Be careful not to get the tab of the battery caught between the edges of battery

cover and the handset. Failure to do so will result in the loss of water resistance.

• If you are using a wrist strap (sold separately), be careful not to get it caught

between the battery cover and the handset. Failure to do so will result in the loss of water resistance.

CAUTION

• Wipe your handset before opening the battery cover to prevent moisture or dust

from entering.

• Failure to follow the below directions for installing/removing the battery could result

in product failure.

• Fully charge the battery before using the handset for the first time.

1. Remove the battery cover and battery, as instructed on page 24. Slide the SIM card into the slot in the direction of the arrow shown in the figure.

- To remove the SIM card, pull out the SIM

card in the opposite direction of the arrow.

2. Slide the battery into the slot by aligning the contacts (1) and press down until you hear “click (2).”

Make sure that the sticker on the battery is put inside when you replace the back

cover. Otherwise it may affect the water resistance function.

REMOVING THE BATTERY

1. Slide the battery cover latch to the FREE position in the direction of the arrow as shown in the figure.

2. Insert your thumb in the right side groove and pull up the battery cover in the direction of the arrow.

3. Remove the battery by pulling the tab up.

Do not leave the removed battery in direct sunlight, or near heat sources such as an

open flame or stove. Otherwise, it may malfunction or cause a fire by bursting or igniting. Do not hit, or exert excessive shock on the battery, as it can ignite or break.

CHARGING THE BATTERY

1. Connect the USB cable into the Wall/USB Charger.

2. Plug the USB cable into the phone’s Charging/ Data Port. Plug the Wall/USB Charger into an electrical outlet. The battery starts charging.

3. Disconnect the charger when the battery is fully charged.

• Hold the small connector with the USB mark facing up. When inserting the connector into the Charging/Data Port on the handset, hold the connector straight against the port without tilting it vertically or horizontally and gently insert it. If the battery connector is not properly aligned, damage could occur to the charging connector and the phone may not be charged.

• Failure to completely reseal the Charging/Data Port cover after charging may allow

water or other liquids to enter the casing, damaging the handset.

Correct Incorrect

4. To remove the wall charger, unplug the USB cable from the phone’s Charging/Data Port.

• When you charge the battery with the handset powered off, you will see a charging status screen. After charging is completed, the Charge Complete message appears and you cannot operate the phone until it is powered on. To turn your phone on, press and hold the

END/PWR Key

until your display turns on.

• The battery may not be fully charged at the time of purchase. Fully charge the

battery before using.

• It is more efficient to charge the battery with the handset powered off.

• Battery operating time gradually decreases over time.

• If the battery fails to perform normally, you may need to replace the battery.

BATTERY HANDLING INFORMATION

Do not install the battery in humid places, like a bathroom, or places where water or liquid can come into contact with the handset or battery. Otherwise, the electrical circuits may short or erode and cause the handset to malfunction.

DO’S

•

Only use the battery and charger approved for use with the

Ravine®2

. Using any charger other than the one

included with the phone may damage your phone or battery.

• Only use the battery for the system for which it is specified.

• Only use or replace the battery with a charging system or another battery that has been qualified with the

system per this standard, IEEE-Std-1725-2006. Use of an unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazard.

• Only use the battery for its original purpose. As an improper battery use may result in a fire, explosion or

other hazard.

• Try to keep batteries in a temperature between 41°F (5°C) and 95°F (35°C). If the battery is stored in

temperatures above or below the recommended range, give it time to warm up or cool down before using.

• Store the discharged battery in a cool, dark, and dry place.

• Purchase a new battery when its operating time gradually decreases after fully charging.

• Properly and promptly dispose of the battery according to local laws.

• Battery usage by children should be supervised.

• Dispose of used battery according to the instructions.

• Completely drain the battery before recharging. It may take one to four days to completely drain.

• When the device is not used for long period, remove the battery from the device.

DON’TS

•

Don’t attempt to disassemble or open the battery – it is a sealed unit with no serviceable parts.

•

Don’t crush, bend or deform, puncture or shred the battery.

•

Don’t drop the phone or battery. If the phone or battery is dropped, especially on a hard surface, and the user suspects damage, take it to a service center for inspection.

•

Don’t leave the battery in extremely hot or cold temperatures. Otherwise, it could significantly reduce the capacity and lifetime of the battery.

•

Don’t modify or remanufacture, attempt to insert foreign objects into the battery, immerse or expose to water or other liquids, expose to fire, explosion or other hazard.

•

Don’t accidentally short-circuit the battery by carrying it in your pocket or purse with other metallic objects such as coins, clips and pens. This may critically damage the battery, and may cause fire or injury.

•

Don’t short-circuit a battery or allow metallic conductive objects to contact battery terminals.

•

Don’t dispose of the battery by placing into a fire.

•

Don’t use the battery with damage or a leak.

CAUTION

There is a risk of explosion if battery is replaced by an incorrect type. Lithium ion batteries are recyclable. When you replace your battery, please request the repair center to recycle the battery in accordance with RBRC standards. When disposing of the battery by yourself, please call RBRC at (800) 822-8837 for proper disposal tips. Never touch any fluid that might leak from the battery. Such liquid when in contact with the eyes or skin, could cause injury to the skin or eyes. Should the liquid come into contact with the eyes, irrigate the eyes thoroughly with clean water and immediately seek medical attention. In the event the liquid comes into contact with the skin or clothing, wash it away immediately with clean water.

REMOVING A microSD™ CARD

1. Open the microSD

card cover, and use your

thumb to press and release the microSD

card.

2. Press the memory card inward, gently, until it pops out.

3. Remove the microSD

card and close the

microSD

card cover.

CAUTION

• Never remove a memory card from the handset while it is being accessed. Doing so

can damage the memory card or the data stored on it.

• The memory card is very small. Make sure you do not drop it.

• To ensure the proper function of removable memory, please use a microSD

card.

• Failure to completely reseal the memory card slot after removing may result in

damage if the handset is exposed to water.

CONNECTING TO THE HEADSET JACK

You can connect a compatible device equipped with a standard 2.5mm plug to your handset for safe, convenient, hands-free conversations.

1. To open the Headset Jack cover, insert your fingertip into the notch and open the cover.

2. Plug the connector into the Headset Jack.

CAUTION

• Do not forcibly insert/remove the connector

into/from the Headset Jack. Carefully insert/ remove it.

• Failure to completely reseal the Headset Jack

cover after use may result in damage if the handset is exposed to water.

USING A MEMORY CARD

The

Ravine®2

supports the use of a microSD™ memory card as a source of external memory.

USING A microSD™ CARD

By using a microSD™card, you can store sounds, videos, images, photos, and other files.

INSTALLING A microSD™ CARD OPTIONAL

1. Open the microSD

card cover, and insert

the microSD

card into the slot with the gold

contacts facing up.

2. Press the microSD

card into the slot until

you hear the “click”, then close the microSD

card cover.

“CARD INSERTED. PICTURE, VIDEO & SOUND WILL BE SAVED TO CARD MEMORY. ACCEPT CHANGES?”

will appear on the display.

4. Press the

Center Select Key [Yes

] to confirm.

CAUTION

•

Whenever installing or removing a memory card, make sure the handset is turned off

and that the Wall/USB Charger is not connected.

•

When installing or removing a memory card, avoid touching the memory card

contacts and avoid damaging the memory card. Either can cause malfunction or loss of data.

•

The front and back of the memory card look different. When inserting the memory

card, make sure the correct side is facing up. If not, the memory card may not fit in the memory card slot, or the memory card and/or memory card slot may be damaged.

•

Do not forcibly insert the memory card into the memory card slot. Hold it with the

contacts facing down and carefully insert it.

•

Failure to completely reseal the memory card slot after installing may result in

damage if the handset is exposed to water.

CHAPTER 2. BASIC OPERATION

TURNING THE PHONE ON AND OFF

MENU ACCESS

MENU SUMMARY

MAKING A CALL

ABOUT PUSH TO TALK

USING A PUSH TO TALK (PTT) ALERT

USING A PUSH TO TALK (PTT) BARGE

ANSWERING CALLS

ANSWERING PTT CALLS

ENDING A CALL

MISSED CALL NOTIFICATION

WAIT/PAUSE

MAKING AN INTERNATIONAL CALL

3 WAY CALLING

CALL WAITING

VOLUME QUICK ADJUSTMENT

CALLER ID

VIBRATE MODE

MUTE FUNCTION

SPEAKERPHONE

FLASHLIGHT

VOICE DICTATION

TEXT TO SPEECH

AVAILABLE OPTIONS DURING A CALL

MAKING AN EMERGENCY CALL

MOTION DETECTION

This chapter addresses and explains the basic features for

Ravine®2 including:

BASIC OPERATION

TURNING THE PHONE ON AND OFF

TURNING ON

1. Press and hold the

END/PWR Key

H until the phone display turns on.

2. Enter your 4-digit lock code if the phone is locked. The default lock code is the last 4 digits of your phone number.

Avoid any unnecessary contact with the internal antenna area while your handset is on.

TURNING OFF

1. Press and hold the

END/PWR Key

H until the phone display turns off.

• Immediately change or recharge the battery when BATTERY LOW appears on the display.

•

Turn the phone off before removing or replacing the battery. If the phone is on,

unsaved data may be lost.

MENU ACCESS

Your phone can be customized via the menu. Each function can be accessed by scrolling with the

Directional Key

or by pressing the number that corresponds with the menu

item.

1. To access the menu, press the

Center Select Key [MENU

2. To scroll through the menu, press the

Directional Key B

up, down, left or

right.

3. To return to the previous page, press the

CLR Key

4. To exit the current menu, press the

END/PWR Key

5. To access the Messaging menu, press the

Left Soft Key

C [

Message

6. To access the Contact List, press the

Right Soft Key

D [

Contacts

All directions in this manual are based on the Grid menu layout and the HUD display

theme. If you have changed the settings, the directions may vary.

MENU SUMMARY

Main Menu 2nd DEPTH 3rd DEPTH 4th DEPTH

Contacts

1. New Contact

2. Contact List

3. Groups

Business Personal

4. Backup Assistant

5. Speed Dials

6. In Case of Emergency

4.* New PTT Contact

5.* PTT Contact List

6.* PTT Group

7. My Name Card

Messaging

1. New Message

1. TXT Message

2. Picture Message

3. Video Message

4. Voice Message

2. Messages

3. Drafts

4. Voicemail

5. Mobile IM

6. Mobile Email

* These options appear when PTT Mode is turned on.

Main Menu 2nd DEPTH 3rd DEPTH 4th DEPTH

Recent Calls

1. Missed

2. Received

3. Dialed

4. All

5. View Timers

Mobile Web

Media Center

1. Apps

2. Mobile Web

3. Tunes & Tones

1. My Ringtones

2. My Sounds

1. Record New

4. Picture & Video

1. V CAST Videos

2. My Pictures

3. My Videos

4. Take Picture

5. Record Video

6. Online Album

Mobile Email

Apps

VZ Navigator

Main Menu 2nd DEPTH 3rd DEPTH 4th DEPTH

Settings & Tools

1. My Verizon

2. Master Volume

3. Tools

1. Voice Commands

2. Calculator

3. Calendar

4. Alarm Clock

5. Stop Watch

6. Countdown Timer

7. World Clock

8. Notepad

9. USB Mass Storage

10. G’z GEAR

1. Earth compass

2. Walking Counter

3. Thermometer

4. Tides

5. Sunrise Sunset

6. Astro Calender

7. Star Gazer

8. Setup

9. How To Use

4. Bluetooth 1. Add New Device

5. Keyguard Settings

1. Keyguard Timer

2. Unlock Options

6. PTT Settings

1. PTT Mode

2. PTT Alert

1. Tone

2. Vibrate

3. PTT Missed Call

4. Tutorial

Main Menu 2nd DEPTH 3rd DEPTH 4th DEPTH

7. Sounds Settings

1. Easy Set-up

2. Call Sounds

1. Call Ringtone

2. Call Vibrate

3. Caller ID Readout

3. Alert Sounds

1. TXT Message

2. Multimedia Message

3. Voicemail

4. Emergency Tone

5. Missed Call

6. PTT Alert

4. Keypad Volume

5. Digit Dial Readout

6. Service Alerts

1. ERI

2. Minute Beep

3. Call Connect

4. Software update

7. Power On/Off

1. Power On

2. Power Off

8. Display Settings

1. Easy Set-up

2. Banner

1. Personal Banner

2. ERI Banner

3. Backlight

1. Display

2. Keypad

4. Wallpaper

1. My Pictures

2. My Videos

3. Animation

5. Display Themes

Main Menu 2nd DEPTH 3rd DEPTH 4th DEPTH

6. Main Menu Settings

1. Menu Layout

2. Replace Menu Items

3. Position Menu Items

4. Reset Menu Settings

7. Dial Fonts

8. Menu Font Size

9. Clock Format

1. Main Clock

2. Front Clock

9. Phone Settings

1. Airplane Mode

2. Set Shortcuts

1. Set My Shortcuts

2. Set Directional Keys

3.* Set Red Side Key

3. Voice Commands Settings

1. Confirm Choices

2. Sensitivity

3. Adapt Voice

4. Prompts

5. VoiceMode Training

6. About

4. Language

5. Time & Date

6. Location

7. Current Country

8. Security

1. Edit Codes

2. Restrictions

* This option will not appear if PTT Mode is turned on.

Main Menu 2nd DEPTH 3rd DEPTH 4th DEPTH

3. Phone Lock Setting

4. Lock Phone Now

5. Restore Phone

9. SIM Security

1. PIN Code

2. SIM Lock

10. Global Data Roaming

11. System Select

1.* Network Mode

2.* CDMA Settings

3.* GSM Settings

12. Motion Detection

1. G'zGEAR

2. My Pics/Videos

10. Call Settings

1. Answer options

2. Auto Retry

3. TTY Mode

4. One Touch Dial

5. Voice Privacy

6. DTMF Tones

7. PTT Mode

8. Assisted Dialing

9. Noise Reduction

* These options will not appear if PTT Mode is turned on.

Main Menu 2nd DEPTH 3rd DEPTH 4th DEPTH

11. Memory

1. Save Options

1. Pictures

2. Videos

3. Sounds

2. Phone Memory

1. Phone Memory Usage

2. My Pictures

3. My Videos

4. My Ringtones

5. My Sounds

6. My Contacts

7. Move All To Card

3. Card Memory

12. USB Mode

13. Phone Info

1. My Number

1. CDMA Number

2. GSM Number

2. SW/HW Version

3. Icon Glossary

4. Software Update

1. Status

2. Check New

5. Operating System

14. SIM Info

15. Tutorial

1. Push To Talk

2. G'zGEAR

3. Voice Dictation

4. Message Readout

16. Set Up Wizard

MAKING A CALL

BY DIALING THE PHONE NUMBER

1. First, gently open the folding cover of the phone.

2. Enter the phone number including the area code if needed and press the

SEND

Key

3. To end the call, press the

END/PWR Key

When you place or receive a call from phone numbers stored in your Contact List, the

name will be displayed.

USING THE SPEED DIALING FUNCTION

1. If the speed dial is set, press the speed dial number you wish to connect to, and hold the last digit number you have assigned for the speed dial. “

Speed Dial

” message appears, and your call is connecting to the contact.

2. To end the call, press the

END/PWR Key

For more information on how to set one-touch dial, please refer to ONE TOUCH DIAL on

page 137.

USING THE CONTACT LIST

1. Press the

Right Soft Key

D [

Contacts

2. Select the contact and press the

SEND Key

3. To end the call, press the

END/PWR Key

If more than 1 number is saved, pressing the SEND Key will dial the default number.

ABOUT PUSH TO TALK

Push to Talk calls may only be made with other Verizon Wireless Push to Talk subscribers, and only from the National Enhanced Services Rate and Coverage Area. A Push to Talk call is terminated by pressing the

END/PWR Key

H or will automatically time out after 20 seconds of inactivity. While you are on a Push to Talk call, voice calls received will go directly to Voice Mail. When you are on

a voice call, you cannot receive a Push to Talk call. You cannot prevent others who have your wireless phone number from entering you into their Push to Talk Contact List. Only one person can speak at a time during Push to Talk calls. When using your phone keypad to make a Push to Talk call, you must enter the 10-digit phone number of the called party. Your Push to Talk service cannot be used for any applications that tether your phone to computers or other devices for any purpose. Push to Talk-capable phone and Calling Plan required. If you wish to switch from a Push to Talk Calling Plan to another Calling Plan, you must first stop using your Push to Talk-capable phone and purchase or provide another compatible phone.

TURNING PTT ON/OF

1. From idle mode, press the

Center Select Key [MENU

2. Select

Settings & Tools

and press the

Center Select Key [OK

3. Select

Call Settings

, press the

Center Select Key [OK

], select

PTT Mode

then

press the

Center Select Key [OK

4. Press the

Directional Key

N up or down to select On/

Off

, then press the

Center Select Key [OK

USING A PUSH TO TALK (PTT) ALERT

The Push To Talk (PTT) feature allows you to use your phone like a Walkie-Talkie to communicate with Verizon Wireless PTT subscribers. An alert call is a call to notify a called party that the calling party wants to talk using a tone. The called party has option to answer or ignore the call.

BY DIALING THE PHONE NUMBER

1. Enter the phone number and press the

Left Soft Key

C [

Alert

“Press PTT Key To Alert”

message appears on your main display screen.

Left Soft Key

C [

Alert

] is not available when PTT Mode is set to Off.

2. Press the

PTT Key/Red Side Key

N on the left hand side of the phone to

alert.

Press and hold the PTT Key/Red Side Key N while talking and then release the

PTT Key/Red Side Key

N to let the other party talk.

USING THE PTT CONTACT LIST

1. From the idle mode, press the

PTT Key/Red Side Key

N to access your PTT

Contact List.

2. Select the contact and press the

Left Soft Key

C [

Alert

“Press PTT Key To Alert”

message appears on your main display screen.

Press and hold the PTT Key/Red Side Key N while talking and then release the

PTT Key/Red Side Key

You can hear the response while the

PTT Key/Red Side Key

N is released.

USING A PUSH TO TALK (PTT) BARGE

A barge call automatically connects to the other party. The called party does not have the option to ignore the call.

BY DIALING THE PHONE NUMBER

1. Enter the phone number.

2. Press and hold the

PTT Key/Red Side Key

N on the left hand side of the

phone.

3. Wait until the “

OK to Talk

” tone sounds and the message “

Talking to

” appears

on the display. Speak while pressing down the

PTT Key/Red Side Key

4. Release the

PTT Key/Red Side Key

N to let the other party talk.

5. Press the

END/PWR Key

H to end the call.

USING THE PTT CONTACT LIST

1. From the idle mode, press the

PTT Key/Red Side Key

N to access your PTT

Contact List.

2. Press and hold the

PTT Key/Red Side Key

N on your left hand side of the

phone.

3. Wait until the “

OK to Talk

” tone sounds and the message “

Talking to

” appears

on the display. Speak while pressing down

PTT Key/Red Side Key

4. Release the

PTT Key/Red Side Key

N to let the other party talk.

5. Press the

END/PWR Key

H to end the call.

ANSWERING CALLS

1. Press the

SEND Key

G to answer the incoming call.

Depending on your phone’s settings, you may also answer incoming calls by opening

the phone or by pressing

any key

2. To ignore incoming calls, press the

Right Soft Key

D [

Ignore

ANSWERING PTT CALLS

INCOMING BARGE CALL

When you receive a barge call, you will hear the calling party speaking through the speakerphone. The calling party’s phone number will appear on your display. If the calling party’s number has already been registered in your PTT Contact List, the contact name will replace the phone number on the display.

1. Press and hold the

PTT Key/Red Side Key

N to talk.

2. Release the

PTT Key/Red Side Key

N to let the other party talk.

3. Press the

END/PWR Key

H to end the call.

INCOMING ALERT CALL

When you receive an alert, you will hear the “

PTT Alert

” tone. The message “

Incoming

Alert

” will be displayed with the phone number or contact name of the calling party. The PTT Alert tone repeats every 5 seconds until you answer or ignore the call. If you do not answer an incoming alert within 20 seconds, the PTT call will be automatically disconnected.

1. Answer or ignore the alert. To answer the alert, press and hold the

PTT Key/Red Side Key

N and begin talking. To ignore the alert, press the

Right Soft Key

D [

Ignore

2. Release the

PTT Key/Red Side Key

N to let the other party talk.

3. Press the

END/PWR Key

H to end the call.

ENDING A CALL

1. Press the

END/PWR Key

MISSED CALL NOTIFICATION

When an incoming call is not answered, the missed call notification appears on the display.

DISPLAY THE MISSED CALL FROM THE NOTIFICATION

1. Select

View Now

and press the

Center Select Key [OK]

2. To dial the phone number, press the

SEND Key

DISPLAY A MISSED CALL FROM IDLE MODE

1. Press the

Center Select Key [MENU

], select

Recent Calls

and press the

Center

Select Key [OK]

2. Select

Missed

and press the

Center Select Key [OK]

3. Select the missed call and press the

Center Select Key [OPEN

4. To dial the phone number, press the

SEND Key

WAIT/PAUSE

Pauses are used for automated systems (i.e., voice mail or calling cards). The numbers entered after the pause will automatically be dialed after the pause. It is useful for dialing into systems that require a code.

WAIT

The phone stops dialing until you press the

SEND Key

G to dial the next number.

1. Enter the phone number.

2. Press the

Right Soft Key

D [

Options

3. Select

Add Wait

and press the

Center Select Key [OK]

4. Enter additional number(s).

5. Press the

SEND Key

G to dial.

2SEC PAUSE

The phone waits 2 seconds before sending the next digits automatically.

1. Enter the phone number.

2. Press the

Right Soft Key

D [

Options

3. Select

Add 2-Sec Pause

and press the

Center Select Key [OK]

4. Enter additional number(s) (pin number or credit card number).

5. Press the

SEND Key

G to dial.

MAKING AN INTERNATIONAL CALL

1. Press and hold the

Shift Key

- The “+” symbol, required for international calls appears.

2. Enter the country code, area code, and phone number.

3. Press

SEND Key

G to make a call.

If you set Assisted Dialing to On, regardless of the user’s intention, the entered phone

numbers maybe changed to the wrong number by the auto-correct function.

3 WAY CALLING

You can talk to two participants at the same time. During the call, the normal airtime rates will be applied for each of the two calls.

1. Enter the phone number and press the

SEND Key

2. When you have connected, enter the second phone number to call and press the

SEND Key

3. When you’re connected to the second party, press the

SEND Key

G again to

begin your 3-Way call.

If one of the participants hangs up during the call, you and the remaining participant

stay connected. If you initiated the call and are the first one to hang up, all three calls are disconnected.

CALL WAITING

If you are on a call and you receive another incoming call, you will hear one beep and the caller’s phone number will appear on the display. With Call Waiting, you may put the active call on hold while you answer the other incoming call.

1. Press the

SEND Key

G to answer the other call. The first call will

automatically be placed on hold. To switch back, press the

SEND Key

again.

VOLUME QUICK ADJUSTMENT

ADJUSTING THE MASTER VOLUME

1. Press the

Volume Keys

L M

to adjust the master volume level.

- To check the ringtone’s volume, press the

Left Soft Key

C [

Play

2. Press the

Center Select Key [SET

] to save.

ADJUSTING THE VOLUME DURING A CALL

1. To increase the volume, press the

Volume Keys

L M

up.

2. To decrease the volume, press the

Volume Keys

L M

down.

CALLER ID

Caller ID displays the name and the phone number of the person calling. If the caller’s information is not stored in your contact list, only the phone number is displayed.

VIBRATE MODE

Vibrate mode mutes the tones and activates an alert for an incoming call or message.

1. To activate, press and hold the

Vibrate Mode Key

2. To deactivate, press and hold the

Vibrate Mode Key

J again.

MUTE FUNCTION

If you activate the mute function while you are talking on the phone, the person you are speaking with cannot hear any sounds from you but, you are still able to hear them. To activate mute function:

1. During a call, press the

Left Soft Key

C [

Mute

2. Press the

Left Soft Key

C [

Unmute

] to deactivate the mute function.

SPEAKERPHONE

The Speakerphone feature lets you hear audio through the speaker and talk without holding the phone.

1. To activate, with the flip open, press the

Speakerphone

Flashlight Key

2. To deactivate, press the

Speakerphone / Flashlight Key

F again.

FLASHLIGHT

Your phone provides you of the flashlight function. To activate the flashlight:

1. In the idle mode, press and hold the

Speakerphone

Flashlight Key

- The flashlight turns on.

2. Press and hold the

Speakerphone

Flashlight Key

F to deactivate the

flashlight.

- The flashlight turns off after the “

Flash Off

” message appears on the display.

VOICE DICTATION

By using the voice dictation function, you can input the text by speaking your words instead of using the keypad.

1. Press the

Left Soft Key

C [

Message

], select

New Message

and press the

Center Select Key [OK]

2. Select the desired message type to send and press the

Center Select Key [OK]

3. Enter the email address or phone number in the “

” field and press the

Center

Select Key [OK]

4. In the

Text

field, press and hold the

Voice Commands Key

O, and speak into

the handset. Release the

Voice Commands Key

O after one word.

5. When entered text is correct, press the

Center Select Key [OK]

to confirm. If incorrect, amend the text by using the keypad. For details on how to use the keypad, see page 60, “TEXT INPUT.”

• Voice dictation mode cannot be used when the Bluetooth® connection is in use.

• The voice dictation function supports US English only.

• Before using voice dictation, the phone should be trained by your voice.

TEXT TO SPEECH

READING OUT UNREAD MESSAGES WITH THE FLIP OPEN

With the flip open, the handset reads out the text information with a synthetic voice.

With the flip open in idle mode, press and hold the Voice Commands Key O.

- The handset reads out unread received messages one after another for you

with a synthetic voice.

2. Press the

Left Soft Key

C [

Again

] to go back to the top of the message

currently being read.

3. Press the

Center Select Key [REPLY

] to create a reply message for the currently

reading message.

4. Press the

Right Soft Key

D [

Options

] to select the desired options.

5. Press the

CLR Key

I to stop reading out.

6. The handset returns to idle mode when reading out is done for all the unread messages or when the

END/PWR Key

H is pressed to abort reading.

READING OUT UNREAD MESSAGES WITH THE FLIP CLOSED

With the flip closed, the handset reads out the text information with a synthetic voice.

1. With the flip closed, press and hold the

Voice Commands Key

- The handset reads out unread received messages one after another for you

with a synthetic voice.

2. The handset returns to idle mode when reading out is done for all the unread messages.

Reading out will continue even when the flip is opened while reading out is in

progress.

AVAILABLE OPTIONS DURING A CALL

During a phone call, you can access the following features by pressing the

Right Soft

Key

D [

Options

]. Press the

Center Select Key [OK]

to select any of the following

options:

•

Messaging

•

Contact List

•

Recent Calls

•

Bluetooth Menu

•

Main Menu

•

Notepad

•

Voice Record

•

Voice Privacy

MAKING AN EMERGENCY CALL

The 911 feature automatically places the phone in Emergency Call Mode when you dial the preprogrammed emergency number, 911. It also operates in Lock Mode and out of the service area.

MAKING AN EMERGENCY CALL IN LOCK MODE

1. Enter any of the numbers 911, *911, #911 or 112 and press the

SEND Key

The phone maintains Emergency Mode for 5 minutes. When the call ends, the phone

returns to Lock Mode.

MAKING AN EMERGENCY CALL IN ANY NETWORK MODE

1. Enter any of the numbers

911, *911, #911

112

and press the

SEND Key

ALL NETWORK MODE

CDMA Mode, GSM Mode

and

Global Mode

The phone will stay in Emergency Mode for 5 minutes in CDMA Mode. While the

phone is in Emergency Mode, the phone can receive an incoming call or you can make outgoing calls even in the Emergency Callback Mode. In this case, making a call can automatically end the Emergency Callback Mode.

The 911 call does not appear in the recent calls list.

MOTION DETECTION

Using the Motion Detection function, you can control your handset just by shaking it. By default, the Motion Detection function is set to

OFF

. To use the Motion

Detection function:

1. From idle mode, press the

Center Select Key

[

] and select

Settings&Tools

, then

press the

Center Select Key [OK]

2. Select

Phone Settings

and press the

Center

Select Key [OK]

, and select

Motion Detection

then press the

Center Select Key [OK]

3. Select

G’zGEAR

My Pics/Videos

4. Select

and press the

Center Select Key

[

SET

]. When shaking the handset, be sure to hold the handset firmly as shown in the figure and shake it from the right to left or vice versa.

When shaking the handset, make sure you do not hit the handset against nearby

objects.

CHAPTER 3. MEMORY FUNCTION

STORING A PHONE NUMBER

TEXT INPUT

USING THE TEXT INPUT MODE

ONE, TWO, THREE DIGIT SPEED DIALING

This chapter addresses memory functions including:

MEMORY FUNCTION

+ 63 hidden pages

Casio Ravine 2, GzOne Ravine 2 Verizon User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
