Casio GP-500BP, GP-400 MIDI Implementation

GP-500BP/GP-400
MIDI Implementation
CASIO COMPUTER CO., LTD.
Contents
I Overview 4
1 Product Configuration as a MIDI Device 4
1.1 System Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Performance Controller Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 Sound Generator Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Conditions that Disable Message Send and Receive 6
II Channel Message 7
3 Note Off 7
4 Note On 8
5 Control Change 8
5.1 Bank Select (00H,20H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.2 Modulation (01H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.3 Portamento Time(05H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.4 Data Entry (06H,26H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.5 Volume (07H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.6 Pan (0AH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.7 Expression (0BH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.12 Release Time (48H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5.14 Vibrato Rate (4CH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5.15 Vibrato Depth (4DH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.16 Vibrato Delay (4EH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.17 Portamento Control(54H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.18 High Resolution Velocity Prefix (58H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.19 Reverb Send (5BH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.20 Chorus Send (5DH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1
5.24 Reset All Controllers (79H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
6 Program Change 16
6.1 DSP Assignments during Tone Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
7 Channel After Touch 16
8 Pitch Bend 17
III System Message 18
9 Active Sensing 18
10 System Exclusive Message 18
10.1 Universal Real Time System Exclusive Message . . . . . . . . . . . . . . . . . . . . . . . . 18
10.2 Universal Non Real Time System Exclusive Message . . . . . . . . . . . . . . . . . . . . . 21
10.3 Instrument-Specific System Exclusive Message . . . . . . . . . . . . . . . . . . . . . . . . 21
IV Instrument-Specific System Exclusive Messages 22
11 Format 22
11.1 Message Classifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
11.2 Basic Message Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
12 Parameter Operations 26
V Parameter List 27
13 Using the Parameter List 27
14 System Parameter 27
14.1 System Information Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
15 Patch Parameter 28
15.1 Master Tune Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
15.2 System Chorus Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
15.3 System Reverb Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
15.4 Portamento Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
16 Spec Parameter 29
VI DSP Parameter List 31
17 Tone with DSP List 31
2
VII Setting Values and Send/ Receive Values 32
18 Setting Value Tables 32
18.1 Off/On Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
18.2 Sustain Pedal Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
18.3 –64 - 0 - +63 Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
18.5 Fine Tuning Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
18.6 Reverb Type Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
18.7 Chorus Type Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
VIII MIDI Implementation Notation 34
19 Value Notation 34
19.1 Hexadecimal Notation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3
Part I
Overview
1 Product Configuration as a MIDI Device
As a MIDI device, this Instrument consists of the System Section, Sound Generator Section, and Per­formance Controller Section described below. Each of these sections can send and receive specific MIDI Messages in accordance with its function.
1.1 System Section
The System Section manages the Instrument status.
1.2 Performance Controller Section
The Performance Controller Section performs generates performance messages in accordance with key­board play and pedal operations, etc. Basically, generated performance messages are sent to external destinations while also being transmitted to the Sound Generator Section. The channel number of the sent channel message is in accordance with the Instrument’s part number.
1.3 Sound Generator Section
The Sound Generator Section mainly performs receive of performance information and sound source setting information. It consists of a common part that does not depend on the channel and a musical instrument part that is independent of each channel.
1.3.1 Sound Generator Common Block
The common block consists of system effects, master control, etc. These can be controlled by general universal system exclusive messages, or the Instrument’s system exclusive messages or all.
1.3.2 Instrument Part Block
The instrument part section consists of a total of 32 instrument parts. The settings of each part can be changed using channel messages or Instrument’s system exclusive messages or all. The functions assigned to each part are shown below. The MIDI send channel and MIDI receive channel can be changed using the Instrument’s MIDI settings.
4
Part Number Part Name MIDI Receive Ch MIDI Send Ch Assigned
Function
Description
00 A01 - 01(Note1) Keyboard Upper1(Main)/
(Right-side keyboard in the Duet Mode)
01 A02 - 02 Keyboard Upper2(Layer) 02 A03 - 03 Keyboard Lower1(Split)/
(Left-side keyboard in the Duet Mode)
03 A04 - - ­04 A05 - 05 Recorder Play Track1 main 05 A06 - 06 Recorder Play Track1 layer 06 A07 - 07 Recorder Play Track1 split 07 A08 - - Metronome/
Count
08 A09 - ­09 A10 - ­10 A11 - ­11 A12 - ­12 A13 - ­13 A14 - ­14 A15 - 04 Recorder Play Track2 15 A16 - - ­16 B01 01 - MIDI/Song Play Ch.01 17 B02 02 - MIDI/Song Play Ch.02 18 B03 03 - MIDI/Song Play Ch.03 (Left hand
track)
19 B04 04 - MIDI/Song Play Ch.04 (Right
hand track)
20 B05 05 - MIDI/Song Play Ch.05 21 B06 06 - MIDI/Song Play Ch.06 22 B07 07 - MIDI/Song Play Ch.07 23 B08 08 - MIDI/Song Play Ch.08 24 B09 09 - MIDI/Song Play Ch.09 25 B10 10 - MIDI/Song Play Ch.10 26 B11 11 - MIDI/Song Play Ch.11 27 B12 12 - MIDI/Song Play Ch.12 28 B13 13 - MIDI/Song Play Ch.13 29 B14 14 - MIDI/Song Play Ch.14 30 B15 15 - MIDI/Song Play Ch.15 31 B16 16 - MIDI/Song Play Ch.16
Note1: Can be changed by Keyboard Channel setting.
5
2 Conditions that Disable Message Send and Receive
No MIDI messages at all can be sent or received while “Please Wait ...” is on the display.
6
Part II
Channel Message
Instrument Velocity Resolution The upper seven bits of the 14-bit resolution correspond to the Note On/Off message, while the lower seven bits correspond to the High Resolution Velocity Prefix message.
Note On/Off High Resolution Velocity Prefix
Upper 7 bits
14bits
The initial default value for the lower 7 bits is 00H. Receipt of a High Resolution Prefix message
causes the lower seven bits to be set, but note on/off is not performed.
Receipt of a Note On/Off message causes the upper seven bits to be set with note on/off performed
with 14-bit resolution Velocity.
The High Resolution Velocity Prefix message corresponds the message immediately following the Note On/Off message, and the lower seven bits are cleared to 00H immediately following note on/off by the Note On/Off message. 7-bit resolution note on/off using only the Note On/Off message also continues to be supported.
For details ab out each message, see ” 3 Note Off”, ”4 Note On”, and ”5.18 High Resolution Velocity Prefix”.
Lower 7 bits
3 Note Off
Format
Message Format: 8nH kkH vvH
9nH kkH 00H(receive only)
n: MIDI Channel Number
kk: Key Number
vv: Velocity
Transmit Sent when something is played on the keyboard. The key number changes in accordance with on the Transpose function and Octave Shift function.
Receive Receipt stops a note being sounded by a note on message.
When a High Resolution Velocity Prefix message is received immediately prior to the Note Off message and the lower seven bits of the 14-bit Velocity are set, the 14-bit resolution note off of the note being sounded is performed.
For information about the relationship between the Note On/Off message and High Resolution Ve­locity Prefix message, see ”Instrument Velocity Resolution” at the beginning of part II.
Note off by making the Note On Velocity 00H is identical to note off by the combination of High Resolution Velocity prefix message 40H and Note Off Message 40H.
7
Note: This Instrument has a function that assumes connection of an external device that sends Note Off Velocity as a fixed value. Note Off Velocity 00H is replaced with 40H until a Note Off message with a Velocity value other than 00H is received. This function is enabled when the Instrument is turned on, and disabled by receipt of a Note Off message with a Velocity value other than 00H.
4 Note On
Message Format: 9nH kkH vvH
n: MIDI Channel Number
kk: Key Number
vv: Velocity
Transmit Sent when something is played on the keyboard. The key number changes in accordance with on the Transpose function and Octave Shift function.
Receive Receipt sounds a note of the corresponding instrument part.
When a High Resolution Velocity Prefix message is received immediately prior to the Note On message and the lower seven bits of the 14-bit Velocity are set, the 14-bit resolution note on is performed.
For information about the relationship between the Note On/Off message and High Resolution Ve­locity Prefix message, see ”Instrument Velocity Resolution” at the beginning of part II.
5 Control Change
Message Format: BnH ccH vvH
n: MIDI Channel Number
cc: Control Number
vv: Value
For details about messages, see each section of this manual that covers them.
5.1 Bank Select (00H,20H)
Message Format: BnH 00H mmH (MSB)
BnH 20H llH (LSB)
n: MIDI Channel Number
mm: MSB Value(Note1)
ll: LSB Value(Transmit:00H, Receive:Ignored)
Note1: For details about the relationship between the MSB value and the tone, see the Tone List that comes with the Instrument.
Transmit Sent when a tone number is selected. For information about numbers, see the Tone List in the User’s Guide.
Receive Receipt causes a change in the tone bank number stored in Instrument memory, but the tone is not actually changed until a Program Change message is received. For details, see “6 Program Change”.
8
5.2 Modulation (01H)
Message Format: BnH 01H vvH
n: MIDI Channel Number
vv: Value
Receive Receipt adds, to the tone being sounded, modulation of a depth specified by the value. In the case of a tone that already has modulation applied, receipt of this message increases the modulation depth. The modulation effect differs according to the tone being used.
5.3 Portamento Time(05H)
Message Format: BnH 05H vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the portamento application time.
5.4 Data Entry (06H,26H)
Message Format: BnH 06H mmH (MSB)
BnH 26H llH (LSB)
n: MIDI Channel Number
mm: MSB Value
ll: LSB Value
Transmit Sent when there is a change to the parameter assigned to RPN. For details about information assigned to parameters that correspond to RPN, see ”5.22 RPN”. This Instrument does not have a parameter that corresponds to NRPN.
Receive Receipt changes the parameter assigned to RPN.
5.5 Volume (07H)
Message Format: BnH 07H vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when layer balance or lower volume is adjusted.
Receive Receipt changes the part volume.
5.6 Pan (0AH)
Message Format: BnH 0AH vvH
n: MIDI Channel Number
vv: Value(Note1)
9
Note1: For information about the relationship between setting values and send/receive values, see “18.4 Pan Setting Value Table” in “VII Setting Values and Send/Receive Values”.
Transmit Sent when Music Library play is stopped.
Receive Receipt changes the pan of the corresponding part.
5.7 Expression (0BH)
Message Format: BnH 0BH vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the Expression value.
5.8 Hold1 (40H)
Message Format: BnH 40H vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when a pedal that has a sustain (damper) function is operated.
Receive Receipt performs an operation equivalent to a sustain pedal operation.
5.9 Portamento On/Off(41H)
Message Format: BnH 41H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “18.1 Off/On Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Receive Receipt changes the portamento on/off setting.
5.10 Sostenuto (42H)
Message Format: BnH 42H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “18.1 Off/On Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
10
Transmit Sent when a pedal that has a sostenuto function is operated.
Receive Receipt performs an operation equivalent to a sostenuto pedal operation.
5.11 Soft (43H)
Message Format: BnH 43H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “18.1 Off/On Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Transmit Sent when a pedal that has a soft function is operated.
Receive Receipt performs an operation equivalent to a soft pedal operation.
5.12 Release Time (48H)
Message Format: BnH 48H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “18.3 –64 - 0 - +63 Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Receive Receipt makes a relative change in the time it takes for a note to decay to zero after a key is released.
5.13 Attack Time (49H)
Message Format: BnH 49H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “18.3 –64 - 0 - +63 Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Receive Receipt makes a relative change in the time it takes for a note to rise to its maximum level.
5.14 Vibrato Rate (4CH)
Message Format: BnH 4CH vvH
n: MIDI Channel Number
vv: Value (Note1)
11
Note1: For information about the relationship between setting values and send/receive values, see the “18.3 –64 - 0 - +63 Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Receive Receipt changes the note vibrato rate.
5.15 Vibrato Depth (4DH)
Message Format: BnH 4DH vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “18.3 –64 - 0 - +63 Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Receive Receipt changes the degree of pitch modulation.
5.16 Vibrato Delay (4EH)
Message Format: BnH 4EH vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “18.3 –64 - 0 - +63 Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Receive Receipt changes the time it takes until note vibrato starts.
5.17 Portamento Control(54H)
Message Format: BnH 54H vvH
n: MIDI Channel Number
vv: Source Key Number
Receive Receipt of this message first stores the Source Note Number for the next note. When the next Note On is received, the portamento effect is applied to the note using this Source Note Number as the pitch start point and the Note On event key number as the end point. If there already is a note being sounded by Source Note Number at this time, the new note on is not performed and the portamento effect is applied to the pitch of the note being sounded. That is to say that legato play is performed.
5.18 High Resolution Velocity Prefix (58H)
Message Format: BnH 58H vvH
n: MIDI Channel Number
vv: Value
Transmit Sends the lower seven bits of 14-bit Velocity when a key is pressed or released.
12
Receive Receipt is handled, in combination with the following Note On/Off message, as the lower seven bits of 14-bit Velocity. For information about the relationship between the Note On/Off message and High Resolution Velocity Prefix message, see ”Instrument Velocity Resolution” at the beginning of part II.
5.19 Reverb Send (5BH)
Message Format: BnH 5BH vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when Music Library play (etc.) is operated.
Receive Receipt changes the reverb send of the corresponding part.
5.20 Chorus Send (5DH)
Message Format: BnH 5DH vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when Music Library play (etc.) is operated.
Receive Receipt changes the chorus send of the corresponding part.
5.21 NRPN (62H,63H)
Message Format: BnH 62H llH (LSB)
BnH 63H mmH (MSB)
n: MIDI Channel Number
ll: LSB Value
mm: MSB Value
5.21.1 Assignable Functions to NRPN
This Instrument does not assign any parameters to NRPN.
5.22 RPN (64H,65H)
Message Format: BnH 64H llH (LSB)
BnH 65H mmH (MSB)
n: MIDI Channel Number
ll: LSB Value
mm: MSB Value
13
5.22.1 Pitch Bend Sensitivity
Message Format: BnH 64H 00H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value(00H - 18H)
ll: LSB Value(Transmit:00H, Receive:Ignored)
Receive Receipt changes Pitch Bend Sensitivity.
5.22.2 Fine Tune
Message Format: BnH 64H 01H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value
ll: LSB Value
Receive Receipt changes Channel Fine Tune.
5.22.3 Coarse Tune
Message Format: BnH 64H 02H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value(28H - 58H)
ll: LSB Value(Transmit:00H, Receive:Ignored)
Receive Receipt changes Channel Coarse Tune.
5.22.4 Null
Message Format: BnH 64H 7FH
BnH 65H 7FH
n: MIDI Channel Number
Transmit Sent when an RPN message send operation is performed.
Receive Receipt de-selects RPN.
14
5.23 All Sound Off (78H)
Message Format: BnH 78H 00H
n: MIDI Channel Number
Receive Receipt stops all voices that are sounding.
5.24 Reset All Controllers (79H)
Message Format: BnH 79H 00H
n: MIDI Channel Number
Transmit Sent when MIDI send related settings are changed.
Receive Receipt initializes each performance controller.
5.25 All Notes Off (7BH)
Message Format: BnH 7BH 00H
n: MIDI Channel Number
Transmit Sent when MIDI send related settings are changed.
Receive Receipt releases (key release) all voices that are sounding.
5.26 Omni Off (7CH)
Message Format: BnH 7CH 00H
n: MIDI Channel Number
Receive Receipt performs the same operation as when All Notes Off is received. Regardless of the reception of this message, the instrument always operates as Omni Off mode.
5.27 Omni On (7DH)
Message Format: BnH 7DH 00H
n: MIDI Channel Number
Receive Receipt performs the same operation as when All Notes Off is received. Regardless of the reception of this message, the instrument always operates as Omni Off mode.
5.28 Mono (7EH)
Message Format: BnH 7EH 00H
n: MIDI Channel Number
15
Receive Receipt performs the same operation as when All Notes Off is received. Regardless of the reception of this message, the instrument always operates as Poly mode.
5.29 Poly (7FH)
Message Format: BnH 7FH 00H
n: MIDI Channel Number
Receive Receipt performs the same operation as when All Notes Off is received. Regardless of the reception of this message, the instrument always operates as Poly mode.
6 Program Change
Message Format: CnH ppH
n: MIDI Channel Number
pp: Program Number (Note1)
Note1: For details about the relationship between the program number and the tone, see the Tone List that comes with the Instrument.
Transmit Sent when a tone number is selected.
Receive Receipt changes the tone of the corresponding part. The selected tone is determined by the
program value of this message and the Bank Select message value received prior to this message.
6.1 DSP Assignments during Tone Selection
6.1.1 DSP Line Structure
Though the Instrument has four DSP lines that can be used simultaneously, selecting a tone that uses DSP causes the required number of DSP lines to become reserved so the tone is configured with the requisite DSP. For information about tones that use DSP, see “17 Tone with DSP List”.
6.1.2 DSP Line Assignment
Selecting multiple tones with DSP at the same time creates the possibility that there will not be enough DSP lines. In this case, the last selected tone with DSP is given priority. Some DSP line(s) already being used will be released so they can be assigned to the newly selected tone.
7 Channel After Touch
Message Format: DnH vvH
n: MIDI Channel Number
vv: Value
Receive Receipt adds, to the tone being sounded, modulation of a depth specified by the value. In the case of a tone that already has modulation applied, receipt of this message increases the modulation depth. The modulation effect differs according to the tone being used.
16
8 Pitch Bend
Message Format: EnH llH mmH
n: MIDI Channel Number
ll: Value LSB
mm: Value MSB
Receive Receipt changes the pitch of the currently sounding note. Pitch bend change sensitivity depends on the pitch bend sensitivity configured with RPN.
17
Part III
System Message
9 Active Sensing
Message Format: FEH
Transmit This message is never sent.
Receive Once this message is received, the Active Sensing mode is entered. If no MIDI message is
received for a specified amount of time, voices being sounded by this Instrument’s sound source are released, the controller is reset, and the Active Sensing mode is exited.
10 System Exclusive Message
Message Format: F0H iiH ddH....F7H
ii: ID Number
dd: Device ID
The Instrument sends and receives standard universal system exclusive messages, and system exclusive messages that have Instrument-specific formats.
ID Number The ID numbers handed by this Instrument are shown below.
ID Number ID Name 44H Casio Computer Co. Ltd 7EH Non Real Time System Exclusive Message 7FH Real Time System Exclusive Message
Device ID The device ID is used mainly for individual control of multiple devices. When a System Exclusive message is sent, the sending device sends messages that include a value that matches the device ID of the sending device. When a System Exclusive message is received, the receiving device receives only messages that include a value that matches the receiving device ID. The device ID 7FH is a special value, and receipt is always performed whenever the device ID of either the receiving device or the message is 7FH. MIDI Device ID is one of Spec Parameter and can be changed by the System Exclusive Message. Device ID of MIDI System Exclusive Message in this case should be sent is set to 7FH.(Initial Value:7FH)
10.1 Universal Real Time System Exclusive Message
Message Format: F0H 7FH ddH....F7H
dd: Device ID
18
10.1.1 Master Volume
Message Format: F0H 7FH ddH 04H 01H llH mmH F7H
dd: Device ID
ll: LSB Value(Receive:Ignored)
mm: MSB Value
Receive Receipt changes the Master Volume.
10.1.2 Master Fine Tuning
Message Format: F0H 7FH ddH 04H 03H llH mmH F7H
dd: Device ID
ll: LSB Value(Note1)
mm: MSB Value(Note1)
Note1: For information about the relationship between setting values and send/receive values, see “18.5 Fine Tuning Setting Value Table” in “VI I Setting Values and Send/Receive Values” of this document.
Transmit This message is sent when the tuning setting is changed.
Receive Receipt changes the tuning setting.
10.1.3 Master Coarse Tuning
Message Format: F0H 7FH ddH 04H 04H llH mmH F7H
dd: Device ID
ll: LSB Value(Transmit:00H,Receive:Ignored)
mm: MSB Value(28H - 58H)
Receive Receipt changes the Patch Master Coarse Tune parameter.
10.1.4 Reverb Type
Message Format: F0H 7FH ddH 04H 05H 01H 01H 01H 01H 01H 00H vvH F7H
dd: Device ID
vv: Value(Note1)
Note1: For information about the relationship between setting values and send/receive values, see “18.6 Reverb Type Setting Value Table” in “VI I Setting Values and Send/Receive Values” of this document.
Transmit This message is sent when the reverb type is changed. This Instrument treats a hall simulator as a reverb.
Receive Receipt changes the reverb type.
19
10.1.5 Reverb Time
Message Format: F0H 7FH ddH 04H 05H 01H 01H 01H 01H 01H 01H vvH F7H
dd: Device ID
vv: Value
Receive Receipt changes the Reverb duration.
10.1.6 Chorus Type
Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 02H 00H vvH F7H
dd: Device ID
vv: Value(Note1)
Note1: For information about the relationship b etween setting values and send/receive values, see “18.7 Chorus Type Setting Value Table” in “VI I Setting Values and Send/Receive Values” of this document.
Transmit This message is sent when the chorus type is changed.
Receive Receipt changes the chorus type.
10.1.7 Modulation Rate
Message Format: F0H 7FH ddH 04H 05H 01H 01H 01H 01H 02H 01H vvH F7H
dd: Device ID
vv: Value
Receive Receipt changes the Chorus Rate.
10.1.8 Modulation Depth
Message Format: F0H 7FH ddH 04H 05H 01H 01H 01H 01H 02H 02H vvH F7H
dd: Device ID
vv: Value
Receive Receipt changes the chorus level setting.
10.1.9 Send To Reverb
Message Format: F0H 7FH ddH 04H 05H 01H 01H 01H 01H 02H 04H vvH F7H
dd: Device ID
vv: Value
Receive Receipt changes the Chorus Sent To Reverb setting.
20
10.2 Universal Non Real Time System Exclusive Message
Message Format: F0H 7EH ddH....F7H
dd: Device ID
10.2.1 GM System On
Message Format: F0H 7EH ddH 09H 01H F7H
dd: Device ID
Receive Receipt puts the settings of sound source into the default of this instrument.
10.2.2 GM System Off
Message Format: F0H 7EH ddH 09H 02H F7H
dd: Device ID
Receive Receipt changes the sound source setting to the Instrument presetting.
10.2.3 GM2 System On
Message Format: F0H 7EH ddH 09H 03H F7H
dd: Device ID
Receive Though the Instrument does not support GM2, receipt of the GM2 System On message has the same result as receipt of the GM System On message.
10.3 Instrument-Specific System Exclusive Message
Message Format: F0H 44H ... F7H
This message can be used to send the Instrument memory status and to perform sound source pa­rameter operations, etc. For more information, see “IV Instrument-Specific System Exclusive Messages”.
21
Part IV
Instrument-Specific System Exclusive Messages
11 Format
This section explains the format of the Instrument-specific System Exclusive Messages. See “V Parameter List” and for information about how parameter sets actually are transferred.
11.1 Message Classifications
Basically, the operation that corresponds to Instrument-specific system exclusive messages is parameter data transfer.
The following operations can be performed from an external device using this parameter transfer message.
Modification of an individual Instrument parameter
Import of an individual Instrument parameter value
In addition to parameters being used as device setting values, some parameters act as commands when received by the Instrument and as device status information when sent from the Instrument.
The following table shows the parameter category for each type of transfer.
Function Section Parameter Category Description System System Commands to the Instrument, Instrument stats Performance Controller Spec Global settings, settings of each music engine Sound Generator Patch Sound source common settings (system effects, mas-
ter settings, etc.)
11.2 Basic Message Structure
”Indivisual Parameter Transfer”(single parameter transmission/reception) is a format of instrument­specific system exclusive message, which comprise a number of different messages for each operation.
The field in the system exclusive message that specifies the message type is the Action field. The format of the body part of the message depends on the act value.
The table below shows the body format for each action of Instrument-specific system exclusive mes­sages. An actual message consists of the items indicated by Y, from left to right.
SX MAN MOD dev act body (act Depends on act) EOX
cat mem pset blk prm idx len data
IPR Y Y Y Y Y Y Y Y Y Y Y Y - Y
IPS Y Y Y Y Y Y Y Y Y Y Y Y Y Y
11.3 Format of Each Field
11.3.1 SX : System Exclusive message Status
Format: 11110000B (F0H)
This is the System Exclusive Message status byte established by the MIDI standard.
22
11.3.2 MAN : Manufacturer’s ID
Format: 01000100B (CASIO = 44H)
Indicates this Instrument’s manufacturer ID.
11.3.3 MOD : Model ID
Format: MSB 00010111B (17H)
LSB 00000010B (03H)
These two successive bytes (MSB, LSB) indicate the GP-500BP/GP-400 model ID.
11.3.4 dev : MIDI Device ID 00H - 7FH
Format: 0dddddddB
The contents of this field in a received message are compared with the Model’s MIDI Device ID, and receipt of the incoming message is allowed only when the two IDs match. When a message containing 7FH is received, receipt of the message is always allowed, regardless of the Instrument’s ID setting.
11.3.5 act : Action
Format: 0aaaaaaaB
This field indicates the operation of the Instrument-specific System Exclusive Message.
aaaaaaaB Action Function
00H IPR Individual Parameter Request
01H IPS Individual Parameter Send
IPR:Individual Parameter Request Indicates an individual parameter value send request message. When the Instrument receives this action, it uses an IPS message to return the specified parameter value.
IPS:Individual Parameter Send Indicates an individual parameter value send message. When the Instrument receives this action, it rewrites the value specified by the data field with the specified parameter value.
11.3.6 cat : Category
Format: 0cccccccB
The category indicates the categories of data handled by the System Exclusive Message. The ID number (ID) of the Category is indicated on the left, while the communication operation (Action) is indicated on the right.
Category Transfer
ID (c) Parameter Set Individual Parameter
00H System A
02H Patch A
2AH Spec A
A · · · Available (Also including when only some parameters are available.)
23
11.3.7 mem : Memory Area ID
Format: 0mmmmmmmB
Specifies the memory area that is the object of the parameter transfer. The following are defined for this Instrument.
mem Data Type Meaning
3 Work Area Read/Write enabled
11.3.8 pset : Parameter Set Number
Format: LSB 0nnnnnnnB
MSB 0mmmmmmmB
This field is a 2-byte (LSB, MSB) value indicating the number of the parameter set (mmmmm­mmnnnnnnnB, Binary) being transferred.
11.3.9 blk Block Number
The block number is a supplementary number that specifies which block parameter is to be accessed when there are multiple blocks (instrument parts, etc.) that include parameters with the same ID within a single parameter set. The array structure of a block can be expressed up to 4 dimensions, and the size of a 1-dimensional array is expressed as 14 bits.
Format: index3 LSB 0iiiiiiiB
index3 MSB 0jjjjjjjB
index2 LSB 0kkkkkkkB
index2 MSB 0lllllllB
index1 LSB 0mmmmmmmB
index1 MSB 0nnnnnnnB
index0 LSB 0oooooooB
index0 MSB 0pppppppB
Note: Arranged in high dimension sequence.
1-dimension array block [index0]
Value Meaning
00jjjjjjjiiiiiiiB 0000H
00lllllllkkkkkkkB 0000H
00nnnnnnnmmmmmmmB 0000H
00pppppppoooooooB index0
2-dimension array block [index1][index0]
Value Meaning
00jjjjjjjiiiiiiiB 0000H
00lllllllkkkkkkkB 0000H
00nnnnnnnmmmmmmmB index1
00pppppppoooooooB index0
24
3-dimension array block [index2][index1][index0]
Value Meaning
00jjjjjjjiiiiiiiB 0000H
00lllllllkkkkkkkB index2
00nnnnnnnmmmmmmmB index1
00pppppppoooooooB index0
4-dimension array block [index3][index2][index1][index0]
Value Meaning
00jjjjjjjiiiiiiiB index3
00lllllllkkkkkkkB index2
00nnnnnnnmmmmmmmB index1
00pppppppoooooooB index0
11.3.10 prm : Parameter ID
Format: LSB 0pppppppB
MSB 0qqqqqqqB
The Parameter ID indicates the parameter type. When transferring parameters (see “V Parameter List” below) individually, this field is used to identify the parameter being transferred by its parameter ID.
11.3.11 idx : Data Index Number
Format: LSB 0iiiiiiiB
MSB 0jjjjjjjB
The data index number indicates the first array number of the array from which transfer starts.
11.3.12 len : Data Length
Format: LSB 0lllllllB
MSB 0mmmmmmmB
The value of this field specifies the size of the parameter value stored in the data field. Data length indicates the length of the array being transferred minus 1 when the parameter contains a character string or other similar array structure.
11.3.13 data : Parameter Data
Single Parameter Data Size Limit Under the Instrument’s System Exclusive message format, the
size of a single message cannot exceed 48 bytes in all other cases. The data size and the array size, however, can cause a packet to exceed 48 bytes when transferring a single parameter array. In this case, the IPS and IPR message data length and data index number values can be modified to enable division of a single parameter value into multiple messages so it can be sent that way.
25
11.3.14 EOX : End of System Exclusive Message
Format: 11110111B (F7H)
This is the End of System Exclusive Message status byte established by the MIDI standard.
12 Parameter Op erations
There are two parameter unit operations: Individual Parameter Transfer and Individual Parameter Request. For one session, in response to an IPR (Individual Parameter Request) from an external device, this Instrument returns an IPS (Individual Parameter Send) or the session is concluded when the external device or this Instrument spontaneously sends an IPS. If this Instrument received an IPS, the value of the applicable parameter is changed. Depending on the function of a parameter, Individual Parameter Send may be used to issue a command to the Instrument and Individual Parameter Request may be used to check Instrument status information.
Data Receiver Data Sender Operation
IPR Send Request(Optional)
IPS Data Transfer
26
Part V
Parameter List
This section explains the parameters that actually can be transferred by the Instrument.
13 Using the Parameter List
Parameter field
Shows the parameter name.
ID field
Shows the parameter ID as a hexadecimal number.
R/W field
Shows “R” to indicate that an IPR (Individual Parameter Request) read operation (Read) is possible or “W” to indicate that an IPS (Individual Parameter Send) write operation is possible.
Block field
Shows the bit field allocation of the block number. The bit field position is shown as a decimal format number.
Size field
Shows the parameter bit width as a decimal format value.
Array field
Shows the parameter array size as a hexadecimal value.
Min-Def-Max field
Shows the minimum value, default value, and maximum value for parameter acquisition as a hexadecimal value.
Description field
Explains the meaning of parameter values. Unless otherwise specified, setting values are all indi­cated in decimal format.
Note: Operation is not guaranteed for values other than those noted here.
14 System Parameter
These parameters make it possible for an external device to check the status of the Instrument and for an external device to command some operation of the Instrument.
14.1 System Information Parameter
This parameter is a container for system information.
Parameter ID R/W Block Size Array Min-Def-Max Description
Model 0001 R 000000 7 01 00-00-7F 0...AP-700
1...GP-300
2...GP-400
4...GP-500BP
27
15 Patch Parameter
The main function of patch parameters is to configure the settings of the sound source of a device.
15.1 Master Tune Parameter
These parameters configure the Master Tuning settings.
Parameter ID R/W Block Size Array Min-Def-Max Description
Master Fine Tune 0001 R/W 55-0:0 10 01 0000-0200-03FF -100 - 0 - +99.8(cent)(1unit=100/512cent) Master Coarse Tune 0002 R/W 7 01 00-40-7F -24 - 0 - +24(semitone)
15.2 System Chorus Parameter
These parameters are for configuring system chorus settings.
Parameter ID R/W Block Size Array Min-Def-Max Description Type 0050 R/W 7 01 00-02-0F (Note1) Rate 0051 R/W 7 01 00-03-7F 0-127 Depth 0052 R/W 7 01 00-13-7F 0-127 Feedback 0053 R/W 7 01 00-00-7F 0-127 Tone 0054 R/W 7 01 00-7F-7F 0-127
Note1: For information about the relationship between setting values and send/receive values, see Spec Number in “18.7 Chorus Type Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
15.3 System Reverb Parameter
These parameters are for configuring system reverb settings.
Parameter ID R/W Block Size Array Min-Def-Max Description
Type 0080 R/W 000000 7 01 00-13-1B (Note1) Time 0081 R/W 7 01 00-40-7F 0 - 127 Early Reflection 0082 R/W 7 01 00-40-7F 0 - 127 High Damp 0084 R/W 7 01 00-67-7F 0 - 127 Tone 0085 R/W 7 01 00-65-7F 0 - 127
Note1: For information about the relationship between setting values and send/receive values, see Spec Number in “18.6 Chorus Type Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
15.4 Portamento Parameter
These are tone portamento operation setting parameters.
Parameter ID R/W Block Size Array Min-Def-Max Description
Portamento Time 0064 R/W 55-0:0 7 01 00-00-7F 0 - 127 Potamento OnOff 0065 R/W 1 01 00-00-01 0...Off
1...On
28
16 Spec Parameter
These are system setting parameters.
Parameter ID R/W Block Size Array Min-Def-Max Description Tuning 0001 R/W 10 01 010B-0200-0303 -245 - 0 - +259 (415.5Hz -
Stretch Tune 0002 R/W 4 01 00-00-07 0...Default
Concert Play Volume 0015 R/W 7 01 00-7F-7F 0 - 127 Song Volume 0017 R/W 7 01 00-7F-7F 0 - 127 Audio Volume 0019 R/W 7 01 00-7F-7F 0 - 127 Transpose 0020 R/W 7 01 34-40-4C -12 - 0 - +12 Octave Shift 0021 R/W 7 01 3E-40-42 -2 - 0 - +2 Keyboard Channel 0023 R/W 7 01 00-00-0F 0 - 15 Local Control 0024 R/W 1 01 00-01-01 0...Off
Hall Simulator 003D R/W 4 01 00-06-0C 0 :OFF
Chorus 003F R/W 4 01 00-00-04 0 :OFF
Brilliance 0040 R/W 7 01 3D-40-43 -3 - 0 - +3 Hammer Response 0041 R/W 4 01 00-00-0B 0 :Default
Lid Simulator 0042 R/W 4 01 00-00-04 0...Default
Damper Resonance 0044 R/W 4 01 00-00-0B 0 :Default
Damper Noise 0045 R/W 4 01 00-00-0B 0 :Default
String Resonance 0046 R/W 4 01 00-00-0B 0 :Default
Open String Resonance 0047 R/W 4 01 00-00-0B 0 :Default
Aliquot Resonance 0048 R/W 4 01 00-00-0B 0 :Default
Pedal Action Noise 0049 R/W 4 01 00-00-0B 0 :Default
Key On Action Noise 004A R/W 4 01 00-00-0B 0 :Default
440.0Hz - 465.9Hz)
1...Upper1
2...Off
3...Piano1
4...Piano2
5...Piano3
6...E.Piano1
7...E.Piano2
1...On
(Note1)
(Note2)
1 :OFF
2 11 :Type1-10
1...Closed
2...Semi Open
3...Full Open
4...Lid removed
1 :OFF
2 11 :Type1-10
1 :OFF
2 11 :Type1-10
1 :OFF
2 11 :Type1-10
1 :OFF
2 11 :Type1-10
1 :OFF
2 11 :Type1-10
1 :OFF
2 11 :Type1-10
1 :OFF
29
Parameter ID R/W Block Size Array Min-Def-Max Description
2 11 :Type1-10
Key Off Aciton Noise 004B R/W 4 01 00-00-0B 0 :Default
1 :OFF
2 11 :Type1-10
Half Pedal Position 004C R/W 7 01 3E-40-42 -2 - 0 - +2 Volume Sync EQ 004D R/W 4 01 00-02-03 0...OFF
1...Weak
2...Normal
3...Strong
HeadPhone Mode 004E R/W 4 01 00-01-01 0...OFF
1...ON
High Reso Velocity Enable 005A R/W 1 01 00-01-01 0...Off
1...On
Temperament Type 005B R/W 5 01 00-00-10 0 - 16 Temperament Base Note 005C R/W 4 01 00-00-0B 0 - 11 :C - B
Note1: For information ab out the relationship between setting values and types, see “18.6 Reverb Type Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document. This Instrument treats a hall simulator as a reverb.
Note2: For information about the relationship between setting values and types, see “18.7 Chorus Type Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
30
Part VI
DSP Parameter List
17 Tone with DSP List
This is a list of tones that use DSP.
Tone Number Tone Name
1 BERLIN GRAND 2 BERLIN GRAND MELLOW 3 BERLIN GRAND BRIGHT 4 HAMBURG GRAND 5 HAMBURG GRAND MELLOW 6 HAMBURG GRAND BRIGHT 7 VIENNA GRAND 8 VIENNA GRAND MELLOW
9 VIENNA GRAND BRIGHT 12 GRAND PIANO JAZZ 16 60’s PIANO 18 VIBRAPHONE 22 JAZZ ORGAN 23 ELECTRIC ORGAN 1 24 ELECTRIC ORGAN 2
31
Part VII
Setting Values and Send/ Receive Values
18 Setting Value Tables
18.1 Off/On Setting Value Table
Transmit Value Receive Value Parameter
00H 00H - 3FH Off
7FH 40H - 7FH On
18.2 Sustain Pedal Setting Value Table
Transmit Value Receive Value Parameter
00H 00H Off
: : (continuous)
7FH 7FH Full
18.3 –64 - 0 - +63 Setting Value Table
Transmit Value Receive Value Parameter
00H 00H -64
: : :
40H 40H 0
: : :
7FH 7FH +63
18.4 Pan Setting Value Table
Transmit Value Receive Value Parameter
00H 00H Left
: : :
40H 40H Center
: : :
7FH 7FH Right
32
18.5 Fine Tuning Setting Value Table
Transmit Value Receive Value Parameter
(LSB, MSB)
(43H, 00H) (00H, 00H) - (5FH, 00H) 415.5 Hz
(65H, 00H) (60H, 00H) - (7FH, 00H) 415.6 Hz
(07H, 01H) (00H, 01H) - (1FH, 01H) 415.7 Hz
(29H, 01H) (20H, 01H) - (3FH, 01H) 415.8 Hz
: : :
(40H, 3FH) (30H, 3FH) - (4FH, 3FH) 439.8 Hz
(60H, 3FH) (50H, 3FH) - (6FH, 3FH) 439.9 Hz
(00H, 40H) (70H, 3FH) - (1FH, 40H) 440.0 Hz
(20H, 40H) (20H, 40H) - (3FH, 40H) 440.1 Hz
(40H, 40H) (40H, 40H) - (5FH, 40H) 440.2 Hz
: : :
(54H, 7EH) (50H, 7EH) - (6FH, 7EH) 465.6 Hz
(73H, 7EH) (70H, 7EH) - (0FH, 7FH) 465.7 Hz
(11H, 7FH) (10H, 7FH) - (2FH, 7FH) 465.8 Hz
(30H, 7FH) (30H, 7FH) - (7FH, 7FH) 465.9 Hz
18.6 Reverb Type Setting Value Table
Transmit Value Receive Value Parameter Spec Number
10H 10H N.Y.Club 3
11H 11H Scoring Stage 4
12H 12H Dutch Church 5
13H 13H Standard Hall 6
14H 14H Opera Hall 7
15H 15H Viennese Hall 8
16H 16H L.A.Hall 9
17H 17H Berlin Hall 10
18H 18H French Cathedral 11
19H 19H British Stadium 12
1AH 1AH Room 1
1BH 1BH Salon 2
18.7 Chorus Type Setting Value Table
Transmit Value Receive Value Parameter Spec Number
00H 00H Light Cho 1
02H 02H Chorus 2
0AH 0AH Deep Chorus 3
0BH 0BH Flanger 4
33
Part VIII
MIDI Implementation Notation
19 Value Notation
19.1 Hexadecimal Notation
MIDI implementation sometimes requires that data be expressed in hexadecimal format. Hexadecimal values are indicated by the letter “H” after the value. The hexadecimal equivalents of decimal values 10 through 15 are expressed as the letters A through F.
The table b elow shows the hexadecimal equivalents for decimal values 0 through 127, which are often
used in MIDI messages.
Decimal Hexadecimal Decimal Hexadecimal Decimal Hexadecimal Decimal Hexadecimal
0 00H 32 20H 64 40H 96 60H 1 01H 33 21H 65 41H 97 61H 2 02H 34 22H 66 42H 98 62H 3 03H 35 23H 67 43H 99 63H 4 04H 36 24H 68 44H 100 64H 5 05H 37 25H 69 45H 101 65H 6 06H 38 26H 70 46H 102 66H 7 07H 39 27H 71 47H 103 67H 8 08H 40 28H 72 48H 104 68H
9 09H 41 29H 73 49H 105 69H 10 0AH 42 2AH 74 4AH 106 6AH 11 0BH 43 2BH 75 4BH 107 6BH 12 0CH 44 2CH 76 4CH 108 6CH 13 0DH 45 2DH 77 4DH 109 6DH 14 0EH 46 2EH 78 4EH 110 6EH 15 0FH 47 2FH 79 4FH 111 6FH 16 10H 48 30H 80 50H 112 70H 17 11H 49 31H 81 51H 113 71H 18 12H 50 32H 82 52H 114 72H 19 13H 51 33H 83 53H 115 73H 20 14H 52 34H 84 54H 116 74H 21 15H 53 35H 85 55H 117 75H 22 16H 54 36H 86 56H 118 76H 23 17H 55 37H 87 57H 119 77H 24 18H 56 38H 88 58H 120 78H 25 19H 57 39H 89 59H 121 79H 26 1AH 58 3AH 90 5AH 122 7AH 27 1BH 59 3BH 91 5BH 123 7BH 28 1CH 60 3CH 92 5CH 124 7CH 29 1DH 61 3DH 93 5DH 125 7DH 30 1EH 62 3EH 94 5EH 126 7EH 31 1FH 63 3FH 95 5FH 127 7FH
34
19.2 Binary Notation
When a MIDI implementation data value is expressed in binary, the letter B(for Binary) is affixed
at the end of the value. The table below shows the binary equivalents for the decimal values 0 through 127, which are often used for settings.
Decimal Hexadecimal Binary
0 00H 00000000B
1 01H 00000001B
2 02H 00000010B
3 03H 00000011B
4 04H 00000100B
5 05H 00000101B
6 06H 00000110B
7 07H 00000111B
8 08H 00001000B
9 09H 00001001B 10 0AH 00001010B 11 0BH 00001011B 12 0CH 00001100B 13 0DH 00001101B 14 0EH 00001110B 15 0FH 00001111B 16 10H 00010000B
: :
125 7DH 01111101B 126 7EH 01111110B 127 7FH 01111111B
35
Loading...
