MA1201-EB
Operation Guide 5219 (OC)
About This Manual
Operations are performed using the watch’s crown, and the two buttons
indicated by the letters A and B in this manual.
Hand Functions
z Hour Hand
x Second Hand
c Minute Hand
v Upper Dial Hand: Indicates a time, in 24-hour format, depending on the
b Lower Dial Hand: Indicates the current day of the week.
n Day
This User’s Guide uses numbers shown above to identify watch hands and
indicators.
About the crown
Some of the operations of this watch are performed by pulling out the crown, while other operations are
performed by pushing the crown in.
Button operations may become disabled after you perform a crown operation. If this happens, rotate
x
the crown slightly. This should restore button operations.
current mode.
Congratulations upon your selection of this CASIO watch.
This watch does not have a city code that corresponds to the UTC offset of –3.5 hours. Because of
this, the radio-controlled atomic timekeeping function will not display the correct time for Newfoundland,
Canada.
Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss suffered by
you or any third party arising through the use of this product or its malfunction.
Things to check before using the watch
1. Hold down B at least two seconds to enter the Timekeeping Mode, and then observe the
ENGLISH
movement of the
Is the x Second Hand moving smoothly at one-second intervals?
Is the x Second Hand moving at two-second intervals
or is it stopped completely?
Power is low. Charge the watch by placing it in a
location where it is exposed to light. For details, see
“Charging the Watch” (page E-7).
2. Check the Home City.
Use the procedure under “To confi gure Home City settings” (page E-20) to confi gure your Home City.
Important!
Proper time calibration signal reception depends on correct Home City, time, and date settings in the
Timekeeping Mode. Make sure you confi gure these settings correctly.
Second Hand.
NO
YES
The watch is charged. For details about
charging, see “Charging the Watch”
(page E-7).
Go to step 2.
YES
NEXT
E-1
E-2
3. Set the current time.
x To set the time using a time calibration signal
See “To get ready for a receive operation” (page E-13).
x To set the time manually
See “Confi guring Current Time and Date Settings Manually” (page E-23).
The watch is now ready for use.
x
For details about the watch’s radio controlled timekeeping feature, see “Radio Controlled Atomic
Timekeeping” (page E-11).
E-4
E-29 Adjusting Home Positions
E-30 To adjust home positions manually
E-32 Troubleshooting
E-36 Specifi cations
Contents
E-2 About This Manual
E-3 Things to check before using the watch
E-7 Charging the Watch
E-10 To recover from the sleep state
E-11 Radio Controlled Atomic Timekeeping
E-13 To get ready for a receive operation
E-15 To perform manual receive
E-16 To check the result of the latest receive operation
E-16 To turn auto receive on and off
E-18 Mode Reference Guide
E-19 Timekeeping
E-20 Confi guring Home City Settings
E-20 To confi gure Home City settings
E-22 To switch between standard time and summer time manually
E-23 Confi guring Current Time and Date Settings Manually
E-23 To change the current time setting manually
E-25 To change the current date setting manually
E-27 Using the Stopwatch
E-27 To perform elapsed time measurement
Charging the Watch
The face of the watch is a solar panel that generates power from light. The generated power charges a
built-in rechargeable battery, which powers watch operations. The watch charges whenever it is exposed
to light.
Charging Guide
Warning!
Leaving the watch in bright light for charging can cause it to become quite hot. Take care when
handling the watch to avoid burn injury. The watch can become particularly hot when exposed to
the following conditions for long periods.
x
On the dashboard of a car parked in direct sunlight
Too close to an incandescent lamp x
Under direct sunlight x
Whenever you are not
wearing the watch, be sure
to leave it in a location where
it is exposed to light.
Best charging
x
performance is achieved
by exposing the watch to
light that is as strong as
possible.
When wearing the watch, makes
sure that its face is not blocked
from light by the sleeve of your
clothing.
The watch may enter a sleep
x
state (page E-10) if its face is
blocked by your sleeve even
only partially.
E-3
E-5
E-6
E-7
Operation Guide 5219 (OC)
x
x
@
x
x
x
x
+
6
B
@
Important!
x
Keep the watch in an area normally exposed to bright light when storing it for long periods. This helps
to ensure that power does not run down.
x
Storing the watch for long periods in an area where there is no light or wearing it in such a way that it is
blocked from exposure to light can cause power to run down. Make sure that the watch is exposed to
bright light whenever possible.
Power Levels
You can get an idea of the watch’s power level by observing the movement of
the
Second Hand in the Timekeeping Mode.
x
Second Hand is moving normally at one-second intervals, power is
If the
at Level 1.
If the
x
Second Hand is moving at two-second intervals, power is at Level 2,
which is quite low. Expose the watch to light as soon as possible so it can
charge (Low battery alert).
Level Hand Movement Function Status
1 Normal. All functions enabled
Second Hand moves at two-second
x
2
intervals.
Moves at two-second
intervals.
When power drops to Level 3, all settings (including timekeeping) will be cleared. Recharging the x
battery will reset all settings to their initial factory defaults.
E-8
Power Saving
Power Saving enters a sleep state automatically whenever the watch is left for a certain period in an area
where it is dark. The table below shows how watch functions are affected by Power Saving.
There actually are two sleep state levels: “second hand sleep” and “function sleep”.
x
Elapsed Time in Dark Operation
60 to 70 minutes (second hand sleep)
6 or 7 days (function sleep)
The watch will not enter a sleep state between 6:00 AM and 9:59 PM. If the watch is already in a sleep x
state when 6:00 AM arrives, however, it will remain in the sleep state.
The watch will not enter a sleep state while it is in the Stopwatch Mode. x
To recover from the sleep state
Move the watch to a well-lit area or press any button.
nn Day changes to 1 (home position).
xx Second Hand stopped.
3
zz Hour Hand and cc Minute Hand
stopped at 12 o’clock.
xx Second Hand only stopped at 12 o’clock, all other functions enabled
All functions, including timekeeping, disabled x
Internal timekeeping maintained x
Time calibration signal reception
disabled
All functions disabled
Power Recovery Mode
The watch is designed to go into a power recovery mode that stops hand operation temporarily whenever
power suddenly drops below a certain level due to continuous signal reception or other operations over a
short period. Note that all operations are disabled while the watch is in the power recovery mode.
The hands will move to the correct positions and the watch will resume normal operation after power
recovers (in about 15 minutes). Putting the watch in a location where it is exposed to light will help power
to recover sooner.
Charging Times
Exposure Level (Brightness)
Outdoor sunlight (50,000 lux) 8 minutes 3 hours 29 hours
Window sunlight (10,000 lux) 30 minutes 7 hours 108 hours
Window sunlight on cloudy day (5,000 lux) 48 minutes 11 hours 175 hours
Indoor fl uorescent lighting (500 lux) 8 hours 118 hours – – –
1 Approximate exposure each day to generate power for normal daily operation. *
2 Approximate exposure to take power up one level. *
The above times are for reference only. Actual times depend on lighting conditions.
x
For details about the operating time and daily operating conditions, see the “Power Supply” section of x
the Specifi cations (page E-36).
Daily
Operation *1
Level Change *2
Level 3 Level 2 Level 1
Radio Controlled Atomic Timekeeping
This watch receives a time calibration signal and updates its time setting accordingly. However, when
using the watch outside of areas covered by time calibration signals, you will have to adjust the settings
manually as required. See “Confi guring Current Time and Date Settings Manually” (page E-23) for more
information.
This section explains how the watch updates its time settings when the city code selected as the Home
City is in Japan, North America, Europe, or China, and is one that supports time calibration signal
reception.
If your Home City Code setting is this:
LONDON (LON), PARIS (PAR), ATHENS (ATH) Anthorn (England), Mainfl ingen (Germany)
HONG KONG (HKG) Shangqiu City (China)
TOKYO (TYO) Fukushima (Japan), Fukuoka/Saga (Japan)
NEW YORK (NYC), CHICAGO (CHI),
DENVER (DEN), LOS ANGELES (LAX),
ANCHORAGE (ANC), HONOLULU (HNL)
Important!
x HONOLULU (HNL) and ANCHORAGE (ANC) are quite far from the calibration
The areas covered by
signal transmitters, so certain conditions may cause reception problems.
The watch can receive the signal from the transmitter
located here:
Fort Collins, Colorado (United States)
E-9
E-10
Approximate Reception Ranges
The Anthorn signal is receivable
within this area.
E-12
UK and German Signals North American Signal
Anthorn
500 kilometers
1,500 kilometers
Mainfl ingen
Japanese Signals Chinese Signal
Fukushima
500 kilometers
Fukuoka/Saga
1,000 kilometers
2,000 miles
(3,000 kilometers)
600 miles
(1,000 kilometers)
Fort Collins
Changchun500 kilometers
1,500 kilometers
Signal reception may be diffi cult or even impossible under the conditions described below. x
Inside or among
buildings
What you should do next depends on whether you are using Auto Receive or Manual Receive.3.
Auto Receive: Leave the watch over night in the location you selected in step 2. See “Auto Receive” x
on page E-14 for details.
Manual Receive: Perform the operation under “To perform manual receive” on page E-15. x
Auto Receive
x
With Auto Receive, the watch performs the receive operation each day automatically up to six times (up
to fi ve times for the Chinese calibration signal) between the hours of midnight and 5 a.m. (according
to the Timekeeping Mode time). When any receive operation is successful, none of the other receive
operations for that day are performed.
When a calibration time is reached, the watch will perform the receive operation only if it is in the
x
Timekeeping Mode. The receive operation is not performed if a calibration time is reached while you
are confi guring settings.
E-14
Inside a vehicle Near household
appliances,
offi ce
equipment, or a
mobile phone
Near a
construction
site, airport, or
other sources of
electrical noise
Near hightension power
lines
Beijing
Shangqiu
Shanghai
Chengdu
Hong Kong
Among
or behind
mountains
Signal reception may not be possible at the distances noted below during certain times of the year or x
day. Radio interference may also cause problems with reception.
Mainfl ingen (Germany) or Anthorn (England) transmitters: 500 kilometers (310 miles)
−
Fort Collins (United States) transmitter: 600 miles (1,000 kilometers) −
Fukushima or Fukuoka/Saga (Japan) transmitters: 500 kilometers (310 miles) −
Shangqiu (China) transmitter: 500 kilometers (310 miles) −
As of December 2010, China does not use Daylight Saving Time (DST). If China does go to the x
Daylight Saving Time system in the future, some functions of this watch may no longer operate
correctly.
Using this watch in a country covered by a time calibration signal that is different from the countries it
x
supports may result in incorrect time indication due to local application of summer time, etc.
To get ready for a receive operation
Confi rm that the watch is in the Timekeeping Mode. If it isn’t, hold down 1. B at least two seconds to
enter the Timekeeping Mode.
Place the watch in a location where signal reception is good.2.
12 o’clock
or
To perform manual receive
In the Timekeeping Mode (page E-19), keep 1. A depressed (for about two seconds) as the
Second Hand goes through the following sequence.
x YES (or Y for some models) or NO (N) to indicate the last signal reception result, then to
Moves to
READY (R).
Second Hand indicates the operations the watch is currently performing.
The 2.
When the xx Second Hand is
pointed here:
READY (R) Watch is setting up for reception.
WORK (W) Reception is in progress.
YES (Y) Reception was completed successfully.
NO (N) Reception failed for some reason.
If signal reception is unstable, the x xx Second Hand may move between
WORK (W) and READY (R).
When the receive operation is successful, the watch adjusts the time
x
setting accordingly, and then resumes regular timekeeping. It does not
adjust the setting if the operation failed.
Note
To interrupt a receive operation and return to the Timekeeping Mode, press x
any button.
Position the watch as shown in the nearby illustration, x
with 12 o’clock pointed towards a window. Make sure
there are no metal objects nearby.
Signal reception normally is better at night.
x
The receive operation takes from two to seven minutes, x
but in some cases it can take as long as 14 minutes.
Take care that you do not perform any button operation
or move the watch during this time.
It means this:
E-11
E-13
E-15
Operation Guide 5219 (OC)
x
@
+@>B
z
v
b
b
*
x
x
z
b
@
+
6*B@
z
x
c
v
b
n
+6*@>B
*
x
@
x
@
To check the result of the latest receive operation
In the Timekeeping Mode, press A.
xx Second Hand will move to YES (Y) if the latest receive operation
The
was successful, or NO (N) if it was not. After about ten seconds, regular
timekeeping will resume.
You can return to the Timekeeping Mode manually by pressing
x A while
the
Second Hand is pointing to YES (Y) or NO (N).
Note
xx Second Hand will indicate NO (N) if you have adjusted the time or
The
date setting manually since the latest receive operation.
To turn auto receive on and off
YES (Y)
In the Timekeeping Mode, press 1. A.
Pull out the crown.2.
xx Second Hand will perform one full revolution and then stop at
The
either YES (Y) or NO (N) to indicate the current on/off setting.
Rotate the crown to move the 3.
To turn on auto receive, select x YES (Y).
To turn off auto receive, select x NO (N).
Second Hand to the setting you want.
Push the crown back in to return to the Timekeeping Mode.4.
NO (N)
E-16
Mode Reference Guide
Your watch has two “modes”. The mode you should select depends on what you want to do.
To do this: Enter this mode: See:
View the current time in your Home City and in one of 29 other cities x
around the globe
x
View the current date in the Home City
Confi gure Home City and daylight saving time (DST) settings x
Perform a time calibration signal receive operation x
Confi gure time and date settings manually x
Use the stopwatch to measure elapsed time Stopwatch Mode E-27
B
Timekeeping Mode
The hand indicates the day of the week
(SUN/MON/TUE/WED/THU/FRI/SAT).
B(Stopwatch reset to 00:00 or running.)
Timekeeping Mode E-19
Stopwatch Mode
Hand points to STW.
Radio-controlled Atomic Timekeeping Precautions
x
Strong electrostatic charge can result in the wrong time setting.
Even if a receive operation is successful, certain conditions can cause the time setting to be off by up x
to one second.
x
The watch is designed to update the date and day of the week automatically for the period from
January 1, 2000 to December 31, 2099. Updating of the date by signal reception will no longer be
performed starting from January 1, 2100.
If you are in an area where signal reception is not possible, the watch keeps time with the precision
x
noted in “Specifi cations” (page E-36).
The receive operation is disabled under any of the following conditions.
x
While power is at Level 2 or lower (page E-8) −
While the watch is in the power recovery mode (page E-9) −
While the watch is in the function sleep state (power saving, page E-10) −
Timekeeping
To enter the Timekeeping Mode, hold down B at least two seconds.
Hand Functions
z Hour Hand
x Second Hand
c Minute Hand
v Upper Dial Hand: Indicates the current hour in the Home City time in
b Lower Dial Hand: Indicates the current day of the week.
n Day
24-hour format.
E-17
x B at least two seconds to enter the Timekeeping Mode.
Hold down
E-18
Confi guring Home City Settings
The Home City is location where you will normally use the watch. You can choose from a selection of city
codes that represent 29 cities around the globe.
To confi gure Home City settings
Note
x
This watch does not have a city code that corresponds to Newfoundland.
TOKYO (TYO)
E-20
To switch between standard time and summer time manually
Switching between AUTO and STD
Press 3. A to move the short end of the
(or DST)
A1 sec
Switching between STD and DST
− STD is indicated, the watch will always show standard time
− DST is indicated, the watch will always show summer time
A
If
If
To switch from x STD or DST to AUTO, hold down A for about one second.
After the setting is way you want, push the crown back in.4.
E-22
Pull out the crown.1.
This will cause the x
currently selected Home City.
This indicates the city code setting mode.
x
If you do not perform any operation with the crown for about two x
minutes after pulling it out, crown operations will become disabled and
the hand will not move if you rotate the crown. If this happens, push the
crown back in and then pull it out again.
For details about city codes, see the “City Code Table” at the back of
x
this manual.
Rotate the crown to move the 2.
to select as your Home City.
Each time you select a city code, the
x
Lower Dial Hand and n Day move to the current time and date for
that city code.
Push the crown back in to return to the Timekeeping Mode.3.
Second Hand to move to the city code of the
Second Hand to the city code you want
Hour Hand, c Minute Hand,
Perform steps 1 and 2 under “To confi gure Home City settings” 1.
(page E-20).
Selecting a city code will cause the
x
Hand, and
current time for the selected city code.
If you will use the watch in a city that is not included in the
x
city code list, select a city code that is in the same time zone
as your city.
x
Displaying the Home City Settings screen will cause the
short end of the b Lower Dial Hand to move to AUTO (auto
switching), STD (standard time manual setting), or DST
(summer time manual setting).
Hold down 2. A for about one second until the short end of the
Lower Dial Hand moves to MNL (manual), and then moves
to STD or DST.
Upper Dial Hand to move automatically to the
If
− STD or DST is indicated, go directly to step 3 of this
procedure.
If
− AUTO is indicated, proceed to step 2.
Lower Dial Hand between STD and DST.
Hour Hand, c Minute
E-19
STD/DST Switching
You can select summer time or standard time independently for each city. The initial default setting for all
cities is AUTO.
Normally you should use the AUTO setting because it automatically switches between summer time
and standard time. You should change the setting to STD (standard time) or DST (summer time) in the
following cases.
When using the watch in a city not included in the City Code Table
−
When the switching dates in your location are different from those shown in the City Code Table −
Daylight Saving Time (DST)
Daylight Saving Time (summer time) advances the time setting by one hour from Standard Time.
Remember that not all countries or even local areas use Daylight Saving Time.
Note that you cannot switch between
x STD (standard time) and DST (daylight saving time) while UTC*
is selected as your Home City.
Coordinated Universal Time, the world-wide scientifi c standard of timekeeping. The reference point for *
UTC is Greenwich, England.
E-21
Confi guring Current Time and Date Settings Manually
You can confi gure current time and date settings manually when the watch is unable to receive a time
calibration signal.
To change the current time setting manually
Pull out the crown.1.
TOKYO (TYO)
x
This will cause the
currently selected Home City.
If you do not perform any operation with the crown for about two minutes
x
after pulling it out, crown operations will become disabled and the hand
will not move if you rotate the crown. If this happens, push the crown
back in and then pull it out again.
Change the Home City setting, if you want.2.
x
To change the Home City setting, perform step 2 under “To confi gure
Home City Settings” (page E-20).
Hold down 3. B for about two seconds. This will enter the time setting mode.
xx Second Hand will move to the 12 o’clock.
The
x B cycles between settings as shown
In the following steps, each press of
below.
Second Hand to move to the city code of the
E-23
Operation Guide 5219 (OC)
n
n
n
n
6
x
x
x
x
x
n
v
6
@>
n
v
b
x
z
x
c
v
b
b
* B
@+
>
c
x
x
b
B
+
x
n
@
6
@
c
c
v
x
Home city/DST
B
Hour/Minute Hour
B
BB
Year DayMonth
Rotate the crown to adjust the time (hour and minute) setting.4.
x
Rotating the crown three full consecutive turns clockwise will cause the
moving clockwise. Rotating the crown another three full consecutive turns clockwise will cause the
Minute Hand to start moving at high speed. To stop hand movement, press any button or rotate
the crown one full turn counterclockwise.
The
xv Upper Dial Hand is synchronized with the z Hour Hand.
When adjusting the setting, check to make sure that the x
a.m. time or p.m. time.
If you want to change the date setting at this time, press
x B and perform the procedure starting from
step 3 under “To change the current date setting manually” (page E-25).
After the settings are the way you want, push the crown back in to return to the Timekeeping Mode.5.
x
This causes timekeeping to resume with the
E-24
0
9
8
6
Setting the year (ones digit)
00
10
90
80
Setting the year (tens digit)
E-26
5070
60
1
57
Press 7. B. This will enter the year setting mode.
2
3
Rotate the crown to adjust the year setting.8.
4
After the settings are the way you want, push the crown back in to 9.
return to the Timekeeping Mode.
20
Note
The watch’s built-in full automatic calendar makes allowances for
x
different month lengths and leap years. Once you set the date, there
30
should be no reason to change it except after you have the watch’s
rechargeable battery replaced or after power drops to Level 3.
40
The xz Hour Hand will move to the number that represents the tens
digit of the year and the
that represents the ones digit. The
12 o’clock and stop there.
x B and
If you want to change the time setting at this time, press
then perform the procedure starting from step 4 under “To change
the current time setting manually” (page E-23).
x
This causes timekeeping to resume with the
starting from 12 o’clock.
The day of the week indicated by the
x
automatically in accordance with the date (year, month, and day).
Second Hand starting from 12 o’clock.
BB
Minute Hand to start
Upper Dial Hand correctly indicates an
Minute Hand will move to the number
Second Hand will move to
Second Hand
Lower Dial Hand changes
To change the current date setting manually
Pull out the crown.1.
x
This will cause the
the currently selected Home City.
Hold down 2. B for about two seconds.
The
xx Second Hand will move to 12 o’clock.
Press 3. B twice. This will enter the date setting mode.
xn Day will move slightly left and right to indicate the setting
The
mode.
Second Hand to move to the city code of
Rotate the crown to adjust the date setting.4.
Day stops moving, press B. This will enter the month
After the 5.
setting mode.
Feb
The
xx Second Hand will move to the currently selected month.
Oct
Nov
Dec
Jan
Rotate the crown to adjust the month setting.6.
Sep
Aug
Jul May
Setting the month
Jun
Mar
Apr
Using the Stopwatch
The stopwatch measures elapsed time and split times.
Hand Functions
z Hour Hand: Indicates the stopwatch minute count
x Second Hand: Indicates the 0.1-second count during stopwatch operation.
c Minute Hand: Indicates the stopwatch seconds count.
v Upper Dial Hand: Indicates the stopwatch minute count
b Lower Dial Hand: Short end points to STW.
To perform elapsed time measurement
Use the crown to enter the Stopwatch Mode, which causes the 1.
to STW.
Now you can perform either of following stopwatch operations.2.
A
Start Stop (Restart) (Stop) Reset
A A A B
(1 revolution = 60 minutes).
(1 revolution = 120 minutes).
Lower Dial Hand (short end) to move
E-25
E-27
Note
x
The Stopwatch Mode can indicate elapsed time up to 1 hour, 59 minutes, 59.9 seconds.
The nearby display illustration shows a stopwatch reading of 20 minutes, 45.10 seconds. x
The watch’s face is marked in 0.1-second units. x
An ongoing stopwatch operation will continue even if you pull out the crown. x
In the following cases, the hands of the watch are moving, so pressing x B will not perform a reset
operation.
While the hands are moving to elapsed timekeeping after you enter the Stopwatch Mode
−
While the watch is changing dates at midnight −
Once started, stopwatch timing continues until you press x A to stop it, even if you exit the Stopwatch
Mode to another mode and even if timing reaches the stopwatch limit defi ned above.
You can press
x A to start an elapsed time operation immediately after entering the Stopwatch Mode,
even if the watch’s hands are still moving to their initial Stopwatch Mode positions. Note, however, that
if the stopwatch was not reset after the last elapsed time operation, timing will restart from where it was
last stopped, and not from 12 o’clock.
The
xx Second Hand indicates the 0.1-second count for the fi rst 30 seconds of a stopwatch elapsed
time operation. After that, the hand stops at 12 o’clock, but 0.1-second timing continues internally after
the fi rst 30 seconds. The
E-28
Second Hand will jump to the current value whenever A (Stop) is pressed.
To adjust home positions manually
Hold down 1. B at least two seconds to enter the Timekeeping Mode.
Pull out the crown.2.
Keep 3. B depressed for more than seven seconds. This will cause the
Second Hand to perform one full revolution.
After about two seconds, the
x
about seven seconds, the
revolution. Keep B depressed until the
full revolution.
After the
x
you do, home position adjustment of all of the hands (but not the
will start automatically.
x
Home position adjustment is complete when all hands are at 12 o’clock.
If the x
hold down A for about two seconds to move it there.
To exit the home position adjustment operation and return to the
x
Timekeeping Mode, push the crown back in.
Second Hand completes its full revolution, release B. When
Upper Dial Hand is not pointing at 24, which is its home position,
Second Hand will start performing one full
Second Hand will move to 12 o’clock. After
Second Hand completes one
Day)
Adjusting Home Positions
Strong magnetism or impact can cause the hands and/or day setting to be off, even if the watch is able to
perform the signal receive operation.
Auto Home Position Adjustment
Auto correction of hand home positions corrects the hand position automatically.
Auto correction is performed in the Timekeeping Mode only. x
Auto correction corrects the positions of all hands. For the x
adjustment procedure under “To adjust home positions manually” (page E-30).
If the
x
Upper Dial Hand is 12 hours off of the current correct time, correct the setting using the
procedure under “To adjust home positions manually” (page E-30).
Auto correction of the
x
watch is in the sleep state (page E-10).
Manual Home Position Adjustment
Perform the procedure in this section if auto home position adjustment is not possible for some reason.
Hand home position adjustment is not required if the time and day settings are correct. x
Note
x
Any time after you enter the home position adjustment mode in step 2 of the following procedure, you
can return to the Timekeeping Mode by pushing the crown back in. In this case, any adjustments you
made before the watch returned to the Timekeeping Mode will be applied.
If you do not perform any operation with the crown for about two minutes after pulling it out, crown
x
operations will become disabled and hands will not move if you rotate the crown. If this happens, push
the crown back in and then pull it out again.
Lower Dial Hand is performed once a day in the middle of the night, while the
Press 4. B.
x
This enters the
Check the 5.
If the x 1 is not in the center of the n Day, rotate the crown to center it.
Rotating the crown three full consecutive turns clockwise will cause the x
Day to start changing in a forward direction (increment).
To stop x
Push the crown back in to return to the Timekeeping Mode.6.
x
This will cause the hands to return to their normal positions and resume
regular timekeeping. Wait until everything stops moving before performing
any other operation.
Day home position adjustment mode.
Day to confi rm that it is 1, which is its home position.
Day movement, press any button.
Day, you must perform the manual
E-29
E-30
E-31
Operation Guide 5219 (OC)
x
x
x
x
x
Troubleshooting
Hand Movement and Position
■ I lost track of what mode the watch is in.
Refer to “Mode Reference Guide” (page E-18). To return directly to the Timekeeping Mode, hold down B
at least two seconds.
■ The
Second Hand is moving at two-second intervals.
■ All the watch’s hands are stopped at 12 o’clock and none of the buttons work.
Power may be low. Expose the watch to light until the
second intervals (page E-8).
■ The hands of the watch suddenly start moving at high speed, even when I do not perform any
operation.
This could be due to any one of the following causes. In all cases, the hand movement does not indicate
malfunction, and should stop shortly.
The watch is recovering from a sleep state (page E-10).
x
The time setting is being adjusted following a successful auto time calibration signal receive operation x
(page E-11).
■ Hands suddenly stop moving. Button operation also is disabled.
The watch may be in the power recovery mode (page E-9). Do not perform any operation until the hands
return to their normal positions (in about 15 minutes). The hands should return to their correct positions
when normal operation returns. To help power recover, leave the watch in a location where it is exposed
to light.
E-32
Time Calibration Signal
The information in this section applies only when LONDON (LON), PARIS (PAR), ATHENS (ATH),
HONOLULU (HNL), ANCHORAGE (ANC), LOS ANGELES (LAX), DENVER (DEN), CHICAGO (CHI),
NEW YORK (NYC), HONG KONG (HKG), or TOKYO (TYO) is selected as the Home City. You need to
adjust the current time manually when any other city is selected as the Home City.
■ The
Second Hand indicates NO (N) when I check the result of the latest receive operation.
Possible Cause Remedy Page
You are wearing or moving the watch, or
x
performing a button operation during the signal
receive operation.
The watch is in an area with poor reception x
conditions.
You are in an area where signal reception is not
possible for some reason.
The calibration signal is not being transmitted for
some reason.
■ The current time setting changes after I set it manually.
You may have the watch confi gured for Auto Receive of the time calibration signal (page E-14), which will
cause the time to be adjusted automatically according to your currently selected Home City. If this results
in the wrong time setting, check your Home City setting and correct it, if necessary (page E-20).
Second Hand starts moving normally, at one-
Keep the watch in an area where reception
conditions are good while the signal receive
operation is being performed.
See “Approximate Reception Ranges”. E-12
Check the website of the organization that x
maintains the time calibration signal in your area
for information about its down times.
Try again later. x
E-13
—
■ The current time setting is off by hours.
x
Your Home City setting may be wrong. Check your Home City setting and correct it, if necessary (page
E-20).
■ The current time setting is off by one hour.
x
If you are using the watch in an area where time calibration signal reception is possible, see “To
confi gure Home City settings” (page E-20).
The period when summer time is applied in the location where you are using the watch may be
x
different from the period set for your currently selected Home City. Use the procedure under “To switch
between standard time and summer time manually” (E-22) to switch from AUTO to STD (for standard
time) or DST (for summer time).
■ The hands and/or day indications are off.
This could indicate that the watch has been exposed to magnetism or strong impact, which has caused
problems with proper hand and day alignment. Adjust the watch’s hand and day home position alignment
(page E-29).
Charging
■ The watch does not resume operation after I expose it to light.
This can happen after the power level drops to Level 3 (page E-8). Continue exposing the watch to light
until the
Second Hand starts moving normally (at one-second intervals).
The ■
Second Hand starts to move at one-second intervals, but then suddenly returns to moving
at two-second intervals.
The watch probably is not suffi ciently charged yet. Continue keeping it exposed to light.
E-33
■ The current time setting is off by one hour.
Possible Cause Remedy Page
The period when summer time is applied in the
location where you are using the watch may be
different from the period set for your currently
selected Home City.
Use the procedure under “To switch between
standard time and summer time manually” to switch
from AUTO to STD (for standard time) or DST (for
summer time).
E-22
■ Auto Receive is not performed or I cannot perform Manual Receive.
Possible Cause Remedy Page
The watch is in the Stopwatch Mode.
Your Home City setting is wrong.
There is not enough power for signal reception. Expose the watch to light to charge it. E-7
Auto Receive is not performed while the watch is
in the Stopwatch Mode. Hold down B at least two
seconds to enter the Timekeeping Mode.
Check your Home City setting and correct it, if
necessary.
E-18
E-11
E-20
■ Signal reception is being performed successfully, but the time and/or day is wrong.
Possible Cause Remedy Page
Your Home City setting is wrong.
The watch may have been exposed to magnetism
or strong impact, which has caused problems with
proper hand and day alignment.
Check your Home City setting and correct it, if
necessary.
Adjust the watch’s hand and day home positions. E-29
E-11
E-20
E-34
Specifi cations
Accuracy at normal temperature: ± 15 seconds a month (with no signal calibration)
Timekeeping (World time): Hour, minutes (hand moves every 10 seconds), seconds, 24-hour, day, day
Calendar system: Full Auto-calendar pre-programmed from the year 2000 to 2099
Other: Home City code (can be assigned one of 29 city codes and Coordinated Universal Time);
Daylight Saving Time (summer time) / Standard Time
Time Calibration Signal Reception: Auto receive up to six times a day (5 times a day for the Chinese
Receivable Time Calibration Signals:
Mainfl ingen, Germany (Call Sign: DCF77, Frequency: 77.5 kHz); Anthorn, England (Call
Sign: MSF, Frequency: 60.0 kHz); Fukushima, Japan (Call Sign: JJY, Frequency: 40.0
kHz); Fukuoka/Saga, Japan (Call Sign: JJY, Frequency: 60.0 kHz); Fort Collins, Colorado,
the United States (Call Sign: WWVB, Frequency: 60.0 kHz); Shangqiu City, Henan
Stopwatch: Measuring capacity: 1:59'59.9"
Other: Power Saving; Low battery alert; Auto Correction of Hand Home Positions
Power Supply: Solar panel and one rechargeable battery
E-36
Province, China (Call Sign: BPC, Frequency: 68.5 kHz)
Measuring unit: 0.1 seconds
Measuring mode: Elapsed time
Approximate battery operating time: 7 months (from full charge to Level 3)
under the following conditions:
Analog hands operational 18 hours per day, sleep state 6 hours per day
x
4 minutes of signal reception per day x
of the week
calibration signal; Remaining auto receives cancelled as soon as one is successful);
Manual receive
City Code Table
City Code City
PAGO PAGO (PPG) Pago Pago –11
HONOLULU (HNL) Honolulu –10
ANCHORAGE
LOS ANGELES
DENVER (DEN) Denver –7
CHICAGO (CHI) Chicago –6
NEW YORK (NYC) New York –5
SANTIAGO (SCL) Santiago –4
RIO Rio De Janeiro –3
F. DE NORONHA
UTC
LONDON (LON) London
PARIS (PAR) Paris +1
ATHENS (ATH) Athens +2
JEDDAH (JED) Jeddah +3 None None
TEHRAN (THR) Tehran +3.5
L-2
(ANC) Anchorage –9
(LAX) Los Angeles –8
(FEN)
Fernando de Noronha
UTC Offset/
GMT Differential
–2
0
2:00 a.m., second Sunday
Midnight, second Saturday
Midnight, third Sunday in
1:00 a.m., last Sunday
2:00 a.m., last Sunday
3:00 a.m., last Sunday
Midnight, March 22 or
Summer Time Period
Summer Time Start Summer Time End
None None
in March
in October
October
None NonePRAIA (RAI) Praia –1
in March
in March
in March
Midnight, March 21
2:00 a.m., fi rst Sunday in
November
Midnight, second Saturday
in March
Midnight,third Sunday in
February or Midnight,fourth
Sunday in February
2:00 a.m., last Sunday in
October
3:00 a.m., last Sunday in
October
4:00 a.m., last Sunday in
October
Midnight, September 22 or
Midnight, September 21
City Code Table
City Code City
DUBAI (DXB) Dubai +4 None None
KABUL (KBL) Kabul +4.5
KARACHI (KHI) Karachi +5
DELHI (DEL) Delhi +5.5
DHAKA (DAC) Dhaka +6
YANGON (RGN) Yangon +6.5
BANGKOK (BKK) Bangkok +7
HONG KONG
TOKYO (TYO) Tokyo +9
ADELAIDE (ADL) Adelaide +9.5
SYDNEY (SYD) Sydney +10
NOUMEA (NOU) Noumea +11 None None
WELLINGTON
x Based on data as of December 2010.
x The rules governing global times (UTC offset and GMT differential) and summer time are determined
by each individual country.
x The summer time periods in this table are applicable to specifi c cities. For cities not included in the
list, select the list city that is in the same time zone as the desired city and perform STD/DST settings
manually.
(HKG) Hong Kong +8
(WLG) Wellington +12
UTC Offset/
GMT Differential
2:00 a.m., fi rst Sunday in
2:00 a.m., last Sunday in
Summer Time Period
Summer Time Start Summer Time End
None None
October
September
3:00 a.m., fi rst Sunday
in April
3:00 a.m., fi rst Sunday
in April
E-35
L-1
L-3
Loading...
