Casio 2515 User Manual
MO0308-EA
Operation Guide 2515
About This Manual
• Button operations are indicated using the letters shown
in the illustration.
(Light)
• Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the “Reference” section.
General Guide
• Press B to change from mode to mode.
• In any mode, press L to illuminate the display.
Data Bank Mode
Timekeeping Mode
Press B.
▲
▲
Timekeeping
Day of week
PM indicator
3. When the setting you want to change is flashing, use E and D to change it as
Press E.
Press D.
4. Press A to exit the setting screen.
• The day of the week is automatically displayed in accordance with the date (year,
• See the “Day of the Week List” for information on abbreviations used.
• In addition to the day of the week display, the language setting also affects the type
• Holding down A in the Timekeeping Mode displays the indicator for the currently
To toggle between 12-hour and 24-hour timekeeping
In the Timekeeping Mode, press C to toggle between 12-hour timekeeping (indicated
by A or P on the display), or 24-hour timekeeping.
• With the 12-hour format, the P (PM) indicator appears on the display for times in the
• With the 24-hour format, times are displayed in the range of 0:00 to 23:59, without
• The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is
Hour : Minutes
Seconds
Year Month–Day
Language indicator
Seconds Year Month Day
• The currently selected language indicator flashes on the display while the
Language (setting) is selected in the above sequence.
described below.
To change this setting
Seconds
Year, Month, Day, Hour,
Minutes
Language
• While the language indicator is flashing on the display, use E and D to cycle
through the language indicators as shown below, until the one for the language
you want to select is displayed.
Indicator Language
ENx English
POR Portuguese
ESP Spanish
FRA French
NED Dutch
month, and day) settings.
of characters you can input for the name in the Data Bank Mode.
selected language. Keeping A depressed for one or two seconds changes to the
Timekeeping Mode setting screen (indicated by the seconds flashing). If you
accidentally display the setting screen, press A again to exit.
range of noon to 11:59 p.m. and the A (AM) indicator appears for times in the range
of midnight to 11:59 a.m.
any indicator.
applied in all modes.
Use the Timekeeping Mode to set the time and date. You
can also view the Dual Time Mode screen or Data Bank
Mode screen from the Timekeeping Mode.
Note
This watch is capable of displaying text for the day of the
week in any one of 13 different languages (English,
Portuguese, Spanish, French, Dutch, Danish, German,
Italian, Swedish, Polish, Romanian, Turkish, and Russian).
To set the time and date
1. In the Timekeeping Mode, hold down A until the
seconds start to flash, which indicates the setting
screen.
2. Use C and B to move the flashing in the sequence
shown below to select other settings.
Press C. Press B.
Minutes Hour Language
Perform this button operation
Press E to reset to 00.
Use E (+) and D (–) to change the setting.
Use E and D to change the language setting.
Indicator Language
DAN Danish
DEU German
ITA Italian
SVE Swedish
POL Polish
Indicator Language
RO Romanian
T)R Turkish
PUC Russian
Alarm Mode
▲
Stopwatch Mode
▲
▲
Dual Time Mode
Countdown Timer Mode
▲
Daylight Saving Time (DST)
Daylight Saving Time (summer time) advances the time setting by one hour from
Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
To toggle the Timekeeping Mode time between DST and Standard Time
To display the Data Bank screen and Dual Time screen in the Timekeeping Mode
Holding down D in the Timekeeping Mode displays the Dual Time screen. Holding
down E displays the record you were viewing when you last used the Data Bank
Mode.
Dual Time Screen Data Bank Screen
Holding down C for about two seconds in the
Timekeeping Mode toggles between Daylight Saving Time
(DST display) and Standard Time (DST not displayed).
• Note that pressing C in the Timekeeping Mode also
toggles between 12-hour timekeeping and 24-hour
timekeeping.
• The DST indicator appears on the display to indicate
that daylight saving time is turned on.
Hold down D. Hold down E.
Data Bank
Remaining
memory
Telephone number
To create a new Data Bank record
Name area
Number area
New Data Screen
Press E.
Press D.
• The above character sequence is for English input. See “Character List” for the
character sequences of other languages.
4. When the character you want is at the cursor position, press C to move the cursor
to the right.
5. Repeat steps 3 and 4 until the name is complete.
• You can input up to eight characters for the name.
The Data Bank Mode lets you store up to 30 records,
each containing name and telephone number data.
Records are automatically sorted based on the characters
of the name. You can recall records by scrolling through
Name
them on the display.
• The characters you can input for the name depend on
the language you select in the Timekeeping Mode. See
“To set the time and date” for more information.
Changing the language setting does not affect names
that are already stored.
• See “Sort Table” for details on how the watch sorts
records.
• All of the operations in this section are performed in the
Data Bank Mode, which you enter by pressing B.
1. In the Data Bank Mode, press C to display the new
data screen.
• If the new data screen does not appear when you
press C, it means that memory is full. To store
another record, you will first have to delete some of
the records stored in memory.
2. Hold down A until the flashing cursor (_) appears in
the name area of the display.
3. In the name area, use E and D to cycle through
characters at the cursor position. The characters cycle
in the sequence shown below.
(space)
A to Z
(alphabet)
@ to -
(symbol)
0 to 9
(number)
1
Operation Guide 2515
6. After you input the name, press C as many times as necessary to move the cursor
to the number area.
• When the cursor is located at the eighth space of the name area, moving the
cursor to the right causes it to jump to the first digit of the number. When the
cursor is at the 15th digit of the number, moving it to the right (by pressing C)
causes it to jump to the first character in the name.
• Pressing C moves the cursor the right, while B moves it to the left.
7. In the number area, use E and D to cycle through numbers and symbols
(hyphen, brackets, space) at the cursor position. The characters cycle in the
sequence shown below.
Press E.
Press D.
8. When the character you want is at the cursor position, press C to move the cursor
to the right.
9. Repeat steps 7 and 8 until you complete number input.
• You can input up to 15 digits for the number.
• The number initially contains all hyphens. You can leave the hyphens as they are
or replace them with numbers or other symbols (brackets, space).
10. Press A to store your data and return to the Data Bank record screen (without
the cursor).
• When you press A to store data, the name and number you input flash for about
one second as Data Bank records are sorted. After the sort operation is complete,
the Data Bank record screen appears.
• The name can show only three characters at a time, so longer text scrolls
continuously from right to left. The last character is indicated by the symbol
To recall Data Bank records
In the Data Bank Mode, use E (+) and D (–) to scroll through Data Bank records on
the display.
• Pressing E while the last Data Bank record is on the display or D while the first
record is on the display displays the new data screen.
To edit a Data Bank record
1. In the Data Bank Mode, use E (+) and D (–) to scroll through the records and
display the one you want to edit.
2. Hold down A until the flashing cursor appears on the display.
3. Use C (right) and B (left) to move the flashing to the character you want to
change.
4. Use E (forward) and D (back) to change the character.
5. After making the changes that you want, press A to store them and return to the
Data Bank record screen.
To delete a Data Bank record
1. In the Data Bank Mode, use E (+) and D (–) to scroll through the records and
display the one you want to delete.
2. Hold down A until the flashing cursor appears on the display.
3. Press B and C at the same time to delete the record.
• The message
record is deleted, the cursor appears on the display, ready for input.
4. Input data or press A to return to the Data Bank record screen.
CLR appears to indicate that the record is being deleted. After the
0 to 9
x
[ ]
(space)
after it.
Alarms
Alarm number
Alarm time
(Hour : Minutes)
Timekeeping
Mode time
Alarm Types
The alarm type is determined by the settings you make, as described below.
• Daily alarm
Set the hour and minutes for the alarm time. This type of setting causes the alarm to
sound everyday at the time you set.
• Date alarm
Set the month, day, hour and minutes for the alarm time. This type of setting causes
the alarm to sound at the specific time, on the specific date you set.
• 1-Month alarm
Set the month, hour and minutes for the alarm time. This type of setting causes the
alarm to sound everyday at the time you set, only during the month you set.
• Monthly alarm
Set the day, hour and minutes for the alarm time. This type of setting causes the alarm
to sound every month at the time you set, on the day you set.
To set an alarm time
Alarm date
(Month–Day)
Alarm number
You can set up to five independent multi-function alarms
with hour, minutes, month, and day. When an alarm is
turned on, the alarm tone sounds when the alarm time is
reached. You can select either a one-time alarm or snooze
alarm that repeats up to seven times, every five minutes.
You can also turn on an Hourly Time Signal that causes
the watch to beep twice every hour on the hour.
• There are five alarms numbered1 through 5. You can
configure Alarm1 as a snooze alarm or a one-timealarm. Alarms 2 through 5 can be used as one-time
alarms only.
• Alarm settings (and Hourly Time Signal settings) are
available in the Alarm Mode, which you enter by
pressing B.
1. In the Alarm Mode, use E and D to scroll through the
alarm screens until the one whose time you want to set
is displayed.
Press E. Press D.
Alarm1 Alarm 2 Alarm 3
Time
Signal
• Each of the five alarm screens has an alarm number.
The hourly time signal screen does not have an alarm
number.
2. After you select an alarm, hold down A until the hour
setting of the alarm time starts to flash, which indicates
the setting screen.
• This operation automatically turns on the alarm.
Alarm 5 Alarm 4
3. Use C and B to move the flashing in the sequence shown below to select other
settings.
Press C.
Press B.
4. While a setting is flashing, use E (+) and D (–) to change it.
• To set an alarm that does not include a month (Daily alarm, Monthly alarm), set x
for the month. Use E and D until the x mark appears (between 12 and 1) while
month setting is flashing.
• To set an alarm that does not include a day (Daily alarm, 1-Month alarm), set xx
for the day. Use E and D until the xx mark appears (between the end of the
month and 1) while the day setting is flashing.
• When setting the alarm time using the 12-hour format, take care to set the time
correctly as a.m. (A indicator) or p.m. (P indicator).
5. Press A to exit the setting screen.
Alarm Operation
The alarm tone sounds at the preset time for 10 seconds, regardless of the mode the
watch is in. In the case of the snooze alarm, the alarm repeats up to seven times
every five minutes until you turn the alarm off or change it to a one-time alarm.
• Pressing any button stops the alarm tone operation.
• Any time you display the setting screen while the Alarm1 screen is on the display,
Alarm1 automatically becomes a one-time alarm.
• Displaying the Timekeeping Mode setting screen during a 5-minute interval between
snooze alarms stops the current snooze alarm operation (but snooze alarm remains
as the alarm type setting).
To test the alarm
In the Alarm Mode, hold down C to sound the alarm.
Hour
To turn Alarms 2 through 5 and the hourly time signal on and off
Alarm on indicators
Hourly time signal
on indicator
To select the operation of Alarm
1. In the Alarm Mode, use E and D to select Alarm1.
2. Press C to cycle through the available settings in the sequence shown below.
Press C.
• The SNZ indicator and Alarm1 on indicator are displayed in all modes.
• The SNZ indicator flashes during the 5-minute intervals between alarms.
• The alarm indicator (Alarm1 on and/or SNZ) flashes while the alarm is sounding.
SNZ indicator and Alarm1 on indicator
Minutes
1. In the Alarm Mode, use E and D to select a one-time
alarm (alarm number 2 through 5) or the Hourly Time
Signal.
2. Press C to toggle it on and off.
• The on/off status of Alarms 2 through 5 is shown by
indicators along the bottom of the displays (
The SIG indicator shows the on (displayed)/off (not
displayed) status of the hourly time signal.
• The alarm on indicators and hourly time signal indicator
are displayed in all modes.
• While an alarm is sounding, the applicable alarm on
indicator flashes on the display.
Month Day
= on).
1
Snooze alarm onOne-time alarm on
Alarm off
Stopwatch
Minutes
Hours
Seconds
Timekeeping
Mode time
1/100 second
To measure times with the stopwatch
Elapsed Time
C
Start Stop
Split Time
C
Start Split
Two Finishes
C
Start Split
The stopwatch lets you measure elapsed time, split times,
and two finishes.
• The display range of the stopwatch is 23 hours, 59
minutes, 59.99 seconds.
• The stopwatch continues to run, restarting from zero
after it reaches its limit, until you stop it.
• The stopwatch measurement operation continues even
if you exit the Stopwatch Mode.
• Exiting the Stopwatch Mode while a split time is frozen
on the display clears the split time and returns to
elapsed time measurement.
• All of the operations in this section are performed in the
Stopwatch Mode, which you enter by pressing B.
C
➤
A ➤
➤
(SPL displayed)
A ➤
➤
First runner
finishes.
Display time of
first runner.
C
➤
Re-start Clear
A
Split release
C
Stop
Second runner
finishes.
C
➤
Stop
C
➤
Stop
A ➤
➤
Split release
Display time of
second runner.
➤
➤
A
A
Clear
A
Clear
2
Loading...
