Casella Apex2, Apex2 PLUS, Apex2 PRO Field Manual

Page 1
FIELD GUIDE for Apex2™
Personal Sampling Pump
This field guide is to familiarise you and get you started with the Apex2TM Personal Air Sampling Pump range. We recommend that to get the best from your purchase, you refer to the full handbook which can be downloaded from the support section of our website;
downloaded from our website.
The Apex2™ Personal Sampling Pump is available in one of three models with the following functionality.
Page 2
Charging the Apex2™
Docking Stations are used to support both battery charging and USB data downloading (in Plus and Pro Models). The single way docking station is powered from a PC18 12 volt mains power adapter, the five way version uses a PC28 adapter.
Please note that in the five-way docking station only the first ‘pocket’ can be used for USB download of run data and is indicated by the symbol
USB to P.C
for Download
To 12V Power
Adapter
Charging commences when an Apex2 is placed in the docking station, the pumps display will show a battery charging icon plus the batteries percentage state of charge. The display may blank after the user selected display timeout period however the red LED will flash continuously during the entire charging cycle. Pressing the power
button will ‘wake’ the display such that the charging progress can be checked. Once fully charged, a solid Blue LED will be shown.
Typical charge time from empty to full is approximately 6 hours. Shorter charge times will result in a reduced pro-rata run time.
Page 3
Switching the Apex2 On and Off
To switch the Apex2™ on, press the on/off key . At power up, the pump will display the
start-up screens followed by the Stop mode screens detailing the last run data.
To power off the Apex2 from any screen when the pump is not running, press and hold the
key for 3 seconds. Countdown screens will be displayed:-
Key Lock Modes
The Apex2 can be set to operate in Partial Lock or Fully Locked modes:
Whilst pressing and holding the Up <> key, press the enter key < > 3 times in quick succession to toggle between the different ‘LOCK’ options.
Partial lock is identified by the open padlock and may be activated in both Run or Stop modes. In the partial Lock mode the wearer may only start or stop a sampling run but cannot access other menus or functions. The wearer is prevented from resetting values or changing the flow rate.
Full lock mode can only be activated once the pump is already sampling in a run mode and is identified by a closed padlock icon. In Full lock mode the keypad is fully de­activated until it is unlocked again. The wearer cannot stop the pump.
Page 4
Warning Messages
The following warning messages are displayed at power up, if relevant. Any key press clears the message.
The following error messages may be displayed for other faults during normal sampling applications:-
Blockage Retry: If the pump cannot maintain the target flow rate within 5% for more than 20 seconds (due to say a kinked tube or inlet blockage) then it will automatically halt sampling. After one minute the pump will attempt to re-start. If the specified number of attempts to retry is unsuccessful, the pump will terminate the current sampling run.
The Dashboard Display Screens
The Run or Stop Mode ‘dashboard’ displays show data from either the previous or the current run. The screen title bars are colour coded; red for ‘stopped’ and green for when the pump is running. They detail:
Battery Life, either % or estimated hours (in Plus & Pro)
Back Pressure
Motion %
Flow rate
Volume
Elapsed Duration of run
Page 5
The Main Menu
To access the main menu press the Down key <> once from a Stop mode screen. Once in the menu use the <> <> to scroll through the options and < > to accept the selected option.
This option will ‘Start’ the pump run at the specified flow rate.
The ‘Reset’ option clears accumulated sample volume and duration data to zero in preparation for a new Run.
Specify the target flow rate using the <> <> keys and press < > to accept
To perform a single point calibration, attach a sampling head and flow tube or other flow-measuring device to the pump’s inlet nozzle then select the Calibrate option to accurately set the flow, adjust the flow using the <> <> keys.
Stopping and Pausing a Sampling Run
To Stop or Pause a sampling run press and hold the Enter key < > for the duration of the countdown screens. To exit the STOP operation release the Enter < > key any time during the countdown.
Page 6
Timers (Plus and Pro Models Only)
To use the timers, ensure ‘Advanced mode’ has been activated within the power up ‘Settings’ menu.
Run Duration Timer
(Plus and Pro Models)
The Run Duration timer allows the pump to sample for a fixed period and switch off automatically when that time has elapsed. (Plus and Pro Models)
Programmable ‘Sequence’ Timer
(Pro Models Only)
The programmable ‘sequence’ timer enables up to 9 ‘on’ and ‘off’ events to be set in sequence; for instance a daily or weekly timer setup may be defined such that sampling will pause during a workers breaks or lunch time etc. After activating the sequence timer, the pump will go to sleep until the next sample ‘on’ time and day has been reached. Timer sequence is defined within the power-up ‘Settings’ menu.
TWA (Time Weighted Average) Mode
(Pro Models Only)
Time weighted average (TWA) mode allows the pump to sample for a fixed proportion of time over a specified total run time. The instrument calculates the required ON/OFF cycle to automatically spread the required sample exposure time evenly over the entire run time. In this example, the pump will run for 1 minute and stop for 1 minute, this will continue for 8 hours.
Page 7
Power-Up Configuration Menu
To access the Settings menus, press and hold the Up <> and Enter < > keys immediately following power up.
Scroll through the items until the desired function is highlighted and accept with the Enter < > key. Use the scroll keys <> and <> again within the function to choose the desired option and confirm with the Enter < > key.
Select the displayed units for Temperature and inlet Pressure measurements.
To maximise battery run time it is recommended that the display is blanked during the sample run. The Display timeout option specifies how long the display remains visible. Press any key to wake the display
In application environments sensitive to Radio transmissions (Medical, Military etc. The Bluetooth radio maybe fully disabled.
For maximum simplicity, operate the pump with Advanced mode off. Advanced mode enables additional menus providing access to the Timer modes and TWA functionality.
The information screen displays the pumps serial number and firmware revision.
Page 8
App for your mobile device
The Airwave™ App can be downloaded from www.casellasolutions.com for your Android
mobile device. Ensure the Bluetooth® is enabled on the pump. Tap the icon on your mobile device to open the App.
From the Dashboard view, ‘tap’ a specific instrument to initiate a direct connection with that instrument.
Whilst connected to an instrument a comprehensive set of measurement results will be displayed.
To Start and Stop an Instrument, touch and hold the appropriate icon in the lower part of the mobile device’s display for 3 seconds.
The dashboard shows the operating status plus the vital measurement results from all the instruments in range. The dashboard provides a condensed ‘snap shot’ of the instrument’s vital measurement data and status.
The MENU contains a number of options to facilitate the convenient transfer of the measurement results via the device’s email or clipboard services.
Email run data alongside photos and notes direct to your laptop.
Page 9
Data Download Utility
This downloads run data from the Apex2 into an Excel compatible format to allow you to collate data for your reports. Place your Apex2 in the docking station in the pocket with the
symbol.
The Download Utility can be found on our website at:
http://www.casellasolutions.com/support/software
Maintenance
Make sure the battery pack never stays in a fully discharged condition for extended durations.
Do not operate without an inlet filter. Ingested dirt and dust particles may cause internal damage, malfunction or erratic flow.
Replace the inlet filters regularly.
Keep the instrument body clean
Service
Casella’s in house service department offers a comprehensive range of repair and calibration services designed to maintain a fast and efficient back-up for all our products. The Service Department is operated under the scope of our BSI registration for products manufactured by us. We will however, undertake the repair of other manufacturer’s equipment.
For further information please contact our service department at our UK headquarters
salessupport@casellasolutions.com or via approved servicing distributors. We will be happy
to provide quotations for individual repairs or provide annual maintenance under contract.
Page 10
Casella Contact Details:-
UK: info@casellasolutions.com
USA: info@casellaUSA.com
China: info@casellasolutions.cn
India: Casella.sales@ideal-industries.in
For more information or to find out more about Casella and our products, please visit our website at:
http://www.casellasolutions.com
Apex2 Field Guide
FG66-00.05 English
June 2015
